Cjing Lighting CJ001 Wireless charger base User Manual 15 CJ TX5VA1 V0 UserMan r1
Cjing Lighting Co.,Ltd Wireless charger base 15 CJ TX5VA1 V0 UserMan r1
15_CJ-TX5VA1-V0 UserMan r1
USER MANUAL
For Wireless charger base
CJ-TX5VA1-V0
This is a 5W digital demodulation wireless charging transmitter that compatible with
WPC-QI standards, support for transmitting and receiving bi-directional. The
operation frequency is 110.5KHz-205KHz
In the case of standby, input 5Vdc,the loss is lower than 0.15W.It also has short circuit
protection, over current protection, over temperature protection, foreign object detect
and vertex shutdown.
Wireless Charger is provided by a high efficient Adapter, the electrical parameter data
of the adapter is as below:
Input voltage: AC100-240V ~50/60Hz
The electrical parameter data of the wireless charger is as below :
Output power: 5W MAX
Attention:
1. Temperature:
1.1 Operating Temperature：0℃ to 40℃
1.2 Storage Temperature：-20℃ to 80℃
2. Humidity
2.1 Operating Humidity：10% to 70% RH
2.2 Storage Humidity：10% to 80% RH
What’s more, the LED indicator light is different as below picture showed in different
working conditions.
Magnet
Metal
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
urning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Warning: Changes or modifications to this unit not expressly approved by the part
responsible
for compliance could void the user’s authority to operate the equipment.
FCC Radiation Exposure Statement:
This equipment complied with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
