Chi Mei Communication Systems 0208WAG01 PCS Handset with GPRS User Manual wolfgang

Chi Mei Communication Systems, Inc. PCS Handset with GPRS wolfgang

Users Manual Part I

CMCS GSM/GPRS Phone
Wolfgang
User Guide
Copyright Statement
Copyright 2002 by Chi Mei Communication Systems, Inc. (hereafter referred to as
CMCS). All rights reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system or translated into any language or computer lan-
guage, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of CMCS.
Disclaimer
CMCS makes no representations or warranties, either expressed or implied, with respect
to the contents hereof and specifically disclaims any warranties, merchantability or fitness
for any particular purpose. Further, CMCS reserves the right to revise this publication and
to make changes from time to time in the contents hereof without obligation of CMCS to
notify any person of such revision or changes.
ALL INFORMATION IS PROVIDED BY CMCS ON AN "AS IS" BASIS ONLY.
THIS COMPANY PROVIDES NO REPRESENTATIONS AND WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF FIT-
NESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY AND NONIN-
FRINGEMENT.
Wichtige Sicherheitshinweise
Bei der Benutzung dieses Produkts müssen die unten genannten Sicherheitshinweise
beachtet werden, um so juristische Ansprüche und Schäden auszuschließen.
SICHERHEIT IN FLUGZEUGEN
Die durch dieses Gerät möglicherweise verursachte Interferenz stört
die Funktion des Navigationssystems und des Netzwerks. In den meis-
ten Ländern ist daher die Benutzung dieses Produkts an Bord von
Flugzeugen per Gesetz verboten.
SICHERHEIT UND DIE UMWELT
Verwenden Sie dieses Produkt nicht an Tankstellen. Die Verwendung
dieses Produkts ist ebenfalls in Brennstofflagern, Chemieanlagen und
in der Nähe von explosiven Stoffen verboten.
SICHERHEIT IM VERKEHR
Während der Fahrt ist das Telefonieren mit einem Handgerät außer in
dringenden Notfällen nicht erlaubt. In einigen Ländern sind daher
alternativ Freisprechgeräte erlaubt.
SICHERHEIT DER STRAHLUNG
Dieses Produkt sollte wegen der Strahlung und möglicher Interferenz
nur unter den vorgestellten normalen Betriebsbedingungen verwendet
werden.
SICHERHEIT VON MEDIZINISCHEN GERÄTEN
Dieses Gerät führt möglicherweise zu Funktionsstörungen von mediz-
inischen Geräten. In den meisten Krankenhäusern und medizinischen
Zentren ist die Benutzung dieses Produkts daher verboten.
Achtung
Tipps zur Verwendung
• Verwenden Sie das Produkt nicht in der Nähe von Metallkonstruktionen (z. B. größere
Metallmöbel oder Stahlrahmen von Gebäuden). Die Übertragung und der Empfang
von Signalen kann von derartigen Objekten beeinträchtigt werden.
• Verwenden Sie das Produkt nicht in der Nähe von starken elektromagnetischen Quellen,
wie z. B. Mikrowellen, Lautsprechern, Fernsehern und Radios.
• Verwenden Sie das Produkt nicht direkt nach extremen Temperaturschwankungen.
Innerhalb des Produkts befinden sich keine vom Benutzer selbst zu repari-
erenden Teile. Wenn das Produkt beschädigt sein sollte, müssen Sie sich an
den autorisierten Kundendienst wenden oder das Gerät zu Ihrem
ursprünglichen Händler schicken. Versuchen Sie nicht, das Produkt selbst
auseinander zu bauen oder zu reparieren, da dabei möglicherweise Strom-
schläge auftreten oder nicht zu behebende Schäden am Produkt verursacht
werden.
Bewahren Sie dieses Produkt außerhalb der Reichweite von kleinen
Kindern auf.
Bewahren Sie das Produkt in seiner Schutzhülle an einem kühlen trockenen
Ort auf.
Setzen Sie die Batterie nicht Feuer oder anderen Wärmequellen aus.
Entsorgen Sie leere Batterien entsprechend der in Ihrem Land geltenden
gesetzlichen Bestimmungen.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Statement according FCC part 15.21
Modifications not expressly approved by CMCS could void the user's authority to operate
the equipment.
Statement according FCC part 15.105
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RF exposure
Tests for SAR are conducted using standard operating positions specified by the FCC
with the phone transmitting at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest certified power level, the actual
SAR level of the phone while operation can be well below the maximum value. This is
because the phone is designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a wireless base sta-
tion antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified to
the FCC that it does not exceed the limit established by the government-adopted require-
ment for safe exposure. The tests are performed in positions and locations (e.g., at the ear
and worn on the body) as required by the FCC for each model. (Body-worn measure-
ments may differ among phone models, depending upon available accessories and FCC
requirements). While there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirement for safe exposure.
For body worn operation, to maintain compliance with FCC RF exposure guidelines, use
only CMCS approved accessories. When carrying the phone while it is on, use the specific
CMCS-supplied or approved carrying case, holster, or other body-worn accessory.
