Cobra Electronics PR945 22 Channel FRS/ GMRS Transceiver User Manual PR945 manual
Cobra Electronics Corporation 22 Channel FRS/ GMRS Transceiver PR945 manual
users manual
FPO
Operating Instructions for Your Cobra® microTALK®
2-WAY RADIO MODEL PR 945 DX
Instrucciones operativas del
RADIO BIDIRECCIONAL
MODELO PR 945 DX
Cobra®microTALK®
Nothing comes close to a Cobra™
Nada se compara a Cobra™
English, pages 1-16
Español, páginas 17-34
PRODUCT FEATURES ENGLISH
1
PRODUCT FEATURES
ENGLISH
2
OFF
ON
Backlit LCD
Display
LOCK Button
MODE Button
ON/OFF
VOLUME
Switch
CHANNEL
SELECT
Button
Charger
Jack
Speaker/
Microphone
Belt Clip
CALL
Button
HI/LOW
(Power) Button
TALK
Button
LIGHT/MAX
RANGE
Button
Antenna
Battery
Compartment
LOCK Tab
External Speaker/
Microphone Jack
LIGHT/MAX
RANGE Button
TALK
Button
Product Features
• TWO-WAY RADIO with up to a
six (6) mile (10 km) range
• 22 CHANNELS (seven (7) shared
with FRS/GMRS, seven (7) FRS
only, eight (8) GMRS only)
• 38 CTCSS PRIVACY CODES
• Selectable HI/LOW POWER Output
(on all GMRS channels)
• UHF FM Frequencies
• BACKLIT LCD Display
• EXTERNAL SPEAKER/MICROPHONE Jack
• 10 MEMORY LOCATIONS
• FULL CHANNEL/CTCSS SCAN
• MEMORY SCAN
• SIGNAL STRENGTH Meter
• MAXIMUM RANGE Extender
• 10 CALL SIGNAL Selections
• “ROGER BEEP” Confirmation Tone
(selectable On/Off)
• KEYSTROKE TONES (selectable On/Off)
• AUTO SQUELCH
• CALL Button
• BATTERY SAVER Circuitry
• LOCK Button
• BELT CLIP
• WATER RESISTANT
Receive/Transmit
Tower Icon
CTCSS Privacy
Code Numbers
Memory
Location
Low Power
Icon
Key Lock
Icon
Keystroke
Tones Icon
Roger Beep
Icon
Memory Icon
Power Saver
Icon Battery Level Meter
Main Channel
Numbers
Signal Strength
Meter Icon
BACKLIT LCD DISPLAY
Scan Icon
Important
FCC Licensing
Information
This radio operates
on General Mobile
Radio Service (GMRS)
frequencies which
require a Federal
Communications
Commission (FCC)
license. See page 14
for licensing and
additional information.
Selecting a Channel
Channels 1-7 are shared with FRS/GMRS.
Channels 8-14 are FRS only. Channels15-22
are GMRS only. (IMPORTANT: See page
16 for FRS/GMRS frequency allocations and
compatibility chart.)
1. With the radio On,
select any of the
22 channels by
pushing the
CHANNEL SELECT button up or down.
(NOTE: Both radios must be tuned to
the same channel to communicate.)
Selecting a CTCSS Privacy Code
CTCSS (Continuous Tone Coded Squelch
System) is an advanced tone coding system
allowing you to select one of 38 privacy
codes to reduce interference from other users
on the channel. (NOTE: If you are using a
privacy code, both radios must be tuned to
the same channel and privacy code to
communicate. Each channel will remember
the last privacy code you selected.)
To select a privacy code:
1. After selecting a
main channel,
press and release
the MODE button.
A small number
will flash next to the channel in the LCD.
2. Push the CHANNEL SELECT button up
or down to select a privacy code. You
can hold the button up or down for
fast advance.
3. When your desired privacy code
is displayed, press and release the
LOCK button.
Calling Another Person
To alert another person that
you are calling:
1. Press and release the CALL button. The
other person will hear a two (2) second
ringing tone. (See page 12 on how to
select between ten (10) call tone settings.)
