Cisco Systems 802.11 a/b/g/n/ac Wireless Access Point UDX 60064010 Regulatory Booklet Rev8
Contents
- 1. UDX-60064010_Installation Guide
- 2. UDX-60064010_Regulatory Booklet_Rev8
UDX-60064010_Regulatory Booklet_Rev8
English
Read the installation instructions before using, installing or connecting the system to the
power source. Only trained and qualied personnel should be allowed to install, replace,
or service this equipment. Ultimate disposal of this product should be handled according to
all national laws and regulations. No user-serviceable parts inside. To avoid risk of electric
shock, do not open. Installation of the equipment must comply with local and national
electrical codes.
Български (Bulgarian)
прочетете инструкциите за инсталация преди използването, инсталирането или
свързването на системата към електрозахранването. Разрешено е само на обучен
и квалифициран персонал да инсталира, заменя или да обслужва това оборудване.
Изхвърлянето на този продукт трябва да се наnрави като се следват всички
национални закони и разпоредби. Не съдържа части, които могат да се обслужват
от потребителите. За да избегнете риска от електрически удар, не отваряйте.
Инсталирането на оборудването трябва да съbтветства на местните и националните
електрически изисквания.
Česky (Czech)
Před použitím, instalací nebo připojením systému ke zdroji napájení si přečtěte pokyny k
instalaci. Instalaci, výměnu nebo opravu tohoto zařízení smějí provádět pouze proškolené
a kvalikované osoby. Likvidace tohoto výrobku musí být provedena podle platných zákonů
a předpisů. Uvnitř zařízení se nenacházejí žádné díly, na kterých by mohl provádět údržbu
uživatel. Aby se předešlo riziku úrazu elektrickým proudem, zařizení neotevírejte. Instalace
zařízení musí splňovat příslušné místní a státní elektrotechnické normy.
Dansk (Danish)
Læs installationsvejledningen inden brug, installation eller inden systemet sluttes til
stromkilden. Kun uddannede personer må installere, udskifte komponenter i eller servicere
dette udstyr. Endelig bortskaelse af dette produkt skal ske i henhold til gældende love og
regler. Ingen brugerservicerbare dele indeni. Må ikke åbnes for at undgå risikoen for elektrisk
stød. Installation af udstyret skal overholde lokale og nationale elektriske forskrifter.
Deutsch (German)
Lesen Sie die Installationshinweise, bevor Sie das System nutzen, installieren oder an die
Stromversorgung anschließen. Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung
sollte nur geschultem, qualiziertem Personal gestattet werden. Die Entsorgung dieses
Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. Im Gerät
benden sich keine vom Benutzer zu wartenden Teile. Um Stromschlaggefahr zu vermeiden,
önen Sie das Gerät nicht. Die Installation der Geräte muss den Sicherheitsstandards
entsprechen.
Eesti (Estonian)
Enne seadme kasutamist, paigaldamist või elektrivõrku ühendamist lugege paigaldusjuhiseid.
Antud seadet tohib paigaldada, asendada ja hooldada vaid koolitatud ja kvalitseeritud
personal. Antud toote lõplik kõrvaldamine tuleb läbi viia kõigi riiklike õigusaktide ja
määruste alusel. Seadmel puuduvad kasutaja poolt hooldatavad osad. Elektrilöögi ohu
vältimiseks seadet mitte avada. Seadme paigaldus peab vastama kohalikele ja riiklikele
elektrieeskirjadele.
Español (Spanish)
Lea las instrucciones de instalación antes de usar, instalar o conectar el sistema a la fuente
de alimentación. Solamente el personal calicado debe instalar, reemplazar o utilizar
este equipo. Al deshacerse por completo de este producto debe seguir todas las leyes y
reglamentos nacionales. El interior no contiene ninguna pieza que el usuario pueda reparar/
mantener. Para evitar el riesgo de sufrir descargas eléctricas, no lo abra. La instalación del
equipo debe cumplir con las normativas de electricidad locales y nacionales.
