Cisco_Aironet 1570 Series_Datasheet

© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Confidential. - DRAFT Page 1 of 10
PRELIMINARY Data Sheet
Next-Generation Outdoor Wireless
Dual-band 2.4 and 5 GHz with 802.11ac Wave 1
support on the integrated 5-GHz radio
Cisco® CleanAir technology provides integrated
spectrum intelligence for a self-configuring and
self-healing network
ClientLink improves reliability and coverage for
legacy clients
Improved 802.11ac range and performance with
4x4:3 multiple-input multiple-output (MIMO)
technology
1.3 Gbps data rates
Multiple-radio support (802.11b/g/n, 802.11a/n/ac)
DOCSIS 3.0/EuroDOCSIS/JapanDOCSIS 3.0,
16x8 hybrid fiber-coaxial (HFC) cable modem
option
Improved radio sensitivity and range performance
with four antenna MIMO and three spatial streams
Multiple uplink options (Gigabit Ethernet-
10/100/1000 BaseT, Fiber SFP, interface-cable
(certain models)
NEMA Type 4X certified enclosure
Cisco Aironet 1572IC
Internal Antennas with Cable modem model
Cisco Aironet 1572EC
Cable modem model with External Antennas
Cisco Aironet 1572EAC
External antenna model
Cisco Aironet 1570 Series Outdoor Access Point
High-Performance Outdoor Wireless
The Cisco® Aironet® 1570 Series Outdoor Access Point with
Cisco CleanAir technology is the industry’s first enterprise and
carrier-grade 802.11ac access point to create a self-healing and self-
optimizing wireless network that mitigates the impact of wireless
interference. It offers a flexible, secure, and scalable mesh network
for high-performance mobility across large metropolitan-sized areas,
enterprise campuses, manufacturing yards, and mining pits.
The Cisco Aironet 1570 Series supports multiple-device and
multiple-network application delivery such as real-time seamless
mobility, video surveillance, 3rd Generation (3G) and 4G data offload,
and public and private Wi-Fi access. Designed to meet customer
needs in a broad range of industries, the Cisco Aironet 1570 Series
offers the following benefits:
Flexible deployment options: Access or mesh network,
extension of an Ethernet network, and Ethernet, fiber,
wireless, or cable backhaul.
Service provider support: Wi-Fi for next-generation mobile
data offload and personalized mobile services.
Cisco CleanAir technology: Integrated spectrum intelligence to detect, classify, and mitigate RF interference
from unauthorized wireless bridges or malicious devices.
High-bandwidth video surveillance over Wi-Fi without the high cost of installing cables over long distances.
High-performance, multipurpose network with low CapEx and OpEx.
Integrated wired and wireless: The Cisco Borderless Network Architecture provides cost savings with
end-to-end network access solutions that include wireless, switching, routing, and security.
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 2 of 10
Flexible, High-Performance Mesh
The Cisco Aironet 1570 Series Outdoor Access Point offers a flexible, secure, and scalable mesh platform that is
part of the Cisco Unified Wireless Network and the Cisco Service Provider Wi-Fi solution. It offers high-
performance mobility across large metropolitan-sized areas and enterprise campuses, manufacturing yards, and
mining pits. Carrier-grade design allows service providers to take advantage of Wi-Fi for next-generation mobile
data offloads. The Cisco Aironet 1570 Series provides high-performance device access through improved radio
sensitivity and range with 802.11a/b/g/n/ac multiple-input multiple-output (MIMO) technology, with three spatial
streams. Multiple uplink and power options are available. The 802.3at-compliant, Power-over-Ethernet (PoE)
interface makes it easy to connect IP devices, such as IP video cameras. NEMA Type 4X enclosures help ensure a
robust system that can withstand demanding environments. The external antenna models include the option to
attach an external module to the Access Point and power off the 802.3at from that AP.
