Cobra Electronics FRS307C FRS Transceiver User Manual
Cobra Electronics Corporation FRS Transceiver Users Manual
Users Manual
FPO
Operating Instructions for Your Cobra® microTALK®
2-WAY RADIO MODEL FRS 307-2 VP
Operating Instructions for Your Cobra® microTALK®
2-WAY RADIO MODEL FRS 307-2 VP
Operating Instructions for Your Cobra® microTALK®
2-WAY RADIO MODEL FRS 307-2 VP
Nothing comes
close to a Cobra™
Nothing comes
close to a Cobra™
Nothing comes
close to a Cobra™
English, pages 1-16
French, pages 17-32
Spanish, pages 33-46
(ENGLISH)
(FRENCH)
(SPANISH)
(ENG)
(FR)
(SPAN)
Product Features
• TWO-WAY RADIO with up to a
2 mile (3 km) range
• 14 CHANNELS
• 38 CTCSS PRIVACY CODES
• UHF FM frequencies
• BACKLIT LCD display
• EXTERNAL SPEAKER/MICROPHONE jack
• 10 MEMORY LOCATIONS
• FULL CHANNEL/CTCSS SCAN
• MEMORY SCAN
• DUAL WATCH
• MAXIMUM RANGE extender
• 5 CALL SIGNAL SELECTIONS
• VOX MODE for hands-free transmissions
• selectable "ROGER BEEP" confirmation tone
• selectable KEYSTROKE TONES
• AUTO SQUELCH
• CALL ALERT
• BATTERY SAVER circuitry
• LOCK button
• BELT CLIP
• WRIST STRAP
• WATER RESISTANT
• 2 NiMH BATTERY packs
• 2-PORT DESKTOP RAPID CHARGER
• 2 EARBUD MICROPHONES
Installing or
Replacing Batteries
1. Pull down the LOCK tab to remove the
battery compartment cover.
2. Insert your NiMH battery pack or four AAA
batteries. Position batteries according to
polarity markings. (NOTE: NiMH batteries
are included with your microTALK®radio.
When not using your NiMHs, always use
high quality alkaline batteries. Recharge
NiMH battery pack according to the
instructions for the FA-CJ charger.)
Only the Cobra®
NiMH battery pack
(included) can be
recharged using the
recharging pads on
the back of the unit.
See page 16 for optional accessories.
OPERATION ENGLISH
1
OPERATION
ENGLISH
2
This device complies with part 15 of the FCC
rules. Operation is subject to the condition that
this device does not cause harmful interference.
FCC Warnings: Replacement or substitution
of transistors, regular diodes or other parts of
a unique nature, with parts other than those
recommended by Cobra,
®may cause a
violation of the technical regulations of part
95 of the FCC Rules, or violation of Type
Acceptance requirements of Part 2 of the Rules.
ON-OFF/
POWER
button
backlit LCD display
LOCK button
MODE button
VOLUME UP
& DOWN
buttons
CHANNEL
SELECT
buttons
speaker/
microphone
belt clip
CALL
button
TALK
button
LIGHT/MAX
RANGE
button
Antenna
Lock tab
battery
compartment
battery
charger
pads
LOCK tab
external speaker/
microphone jack
LIGHT/MAX
RANGE button
TALK
button
O P E R AT I O N
Selecting a CTCSS
Privacy Code
CTCSS (Continous Tone Coded Squelch
System) is an advanced tone coding system
allowing you to select one of 38 privacy codes
to reduce interference from other users on the
channel. (NOTE: If you are using a privacy
code, both radios must be tuned to the same
channel and privacy code to communicate.
Each channel will remember the last privacy
code you selected.) To select a privacy code:
1. After selecting a main channel, press and
release the MODE button. A small number
will flash next to the channel in the LCD.
2 . Push the CHANNEL SELECT button up or
down to select a privacy code. You can hold
the button up or down for fast advance.
