Important Information and
Customer Assistance
Introduction
Important Information •
Federal Laws Governing the Use of Radar Detectors
It is not against federal law to receive radar transmissions with your Cobra®radar/laser
detector. The Communications Act of 1924 guarantees your right to receive radio
transmissions on any frequency. Local laws that contravene this Act, while illegal, may
be enforced by your local law enforcement officials until and unless they are prohibited
from doing so by federal court action.
Safety/Strobe Alert
Use of this product is not intended to, and does not, ensure that motorists or
passengers will not be involved in traffic accidents. It is only intended to alert the
motorist that an emergency vehicle equipped with a Cobra Safety Alert, 3M or Tomar
strobe transmitter is within range as defined by that product. Please call local fire and
police departments to learn if coverage exists in your area.
Some states and municipalities prohibit mounting any object on your windshield. If you
drive in these states or areas; you can mount the MDU on the dash.
Safe Driving
Motorists are expected to exercise all due caution while using this product, and to obey
all applicable traffic laws.
Security of Your Vehicle
Before leaving your vehicle, always remember to conceal your Remote Display Unit
(RDU) in order to reduce the possibility of break-in and theft. Your Main Detector Unit
(MDU) has a two-position bracket that, when in the up position, presents a very discreet
profile from outside the vehicle.
Customer Assistance •
Use your owner’s manual to learn about product features. Cobra Electronics offers the
following customer assistance services:
For Assistance in the U.S.A.
Automated Help Desk, English only. 24 hours a day, 7 days a week 773-889-3087.
Customer Assistance Operators, English and Spanish, 8:00 am to 6:00 p.m. Central
Time Mon. through Fri. (except holidays) 773-889-3087.
Questions, English and Spanish, Fax: 773-622-2269.
Technical Assistance, English only, www.cobra.com.
English and Spanish e-mail, Product info@cobra.com.
For Assistance Outside the U.S.A. Contact Your Local Dealer
©2007 Cobra Electronics Corporation™
6500 West Cortland Street
Chicago, Illinois 60707 USA
www.cobra.com
Customer Assistance
A1 English
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page A1
FOURTH DRAFT
THIS
SURFACE
TOWARDS
SKY
Controls, Indicators
and Connections
Introduction
A2 English
IntelliLink™Remote Display Unit (RDU)
Full-Color
Extreme Bright
DataGrafix™
Display
Global Positioning System Locator
(GPSL)
USB Connector 12-Volt Power Connector
MDU Connector
Power &
Pairing
Button
Two-Piece,
Self-Adhesive
Fasteners
Main Detector Unit (MDU)
Speaker
Optional GPSL for Model XRS R7 and Standard on Model XRS R9G
GPSL Cable
The XRS R7 provides detection capabilities for radar, laser and strobe signals.
The XRS R9G has all the features of the XRS R7 plus a GPSL module with
alerts when approaching photo-enforced intersections and roads with fixed
red light/speed cameras. The XRS R9G can store up to 1,000 additional user
programmable Location Alerts.
