Users Manual

User Manual
Remote Control
WASPcam 9820WR
NOTE**: Before pairing the remote to the camera, format the MicroSD card in the camera.
How To Pair the Remote:
1. When the camera is in standby mode, press the menu button twice to enter
system settings.
2. Press the left/right arrow buttons to scroll through the menu, choose remote
control to enter the remote menu. Then select Remote Match.
3. A message will appear on the LCD Screen Wait Remote Match, the camera is
now in pairing mode.
4. At the same time, press both buttons on the remote controller to start
pairing. Pairing is successful when the LCD screen shows Remote Match
OK
1 - Indicator light
2 Photo Button - press to take photos,
Press the Inquiry/Record Button (3) and the Photo
button (2) simultaneously to enter Pairing mode
3 Inquiry/Record Button press to start/stop
recording, press and hold for 3 seconds to check
the present status of the camera (see below)
Remote Control Indicator Light Status
Status/LED Red LED Light Blue LED Light
Standby 1 time/sec frequently
Flickers about 5sec Off
Recording Off Light on 3 seconds, then off
Status Inquiry
Power off Light on 3 secs, then off Off
Pairing Long light Long light
Success Light on 3 secs, then off Light on 3 secs, then off
Pairing Mode Failure Off Off
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Start recording 2 times/sec frequent
Flickers about 5sec Off
Stop recording 1 time/sec frequent
Flickers about 5sec Off
Photo Off Flashes once each time you
take a photo
IC Statement
This device complies with Industry Canadas licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interfe
The term IC: before the certification/registration number only signifies that the
Industry Canada technical specifications were
met. This product meets the applicable Industry Canada technical specifications.
Le présent appareil est conforme aux CNR d'Industrie Canada applicable aux
appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en
compromettre le fonctionnement