3. When your desired privacy code is displayed,
p ress and release the LOCK button or pre s s
mode to enter selection and go to the next
f u n c t i o n .
Calling Another Person
To alert another person that you are calling:
1 . P ress and release the CALL button. The other
person will hear a 2-second ringing tone.
You cannot send or receive transmissions
during the 2-second call tone. (See page
13 for instructions on how to select between
5 call tone settings.)
O P E R AT I O NENGLISH
4
CALL button
LOCK
b u t t o n
M O D E
b u t t o n
CHANNEL
U P
C H A N N E L
D O W N
Turning On Your
microTALK®Radio
1. Press and hold the ON/OFF POWER
button for 2 seconds. A series of audible
tones will indicate the radio is on.
2. Your microTALK®is now in Standby mode,
ready to receive transmissions. The radio is
always in Standby mode except when the
TALK, CALL, or MODE buttons are pressed.
(For Advanced Features accessed through
the MODE button, see page 7.)
Illuminating the Display
1. Press and release the LIGHT/MAX RANGE
button to illuminate the display for
10 seconds.
Battery Indicator
When only one segment of the battery
indicator is blinking, the battery power is low
and you should recharge
your FA-BP battery pack
or change your AAA
alkaline batteries.
Auto Battery Save
Your microTALK®radio has a unique circuit
designed to extend battery life. If there are no
transmissions within 10 seconds, the unit will
automatically switch to Battery Save mode
and POWER SAVER will
appear in the display.
This will not affect the
unit’s ability to receive
incoming transmissions.
Selecting a Channel
1. With the radio on, select any of the
14 channels by pushing the CHANNEL UP
or CHANNEL DOWN button.
(NOTE: Both radios must be tuned to
the same channel to communicate.)
ENGLISH
3
ON-OFF/POWER
b u t t o n
LIGHT/MAX RANGE
b u t t o n
CHANNEL
U P
C H A N N E L
D O W N
O P E R AT I O N
Using the Lock Function
The Lock function locks the CHANNEL, MODE,
and POWER buttons to prevent accidental
operation. To use the Lock function:
1. While in Standby mode, press and hold
the LOCK button for one second.
The Lock icon will be visible when the unit
is locked.
Buttons that are NOT locked are the CALL,
VOLUME, LIGHT/MAX RANGE, and TALK
buttons, which are all fully functional while
the unit is locked.
2. To “unlock” buttons, press and release
the LOCK button again. The Lock icon
disappears and all buttons will be
unlocked.
External Speaker/
Microphone Jack
Your microTALK®radio can be fitted with an
external speaker/microphone, freeing your
hands for other tasks. (Earbud microphones
are included with your FRS 307-2 VP–see
enclosed instruction sheet. For additional
accessories (sold separately) see page 16.)
To attach an external speaker/microphone:
1. Open the SPKR/MIC tab on top of
the unit.
2. Insert the plug into the SPKR/MIC jack.
Using the MODE button
The MODE button allows you to use and
program the various functions of your
microTALK®radio. If you press and hold the
MODE button, the LCD will cycle through the
different functions.
O P E R AT I O NENGLISH
6
e x t e rnal micro p h o n e
s p e a k e r
s p e a k e r / m i c ro p h o n e
j a c k
LOCK button
M O D E
b u t t o n
Talking to Another Person
1. Press and
hold the
TALK button.
2 . With the micro p h o n e
about 2 inches (5 cm)
f rom your mouth, speak in a normal voice.
3. Release the button when you’re finished
talking and listen for a response. You
cannot receive incoming calls while
pressing the TALK button.
“Roger Beep”
Confirmation Tone
Your listener will hear an audible tone when you
release the TALK button. This alerts the other part y
that you are finished talking and it is OK for them
to speak. (
NOTE:
The Roger Beep can be turn e d
o ff and on, see page 12.)
Listening for a Response
When you are finished talking:
1 . Release the TALK button to receive i n c o m i n g
t r a n s m i s s i o n s . The radio is always in Standby
mode except when the TALK, CALL, or MODE
buttons are pre s s e d .