You cannot send or receive transmissions
during the two (2) second call tone.
CALL Button
LOCK
Button
MODE
Button
CHANNEL SELECT
Button
OPERATION OPERATION
ENGLISH
4
Batteries
To install or replace batteries:
1. Remove belt clip by releasing belt clip
latch and sliding clip down.
2. Pull down on the Battery Latch to
remove the battery compartment cover.
3. Insert four (4) AAA batteries. (Always use
high quality alkaline batteries.) Position
batteries according to
polarity markings.
4. Replace Battery
Compartment cover
and belt clip.
(NOTE: Contact your local Cobra®
dealer or Cobra®directly for optional
charger accessories.)
Turning On Your microTALK®
Radio
1. Rotate the ON-
OFF/VOLUME
switch clockwise
to turn On the
radio (and to
adjust the volume). An audible tone will
indicate the radio is On.
Your microTALK®is now in Standby mode,
ready to receive transmissions. The radio is
always in Standby mode except when the
TALK, CALL, or MODE buttons are pressed.
Battery Low
Battery power is indicated by the segments
appearing at the bottom of the LCD. As
battery power decreases, fewer segments will
be visible. When bA Lo begins to flash, the
batteries should be replaced. If you are using
rechargeable batteries, they should be recharged.
Auto Battery Save
Your microTALK®radio has a unique circuit
designed to extend battery life. If there are no
transmissions within ten (10) seconds, the
radio will automatically switch to Battery Save
mode and POWER SAVER will appear in the
display. This will not affect the radio’s ability
to receive incoming transmissions.
ENGLISH
3
ON-OFF/VOLUME
Switch
Lock Tab
Belt Clip
OPERATION
To turn Maximum Range Extender On:
1. Press and hold the LIGHT/MAX RANGE
button for at least five (5) seconds until
you hear two (2) beeps which indicates
the Maximum Range Extender is On.
To turn Maximum Range Extender Off:
1. Press and release the LIGHT/MAX RANGE
button or change channels.
Using the Lock Function
The Lock function locks the CHANNEL, MODE
and HI/LOW POWER buttons to prevent
accidental operation.
To use the
Lock function:
1. While in Standby
mode, press and
hold the LOCK
button for one (1)
second. The Lock
icon will blink
when the radio is
locked. Buttons
that are NOT
locked are the CALL, LOCK, LIGHT/MAX
RANGE, TALK buttons, and ON-
OFF/VOLUME switch which are all fully
functional while the radio is locked.
2. To “unlock” buttons, press and release
the LOCK button again. The Lock icon
disappears and all buttons will be unlocked.
External Speaker/
Microphone Jack
Your microTALK®radio can be fitted with an
external speaker/microphone, freeing your
hands for other tasks. (See page 16 for
optional accessories.)
To attach an external
speaker/microphone:
1. Open the SPKR/MIC tab on top of
the radio.
2. Insert the plug into the SPKR/MIC jack.
(CAUTION: Do not use an external
speaker/microphone with common
ground circuits with this radio. Damage
can result. We recommend using only
Cobra®authorized accessories.)
Using the
MODE Button
The MODE button
allows you to use
and program the
various functions of your microTALK®radio.
If you press and hold the MODE button, the
LCD will cycle through the different functions.
OPERATION
ENGLISH
6
Talking to Another Person
1. Press and hold
the TALK button.
2. With the microphone
about two (2)
inches (5 cm) from
your mouth, speak
in a normal voice.
3. Release the button
when you’re
finished talking
and listen for a
response. You cannot receive incoming
calls while pressing the TALK button.
“Roger Beep” Confirmation Tone
Your listener will hear an audible tone when
you release the TALK button. This alerts the
other party that you are finished talking and
it is OK for them to speak. (NOTE: The Roger
Beep can be turned Off and On, see page 10.)
Listening for a Response
When you are finished talking:
1. Release the TALK button to receive incoming
transmissions. Your
microTALK®is
always in listening
mode while the
TALK button is
not pressed.
2. Adjust the volume by rotating the
ON-OFF/VOLUME switch.
