Cobra Electronics 2016C RADAR DETECTOR User Manual
Cobra Electronics Corporation RADAR DETECTOR Users Manual
Users Manual
![](/img.php?id=2974330&img=bg1.png)
Nothing Comes Close to a Cobra®
A1
The Cobra line of quality products includes:
For more information or to
order any of our products,
please visit our website:
www.cobra.com
©2016 Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
EnglishNothing Comes Close to a Cobra®
Important Information
Customer Assistance
Federal Laws Governing the Use of Radar Detectors
It is not against federal law to receive radar transmissions with your Cobra radar/
laser detector. The Communications Act of 1924 guarantees your right to receive
radio transmissions on any frequency. Local laws that contravene this Act, while illegal,
may be enforced by your local law enforcement ofcials until and unless
they are prohibited from doing so by federal court action.
Safe Driving
Motorists, as well as operators of emergency or service vehicles, are expected to
exercise all due caution while using this product, and to obey all applicable trafc
laws. Do not attempt to change settings of the unit while in motion.
Security of Your Vehicle
Before leaving your vehicle, always remember to conceal your radar detector
in order to reduce the possibility of break-in and theft.
Introduction
Printed in the Philippines
Part No. 480-1071-P
Version B
Operating Instructions
RADAR/LASER
PROTECTION
RAD450
Important Information and
Customer Assistance
CB Radios
Dash Cams
Radar Detectors
Marine VHF Radios
Power Inverters
Accessories
RAD450_MANL_vB.indd 1-1 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bg2.png)
Nothing Comes Close to a Cobra®Nothing Comes Close to a Cobra®
English
A2 A3 20
Display and Product Features NOTESControls Indicators and Connections
Congratulations! You’ve made a smart choice by purchasing a radar/laser
detector from Cobra. Just look at some of the sophisticated features and
capabilities your new unit includes:
Radar/Laser Protection
Detects all radar and laser guns.
LaserEye
Detects laser signals from both front and rear.
VoiceAlert
Digital voice announcements keep your eyes on
the road.
QuietDrive™
Quiet Drive is a muted driving mode for times
when a driver wants less audible feedback while
talking with passengers, on the phone, etc.
Premium Anti-Falsing Circuitry
Automatically reduces false alerts from
erroneous sources including vehicle collision
avoidance systems, trafc ow monitoring
devices and other radar detectors.
Controls, Indicators and Connections •Easy-to-Read Display •
Product Features •
12V DC
Power Jack
Dim Button
For adjusting the
display brightness.
Mute Button
For manual mute of audio
alerts, changing standby
screens, turning Quiet
Drive on/off.
On-Off/Volume Control
Allows you to adjust the
volume of the alerts.
Introduction Introduction
LaserEye
For detection of
laser signals.
Speaker
This booklet describes the simple steps for mounting and setting up your detector.
It also provides helpful information about how radar and laser guns are used and
how you can interpret the alerts you receive.
SEN Button
Adjust sensitivity
and ltering modes
to reduce unwanted
alerts.
FCC NOTICE This device complies with part 15 of FCC rules: Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received
including interference that may cause undesired operation.
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Windshield
Bracket
Mount
AVIS FCC Cet appareil est conforme à la partie 15 des règles de la FCC: Son
fonctionnement est soumis aux deux conditions suivantes: (1) Ce dispositif ne peut
causer des interférences nuisibles, et (2) Cet appareil doit accepter toute interférence
reçue, y compris les interférences qui peuvent causer un mauvais fonctionnement.
Menu Button
To select
detector
settings.
Radar Band Frequency
USB
Port
Signal Strength
Radar/Laser Protection
Detects all radar and laser guns.
LaserEye®
Detects laser signals from both front and rear.
VoiceAlert
Digital voice announcements help keep your
eyes on the road.
QuietDriveTM
Muted driving mode for times driver wants less
audible feedback while talking with passengers
or on the phone.
Premium Anti-Falsing Circuitry
Automatically reduces false alerts from
erroneous sources including automatic door
openers, xed position trafc ow monitoring
systems and other radar detectors.
Updatable IVT FilterTM
User updatable system automatically reduces
false alerts from moving In-Vehicle Technology
sources such as collision avoidance systems and
adaptive cruise control.