Cisco CleanAir Technology
The Cisco Aironet 1570 Series with Cisco CleanAir technology provides the highest-performance 802.11ac
connectivity for mission-critical outdoor networks by detecting interference from unauthorized devices, as well as
common outdoor interference sources, such as WiMAX networks and wireless bridging products. The 1570 Series
uses chip-level intelligence to create a spectrum-aware, self-healing, and self-optimizing wireless network that
mitigates the impact of wireless interference. Cisco CleanAir technology is a systemwide feature of the Cisco
Unified Wireless Network that improves wireless network quality by detecting RF interference that other systems
can’t recognize, identifying the source, locating it, and then making automatic adjustments to optimize wireless
coverage.
RF Excellence
Building on the Cisco Aironet heritage of RF excellence, the Cisco Aironet 1570 Series delivers industry-leading
performance for secure and reliable wireless connections. Industrial-grade parts, enterprise-class silicon-level
intelligence, and optimized radios deliver a robust mobility experience. The Cisco Aironet 1570 Series provides a
set of tools that deliver the robust, scalable wireless foundation required to realize the true potential of outdoor
wireless mobility:
Cisco ClientLink technology to raise uplink and downlink performance of and coverage to 802.11a/g/n/ac
clients
Radio resource management (RRM) for automated channel selection and power setting management of
access points
Advanced capabilities to select data rates, adjust power, and manage quality of service (QoS) for access
points
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 3 of 10
Centrally Managed Mesh Network
Central management and troubleshooting of the Cisco outdoor wireless access points prevent costly maintenance
service calls to outdoor locations. The Cisco Prime Infrastructure (CPI) works in conjunction with the Cisco Aironet
Access Points and Cisco Wireless LAN Controllers to configure and manage the wireless networks. With CPI,
network administrators have a single solution for RF prediction, policy provisioning, network optimization,
troubleshooting, security monitoring, and wireless LAN systems management. Cisco CleanAir technology is
integrated into the CPI to provide real-time information on your outdoor network. Wireless network security is also a
part of a unified wired and wireless solution. Cisco wireless network security offers the highest level of network
security, which helps ensure that data remains private and secure and that the network is protected from
unauthorized access.
Cisco Aironet 1572EAC External Antenna Access Points
The Cisco Aironet 1572EAC Outdoor Access Points are the standard models, dual-radio system with external
antenna ports that are compliant with IEEE 802.11b/g/n standards (2.4 GHz) and 802.11a/n/ac (5-GHz). The
1572EAC has four (4) external antenna connections which can be configured as a) four double-band 2/5GHz ports,
or b) two pairs of single-band (2.4 & 5 GHz). They have Ethernet and fiber Small Form-Factor Pluggable (SFP)
backhaul options. These models also have a PoE-out (802.3at) port that can power a video surveillance camera or
other devices. A Highly flexible AP, the Cisco Aironet 1572EAC is well equipped for municipal and campus
deployments, video surveillance applications, mining environments, and data offload.
Cisco Aironet 1572IC/1572EC Cable Modem Access Points
Where service providers have already invested in a broadband cable network, the Cisco next-generation outdoor
wireless mesh can seamlessly extend network connectivity with the Cisco Aironet 1572IC/1572EC access points
by connecting to its integrated cable modem interface. The Cisco Aironet 1572IC/1572EC Outdoor Mesh Access
Points are dual-radio systems with DOCSIS 3.0/EuroDOCSIS/JapanDOCSIS 3.0 (16x8 HFC) compliant cable
modem for power and backhaul. They have dual-band radios that are compliant with IEEE 802.11b/g/n (2.4 GHz)
and 802.11a/n/ac (5 GHz) standards. The 1572IC has an integrated, four-element, dual-band antenna and easily
fits within the 30 cm height restriction for service providers. The 1572EC has four external antenna connections,
that can be configures as 2/5 GHz dual-band or two 2.4 GHz plus two 5 GHz ports that support Omni and
directional antennas.
External and Integrated Antennas
The Cisco Aironet 1572E Outdoor Access Points can also use four Cisco AIR-ANT2568VG-N or four
AIR-ANT2547VG-N Antennas. These dual-band, omnidirectional, stick antennas have a gain of 6/8 dBi or 4/7 dBi
on bands 2/5 GHz respectively. The 1572 can also utilize a number of single or dual band antenna. A summary of
those antennas is listed in the below table.