Français (French)
lisez les instructions d’installation avant d’utiliser, d’installer ou de connecter le système à la
source d’alimentation. Il est vivement recommandé de coner l’installation, le remplacement
et la maintenance de ces équipements à des personnels qualiés et expérimentés. La mise
au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives
de respect de l’environnement. Renseignez-vous auprès de l’organisme compétent. Pas de
parties utilisables par l’utilisateur à l’intérieur. An d’éviter tout risque de choc électrique, ne
pas ouvrir. L’équipement doit être installé conformément aux normes électriques nationales
et locales.
Gaélico (Gaelic)
Leugh an treòrachadh airson stàladh mus cleachd thu, mus stàlaich thu, no mus ceangail
thu an siostam ris a’ chumhachd. Cha bu chòir ach daoine aig a bheil trèanadh is teisteanas
a bhith a’ stàladh, ag ath-sholar no a’ seirbheiseadh an uidheim seo. Bu chòir fhaighinn
cuidhteas seo aig a’ cheann thall a rèir gach lagh is riaghailt nàseanta. Cha ghabh gin de na
pàirtean am broinn seo a sheirbheiseadh leis an neach-cleachdaidh. Cunnart bho dhealan,
na fosgail. Feumaidh stàladh an uidheim a bhith a rèir riaghailtean ionadail is nàiseanta a
thaobh dealain.
Neatidarykite, kad išvengtumėte elektros smūgio pavojaus. Šios įrangos įdiegimas privalo
atitikti visus vietos ir nacionalinius elektros kodeksus.
Magyar (Hungarian)
Olvassa el a telepítési útmutatót, mielőtt használná, telepítené vagy csatlakoztatná a
rendszert az áramforráshoz. A berendezést csak szakképzett személyek helyezhetik üzembe,
cserélhetik és tarthatják karban. A készülék végsö elhelyezéséről az adott országban
érvényes törvények és elöírások szerint kell intézkedni. nem tartalmaz a felhasználó által
javítható alkatrészeket. Az áramütés elkerülése érdekében ne nyissa ki. A berendezés
üzembe helyezését a helyi és a nemzeti elektromossági elöírások gyelembevételével kell
elvégezni.
Malti (Maltese)
Aqra I-istruzzjonijiet għall-installazzjoni qabel tuża, tinstalla jew tikkonnettja s-sistema
mas-sors tad-dawl. Huwa biss persunal imħarreġ u kwalikat Ii għandu jitħalla jinstalla,
ibiddel, jew jisservisja dan it-tagħmir.Dan il-prodott għandu jintrema skont ma jitolbu I-liġijiet
u r-regolamenti kollha nazzjonali. Ma hemm I-ebda partijiet fuq ġewwa Ii jistgħu jiġi servisjati
mill-utent. Tiftaħx sabiex tevita r-riskju ta‘ xokk elettriku. L-installazzjoni tat-tagħmir għandha
tikkonforma mal-kodiċi dwar I-elettriku lokali u nazzjonali.
Nederlands (Dutch)
lees de installatie-instructies voordat u het systeem gebruikt, installeert of aansluit op een
stroombron. Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld
door bevoegd geschoold personeel. Het uiteindelijke wegruimen van dit product dient te
geschieden in overeenstemming met alle nationale wetten en reglementen. Dit product
bevat geen onderdelen waarop de gebruiker onderhoud kan uitvoeren. Niet openen, om het
risico op elektrische schokken te voorkomen. Bij installatie van de apparatuur moet worden
voldaan aan de lokale en nationale lektriciteitsvoorschriften.