Use of non-CMCS-approved accessories may violate FCC RF exposure guidelines and
should be avoided.
Health and Safety Information
Exposure to Radio Frequency (RF) Signals
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured
not to exceed the emission limits for exposure to radio frequency (RF) energy set by the
Federal Communications Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the general pop-
ulation. The guidelines are based on the safety standards previously set by both U.S. and
international standards bodies:
* American National Standards Institute (ANSI) IEEE. C95.1-1992
* National Council on Radiation Protection and Measurement (NCRP). Report 86. 1986
* International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996
* Ministry of Health (Canada), Safety Code 6. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg *.
* In the U.S. and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give addi-
tional protection for the public and to account for any variations in.
i
Table of Contents
Making Your First Call ............................................ 1
Installing SIM card .................................................2
Installing and charging the battery ........................3
Turning on the phone ...........................................5
Dialing the number ...............................................6
Ending the call ......................................................6
Introduction to Your Phone .................................... 7
Parts of your phone and their names .....................8
Front view .............................................................8
Top view ...............................................................9
Bottom view ..........................................................9
Rear view ..............................................................9
Icons on the screen ...............................................10
The keys on the phone ..........................................12
Function keys .............................. 12
Alphanumeric keys .........................................13
Basic Operations .................................................... 14
Turning on the phone ...........................................15
Turning off the phone ...........................................15
Making a call .........................................................15
Making an emergency call .....................................16
Answering a call ....................................................17
Ending a call .........................................................17
Missed call message ..............................................17
Adjusting earpiece volume ....................................17
Selecting sound profile ..........................................17
Options during a call .............................................17
Making a new call .................................................18
Answering a new incoming call .............................18
ii
Transmitting DTMF tones ......................................18
Ending calls ..........................................................18
Consulting Phone Book .........................................18
Accessing Main Menu ............................................19
Muting/unmuting the microphone ........................19
Holding/unholding a call ......................................19
Listening to your voice mail ..................................20
Reading messages ................................................20
Entering Text ........................................................20
Selecting an input mode ........................................20
Entering text .........................................................21
Erasing text ..........................................................22
Using key lock .......................................................22
Phone Book ............................................................ 23
Adding a Phone Book entry ...................................24
Method 1 ........................................................24
Method 2 ........................................................24
Method 3 ........................................................24
Searching for a Phone Book entry ...........................24
Editing a Phone Book entry ....................................24
Editing name .........................................................24
Editing number .....................................................25
Adding new phone number to existing entries ......25
Changing caller group ...........................................25
Sending a entry as business card ..........................25
Assigning default phone number ..........................26
Changing the type of number ...............................26
Sending messages from Phone Book .....................26
Erasing Phone Book entry ......................................26
Method 1 ........................................................26
Method 2 ........................................................27
Copying Phone Book entry ....................................27
Method 1 ........................................................27
iii
Method 2 ........................................................27
Setting up Speed Dial ............................................27
Method 1 ........................................................28
Method 2 ........................................................28
Viewing speed dial number ...................................28
Changing speed dial number ................................28
Erasing speed dial number ....................................28
Setting up Caller Group .........................................28
Creating a new Caller Group .................................29
Renaming a Caller Group ......................................29
Miscellaneous settings ..........................................29
Personal number ...................................................29
Adding a personal number .............................29
Editing personal number ................................29
Erasing personal number ................................30
Your own business card ........................................30
Creating your own business card ....................30
Viewing your business card ............................30
Sending your business card ............................30
Editing your business card ..............................30
Erasing your business card .............................31
Fixed dial number .................................................31
Activating Fixed dial .......................................31
Adding new Fixed dial number .......................31
Viewing Fixed dial number .............................31
Editing Fixed dial number ...............................31
Erasing Fix dial number ..................................31
Phone Book memory setting ..................................32
Selecting Phone Book memory ........................32
Checking Phone Book memory status .............32
The Main Menu ...................................................... 33
Overview .................................................................... 34
iv
Message .................................................................... 35
Writing and sending new messages .......................35
Viewing sent messages .........................................36
Receiving messages ..............................................36
Viewing received messages ...................................36
Chatroom ..............................................................37
Opening a new chat session ..................................38
Options during a chat session ...............................38
Ending a chat session ...........................................38
Customizing templates .........................................38
Customizing message template ............................38
Erasing customized message template ..................39
Sending a message from templates .......................39
Erasing all messages .............................................39
Message settings ..................................................39
Configuring message setting profiles ....................39
Using the profile on your SIM card ..................39
Configuring a new profile ...............................39
Using a configured profile ..............................40
Configuring voice mailbox number .......................40
Message options ...................................................40
Message status report ....................................40
Reply path ......................................................41
Send by GSM or GPRS ......................................41
Checking message memory status ..................41
Cell broadcast options ..........................................42
Turning on or off cell broadcast .....................42
Setting up cell broadcast topics ......................42
Sending message service commands .....................42
Call Meter .................................................................. 43
Viewing missed call records ..................................43
Viewing received call records ................................43
v
Viewing dialed call records ....................................43
Erasing all call records ..........................................43
Viewing call time information ................................44
Clearing call timer .................................................44
Viewing call cost information ................................44
Viewing call cost ...................................................44
Clearing call cost ..................................................44
Viewing remaining call cost credit .........................45
Configuring call cost settings ................................45
Viewing GPRS related information .........................45
GPRS data .............................................................45
GPRS data counter ..........................................45
Clearing GPRS data counter ............................46
GPRS connection time ...........................................46
GPRS timer .....................................................46
Clearing GPRS timer ........................................46