2. Adjust the volume by pressing and holding
the VOLUME UP or VOLUME DOWN buttons.
Auto Squelch
Your microTALK®radio is equipped with Auto
Squelch, which automatically shuts off weak
transmissions and unwanted noise due to
terrain, conditions, or if you’ve reached your
maximum range limit. (NOTE: To learn more
about the range of your microTALK®radio,
see page 13.)
Maximum Range Extender
You can temporarily turn off Auto Squelch,
allowing all signals to be received and
extending the maximum range of your radio:
1. Press and hold the LIGHT/MAX RANGE
button for 5 seconds. You will hear
2 beeps indicating that Maximum Range
Extender is on.
2. To turn Maximum Range Extender off, press
and hold the LIGHT/MAX RANGE button for
1 second, or change channels.
ENGLISH
5
TALK button
L I G H T / M A X
RANGE button
O P E R AT I O NO P E R AT I O N • A D VANCED FEAT U R E S
Programming Memory
Locations
Your microTALK®radio has 10 memory
locations (0-9) for storing your most
frequently used channels and privacy codes.
To program locations:
1. Push the MODE
button until the
Memory icon and
the memory
location flashes.
2. Select the memory
location you wish to
change by pushing
the CHANNEL SELECT
button up or down.
3. Press and release the MODE button again.
The Memory icon and the main channel
number will flash.
4.
Select the main channel you wish to s t o re by
pushing the CHANNEL SELECT button up or
d o w n .
5. P ress the MODE button again to store the
main channel in memory and move to
privacy code selection. The privacy code
number begins flashing and the Memory
icon continues to flash.
6. Select the privacy code (0-38) you
wish to store by pushing the CHANNEL
SELECT button up or down.
7. Press the TALK button
to transmit on your
selected channel and
privacy code, which
will be stored into
the memory location you are using.
8. Press and release the LOCK button to
return to Standby mode at your new
memory location, or press and release the
MODE button to save the memory location
and proceed to other functions.
ENGLISH
8
M O D E
b u t t o n
TALK
b u t t o n
MODE button
MODE button
L O C K
b u t t o n
MODE
b u t t o n
CHANNEL SELECT
b u t t o n
Using VOX Mode
In VOX mode, your microTALK®can be used
"hands-free," automatically transmitting when
you speak. To turn VOX mode on and off:
1. Press the MODE button until the VOX icon
flashes and the current setting ("on" or
"off") is displayed.
2. Push the CHANNEL SELECT button up or
down to turn VOX mode on or off.
3. Press and release the LOCK button to enter
the new setting, or press the MODE button
to enter the new setting and proceed to
other functions.
Setting the VOX
Sensitivity Level
You can set the VOX sensitivity level to fit the
volume of your voice and avoid transmissions
triggered by background noise. To set the
sensitivity:
1. Press the MODE button until the VOX
icon flashes and the number for the
current sensitivity level is displayed next
to the letter L (level 5 = most sensitive,
level 1 = least sensitive).
2. Push the CHANNEL SELECT button up or
down to change the setting.
3. Press and release the LOCK button to enter
the new setting, or press the MODE button
to enter the new setting and proceed to
other functions.
ENGLISH
7
M O D E
b u t t o n
LOCK
b u t t o n
MODE
b u t t o n
C H A N N E L
U P
C H A N N E L
D O W N
C H A N N E L
U P
C H A N N E L
D O W N
M O D E
b u t t o n
OPERATIONOPERATION
Using the Scan Function
(continued)
To scan privacy codes:
1. While in Standby mode, press the
CHANNEL SELECT button up or down to
choose the main channel you wish to scan.
2. Press the MODE button until the Scan
icon and the privacy code number flashes.
3. Push the CHANNEL SELECT button
up or down and the unit will begin
scanning privacy codes within the
main channel you selected.