Polski (Polish)
Przed eksploatacją, montażem lub podłączeniam systemu do zasilania przeczytaj instrukcję
montażu. Do instalacji, wymiany i serwisowania tych urządzeń mogą być dopuszczone
wyłącznie osoby wykwalikowane i przeszkolone. Ostateczna likwidacja tego urządzenia
po jego wycofaniu z eksploatacji powinna odbywać się zgodnie z przepisami krajowymi.
Urządzenie nie ma części przeznaczonych do wymiany przez użytkownika Aby uniknąć
porażenia prądem, nie należy otwierać urządzenia. Instalacja sprzętu musi być zgodna z
lokalnymi i krajowymi normami elektrycznymi.
Ελληνική (Greek)
Πριν από τη χρήση, την εγκατάσταση ή τη σύνδεση του συστήματος στην παροχή ρεύματος,
διαβάστε τις οδηγίες εγκατάστασης. Η τοποθέτηση, η αντικατάσταση και η συντήρηση του
εξοπλισμού επιτρέπεται να γiνονται μόνο από καταρτισμένο π με τα κατάλληλα προσόντα. Η
τελική απόρριψη αυτού του προiόντος πρέπει να γίνεται σύμφωνα με όλοuς τους εθνικούς
νόμους Και Κανονισμσύς. Στο εσωτερικό της συσκευής, δεν περιλαμβάνονται εξαρτηματα
που μπορούν να συντηρηθoύν από το χρήστη. Μην ανοίγετε τη συσκευή. Η εγκατάσταση
του εξοπλισμού πρέπει να συμμορφώνεται με τους τοπικους και εθνικους κώδικες
ηλεκτρολογικών εγκαταστάσεων.
Hrvatski (Croatian)
Prije upotrebe, ugradnje i priključivanja sustava na izvor napajanja pročitajte upute za
instaliranje. Uređaj smije ugrađivati, mijenjati iservisirati samo za to obučeno i osposobljeno
servisno osoblje. Zbrinjavanje ovoga proizvoda u otpad treba provesti u skladu s važećim
zakonima i odredbama. Unutra nema dijelova koje može servisirati korisnik. Ne otvarajte
kako bi izbjegli opasnost električnog udara. Instalacija opreme mora biti sukladna lokalnim i
nacionalnim normama izvedbe električnih instalacija.
Italiano (Italian)
leggere le istruzioni per l’installazione prima di usare, installare o collegare il sistema
all’alimentazione. Questo apparato può essere installato, sostituito o mantenuto unicamente
da un personale competente. Lo smaltimento di questo prodotto deve essere eseguito
secondo le leggi e regolazioni locali. Il sistema non contiene componenti che possono
essere sostituiti o riparati dall’utente. Per evitare il rischio di scosse elettriche, non aprire.
L’installazione dell’impianto deve essere conforme ai codici elettrici locali e nazionali.
Latviski (Latvia)
Pirms sistēmas izmantošanas, uzstādīšanas vai pievienošanas strāvas avotam izlasiet
uzstādīšanas instrukcijas. Tikai apmācītiem un kvalicētiem darbiniekiem ir atļauts uzstādīt,
nomainīt vai veikt šī aprikojuma apkopi. Ši produkta pilnīgu likvidēšanu jāveic atbilstoši
visiem valsts tiesību aktiem. lekšpusē nav detaļu, kuru apkopi var veikt lietotājs. Lai izvairītos
no elektriskās strāvas trieciena riska, neatveriet. Aprīkojuma uzstādīšanu jāveic, ievērojot
vietējos un valsts elektrotehniskos normatīvus.
Lietuvių (Lithuanian)
Perskaitykite įdiegimo nurodymus prieš naudodami, įdiegdami arba prijungdami sistemą
prieš maitinimo šaltinio. Įdiegti, pakeisti arba aptarnauti šią įrangą leidžiama tik apmokytiems
ir kvalikuotiems darbuotojams. Galutinis šio gaminio utilizavimas turėtų būti atliktas
pagal visus nacionalinius įstatymus ir taisykles. Nėra vartotojo aptarnaujamų dalių viduje.
