User Guide
IMPORTANT SAFETY INSTRUCTIONS
Notice to Installers
The servicing instructions in this notice are for use by quali ed service personnel only. To reduce
the risk of electric shock, do not perform any servicing other than that contained in the operating
instructions, unless you are quali ed to do so.
20080814_Installer820
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8) Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding-type
plug has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of
the obsolete outlet.
10) Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories
specified by the manufacturer.
12) Use only with the cart, stand,
tripod, bracket, or table
specified by the manufacturer,
or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14) Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as a power-supply cord or
plug is damaged, liquid has been spilled
or objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
Power Source Warning
A label on this product indicates the correct
power source for this product. Operate this
product only from an electrical outlet with the
voltage and frequency indicated on the product
label. If you are uncertain of the type of power
supply to your home or business, consult your
service provider or your local power company.
The AC inlet on the unit must remain accessible
and operable at all times.
Note to System Installer
WARNING
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
For this apparatus, the coaxial cable shield/screen shall be
grounded as close as practical to the point of entry of the cable
into the building.For products sold in the US and Canada, this
reminder is provided to call the system installer's attention to
Article 820-93 and Article 820-100 of the NEC (or Canadian
Electrical Code Part 1), which provides guidelines for proper
grounding of the coaxial cable shield.
This symbol is intended to alert you that uninsulated voltage
within this product may have sufficient magnitude to cause
electric shock.Therefore, it is dangerous to make any kind of
contact with any inside part of this product.
Ce symbole a pour but d’alerter toute personne qu’un contact
avec une pièce interne de ce produit, sous tension et non isolée,
pourrait être suffisant pour provoquer un choc électrique. Il est
donc dangereux d’être en contact avec toute pièce interne de
ce produit.
This symbol is intended to alert you of the presence of important
operating and maintenance (servicing) instructions in the literature
accompanying this product.
Ce symbole a pour but de vous avertir qu’une documentation
importante sur le fonctionnement et l’entretien accompagne ce produit.
CAUTION: To reduce the risk of electric shock, do not remove cover (or
back). No user-serviceable parts inside. Refer servicing to qualified
service personnel.
Ground the Product
WARNING: Avoid electric shock
and re hazard! If this product connects
to coaxial cable wiring, be sure the cable
system is grounded (earthed). Grounding
provides some protection against voltage
surges and built-up static charges.
Outdoor Grounding System
If this product connects to an outdoor antenna
or cable system, be sure the antenna or cable
system is grounded (earthed). This provides
some protection against voltage surges and
built-up static charges.
Article 810 of the National Electric Code (NEC)
ANSI/NFPA No. 70-1990, provides the following
information:
• Grounding of the mast and supporting structure
• Grounding the lead-in wire to an antenna
discharge unit
• Size of the grounding conductors
• Location of the antenna-discharge unit
• Connection to grounding electrodes
• Requirements for the grounding electrodes (see
the following antenna grounding diagram as
recommended by NEC ANSI/NFPA 70)
WARNING: Avoid electric shock and
re hazard! Do not locate an outside antenna
system in the vicinity of overhead power lines
or power circuits. Touching power lines or
circuits might be fatal.
Eliminate AC Power/Mains Overloads
WARNING: Avoid electric shock and
re hazard! Do not overload AC power/
mains, outlets, extension cords, or integral
convenience receptacles. For products
that require battery power or other power
sources to operate them, refer to the
operating instructions for those products.
Handling Disposable Batteries
This product may contain disposable batteries.
Heed the following warning and follow the Battery
Safety and Battery Disposal instructions below.
WARNING: There is danger of
explosion if the battery is mishandled or
incorrectly replaced. Replace only with the
same type of battery. Do not disassemble
it or attempt to recharge it outside the
system. Do not crush, puncture, dispose
of in re, short the external contacts, or
expose to water or other liquids. Dispose
of the battery in accordance with local
regulations and instructions from your
service provider.
Battery Safety
• Insert batteries correctly. There may be a risk of
explosion if the batteries are incorrectly inserted.
• Do not attempt to recharge ‘disposable’ or ‘non-
reusable’ batteries.
• Please follow instructions provided for charging
‘rechargeable’ batteries.
• Replace batteries with the same or equivalent
type that we recommend.
• Do not expose batteries to excessive heat (such
as sunlight or re).
• Do not expose batteries to temperatures above
100°C (212°F).
Battery Disposal
• The batteries may contain substances that could
be harmful to the environment.
• Recycle or dispose of batteries in accordance
with the battery manufacturer’s instructions and
local/national disposal and recycling regulations.
• The batteries may contain perchlorate, a known
hazardous substance, so special handling and
disposal of this product might be necessary.
For more information about perchlorate and
best management practices for perchlorate-
containing substance, see www.dtsc.ca.gov/
hazardouswaste/perchlorate
T11518
Protect the Product from Lightning
In addition to disconnecting the AC power from
the wall outlet, disconnect the signal inputs.
Verify the Power Source from the
Power Light
When the power light on the front panel is not
illuminated, the apparatus may still be connected
to the power source. The light may go out when
the apparatus is turned o , regardless of whether
it is still plugged into an AC power source.
Cisco Explorer 9800 Multi-Screen
Gateway Series
Models: 9825HDC, 9835HDC, 9842HDC,
9845HDC, 9855HDC, 9862HDC, 9865HDC,
9845HD, 9865HD
Manufactured by:
Cisco Systems, Inc.