4. The radio will continue to scan privacy
codes and stop if an incoming
transmission is detected. The unit will
remain on that code for 10 seconds.
During that time you can:
a) Press and hold the TALK button and talk.
The radio will remain on that channel and
privacy code, then return to Standby mode.
b) Push the CHANNEL SELECT button up or
down to resume scanning privacy codes.
c) Press the MODE button to proceed
to memory location scanning.
If you do not press any button within
10 seconds, the radio will automatically
resume scanning privacy codes.
To scan memory locations:
1. Press the MODE button until the Scan icon,
Memory Location icon and memory
location number flashes.
2. Push the CHANNEL
SELECT button up or
down and the unit
will begin scanning
memory locations.
ENGLISH
10
MODE button
TALK button
MODE button
CHANNEL SELECT
button
CHANNEL SELECT
button
MODE button
CHANNEL SELECT
button
Recalling Memory Locations
To recall a channel you have stored in a
memory location:
1. Press the MODE button until the Memory
icon and a memory location flashes.
2. Select your desired
memory location
by pushing the
CHANNEL SELECT
button up or down.
Press the LOCK
button to enter
your selection. To
go on to the next
function without
selecting a memory
location, press the MODE button.
3. Repeat steps 1 and 2 to recall other
memory locations.
Using the Scan Function
Your microTALK®radio can automatically
scan main channels (1-14), the privacy
codes (0-38) within one main channel,
or memory locations.
To scan main channels:
1. Press the MODE button until the Scan icon
and main channel number flashes.
2. Push the CHANNEL SELECT button up
or down and the unit will begin scanning
the main channels. (NOTE: The unit
“ignores” privacy codes while scanning
main channels.)
3. The radio will continue to scan all main
channels and stop if an incoming
transmission is detected. The unit will
remain on that channel for 10 seconds.
During that time you can:
a) Press and hold the TALK button and
talk. The radio will remain on that
channel and return to Standby mode.
b) Push the CHANNEL SELECT button
up or down to resume scanning main
channels.
c) Press the MODE button to proceed
to privacy code scanning (see following
page).
If you do not press any button within
10 seconds, the radio will automatically
resume scanning main channels.
ENGLISH
9
MODE button
CHANNEL SELECT
button
MODE button
LOCK
button
3. The radio will continue to scan all memory
locations and stop if an incoming
transmission is detected. The unit will
remain on that location for 10 seconds.
During that time you can:
a) Press and hold the TALK button and talk.
The radio will remain on that memory
location channel and return to Standby mode.
b) Push the
CHANNEL SELECT
button up or down
to resume scanning
memory locations.
c) Press the MODE button to proceed to
other functions.
If you do not press any button within
10 seconds, the radio will automatically
resume scanning memory locations.
Setting Dual Watch
Dual watch allows you to simultaneously
monitor any two channels/privacy codes
you select. To program Dual Watch:
1. Select the first channel and privacy code
you wish to monitor. (To review, see
pages 3-4.)
2. Press the MODE button until the Dual
Watch icon flashes.
3. Push the CHANNEL
SELECT button up or
down to select the
second channel you
wish to monitor.
4. Press the MODE button. The privacy code
flashes.
5. Push the CHANNEL SELECT button up or
down to select the second privacy code.
6. Press and release the
LOCK button to store
the second channel/
privacy code and
engage Dual Watch.
7. To terminate Dual Watch and return to
normal Standby mode, press and release
the LOCK, TALK or MODEbutton.
O P E R AT I O NENGLISHO P E R AT I O N ENGLISH
Turning Roger Beep
Off and On
With Roger Beep turned on, your listener
will hear an audible tone when you release the
TALK button. To change Roger Beep mode:
1. Press the MODE button until the Roger
Beep icon flashes and the current setting
(“on” or “off ” ) is displayed.
2. Push the CHANNEL SELECT button up or
down to turn Roger Beep on or off.
3. To enter the new setting you can press and
release the LOCKbutton, or press no
buttons for 15 seconds. Press the MODE
button to enter the new setting and
proceed to other functions.
