Users manual 1
Konstanze
User’s Guide
PMG Phone
Copyright Statement
Copyright 2003 by CMCS. All rights reserved. No part of this publication may be reproduced, trans-
mitted, transcribed, stored in a retrieval system or translated into any language or computer language,
in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or other-
wise, without the prior written permission of CMCS.
Disclaimer
CMCS makes no representations or warranties, either expressed or implied, with respect to the con-
tents hereof and specifically disclaims any warranties, merchantability or fitness for any particular pur-
pose. Further, CMCS reserves the right to revise this publication and to make changes from time to
time in the contents hereof without obligation of CMCS to notify any person of such revision or
changes.
ALL INFORMATION IS PROVIDED BY CMCS ON AN "AS IS" BASIS ONLY. CMCS PRO-
VIDES NO REPRESENTATIONS AND WARRANTIES, EXPRESS OR IMPLIED, INCLUD-
ING THE IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE,
MERCHANTABILITY AND NONINFRINGEMENT.
Important Safety Precautions
When using this product, the safety precautions below must be taken against possible legal issues and
damages.
SAFETY IN AIRCRAFT
The interference would be caused by this product to an aircraft's navigation system
and its network. In most countries, using this product on board an airplane is
against the law.
SAFETY FOR ENVIRONMENTS
Do not use this product in gas stations. Also the use of this product is prohibited
in fuel storehouse, chemical plants and locations containing explosives.
SAFETY ON THE ROAD
Vehicle drivers in motion are not permitted to use telephony services with the
handheld device, except in the case of emergency. In some countries, using hand-
free devices as an alternative is allowed.
SAFETY ABOUT RADIATION
This product should be operated in the suggested normal condition only to ensure
the radiative performance and safety of the interference.
SAFETY FOR MEDICAL EQUIPMENTS
This product may cause malfunctions of medical equipments. In most hospital or
medical centers, use of this product is forbidden.
Attention
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
Tips When Using
• Avoid using the product near metal structures (for example, large metal furniture or steel frames of a
building). The transmission and reception of signal can be effected by these objects.
• Avoid using the product near strong electromagnetic sources, such as microwave ovens, sound
speakers, TV and radio.
• Avoid using the product right after dramatic change of temperature.
There are no user serviceable parts inside this product. If this product appears to be
broken, call a qualified service personnel or send this product to your original dealer.
Do not attempt to disassemble or repair this product as it may result in electric shock
or unrecoverable damage to the product itself.
Keep this product out of reach of small children.
Store this product in its protective case in a cool dry place.
Do not throw the battery into fire or other heat source. Dispose of used batteries
according to your local regulations.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) this
device may not cause harmful interference, and (2) this device must accept any interfer- ence received, including
interference that may cause undesired operation.
FCC ID: QDJ-0307KON01
Statement according to FCC part 15.21
Modifications not expressly approved by CMCS could void the user's authority to operate the equip- ment.
Statement according to FCC part 15.105
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
---Consult the dealer or an experienced radio/TV technician for help.
Regulatory information / Disclaimers
Installation and use of this 900/ 1800/ 1900/ Bluetooth Mobile Handset device must be in strict accordance with the
instructions included in the user documentation provided with the product. Any changes or modifications (including the
antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to
operate the equipment. The manufacturer is not responsible for any radio or television interference caused by
unauthorized modification of this device, or the substitution of the connecting cables and equipment other than
manufacturer specified. It is the responsibility of the user to correct any interference caused by such unauthorized
modification, substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no
liability for any damage or violation of government regulations arising from failing to comply with these guidelines.
IMPORTANT NOTE (CO-LOCATION)
FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for
an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any
other antenna or transmitter.
Tests for SAR are conducted using standard operating positions specified by the FCC with the phone transmitting at
its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while operation can be well below the maximum value. This is because
the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In
general, the closer you are to a wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not
exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. (Body-worn
measurements may differ among phone models, depending upon available accessories and FCC requirements).
While there may be differences between the SAR levels of various phones and at various positions, they all meet the
government requirement for safe exposure.
For body worn operation, to maintain compliance with FCC RF exposure guidelines, use only accessories that contain
no metallic components and provide a separation distance of 1.5cm (0.6 inches) to the body. Use of other
accessories may violate FCC RF exposure guidelines and should be avoided.
Health and Safety Information
Exposure to Radio Frequency (RF) Signals
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed
the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The guidelines are based on the safety stan-
dards previously set by both U.S. and international standards bodies:
* American National Standards Institute (ANSI) IEEE. C95.1-1992
* National Council on Radiation Protection and Measurement (NCRP). Report 86. 1986
* International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996
* Ministry of Health (Canada), Safety Code 6. The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the Spe-
cific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg *.
* In the U.S. and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over
one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public
and to account for any variations in.
SAR Information
THIS MODEL DEVICE MEETS THE GOVERNMENT'S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless mobile GSM phone is a radio transmitter and receiver. It is designed and manufactured
not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Com-
munications Commission of the U.S. Government. These limits are part of comprehensive guidelines
and establish permitted levels of RF energy for the general population. The guidelines are based on
the safety standards previously set by both U.S. and international standards bodies:
* American National Standards Institute (ANSI) IEEE. C95.1-1992
* National Council on Radiation Protection and Measurement (NCRP). Report 86. 1986
* International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996
* Ministry of Health (Canada), Safety Code 6. The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile GSM phone employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg *.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines
when used with an accessory that contains no metal and that position the antenna of the GSM phone
a minimum of 1.5cm from the body. The SAR values of this GSM phone are 0.639mW/g (body) and
0.603mW/g (head). Use of other accessories may not ensure compliance with the FCC RF exposure
guidelines.
The FCC has granted an Equipment Authorization for this model device with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model
device is on file with the FCC and can be found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID QDJ-0307KON01. Additional information on
Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Asso-
ciation (CTIA) web-site at http://www.devicefacts.net.
* In the U.S. and Canada, the SAR limit for mobile GSM phone used by the public is 1.6 watts/kg
(W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to
give additional protection for the public and to account for any variations in.
