Chaney Instrument 276TX Weather Station User Manual 15
Chaney Instrument Co. Weather Station 15
User Manual
Instruction Manual
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Questions? Contact Customer Support at
(877) 221-1252 or visit www.AcuRite.com.
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
................. 3
Setup .................................... 4
Placement Guidelines ............. 5
Using the Room Monitor ......... 6
Add-on Wired Sensors ........... 7
Troubleshooting ..................... 8
......................... 8
FCC Information .................... 9
Customer Support .................10
Warranty..............................10
Room Monitor
00276RM
00276TX
2 3
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Package Contents
1. Room Monitor
2. Mounting hardware
3. Instruction manual
PRODUCT REGISTRATION
Register online
to receive 1 year
warranty protection
www.AcuRite.com
IMPORTANT
Register a Product
BACK
5. Sensor Input
Plug-in for additional sensors
(optional; sold separately).
6. Integrated Keyhole
For easy wall mounting.
7. Alarm “ON/OFF” Switch
For water detector (optional;
sold separately).
8. Wired Sensor Retention Slot
Simplifies cord management
when using add-on wired
sensors (sold separately).
9. Monitor ID
Alphanumeric ID used to
identify the Monitor during
system configuration.
10. “ºC/ºF” Button
Select between degrees
Celsius (°C) or Fahrenheit (°F)
temperature units.
11. Reset Button
Resets display and sensor
transmission.
12. Battery Compartment
13. Battery Compartment Cover
14. Mounting Hardware
Includes drywall anchor
and screw.
Item Qty Diameter Length
Screw 1 #6 3/4”
Anchor 1 #6 3/4”
2
34
12
5
1
67
811 10 9
8
14
8
13
FRONT
1. Wireless Signal Indicator
Flashes when data is being
wirelessly transmitted.
2. Low Battery Indicator
3. Current Indoor Humidity
Displayed when no wired sensor
is attached (see page 6).
4. Current Indoor Temperature
Displayed when no wired sensor
is attached (see page 6).
4 5
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment which is not to
be used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of
used batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries
!"#
recharge non-rechargeable batteries. DO NOT short-circuit the supply terminals.
SETUP
1 2
Install or Replace Batteries
Batteries MUST be installed for
this product to operate. AcuRite
recommends high quality alkaline
batteries for the best product
performance. Heavy duty or
rechargeable batteries are not
recommended.
1. Twist off the battery
compartment cover.
2. Insert 2 x AA batteries into
the battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
After batteries are installed,
a unique 6-digit alphanumeric
momentarily. It can also be found
printed on the back of the Room
be referenced for connectivity
functions.
Room Monitor Setup
1Install Batteries
2 AA Batteries
2
Placement for Maximum Accuracy
AcuRite products are sensitive to surrounding environmental conditions. Proper
placement of the Room Monitor is critical to the accuracy and performance of
the product.
Room Monitor Placement
The Monitor is designed for indoor use. Place the Monitor in
a dry area free of dirt and dust. Monitor stands upright for
tabletop use or is wall-mountable.
Important Placement Guidelines
• Monitor must be within 330 feet (100 meters) of a companion unit
(optional; sold separately).
MAXIMIZE WIRELESS RANGE
Place units away from large metallic items, thick walls, metal surfaces, or other
objects that may limit wireless communication.
PREVENT WIRELESS INTERFERENCE
computer, microwave, radio, etc.).
LOCATE AWAY FROM HEAT SOURCES
To ensure accurate temperature measurement, place Monitor out of direct
sunlight and away from any heat sources.
LOCATE AWAY FROM HUMIDITY SOURCES
To ensure accurate humidity measurement, locate Monitor away from humidity
sources. Avoid installing the Monitor near indoor pools, spas, or other bodies
of water. Water sources may impact humidity accuracy.
6 7
OPERATION
Using the Room Monitor
The Room Monitor features built-in temperature and humidity sensors, to view
current conditions in the location where the Monitor is placed.
Expand the System
The Room Monitor can be expanded to track additional conditions using
compatible wired sensors (optional; sold separately) that simply plug into the
Monitor. Wired sensors feature an extra-long cord, perfect for installing the
sensors in hard-to-reach places.
humidity readings move to the top of the display. The display will automatically
Compatible digital displays, wired sensors and companion units are
available at: www.AcuRite.com
Add-on Wired Sensors
Add-On Sensor Room Monitor Display
with wired sensor Perfect for:
Water Detector
with audible alert
Model 06010RM
•
• Roof leaks
•
• Sump pump failure
• Tracking high or low
water level
Liquid & Soil
Temperature Sensor
Model 06011RM
• Indoor pool, spa,
pond or fountain
temperature
• Preventing frozen
pipes
• Seeding, potting and
gardening
Spot Check
Temperature &
Humidity Sensor
Model 06012RM
32
18
• Monitoring conditions
in hard to reach
places (attic,
basement, etc.)