Illuminating the Display
1. Press and release the LIGHT/MAX RANGE
button to illuminate the display for
ten (10) seconds.
Auto Squelch/Maximum Range
Your microTALK®radio is equipped with
Auto Squelch, which automatically shuts
Off weak transmissions and unwanted noise
due to terrain, conditions, or if you’ve
reached your maximum range limit.
You can temporarily turn Off Auto Squelch or
turn On Maximum Range Extender, allowing
all signals to be received and extending the
maximum range of your radio.
To temporarily turn Off Auto Squelch:
1. Press the
LIGHT/MAX RANGE
button less than
five (5) seconds.
If you hear two (2)
beeps, you have turned the Maximum Range
Extender On (see page 6).
ENGLISH
5
External Microphone
Speaker
Speaker/Microphone
Jack
LIGHT/MAX
RANGE Button
2 inches away
TALK Button
ON/OFF
VOLUME
Switch
LIGHT/MAX RANGE
Button
MODE
Button
LOCK Button
OPERATION•ADVANCED FEATURES OPERATION
ENGLISH
8
Programming Memory Locations
Your microTALK®radio has ten (10) memory
locations (0-9) for storing your most
frequently used channels and privacy codes.
To program locations:
1. Push the MODE
button until the
Memory icon and
the memory
location flashes.
2. Select the memory
location you wish
to change by
pushing the
CHANNEL SELECT
button up or down.
3. Press and release
the MODE button
again. The Memory
icon and the main
channel number
will flash.
4. Select the main channel you wish to
store by pushing the CHANNEL SELECT
button up or down.
5. Press the MODE
button again to store
the main channel in
memory andmove
to privacy code
selection. The privacy code number begins
flashing and the Memory icon continues to
flash.
6. Select the privacy code (00-38) you wish
to store by pushing the CHANNEL SELECT
button up or down.
7. Press the LOCK
button to program
your selection.
You may also press
the TALK button to
transmit your
selected channel and privacy code, which will
be stored into the memory location you are
using. (NOTE: To “unprogram” a memory
location you programmed previously, select
00 for both the main channel and privacy
code in steps 4 through 6.)
8. Press and release
the LOCK button to
return to Standby
mode at your new
memory location,
or press and release
the MODE button to save the memory
location and proceed to other functions.
ENGLISH
7
MODE
Button
CHANNEL
SELECT
Button TALK Button
Recalling Memory Locations
To recall a channel you have
stored in a memory location:
1. Press the MODE
button until the
Memory icon
and a memory
location flashes.
2. Select your desired
memory location
by pushing the
CHANNEL SELECT
button up or down.
Your radio will stay
at this memory location until you exit
Memory Function mode by pressing the
LOCK button.
3. Repeat steps 1 and 2 to recall other
memory locations.
Using the Scan Function
Your microTALK®radio can automatically scan
main channels (1-22), the privacy codes (00-
38) within one main channel, or memory
locations.
To scan main
channels:
1. Press the MODE
button until the
Scan icon and main
channel number flashes.
2. Push the CHANNEL SELECT button up or
down and the radio will begin scanning
the main channels. (NOTE: The radio
“ignores” privacy codes while scanning
main channels.)
3. The radio will continue to scan all
main channels and stop if an incoming
transmission is detected. The radio will
remain on that channel for ten (10)
seconds. During that time you can:
a) Press and hold
the TALK button
and talk. The
radio will
remain on that
channel and
return to Standby mode.
b) Push the CHANNEL SELECT button
up or down to resume scanning
main channels.
c) Press the MODE button to proceed to
privacy code scanning (see following page).
If you do not press any button within ten
(10) seconds, the radio will automatically
resume scanning main channels.
TALK Button
LOCK
Button
MODE
Button
LOCK Button
MODE
Button
OPERATION
ENGLISH
OPERATION
Using the Scan Function (continued)
To scan privacy codes:
1. While in Standby mode, press the
CHANNEL SELECT button up or down to
choose the main channel you wish to scan.
2. Press the MODE
button until the
Scan icon and the
privacy code
number flashes.
3. Push the CHANNEL SELECT button up or
down and the radio will begin scanning
privacy codes within the main channel you
selected.