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 4 of 10
The Cisco Aironet 1572I Outdoor Access Point includes a dual-band, integrated antenna radome. This antenna
has four omnidirectional antenna elements that have antenna gains of 4/6 dBi gain on bands 2/5 GHz respectively.
Product Specifications
Table 1 lists specifications for the Cisco Aironet 1570 Series.
Table 1. Cisco Aironet 1570 Series Product Specifications
Item
Specification
Part numbers
Cisco Aironet 1572IC Access Point with Internal antennas & DOCSIS 3.0 Cable Modem
AIR-CAP1572IC1-zzK9 where “zz” represents the regulatory domain.
AIR-CAP1572IC2-zzK9
AIR-CAP1572IC3-zzK9
AIR-CAP1572IC4-zzK9
Cisco Aironet 1572EC Access Point with External Antennas & DOCSIS 3.0 Cable Modem
AIR-CAP1572EC1-zzK9 where “zz” represents the regulatory domain.
AIR-CAP1572EC2-zzK9
AIR-CAP1572EC3-zzK9
AIR-CAP1572EC3-zzK9
Cisco Aironet 1572EAC Access Point with External Antennas
AIR-CAP1572EAC-zzK9 where “zz” represents the regulatory domain.
The “zz”Regulatory Domain options are (note: not all models available for all regulatory domains)
A-
C-
D-
E-
F-
H-
K-
M-
N-
Q-
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 5 of 10
Item
Specification
R-
S-
T-
Z-
UX
- Not all models available for all regulatory domains
- Not all regulatory domains have been approved. As they are approved, the part numbers will be available on the
Global Price List.
- The C1, C2, C3, C4 models are associated with the Upstream/Downstream cable modem analog filter and
DOCSIS 3.0 options as listed below:
o C1 5-42/ 54-1000 MHz North American DOCSIS 3.0
o C2 5-85/ 108-1002 MHz North American DOCSIS 3.0
o C3 5-65/ 108-1002 MHz EuroDOCSIS 3.0
o C4 5-65/ 108-1002 MHz JapanDOCSIS 3.0
802.11n Version 2.0
capabilities
4x4 MIMO with three spatial streams
Maximal ratio combining (MRC)
802.11n and 802.11a/g beamforming
20- and 40-MHz channels
PHY data rates up to 450 Mbps (40 MHz with 5 GHz)
Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
802.11 dynamic frequency selection (DFS)
Cyclic shift diversity (CSD) support
802.11ac Wave 1
capabilities
4x4 MIMO with three spatial streams
MRC
802.11ac beamforming
20-, 40-, and 80-MHz channels
PHY data rates up to 1.3 Gbps (80 MHz with 5 GHz)
Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx)
802.11 DFS
CSD support
DOCSIS 3.0 Capabilities
DOCSIS and EuroDOCSIS 3.0 16x8 cable modem provides:
Sixteen (16) bonded channels on the downstream with total throughput in excess of 600 Mbps (without overhead)
Eight (8) bonded channels on the upstream with total throughput in excess of 200 Mbps (without overhead)
Designed to meet DOCSIS 3.0 specifications as well as backward compatibility with existing DOCSIS 2.0, 1.1 and
1.0 networks
Enhanced packet processing technology to maximize performance
Channel-bonded cable modems must be used in conjunction with a cable modem termination system (CMTS) that
supports channel bonding per the DOCSIS 3.0 specifications. When used with a non-channel-bonded CMTS,
channel-bonded cable modems function as conventional DOCSIS 2.0 cable modems.
Data Rates Supported
802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates (2.4 GHz and 5 GHz):
GI2 = 800 ns
GI = 400 ns
20-MHz Rate (Mbps)
20-MHz Rate (Mbps)
6.5
7.2
13
14.4
19.5
21.7
1
MCS Index: The Modulation and Coding Scheme (MCS) index determines the number of spatial streams, the modulation,
the coding rate, and data rate values.