Incall count ...........................................................46
Session information ..............................................47
Call Feature ............................................................... 48
Call divert .............................................................48
Diverting voice calls ..............................................48
Deactivating voice call divert function .............48
Inquiring status ..............................................48
Diverting data or fax calls .....................................49
Deactivating data or fax call divert function ....49
Inquiring status ..............................................49
Deactivating all call divert functions ......................49
Call waiting ...........................................................49
Deactivating call waiting .......................................49
Inquiring status .....................................................49
Call barring ...........................................................50
Barring outgoing calls ...........................................50
vi
Cancel barring of outgoing calls .....................50
Inquiring status ..............................................50
Barring incoming calls ...........................................50
Cancel barring of incoming calls .....................51
Inquiring status ..............................................51
Cancel all call barring functions ............................51
Changing network code ........................................51
Showing/hiding your number ................................51
Selecting a phone line to use .................................52
Anykey answer ......................................................52
Auto redial ............................................................52
Speed dialing ........................................................52
Receiving a fax or data call ....................................53
Talk and Fax .........................................................53
Sound ........................................................................ 54
Sound profiles .......................................................54
Selecting a sound profile ................................54
Customizing a sound profile ...........................54
Renaming a sound profile .....................................55
Composing your ringing tones ..............................55
Minute reminder ...................................................57
Phone setup ............................................................... 58
Changing menu language .....................................58
Adjusting backlight ...............................................58
Adjusting backlight duration .................................58
Changing backlight color ......................................58
Adjusting screen contrast .....................................58
Clock ....................................................................58
Showing/hiding clock on the screen ......................58
Setting up current time and date ...........................59
vii
Selecting time zone ........................................59
Setting up current time and date ....................59
Setting up date format ..........................................59
World clock ...........................................................59
Auto power off ......................................................60
Activating Auto power off .....................................60
Deactivating Auto power off ..................................60
Idle screen display ................................................60
Screen saver ..........................................................60
Activating screen saver ...................................60
Deactivating Screen saver ...............................61
Setting up timeout period ...............................61
Standby logo .........................................................61
Showing/hiding standby logo .........................61
Selecting standby logo ....................................61
Key lock ................................................................61
Activating Key lock .........................................61
Deactivating Key lock .....................................62
Selecting default input mode .................................62
Restoring factory settings .....................................62
Phone security settings .........................................63
Activating/deactivating security codes ..................63
Activating/deactivating PIN code ....................63
Activating/deactivating phone code ................63
Activating/deactivating SIM lock .....................64
Changing security codes .......................................64
Changing PIN code .........................................64
Changing PIN2 code .......................................64
Changing phone code .....................................64
Changing SIM lock code ..................................65
Closed user group ................................................65
Network settings ...................................................65
viii
Network selection .................................................65
Band selection .......................................................66
Extras ........................................................................ 67
My Picture .............................................................67
Creating My Picture ...............................................67
Editing My Picture .................................................68
Erasing My Picture .................................................68
Sending My Picture ................................................68
Alarm clock ...........................................................69
Activating alarm clock ...........................................69
Activating alarm clock ...........................................69
Calendar ...............................................................69
Writing note ..........................................................69
Viewing note .........................................................70
Viewing today’s note ......................................70
Viewing notes on a specific date .....................70
View all notes .................................................70
Editing note ..........................................................70
Erasing note ..........................................................71
Method 1 ........................................................71
Method 2 ........................................................71
Moving a note to another date ..............................71
Copying a note to another date .............................71
Sending a note ......................................................71
Viewing calendar in month mode ..........................72
Jumping to a specific day ......................................72
Account book ........................................................72
Creating an accounting record ..............................72
Viewing accounting records ..................................73
Viewing result of accounting records ....................73
Editing accounting record .....................................74
Erasing accounting record .....................................74
Method 1 ........................................................74
Method 2 ........................................................74
Playing Games .......................................................74
ix
Ping Pong .............................................................. 75
Bingo ....................................................................75
Insect shooting .....................................................76
Tank destroyer ......................................................76
Thirteen ................................................................77
Calculator .............................................................77
Using calculator ....................................................77
Converting currencies ...........................................78
Setting up exchange rate ................................78
Performing currency exchange .......................78
Stopwatch .............................................................78
Split timing ...........................................................78
Lap timing ............................................................79
Viewing timing records .........................................79
Erasing timing records ..........................................79
Operator services ..................................................80
WAP Service ............................................................... 81
Configuring WAP settings ......................................81
Setting up a WAP profile ........................................81
Selecting and activating a WAP profile ...................81
Renaming a WAP profile ........................................81
Using WAP Service .................................................82
Options while browsing .........................................82
Other options .......................................................82
Working with bookmarks ................................82
Adding a bookmark ............................................ 82
Editing a bookmark ............................................ 82
Erasing a bookmark ............................................ 82
Appearance settings .......................................82
Security certificate ..........................................83
My shortcut ............................................................... 84
Using My shortcut .................................................84
Customizing My shortcut ......................................84
x
1
Making Your First Call
2
Making Your First Call
Installing SIM card
The SIM (Subscriber Identification Module) card is a small plastic card with metal
contact on it. You get this card after you subscribe to your operator. Your personal
subscriber information is stored in the SIM card and you need to use this card in
the phone to make/receive calls and access services provided by your operator.