GPSL
Connector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page A2
FOURTH DRAFT
Introduction
Nothing Comes Close to a Cobra®A3
In This Package
12-Foot Power Cord - Fuse Box 12-Foot Power Cord - Accessory Plug
In This Package •
USB/USB Mini Retractable Cable
RDU Holster and Vent/Visor Clips GPSL Cable (R9G Only)
12V-5V USB Power Adapter
MDU Power Cord Clips
20 clips and 20 adhesive squares
Two Hoop Loop Strips for Mounting
Holster
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page A3
FOURTH DRAFT
Contents
Introduction
Nothing Comes Close to a Cobra®1
Introduction
Important Information . . . . . . . . . .A1
Customer Assistance . . . . . . . . . . .A1
Controls, Indicators and
Connections . . . . . . . . . . . . . . . .A2
In This Package . . . . . . . . . . . . . . .A3
Product Overview . . . . . . . . . . . . . . .2
Installation Overview . . . . . . . . . . . .4
Your Detector
Installation . . . . . . . . . . . . . . . . . . . .6
Controls and Display . . . . . . . . . . .15
Getting Started . . . . . . . . . . . . . . . .17
EasySet Programming . . . . . . . . . .21
Program Navigation . . . . . . . . . . . .22
Settings . . . . . . . . . . . . . . . . . . . . .24
Detection Alerts . . . . . . . . . . . . . . .29
Radar and Laser . . . . . . . . . . . . . . .32
Maintenance . . . . . . . . . . . . . . . . . .35
Specifications . . . . . . . . . . . . . . . . .36
Warranty
Warranty . . . . . . . . . . . . . . . . . . . . .37
User License
User License . . . . . . . . . . . . . . . . . .39
Customer Assistance
Product Service . . . . . . . . . . . . . . .41
Trademark Acknowledgement . . . .42
Optional Accessories . . . . . . . . . . .43
Accessories Order Info . . . . . . . . . .44
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page 1
FOURTH DRAFT
Introduction
2English
Product Overview
WARNING
Modifications or parts not approved by Cobra Electronics Corporation
may violate FCC Rules and void authority to operate this equipment.
Cobra XRS R7 and XRS R9G •
Read and understand the information in the Installation Overview and
Installation sections of this manual for best operation.
The XRS R7 consists of a Main Detector Unit (MDU) and a wireless Remote
Display Unit (RDU). The XRS R9G adds a Global Positioning System Locator
(GPSL) module, providing fixed red light/speed camera location-based alerts.
The XRS R7 can be upgraded with a Cobra GPSL and updated GPSL
databases and features purchased later.
Main Detector Unit (MDU)
The MDU is equipped with an adjustable, two-position bracket for detection
operation in the down (horizontal) position or in the up position for a less
visible profile from the outside. The MDU issues audible messages during
power-on and self-testing. The MDU is also equipped with an alternate power
button used to power the unit or as a pairing switch, if the RDU is lost or
broken and needs to be replaced.
The MDU contains detection function sensors so proper mounting and
orientation are important.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page 2
FOURTH DRAFT
Product Overview
Introduction
Nothing Comes Close to a Cobra®3
Remote Display Unit (RDU)
The RDU is a wireless remote controller/display module that shows alerts
detected by the MDU. The RDU display uses an Extreme Bright DataGrafix™
(Organic Light Emitting Diode) Display to show large graphical alerts as
signals are detected.
The RDU uses a rechargeable lithium-ion (LiON) battery and is supplied with
a holster and clips for mounting on heating/air conditioner vents or visor.
Power cables and other adapters are supplied for charging this battery using
the vehicle 12V vehicle power with accessory adaptor plug or via a PC USB
port.
The normal Auto Dark screen is dark with a moving dot. The Auto Dark
screen provides discreet usage and helps conserve RDU battery life. The
display color can be changed to match most dash illumination.
Global Positioning System Locator (GPSL) -
(XRS R9G Only)
The GPSL module tracks vehicle location. It uses a database that alerts as it
approaches photo-enforced intersections and roads with fixed red light/speed
cameras.
Use the GPSL functions to program alerts and store up to 1,000 user
programmable Location Alerts. Software will be available to update the
database and stay current with future hazards and warning locations. The
GPSL module has no external controls and connects to the MDU with one
cable.
Registering Your Detector
To register Cobra XRS R7 or XRS R9G go to www.cobra.com. Click on the
Product Registration tab.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page 3
FOURTH DRAFT
4English
Installation Overview
Mount Unit
Main Detector Unit (MDU)
Note: To power the MDU, use one of the two power cords provided
(See Page A3).
•12-Foot Power Cord – Acessory Plug: For connecton to 12-volt
vehicle accessory outlet, or
•12-Foot Power Cord – Fuse Box: For connection to vehicle’s fuse
box using the in-line fuse and wires.