i
Table of Contents
Making Your First Call ....................................................1
Installing SIM card ..........................................................2
Installing and charging the battery .................................3
Turning on the phone ....................................................5
Dialing the number ........................................................7
Ending the call ...............................................................7
Introduction to Your Phone ............................................8
Parts of your phone and their names ............................. 9
Front view ......................................................................9
Top view ......................................................................10
Bottom view .................................................................10
Rear view .....................................................................11
Icons on the screen ......................................................11
The keys on the phone .................................................13
Function keys ........................................................13
Alphanumeric keys ................................................14
Service light .................................................................15
Basic Operations ..........................................................16
Turning on the phone .................................................. 17
Turning off the phone .................................................. 17
Making a call ............................................................... 17
Making an emergency call ............................................ 19
Answering a call .......................................................... 19
Ending a call ................................................................ 20
Missed call message .................................................... 20
ii
Adjusting earpiece volume ........................................... 20
Selecting sound profile ................................................ 20
Options during a call .................................................... 20
Making a new call ........................................................ 20
Answering a new incoming call .................................... 21
Holding/unholding a call ............................................. 21
Switching calls ............................................................. 21
Transferring a call ........................................................ 21
Conference call ............................................................ 21
Private call on a conference call ................................... 22
Transmitting DTMF tones ............................................. 22
Ending calls ................................................................. 22
Consulting Phone Book ................................................ 22
Accessing Main Menu .................................................. 23
Muting/unmuting the microphone ............................... 23
Listening to your voice mail ......................................... 23
Reading messages ....................................................... 23
Reading multimedia messages .....................................24
Receiving business card ............................................... 25
Downloading operator logo .......................................... 25
Downloading ring tone ................................................25
Entering Text ...............................................................26
Selecting an input mode .............................................. 26
Entering Latin characters and words ............................ 26
Entering characters and words using multi-tap
input methods ....................................................... 26
Entering text using T9 English input method ......... 28
Entering numbers ........................................................ 28
Entering symbols ......................................................... 28
Erasing text ................................................................. 29
iii
Using key lock ............................................................. 29
Phone Book ..................................................................30
Adding a Phone Book entry .......................................... 31
Searching for a Phone Book entry ................................. 31
Editing a Phone Book entry .......................................... 32
Editing name ................................................................32
Editing number ............................................................ 32
Adding new phone number to existing entries .............32
Adding notes to existing entries ..................................32
Changing caller group ..................................................33
Sending an entry as business card ................................33
Assigning default phone number .................................34
Changing the type of number .......................................34
Sending messages from Phone Book............................ 34
Erasing Phone Book entry ............................................ 34
Copying Phone Book entry ........................................... 35
Setting up Speed Dial ................................................... 36
Viewing speed dial number ..........................................36
Changing speed dial number ........................................37
Erasing speed dial number ...........................................37
Setting up Caller Group ................................................ 37
Changing caller group settings .....................................37
Changing caller group name ..................................37
Changing caller group ringtone .............................38
Changing caller group graphic ...............................38
Miscellaneous settings ................................................. 38
Personal number ..........................................................38
Adding a personal number .....................................38
Editing personal number ........................................39
iv
Erasing personal number ....................................... 39
Your own business card ............................................... 39
Creating your own business card ........................... 39
Viewing your business card ................................... 39
Sending your business card ................................... 39
Editing your business card .................................... 40
Erasing your business card .................................... 40
Fixed dial number ........................................................ 40
Activating Fixed dial .............................................. 40
Adding new Fixed dial number .............................. 40
Viewing Fixed dial number .................................... 41
Editing Fixed dial number ...................................... 41
Erasing Fix dial number ......................................... 41
Phone Book memory setting ........................................ 41
Selecting Phone Book memory ............................... 41
Checking Phone Book memory status .................... 42
Looking up a dialing number ................................. 42
The Main Menu ............................................................43
Overview ...........................................................................44
Message ............................................................................45
Writing and sending new messages ..............................45
Viewing sent messages ................................................46
Viewing received messages .......................................... 46
Viewing received messages in the Inbox ...................... 47
Customizing preset message templates ....................... 48
Customizing message template ................................... 48
Erasing customized message template ......................... 48
v
Sending a message from templates ..............................48
Erasing all messages .................................................... 48
Multimedia messages .................................................. 49
Writing and sending multimedia messages ...................49
Viewing unsent multimedia messages ..........................50
Viewing received multimedia messages ........................51
Erasing all multimedia messages ..................................52
Chatroom .................................................................... 52
Accepting an invitation to join a chatroom ...................52
Opening a new chat session .........................................52
Options during a chat session ......................................53
Message settings ......................................................... 53
Configuring text message setting profiles ....................53
Using the profile on your SIM card .........................54
Configuring a new profile ......................................54
Using a self-configured profile ..............................54
Multimedia message settings .......................................54
Retrieving messages automatically ........................54
Retrieving messages while roaming ....................... 55
Connection settings ...............................................55
Allow adverts. ........................................................57
Sending options .....................................................57
Message options ..........................................................58
Message status report ...........................................58
Reply path .............................................................58
Send by GSM or GPRS .............................................58
Checking message memory status .........................59
Configuring voice mailbox number ..............................59
Sending history ............................................................ 59
Cell broadcast options .................................................59
vi
Turning on or off cell broadcast ............................ 59
Setting up cell broadcast topics ............................. 60
Sending message service commands ........................... 60
Call Meter ..........................................................................61
Viewing missed call records ......................................... 61
Viewing received call records .......................................61
Viewing dialed call records ........................................... 61
Erasing all call records ................................................. 62
Viewing call time information ....................................... 62
Clearing call timer ....................................................... 62
Viewing call cost information .......................................62
Viewing call cost .......................................................... 63
Clearing call cost ......................................................... 63
Viewing remaining call cost credit ................................ 63
Configuring call cost settings ...................................... 63
Viewing GPRS related information ................................64
GPRS data .................................................................... 64
GPRS data counter ................................................. 64
Clearing GPRS data counter ................................... 64
GPRS connection time .................................................. 64
GPRS timer ............................................................ 64
Clearing GPRS timer .............................................. 65
In-call count ................................................................ 65
Session information .....................................................65
Call Feature .......................................................................66
Call divert ....................................................................66
Diverting voice calls ..................................................... 66
vii
Deactivating voice call divert function ....................66
Inquiring status .....................................................67
Diverting data or fax calls ............................................67
Deactivating data or fax call divert function ...........67
Inquiring status .....................................................67
Deactivating all call divert functions .............................67
Call waiting .................................................................. 67
Deactivating call waiting ...............................................68
Inquiring status ............................................................68
Call barring .................................................................. 68
Barring outgoing calls ..................................................68
Cancel barring of outgoing calls ............................68
Inquiring status .....................................................69
Barring incoming calls ..................................................69
Cancel barring of incoming calls ............................ 69
Inquiring status .....................................................69
Cancel all call barring functions ...................................69
Changing network code ...............................................69
Showing/hiding your number ...................................... 70
Selecting a phone line to use ....................................... 70
Anykey answer ............................................................. 71
Auto redial ................................................................... 71
Speed dialing ............................................................... 71
Receiving a fax or data call .......................................... 71
Talk and Fax ................................................................ 72
Minute reminder .......................................................... 72
Connection indication .................................................. 72
viii
Sound ................................................................................74
