Cyber Knight (RF-626u) – The Wireless 3D
Joystick Quick Start Guide.
Software Installation
1. Locate the bundled CD disc into your CD-ROM drive; wait for a few seconds for
your computer to read the disc.
2. If your system is set up to automatically read a newly inserted CD, then the auto
run program is executed and the opening screen for installation appears. Please
follow the on-screen instruction to install the Rockfire USB Driver and the
GameWizard step-by-step. Once the installation screen asks you to input the
serial number, please find it out from the CD packaging and then key in the right
keystroke from your keyboard for keeping installation forward.
If your system doesn’t launch the installation software automatically, please find
the auto execute file “Install.bat”, which is located under the directory of your
CD drive and click on it, then follow the on-screen instruction to install the
Rockfire USB Driver and the GameWizard software accordingly.
3. Upon software installation completed, restart you PC as the installation screen
requests.
Hardware Installation
Insert the Cyber Knight receiver USB connector to the USB port or USB Hub of
your computer and make sure it is firmly connected.
After the receiver is connected, then the monitor shows “Find a new hardware”
and the Rockfire USB driver is located and GameWizard appears in the Start
Tray for your instant access game play.
After you finish installation, the Cyber Knight will be ready to use.
Launch your game, then setup the buttons as desired. (Refer to your
game manual for best game control settings.)
Operation Reference
1. No Calibration Required.
Upon the software installation completed, there is an exclusive driver for this
joystick along with the software installed in your PC. This driver provides you the
convenience to start game play right away once the hardware and software
installation completed yet without the complicated game controllers’ calibration
procedure you have to perform before start using the conventional joysticks.
2. Instant Game play Access
The GameWizard starts to run automatically each time when you boot your
computer. It appears as an icon in the Start Tray, for your instant access game
play at anytime, as you want. For more details about software operation, please
refer to the Help / e-manual inside the CD, or the online manual in the
GameWizard to get sufficient information.
3. 3D Ergonomic Handgrip with Rudder Function
This joystick is equipped with the 3D ergonomic handgrip, which offers 360-
degree auto centering movement and the precise hand-twist rudder control for
your instant maneuver in gaming.
4. Hat Switch (View Finder)
Throttle
Twisted Rudder
Hat Switch
Trigger Button Button C
Button D
Button E
Button F
Button G
RF Transmitter
Button A
Button B
RF Receiver
The realistic 8-way coolie hat switch can be set as a view finder and allow you to
view your surroundings from your aircraft’s cockpit in the flight simulation
games. Or you may set it as the weapon control system for efficient control to
category weapons in flight missions.
5. Rotary Throttle
This centralized throttle has standard momentum function, which is required by
flight simulation games. You may accelerate or slow down the aircraft speed by
rotating this switch for efficient maneuver control.
***Please put the THROTTLE at the center position before the
Calibration and editing Game Files.
6. Functioning Buttons
You are happy to know there are 8 independent functioning buttons equipped on
this powerful game control system. The functions of A (The fire trigger), B, C, D,
E & F (Function buttons in the handgrip) and G & H (Function buttons at the base)
are all game dependent. Refer to the game manual for the best use for these
buttons, and such numbers of button is sufficient enough for you to control pop
games.
7. Channel Selector
The channel selector avails dual player to play a game software at the same time.
Its frequency is preset to accept any interference received, including
interference that may cause undesired operation.
If the receiver is set at Channel 1 then the joystick should be set at Channel 1.
This logic is applicable for dual player having a second set of Cyber Knight at this
time, the second device should be set at Channel 2.
Importance & Attention
1. Ensure the Joystick ID of Cyber Knight is “Joystick 1”, if it is properly
plugged but does not work. *
If the receiver is properly plugged to your PC but it seems does not working,
please enter the Game Controllers page (Start \ Setting \ Control Panel \
Game Controllers or Joysticks) and select “Advanced “ page to check the name
“Rockfire Cyber Knight” is in the “Controller 1” or not. Note when there is only
one game controller connected to your PC, this joystick must absolutely be
the “Controller 1” and then it works. If the Cyber Knight is not the
“Controller 1”, please remove it from the Game Controllers page, as well as
other installed controller. Subsequently re-install the joystick and complete the
calibration procedure, then it will work as usual.
Note: If you are playing duo using two “Rockfire Cyber Knight”, please check
Game Controllers page. There should be two “Rockfire Cyber Knight” registered
in “Controller 1” and “Controller 2” respectively, if not, un-plug the none functioning
“Rockfire Cyber Knight” and re-plug the receiver.
2. Not every game requires all functioning buttons (8 buttons) on your joystick. If
you find some buttons do not work inside the game, please check the game
setting again.
3. The function of the joystick buttons may vary in different games. Before proceed
with game setting, whatever through the GameWizard or from the OPTION
inside the game, always read your game manual carefully to approach the best
game setting.
4. If the game supports a joystick / gamepad and you wish to play the game with
its default joystick setting instead of through the GameWizard, please disable
GameWizard from its exclusive control panel. *
5. The “Rockfire Cyber Knight” needs little care and services. You may clean it with
a damp cloth periodically. Do not use abrasive cleaners of any type and do
not spray liquid cleaners directly on your Joystick. Any fluid leaks
inside the joystick may cause unexpected damages.
Visit Rockfire’s Web Site at http://www.rockfire.com.tw occasionally. The
site contains the latest on Rockfire’s product line and useful technical
support information, or drop us some line at e-mail:
service@rockfire.com.tw
IMPORTANT HEALTH INFORMATION
Long periods of repetitive motions using an improperly set-up workspace, incorrect
body position, and poor work habits may be associated with physical discomfort
and injury to nerves, tendons, and muscles.
If you feel numbness, weakness, swelling in your hands, neck or shoulders, consult
a qualified health professional.
All brand names, trademarks and logos are the properties of their
respective owners.
FCC Information to the user
“This device complies with Part 15 of the FCC rule.Operation is subject to
the following two conditions: (1)This device may not cause harmful
interference, and (2)this device must accept any interference received,
including interference that may cause undesired operation.”
Note: The manufacturer is not responsible for any radio or TV Interference
caused by unauthorized modifications to this equipment. Such modifications
could void the User′s authority to operate the Equipment.”