What is a SIM card?
• Turn the phone face down.
• Place the SIM card in the SIM card
socket with the metal contact on the
card facing down and the bevelled cor-
ner to the direction shown.
• Push the SIM card completely into the
socket.
• Slide the SIM card retainer to the direc-
tion shown to secure the SIM card.
The bevelled corner
SIM card retainer
Pay special attention to the SIM card when you install. The metal contacts can be
damaged easily by scratches.
3
Making Your First Call
Installing and charging the battery
Place the top end of the battery on
the back of the phone, then push the
bottom end into the phone until you
hear a click.
Install the battery cover as shown.
4
Making Your First Call
• Charge the new battery for 24 hours for first time use. When the battery is
being charged, the bars of the charging status icon on phone screen scrolls.
When charging is completed, the bars will stop scrolling.
• You can use the phone while charging, however, it will take longer to charge
the battery.
• For future use of the battery, it takes approximately 3 hours to complete the
recharging process.
• When battery power is low, the xxx message will appear on the screen. Charge
the battery immediately. If battery power runs out, the power of phone will be
turned off automatically.
Note
Insert the battery charger connector
into the battery charging socket located
at the bottom of the phone.
5
Making Your First Call
Turning on the phone
Press and hold the Power key located on the top of the phone.
A welcome screen appears and you probably will be asked to enter
your PIN code. Enter the PIN code and press OK. If you acciden-
tally typed a wrong number, press Clear to erase it.
After the PIN code is verified, the phone will start searching for
the network to use. If network is available, the operator name, sig-
nal strength and some other icons will appear on the screen (see
Power key
For convenience of operation, your phone is equipped with two soft keys. You
can press a softkey to execute the function that is indicated on the screen. In this
manual, “press OK” refers to “press the softkey under OK that is displayed on
the screen”.
Note
OK
Press this soft key to
confirm the PIN code
you entered.
Clear
6
Making Your First Call
"Icons on the screen"on page 10 for details). This is called the
standby mode of the phone.
Dialing the number
Enter the number you want to dial (including the area code) and
press key. If the phone number you entered is wrong, press
Clear to erase a wrong number, or press and hold Clear to clear a
whole line.
Ending the call
When you want to end the call, press key (or press End).
The call will be terminated.
7
Introduction to Your Phone
8
Introduction to Your Phone
Parts of your phone and their names
Front view
Screen
Right soft key
Left soft key
Power/End key
Send key
Navigation key
Earpiece
Alphanumeric keys
9
Introduction to Your Phone
Volume adjustment key
Top view
SIM card socket
Battery latch
Battery terminals
Battery charger socket & Data
cable connector
Bottom view
Power key
Rear view
10
Introduction to Your Phone
Icons on the screen
Please refer to the table below for the icons that appear on the
screen and their meanings.
Status icons
Signal strength Battery power level
Current time
Operator name
Soft key items
Current operation
profile
Icon Name Description
Signal strength
Shows the condition of signal reception. The
more the number of vertical bars, the better the
reception of signal (Appearance of 4 bars indi-
cates the best signal reception).
Battery power level
Shows remaining battery power. The more the
number of vertical bars, the more the battery
power (Appearance of 4 bars indicates that the
battery is full).
If battery power is near empty, the battery icon
flashes. At this time, charge the battery immedi-
ately. When charging, the vertical bars scroll until
the battery is fully charged.
Current time Shows current time. See "Setting up current time
and date"on page 59 for how to set up current
time.
Status
icons
New message Appearance of this icon indicates that you have
new unread message(s).
Message full This icon appears when the message storage is
full. You need to delete some messages.
New voicemail
message Appearance of this icon indicates that you have
new voicemail messages.
11
Introduction to Your Phone
Status
icons
Roaming This icon appears when you are roaming under
another network.
Home zone Appearance of this icon indicates that you are cur-
rently under your home network zone.
Line 2 If you speak with the second telephone line, this
icon will appear. (See "Selecting a phone line to
use"on page 52 for details)
Vibrator on This icon appears when the vibrator function is
turned on.
Silent This icon appears when you turn off all sounds of
your phone.
Key lock This icon indicates that the key lock is ON. (See
"Key lock"on page 61 for details)
Call divert This icon shows that the call divert function is
turned ON. (See "Call divert"on page 48 for
details)
Call divert to voice-
mail box
This icon indicates that the Call divert to voice-
mail box function is enabled and your calls will be
diverted to your voicemail box automatically. (See
for details)
GPRS mode When your phone is working in the GPRS mode,
this con will appear.