Sound profiles ............................................................. 74
Selecting a sound profile ....................................... 74
Customizing a sound profile ................................. 75
Renaming a sound profile ............................................ 76
Composing your ringing tones .....................................76
Quick silence ...............................................................78
Phone setup ......................................................................79
Changing menu language ............................................ 79
Adjusting backlight duration ........................................ 79
Adjusting screen contrast ............................................ 79
Clock ........................................................................... 79
Showing/hiding clock on the screen ............................ 79
Setting up current time and date .................................. 79
Selecting time zone ............................................... 80
Setting up current date .......................................... 80
Setting up current time .......................................... 80
Setting up date format ................................................. 80
World clock .................................................................. 80
Auto power off .............................................................81
Activating Auto power off ............................................ 81
Deactivating Auto power off ......................................... 81
Display settings ...........................................................81
Changing color scheme ............................................... 81
Changing wallpaper ..................................................... 82
Activating screen saver ................................................ 82
Showing/hiding standby information ........................... 82
Showing/hiding standby logo ...................................... 82
ix
Key lock ....................................................................... 83
Activating Key lock ................................................83
Deactivating Key lock .............................................83
Selecting default input mode ....................................... 83
Changing right softkey function ................................... 84
Restoring factory settings ............................................ 84
Phone security settings ................................................ 84
Activating/deactivating security codes .........................85
Activating/deactivating PIN code ...........................85
Activating/deactivating phone code .......................85
Activating/deactivating SIM lock ............................ 86
Changing security codes ..............................................86
Changing PIN code ................................................86
Changing PIN2 code ..............................................86
Changing phone code ............................................86
Changing SIM lock code .........................................87
Closed user group ........................................................87
Network settings ......................................................... 88
Network selection ........................................................88
Band selection ..............................................................88
GPRS attach ..................................................................88
Service light ................................................................. 89
Extras ................................................................................90
My Picture .................................................................... 90
Creating My Picture ......................................................90
Editing My Picture ........................................................91
Erasing My Picture ........................................................91
Sending My Picture .......................................................91
x
Alarm clock ..................................................................92
Activating alarm clock .................................................. 92
Deactivating alarm clock .............................................. 92
Calendar ...................................................................... 93
Writing note ................................................................. 93
Viewing note ................................................................ 93
Viewing today’s note ............................................. 93
Viewing notes on a specific date ............................ 94
View all notes ........................................................ 94
Viewing calendar in month mode ................................. 94
Jumping to a specific day ............................................. 94
Editing note ................................................................. 94
Erasing note ................................................................ 95
Moving a note to another date ..................................... 95
Copying a note to another date .................................... 95
Sending a note ............................................................. 96
Sending a message ...................................................... 96
Account book ..............................................................96
Creating an accounting record ..................................... 96
Viewing accounting records ......................................... 97
Viewing results of accounting records .......................... 97
Editing accounting record ............................................ 98
Erasing accounting record ........................................... 98
Playing Games .............................................................98
Five ball ....................................................................... 99
Flying ........................................................................ 100
Popo car .................................................................... 100
Genie ......................................................................... 101
Calculator ..................................................................102
Using calculator ......................................................... 102
Converting currencies ................................................ 102
Setting up exchange rate ..................................... 102
xi
Performing currency exchange .............................103
Stopwatch .................................................................. 103
Split timing ................................................................103
Lap timing ..................................................................103
Viewing timing records ..............................................103
Erasing timing records ...............................................104
Voice recorder ........................................................... 104
Recording voice ..........................................................104
Playing recordings ......................................................104
Renaming recordings .................................................105
Erasing recordings .....................................................105
Activating speaker ......................................................105
WAP Service .....................................................................106
Browsing the Internet ................................................. 106
Going to your homepage ............................................106
Going to your bookmarked pages ..............................106
Navigating the Internet using the options menu .........106
Configuring WAP profiles ........................................... 108
Setting up a WAP profile .............................................108
Selecting and activating a WAP profile ........................109
Editing a WAP profile ..................................................109
Renaming a WAP profile .............................................109
Media center ...................................................................110
Viewing the contents of the Media center ................... 110
Inserting multimedia objects in multimedia msgs. ..... 110
My shortcut .....................................................................111
Using My shortcut ...................................................... 111
Customizing My shortcut ........................................... 111
Operator services ............................................................112
xii
PMG .................................................................................113
Adding new devices ...................................................113
Changing name ..........................................................113
Switching between Handset and Headset ...................113
Troubleshooting & FAQ ..............................................115
Care and Maintenance ...............................................118
Appendix ...................................................................121
Left soft key ...............................................................122
Quick Reference .........................................................123
1
Making Your First Call
Making Your First Call
2
Installing SIM card
The SIM (Subscriber Identification Module) card is a small plastic card with metal contact
on it. You get this card after you subscribe to your operator. Your personal subscriber infor-
mation is stored in the SIM card and you need to use this card in the phone to make/receive
calls and access services provided by your operator.
What is a SIM card?
• Turn the phone face down.
• Open the back cover. • Slide the SIM card into the SIM card socket.
The bevelled corner
SIM card socket
Pay special attention to the SIM card when you install. The metal contacts can be damaged
easily by scratches.
3
Making Your First Call
Installing and charging the battery
Place the top end of the battery on the back of the phone, then
push the bottom end into the phone until you hear a click.
Install the battery cover as shown.
Making Your First Call
4
• Charge the new battery before first time use. When the battery is being charged, the ser-
vice light becomes red, the bars of the charging status icon on phone screen scrolls. When
charging is completed, the bars will stop scrolling.
• You can use the phone while charging, however, it will take longer to charge the battery.
• For future use of the battery, it takes approximately 3 hours to complete the recharging
process.
• When battery power is low, low battery message will appear on the screen. Charge the
battery immediately. If battery power runs out, the power of phone will be turned off
automatically.
Note
Insert the battery charger connector into the
battery charging socket located at the bottom of
the phone, and then plug into the electric
power outlet.
5
Making Your First Call
Turning on the phone
Long press the power key located on the top of the phone.
A welcome screen appears and you probably will be asked to enter your PIN
code. Enter the PIN code and press OK. If you accidentally typed a wrong
number, press Clear to erase it.
Power key
In this manual, "long press" a key means "press and hold the key for at least 2 seconds and then
release it", while "press" a key means "press the key and release it immediately".
Note
If you entered the wrong PIN code 3 times in a row, your SIM card will be blocked. Contact
your operator to unblock it.
Note
Making Your First Call
6
After the PIN code is verified, you will be prompted to enter current time and
date. Enter the information and press OK.
The phone will start searching for the network to use. If network is available,
the operator name, signal strength and some other icons will appear on the
screen (see "Icons on the screen"on page 11 for details). This is called the
standby mode of the phone.
Press this soft key to confirm
the PIN code you entered.
For convenience of operation, your phone is equipped with two soft keys. You can press a
softkey to execute the function that is indicated on the screen. In this manual, “press OK”
refers to “press the softkey under OK that is displayed on the screen”.
Note
7
Making Your First Call
Dialing the number
Enter the number you want to dial (including the area code) and press
key. If the phone number you entered is wrong, press Clear to erase a wrong
number, or press and hold Clear to clear a whole line.
Ending the call
When you want to end the call, press key (or press End). The call will be
terminated.
8
Introduction to Your Phone
9
Introduction to Your Phone
Parts of your phone and their names
Front view
Screen
Right soft key
Left soft key
End key
Send key
Navigation key
Earpiece
Alphanumeric keys
Service light
Power key
Introduction to Your Phone
10
Earpiece volume adjustment key
Top view
Battery charger socket &
Data cable connector
Bottom view
Power key
Earphone jack
Microphone
11
Introduction to Your Phone
Icons on the screen
SIM card socket
Battery terminals
Rear view
Battery latch
Handstrap hole
Status icon(s)
Signal strength Battery power level
Current time
Operator name
Soft key items
Current date
Introduction to Your Phone
12
Please refer to the table below for the icons that appear on the screen and their
meanings.
Icon Name Description
Signal strength Shows the condition of signal reception. The more the num-
ber of vertical bars, the better the reception of signal (Appear-
ance of 4 bars indicates the best signal reception).
Battery power level
Shows remaining battery power. The more the number of
vertical bars, the more the battery power (Appearance of 4
bars indicates that the battery is full).
If battery power is near empty, charge it immediately. When
charging, the vertical bars scroll until the battery is fully
charged.
Current time Shows current time. See "Setting up current time and date"on
page 79 for how to set up current time.
Current date Shows current date. See "Setting up current time and date"on
page 79 for how to set up current time.