4. The radio will continue to scan privacy codes
and stop if an incoming transmission is
detected. The radio will remain on that code
for ten (10) seconds. During that time you can:
a) Press and hold the TALK button and
talk. The radio will remain on that
channel and privacy code, then return
to Standby mode.
b) Push the CHANNEL SELECT button up or
down to resume scanning privacy codes.
c) Press the MODE button to proceed to
memory location scanning (see below).
If you do not press any button within ten
(10) seconds, the radio will automatically
resume scanning privacy codes.
To scan memory locations:
1. Press the MODE button until the Scan
icon, Memory Location icon and memory
location number flashes.
2. Push the CHANNEL SELECT button up or
down and the radio will begin scanning
memory locations.
3. The radio will continue to scan all memory
locations and stop if an incoming
transmission is detected. The radio will
remain on that location for ten (10)
seconds. During that time you can:
a) Press and hold
the TALK button
and talk. The
radio will
remain on
that memory location channel and return
to Standby mode.
10
ENGLISH
9
MODE
Button
TALK Button
b) Push the CHANNEL SELECT button
up or down to resume scanning
memory locations.
c) Press the MODE button to proceed
to other functions.
If you do not press any button within ten
(10) seconds, the radio will automatically
resume scanning memory locations.
You must have at least two (2) memory
locations programmed in order to scan
memory locations.
(NOTE: If you want to reduce the number
of memory locations being scanned you need
to ”unprogram“ all unwanted locations by
changing both the main channel and privacy
code to 00. See Programming Memory
Locations, page 8.)
“Roger Beep” Confirmation Tone
Your listener will hear an audible tone when
you release the TALK button. This alerts the
other party that you are finished talking and
it is OK for them to speak. This feature can
be turned On or Off.
To turn “Roger Beep” On or Off:
When turning On your microTALK®radio for
the first time, “Roger Beep” will be On.
1. Press the MODE button until the “Roger
Beep’’ icon flashes on the LCD. The current
On or Off setting is displayed.
2. Press the CHANNEL
UP or CHANNEL
DOWN button to
select “Roger
Beep” On or Off.
3. a) Press the MODE button to enter
the new setting and proceed to
other functions.
b) Press the LOCK button to enter the new
setting and return to Standby mode.
c) Do not press any buttons for
15 seconds to enter the new setting
and return to STANDBY MODE.
The setting you select will be saved
when you turn your radio Off and On again.
When the “Roger Beep” is On, the “Roger
Beep” icon will be displayed.
CHANNEL SELECT
Button
MODE
Button
CHANNEL
SELECT
Button
High/Low Power
When in close proximity to another party,
or during favorable conditions, you can switch
from High to Low Power to extend battery life.
(NOTE: This feature applies to GMRS channels
1 through 7 and 15 through 22 only. Channels
8 through 14 operate exclusively on low power.)
To switch from high to low power:
1. Press and release the HI/LOW button.
When in low power, and when using
channels 8 through 14, the LOW icon
will be visible in the LCD display.
Signal Strength Meter
Your microTALK®radio is equipped with a signal
strength meter that shows the strength of your
incoming or outgoing transmissions. The ascending
bars next to the signal strength indicate the
strength of the signal. The greater the number
of bars visible, the stronger the signal. The fewer
number of bars visible, the weaker the signal.
microTALK®Range
Your microTALK®radio has a range of up to
six (6) miles (10 km) when using GMRS
channels on HI power. In LOW power and on
channels 8 through 14, your radio’s range is up
to two (2) miles (3 km). Your range will vary
depending on terrain and conditions. In flat,
open country your radio will operate at
maximum range.
Buildings and foliage in the path of the signal
can reduce the range.
Dense foliage and hilly terrain will further
reduce the signal.
Remember, you can achieve maximum
range by using Maximum Range Extender.
See page 5 for details.
HI/LOW Button
SIGNAL STRENGTH Meter
OPERATION ENGLISH OPERATION
ENGLISH
1211
Keystroke Tones
With Keystroke Tones turned On, your radio
will sound beeps each time you press a
button or change a setting.