Next call is set as fax
call This icon appears when you have set your phone
ready to receive the next incoming call as fax call.
Next call is set as
data call This icon appears when you have set your phone
ready to receive the next incoming call as data call.
Alarm If you have activated the Alarm function, this icon
will appear.
Auto power off If you have activated the Auto Power Off func-
tion, this icon will appear.
New fax message This icon appears when you have received a new
fax message.
New data message This icon appears when you have received a new
data message.
New e-mail This icon appears when you have received a new
e-mail.
12
Introduction to Your Phone
The keys on the phone
Function keys
Key Name Description
Power key
• Long press this key to turn phone power on or off.
• When phone power is on, press this key to open the Pro-
file Selection menu. (See "Selecting sound profile"on page
17 for details)
Call key
• When there is an incoming call, press this key to answer
the call.
• After phone number is entered using alphanumeric keys,
press this key to dial.
• In standby mode, press to view the last dialed calls.
Cancel key
• Press to return to standby mode from the Main Menu.
• If there is an incoming call, press to reject the call.
• Long press to return to standby mode from Browser
mode (See for details), or enter Browser mode from
standby mode.
Navigation
key
• In standby mode, press to access Phone Book.
• In Main Menu, press to scroll items up.
• In standby mode, press to view miss calls.
• In Main Menu, press to return to the previous
menu level.
• When entering text, press to move the cursor to
the left.
• In standby mode, press to view answered calls.
• In Main Menu, press to go to the submenus.
• When entering text, move the cursor to the right.
• In standby mode, press to access Phone Book.
• In Main Menu, press this arrow to scroll items
down.
Left/Right
Soft keys Press these soft keys to execute corresponding commands
that appear above them on the screen.
Volume adjustment key Press the key to adjust earpiece volume.
13
Introduction to Your Phone
Alphanumeric keys
The alphanumeric keys on the phone can be used to enter num-
bers and letters. To enter phone numbers, press corresponding
number keys directly. To enter letters, please see "Entering text"on
page 21 for details.
14
Basic Operations
15
Basic Operations
Turning on the phone
When phone power is off, press and hold the power key
located on the top of the phone to switch it on.
You will probably be asked to enter your PIN code. Enter PIN
code and press OK. You can also choose to turn off the PIN code
protection. Please see "Activating/deactivating PIN code"on page
63 for details.
A welcome screen will appear and the phone will start searching
for its home network automatically. If the network is found, the
operator and phone profile name, battery level icon and signal
strength icon (and other icons if available) will appear on the
screen.
Now the phone enters its standby mode. In this mode, you can:
• Press Names to enter Phone Book.
• Press Menu to access Main Menu.
• Press or to browse your Phone Book records.
• Press to view missed call records.
• Press to view answered call records.
Turning off the phone
When hone power is on, long press the power key located on
the top of the phone to switch it off.
Making a call
In standby mode, you can make an outgoing call in the following
ways:
• Enter phone number using alphanumeric keys and press
key.
• Press key two times to redial the last dialed call.
• Press key to view last dialed call records.
Scroll to the one you want to call.
Press key to dial.
• Press to view missed call records.
Scroll to the one you want to call.
16
Basic Operations
Press key to dial.
• Press to view answered call records.
Scroll to the one you want to call.
Press key to dial.
• Find a phone number in the Phone Book and press key to
dial.
• Long press alphanumeric keys ~ to dial the phone
number located #2 ~#9 in the Phone Book. (You must set up
Speed Dial and activate such function first. Please see "Setting
up Speed Dial"on page 27 and "Speed dialing"on page 52 for
details)
During a call, the call time counter will appear on the screen, let-
ting you know the time you spent on the call.
Making an emergency call
Press (or any other emergency number speci-
fied by your operator) and then key. Depending on your oper-
ator, the emergency call can be made even when there is no SIM
card in the phone.
Inserting pause To insert a pause after phone number (used when there is an
extension number following the phone number), long press
key until P appears.
For example, to call extension number 234 after the number
1234567, enter 1234567 and then long press key to
insert a P, then enter the extension number 234.
Making an
international call To make an international call:
1. Long press key to insert a + (international dialing
prefix).
2. Enter the recipient’s country code and area code (omit the
starting 0).
3. Enter the recipient’s phone number.
Note
17
Basic Operations
Answering a call
Your phone rings or vibrates (or remains silent, according to your
setting of sound profile) when an incoming call is received. Mean-
while, the caller’s name (if the caller’s name can be found in your
Phone Book) or number will appear on the screen. Otherwise,
“Unknown” will appear. You can:
• Press key (or any key on the phone except key, if the
AnyKey Answer function has been turned on) to answer the
call.
• Press key to reject the call.
Ending a call
Press key to end a call. Depending on your setup in Session
information (see "Session information"on page 47 for details), the
session information may appear on the screen.