2
GI: A guard interval (GI) between symbols helps receivers overcome the effects of multipath delays.
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 6 of 10
Item
Specification
26
28.9
39
43.3
52
57.8
58.5
65
65
72.2
13
14.4
26
28.9
39
43.3
52
57.8
78
86.7
104
115.6
117
130
130
144.4
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 7 of 10
Frequency Band and 20-
MHz Operating Channels
-A Domain:
2.400 to 2.4835 GHz, 11 channels
5.280 to 5.320 GHz; 3 channels
5.500 to 5.560 GHz, 4 channels
5.680 to 5.700 GHz, 2 channels
5.745 to 5.825 GHz, 5 channels
-C Domain:
2.400 to 2.4835 GHz; 13 channels
5.725 to 5.850 GHz; 5 channels
-D Domain:
2.401 to 2.4835 GHz; 11 channels
5.725 to 5.875 GHz; 7 channels
-E Domain:
2.401 to 2.4835 GHz; 13 channels
5.470 to 5.725 GHz; 8 channels
-K Domain:
2.400 to 2.4835 GHz; 11 channels
5.250 to 5.825 GHz; 14 channels
-M Domain
2.400 to 2.4835 GHz; 13 channels
5.470 to 5.850 GHz; 12 channels
-N Domain:
2.400 to 2.4835 GHz; 11 channels
5.725 to 5.850 GHz; 5 channels
-Q Domain:
2.400 to 2.4835 GHz; 13 channels
5.470 to 5.725 GHz; 11 channels
-R Domain:
2.400 to 2.4835 GHz; 13 channels
5.250 to 5.725 GHz; 11 channels
-S Domain:
2.400 to 2.4835 GHz; 13 channels
5.725 to 5.850 GHz; 5 channels
-T Domain:
2.400 to 2.4835 GHz; 11 channels
5.470 to 5.850 GHz; 16 channels
-Z Domain:
2.400 to 2.4835 GHz; 11 channels
5.470 to 5.850 GHz; 12 channels
Note: This varies by regulatory domain. Refer to the product documentation for specific details for each regulatory domain.
Maximum Number of
Non-overlapping
2.4 GHz
5 GHz
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 8 of 10
Channels
802.11b/g:
20 MHz: 3
802.11n:
20 MHz: 3
● 802.11a:
20 MHz: 21
● 802.11n:
20 MHz: 21
40 MHz: 9
● 802.11ac:
20 MHz: 21
40 MHz: 9
80 MHz: 5
Note: This varies by regulatory domain. Refer to the product documentation for specific details for each regulatory domain.
Receive Sensitivity
802.11b (Complementary Code
Keying [CCK])
-101 dBm @ 1 Mbps
-98 dBm @ 2 Mbps
-92 dBm @ 5.5 Mbps
-89 dBm @ 11 Mbps
802.11g (non HT20)
-94 dBm @ 6 Mbps
-93 dBm @ 9 Mbps
-92 dBm @ 12 Mbps
-90 dBm @ 18 Mbps
-86 dBm @ 24 Mbps
-84 dBm @ 36 Mbps
-79 dBm @ 48 Mbps
-78 dBm @ 54 Mbps
802.11a (non HT20)
-92 dBm @ 6 Mbps
-91 dBm @ 9 Mbps
-89 dBm @ 12 Mbps
-87 dBm @ 18 Mbps
-85 dBm @ 24 Mbps
-81 dBm @ 36 Mbps
-77 dBm @ 48 Mbps
-76 dBm @ 54 Mbps
2.4-GHz
802.11n (HT20)
-93 dBm @ MCS0
-91 dBm @ MCS1
-89 dBm @ MCS2
-86 dBm @ MCS3
-82 dBm @ MCS4
-78 dBm @ MCS5
-77 dBm @ MCS6
-75 dBm @ MCS7
-93 dBm @ MCS8
-91 dBm @ MCS9
-89 dBm @ MCS10
-86 dBm @ MCS11
-82 dBm @ MCS12
-78 dBm @ MCS13
-77 dBm @ MCS14
-75 dBm @ MCS15
5-GHz
802.11n (HT20)
-92 dBm @ MCS0
-89 dBm @ MCS1
-87 dBm @ MCS2
-85 dBm @ MCS3
-81 dBm @ MCS4
-77 dBm @ MCS5
-76 dBm @ MCS6
-75 dBm @ MCS7
-90 dBm @ MCS8