Status
icons
New text message Appearance of this icon indicates that you have new unread
text message(s).
Message full This icon appears when the message storage is full. You need
to delete some messages.
New multimedia
message Appearance of this icon indicates that you have new unread
multimedia message(s).
Multimedia mes-
sage full This icon appears when the multimedia message storage is
full. You need to delete some messages.
Processing multime-
dia message
Appearance of this icon indicates that your phone is sending
the multimedia message or downloading the multimedia mes-
sage from the server.
New voicemail
message Appearance of this icon indicates that you have new voicemail
messages.
Roaming This icon appears when you are roaming under another net-
work.
Line 2 If you speak with the second telephone line, this icon will
appear. (See "Selecting a phone line to use"on page 70 for
details)
13
Introduction to Your Phone
The keys on the phone
Function keys
Status
icons
Vibrator on This icon appears when the vibrator function is turned on.
Silent This icon appears when you turn off all sounds of your phone.
Call divert This icon shows that the call divert function is turned ON.
(See "Call divert"on page 66 for details)
GPRS mode When your phone has been connected to the GPRS network,
this con will appear.
Next call is set as fax
call This icon appears when you have set your phone ready to
receive the next incoming call as fax call.
Next call is set as
data call This icon appears when you have set your phone ready to
receive the next incoming call as data call.
Alarm If you have activated the Alarm function, this icon will appear.
New fax message This icon appears when you have received a new fax message.
New data message This icon appears when you have received a new data mes-
sage.
New e-mail This icon appears when you have received a new message in e-
mail format.
Key Name Description
Power key • Long press this key to turn phone power on or off.
• When phone power is on, press this key to open the Profile Selection
menu. (See "Selecting sound profile"on page 20 for details)
Call key • When there is an incoming call, press this key to answer the call.
• After phone number is entered using alphanumeric keys, press this key
to dial.
• In standby mode, press to view the last dialed calls. Press again to dial.
Introduction to Your Phone
14
Alphanumeric keys
Cancel key • Press to return to standby mode from the Main Menu.
• If there is an incoming call, press to reject the call.
Navigation
key
Up • In standby mode, press to access Phone Book.
• In Main Menu, press to scroll items up.
Left • In standby mode, press to view missed calls.
• In Main Menu, press to return to the previous menu level.
• When entering text, press to move the cursor to the left.
Right • In standby mode, press to view answered calls.
• In Main Menu, press to go to the submenus.
• When entering text, move the cursor to the right.
Down • In standby mode, press to access Phone Book.
• In Main Menu, press this arrow to scroll items down.
Left/Right
Soft keys Press these soft keys to execute corresponding commands that appear
above them on the screen.
Volume adjustment key Press the key to adjust earpiece volume.
15
Introduction to Your Phone
The alphanumeric keys on the phone can be used to enter numbers and letters.
To enter phone numbers, press corresponding number keys directly. To enter
letters, please see "Entering Latin characters and words"on page 26 for details.
Service lightThere is a service light on your phone. Please refer to the table below for the
type of flash, color and their meanings(You can change the color of the service
light, please see "Service light"on page 89 for details).
Flash type Color Description
Light out None No signal
Flash once every 5
seconds Changeable • In Standby mode
• The phone call is connecting
Flash once every 5
seconds Red Low battery notice
Flash 4 times every
1 second Random • Receiving an incoming call
• Alert
• Calendar reminding
Light on continu-
ously Red The battery is being charged.
Flash 3 times every
5 seconds Red Missed call, unread message...etc.
16
Basic Operations
17
Basic Operations
Turning on the phone
When phone power is off, long press the power key to switch it on.
If the PIN code protection function has been activated, you will be asked to
enter your PIN code. Enter the code and press OK. You can also choose to
turn off PIN code protection. Please see "Activating/deactivating PIN code"on
page 85 for details.
A welcome screen will appear and the phone will start searching for its home
network automatically. If the network is found, the operator and phone pro-
file name, battery level icon and signal strength icon (and other icons if avail-
able) will appear on the screen.
Now the phone enters its standby mode. In this mode, you can:
• Press the right soft key to enter Phone Book.
• Press the left soft key to access Main Menu.
• Press Up or Down to browse your Phone Book records.
• Press Left to view missed call records.
• Press Right to view answered call records.
• Long press key to access your voicemail box.
• Long press key to access Silence mode.
• Long press key to access My shortcut.
• Press the power key to access Profile menu.
Turning off the phone
When phone power is on, long press the power key to switch it off.
Making a call
In standby mode, you can make an outgoing call in the following ways:
• Enter phone number using alphanumeric keys and press key.
• Enter a Latin character using alphanumeric keys. When entering, your
phone will look up possible corresponding entries in the phone book auto-
matically and display them on the screen. Press Up or Down to scroll to a
desired entry and press key(To use this function, you have to activate
dialing number lookup function first. Please see "Looking up a dialing num-
ber"on page 42 for details).
Basic Operations
18
• Press key two times to redial the last dialed call.
• Press key to view last dialed call records.
Scroll to the one you want to call.
Press key to dial.
• Press Left to view missed call records.
Scroll to the number you want to call.
Press key to dial.
• Press Right to view answered call records.
Scroll to the number you want to call.
Press key to dial.
• Find a phone number in the Phone Book and press key to dial.
• Long press alphanumeric keys ~ to dial the phone number
located #2 ~#9 in the Phone Book. (You must set up Speed Dial and acti-
vate such function first. Please see "Setting up Speed Dial"on page 36 and
"Speed dialing"on page 71 for details)
During a call, the call time counter will appear on the screen, letting you know
the time you spent on the call.
Inserting pause To insert a pause after phone number (used when there is an extension
number following the phone number), long press key until P
appears.
For example, to call extension number 234 after the number 1234567,
enter 1234567 and then long press key to insert a P, then enter
the extension number 234.
Making an
international call To make an international call:
1. Long press key to insert a + (international dialing prefix).
2. Enter the recipient’s country code and area code (omit the starting 0).
3. Enter the recipient’s phone number.
Note
19
Basic Operations
Making an emergency call
Press (or any other emergency number specified by your
operator) and then key. Depending on your operator, the emergency call
can be made even when there is no SIM card in the phone.
Answering a call
Your phone rings or vibrates (or remains silent, according to the setting of
sound profile) when an incoming call is received. Meanwhile, the caller’s name
(if the caller’s name can be found in your Phone Book) or number will appear
on the screen. Otherwise, “Unknown” will appear instead. You can:
• Press key (or any key on the phone except key, if the Anykey
answer function has been turned on) to answer the call.
• Press key to reject the call.
If you have another new incoming call when you are already on a call, new
incoming call message will appear on the screen. Press key to put the cur-
rent call on hold and answer the new call. Press key to end the new call
and you will be connected to the old call automatically. Press Hold to put the
new call on hold.
If the home network is not found(the signal strength icon appears on the screen with no
bars), you can only make emergency call.
Note
Holding a call needs support form your operator, and you have to activate the call waiting
function(See "Call waiting"on page 67 for details).
Note
Basic Operations
20
Ending a call
Press key to end a call. Depending on your setup in Session information
(see "Session information"on page 65 for details), the session information may
appear on the screen.
Missed call message
If you have missed calls, “Missed call” message and the number of missed calls
will appear on the screen. You can press Detail to view detailed missed call
records, or Exit to clear the screen and return to standby mode.