Português (Portugese)
Leia as instruções de instalação antes da utilização, instalação ou ligação do sistema à fonte
de energia. Apenas pessoal treinado e qualicado deve ser autorizado a instalar, substituir
ou fazer a revisão deste equipamento. Deitar fora este produto em conformidade com todas
as leis e regulamentos nacionais. Não existem peças no interior que possam ser reparadas
pelo usuário. Há riscos de choque. Não abra. A instalação do equipamento tem de estar em
conformidade com os códigos eléctricos locais e nacionais.
Romanian (Romanian)
Citiți instrucțiunile de montare înainte de a utiliza, instala sau conecta sistemul la sursa de
alimentare. Instalarea, înlocuirea sau lucrările de service pentru acest echipament trebuie
efectuate numai de personal instruit și calicat. Acest produs trebuie reciclat în conformitate
cu toate legile și reglementările naționale. Nu conține piese ce pot reparate de către
utilizator. Pentru a evita riscul de electrocutare, nu deschideți. Instalarea echipamentului
trebuie să respecte codurile electrice locale și naționale.
Slovensko (Slovenian)
pred uporabo, namestitvijo ali priključitvijo sistema na vir energije, preberite navodila za
namestitev.Opremo lahko priključi, zamenja ali popravi le za to usposobljeno osebje. Uničenje
izdelka, ki ni več uporaben, mora potekati po državnih zakonih in predpisih. Znotraj ni delov,
ki bi jih lahko servisirali uporabniki Da bi preprečili električni šok, ne odpirajte. Priključitev
opreme mora potekati v skladu z lokalnimi in državnimi predpisi o električni opremi.
Slovensky (Slovak)
pred použitím, inštaláciou alebo pripojením systému ku zdroju elektrickej energie si prečítajte
pokyny na inštaláciu. Inštaláciu, výmenu alebo opravu tohto zariadenia smú vykonávať iba
vyškolené a kvalikované osoby. Upozornenie Likvidácia tohto výrobku musí byť vykonaná
podľa platných zákonov a predpisov. vo vnútri sa nenachádzajú žiadne diely, ktorých
údržbu či opravu by mohol vykonať použivateľ. Zariadenie neotvárajte. Zabránite tým riziku
zasiahnutia elektrickým prúdom. Inštalácia zariadenia sa musí vykonať v súlade s miestnymi
a národnými predpismi pre inštaláciu elektrických zariadení.
Suomi (Finnish)
Lue asennusohjeet ennen käyttämistä, asentamista tai järjestelmän liittämistä
virtalähteeseen. Tämän laitteen saa asentaa, vaihtaa tai huoltaa ainoastaan koulutettu ja
laitteen tunteva henkilökunta. Tämä tuote on hävitettävä kansallisten lakien ja määräysten
mukaisesti. Sisällä ei ole käyttäjän huollettavissa olevia osia. Välttääksesi sähköiskuvaaran,
älä avaa. Asennustyöt tulee noudattaa paikallisia sähköturvallisuusmääräysten.
Svenska (Swedish)
Läs monteringsinstruktionerna innan du använder, installerar eller ansluter systemet till en
strömkälla. Endast utbildad och kvalicerad personal bör få tillåtelse att installera, byta ut
eller reparera denna utrustning. Vid deponering hanteras produkten enligt gällande lagar
och bestämmelser. Innehåller inga delar som användaren kan utföra service på. Låt bli att
öppna för att undvika stötar. Installation av utrustningen måste ske i enlighet med gällande
elinstallationsföreskrifter.
Europe – EU Declaration of Conformity
Scope
The information in this document is applicable to the Cisco Meraki MR53E-HW wireless
LAN product. This product is intended to be placed on the market within the European
Union, Lichtenstein, Switzerland, Iceland, Norway, Turkey and other countries that have
implemented the EU Directive 2014/53/EU.
