3-BUTTON REMOTE CONTROLS
MODELS 890MAX, 893MAX, AND 895MAX
To prevent possible SERIOUS INJURY or
DEATH from a moving gate or garage door:
• ALWAYS keep remote controls out of
reach of children. NEVER permit children
to operate or play with remote controls.
• Activate gate or door ONLY when it can be
seen clearly, is properly adjusted and there
are no obstructions to door travel.
• ALWAYS keep gate or garage door in sight
until completely closed. NEVER permit
anyone to cross path of moving gate or
door.
LED
LED
Locate the Program button on
the remote control.
Locate the Learn
button on the garage
door opener.
NOTE: Your garage door
opener may look different.
OR OR
Learn
LED
Learn
LED
Learn
LED
Green
or
Red/Orange Purple
Yellow
Program Button
23Press and release the remote control button
you want to use...
4To exit programming mode, press
any remote control button except
the button that was just programmed.
Install the visor clip (not
applicable for Model 890MAX).
6
The garage door opener
will activate.
To test, press the programmed button on
the remote control...
1Press and release the
Learn button on the
garage door opener.
Within 30 seconds...
The Learn LED will light.
Check to see if the garage
door opener light bulb
blinks.
If not, wait for the remote
control LED to light solid
then slowly press and
release the remote
control button again.
Repeat until the
light bulb blinks.
DO NOT press the
button after the light
bulb blinks.
5
To enter programming mode, press the Program button
until the LED on the front of the remote control turns on.
Safety Pin or
Paper Clip
Visor Clip
MODEL 893MAX
MODEL 890MAX
PREPARE
PROGRAMMING THE REMOTE CONTROL
893MAX
890MAX
MODEL 895MAX
895MAX
LEDs
890MAX
895MAX
893MAX
Can be used as a replacement remote control for 80
Series, 970 Series, and 370 Series LiftMaster remote
controls.
Compatible with 315 MHz or 390 MHz garage door
openers manufactured after January 1, 1993. Make
sure the garage door opener has a working light bulb
because it is a programming indicator.
For use with gate operators, commercial door
operators, or other products that are 315 MHz or 390
MHz and have a Learn button. Refer to your product
manual for the location of the Learn button.
NOTICE: To comply with FCC and or Industry Canada rules (IC),
adjustment or modifications of this receiver and/or transmitter
are prohibited, except for changing the code setting or replacing
the battery. THERE ARE NO OTHER USER SERVICEABLE
PARTS.
Tested to Comply with FCC Standards for Home or office use.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
BATTERY
The LED(s) on your remote control will stop flashing when the battery is low and needs to be
replaced. To replace battery, open the case as shown. Insert battery positive side up (+). Replace
the battery with only 3V2032 or 3V2016 coin cell batteries (depending on the model). Dispose of
old battery properly. To prevent possible SERIOUS INJURY or
DEATH:
• NEVER allow small children near batteries.
• If battery is swallowed, immediately notify
doctor.
To reduce risk of fire, explosion or chemical
burn:
• Replace ONLY with 3V2032 coin batteries.
• DO NOT recharge, disassemble, heat
above 212° F (100° C) or incinerate.
1-800-528-9131
114A3930 © 2011, The Chamberlain Group, Inc.
All Rights Reserved
REPLACEMENT PARTS
3V2032 Lithium Battery (Models 893MAX & 890MAX) . . . . . . . . . . 10A20
3V2016 Lithium Battery (Model 895MAX) . . . . . . . . . . . . . . . . . . . . 10A19
Visor Clip (Model 893MAX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29B137
Visor Clip (Model 895MAX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29C151
1
2
3
WARRANTY
www.liftmaster.com
ONE YEAR LIMITED WARRANTY
The Chamberlain Group, Inc. warrants to the first consumer purchaser
of this product that it is free from defect in materials and/or
workmanship for a period of 1 year from the date of purchase.
Pry open the case with a
screwdriver blade.
890MAX
Pry open the case fi rst in the
middle (1), then at each side
(2 and 3) with the visor clip.
893MAX
Remove the two screws
and open the case.
895MAX
3V2032 3V2016
Additional buttons on the remote control can be programmed to operate
up to 3 devices such as additional garage door openers, light controls,
gate operators or access control systems.
Press and hold the button down until the door or gate starts to move.
The remote control will operate from up to 3 car lengths away on typical
installations. Installations and conditions vary, contact an installing dealer
for more information.
HOW TO USE THE REMOTE CONTROL