-87 dBm @ MCS9
-85 dBm @ MCS10
-82 dBm @ MCS11
-78 dBm @ MCS12
-74 dBm @ MCS13
-73 dBm @ MCS14
-72 dBm @ MCS15
5-GHz
802.11n (HT40)
-89 dBm @ MCS0
-86 dBm @ MCS1
-84 dBm @ MCS2
-82 dBm @ MCS3
-78 dBm @ MCS4
-74 dBm @ MCS5
-73 dBm @ MCS6
-72 dBm @ MCS7
-87 dBm @ MCS8
-84 dBm @ MCS9
-82 dBm @ MCS10
-79 dBm @ MCS11
-75 dBm @ MCS12
-71 dBm @ MCS13
-70 dBm @ MCS14
-69 dBm @ MCS15
Maximum Transmit
Power
2.4 GHz
802.11b (CCK)
30 dBm with 4 antennas
802.11g (non HT duplicate mode)
30 dBm with 4 antennas
802.11n (HT20)
30 dBm with 4 antennas
5 GHz
802.11a
30 dBm with 4 antennas
802.11n non-HT duplicate (802.11a duplicate) mode
30 dBm with 4 antennas
802.11n (HT20)
30 dBm with 4 antennas
802.11n (HT40)
30 dBm with 4 antennas
802.11ac
non-HT80:30 dBm, 4 antennas
VHT20 30 dBm, 4 antennas
VHT40: 30 dBm, 4 antennas
VHT80: 30 dBm, 4 antennas
VHT20-STBC: 30 dBm, 4 antennas
VHT40-STBC: 30 dBm, 4 antennas
VHT80-STBC: 30 dBm, 4 antennas
Note: The maximum power setting will vary by channel and according to individual country regulations. Refer to the product documentation for
specific details.
Network Interface
10/100/1000BASE-T Ethernet, autosensing (RJ-45)
Fiber SFP
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 9 of 10
DOCSIS/EuroDOCSIS/JapanDOCSIS 3.0 (16x8) Cable modem interface (1572IC/1572EC)
Dimensions (L x W x D)
1572IC: 12.0 x 7.9 x 7.9 in. (30.5 x 20.1 x 20.1 cm)
1572EC/1572EAC: 12.0 x 7.9 x 6.2 in. (30.5 x 20.1 x 15.9 cm)
Weight
1572IC: 14.3 lbs (6.5 kg)
1572EC/1572EAC: 16.5 lbs (7.5 kg)
Cable strand mounting bracket 1 (SMK1): 0.7 lbs (0.3 kg)
Cable strand mounting bracket 2 (SMK2): 1.3 lbs (0.6 kg)
Pole mounting Kit 1 (PMK1): 2.2 lbs (1.0 kg)
Pole mounting Kit 2 (PMK1): 4.4 lbs (2.0 kg)
Pole mounting Kit 3 (PMK1): 6.1 lbs (2.8 kg)
Environmental
Operating temperature: -40 to 55°C (-40 to 131°F) plus Solar Loading
Storage temperature: -50 to 70°C (-58 to 158°F)
Wind resistance:
Up to 100-MPH sustained winds
Up to 165-MPH wind gusts
Environmental Ratings
IP67
NEMA Type 4X
Antenna Gain
Integrated Dual Band Omnidirectional Antenna Radome (1572IC)
4 dBi (2.4 GHz), 7 dBi (5 GHz)
External Dual-Band Omnidirectional Antennas (1572EC / 1572EAC)
AIR-ANT2568V-N (6 dBi (2.4 GHz), 8 dBi (5 GHz))
AIR-ANT2547V-N (4 dBi (2.4 GHz), 7 dBi (5 GHz))
External Dual-Band Directional Antennas (1572EC/1572EAC )
AIR-ANT2588P3M-R= (8 dBi (2.4 GHz), 8 dBi (5 GHz))
AIR-ANT2513P4M-N= (13 dBi (2.4 GHz), 13 dBi (5 GHz))
External Single Band Antennas (for 1572EC / 1572EAC)
2.4 GHz
AIR-ANT2420V-N (2 dBi, omni); right-angle
AIR-ANT2450V-N (5 dBi, omni)
AIR-ANT2480V-N (8 dBi, omni)
AIR-ANT2413P2M-N= (13 dBi, dual polarized patch)
5 GHz
AIR-ANT5140V-N (4 dBi, omni); right-angle
AIR-ANT5180V-N (8 dBi, omni)
AIR-ANT5114P2M-N= (14 dBi, dual polarized patch)
Powering Options