Adjusting earpiece volume
During a phone call, press the volume adjustment key to increase/decrease ear-
piece volume.
Selecting sound profile
1. Press the power key in standby mode. The sound profiles menu will appear
on the screen.
2. Scroll to desired profile and press Select.
You can also customize these profiles. See "Customizing a sound profile"on
page 75 for details.
Options during a call
During a call, you have the choice to access several in-call options.
To access these options:
1. Press Options during a call.
2. Scroll to a desired item in the In Call Option menu that appears.
3. Press Select to select it.
Making a new call
These options during a call need support from your operator. Please consult your operator
for availability.
Note
21
Basic Operations
To make a new call during a call:
1. Scroll to Dial new call in the In-call Option menu and press Select.
2. Enter the phone number of the second call and press key.
Answering a new incoming call
If you have a new incoming call when you are already on a call, new incoming
call message will appear on the screen. Press key to put current call on
hold and answer the new call. Press key to end (or reject) the new incom-
ing call and you will be connected to the old call automatically.
Holding/unholding a call
If you have multiple calls in progress, you can use this function to hold one of
the calls.
To hold a call:
1. Scroll to Hold in the In-call Option menu and press Select.
2. Select the call you want to hold in the menu that appears.
3. Press Select.
To unhold calls:
1. Scroll to Unhold in the In-call Option menu and press Select.
2. Select the call you want to unhold in the menu that appears.
3. Press Select.
Switching calls
If you have two active calls, you can use this function to switch between them.
To switch calls, scroll to Switch in the In-call Option menu and press Select.
Transferring a call
If you have two active calls, you can use this function to transfer the current
call to another call on hold.
To transfer a call, scroll to Transfer in the In-call Option menu and press
Select.
Conference call
Basic Operations
22
If you have multiple active calls, you can use this function to connect all calling
parties so that they can talk to each other at the same time.
To establish a conference call, scroll to Conference in the In-call Option menu
and press Select.
Private call on a conference call
When a conference call is in progress, you can use this function to talk to one
of the call parties privately.
To use this function:
1. On a conference call, scroll to Private in the In-call Option menu and press
Select.
2. Scroll to a calling party you want to talk to privately and press Select.
3. To return to the conference call, scroll to Conference in the In-call Option
menu and press Select.
Transmitting DTMF tones
This feature allows you to send DTMF tones during a call. For example, when
you are asked to enter your bank account number during a telephone banking
service call.
To transmit DTMF tones:
1. Scroll to Send DTMF in the In-call Option menu and press Select.
2. Enter the number you are asked to.
Ending calls This feature allows you to end current call or end one of the calls on progress
on a multi-party call.
To end current call:
Scroll to End calls in the In-call Option menu and press Select.
• To end one call on a multi-party call, scroll to the call party you want to end
and press Select.
• To end all calls, scroll to All calls and press Select.
Consulting Phone Book
23
Basic Operations
During a call, you can use this function to consult names and numbers in the
Phone Book. For details about Phone Book, please refer to "Phone Book"on
page 30.
To consult Phone Book during a call:
1. Scroll to Phone book in the In-call Option menu and press Select.
2. You will enter the Phone Book menu. You can search for a name and num-
ber or add a new number..., etc.
Accessing Main Menu
During a call, you can use this function to access the Main Menu. For details
about Main Menu, please refer to "The Main Menu"on page 43.
To access Main Menu during a call:
1. Scroll to Main menu in the In-call Option menu and press Select.
2. The Main Menu will appear on the screen.
Muting/unmuting the microphone
If you don’t want the calling party to hear your voice, you can use this func-
tion to mute the microphone.
• To mute the microphone during a call:
Scroll to Mute in the In-call Option menu and press Select.
• To unmute the microphone:
Scroll to Unmute in the In Call Option menu and press Select.
Listening to your voice mail
When a new voice mail is received, the icon appears on the screen. To lis-
ten to the new voice mail, long press key in standby mode and connect
to your voice mailbox.
Depending on your operator, you may need to configure your voice mailbox
before you can use this function. Please refer to "Configuring voice mailbox
number"on page 59 for how to setup your voice mailbox.
Reading messages
When a new message is received, new message alert will be generated
(depending on your sound profile setting) and the new message prompt will
appear on the screen.
Basic Operations
24
To read the new message:
1. Press Detail to go to the list of received messages.
2. Scroll to the message you want to read and press Select.
Reading multimedia messages
When a new multimedia message is received, new message alert will be gener-
ated (depending on your sound profile setting) and the “New MMS” prompt
and an icon will appear on the screen.
To read the new message:
1. Press Detail to go to the list of received messages.
2. Scroll to the message you want to read and press Select.
You can turn on the Auto fetch function if you want your phone to retrieve
the multimedia message immediately. If you select Ask me, a notice will be
sent to the Inbox first(See "Retrieving messages automatically"on page 54).
To read the new multimedia message:
1. Press the left soft key two times in standby mode.
2. Scroll to Multimedia msgs. and press Select.
3. Scroll to Inbox and press Select.
4. Scroll to a message with an icon , press Select for the following
options:
• Fetch this msg.: Fetch the message immediately.
• Erase: Erase the message immediately without fetching it.
• Detail info.: View the title, sender’s number and memory size of this mes-
sage.
• If a multimedia message is received during a call, you still have to enter the Inbox and fetch
this message manually after the phone call is end even if you have turned on the Auto fetch
function.
• A maximum of 30KB is allowed for each received multimedia message. The message can not
be fetched by your phone if its memory size is over 30KB.
• If there is any inserted multimedia objects in a received multimedia message that can not be
displayed by your phone, the names of the inserted objects will be shown on the screen.
Note
25
Basic Operations
Receiving business card
When a new business card is received, new business card alert will be gener-
ated (depending on your sound profile setting) and the “Business card”
prompt will appear on the screen.
To read the new business card:
1. Press Detail to go to the list of received business cards.
2. Scroll to the business card you want to read, press Select for the following
options:
• Scroll to View and press Select to view the business card.
• Scroll to Save and press Select to save the new business card as a Phone
Book entry.
• Scroll to Discard and press Select to abort this business card without saving.
You can also edit and send your own business card(See "Your own business
card"on page 39) or send Phone Book entry to another person as business
card(See "Sending an entry as business card"on page 33).
Downloading operator logo
Operator logo download is an extra service. You can replace the operator
name shown on the screen with the new logo. When the operator logo is
received, “New operator logo” prompt will appear on the screen and your
phone alert will also be generated (depending on your sound profile setting).
Press Detail to access the following options:
• Scroll to Show and press Select to view the operator logo.
• Scroll to Save and Select to replace the old logo with the new one.
• Scroll to Discard and Select to abort this logo without saving.
Downloading ring tone
Ring tone download is an extra service. When the ring tone is received, “New
ringtone” prompt will appear on the screen and your phone alert will also be
generated (depending on your sound profile setting). Press Detail to access
the following options:
• Scroll to a desired ring tone and press Select.
• Scroll to Play and press Select to play the ring tone.
• Scroll to Save and press Select to save as a profile.
• Scroll to Discard and press Select to abort this ring tone without saving.
Basic Operations
26
Entering Text
The phone provides several input methods that enable you to enter text in
Phone Book, write a message..., etc. You can also switch among these input
methods easily.