Sensitivity Modes
Selectable Low/Med/High modes reduce falsing
in densely populated areas.
Auto Mute
Automatically mutes audio for sustained alerts.
Eye-Catching OLED Display
Bright white OLED display features band
identication icons and numeric signal strength
meter.
Adjustable Sensitivity
Select preferred radar sensitivity (City/City Max/
Highway) to suit driving environment.
Dual Language
English and Spanish voice and text alerts.
6’ Power Cord and Mount Included.
RAD450_MANL_vB.indd 2-21 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bg3.png)
Nothing Comes Close to a Cobra®
1
Contents
Introduction
Important Information ................................. A1
Controls, Indicators and Connections ..................... A2
Display ............................................. A3
Product Features .................................... A3
Your Detector
Installation ........................................... 2
Getting Started ....................................... 5
Buttons ............................................. 5
SEN .............................................. 5
Anti-Falsing Circuitry .................................5
MUTE ............................................. 6
Quiet Drive ........................................ 6
Battery Voltage ..................................... 6
DIM .............................................. 6
Menu-User Settings .................................... 6
Menu-Alert Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Detail ............................................. 8
AutoMute. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Language ......................................... 8
IntelliMute ..........................................8
Screen Saver ........................................9
Smart Power ........................................9
Low Car Voltage .....................................9
System Info .........................................9
Restore Defaults .....................................9
Radar Alerts ..........................................10
Radar Detector-Detector Alerts .........................10
Laser Alerts ........................................10
Responding to Alerts ................................ 11
Understanding Radar and Laser ......................... 12
Understanding LIDAR .................................. 13
Customer Information
Specications ...................................... 14
Maintenance ........................................ 14
Limited 1-Year Warranty ............................... 15
Product Service & Optional Accessories .................. 16
Trademark Acknowledgement ............................17
Introduction
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
RAD450_MANL_vB.indd 1 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bg4.png)
Nothing Comes Close to a Cobra®
English
2 3
Installation
Your Detector Installation
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Installation •
Where to mount your unit
You will get optimum performance from your detector if you mount it at a point
approximately in the center of the vehicle, as low as possible on the front windshield
without obstructing the unit’s view of the road either to the front or rear. You can
also mount it directly on the dashboard.
The unit’s lens must not be blocked and the LaserEye should have a clear view
out the back window to allow maximum detection.
Radar and laser signals pass through glass but not through other materials and
objects. Objects that can block or weaken incoming signals include:
n Windshield wiper blades
n Mirrored sun screens
n Dark tinting at the top of the windshield
n Heated windshields currently available on some vehicles
(Instaclear for Ford, Electriclear for GM). Consult your dealer
to see if you have this option.
Windshield Mounting Dashboard Mounting
1. Attach the rubber cups
to the bracket.
2. Make sure the rubber cups and your windshield are clean.
3. Push the bracket rmly onto
the windshield.
4. Attach the detector to
the bracket. Check that
the unit is parallel to the
road’s surface.
5. To adjust the angle if
necessary, gently push or
pull on the bracket to bend
it. DO NOT use the detector
to bend the bracket.
6. Plug the power cord
into the detector.
7. Plug the cigarette lighter
adapter on the power cord
into your vehicle’s cigarette
lighter.
The LaserEye should have a clear view
Windshield mounting
RAD450_MANL_vB.indd 2-3 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bg5.png)
Nothing Comes Close to a Cobra®
5
Getting Started
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
English
4
Installation
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
NOTE: In some vehicles, power is supplied to the cigarette lighter even
while the ignition is Off. If this is the case with your vehicle, you should
turn Off or unplug your detector when parking for lengthy periods.
1. Place the detector on the dashboard to nd a location
where the unit has a clear, level view of the road and is
parallel to the road’s surface. The angle CANNOT be
adjusted after mounting
2. Remove the paper backing
from one side of the hook-
and-loop fastener.
3. Attach the pad to the
dashboard at your chosen
location and remove the
other paper backing.
4. Attach the detector to the
hook-and-loop fastener. You
can remove and reattach the
unit as often as you like.
5. Plug the power cord into the
detector.
6. Plug the cigarette lighter
adapter on the power
cord into your vehicle’s
cigarette lighter.