To change Keystroke Tones:
1. Press the MODE button until the Keystroke
Tones icon flashes on the LCD. The current
On or Off setting is displayed.
2. Press the
CHANNEL UP or
CHANNEL DOWN
button to turn
Keystroke Tones
On or Off.
3. a) Press the MODE button to enter
the new setting and proceed to
other functions.
b) Press the LOCK button to enter the new
setting and return to STANDBY MODE.
c) Do not press any buttons for fifteen
(15) seconds to enter the new setting
and return to STANDBY MODE.
10 Call Tone Settings
You can choose between ten (10) different call
tone settings to transmit a unique call alert.
To change a Call Tone Setting:
1. Press the MODE button until the letter
“C” and the current call tone number
(1 through 10) is displayed. The current
call tone will sound for one (1) second.
2. Press the CHANNEL
UP or CHANNEL
DOWN button to
hear the other call
tone settings.
3. a) Press the MODE button to enter the new
setting and proceed to other functions.
b) Press the LOCK button to enter the new
setting and return to STANDBY MODE.
c) Do not press any buttons for fifteen
(15) seconds to enter the new setting
and return to STANDBY MODE.
MODE
Button
CHANNEL
SELECT
Button
MODE
Button
CHANNEL
SELECT
Button
FCC INFORMATION
14
SPECIFICATIONS ENGLISH
13
B. RECEIVER
RADIO NOMINAL
1. SENSITIVITY
FOR 12 DB SINAD dBm -121
FOR CALL SIG DETECTION dBm -121
2. MAX. AUDIO OUTPUT @10% THD mW 200
3. MAX. S/N RATIO @ 1mV RF INPUT dB 50
4. SQUELCH
a) SENSITIVITY dB m -121
b) ATTACK TIME mS 150
c) CLOSING TIME mS 200
5. AUDIO FREQUENCY RESP.
@ 300 HZ dB -3
@ 2500 HZ dB -10
6. SIGNAL DISPLACEMENT BW +/-KHZ 5
7. ADJACENT CH. REJECTION dB 60
8. INTERMODULATION REJECTION dB 65
9. SPURIOUS RESPONSE REJECTION dB 55
C. TRANSMITTER
RADIO NOMINAL
1. POWER
Hi (GMRS only) W 2
Low (GMRS /FRS) mW 500
2. CARRIER FREQ. STABILITY +
_Hz 500
3. MODULATION LIMITING KHz 2.5
4. CARRIER ATTACK TIME mS 30
5. AUDIO FREQUENCY RESPONSE
@ 300 HZ dB -10
@ 2500 HZ dB 4
6. AUDIO DISTORTION % 3
7. HUM NOISE dB 38
8. TRANSIENT FREQ. BEHAVIOR
a) TX ON mS 30
b) TX OFF mS 5
D. POWER SUPPLY
1. BATTERY LIFE (1:1:18 RATIO) HR 24
2. BATTERY OPERATING RANGE V 4.0 - 6.0
General Specifications
ENGLISH
IMPORTANT NOTICE: FCC LICENSE REQUIRED
This two-way radio operates on GMRS (General Mobile
Radio Service) frequencies which require an FCC (Federal
Communications Commission) license. A user must be
licensed prior to operating on channels 1 through 7 or 15
through 22, which comprise the GMRS channels of this
radio. Serious penalties could result for unlicensed use of
GMRS channels, in violation of FCC rules, as stipulated in
the Communications Act’s Sections 501 and 502 (amended).
Licensed users will be issued a call sign by the FCC, which
should be used for station identification when operating this
radio. GMRS users should also cooperate by engaging in
permissible transmissions only, avoiding channel interference
with other GMRS users, and being prudent with the length
of their transmission time.
For licensing information and application forms, please call
the FCC Hotline at 800-418-FORM. Request form #159
and form #605. Questions regarding the license application
should be directed to the FCC at 888-CALL-FCC. Additional
information is available on the FCC’s website at www.fcc.gov.