Missed call message
If you have missed calls, the number of missed calls will appear on
the screen. You can press Detail to view detailed missed call
records, or Exit to clear the screen and return to standby mode.
Adjusting earpiece volume
During a phone call, press the volume adjustment key to increase/
decrease earpiece volume.
Selecting sound profile
1. Press the power key in standby mode. The sound profiles
will appear on the screen.
2. Scroll to desired profile and press Select.
You can also customize these profiles. See "Customizing a sound
profile"on page 54 for details.
Options during a call
During a call, you have the choice to access several in-call options.
To access these options:
1. Press Options during a call.
18
Basic Operations
2. Scroll to a desired item in the In Call Option menu that
appears.
3. Press Select to select it.
Making a new call
To make a new call during a call:
1. Highlight Dial new call in the In Call Option menu and press
Select.
2. Enter the phone number of the second call and press key.
Answering a new incoming call
If you have a new incoming call when you are already on a call,
new incoming call message will appear on the screen. Press
key to put current call on hold and answer the new call. Press
key to end (or reject) the new incoming call and you will be con-
nected to the old call automatically.
Transmitting DTMF tones
This feature allows you to send DTMF tones during a call. For
example, when you are asked to enter your bank account number
during a telephone banking service call.
To transmit DTMF tones:
1. Highlight Send DTMF in the In Call Option menu and press
Select.
2. Enter the number you are asked to.
Ending calls
This feature allows you to end current call or end one of the calls
on progress on a multi-party call.
To end current call:
Highlight End Calls in the In Call Option menu and press Select.
• To end one call on a multi-party call, highlight the call party you
want to end and press Select.
• To end all calls, highlight All and press Select.
Consulting Phone Book
19
Basic Operations
During a call, you can use this function to consult names and
numbers in the Phone Book. For details about Phone Book, please
refer to "Phone Book"on page 23.
To consult Phone Book during a call:
1. Highlight Phone Book in the In Call Option menu and press
Select.
2. You will enter the Phone Book menu. You can search for a
name and number or add a new number..., etc.
Accessing Main Menu
During a call, you can use this function to access the Main Menu.
For details about Main Menu, please refer to "The Main Menu"on
page 33.
To access Main Menu during a call:
1. Highlight Main Menu in the In Call Option menu and press
Select.
2. The Main Menu will appear on the screen.
Muting/unmuting the microphone
If you don’t want the calling party to hear your voice, you can use
this function to mute the microphone.
To mute the microphone during a call:
Highlight Mute in the In Call Option menu and press Select.
To unmute the microphone:
Highlight unmute in the In Call Option menu and press Select.
Holding/unholding a call
If you have multiple calls in progress, you can use this function to
hold one of the calls.
To hold a call:
1. Highlight Hold in the In Call Option menu and press Select.
2. Select the call you want to hold in the menu that appears.
3. Press Select.
To unhold calls:
1. Highlight Unhold in the In Call Option menu and press Select.
2. Select the call you want to unhold in the menu that appears.
3. Press Select.
20
Basic Operations
Listening to your voice mail
When a new voice mail is received, the icon appears on the
screen. To listen to the new voice mail, long press key in
standby mode and connect to your voice mailbox.
Depending on your operator, you may need to configure your
voice mailbox before you can use this function. Please refer to
"Configuring voice mailbox number"on page 40 for how to setup
your voice mailbox.
Reading messages
When a new message is received, new message alert will be gener-
ated (depending on your sound profile setting) and the new mes-
sage prompt will appear on the screen.
To read the new message:
1. Press Detail to go to the list of received messages.
2. Scroll to the message you want to read and press Select.
Entering Text
The phone provides several input methods that enable you to
enter text in Phone Book, write a message..., etc. You can also
switch among these input methods easily.
When you add a new entry to your Phone Book (see "Adding a
Phone Book entry"on page 24) or write a new message (see page),
the following text editor screen appears:
Selecting an input mode
Phone Book
editor screen
Message editor screen
Remaining number of
characters available for
input
Current input mode
21
Basic Operations
1. Press key. Available input modes will appear on the
screen.
2. Scroll to the desired input method and press Select. The
selected mode will appear on the upper right corner of the
screen.
• abc mode: Allows you to enter lower case letters.
• ABC mode: Allows you to enter upper case letters.
• Abc mode: The first letter entered is automatically capitalized.
• 123 mode: Allows you to enter numbers.
• Punctuation (,.!?:;) mode: Enter punctuation marks.
Entering text
• Press a key and the corresponding letters will appear in a bar on
the lower part of the screen.
• Press the key several times to highlight the desired letter (or
number) and it will be entered when the bar disappears. You can
also proceed to enter the next letter when the desired letter (or
number) is highlighted. The remaining number of letters you
can enter is shown on the upper right corner of the screen.
The table below shows the mapping of each key and the corre-
sponding letter in different input modes.
Keys Input Modes
ABC abc 123
(Space)
22
Basic Operations
Erasing text
If you have entered a wrong character or number, press Clear to
erase. Pressing and holding Clear will clear a whole line.
Press or to move the cursor backward/forward.
Using key lock
The key lock helps to prevent unwanted key operations when you
carry your phone.