The following test methods have been applied in order to prove presumption of conformity
with the essential requirements of the EU Directive 2014/53/EU:
Radio: EN 300 328, EN 301 893
EMC: EN 301 489-1, EN 301 489-17
Safety: EN 60950-1
RF Exposure: EN 50385
Emissions: EN 55032, EN 55024, EN 61000-3-2, EN 61000-3-3
Immunity: EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,
EN 61000-4-5, EN 61000-4-6, EN 61000-4-11
Simplied EU Declaration of Conformity
This declaration is only valid for congurations (combinations of software,
rmware and hardware) provided and/or supported by Cisco Systems for
use within the EU or countries that have implemented the EU Directives and/
or spectrum regulation. The use of software or rmware not supported/
provided by Cisco Systems may result in equipment no longer compliant
with the regulatory requirements.
The full declaration of conformity for this product can be found at
meraki.cisco.com/compliance
Latviski (Latvian): Ar šo Cisco Systems, Inc. deklarē, ka wireless device atbilst Direktīvas
2014/53/ES būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių (Lithuanian): Šiuo Cisco Systems, Inc. deklaruoja, kad šis wireless device atitinka
esminius reikalavimus ir kitas 2014/53/ES Direktyvos nuostatas.
Magyar (Hungarian): Alulírott, Cisco Systems, Inc. nyilatkozom, hogy a wireless device
megfelel a vonatkozó alapvetõ követelményeknek és az 2014/53/EU irányelv egyéb
elõírásainak.
Malti (Maltese): Hawnhekk, Cisco Systems, Inc. jiddikjara li dan wireless device jikkonforma
mal-ħtigijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fi d-Dirrettiva 2014/53/
UE.
Nederland (Dutch): Hierbij verklaart Cisco Systems, Inc. dat het toestel wireless device in
overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn
2014/53/EU.
Norsk (Norwegian): Erklærer herved Cisco Systems, Inc. at denne trådløse enheten er i
samsvar med de grunnleggende krav og øvrige relevante krav i direktiv 2014/53/EU.
Polski (Polish): Niniejszym Cisco Systems, Inc. deklaruje że to urządzenie bezprzewodowe
jest zgodne z zasadniczymi wymaganiami oraz pozostalymi stosowynmi postanowieniami
Dyrektywy 2014/53/UE.
Português (Portuguese): Cisco Systems, Inc. declara que este wireless device está
conforme com os requisitos essenciais e outras disposições da Directiva 2014/53/UE.
Română (Romanian): Prin prezenta, Cisco Systems, Inc. declară că acest dispozitiv fără r
este în conformitate cu cerințele esențiale și alte prevederi relevante ale Directivei 2014/53/
UE.
Slovensko (Slovenian): Cisco Systems, Inc. izjavlja, da je ta wireless device v skladu z
bistvenimi zahtevami in ostalimi relevantnimi dolocili direktive 2014/53/EU.
Slovensky (Slovak): Cisco Systems, Inc. týmto vyhlasuje, že wireless device splna základné
požiadavky a všetky príslušné ustanovenia Smernice 2014/53/EÚ.
Suomi (Finnish): Cisco Systems, Inc. vakuuttaa täten että wireless device tyyppinen laite on
English: Hereby, Cisco Systems, Inc. declares that this wireless device is in compliance with
the essential requirements and other relevant provisions of Directive 2014/53/EC.
Български (Bulgarian): Настоящото Cisco Systems, Inc. декларира, че това безжичното
устройство е в съответствие със съществените изисквания и другите приложими
разпоредби на Директива 2014/53/EC.
Dansk (Danish): Undertegnede Cisco Systems, Inc. erklærer herved, at følgende udstyr
wireless device overholder de væsentlige krav og øvrige relevante krav i direktiv 2014/53/EU.
Deutsch (German): Hiermit erklärt Cisco Systems, Inc. dass sich das Gerät wireless device
in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen
Bestimmungen der Richtlinie 2014/53/EU befi ndet.
