Chuango Security Technology P70 HD Wi-Fi Camera User Manual
Chuango Security Technology Corporation HD Wi-Fi Camera Users Manual
Users Manual
Printed in China
PA: P70-QG-ML-V1.0
© 2017 SMANOS HOLDING LTD. All Rights Reserved.
P70
HD WiFi Camera
MULTILINGUAL
USER MANUAL
EN DE ESFR PTNL IT
ENEN
Overview
• Front View
LED Indicators
Camera
Microphone
Bracket
WiFi Pairing State Red LED Indicator Blinks once per
second
Realtime View Red LED Indicator Blinks every 2
seconds
Searching for
Network Blue LED Indicator Constantly Blinking
Connected to a
Network Blue LED Indicator Solid
Privacy Mode Red & Blue LED
Indicator Solid
• Side View • Back View
Reset button
microSD Card
Slot
Heat Vent
Power Jack
microSD Card (Not included)
Support 32GB microSD card maximum; please do not insert the
card after the camera is powered on.
Note: Please format your microSD card before inserting into this slot if any
le had been written in.
ENEN
What is inside the box
WiFi Camera×1 AC Adapter×1
Quick guide×1 Reset Pin×1
Pairing Camera with WiFi through App
Download the App by searching “P70 camera” from App Store or
Google Play.
P70 Camera
ENEN
Installation
Important: This camera should be placed where the WiFi signal is
strong for optimal performance.
1. Separate the mounting
template on the bottom
of this camera from the
bracket by pressing the
snap as picture shows
2. Mount the template on the
wall by using the supplied
screws
3. Push and press the bracket
of the camera into the
template carefully, and then
adjust the angle to achieve
best shooting effect
Specications
Image sensor
Min. illumination
Shutter time
Lens
Angle of view
Video compression
Bit rate
Max. image resolution
Frame rate
Storage
Wireless standards
Frequency range
Channel bandwidth
Operating conditions
Power supply
Power consumption
Dimensions (L x W x H)
Sony 1/2.9" CMOS sensor
Color: 0.01Lux@ (F1.2, AGC ON)
Black and white : 0.001Lux@
(F1.2, AGC ON)
1/50s to 1/100,000s
2.4mm F2.0
115°
H.264
Self-adaption
1920 X 1080
20fps (1920 X 1080)
Built-in microSD card slot, up to 32GB
IEEE802.11b/g/n
2.412 GHz ~ 2.462 GHz
20/40MHz Support
Temperature: 0 °C - 60 °C
(32 °F - 140 °F)
Humidity: < 95% (non-condensing)
DC 5V 1A
5W MAX
80 x 80 x 150 mm
FCC Warning：
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference (2) this device must
accept any interference received, including interference that may cause undesired
operation.
FCC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment .This
equipment should be installed and operated with minimum distance 20cm between the radiator& your body.
IC RSS warning
This device complies with ICDC licence-exempt RSS standard (s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference,including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment .This
equipment should be installed and operated with minimum distance 20cm between the radiator& your body. This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Le rayonnement de la classe b repecte IC fixaient un environnement non contrôlés.Installation et mise en œuvre
de ce matériel devrait avec échangeur distance minimale entre 20 cm ton corps.Lanceurs ou ne peuvent pas
coexister cette antenne ou capteurs avec d’autres.