To enable key lock:
In standby mode, press Menu, then key.
To unlock:
Press Unlock, and then press key.
23
Phone Book
24
Phone Book
Adding a Phone Book entry
You can add a new entry to Phone Book in the following ways:
Method 1
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Add and press Select.
3. You will be prompted to enter the name of the entry. Enter the
name and press OK.
4. Enter the phone number and press OK.
Method 2
1. In standby mode, enter the number using the alphanumeric
keys.
2. Press Save. You will be prompted to enter the name of the
entry. Enter the name and press OK.
Method 3
1. During a call, enter the number using the alphanumeric keys.
2. Press Save. You will be prompted to enter the name of the
entry. Enter the name and press OK.
Searching for a Phone Book entry
To search for a Phone Book entry:
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Search and press Select.
3. Enter the name of the Phone Book entry you want to look for.
You can also enter only the beginning few letters of the name.
4. The entries that match the name (or contain the letters) you
entered will appear on the screen.
Editing a Phone Book entry
Editing name
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name (or number) and press Options.
4. Scroll to Edit (or Edit name if you scrolled to the number in
step 1) and press Select.
5. Edit the name and when finished, press OK.
25
Phone Book
Editing number
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the number and press Options.
4. Scroll to Edit in the menu that appears and press Select.
5. Edit the number and when finished, press OK.
Adding new phone number to existing entries
You can record up to 4 different phone numbers under a Phone
Book entry.
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name (or number) and press Options.
4. Scroll to Add Number and press Select.
5. Enter the new number and when finished, press OK.
6. You will be prompted to select a type for the new number.
Scroll to an appropriate type and press Select.
Changing caller group
The Caller group function allows you to separate your Phone
Book entries in different groups. For details about the Caller
group function, please refer to "Setting up Caller Group"on page
28.
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name (or number) press Options.
4. Scroll to a desired caller group and press Select.
Sending a entry as business card
With this function, you can send the details of a Phone Book entry
to another person as a business card.
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name (or number) and press Options.
4. Scroll to Send business card and press Select.
5. If you want to send the business card as a new message immedi-
ately, scroll to Send as SMS and press Select. Enter the number
of the recipient (or pick up a recipient from Phone Book by
pressing Names) and press Send.
If you want to edit the business card before sending it, scroll to
Send as text and press Select.
26
Phone Book
Assigning default phone number
If you have multiple phone numbers in a Phone Book entry, you
can assign one of these numbers as default number. This default
number is dialed when you make a call from the Phone Book or
using the Speed Dial function.
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the number you want to set as default and press
Options.
4. Scroll to Set as default and press Select.
Changing the type of number
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the number and press Options.
4. Scroll to Change Type and press Select.
5. Scroll to a desired type for the number and press OK.
Sending messages from Phone Book
To send a new message from Phone Book:
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the number and press Options.
4. Scroll to Send message and press Select.
5. Compose the message. When finished, press Options and then
Send to send the message.
Erasing Phone Book entry
Method 1
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Erase and press Select.
To erase Phone Book entries one by one:
1. Scroll to One by one and press Select.
2. Scroll to select the Phone Book entry you want to erase and
press OK.
3. Press OK.
To erase all Phone Book entries:
1. Scroll to All.
2. To delete all Phone Book entries stored in phone memory,
scroll to Phone. To delete entries on the SIM card, scroll to
SIM.
27
Phone Book
3. Press Select.
Method 2
1. In Phone Book, scroll to the entry you want to erase and press
Detail.
2. Scroll to the name (or number) and press Options.
3. Scroll to Erase and press Select.
Copying Phone Book entry
Method 1
With the copy function, you can copy Phone Book entries in the
phone memory to SIM card memory and vise versa.
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Copy and press Select.
To copy Phone Book entries from phone to SIM card:
Scroll to Phone to SIM and press Select. You can choose to copy
Phone Book entries one by one or all at once.
To copy Phone Book entries from SIM card to phone:
Scroll to SIM to Phone and press Select. You can choose to copy
Phone Book entries one by one or all at once.
Method 2
1. In Phone Book, scroll to the entry you want to copy and press
Detail.
2. Scroll to the name (or number) and press Options.
3. Scroll to Copy and press Select.
4. If you want to keep the original and make a copy to another
location (i.e, if your Phone Book is using SIM card memory, it
will be copied to the phone memory and vise versa), scroll to
Keep original. To move the entry to another location, scroll to
Move original.
5. Press Select.
Setting up Speed Dial
Speed Dial is a shortcut that allows you to make a call simply by
long pressing alphanumeric keys ~ .
To set up speed dial:
28
Phone Book
Method 1
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Speed Dial and press Select.
3. Choose an empty speed dial key and press Select.
4. Your Phone Book entries will appear on the screen. Pick up a
number by pressing Select.
Method 2
1. Long press a key that has not been assigned a speed dial num-
ber.
2. The screen will prompt you to assign the speed dial key. Press
OK.
3. Your Phone Book entries will appear on the screen. Pick up a
number by pressing Select.
Viewing speed dial number
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Speed Dial and press Select.