1572IC/1572EC
40-90 VAC, 50-60 Hz,
quasi-square wave,
Power over Cable
12 VDC
1572EAC
90-305 VAC, 50-60 Hz
12 VDC
UPOE
PoE with power injector
Warranty
1 year
Compliance
Safety
UL 60950, 2nd Edition
CAN/CSA-C22.2 No. 60950, 2nd Edition
IEC 60950, 2nd Edition
EN 60950, 2nd Edition
Immunity
<= 5 mJ for 6kV/3kA @ 8/20 ms waveform
ANSI/IEEE C62.41
EN61000-4-5 Level 4 AC Surge Immunity
EN61000-4-4 Level 4 Electrical Fast Transient Burst Immunity
EN61000-4-3 Level 4 EMC Field Immunity
EN61000-4-2 Level 4 ESD Immunity
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. - DRAFT Page 10 of 10
EN60950 Overvoltage Category IV
Radio approvals
FCC Part 15.247, 15.407
FCC Bulletin OET-65C
RSS-210
RSS-102
AS/NZS 4268.2003
EN 300 328
EN 301 893
EMI and susceptibility
FCC part 15.107, 15.109
ICES-003
EN 301 489-1, -17
Security
Wireless bridging/mesh
X.509 digital certificates
MAC address authentication
Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)
Wireless access
802.11i, Wi-Fi Protected Access (WPA2), WPA
802.1X authentication, including Extensible Authentication Protocol and Protected EAP (EAP-PEAP),
EAP Transport Layer Security (EAP-TLS), EAP-Tunneled TLS (EAP-TTLS), and Cisco LEAP
Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)
VPN pass-through
IP Security (IPsec)
Layer 2 Tunneling Protocol (L2TP)
MAC address filtering
Plan, Build, and Run Services for a Seamless Outdoor Experience
Professional services from Cisco and Cisco Advanced Wireless LAN Specialized Partners facilitate a smooth
deployment of the next-generation wireless outdoor solution, while tightly integrating it with the wired and indoor
wireless networks. Based on proven methodologies for planning and deploying end-to-end solutions with secure
voice, video, and data technologies and years of experience designing and implementing some of the world’s most
complex enterprise-class wireless networks, our specialists can help you optimize mobile connectivity to transform
your business operations.
We work with your IT staff to see that your architecture, physical sites, and operational staff are ready to support
Cisco’s integrated, next-generation, outdoor wireless solution that combines the high performance of the 802.11ac
standard and Cisco CleanAir technology.
For More Information
For more information about Cisco wireless mesh, contact your local account representative or visit:
http://www.cisco.com/go/outdoorwireless.
For more information about the Cisco Unified Wireless Network framework, visit:
http://www.cisco.com/go/unifiedwireless.
For more information about the Cisco service provider Wi-Fi solution, visit: http://www.cisco.com/go/ap1570.
For more information about the Cisco Wireless LAN Services, visit: http://www.cisco.com/go/wirelesslanservices.

Navigation menu