Fuse box hard wiring is recommended. Use this configuration to
provide a more discreet installation. If you are unsure about making
this connection yourself, contact a professional installer.
On a negative grounded vehicle:
1. Connect the positive wire [marked with a tag (+)] of the DC power cord
to an accessory 12-volt fuse that is controlled by the ignition switch
(Figure A).
2. Connect negitive wire (-) to a chassis ground location (Figure A). Body
paint may may need to be removed to assure a good ground
connection.
Introduction
ACC
Figure A
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page 4
FOURTH DRAFT
Installation Overview
Nothing Comes Close to a Cobra®5
Mount MDU high on windshield to right of rear view mirror (Figure B). MDU
must have clear view through windshield and parallel to the road (Figure C)
and have clearance to snap into the “up” position.
Position MDU for easy access to power switch, cable connections and for
mirror movement. Mount the MDU on the windshield close to the headliner.
IMPORTANT: Do not block the MDU lens with the sun-shaded area of the
windshield (Figure D) or the rear view mirror.
Dash mounting results in decreased performance. Heated windshields
currently available on some vehicles (Instaclear for Ford, Electriclear for GM),
may block or weaken incoming signals. Consult your automobile
manufacturer.
Introduction
Figure B Figure C
THIS
SURFACE
TOWARDS
SKY
Figure D
External View
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page 5
FOURTH DRAFT
Installation
Your Detector
6English
Global Positioning System Locator (GPSL) - (XRS R9G Model Only)
Mount GPSL module close enough to the MDU for supplied cable to connect
both modules (Figure E). Mount GPSL with proper side (“This Surface
Toward Sky” wording embossed in unit case) attached to windshield and
exposed to the sky.
IMPORTANT: Some states and municipalities prohibit mounting any object on
the windshield. If you drive in these states or areas, mount the MDU on the
dash (Figure F).
IMPORTANT: Both the MDU and GPSL units will need to be flipped
upside-down compared to a dashboard installation. Pay special attention to
mount GPSL unit with proper side (“This Surface Toward Sky” wording
embossed in unit case) towards the sky.
Figure E
Internal View
Figure F
Internal View
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page 6
FOURTH DRAFT
Installation
Your Detector
Nothing Comes Close to a Cobra®7
1. Position MDU before actual
mount.
• Do not attempt to adjust
MDU bracket.
• Hold unit in place.
• Using non-permanent
pen, mark two opposite
corners.
2. Peel off film from two-piece
fastener strips. Align with
two corner markings made
in step 1. Press MDU
bracket against windshield.
• Fastener strips cannot
easily be removed.
Strength of adhesive
strips increases with
time.
• Do not pull on MDU for
first 20 minutes.
Main Detector Unit (MDU)
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 7
FOURTH DRAFT
Installation
8English
3. Loosen MDU (gray) bracket
adjust knob. Adjust module
to a position parallel to the
road. Tighten knob to set
proper detection position.
The MDU mounting bracket
has two detent positions:
• one for detection
operation (horizontal
position)
• one for storage or
concealment (up
position). Makes MDU
less visible from outside.
IMPORTANT:
MDU
will not provide radar
detection in
“Stored/Concealed”
position.
Your Detector
Not In Use.
Stored/Concealed
Position.
Detection
Position
Lower to
Operating
Detection
Position.
Bracket
Adjust Knob
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 8
FOURTH DRAFT
4. Attach power cord to MDU.
Use power cord clips to
route to fuse box or
lighter/accessory outlet,
depending on the selected
power cord. Surfaces must
be clean and free of dirt,
oil and dust. Plug in the
power cord.
Nothing Comes Close to a Cobra®9
Installation
Your Detector
Internal View
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 9
FOURTH DRAFT
10 English
Installation
Your Detector
Battery Charging
The unit is shipped with a sealed lithium-ion (LiON) batery pack that is
rechargeable.