Safety Information for microTALK®Radios
Your wireless handheld portable transceiver contains a low
power transmitter. When the Talk button is pushed, it sends
out radio frequency (RF) signals. The device is authorized
to operate at a duty factor not to exceed 50%. In August
1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for
handheld wireless devices.
Important:
To maintain compliance with the FCC’s RF guidelines, hold
the transmitter at least 2 inches (5 centimeters) from your
face and speak in a normal voice, with the antenna pointed
up and away. If you wear the handset on your body while
using the headset accessory, use only the Cobra®supplied
belt clip for this product and ensure that the antenna is
at least 1 inch (2.5 centimeters) from your body while
transmitting. If the distance between the antenna and
the body is LESS THAN 1.0 inch (2.5 cm), DO NOT USE
THIS DEVICE IN THE BODY WORN CONFIGURATION. Use only
the supplied antenna. Unauthorized antennas, modifications,
or attachments could damage the transmitter and may
violate FCC regulations.
Normal Position:
Hold the transmitter approximately 2 inches (5 cm) from
your face and speak in a normal voice, with the antenna
pointed up and away.
Note:
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Warnings:
Replacement or substitution of transistors, regular diodes
or other parts of a unique nature, with parts other than
those recommended by Cobra®may cause a violation of
the technical regulations of part 95 of the FCC Rules,
or violation of type acceptance requirements of part 2
of the Rules.
A. FRS/GMRS FREQUENCY ALLOCATION AND COMPATIBILITY
Important: Please note that Cobra®GMRS models with 15
channels may designate different channel numbers for the same
frequency. For example, a Cobra®15 channel GMRS model would
need to be tuned to channel 11 in order to communicate with a
22 channel GMRS tuned to channel 15. Please refer to the chart
below for channel/ frequency number compatibility.
A = Channel No. For 22 Channel GMRS Models
B = Channel No. For 15 Channel GMRS Models
C = Type of Radio Service
D = Frequency in MHz
E = Power in Watts
a = 2.0/0.5 (selectable)
b = 0.5
AB CD E
1 1 FRS/GMRS 462,5625 a
2 2 FRS/GMRS 462,5875 a
3 3 FRS/GMRS 462,6125 a
4 4 FRS/GMRS 462,6375 a
5 5 FRS/GMRS 462,6625 a
6 6 FRS/GMRS 462,6875 a
7 7 FRS/GMRS 462,7125 a
8 FRS 467,5625 b
9 FRS 467,5875 b
10 FRS 467,6125 b
11 FRS 467,6375 b
12 FRS 467,6625 b
13 FRS 467,6875 b
14 FRS 467,7125 b
15 11 GMRS 462,5500 a
16 8 GMRS 462,5750 a
17 12 GMRS 462,6000 a
18 9 GMRS 462,6250 a
19 13 GMRS 462,6500 a
20 10 GMRS 462,6750 a
21 14 GMRS 462,7000 a
22 15 GMRS 462,7250 a
15
ORDER FORM
16
CUSTOMER ASSISTANCE • WARRANTY
CUSTOMER ASSISTANCE
After reading this owner’s manual, if you have any questions
about installing or operating your microTALK®radio, or if you
are missing any parts, please contact Cobra®first. Do not return
this product to the store. Cobra®Electronics offers the following
customer support services.
For Assistance In the U.S.A.
In this user’s manual, you should find all the information you
need to operate your microTALK®radio. If you require further
assistance after reading this manual, Cobra®Electronics offers
the following customer assistance services:
Automated Help Desk
English only. 24 hours a day, 7 days a week
773-889-3087 (phone).
Customer Assistance Operators
English and Spanish. 8:00 a.m. to 6:00 p.m. CT, Monday
through Friday (except holidays) 773-889-3087 (phone).
Questions
English and Spanish. Faxes can be received at 773-622-2269 (fax).
Technical Assistance
English only. www.cobra.com (on-line: Frequently Asked Questions).
English and Spanish. productinfo@cobra.com (e-mail).
For Assistance Outside the U.S.A.
Contact Your Local Dealer
If your product should require factory service please
call Cobra®first before sending your radio in. This will
ensure the fastest turn-around time on your repair.
You may be asked to send your radio to the Cobra®factory.