Dashboard Mounting Getting Started •
To Turn On The Unit And Adjust The Audio Volume
Rotate the On-Off/
Volume control
clockwise (away
from you).
Audible Tone Visual Display
“Testing”
Three beeps
“System Ready”
Icon Sens Level For
High No ltering for maximum range
Medium Minimal ltering to reduce unwanted alerts
Low Maximum ltering to reduce unwanted alerts
SEN Button
Setting your detector to Low or Medium sensitivity delays the audio alerts
for weak X band and K band signals until they become stronger. (A single beep
will sound when the signal is rst detected.) Also, additional ltering is done to
reduce false alerts while you are driving in, or near, urban areas where there are
many sources for conicting X and K band signals such as microwave towers and
automatic door openers.
Premium Anti-Falsing Circuitry
Your RAD 450 is designed to provide you the truest alerts and minimize the
distraction of erroneous signals from radar-based xed-position and moving sources.
• Adjustable Sensitivity: High/Medium/Low modes allow driver to adjust sensitivity
to driving environment, reducing false alarms from xed position sources such as
automatic door openers.
• IVT Filter: updatable system automatically reduces false alerts from moving
In-Vehicle Technology sources such as collision avoidance systems and adaptive
cruise control.
RAD450_MANL_vB.indd 4-5 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bg6.png)
Nothing Comes Close to a Cobra®
English
6 7
Settings Settings
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Quiet Drive is a muted driving mode for times when a driver wants less audible
feedback while talking with passengers, on the phone, etc. Only the rst few
seconds of audio will be heard. This mode is Off by default.
This mode can be changed in the User Settings menu or by
pressing and holding the MUTE button for two seconds. When
Quiet Drive is on the audio icon on the display will change to:
Battery Voltage
To display your vehicle’s battery voltage, press the MUTE button while no signal
is being detected.
DIM Button
You can choose from four settings for the brightness of the display. Repeatedly
push the DIM button to cycle through the settings. The factory setting is Bright.
Menu - User Settings •
To change the User settings enter the Menu by pressing the MENU button. A voice
announces “Menu” and the display will change to
Press the DIM button to enter the User settings menu.
Press the MUTE or MENU buttons to switch between the User settings.
Press the DIM or SEN buttons to change the selected User setting’s value.
The value that is shown on the display is the selected value. To exit the menu
simply wait several seconds or select Exit Menu.
USER MENU ALERT
USER SETTING VALUE
Detail More*/Less
Quiet Drive Off*/On
Auto Mute Off/On*
Voice Off/On*
Language English*/Spanish
IntelliMute Off*/On/Set
Screen Saver Off/1 Minute*/3 Minute
Smart Power Off*/On
System Info Press the SEN button to display system information.
Restore Defaults Press the SEN button to restore factory default settings
then press SEN button again to conrm.
Exit Menu Press the MUTE button to exit the menu.
* = Factory default setting
Menu - User Settings continued •
Menu - Alert Settings •
To change the Alert settings enter the Menu by pressing the MENU button.
A voice announces “Menu” and the display will change to
Press the SEN button to enter the Alert settings menu.
Press the MUTE or MENU buttons to switch between the Alert settings.
Press the DIM or SEN buttons to change the selected Alert setting’s value.
The value that is shown on the display is the selected value. To exit the menu
simply wait several seconds or select Exit Menu.
USER MENU ALERT
MUTE Button
Manual Mute: Your detector allows you to quickly turn OFF an audio alert by
momentarily pressing the MUTE button. If you press the MUTE button a second
time during the alert, the audio alert will be turned back ON.
When an alert is being muted the audio icon on the display will
change to:
MENU Button
RAD450_MANL_vB.indd 6-7 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bg7.png)
Nothing Comes Close to a Cobra®
English
8 9
Settings Settings
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Detail
In the More detail mode, information about the radar band, signal strength and
frequency will be displayed.
In Less detail mode, only the threat level is displayed (see page 10).
AutoMute
AutoMute will automatically reduce the audio volume of all alerts after four
seconds for as long as the signal is detected. The factory setting for AutoMute
is On.
RADAR SETTING VALUE
X Band Off/On*
K Band Off/On*
Ka Band Off/On*
VG-2 Off*/On
Spectre Off*/On
Exit Menu Press the MUTE button to exit the menu.