Turning Keystroke Tones
Off and On
With Keystroke Tones turned on, your unit will
sound beeps each time you press a button or
change a setting. To change Keystroke Tones
mode:
1 . P ress the MODE button until the Keystro k e
tones icon flashes and the current setting
(“on” or “off”) is displayed.
2. Push the CHANNEL SELECT button up or
down to turn Keystroke Tones on or off.
3. To enter the new setting you can press and
release the LOCKbutton, or press no
buttons for 15 seconds. Press the MODE
button to enter the new setting and
proceed to other functions.
12
MODE button
MODE
b u t t o n
CHANNEL UPCHANNEL DOWN
CHANNEL UPCHANNEL DOWN
LOCK button
MODE button
11
MODE button
MODE button
CHANNEL SELECT
b u t t o n
CHANNEL SELECT
b u t t o n
TALK button
LOCK
b u t t o n
O P E R AT I O N LI M IT ED 2- Y E AR WA R R A N T YENGLISH
14
Customer Assistance
After reading this owner’s manual, if you have any questions
about installing or operating your microTALK®radio, or if you
are missing any parts, please contact Cobra®first. Do not
re t u rn this product to the store. C o b r a®E l e c t r onics offers the
following customer support services.
•Automated Help Desk is available 24 hours
a day, 7 days a week at 773-889-3087.
• Customer Service Operators are available at
the same number 8:00 a.m. to 6:00 p.m. CST
Monday through Friday (except holidays).
• Questions can be faxed to 773-622-2269.
• Technical assistance is available on-line in
the Frequently Asked Questions (FAQ)
section at www.cobra.com or by e-mail
to productinfo@cobra.com.
If your product should require factory service please
call Cobra®first before sending your unit in. This will
ensure the fastest turn-around time on your repair.
You may be asked to send your unit to the Cobra®factory.
It will be necessary to furnish the following in order to
have the product serviced and returned.
1. For Warranty Repair include some form of proof-of-
purchase, such as a mechanical reproduction or carbon
of a sales receipt. If you send the original receipt it
cannot be returned.
2. Send the entire product.
3. Enclose a description of what is happening with the unit.
Include a typed or clearly printed name and address of
where the unit is to be returned.
4. Pack unit securely to prevent damage in transit.
If possible, use the original packing material.
5. Ship prepaid and insured by way of a traceable carrier such
as United Parcel Service (UPS) or First Class Mail to avoid
loss in transit to: Cobra®F a c t o ry Service, Cobra Electro n i c s
C o r p o r a t i o n , 6500 W. Cortland St., Chicago, IL 60707.
6. If the unit is in warranty, upon receipt of your unit it will
either be repaired or exchanged depending on the model.
Please allow approximately 3-4 weeks before contacting
us for status. If the unit is out of warranty a letter will
automatically be sent informing you of the repair charge
or replacement charge. If you have any questions, please
call 773-889-3087 for assistance.
FOR PRODUCTS PURCHASED IN U.S.A.
Cobra Electronics Corporation warrants that its Cobra ®FRS
Radios, and the component parts thereof, will be free of
defects in workmanship and materials for period of two
(2) years from the date of first consumer purchase. This
warranty may be enforced by the first consumer purchaser,
provided that the product is utilized within the U.S.A.
Cobra®will, without charge, repair or replace, at its option,
defective FRS radios, products or component parts upon delivery
to the Cobra®F a c t o ry Service Department, accompanied by proof
of the date of first consumer purchase, such as a duplicated copy
of a sales re c e i p t .
You must pay any initial shipping charges required to ship
the product for warranty service, but the return charges will
be at Cobra's expense, if the product is repaired or replaced
under warranty.
