Chuango Security Technology SS20 SS-20 Indoor Siren User Manual
Chuango Security Technology Corporation SS-20 Indoor Siren
User Manual
SS-20
Indoor Siren
USER MANUAL
EN DE ESFR PTNL IT
© 2017 SMANOS HOLDING LTD. All Rights Reserved. Ver: SS-20-UM-ML-V1.0
Printed in China
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
2. Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital, pursuant to Part 15 or the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not in stalled and used in
accordance with the instructions, may casue harmful interference
to radio communications, However, there is no guarantee
that interference will not occur in a particular installation. If
the equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
--- Reorient or relocate the receiving antenna.
--- Increase the separation between the equipment and receiver.
--- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
--- Consult the dealer or an experienced radio/ TV technician for
help.
Industry Canada Notice
This device complies with Industry Canada licence-exempt RSS
standard(s).
1. Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interferencethat may cause undesired operation of the device."
2.Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
Avis d'Industrie Canada
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes : (1) l'appareil ne doit pas produire
de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement. Cet appareil numérique ne dé
passe pas les Rèlements sur l'interférence radio par un appareil num
érique de classe B stipulées dans les Règlement sur l'interférence
redio d'industrie Canada.
Introduction
The SS-20 Indoor Siren will go off on-site, with a loud 90dB siren
sound, to deter any would-be intruders when a sensor of K1
system has been triggered It is smart to have 2-4 sirens strategically
placed around the your home as it easily deters any intruder if they
defeated one siren but still hear NOISE! Intruders DO NOT like
attention. Also consider a smanos SS-2800 outdoor Strobe Siren for
even more noise and attention with the ashing strobe.
Pairing to the K1 Hub
This Siren needs to be paired to the K1 Hub rst before use. To pair
the Siren, please refer to the K1 Hub’s user manual or in the K1
section of the smanos home app, press the "+" button and follow
the instructions on the Accessories page to easily add your smanos
SS-20 siren.
Product Overview
Back View with mounting plate & level
;6ɑ
Tamper LED Indicator
Switch
LED Indicator
Blinks rapidly: K1 system is alarming.
Blinks once per 3 seconds: Low battery, please change the batteries.
Tampering Switch
Anti-tampering protection ensures that any attempts to remove
the cover results in the alarm sounding as well as email and push
notication.
Installation
The Siren can be placed in any location as long as it is within the
range with K1 Hub
;6ɑ
Set the entire system status to
Arm and then press the Tamper
Switch on the backside of the SS-
20 (as shown) to trigger an alarm
which conrms the connection
with K1 Hub
;6ɑ
Install the Siren using either the double-sided tape or the screws
with mollys included in the package.
Notice: Removing the Back Cover will result in triggering the
system and the siren sounding. You can disarm simply the alarm
with the app or KP-20 and continue the installation.
Specications
Model: SS-20
Power: 3V CR123A Li-Mn battery x 4 pcs
Sound: 90 Decibels
Frequency: 915MHz
Wireless range: ≤ 80 m (in open area)
Operating conditions:
0-50°C / 32° - 122°F, humidity < 90% RH (non-condensing)
Dimensions (L x W x H): 85 x 85 x 37mm / 3.35" x 3.35" x 1.46"