It will be necessary to furnish the following in order to have
the product serviced and returned.
1) For Warranty Repair include some form of proof-of-purchase,
such as a mechanical reproduction or carbon of a sales receipt. If you
send the original receipt it cannot be returned. 2) Send the entire
product. 3) Enclose a description of what is happening with the
radio. Include a typed or clearly printed name and address of where
the radio is to be returned. 4) Pack radio securely to prevent
damage in transit. If possible, use the original packing material.
5) Ship prepaid and insured by way of a traceable carrier such
as United Parcel Service (UPS) or First Class Mail to avoid
loss in transit to: Cobra®Factory Service, Cobra®Electronics
Corporation, 6500 West Cortland Street, Chicago, IL 60707
USA. 6) If the radio is in warranty, upon receipt of your radio it
will either be repaired or exchanged depending on the model.
Please allow approximately 3-4 weeks before contacting us for
status. If the radio is out of warranty, a letter will automatically
be sent informing you of the repair charge or replacement
charge. If you have any questions, please call 773-889-3087
for assistance.
FOR PRODUCTS PURCHASED IN U.S.A.
Cobra®Electronics Corporation warrants that its Cobra®PR
Radios, and the component parts thereof, will be free of defects
in workmanship and materials for period of one (1) year from
the date of first consumer purchase. This warranty may be
enforced by the first consumer purchaser, provided that the
product is utilized within the U.S.A.
Cobra®will, without charge, repair or replace, at its option,
defective PR radios, products or component parts upon delivery
to the Cobra®Factory Service Department, accompanied by
proof of the date of first consumer purchase, such as a duplicated
copy of a sales receipt.
You must pay any initial shipping charges required to ship the
product for warranty service, but the return charges will be
at Cobra's expense, if the product is repaired or replaced
under warranty.
This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Exclusions: This limited warranty does not apply 1) to any product
damaged by accident; 2) in the event of misuse or abuse of the
product or as a result of unauthorized alterations or repairs; 3) if the
serial number has been altered, defaced or removed; 4) if the owner
of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability
and fitness for a particular purpose are limited in duration to
the length of this warranty. Cobra®shall not be liable for any
incidental, consequential or other damages; including, without
limitation, damages resulting from loss of use or cost of installation.
Some states do not allow limitations on how long an implied
warranty lasts and/or do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitations
may not apply to you.
Name
Address (No P.O. Boxes)
City State/Province Zip Country
Telephone
Credit Card Number Type: ❒Visa ❒Mastercard ❒Discover Exp. Date
Customer Signature
Optional Accessories
You can find accessories at your local Cobra®dealer, or in the U.S.A. you can order directly from Cobra.
®
Ordering From U.S.
Call 773-889-3087 for pricing or visit www.cobra.com.
For credit card orders,complete and return this order form to fax number 773-622-2269.
Or call 773-889-3087 (Press 1 from the main menu) 8:00 a.m. to 6:00 p.m. CT, Monday through Friday.
Make check or money order payable to:
Cobra®Electronics, Attn: Accessories Dept.
6500 West Cortland Street, Chicago, IL 60707 USA
To order online,please visit our website: www.cobra.com
AmountShipping/Handling*
$10.00 or less . . . . . . . . . . . $3.00
$10.01-$25.00 . . . . . . . . . . $5.50
$25.01-$50.00 . . . . . . . . . . $7.50
$50.01-$90.00 . . . . . . . . . $10.50
$90.01-$130.00 . . . . . . . . $13.50
$130.01-$200.00 . . . . . . . $16.50
$200.01 plus . . . . . . . . . . . 10% of
purchase
Tax Table
Ohio, Wisconsin add 5%
Indiana, Michigan add 6%
Illinois add 8.75%
*For AK, HI and PR add additional $26.95 for FedEx Next Day or
$10.95 for FedEx 2nd Day. Excludes weekends and holidays shipments.
Please allow 2-3 weeks for delivery in the U.S. Prices subject to
change without notice.
Item # U.S. Cost Each Qty Amount
U.S. Subtotal
(Tax if Applicable)
Shipping/Handling
Total
