User Manual
User Manual
Outdoor Temperature Transmitter
Features
- Outdoor temperature measuring range : -58oF to 158oF; -50oC to 70oC
- LED transmission indicator
- 2 “AAA” size battery (batteries not included)
- 82 feet operating range without interference (metal surfaces, electrical devices, etc)
- 3-channel selection
- Wall mountable
Buttons
- TEST (TX) button
- RESET (RE) button
- CHANNEL SELECTION (1 2 3 ) switch
Operation
Insert 2 “AAA” alkaline batteries into the unit following the polarity shown in the battery
compartment. Each time the temperature is measured the remote will transmit the data
immediately. The red LED on the front of the transmitter will flash once. Pressing the
TEST key once will immediately transmit temperature. Use the CHANNEL SELECTION
switch to choose your preferred channel. When using only 1 remote sensor Channel 1 is
the most common choice.
Please note that subfreezing temperatures will lower the power output of the batteries and
affect the transmission range and effectiveness of the remote unit. Severe cold,
-12oF/-24oC, will freeze the batteries and prevent the unit from functioning. Interference
from electrical devices, metal siding, security systems, etc may limit the transmission
range. It is recommended you try several locations to find the best location for the
transmitter.
Wireless transmitters are not universal. Transmitters made by other companies will not
work with an Acu>Rite instrument and vice versa. Additional transmitters may be
purchased at www.chaneyinstrument.com. The package of this transmitter is marked with
an A as are the packages of all Acu>Rite transmitters this product will function with.
Reset Operation
After the batteries are inserted, the sensor will start to measure the outdoor temperature
and transmit the temperature data to the base unit. Pressing the RESET button will restart
this procedure.
Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment dose cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Trade Name:
Model Number: 00739/00999
The responsible party information:
Chaney Instrument Co.
965 S. Wells Street,
Lake Geneva, WI 53147,
Tel: 262-248-4449
LIMITED WARRANTY INTERNATIONAL
Consumer may have more remedies at law than follows. Chaney Instrument
Company warrants to the owner, this product to be free from defect in material and
workmanship for one year from date of purchase. CHANEY INSTRUMENT SHALL
NOT BE LIABLE FOR ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL
DAMAGES, WHETHER ARISING IN CONTRACT OR TORT. Chaney Instrument’s
obligation (at its option) is limited to repair or replace this product.
For in- warranty repair, send clock, accompanied by Guarantee, bearing Dealer’s
name and date of purchase, with $5.00 to cover handling and postage, to:
Chaney Instrument Company
965 Wells Street
Lake Geneva, Wisconsin 53147
Lake Geneva, WISCONSIN 53147
www.chaneyinstrument.com