This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Exclusions: This limited warranty does not apply 1) to any pro d u c t
damaged by accident; 2) in the event of misuse or abuse of the
p roduct or as a result of unauthorized alterations or repairs;
3) if the serial number has been altered, defaced or removed;
4) if the owner of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability
and fitness for a particular purpose are limited in duration to
the length of this warranty. Cobra®shall not be liable for any
incidental, consequential or other damages; including, without
limitation, damages resulting from loss of use or cost of
installation.
Some states do not allow limitations on how long an implied
warranty lasts and/or do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitations
may not apply to you.
Changing Call Tone Settings
You can choose between five different call
tone settings to transmit a unique call alert.
To select a call tone setting:
1 . With the power turned off, press and hold the
CALL button as you turn the power on. The
number of the current call tone setting will
flash and the tone will sound for one second.
2. Push the CHANNEL SELECT button up or
down to hear the other
call tone settings.
3. With the number
of your desired
call tone setting
displayed, press
and release the
TALK button or
LOCK button. Your selection will be entered.
4. If no buttons are pushed for 15 seconds,
the unit will automatically enter the last
call tone pattern that was displayed.
microTALK®Range
Your microTALK®radio has a range of up to 2
miles (3 km). Your range will vary depending
on terrain and conditions. In flat, open country
your radio will operate at maximum range.
Buildings and foliage in the path of the signal
can reduce the range. Dense foliage and hilly
terrain will further reduce the signal.
Remember, you can achieve maximum
range by using Maximum Range Extender.
(See page 5.)
ENGLISH
13
CALL button
POWER button
C H A N N E L
U P
C H A N N E L
D O W N
LOCK button
15
A C CES SOR IES • ORD E R FOR MENGLISH
16
Name _____________________________________________________________________
Address (No P.O. Box) ___________________________________________________________
City ____________________ State/Province ______________ Zip___________ Country _ ______
Telephone (___) _________________________ Circle One: Visa MasterCard Discover
Credit Card No. ___________________________________ Exp. Date _____________________
Customer Signature_____________________________________________________________
Vox Headset Mic
MA-VOX Ear Bud Mic
with PTT
M A - E B M
Lapel Speaker/
Microphone
M A - S M
Replacement
Belt Clip
FA - B C 4
2 Port Desktop
NiMH Charger
FA - C F
NiMH Rechargeable
Battery Pack
FA-BP
U.S. Subtotal
(Tax if applicable)
Shipping/handling
Total
Canada Amount
G.S.T.7%
*QST 7.5%
Shipping/ handling
Total
*Quebec residents only
Ordering from Canada
(Call 514-683-1771
for pricing)
Order by phone:
Call 514-683-1771
(Press 1 from the main menu)
9 a.m. - 5p.m., M-F, EST.
Order by e-mail:
cobraextras@avs.ca
Order by mail or fax:Please
fill out order form below,
and mail/fax directly to:
AVS Technologies Inc.
2100 Trans Canada Hwy. S.
Montreal, Que. H9P 2N4
Fax to: 514-683-5307
Please allow 4-6 weeks
for delivery in Canada.
Prices subject to change
without notice.
Item # US Cost Ea. Canada Cost Ea. Qty. Amount
$5.50
Ordering from U.S.
Call 773-889-3087
for pricing or visit
www.cobra.com
For credit card orders fill
out order form and fax
to 773-622-2269
Or call 773-889-3087
(Press 1 from the main
menu) 8:00 am-6:00 pm,
M-F, CST.
Make check or money
order payable to:
Cobra®Electronics
Attn: Accessories Dept.
6500 West Cortland St.
Chicago, IL 60707
Please allow 2-3 weeks
for delivery in U.S.
Prices subject to change
without notice.
Tax
Table
Illinois add 8.75%
Indiana & Wisconsin add 5% Michigan & Ohio add 6 %
$25.00 and under
$ 2 5 . 0 1-$4 0 . 0 0
$ 4 0 . 0 1-$ 8 0 . 0 0
$ 8 0 . 0 1-$ 1 2 0 . 0 0
$ 1 2 0 . 0 1-$ 1 6 0 . 0 0
$160.01 and up
$4.75
$6.95
$ 9 . 2 5
$ 1 0 . 2 5
$ 1 1 . 7 5
$14.50
Amount Shipping/Handling For AK, HI and
PR please add
an additional
$15.00 for
UPS shipments.