When you add a new entry to your Phone Book (see "Adding a Phone Book
entry"on page 31) or write a new message (see "Writing and sending new
messages"on page 45), the following text editor screen appears:
Selecting an input mode
1. Press key. Available input modes will appear on the screen.
2. Scroll to the desired input method and press Select. The selected mode will
appear on the upper right corner of the screen.
• abc mode: Allows you to enter lower case letters.
• ABC mode: Allows you to enter upper case letters.
• Abc mode: The first letter entered is automatically capitalized.
• 123 mode: Allows you to enter numbers.
• T9 English: Allows you to enter text using T9 English input method.
• Symbol: Allows you to enter punctuation marks and symbols.
Entering Latin characters and words
Entering characters and words using multi-tap input methods
1. Select abc, ABC or Abc mode in the input mode selection menu.
Phone Book editor screen Message editor screen
Remaining number of characters
available for input
Current input mode
If the content of message is longer than
160 characters, it will be split and sent via
several messages. The number of the split
messages is shown in the brackets here.
27
Basic Operations
2. Press a key and the corresponding letters will appear in a bar on the lower
part of the screen.
3. Press the key several times to highlight the desired letter (or number) and it
will be entered when the bar disappears. You can also proceed to enter the
next letter when the desired letter (or number) is highlighted. The remain-
ing number of letters you can enter is shown on the upper right corner of
the screen.
Long press key to switch between upper and lower cases.
The table below shows the mapping of each key and the corresponding letter
in different input modes.
Keys Input Modes
ABC abc 123
(Space)
Basic Operations
28
Entering text using T9 English input method
The T9 English input method is able to detect your key presses and combine
them into possible words automatically for you to select. This can dramatically
reduce the time you need to select correct characters and words using conven-
tional input method.
To use T9 English input method:
1. Select T9 English in the input mode selection menu.
2. Type the word you want to enter using the keypad. For example, if you
want to enter the word "phone", press .
3. If the word that appears on the screen is not the desired one, press Up or
Down to scroll to the word you want.
4. To enter the word and add a space after the word, press .
Long press key to switch between upper and lower cases.
Entering numbers
1. Select 123 in the input mode selection menu.
2. Enter numbers using the alphanumeric keys.
Entering symbols
1. Select Symbol in the input mode selection menu.
2. Scroll to the symbol you want to enter and then press Select.
29
Basic Operations
Erasing textIf you have entered a wrong character or number, press Clear to erase. Long
press Clear will clear a whole line.
Press Left or Right to move the cursor backward/forward.
Using key lock
The key lock helps to prevent unwanted key operations when you carry your
phone.
• To enable key lock:
In standby mode, press the left soft key, then key.
• To unlock:
Press Unlock, and then press key.
30
Phone Book
31
Phone Book
Adding a Phone Book entry
You can add a new entry to Phone Book in the following ways:
Method 1 1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Add and press Select.
3. You will be prompted to enter the name of the entry. Enter the name and
press OK.
4. Enter the phone number and press OK.
Method 2 1. In standby mode, enter the number using the alphanumeric keys.
2. Press Save. You will be prompted to enter the name of the entry. Enter the
name and press OK.
Method 3 1. During a call, enter the number using the alphanumeric keys.
2. Press Save. You will be prompted to enter the name of the entry. Enter the
name and press OK.
Method 4
1. In standby mode, press key to enter the dialed calls list.
2. Scroll to a desired number and then press Options.
3. Scroll to Save and press Select.
4. You will be prompted to enter the name of the entry. Enter the name and
press OK.
Searching for a Phone Book entry
To search for a Phone Book entry:
1. In standby mode, press the right soft key to enter the Phone Book.
When entering the name of a new entry to phone book, it allows you to enter a maximum of 4
Chinese characters or 10 Latin characters. When entering the phone number, a maximum of
20 numbers(including symbols) is allowed.
Note
Phone Book
32
2. Press Select.
3. Enter the name of the Phone Book entry you want to look for. You can also
enter only the beginning few letters of the name.
4. Press OK, The entries that match the name (or contain the letters) you
entered will appear on the screen. You can also press UP or Down in
standby mode to enter the phone book for searching.
Editing a Phone Book entry
Editing name
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name and press Options.
4. Press Select.
5. Edit the name and when finished, press OK.
Editing number
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the number and press Options.
4. Scroll to Edit in the menu that appears and press Select.
5. Edit the number and when finished, press OK.
Adding new phone number to existing entries
You can store up to four different phone numbers under a Phone Book entry
that is stored in the phone memory(See "Selecting Phone Book memory"on
page 41).
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name (or number) and press Options.
4. Scroll to Add number and press Select.
5. Enter the new number and when finished, press OK.
6. You will be prompted to select a type for the new number. Scroll to an
appropriate type and press Select.
Adding notes to existing entries
33
Phone Book
You can add four types of notes to a Phone Book entry that is stores in the
phone memory.
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name (or number) and press Options.
4. Scroll to Add text and press Select:
• Note: Enter notes.
• E-mail: Enter e-mail addresses.
• Postal address: Enter postal addresses.
• Web address: Enter the web addresses.
5. Scroll to a desired type and press Select.
6. Enter the text and press OK when finished.
Changing caller group
The Caller group function allows you to separate your Phone Book entries in
different groups. For details about the Caller group function, please refer to
"Setting up Caller Group"on page 37.
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name (or number) and press Options.
4. Scroll to Change group and press Select.
5. Scroll to a desired caller group and press Select.
Sending an entry as business card
With this function, you can send the details of a Phone Book entry to another
person as a business card. If the recipient’s phone supports business card for-
mat, it can be saved as a new Phone Book entry.
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the name (or number) and press Options.
4. Scroll to Send business card and press Select.
5. If the entry you selected has more than one phone number, scroll to one of
the followings and press Select:
Send default number: Allows you to send the default number of the entry to
another person.
Send details: Allows you to send all phone numbers of the entry to another
person.
6. If you want to send the business card as a new message immediately, scroll
to Send as SMS and press Select. Enter the number of the recipient (or pick
Phone Book
34
up a recipient from Phone Book by pressing Names) and press Send. If you
are not sure whether the recipient's phone supports business card format,
scroll to Send as text and press Select. You can edit the contents before
sending it.
If you added notes to a Phone Book entry, only e-mail address will be attached
when you send the entry as a business card.
Assigning default phone number
If you have multiple phone numbers in a Phone Book entry, you can assign
one of these numbers as default number. This default number is dialed when
you make a call from the Phone Book or using the Speed Dial function.
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the number you want to set as default and press Options.
4. Scroll to Set as default and press Select.
Changing the type of number
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the number and press Options.
4. Scroll to Change type and press Select.
5. Scroll to a desired type for the number and press Select.
Sending messages from Phone Book
To send a new message from Phone Book:
1. Scroll to a Phone Book entry.
2. Press Detail.
3. Scroll to the number and press Options.
4. Scroll to Send message and press Select.
5. Compose the message. When finished, press Options and then Select to
send the message.
For how to write a message, please refer to "Writing and sending new mes-
sages"on page 45.
Erasing Phone Book entry
Method 1
35
Phone Book
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Erase and press Select.
To erase Phone Book entries one by one:
1. Scroll to One by one and press Select.
2. Scroll to select the Phone Book entry you want to erase and press OK.
3. Press OK.
To erase all Phone Book entries:
1. Scroll to All.
2. To delete all Phone Book entries stored in phone memory, scroll to Phone.
To delete entries on the SIM card, scroll to SIM.