Eesti (Estonian): Käesolevaga kinnitab Cisco Systems, Inc. seadme wireless device
vastavust direktiivi 2014/53/EL põhinõuetele ja nimetatud direktiivist tulenevatele.
Español (Spanish): Por medio de la presente Cisco Systems, Inc. declara que el wireless
device cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o
exigibles de la Directiva 2014/53/UE.
Ελληνική (Greek): ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Cisco Systems, Inc. ΔΗΛΩΝΕΙ ΟΤΙ wireless device
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ
ΤΗΣ ΟΔΗΓΙΑΣ 2014/53/ЕE.
Français (French): Par la présente Cisco Systems, Inc. déclare que l’appareil wireless
device est conforme aux exigencies essentielles et aux autres dispositions pertinentes de
la directive 2014/53/UE.
Hrvatski (Croatian): Ovime Cisco Systems, Inc. izjavljuje da je ovaj bežični uređaj u skladu s
osnovnim zahtjevima i drugim relevantnim odredbama Direktive 2014/53 / EC
.
Ícelenska (Icelandic): Hér, Cisco Systems, Inc. yr að þráðlaus tæki er í samræmi við
grunnkröfur og önnur viðeigandi ákvæði tilskipunar 2014/53/EU.
Italiano (Italian): Con la presente Cisco Systems, Inc. dichiara che questo wireless device
è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva
2014/53/UE
antennas available from Cisco. Below are the allowable antennas. All antennas were
assessed together with the equipment against the requirements of the EU Directive
2014/53/EU. It is the responsibility of the end user to select a power level that, together
with the antennas, results in a radiated power level that is below the applicable limit.
• MA-ANT-3-A
• MA-ANT-3-B
• MA-ANT-3-C
• MA-ANT-3-D
• MA-ANT-3-E
• MA-ANT-3-F
Operating Frequency & Maximum Output Power
Frequency Band
(MHz)
Max Power Level
(EIRP) (mW)
Indoor ONLY Indoor and Outdoor
2400 - 2483.5 100 X
5150 - 5350 200 X
5470 - 5725 1000 X
All operational modes:
2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac
(VHT40), Bluetooth(LE)
5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40),
802.11ac (VHT80), 802.11ac (VHT80+80)
The frequency and the maximum transmitted power in EU are listed below:
2412-2472MHz: 19.99 dBm
2402-2480MHz (LE): 8.36 dBm
5180-5240MHz: 22.99 dBm
5260-5320MHz: 22.99 dBm
5500-5700MHz: 29.99 dBm
The device is restricted to indoor use only when operating in the 5150 to 5350 MHz
frequency range.
direktiivin 2014/53/EU oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen
mukainen.
Svenska (Swedish): Härmed intygar Cisco Systems, Inc. att denna wireless device står I
överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser
som framgår direktiv 2014/53/EU.
Türk (Turkish): İşbu belge ile, Cisco Systems, Inc., bu kablosuz aygıtın, 2014/53 / EC sayılı
Direktin esas şartlarına ve diğer ilgili hükümlerine uygun olduğunu beyan eder.
National Restrictions or Requirements for Authorization of Use
This device is a 2.4 GHz and 5 GHz wideband transmission system (transceiver), intended for
use in all EU member states and EFTA countries with the following restrictions:
Denmark
The band 5150 - 5350 MHz is also allowed for outdoor usage.
I Danmark må frekvensbåndet 5150 -5350 også anvendes udendørs.
Italy
This product meets the National Radio Interface and the requirements specied in the
National Frequency allocation Table for Italy. Unless this wireless LAN product is operating
within the boundaries of the owner’s property, it uses requires a “general authorization”.
Please check http://www.comunicazioni.it/it/ for more details.