IMPORTANT: Avoid temperature extremes (hot and/or cold) to help prolong
battery life and performance. DO NOT leave RDU exposed to direct sunlight. If
the RDU is mounted on vent, clip must be on lower fin to avoid hot air
blowing on RDU battery compartment.
NOTE: When battery begins to discharge too quickly, it is time to
install a new battery.
1. Turn RDU over and slide
battery cover off of RDU
body.
2. Carefully plug battery wire
connector into the battery
connection port in RDU.
Connector only fits one way.
3. Replace battery cover.
Remote Display Unit (RDU) •
Battery Installation
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 10
FOURTH DRAFT
Nothing Comes Close to a Cobra®11
Installation
Your Detector
1. Attach 12-volt – 5-volt
retractable USB power
cable to bottom of RDU
and to
12-volt power adapter.
2. Connect 12-volt power
adapter to vehicle
accessory outlet.
3. Initial charge for battery is
two (2) hours.
WARNING
This lithium-ion (LiON) battery should only be recharged inside the
RDU. Do not substitute any other type of charging adapter or charging
base to charge the battery. Battery damage, fire or explosion may result.
NOTE: Lithium-ion (LiON) batteries are toxic. Please dispose of properly.
Some municipal waste disposal agencies have special provisions for
battery disposal.
NOTE: After battery is fully charged, unit can be operated without
retractable power cord until battery needs recharging.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 11
FOURTH DRAFT
12 English
Installation
Your Detector
RDU Holster
A holster is provided to allow you to position the RDU for best driver
visibility, access and while charging battery. A vent or visor clip will attach to
rear of holster for easy removable mounting locations. Two self adhesive
hook loop strips are also included for more permanent mounting most
anywhere on the vehicle dashboard.
Visor Clip
Vent Clip
Hook Loop Strips
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 12
FOURTH DRAFT
Nothing Comes Close to a Cobra®13
1. Position GPSL before actual
mount.
• Hold GPSL unit in place
with USB cable
connected to MDU.
• Using non-permanent
pen, mark two opposite
corners.
2. Peel off film from two-piece
fastener strips. Align with
two corner markings made
in step 1. Press GPSL
bracket against windshield.
• Fastener strips cannot
easily be removed.
Strength of adhesive
strips increases with
time.
• Do not pull on GPSL for
first 20 minutes.
THIS
SURFACE
TOWARDS
SKY
3. Connect cable between
MDU and GPSL.
IMPORTANT: Proper side of
GPSL module (“This Surface
Toward Sky” wording
embossed in unit case) must
be against windshield and face
sky.
Global Positioning System Locator (GPSL)
(XRS Model R9G Only) •
Installation
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:42 PM Page 13
FOURTH DRAFT
Introduction
14 English
Installation
GPSL Initial Satellite Lock •
The GPSL module now needs to be linked to a satellite.
NOTE: This procedure may need to be repeated if the unit has not been
used after prolonged non-usage.
1. With vehicle running and
parked in an area clear of
obstructions to the sky, turn
On radar detector.
2. Keep the unit turned on for
at least 15 minutes. This
will allow fast satellite
acquistion in subsequent
power-ups GPSL Icon
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:42 PM Page 14
FOURTH DRAFT
Nothing Comes Close to a Cobra®15
Controls and Display
DIM/Button
Press for display
brightness.
Navigates Program
Screens.
Adjusts volume in
Menu mode.
Adjusts volume DOWN
in Volume mode.
MUTE/Button
Press for Standby
Status Screens.
Mutes an alert.
CITY/Button
Toggle between
Highway and City
modes.
Navigates Menu
Screens.
Adjusts volume UP in
Volume mode.
MENU/SAVE Button
Press to enter Menu
screen.
POWER/VOLUME Button
A two second press and
release turns unit on or off.
Release for Standby Screen
or Volume Screen.
A momentary press for
Volume screen.
RDU Controls
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 15
FOURTH DRAFT
16 English
Controls and Display
The RDU link
indicators show the
the MDU is connected
to the RDU by the
wireless link.