3. Press Select, and then press OK.
4. Enter your phone code and press OK. For more information about phone
code, see "Phone security settings"on page 84.
Method 2 1. In Phone Book, scroll to the entry you want to erase and press Detail.
2. Scroll to the name (or number) and press Options.
3. Scroll to Erase and press Select, OK.
Copying Phone Book entry
With the copy function, you can copy (or moving) Phone Book entries in the
phone memory to SIM card memory and vise versa. Please note that if you
copy a Phone Book entry with multiple numbers from phone memory to SIM
card, only the first (default) number will remain.
Method 1 1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Copy and press Select.
To copy Phone Book entries from phone to SIM card:
• Press Select. You can choose to copy Phone Book entries one by one or all
at once.
• Select Keep original (copy the Phone Book entry to a new location) or
Move original (move the Phone Book entry to a new location).
To copy Phone Book entries from SIM card to phone:
• Scroll to SIM to phone and press Select. You can choose to copy Phone
Book entries one by one or all at once.
Phone Book
36
• Select Keep original (copy the Phone Book entry to a new location) or
Move original (move the Phone Book entry to a new location).
Method 2 1. In Phone Book, scroll to the entry you want to copy and press Detail.
2. Scroll to the name (or number) and press Options.
3. Scroll to Copy and press Select.
4. If you want to keep the original and make a copy to another location (i.e, if
your Phone Book is using SIM card memory, it will be copied to the phone
memory and vise versa), scroll to Keep original. To move the entry to
another location, scroll to Move original.
5. Press Select.
Setting up Speed Dial
Speed Dial is a shortcut that allows you to make a call simply by long pressing
alphanumeric keys ~ . To use this function, you have to activate
speed dialing function(please see "Speed dialing"on page 71 for details).
To set up speed dial:
Method 1 1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Speed dial and press Select.
3. Choose an empty speed dial key and press Change.
4. Your Phone Book entries will appear on the screen. Pick up a number and
press OK.
Method 2 1. Long press a key that has not been assigned a speed dial number.
2. The screen will prompt you to assign the speed dial key. Press OK.
3. Press Change.
4. Your Phone Book entries will appear on the screen. Pick up a number by
pressing OK.
Viewing speed dial number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Speed dial and press Select.
37
Phone Book
3. On the speed dial list that appears, scroll to a number you want to view.
4. Press Options and select View.
Changing speed dial number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Speed dial and press Select.
3. On the speed dial list that appears, scroll to a number you want to change.
4. Press Options and select Change.
5. Your Phone Book numbers will appear on the screen. Pick up a new num-
ber by pressing OK.
Erasing speed dial number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Speed dial and press Select.
3. On the speed dial list that appears, scroll to a number you want to erase.
4. Press Options and select Erase.
Setting up Caller Group
You can place your Phone Book entries under different Caller Groups and
give each Caller Group different ringtone, backlight and screen graphic. When
you have an incoming call, you can judge the caller by its specific Caller
Group.
Your phone provides 5 pre-configured caller groups. You can also customize
the caller group settings.
Changing caller group settings
Changing caller group name
1. Enter Phone Book by pressing the right soft key in standby mode.
• For using the Caller Group function, you have to set up Incoming call alert as Group in the
Sound profiles and select a corresponding caller group(Please see "Customizing a sound pro-
file"on page 75).
• Each phone book entry can only pick up a corresponding Caller Group.
Note
Phone Book
38
2. Scroll to Caller group and press Select.
3. The Caller Group list will appear on the screen. Scroll to a caller group and
press Select.
4. Press Select.
5. Enter a new name of the Caller Group.
6. Press OK.
Changing caller group ringtone
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Caller group and press Select.
3. The Caller Group list will appear on the screen. Scroll to a caller group and
press Select.
4. Scroll to Ring tone and press Select.
5. Scroll to a desired ring tone and press OK.
Changing caller group graphic
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Caller group and press Select.
3. The Caller Group list will appear on the screen. Scroll to a caller group and
press Select.
4. Scroll to Graphic and press Select.
5. Press On (display graphic) or Off (do not display graphic).
6. If On is selected, scroll to View and press Select to view available graphics.
Scroll to a desired graphic and press OK.
Miscellaneous settings
Personal number
If your SIM card supports, your phone number will be recognized and dis-
played here. Otherwise, you need to specify your phone number manu-
ally.You can specify up to 2 numbers.
Adding a personal number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Personal number and press Select.
3. Scroll to Add and press Select.
4. Enter your name and phone number. When finished, press OK.
39
Phone Book
Editing personal number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Personal number and press Select.
3. Scroll to the number you want to edit and press Options.
4. Scroll to Edit and press Select.
5. Edit the name and number. When finished, press OK.
Erasing personal number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Personal number and press Select.
3. Scroll to the number you want to erase and press Options.
4. Scroll to Erase and press Select.
5. Press OK.
Your own business card
With the business card function, you can edit your personal information and
send it to other person via a short message.
Creating your own business card
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to My own card and press Select.
3. Scroll to Edit and press Select.
4. Enter your personal information. When finished, press Save.
Viewing your business card
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to My own card and press Select.
3. Press Select.
Sending your business card
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to My own card and press Select.
3. Scroll to Send my own card and press Select.
4. If you want to send the business card as a new message immediately, scroll
to Send as SMS and press Select. Enter the number of the recipient (or pick
up a recipient from Phone Book by pressing Names) and press Send.
If you want to edit the business card before sending it, scroll to Send as text
and press Select.
Phone Book
40
Before sending a business card, you can specify the contents of the informa-
tion.
1. Scroll to Info. setting and press Select.
2. Scroll to an item and press Off or On. Only checked items will be included
in the business card.
Editing your business card
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to My own card and press Select.
3. Scroll to Edit and press Select.
4. Edit the contents of your business card. When finished, press Save.
Erasing your business card
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to My own card and press Select.
3. Scroll to Erase and press Select.
4. Press OK.
Fixed dial number
If your SIM card supports, you can use this function to restrict outgoing calls
only to the numbers (or the numbers that begin with the same digit(s)) on the
fixed dial list.
Activating Fixed dial
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Press On.
4. Enter your PIN 2 code and press OK.
Adding new Fixed dial number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to Number list and press Select.
4. Press Select.
You need to enter PIN2 code to set up this function.
Note
41
Phone Book
6. Enter your PIN 2 code and press OK.
7. Enter the name of the fixed dial number and press OK.
8. Enter the number and press OK.
Viewing Fixed dial number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to Number list and press Select.
Editing Fixed dial number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to Number list and press Select.
4. Scroll to a Fixed dial number and press Options.
5. Scroll to Edit and press Select.
6. Enter your PIN2 code and press OK.
7. Edit the name and number. When finished, press OK.
Erasing Fix dial number
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Fixed dial number and press Select.
3. Scroll to Number list and press Select.
4. Scroll to a Fixed dial number and press Options.
5. Scroll to Erase if you want to erase selected Fixed dial number. If you want
to erase all fixed dial numbers, scroll to Erase all. Press Select.
6. Enter your PIN2 code and press OK.
7. Press OK to confirm.
Phone Book memory setting
Selecting Phone Book memory
You can select the memory to use for your Phone Book.
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Option and press Select.