Questo prodotto è conforme alla speciche di Interfaccia Radio Nazionali e rispetta il Piano
Nazionale di ripartizione delle frequenze in Italia. Se non viene installato all ‘interno del
proprio fondo, l’utilizzo di prodotti Wireless LAN richiede una “Autorizzazione Generale”.
Consultare http://www.comunicazioni.it/it/ per maggiori dettagli.
Latvia
The outdoor usage of the 2.4 GHz band requires an authorization from the Electronic
Communications Oce. Please check http://www.esd.lv for more details.
2.4 GHz frekvenču joslas izmantošanai ārpus telpām nepieciešama at auja no Elektronisko
sakaru direkcijas. Vairāk informācijas: http://www.esd.lv.
Antennas
This device is equipped with antenna connectors to allow the use of dedicated external
EU Radiation Exposure Statement
This equipment complies with EU radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20
cm between the radiator and your body.
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This device is restricted for indoor use.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to correct the interference by one of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
Any changes or modications not expressly approved by Cisco Systems, Inc. could void the user’s
authority to operate this equipment. This Transmitter must not be co-located or operation in
conjunction with any other antenna or transmitter.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 30 cm between the radiator
and your body. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
For products available in the USA/Canada market, only channel 1~11 can be operated. Selection of
other channels is not possible.
Industry Canada Statement
This device complies with RSS-247 of the Industry Canada Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation. (3)
this device subject to this section shall not be capable of transmitting in the band 5600-5650 MHz.
This restriction is for the protection of Environment Canada’s weather radars operating in this band.
Ce dispositif est conforme à la norme CNR-247 d’Industrie Canada applicable aux appareils radio
exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif
ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage
reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. (3) Ce
dispositif soumis au présent article ne doit pas pouvoir émettre dans la bande 5600-5650 MHz. Cette
restriction vise la protection des radars météorologiques d’Environnement Canada qui fonctionnent
dans cette bande.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection
of other channels is not possible.
Ant. Brand Model
Name Ant.
Type
Output Power
2.4
GHz Blue
tooth
5GHz
Band
1
5GHz
Band
2
5GHz
Band
3
1 Cisco MA-ANT-3-A Dipole 19.87 1.65 - - -
2 Cisco MA-ANT-3-B Dipole - - 22.96 22.99 29.89
3 Cisco MA-ANT-3-F Patch 19.94 8.36 22.83 22.91 29.97
4 Cisco MA-ANT-3-E Patch 19.99 3.51 22.99 22.96 29.96
5 Cisco MA-ANT-3-C Omni 19.99 1.75 22.97 22.99 29.99
6 Cisco MA-ANT-3-D Omni 19.99 -0.19 22.92 22.97 29.99
Pour les produits disponibles aux États-Unis / Canada du marché, seul le canal 1 à 11 peuvent
être exploités. Sélection d’autres canaux n’est pas possible.
This device and it’s antenna(s) must not be co-located or operating in conjunction with any
other antenna or transmitter except in accordance with IC multi-transmitter product procedures.
Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association
avec une autre antenne ou transmetteur.
Dynamic Frequency Selection (DFS) for devices operating in the bands 5250- 5350 MHz,
5470-5600 MHz and 5650-5725 MHz.
Sélection dynamique de fréquences (DFS) pour les dispositifs fonctionnant dans les bandes
5250-5350 MHz, 5470-5600 MHz et 5650-5725 MHz.
Industry Canada Caution
(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems.
Avertissement:
(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour
une utilisation à l’intérieur an de réduire les risques de brouillage préjudiciable aux systèmes
de satellites mobiles utilisant les mêmes canaux.
For indoor use only.
Pour une utilisation en intérieur uniquement.
This radio transmitter (6961A-60064010) has been approved by Industry Canada to operate
with the antenna types listed below with the maximum permissible gain indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated
for that type, are strictly prohibited for use with this device.