* = Factory default setting
Menu - Radar Settings continued •
Language
The detector can be set to either English or Spanish for all text and voice audio.
IntelliMute
INTELLIMUTE allows you to avoid alerts you don’t need to hear because you are
stopped or moving slowly. By sensing the “revs” (RPMs) of your engine, INTELLIM-
UTE knows when you are at low speed and automatically mutes alerts (except for
strobe signals from emergency vehicles).
Before INTELLIMUTE will work, you must set an activation point for your engine’s
revs. Whenever the revs are below that point, INTELLIMUTE will begin muting.
The activation point will be stored in memory and recalled each time the power is
turned On. The factory setting is INTELLIMUTE Off.
NOTE: INTELLIMUTE may not work with some vehicles because it cannot sense
the engine’s revs. In such cases, you can reduce unwanted audio alerts
by using Auto Mute and SEN mode when appropriate.
Screen Saver
Your detector has a SCREEN SAVER mode. When SCREEN SAVER is turned On
(factory default is 3 minutes), the screen will change to Dark from it’s Bright,
Dim, or Dimmer setting after the time interval selected. While the screen is Dark,
the scanner will be displayed dimly.
NOTE: While
SCREEN SAVER
is activated, any alert will turn the display back on
at the last brightness setting (Bright, Dim or Dimmer). Touching any button will
also turn On the display.
Smart Power
Your detector includes the SMARTPOWER feature that, when turned On, will put the
unit into Low Power mode 15 minutes after the car’s engine has been turned Off.
Before
SMARTPOWER
enters Low Power mode, you will hear three beeps and
SMARTPOWER
will ash on the display. To return the unit to Normal Power mode
and exit Low Power mode, start the car, press any button or turn the unit
Off
and
then On again.
Low Car Voltage
Displays your car battery voltage and automatically warns you if this drops
below 11.9V. Your detector will then shut off to prevent further draining of
your car battery.
System Info
Displays information about the versions of software/rmware that are
installed on your detector.
Restore Defaults
To return your detector to factory default settings, press the SEN Button.
Press the SEN Button again to conrm that you want to restore factory
settings. Press the MUTE Button to exit.
RAD450_MANL_vB.indd 8-9 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bg8.png)
Nothing Comes Close to a Cobra®
English
10 11
Settings and Detection Detection
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Radar Alerts •
In More detail mode the radar band, signal strength and frequency of the detected
radar signal will be displayed.
If you are a new user of radar detectors, you may want to use the Less detail
mode. In this mode the display will only show one, two, or three bars which
indicate how likely the alert is to be a police radar or laser gun. This threat level
indication takes into account the laser or radar band, strength, and frequency of
the detected signal.
Level Display Threat
1Low
2Medium
3High
Police use radar detector detectors (RDDs) to spot users of radar detectors.
Your detector is able to identify signals from VG-2, Spectre I and Spectre IV+
RDDs and can provide alerts when any of these or similar devices are in use
near your vehicle.
Radar Alerts - Radar Detector-Detectors •
Laser Alerts •
With Laser signals you will always receive a full strength alert. In More Detail
mode the word Laser will be shown on the display along with the pulse rate of
the Laser signal. In Less Detail mode three signal strength bars will be shown.
Description Interpretation Recommended Response
Tone repeats slowly at rst,
then speeds up rapidly.
Probably police radar. FULL ALERT
Tone sounds one time only. Probably a false alarm,
but possibly pulsed radar
or VG-2 nearby.
Exercise caution
Tone instantly begins
repeating rapidly.
Radar or VG-2 nearby has
been activated suddenly.
FULL ALERT
Tone repeats slowly as you
approach a hill or bridge,
then speeds up sharply as
you reach it.
Probably police radar
beyond the hill or bridge.
FULL ALERT
Tone repeats slowly for a
short period.
Probably a false alarm. Exercise caution
Any type of laser alert. Laser alerts are never
false alarms.