3. On the speed dial list that appears, scroll to choose a number to
view.
4. Press Options and select View.
Changing speed dial number
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Speed Dial and press Select.
3. On the speed dial list that appears, scroll to choose a number to
change.
4. Press Options and select Change.
5. Your Phone Book numbers will appear on the screen. Pick up a
new number by pressing Select.
Erasing speed dial number
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Speed Dial and press Select.
3. On the speed dial list that appears, scroll to choose a number to
view.
4. Press Options and select Erase.
Setting up Caller Group
You can place your Phone Book entries under different Caller
Groups and give each Caller Group different ringtone, backlight
29
Phone Book
and screen graphic. When you have an incoming call, you can
judge the caller by its specific Caller Group.
Creating a new Caller Group
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Caller Group and press Select.
3. The Caller Group list will appear on the screen. Scroll to an
empty caller group and press Select.
4. Scroll to Rename and press Select. Enter the name of the Caller
Group. When finished, press OK.
5. Scroll to Ring Tone and press Select. Scroll to a desired ring
tone and press OK.
6. Scroll to Graphic and press Select. If you want to choose a
screen graphic for the Caller Group, Scroll to On and press
OK. Scroll to View and press Select to choose a graphic. Oth-
erwise, select Off. Press Back to return to the previous menu.
7. Scroll to Backlight and press Select. Scroll to a desired backlight
color from the list that appears and then press OK.
Renaming a Caller Group
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Caller Group and press Select.
3. The Caller Group list will appear on the screen. Scroll to an
empty caller group and press Select.
4. Scroll to Rename and press Select. Enter a new name of the
Caller Group. When finished, press OK.
Miscellaneous settings
Personal number
You can store your own phone number here. Up to two personal
numbers can be saved.
Adding a personal number
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Personal Number and press Select.
3. Press Options and select Add.
4. Enter your name and number.
5 Press OK.
Editing personal number
1. Enter Phone Book by pressing Names in standby mode.
30
Phone Book
2. Scroll to Personal Number and press Select.
3. Scroll to the number you want to edit and press Options.
4. Scroll to Edit and press Select.
5. Edit the name and number. When finished, press OK.
Erasing personal number
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Personal Number and press Select.
3. Scroll to the number you want to erase and press Options.
4. Scroll to Erase and press Select.
Your own business card
You can create your own business card and send it to other per-
son.
Creating your own business card
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to My Own Card and press Select.
3. Scroll to Edit and press OK.
4. Enter all necessary information. When finished, press Save.
Viewing your business card
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to My Own Card and press Select.
3. Scroll to View and press Select.
Sending your business card
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to My Own Card and press Select.
3. Scroll to Send My Own Card and press Select.
4. If you want to send the business card as a new message immedi-
ately, scroll to Send as SMS and press Select. Enter the number
of the recipient (or pick up a recipient from Phone Book by
pressing Names) and press Send.
If you want to edit the business card before sending it, scroll to
Send as text and press Select.
Editing your business card
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to My Own Card and press Select.
3. Scroll to Edit and press OK.
4. Edit the contents of your business card. When finished, press
Save.
31
Phone Book
Erasing your business card
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to My Own Card and press Select.
3. Scroll to Erase and press Select.
Fixed dial number
If your SIM card supports, you can use this function to restrict
outgoing calls only to the numbers (or the numbers that begin
with the same digit(s)) on the fixed dial list.
Activating Fixed dial
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to On and press OK.
4. Enter your PIN 2 code and press OK.
Adding new Fixed dial number
You need to activate Fixed dial before adding new Fixed dial num-
ber.
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to View and press Select.
4. Press Options.
5. Scroll to Add and press Select.
6. Enter your PIN 2 code and press OK.
7. Enter the name of the fixed dial number. Press OK.
8. Enter the number. Press OK.
Viewing Fixed dial number
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to View and press Select.
Editing Fixed dial number
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to View and press Select.
4. Scroll to a Fixed dial number and press Options.
5. Scroll to Edit and press Select.
6. Enter your PIN2 code and press OK.
7. Edit the name and number. When finished, press OK.
Erasing Fix dial number
32
Phone Book
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to View and press Select.
4. Scroll to a Fixed dial number and press Options.
5. Scroll to Erase if you want to erase selected Fixed dial number.
If you want to erase all fixed dial numbers, scroll to Erase all.
Press Select.
6. Enter your PIN2 code and press OK.
7. Press OK to confirm.
Phone Book memory setting
Selecting Phone Book memory
You can select the memory to use for your Phone Book.
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Option and press Select.
3. Scroll to Memory and press Select.
4. Scroll to SIM if you want to use SIM memory, or Phone if you
want to use phone memory.
5. Press OK.
Checking Phone Book memory status
1. Enter Phone Book by pressing Names in standby mode.
2. Scroll to Option and press Select.
3. Scroll to Memory status and press Select.
4. Scroll to SIM if you want to check the status of SIM memory,
or Phone if you want to check the status of phone memory.
5. Press OK. The status of selected memory will appear on the
screen.

Navigation menu
