Clearsounds Communications Inc. Amplified 900MHz Cordless Phone
User Manual
USER'S MANUAL
CL-3108
BUEFORE SING
1
ISIMPORTANT AFETY NSTRUCTIONS
26
Before first Use
Accessories
Please read IMPORTANT SAFETY INSTRUCTIONS on pages
25~26before use.
Take out from box: cordless handset, belt clip and base unit, in
addition each carton contains the following accessories:
Congratulation
for buying our high quality product.
It is necessary to read through the manual carefully
to find out all features and how to operate this
cordless phone.
AC Adapter (One)
Telephone line cord (One)
Batteries (Three)
User's Manual (One)
9.
10.
11.
Do not overload wall outlets and extension cords as this will result in
the risk of fire or electric shock.
Never introduce objects into this unit through the slots as this may
risk in fire or electric shock hazard. Never spill any liquid on the unit.
To reduce the risk of electric shock, do not disassemble this unit,
instead take it to a qualified service station for checking . Opening or
removing covers may expose you to dangerous voltages or other risks.
Incorrect repair jobs can be highly dangerous.
12. Unplug this unit from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
A. When the power supply cord or plug is damaged.
B. If liquid has been spilled over the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not work normally upon following the instruction.
Adjust only controls covered by the operating instructions, to avoid
expensive repairs by qualified technicians.
E. If the unit has been dropped or damaged.
F. If the unit exhibits a distinct change in performance.
13. Avoid using the phones during a lightning storm. There may be a
remote risk of electric shock from lightning.
14. Do not use the phones to report a gas leak nearby.
USER'S MANUAL
CL-3108
BUEFORE SING
2
25
ISIMPORTANT AFETY NSTRUCTIONS
Calls are transmitted between the base unit and the handset using
wireless radio waves. To find out max distance and limit of noise
free operation, you have to follow these rules:
Keep away from electrical
appliances, such as a TV,
PC or another cordless
phone.
Battery Charge
Operating Distance/Noise
To power the handset, install the battery and charge it for
about 24 hours before initial use.
In a HIGH and CENTRAL
locationstayawayfrom
obstructions such as walls.
When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electric shock
a
Unplug this unit from wall outlets and telephone jacks before
cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for
the job.
Do not use this unit near water, for example, near a bath tub, wash
bowl, kitchen sink. If the unit comes in contact with any liquid, cut the
power and unplug cords immediately. Do not reconnect the unit before
totally dried.
Put this unit securely on a stable surface. Serious damage may result
from falling.
Do not cover slots and openings of the unit, they are needed for
ventilation and protection against overheating. Never place the unit
near hot places where proper ventilation is not provided.
Use only the battery and adapter of the same type we offer.
Do not place objects on the power cord. Put the unit where no one
can step on the cord.
nd injury to persons, including following items:
1. Please understand all instructions in the operation manual.
2. Follow all warnings and instructions marked on this unit.
3.
4.
5.
6.
7.
8.
Important safety instructions
BUEFORE SING
324
TROUBLESHOOTING
Features
1. FSK standard Caller ID
2. Stores up 72 calling numbers with the date and time
3. Stores up to 60 numbers in phone book
4. Line transfer between handsets
5. Out of area/Private/Repeat/Error
6.Deletessingleorallrecords
7. LCD display calling and dialling number
8. Auto-scan channel
9. 24 digits pre-enters dial digit with edit function
10.Pageonbaseunittolookforthehandseteasily
11.Memorydialfunction
12. Compander circuit for noise reduction
13. LCD display indicates: operation mode, dial digits,
real time and memory dial digits
14.Lastnumberredial
15. Multi-handset compatibility, up to 3 handsets
16. Ringer volume selection (on/off) on handset
17. Receiver volume and tone adjustment on handset
18. LCD contrast selection
19. Ringer volume selection on base
20. Flash and vibration function on handset
21. LCD back light
22. Wall mounting
If you hear noise or static
during a phone conversation
Never touch the battery contacts
on the base unit and handset with
sweaty or the battery contacts may
result in charging failure. If this has
happened, clean them with
Cleaned cloth or swab.
If the battery is recharging
The battery needs recharge.