The indicator changes
to show a lost
connection.
The IntelliMute
symbol shows
activated feature.
Changes to indicate
if above or below
Set-point when
IntelliMute is
turned on.
(Refer to page 24.)
RDU Display
Standby Screen
When arrow displays,
you can go to the
Standby Control
screens by pushing
MUTE/ button.
RDU battery icon
displays charge
condition of RDU
battery. Sections change
to display battery level.
City/Highway symbol
changes to indicate
activated alert filtering
mode.
GPSL icon indicates
GPS satellite lock.
Icon changes to
indicate lost signal
condition.*
Compass indicator uses
GPSL to indicate direction
traveling. Indicator changes
with vehicle direction.*
*Note: Compass and GPSL icons only display if GPSL module is
connected (optional for XRS R7, standard on XRS R9G).
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 16
FOURTH DRAFT
Nothing Comes Close to a Cobra®17
Getting Started
Power On/Off •
1. Press power button
on RDU.
2. Unit cycles through power
on/self test. Displays
Standby screen when
process completed.
3. Display changes to Auto
Dark operating screen after
30 seconds (factory
default). Can be changed to
“Always On,” but will
reduce battery On time.
4. Press, hold power button
on RDU for more than two
seconds to turn off unit.
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 17
FOURTH DRAFT
18 English
Getting Started
Press Mute/while the Standby screen displays to show Standby screen
menus.
Standby Screen
Standby screen displays information about detector: alert
filtering, automatic muting functions and RDU battery
status. If GPSL is connected, compass heading and GPS
status icon also display.
RDU Battery
RDU Battery screen displays status of RDU battery.
Indicates charge left in battery or if it is plugged into
power source and is charging.
I-Mute/City or Hwy Mode
I-Mute screen displays status of alert filtering (City or
Highway modes) and automatic muting (IntelliMute)
functions. Refer to related sections to set these features.
Car Voltage
Car Voltage screen displays voltage level of car battery. If
battery voltage drops below 11.9 volts, an alert sounds.
Low Car Voltage feature in Alert Settings programming
must be activated.
Standby Screen Menus •
I-MUTE CITY
These screens display in this order when navigating Standby screen.
Standby
Screen
RDU
Battery
I-Mute
City/Hwy Mode
Car
Voltage
Lat/Lon Speed Compass
Compass, Speed and Latitude/Longitude screens
only display if GPSL is connected to system.
NOTE: Last Standby screen viewed will be one displayed when exiting
Auto Dark mode.
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 18
FOURTH DRAFT
Nothing Comes Close to a Cobra®19
Getting Started
Screens display only if GPSL is connected.
Compass
Indicates driving direction.
Speed
Indicates the GPSL system is tracking speed.
Lat/Lon
Displays latitude and longitude of present location.
Compass
NW
Speed
55
mph
Lat / Lon
41º54'53"N
87º47'22"W
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 19
FOURTH DRAFT
20 English
Getting Started
Your Detector
Muting Alerts •
Manual Mute
Press MUTE/button momentarily to turn off Audio Alert during an Alert
condition. Press MUTE/button again during alert to turn on Audio Alert.
After current alert is gone, detector will un-mute and next alert sounds.
Auto Dark •
When Auto Dark screen is engaged, a small dot displays
at bottom of screen to show that power is on. Touch any
button to recall Standby screen.
Highway/City Mode •
IntelliShield®Tri-level City mode has a Highway mode and three City mode
levels: City X, City X Beep Off and City X+K.
IntelliShield®Tri-Level City Mode
Toggle from Highway to City mode for three levels of
Audio Alert suppression. Factory setting is City X.
City X sounds a single beep when X band signal is first
detected. The alert sounds when signal strength reaches
level 3.
City X+K combines City X mode with delay of K band
audio alerts until signal strength reaches level 2.
City X Beep Off blocks all X band audio alerts until signal
strength reaches level 3.