FULL ALERT
Responding to Alerts
Radar Band Frequency
Signal Strength
RAD450_MANL_vB.indd 10-11 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bg9.png)
Nothing Comes Close to a Cobra®
English
12 13
Detection
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Understanding Radar and Laser •
Radar Speed Monitoring Systems
Three band frequencies have been approved by the Federal Communications
Commission (FCC) for use by speed monitoring radar equipment:
X band 10.525 GHz
K band 24.150 GHz
Ka band 33.400 – 36.00 GHz
Your detector detects signals in all three radar bands, plus Ku band (13.435
GHz), which is an approved frequency used in parts of Europe and Asia.
VG-2
VG-2 is a “detector detector” that works by detecting low-level signals emitted
by most radar detectors. Your detector does not emit signals that can be detected
by VG-2, but does detect VG-2 signals and will alert you when a device is in use
near your vehicle. While no signal is being detected, press and hold the Dim
button for four seconds.
Your detector can be spotted by Spectre IV+ RDDs, but is invisible to VG-2 and
Spectre I RDDs. You can choose whether you want to be alerted to VG-2 and
Spectre I & IV+ RDD signals. The factory setting for VG-2 and Spectre I & IV+
alerts is Off. It is recommended to leave these Off unless you are concerned
about being monitored for having a radar detector.
The factory setting for VG-2 alerts is Off.
LIDAR (Laser)
The correct name for the technology that most people refer to as laser is
actually LIDAR, which stands for Light Detection and Ranging.
LIDAR operates much like radar. Its signal spreads out like a radar signal, though
not as widely. Unlike radar, LIDAR must have a clear line of sight to its target
vehicle throughout the entire measurement interval. Obstructions such as sign
posts, utility poles, tree branches, etc., will prevent valid speed measurement.
Some common questions about LIDAR include:
n Does weather have any affect on LIDAR?
Yes. Rain, snow, smoke, fog or airborne dust particles will reduce the
effective range of LIDAR and can, if dense enough, prevent its operation.
n Can LIDAR operate through glass?
Yes. Newer LIDAR guns can obtain readings through most types of glass.
However, the laser pulse also can be received through glass to trigger an
alarm by your detector.
n Can LIDAR operate while in motion?
No. Because LIDAR operates by line of sight, the person using it cannot drive
the vehicle, aim and operate the gun all at the same time.
n Is it legal for police to use LIDAR?
Yes, LIDAR is allowed to be used in all 50 States by police. Your detector
detects LIDAR (laser).
Understanding LIDAR &
Maintenance
RAD450_MANL_vB.indd 12-13 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bga.png)
Nothing Comes Close to a Cobra®15
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
English
14
Your Detector
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Specications &
Maintenance
U.S. Patent Number: 6,078,279
Specications •
Band and Frequencies
WARNING Modications or parts substitutions not approved by
Cobra Electronics Corporation may violate FCC Rules and void your
authority to operate this equipment.
Band Frequencies
X Band 10.525 ± 0.050 GHz
K Band 24.125 ± 0.125 GHz
Ka Band 34.700 ± 1.300 GHz
Laser 910 ± 50 nm 100 PPS
VG-2 11.500 ± 0.250 GHz
Maintenance •
Your detector is designed and built to give you years of trouble-free performance
without the need for service. No routine Maintenance is required.
If your unit does not appear to be operating properly, please follow these
troubleshooting steps:
n Make sure the power cord is properly connected.
n Make sure the socket of your vehicle’s cigarette lighter is clean and free
of corrosion.
n Make sure the power cord’s cigarette lighter adapter is rmly seated in
your cigarette lighter.
Warranty
Limited 1-Year Warranty •
Cobra Electronics Corporation warrants that this product and the component parts
thereof, will be free of defects in workmanship and materials for a period of one year
from the date of rst consumer purchase. This warranty may be enforced by the rst
consumer purchaser. If the product is under warranty, it will be repaired or exchanged
depending on the model as determined at Cobra’s sole discretion. Such remedy shall
be your sole and exclusive remedy for any breach of warranty.
The procedure for obtaining service and support, and the applicability of this warranty,
will vary depending on the country or jurisdiction in which you purchased and utilize
the product. For the details on obtaining product service, support and warranty please
visit www.cobra.com/support
Provided that the product is utilized within the U.S.A.- Cobra will, without charge,
repair or replace, at its option, defective products, products or component parts upon
delivery to the Cobra Factory Service department, accompanied by proof of the date of
rst consumer purchase, such as a duplicated copy of a sales receipt. You must pay
any initial shipping charges required to ship the product for warranty service, but the
return charges, to an address in the U.S.A., will be at Cobra’s expense, if the product is
repaired or replaced under warranty.