If the LOW BATTERY indicator is
on display
Move away from TV, VCR,
computers, fax machines,
electronic equipment and other
motor device.
Interference and noise on
line
Remove the base unit as far away
from the TV or VCR as needed.
The TV or VCR picture
becomes distorted while
talking
Move closer to the base unit.
Keep the base unit away from PCS,
family videos, game and fax
machines.
Press the "CH." key to switch to
another channel.
BUEFORE SING
4
TROUBLESHOOTING
23
Base Unit
Location of Controls
If you experience trouble with your unit, please check following items
before calling for help.
Problem Cause & Remedy
Troubleshooting
Make sure the telephone line cord
is connected firmly to the base
unit and the telephone jack.
Make sure the AC adapter is
plugged into an outlet and the wall
switch is on.
Your phone may be too far away
from the base unit. Move closer to
the base unit.
You may have too many extension
phones on your telephone line to
allow all of them to ring.
Try unplugging some of the other
phones.
The handset is located beyond the
range of the base Unit. Or the
handset is out of registration.
Place the handset On the base
cradle.
Move closer to the base unit or
replace the handset on the base
cradle. Try again a few seconds
later.
If the phone does not ring
with an incoming call
If you hear two beeps when
trying to use the phone
AC adapter unplugged or main
power failure.
The unit does not work
Charge Indicator
In Use
Indicator
Page button
Charge Pins
Adapter socket
Telephone
line jack
Ringer volume
switch (HI/MI
/LO/OFF)
Shaker socket
BUEFORE SING
522
CIDOALLER PERATION
Deleting a single Caller ID number
Call ID on call waiting
1. Press or button, the LCD shows the total number of CID numbers
and new numbers.( )
2. Press or button to find out the number you want to delete.
3. Press button twice to delete the number.
When you have subscribed to call waiting service from your local
telephone company, this telephone can indicate the name and
number of the second caller while you are having a conversation
with the first caller.
You can press button to answer the 2nd caller. After the call, you
can press this button once more to continue the first conversation.
st
st
ALL XX NEW XX
F
F
Handset
Fbutton
MEMO button
LCD
button
button
button
SEL button
CH button
Microphone
Charge pins
Visual ringer
R/P button
BUEFORE SING
6
CIDOALLER PERATION
21
TALK
TALK
TALK
Press buttontodialthelast8digitsofthenumber.8
Press buttontodialthelast7digitsofthenumber.7
Press buttontodialthenumberaheadwiththe1digit.1
Deleting all Caller ID numbers
1. Press or button, the LCD shows the total number of Caller ID
numbers and new numbers.( )
2. Press button twice to delete all of the Caller ID numbers.
st
ALL XX NEW XX
F
Receiver volume
and tone select
switch
Belt clip
Amplify button
Shaking switch
Receiver volume
switch
Receiver tone
switch
BUEFORE SING
7
Reviewing the Caller ID list
Dialling the Caller ID numbers
1. Press or button, the LCD shows the total number of Caller ID
numbers and new numbers.( )
2. Press or button to review the other caller numbers.
During the reviewing mode, press button to dialled out the number
showed on the LCD.
If the Caller ID number exceeds 8 digits, you can dial the number as
above or in other 4 ways as follows.(e.g. the number is )
st
st
ALL XX NEW XX
34567890123
Caller ID Operation
CIDOALLER PERATION
20
JOHN BULL
Press button to dial the number with the digit.00
TALK
Installation
(1) Install belt clip (2) Remove belt clip
Base unit
Connect the telephone line and the power.
Handset
Install and remove the belt clip
Single-Line
Telephone
Jack
AC Adapter
Telephone Line Cord
BUEFORE SING
8
BFASIC UNCTION
19
2. Press button to dial it out.
1. In standby mode, press button, then the LCD shows the total
number of records.
2. Press button twice, then all of the records will be deleted.
1. Find out the record you want to delete. Please see "Reviewing names
and numbers in phone book" for details.
2. Press button twice, then the record will be deleted.
MEMO
F
F
Deleting all records from phone book
Deleting a single record from phone book
Install the battery
(1) Slide the battery compartment cover downwards.