To change setting, navigate to the City Default screen.
Press Mute/button to cycle through options until
setting to change displays. Press MENU/SAVE button to
save select and return to Standby screen.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 20
FOURTH DRAFT
Nothing Comes Close to a Cobra®21
Programming Overview •
Begin all programming or setup with MENU/SAVE button.
Select this to change USER or ALERT settings. USER
settings customize how system handles alert filtering,
audio-related options, visual options and system-related
options. ALERT settings determine which ALERT types
are activated. ALERT settings on the XRS R9G model
includes GPS-related features.
Press MENU/SAVE button again to save feature and
function changes and return to Standby screen. If a
button is not pressed within 15 seconds while in
Setup/Programming mode, Standby screen displays and
settings made up to this point are saved automatically.
NOTE: You can restore factory settings at any time.
Enter USER or ALERT settings sub-menu and display
shows left arrow , down arrow and right arrow.
Arrows correspond with arrows on DIM, MUTE and CITY
buttons on RDU.
Press left arrow to return to previous screen. Press
right arrow to access next screen. Press down arrow
to make change. Press MENU/SAVE button to exit
setup program and save new settings. If a button is not
pressed within 15 seconds while in Setup/Programming
mode, Standby screen displays and settings made up to
this point are saved.
Each of these functions and settings are explained in
SETTINGS section of this manual.
NOTE: Advancing at the end of menu returns to beginning of menu.
NOTE: Setup/Programming mode cannot be accessed during an alert.
Unit does not detect signals while in Setup/Programming mode.
EasySet Programming
User Settings
Alert Settings
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 21
FOURTH DRAFT
22 English
City
Default
Restore
Factory
Settings
Intelli
Mute
Auto
Mute
Voice/
Tone
RDU
Beeps
Display
Color
Display
Set-up
Smart
Power
Speed
Units
Pair
Remote
NOTE: Only
shown if RDU
lock is lost.
NOTE: Only
shown when
GPSL is
installed.
User Settings
Program Navigation
Your Detector
Program Flow Diagrams •
User Settings Diagram
Screens display in this order when navigating through User Settings menu.
Speed Units screen displays only if GPSL is connected to system. Pair RDU
screen displays only if system detects a missing RDU connection.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 22
FOURTH DRAFT
Nothing Comes Close to a Cobra®23
Alert Settings Diagram
Screens display in this order when navigating through Alert Settings menu.
Speed Alert, Display GPS Db Date and Delete ALL User Locations screens
display only if a GPSL is connected to system.
POP X Band K Band KU Band
Delete
All User
Locations
Display
GPS
Db
Speed
Alert
Low Car
Voltage
These screens display only if GPSL is connected.
VG-2 Spectre
Safety
Alert
Alert Settings
Program Navigation
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 23
FOURTH DRAFT
24 English
Settings
Your Detector
Programming User Settings •
IntelliMute®Mode
Set IntelliMute to mute alerts when vehicle is stopped or
moving slowly. Intellimute senses engine RPMs and
mutes alerts. IntelliMute does not mute strobe signals
from emergency vehicles. IntelliMute works with City and
Auto Mute modes.
Set an RPM activation point to start IntelliMute.
IntelliMute begins muting alerts when engine RPMs fall
below set RPMs. The activation point is stored in
memory and recalled each time the power is turned on.
IntelliMute is factory set off.
An IntelliMute icon appears in display when IntelliMute is
on and activation is set. When engine RPMs fall below
the activation point, Arrow points down. Arrow points up
when engine RPMs are above the activation point. If unit
stops sensing the engine’s RPMs, IntelliMute indicates an
error and automatically turns off.
When initially choosing your IntelliMute activation point, a
setting approximately 300 to 600 RPMs above idle is
recommended. Reset the activation point at any time to fit
individual preferences and driving style.
NOTE: Reset RPM point if detector is used in a different vehicle.