• Pet areas
•
coverage in your home
• Monitoring conditions
room
32
18
Automatically toggles between
Indicates sensor is
plugged into the
Monitor
Icon indicates the type of
sensor that is plugged into
the Monitor
readings
readings
8 9
Troubleshooting
Problem Possible Solution
Inaccurate
temperature or
humidity
•
sources or vents (see page 5).
•
sources (see page 5).
Display screen
not working
• Check that the batteries are installed correctly.
Batteries may need to be replaced.
•
on the back of the Monitor.
Display screen shows
ERROR 1
• Check the cord on the wired sensor (sold
separately) and the connection tip for excessive
heat, excessive cold or damage. Wired sensor may
need to be replaced.
Display screen shows
ERROR 2
•
may be out of range. Check the location of the
being monitored are within the measurement range
for the wired sensor.
If your AcuRite product does not operate properly after trying
the troubleshooting steps, visit www.AcuRite.com or call
(877) 221-1252 for assistance.
Care & Maintenance
TEMPERATURE RANGE -4ºF to 158ºF; -20ºC to 70ºC
HUMIDITY RANGE 1% to 99% RH
WIRELESS RANGE 330ft / 100m depending on home construction materials
OPERATING FREQUENCY
POWER 2 x AA alkaline batteries
FCC Information
2- This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
(1) This device may not cause interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation of the device.
433.92MHz
Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada .
Son fonctionnement est soumis aux deux conditions suivantes :
( 1 ) Ce dispositif ne peut causer d'interférences ; et
( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences
qui peuvent causer un mauvais fonctionnement de l'appareil.
This device complies with Industry Canada’s licence-exempt RSSs.
10 11
Limited One Year Warranty
At AcuRite, we proudly uphold our commitment
to quality technology. Chaney Instrument Co.
warrants that all products it manufactures to
be of good material and workmanship, and to
be free of defects when properly installed and
operated for a period of one year from the date
of purchase.
We recommend that you visit us at www.AcuRite.
com for the fastest way to register your product.
However, product registration does not eliminate
the need to retain your original proof of
Chaney Instrument Co. warrants that all products it manufactures
to be of good material and workmanship, and to be free of
defects when properly installed and operated for a period of
one year from the date of purchase. Remedy for breach of this
warranty is limited to repair or replacement of the defective
item(s). Any product which, under normal use and service, is
and at its sole option, be repaired or replaced by Chaney.
Transportation costs and charges for returned goods shall
be paid for by the purchaser. Chaney hereby disclaims all
responsibility for such transportation costs and charges. This
warranty will not be breached, and Chaney will give no credit
for products it manufactures which have received normal wear
and tear, been damaged (including by acts of nature), tampered,
abused, improperly installed, damaged in shipping, or repaired
or altered by others than authorized representatives of Chaney.
The above-described warranty is expressly in lieu of all other
warranties, express or implied, and all other warranties are
hereby expressly disclaimed, including without limitation the
implied warranty of merchantability and the implied warranty
all liability for special, consequential or incidental damages,
whether arising in tort or by contract from any breach of this
warranty. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation
or exclusion may not apply to you. Chaney further disclaims all
liability from personal injury relating to its products to the extent
the purchaser assumes all liability for the consequences arising
authorized to assume for Chaney any other liability in connection
corporation is authorized to modify or waive the terms of this
paragraph, and the preceding paragraph, unless done in writing
and signed by a duly authorized agent of Chaney. This warranty
rights which vary from state to state.
Chaney Instrument Co.
Customer Support
AcuRite customer support is committed to providing you with best-in-
class service. For assistance, please have the model number of this
(877) 221-1252 info@chaney-inst.com
24/7 support at www.AcuRite.com
Register your Product
Instruction Manuals Support User Forum
Replacement Parts Submit Feedback & Ideas
PRODUCT REGISTRATION
Register online
to receive 1 year
warranty protection
www.AcuRite.com
IMPORTANT
Register a Product
©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of
the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copy-
rights are the property of their respective owners. AcuRite uses patented technology.
Visit www.AcuRite.com/patents for details.
Printed in China
00276 INST 052215
It’s More than Accurate, it’s
AcuRite offers an extensive assortment of precision instruments,
designed to provide you with information you can depend on to
™.
www.AcuRite.com
Weather
Stations
Temperature
& Humidity
Weather
Alert Radio
Kitchen
Thermometers
& Timers
Clocks