5030 Sugarloaf Parkway
Lawrenceville, Georgia 30044 USA
Telephone: 770 236-1077
Provide Ventilation and Select a
Location
• Remove all packaging material before applying
power to the product.
• Do not place this apparatus on a bed, sofa, rug,
or similar surface.
• Do not place this apparatus on an unstable
surface.
• Do not install this apparatus in an enclosure,
such as a bookcase or rack, unless the
installation provides proper ventilation.
• Do not place entertainment devices (such as
VCRs or DVDs), lamps, books, vases with liquids,
or other objects on top of this product.
• Do not block ventilation openings.
Operating Environment
The gateway is designed for operation indoors
with a temperature range from 32° to 104° F (0°
to 40°C). Each gateway should have adequate
spacing on all sides so that the cooling air vents
on the chassis are not blocked.
Protect from Exposure to Moisture
and Foreign Objects
WARNING: Avoid electric shock and
re hazard! Do not expose this product
to dripping or splashing liquids, rain, or
moisture. Objects lled with liquids, such
as vases, should not be placed on this
apparatus.
WARNING: Avoid electric shock and
re hazard! Unplug this product before
cleaning. Do not use a liquid cleaner or an
aerosol cleaner. Do not use a magnetic/
static cleaning device (dust remover) to
clean this product.
WARNING: Avoid electric shock and
re hazard! Never push objects through the
openings in this product. Foreign objects
can cause electrical shorts that can result in
electric shock or re.
Service Warnings
WARNING: Avoid electric shock! Do
not open the cover of this product. Opening
or removing the cover may expose you to
dangerous voltages. If you open the cover,
your warranty will be void. This product
contains no user-serviceable parts.
Check Product Safety
Upon completion of any service or repairs to this
product, the service technician must perform
safety checks to determine that this product is in
proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when
moving the apparatus or connecting or
disconnecting cables. 20110316_IP Gateway_Safety
United States FCC Compliance
This device has been tested and found to
comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against such interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy.
If not installed and used in accordance with the
instructions, it may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined by
turning the equipment OFF and ON, the user is
encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit di erent from that to which the receiver
is connected.
• Consult the service provider or an experienced
radio/television technician for help.
Any changes or modi cations not expressly
approved by Cisco Systems, Inc., could void the
user’s authority to operate the equipment.
The information shown in the FCC Declaration
of Conformity paragraph below is a requirement
of the FCC and is intended to supply you with
information regarding the FCC approval of
this device. The phone numbers listed are for
FCC-related questions only and not intended for
questions regarding the connection or operation
for this device. Please contact your service
provider for any questions you may have regarding
the operation or installation of this device.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its a liates in the U.S. and other countries.
A listing of Cisco’s trademarks can be found at www.cisco.com/go/trademarks.
Rovi is a trademark of Rovi Corporation.
Other third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1009R)
© 2011 Cisco and/or its a liates All rights reserved.
December 2011 Part Number 4041467 Rev A
Cisco Systems, Inc. 678 277-1120
5030 Sugarloaf Parkway, Box 465447 800 722-2009
Lawrenceville, GA 30042 www.cisco.com
Declaration of Conformity
This device complies with Part 15 of FCC
Rules. Operation is subject to the following two
conditions: 1) the device may not cause harmful
interference, and 2) the device must accept any
interference received, including interference that
may cause undesired operation.
Canada EMI Regulation
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la class B est
conforme à la norme NMB-003 du Canada.
AVC VIDEO LICENSE
With respect to each AVC/H.264 product, we are
obligated to provide the following notice:
THIS PRODUCT IS LICENSED UNDER THE
AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL USE OF A CONSUMER OR OTHER
USES IN WHICH IT DOES NOT RECEIVE
REMUNERATION TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD (“AVC
VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN
A PERSONAL ACTIVITY AND/OR WAS OBTAINED
FROM A VIDEO PROVIDER LICENSED TO PROVIDE
AVC VIDEO. NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG
LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM.
Accordingly, please be advised that service
providers, content providers, and broadcasters
may be required to obtain a separate use license
from MPEG LA prior to any use of AVC/H.264
encoders and/or decoders.
ROVI CORPORATION COPYRIGHT
NOTICE
This product incorporates copyright protection
technology that is protected by U.S. patents
and other intellectual property rights of Rovi
Corporation. Use of this copyright protection
technology must be authorized by Rovi
Corporation, and is intended for home and
other limited viewing uses only unless otherwise
authorized by Rovi Corporation. Reverse
engineering and disassembly are prohibited.
Open Source GNU GPL Statement
Cisco Explorer 9800 Multi-Screen Gateway
Series contain(s), in part, certain free/open
source software (“Free Software”) under
licenses which generally make the source
code available for free copy, modi cation, and
redistribution. Examples of such licenses include
all the licenses sponsored by the Free Software
Foundation (e.g. GNU General Public License
(GPL), GNU Lesser General Public License
(LGPL), Berkeley Software Distribution (BSD),
the MIT licenses and di erent versions of the
Mozilla and Apache licenses). To nd additional
information regarding the Free Software,
including a copy of the applicable license
and related information, please go to: (i) for
North America http://www.cisco.com/web/
consumer/support/open_source.html, or (ii)
for outside North America http://www.cisco.
com/web/consumer/support/open_source.
html#~international. Once at the site, search
for the product listing and click on the related
items identi ed. If you have any questions or
problems accessing any of the links, please
contact: spvtg-external-opensource-
requests@cisco.com.