Le présent émetteur radio (6961A-60064010) a été approuvé par Industrie Canada pour
fonctionner avec les types d’antenne énumérés ci-dessous et ayant un gain admissible
maximal d’antenne.
Les types d’antenne non inclus dans cette liste, ou dont le gain est supérieur au gain
maximal indiqué, sont strictement interdits pour l’exploitation de l’émetteur.
The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-
5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit.
le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5250-5350 MHz et
5470-5725 MHz doit se conformer à la limite de p.i.r.e.
The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such
that the equipment still complies with the e.i.r.p. limits specied for point-to-point and non-
point-to-point operation as appropriate.
le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5725-5850 MHz)
doit se conformer à la limite de p.i.r.e. spéciée pour l’exploitation point à point et non point
à point, selon le cas.
Industry Canada Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 38cm
between the radiator & your body.
Déclaration d’exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de
38cm de distance entre la source de rayonnement et votre corps.
Australia Radiation Exposure Statement
This equipment complies with Australian radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with minimum
distance 30 cm between the radiator and your body.
VCCI Statement for Japan
警告 この装置は、クラスＢ情報技術装置です。この装置は、家庭環境で使用することを目的
としていますが、この装置がラジオやテレビジョン受信機に近接して使用されると、
受信障害を引き起こすことがあります。取扱説明書に従って正しい取り扱いをしてくだ
さい。 VCCI-B
5GHz band (W52, W53): Indoor use only
Taiwan Wireless Statements
低功率射頻設備的管理辦法
第12條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均
不得 擅自變更頻率、加大功率或 變更原設計之特性及功能。
第14條 低功率射頻電機之使用不得影響飛航安全及干擾合 法通信；經發現有干
擾現象時，應立即停用，並改善 至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫 療用電波輻射性電機
設備之干擾。
低功率射頻電機技術規範
4.7 無線資訊傳輸設備
4.7.6 無線資訊傳輸設備須忍受合法通信之干擾且不得 干擾合法通信；如造成
干擾，應立即停用，俟無干擾之 虞，始得 繼續使用。
4.7.7 無線資訊傳輸設備的製造廠商應確保頻率穩定性，如依製造廠商使用手
冊上所述正常操作，發射的信號 應維持於操作帶中。
在5.25-5.35秭赫頻帶內操作之無線資訊傳輸設備，限於室內使用。
電磁波曝露量MPE標準值1mW/cm2，本產品使用時建議應距離人體 30 cm。
Statement CS-0438 - 台灣 RoHS
台灣RoHS“限用物質含有情況標示聲明書”網址 www.cisco.com/go/taiwanrohs
Statement CS-0438 - Taiwan RoHS
Taiwan RoHS “Restricted Substances Content Disclosure Table” web address
www.cisco.com/go/taiwanrohs
Ant. Brand Model
Name Ant.
Type
Output Power
2.4
GHz Blue
tooth
5GHz
Band
1
5GHz
Band
2
5GHz
Band
3
5GHz
Band
4
1 Cisco MA-ANT-3-A Dipole 27.06 -2.68 27.35 23.41 22.22 24.32
2 Cisco MA-ANT-3-B Dipole 27.06 -2.68 27.35 23.41 22.22 24.32
3 Cisco MA-ANT-3-F Patch 25.08 -2.68 25.71 20.49 20.51 26.33
4 Cisco MA-ANT-3-E Patch 27.06 -2.68 26.86 23.41 23.22 27.28
5 Cisco MA-ANT-3-C Omni 28.62 -2.68 27.62 23.72 22.93 28.16
6 Cisco MA-ANT-3-D Omni 29.43 -2.68 29.77 23.84 23.97 29.97
Singapore IMDA Marking:
Brazil Wireless Statement
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção
contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter primário.
This equipment operates on a secondary basis and consequently must accept harmful
interference, including interference from stations of the same kind. This equipment may not
cause harmful interference to systems operating on a primary basis.
