Product supplementary sheet to
Energy harvesting wireless switch module AFIM-5002
Safety instructions
1. Application field
Batteryless and wireless RF switch module.
2. Product description
The energy harvesting wireless switch module includes a generator which converts the mechanical energy of the
actuation into electrical energy. The energy is used for the RF electronics and the data is transmitted without
batteries and wires via 915 MHz to a receiver. The energy harvesting wireless switch module is network-compatible.
A flexible ‟Pairing” allows the operation of several receivers with one switch module (and vice versa). Each wireless
RF switch module has a ‟Unique ID” which excludes a mutual interference between different RF-switch modules.
3. Technical Data
Temperature range -40 to +85 °C
Lifetime generator up to 1,000,000 operations
Frequency bands 915 MHz
Modulation 2FSK
Protocol ZF Proprietary
RF distance (open area) up to 300 m
RF distance (in buildings) up to 30 m
Operating force max. 15 N
Operating speed 0.03 – 0.25 m/s
Energy generated min. 0.33 mWs
4. Dimensions
5. Declaration of Conformity
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
NOTICE:
Changes or modifications made to this equipment not expressly approved by (manufacturer name) may void the FCC
authorization to operate this equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
6. Disposal
Dispose of the used components of the evaluation kit at an official collection point for electronic waste or at your local
dealer.
7. Contact ZF Friedrichshafen AG
Cherrystraße
91275 Auerbach
Model: AFIM-5002 FCC ID: GDDAFIM5002 IC ID:11057A-AFIM5002
CAN RSS_Gen/CNR_Gen
This device complies with Part 15 of the FCC Rules and with Industry Canada
licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