To order online,
please visit our website:
www.cobra.com
Click “shop Cobra®”
WA RRANTY •C US TO ME R ASS ISTA N C E • S P E C I F I C AT I O N S
A. FREQUENCIES
CHANNEL ASSIGNMENT
CH 1: 462.5625MHz CH 8: 467.5625MHz
CH 2: 462.5875MHz CH 9: 467.5875MHz
CH 3: 462.6125MHz CH 10: 467.6125MHz
CH 4: 462.6375MHz CH 11: 467.6375MHz
CH 5: 462.6625MHz CH 12: 467.6625MHz
CH 6: 462.6875MHz CH 13: 467.6875MHz
CH 7: 462.7125MHz CH 14: 467.7125MHz
B. RECEIVER UNIT NOMINAL
1. SENSITIVITY
FOR 12 DB SINAD dBm -121
FOR CALL SIG DETECTION dBm -121
2. MAX. AUDIO OUTPUT @10% THD mW 200
3. MAX. S/N RATIO @ 1mV RF INPUT dB 50
4. SQUELCH
a) SENSITIVITY dB m -121
b) ATTACK TIME mS 150
c) CLOSING TIME mS 200
5. AUDIO FREQUENCY RESP.
@ 300 HZ dB -3
@ 2500 HZ dB -10
6. SIGNAL DISPLACEMENT BW +/-KHZ 5
7. ADJACENT CH. REJECTION dB 60
8. INTERMODULATION REJECTION dB 65
9. SPURIOUS RESPONSE REJECTION dB 55
C. TRANSMITTER UNIT NOMINAL
1. POWER mW 500
2. CARRIER FREQ. STABILITY +
_H z 500
3. MODULATION LIMITING KHz 2.5
4. CARRIER ATTACK TIME mS 30
5. AUDIO FREQUENCY RESPONSE
@ 300 HZ dB -10
@ 2500 HZ dB 4
6. AUDIO DISTORTION % 3
7. HUM NOISE dB 38
8. TRANSIENT FREQ. BEHAVIOR
a)TXON mS 30
b) TXOFF mS 5
D. POWER SUPPLY
1. BATTERY LIFE (1:1:18 RATIO) HR 24
2. BATTERY OPERATING RANGE V 4.0 - 6.0
General Specifications
Customer Assistance
After reading this owner’s manual, if you have any questions
about installing or operating your microTALK®radio, or if you
are missing any parts, please contact Cobra®first. Do not
return this product to the store. Cobra®Electronics offers the
following customer support service.
• Technical assistance is available on-line in
the Frequently Asked Questions (FAQ)
section at www.cobra.com or by e-mail
to productinfo@cobra.com.
For out of warranty service, ship prepaid this product to:
AVS Technologies Inc., 2100 TransCanada Hwy S., Montreal,
Quebec, H9P 2N4. We reserve the right to repair or replace
the unit with an equivalent product. Please include the
following information:
Date of purchase:
Model No.:
Dealer Purchased from:
Dealer address:
Dealer phone No.:
FOR PRODUCTS PURCHASED IN CANADA
Your new Cobra®FRS is covered by a two (2) year replacement
w a rr a n t y. If any manufacturing defect becomes apparent in this
p roduct within two years from the original date of purchase, it
will be replaced. Please re t u rn the FRS radio to your dealer with
original or copy of dated proof of purchase.
This warranty does not cover damages due to careless handling,
negligence, accident, abuse or failure to follow operating
i n s t r uctions. Alteration of this product or defacing of the serial
number cancels all obligations of this warr a n t y. This warr a n t y
gives you specified legal rights. Additional warranty rights may
be provided by law in some are a s .