This warranty gives you specic legal rights, and you may also have other rights which
may vary from state to state and country to country.
Exclusions: This limited warranty does not apply: 1) To any product damaged by
accident; 2) In the event of misuse, ordinary wear, failure to follow directions, or
improper maintenance of the product or as a result of unauthorized alterations or
repairs; 3) If the serial number has been altered, defaced, or removed; 4) If the product
was purchased or is utilized in a jurisdiction not covered by the limited warranty.
All implied warranties, including warranties of merchantability and tness for a
particular purpose are limited in duration to the length of this warranty. Cobra shall
not be liable for any incidental, consequential or other damages; including, without
limitation, damages resulting from loss of use or cost of installation.
Some states and countries do not allow limitations on how long an implied warranty
lasts and/or do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations may not apply to you. This warranty gives you
specic legal rights, and you may also have other rights which vary from state to state
and country to country.
RAD450_MANL_vB.indd 14-15 3/30/16 12:04 PM
![](/img.php?id=2974330&img=bgb.png)
Nothing Comes Close to a Cobra®
English
16 17
Product Service and Support •
For any questions about operating or installing this new Cobra product, PLEASE CONTACT
COBRA FIRST…do not return this product to the retail store. The contact information for
Cobra will vary depending on the country in which you purchased and utilize the product.
For the latest contact information, please go to www.cobra.com/support
For products purchased in the U.S.A. you may also call 1-773-889-3087.
For Products Purchased in the U.S.A., if your product should require factory service, please
go to www.cobra.com/support and follow the instructions for returning your product to
the Cobra Factory Service Department for service.
Optional Accessories •
You can nd quality Cobra products and accessories at your local Cobra dealer,
or in the U.S.A., you can order directly from Cobra at www.cobra.com
Straight 12V DC
Power Cord
Includes plug and fuse
Item #420-030-N-001
Windshield
Mounting Bracket
Includes suction cups
Item #545-159-N-001
Product Service & Support
and Optional Accessories Customer Information
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Coiled 12V DC
Power Cord
Includes plug and fuse
Item # 420-026-N-001
Dual Port Power Adapter
Includes adjustable plug
(up to 90˚) and fuse
Item # CLP-2B
Straight Combination Radar
USB Cord
Includes plug and USB
Output
Item # PWR USB-01
Hardwire Cord for Radar
Includes fuse
Item # RA-PSCB
Install Mount
Includes 3M Dual Lock
Item # 545-002
Customer Information
Intro Operation Customer
Assistance
Warranty
Notice
Main Icons
Secondary Icons
Trademark Acknowledgement
Trademark Acknowledgement •
Cobra®, DigiView®, EasySet®, Extra Sensory Detection®, LaserEye®, Nothing Comes Close to
a Cobra®, VG-2 Alert®, Xtreme Range Superheterodyne® and the snake design are registered
trademarks of Cobra Electronics Corporation, USA.
Cobra Electronics Corporation™, AURA™, IntelliLink™, IntelliScope™, IntelliView™, Revolution™ Series,
IVT Filter™, SmartPower™, Super-Xtreme Range Superheterodyne™, S-XRS™, and Voice Alert™ are
trademarks of Cobra Electronics Corporation, USA.
Instaclear® for Ford is a registered trademark of Ford Motor Company, Inc. Electriclear® for GM is
a registered trademark of General Motors Corporation. LTI Laser™ and LTI 20-20™ are trademarks
of Laser Technology, Inc. Kustom Laser™, Kustom Laser 340™ and ProLaser II™ are trademarks of
Kustom Signals, Inc. SpeedLaser™ is a trademark of Laser Atlanta. Stalker™ LIDAR is a trademark of
Applied Concepts, Inc. Spectre I™ and Spectre IV™ are trademarks of Stealth Micro Systems Pty. Ltd.
SpeedLaser™ is a trademark of Laser Atlanta, LLC. Interceptor VG-2™ is a trademark of TechniSonic
Industries LTD.
RAD450_MANL_vB.indd 16-17 3/30/16 12:04 PM