(2) Insert new batteries as indicated, matching correct polarity
(+, -).
(3)Slidethecoverupuntilitsnapsinplace.
BUEFORE SING
9
a. Press or button to review the records.
b. Enter the caller's name, then press button to review the
matching record.
c. Enter the first character of the caller's name, then press
button. The LCD shows the matching records, press or button to
get your desired record.
1. Find out the record you want to modify. Please see "Reviewing
names and numbers in phone book" for details.
2. Press button to enter the modifying mode, the last digit of the
number flashes.
3. Enter the new number by keypad. If necessary, press button to
delete the error digits.
4. Press button to confirm and enter the name modification.
5. Enter the new name by keypad. If necessary, press button to delete
the error characters.
6. Press button to confirm.
1. Find out the record you want to dial. Please see "Reviewing names
and numbers in phone book" for details.
st
st
MEMO
MEMO
Modifying names and numbers in phone book
SEL
F
MEMO
F
MEMO
Dialling a number from phone book
BFASIC UNCTION
18
LCD Informations
In standby mode: In this mode, the LCD will show the handset number,
date and real time.
After pressing button, the will turn on, in use indicator on base
unit and handset will be bright steadily, which indicates that the unit is
in use mode. The timer will turn on after about 6 seconds.
If there are new calls in memory, the icon will turn on and flash.
After all the new calls have been reviewed, the icon will turn off.
:
If a call comes repeatedly, the icon will turn on.
If the battery is low, the battery low icon will show as .
This message will display when reaching the top (end) of the phone
book or Caller ID list by using the button.
If the caller has exercised the option to prevent his number from being
sent, it will be shown on the screen.
IN USE indicator:
NEW call:
REPEAT icon
Battery indicator:
END OF LIST
PRIVATE
TALK
NEW
RPT
stor
HS-1
00: 47 01/01
Description
Before Using
10
BFASIC UNCTION
17
Phone Book
Storing names and numbers to phone book
Reviewing names and numbers in phone book
You can store up to 60 names and numbers in the memory.
1. In standby mode, input the number you want to store by keypad.
2. Press button and then the LCD will show .
3. Enter the name by keypad. If the next character is on the same button
as the previous one, you need to for about 2 seconds before entering
the next character. You can press button to delete the error characters.
4. Press button to confirm and exit.
1. In standby mode, press or button repeatedly to find out the
Caller ID number you want to add.
2. If the number with caller's name, press button to store. If the
number without caller's name, press button, then enter the
name. After that, press button again to store.
In standby mode, press button, then the LCD shows the total
number of records.
Then there are to review the records:
1. Adding names and numbers to phone book:
2. Copying Caller ID numbers to phone book:
MEMO
F
MEMO
MEMO
MEMO
MEMO
MEMO
name
st
3ways
OUT OF AREA
ERROR
MESSAGE WAITING
This message will display when someone calls from an area where the
telephone company is not offering the caller identification services or
is not yet providing name and number delivery to your area via the long
distance net work.
If there are some error information in the incoming number or your
telephone cannot receive the information correctly, the LCD will show
ERROR. This does not mean that there is something wrong with your
phone.
If you have voice mail service from your telephone company and a
recorded message is left, the will turn on and flash. You can
press button twice to delete the icon.
""
F
NOTE: This function should be supported by your local telephone
company.
MESSAGE
BUEFORE SING
11
BFASIC UNCTION
16
Out of range warning
Line transfer
Paging
In talk mode, if the handset is too far away from base unit, an out of
range warning tone will be heard. The user should move closer to the
base unit. If not, the handset will automatically return to standby mode
after about 20 seconds. When the handset makes a noise, press but-
ton to return to standby mode.
If extra handsets are set to the base unit:
1. During a phone conversation, press button and handset number.
The line will be hold and make music sounds to the other end, both the
two handsets will ring.
2. The other handset can press button to answer the call
automatically after receiving the transfer ring.
3. Press button to cancel the transfer if the other handset user does
not want to answer the call during the transfer ring.
4. If the two handsets do not respond within 40 seconds, the line will be
disconnected automatically.