3. Press Select.
4. Scroll to SIM and press OK if you want to use SIM memory, or scroll to
Phone and press OK if you want to use phone memory.
Phone Book
42
Checking Phone Book memory status
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Option and press Select.
3. Scroll to Memory status and press Select.
Looking up a dialing number
If you activate this function, your phone will search for possible correspond-
ing entries from the Phone Book and display them on the bottom of the
screen when you are entering a Latin character by pressing alphanumeric keys
in standby mode.
1. Enter Phone Book by pressing the right soft key in standby mode.
2. Scroll to Option and press Select.
3. Scroll to Dialing number lookup and press On.
43
The Main Menu
The Main Menu
Overview
44
Overview
The main menu of your phone is accessed by pressing the left soft key in
standby mode.
Press Up or Down to scroll the menu.
Press Right or Select to view the contents of the menu or select an option.
Press Left or Exit to return to previous menu or abort selection.
You can also navigate using the quick access keys:
1. In standby mode, press the left soft key.
2. Press the quick access keys. For example, to go to Dialed calls, press , Select, .
See “Appendix” on page 121 for the quick access keys.
To navigate in the Main Menu
The Main Menu
Message
45
Message The options in the Message menu allow you to write, send and receive mes-
sages and setup message settings.
Writing and sending new messages
You can write and send text messages. Your phone supports EMS (Enhanced
Messaging Service) standard which allows you to insert picture, sound, anima-
tion and melodies..., etc. in a message.
To write a new message:
1. In standby mode, press the left soft key, Select.
2. Press Select two times.
3. Enter the contents of the message. When writing, you can press Options to
access the options below:
• Send: Send the message immediately. If this option is selected, you will be
prompted to enter the number of the recipients. You can also pick up recip-
ients from your Phone Book by pressing Names.
The message can be sent to one recipient and copy to up to 9 recipients.
• Save: Save the message as a draft in Outbox. You have to enter the recipi-
ent’s phone number before you save.
• Insert template: Insert preset messages template. You can also customize
your own templates. Please refer to "Customizing preset message tem-
plates"on page 48 for how to customize message templates.
• Insert picture: Insert a picture into the message. You can also draw your
own picture. For details, refer to "My Picture"on page 90.
• Insert animation: Insert an animation into the message.
• Insert sound: Insert sound effect into the message. The icon will
appear on the screen.
Before you can use Message functions, make sure that related message settings are configured
properly. (Depending on your operator, the settings may have already been programmed on
the SIM card). Refer to "Message settings"on page 53 for details.
Note
The recipient’s phone must also support EMS functionality to receive and view your EMS mes-
sages.
Note
The Main Menu
Message
46
• Insert melody: Insert a ring tone melody into the message. The icon
will appear on the screen.
You can also send a message from message templates. Please refer to "Sending
a message from templates"on page 48 for details.
Viewing sent messages
The draft and sent messages are automatically stored in the Outbox. To open
the Outbox and check these messages:
1. In standby mode, press the left soft key, Select.
2. Press Select.
3. Scroll to Outbox and press Select. A list of draft and sent messages will
appear on the screen. The icon that appears in front of a message indicates
the status of the message.
4. Scroll to a message and press Select. The message will be opened.
5. Press Options and you can also choose to perform the following operations
to selected message.
• Erase: Erase current message.
• Send: Send this message to other recipients.
• Edit: Edit current message. You can send the message after you finish edit-
ing.
• Use address: Capture the numbers in the message. The numbers captured
will appear on the screen. Scroll to a number and press Select. You can call
the number directly or save it in Phone Book.
Viewing received messages
When a new message is received, the new message prompt and the icon
will appear on the screen.
Press Detail. The list of received messages will appear on the screen.
Icon Status of message
Unsent message
Sent message
The Main Menu
Message
47
Viewing received messages in the Inbox
The messages you received are stored in the Inbox.
To open Inbox and view received messages:
1. In standby mode, press the left soft key, Select.
2. Press Select.
3. Scroll to Inbox and press Select. A list of received messages will appear on
the screen. The icon that appears in front of a message indicates the status
and type of it.
4. Scroll to a message you want to read and press Select. The contents of the
message will be opened to the screen.
5. You can press Options to perform the following operations:
• Erase: Erase current message.
• Reply: Reply to current message.
• Forward: Send this message to other recipients.
• Edit: Edit current message. You can send the message after you finish edit-
ing.
• Use address: Capture the numbers in the message. The numbers captured
will appear on the screen. Scroll to a number and press Select. You can call
the number directly or save it in Phone Book.
Icon Status of message
Unread message
Read message
Unread e-mail message
Read e-mail message
Unread Fax message
Read Fax message
Unread paging message
Read paging message
Unread message in any other format
Read message in any other format
The Main Menu
Message
48
• Call back: Make a call to the sender of current message.
• Open chatroom: Open a new chatroom session with the sender of current
message. You can also add other members to the chatroom.
Customizing preset message templates
Templates are frequently used phrases preset in phone memory. When writing
a message, you can insert them into your message directly. You can also cus-
tomize your own templates.
Customizing message template
1. In standby mode, press the left soft key, Select.
2. Press Select.
3. Scroll to Template and press Select.
4. Scroll to an empty template and press Select.
5. Scroll to Edit template and press Select.
6. Write the contents of the template. When done, press Save.
Erasing customized message template
1. In standby mode, press the left soft key, Select.
2. Press Select.
3. Scroll to Template and press Select.
4. Scroll to a customized template and press Select.
5. Scroll to Erase template and press Select.
Sending a message from templates
1. In standby mode, press the left soft key, Select.
2. Press Select.
3. Scroll to Template and press Select.
4. Scroll to a template you want to send and press Select.
5. Press Select.
6. Enter the recipients number or pick one from Phone Book by pressing
Names.
7. Press Send and the message will be sent.
Erasing all messages
This function allows you to erase all messages in Inbox and Outbox.
The Main Menu
Message
49
1. In standby mode, press the left soft key, Select.
2. Press Select.
3. Scroll to Erase all and press Select.
4. Press Erase.
Multimedia messages
You can write and send multimedia messages. Your phone supports MMS
(Multimedia Messaging Service) standard which allows you to insert color
picture, sound, animation and melodies..., etc. in a message and to send the
message to an e-mail address.
Writing and sending multimedia messages
To write a new message:
1. In standby mode, press the let soft key, Select.
2. Scroll to Multimedia msgs. and press Select two times.
3. Enter the contents of the message. When writing, you can press Options to
access the options below:
• Send: Send the message immediately. You will be prompted to enter the
number of the recipients. You can also press Options, scroll to Add recipient
and press Select. Scroll to Number and press Select to pick up one recipient
from your Phone Book by pressing Names. Scroll to e-mail address and
press Select to enter the recipient’s e-mail address.
Scroll to Sending options and press Select to access the options below:
Status report: Turn on/off a message delivery status report.
Validity period: Select a validity period.
• Save to outbox: Save the message as a draft in Outbox.
• Insert object: Insert multimedia objects, preset messages template and
phone number. The inserted object is represented by an icon that appears on
the upper right corner of the screen( represents an inserted image,
represents an inserted sound).
• Add new page: Add a new page for writing messages.
• You have to subscribe to your operator for the Multimedia msgs. service. Please consult your
operator for more information.
• The recipient’s phone must also support MMS functionality to receive and view your MMS
messages.
Note