1. Press the button to page the handset.
2. Press button once more to cancel the paging operation.
3. If you do not press button again, the handset will ring for about
25 seconds then end the paging automatically.
SEL
Handset registration
Settings
1. Make sure the base unit is connected into the AC outlet and line
jack.
2. Press and hold the button on the base unit. After 3 seconds,
press the button on the handset, the unit will give you a
confirmation beep, which means that the code has been set and the
handset will show on the LCD.
3. If you have a second handset need to be registered to the same
base, press the button on the handset until you get a beep and
the display shows . Continue the same procedure, if you have a
third handset. If not, release the button from the base unit.
The button on the base unit should be kept pressing
during the whole procedure.
The base unit and the handset have been set
code already.
In standby mode, press button once, then the LCD will show
to indicate you enter the setting mode.
CH
CH
NOTE:
IMPORTANT NOTICE:
SEL
HS -1
HS -2
PROGRAM
Handset Settings
BUEFORE SING
12
BFASIC UNCTION
15
Press button, then press button to redial the last dialled number.
During the conversation, the phone will scan the clear channel
automatically. If you still hear noise or static, press the button to find
a clearer channel.
It takes about 2 seconds for the unit to scan a channel.
This function allows you to insert a temporary pause during dialling
sequence. For example, dialling an international number (e.g. 011-886-
22-795-1234), some telephone company systems will not register the
entire number entry without a pause between the prefix numbers. You
may have to dial 011- , dial 886 - . This allows adequate timing for
the phone number to register with the telephone company's system
and complete the call.
Every time you press a key, your handset acknowledges it with a key
tone.
Once the battery voltage is low, the low battery icon will turn on.
The low battery warning tone will also be generated if the handset is in
talk mode. You can press button to return to standby mode, then
replace it on the base to recharge.
Last number redial
CH button
Pause function
Keys confirmation tone
Battery low warning and shut down protection
R/P
CH
NOTE:
R/P R/P
LCD contrast setting
Ringer setting
Time setting
Receiver volume and tone setting
Press button, then button, and then the current level
will show on the LCD. Press or button to get the
desired level and press button once more to confirm and exit.
Press button, then button, and then the current mode
will show on the LCD. Press or button to
activate/deactivate the ringer function. Press button once more
to confirm and exit.
Press button, then button, and then the will show on
the LCD and the digit for will flash. Press or button to
get the desired digit then press button to confirm and enter the
next item (the sequence is ). After the
setting, press button to confirm and exit.
You can increase the volume and adjust the receiver tone according
to your own hearing requirements. The
switch within the battery compartment allows extra-receiver
and tone function to be activated or not during the conversation. If
you move the switch to up
position, the amplify function will be activated and the LED indicator
will lit up, you can adjust the receiver tone and receiver volume
button to get the desired volume level.
SEL 2
SEL
SEL 3
SEL
SEL 4
SEL
SEL
receiver volume and tone
select
receiver volume and tone select
contrast
adj X(X=1,2,3,4)
RING
ON/OFF
SET TIME
st
st
st
MONTH
MONTH-DAY-HOUR-MINUTE
HSANDSET ETTINGS
13
HSANDSET ETTINGS
14
To make a call
To receive a call
To end a call
Pre-dialling function
1. Press button and wait for a dial tone.
2. Dial the telephone number.
3. During a call, you can press button to get a new dial tone for
another call or switch to call waiting.
To receive a call, just press button.
To end a call, just press button.
1. In standby mode, dial your desired number. You can press button to
delete the incorrect digits.
2. If the phone number is correct, press button to dial it out. Then
you can start your conversation.
F
F
Basic Function
NOTE:
volume and tone receiver select
amplify
volume and tone receiver select
shaking
shaking
1.If you move the switch up, the
amplify function are automatically activated each time you use the
phone. If you want to deactivate the function temporarily, press the
button once, at the same time, the LED turns off.
2.If you turn the switch down, the
amplify function are automatically deactivated each time you use the
phone, you will need to activate the function temporarily by pressing
the amplify button.
You can move the switch to up position, when a call is
receiving, the handset will shake. To turn off this function, just move
the switch to down position.
Vibration function
Warning:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