IntelliMute may not work with some vehicles because it cannot sense
the engine’s RPMs. Reduce unwanted audio alerts by using Auto Mute
IntelliShield®Tri-level and City Mode.
WARNING
DO NOT attempt to set the RPM point while driving. Your vehicle should
be parked and idling to avoid a collision during the process.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 24
FOURTH DRAFT
Nothing Comes Close to a Cobra®25
Settings
Your Detector
Setting IntelliMute
From the IntelliMute Setup screen:
1. Press MUTE/button to start setup.
2. Press and hold the vehicle accelerator at desired engine RPMs.
3. Press DIM/button to complete setting process.
System stores engine RPM setting and displays a completion message and a
tone or voice message. Unit must sense a usable pulse within three seconds
or a set RPM point within 30 seconds of beginning of setup, or IntelliMute
detects an error and turns off.
Change a set activation point by accessing Set IntelliMute in User Settings
Programming. Repeat three-step setup process above.
Auto Mute Mode
Auto Mute reduces audio volume of all alerts after four seconds. Alerts
remain muted as long as signal is detected. Alerts sound at full volume as
long as signal is detected when Auto Mute is off. Auto Mute factory setting is
on. Press the MUTE/from the Auto Mute screen to change the setting.
Voice or Tone Mode
Set detector to sound alerts and confirm program settings with a Voice or a
Tone. Voice Alert provides voice messages in addition to tones. Tone Alert
provides tones only. Factory setting is Voice Alert.
Remote Display Unit (RDU) Beep Level
RDU Beep sets the volume level for the keypad confirmation tones of the
RDU. Choose from low, high or off RDU beep level volumes.
RDU Display Color
RDU screen color theme is customizable to match your personal preference
or your vehicle’s dash illumination. Choices include Multi-Color, Red, Blue,
Orange or Green. Factory setting is Multi -Color.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 25
FOURTH DRAFT
26 English
Settings
Your Detector
Display Setup
Display Setup determines how long RDU button backlight and display stays
on and delay time before RDU screen switches to Auto Dark mode. Set RDU
display time for 15 seconds, 30 seconds, one minute, three minutes or
Always On. Factory default is 30 seconds.
NOTE: If selecting “Always On” setting, RDU battery will need charging
more frequently.
Smart Power Mode
SmartPower feature turns system off five minutes after car’s engine is turned
off. Before SmartPower engages, three beeps sound and SmartPower flashes
on display. Start the car or press Power/Pairing button to return to normal
power. Factory setting is SmartPower On.
Speed Units (Shown only if GPSL is connected)
Displays vehicle speed in miles per hour (MPH) or kilometers per hour
(km/h). Factory setting is MPH.
Restore Factory Settings
Restore detector to original settings here. Confirmation messages display
during process.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 26
FOURTH DRAFT
Nothing Comes Close to a Cobra®27
Settings
Programming Alert Settings •
POP Alert
With Pop Detect mode on, signals are detected and an alert given. During
alert unit continues to detect other signals. Factory setting is Pop Detect Off.
X Band Alert
With X Band Detect mode on, signals are detected and an alert given. During
alert unit continues to detect other signals. Factory setting is X Band
Detection On.
K Band Alert
With K Band Detect mode on, signals are detected and an alert given. During
alert unit continues to detect other signals. Factory setting is K Band Detect
On.
Ku Band Alert
With Ku Band Detect mode on, signals are detected and an alert given. During
alert unit continues to detect other signals. Factory setting is Ku Band Detect
Off.
VG-2 Alert
Detector is undetectable by VG-2 detection devices. An alert is given when
such a device is in use near the vehicle. When VG-2 Detect mode is On, VG-2
signals are detected and an alert given. During alert unit continues to detect
other signals. Factory setting is VG-2 Detect Off.
VG-2 Audio Mode
When VG-2 Audio mode is On, alerts are heard and displayed. This setting is
only available if VG-2 Alert is On. Factory setting is VG-2 Audio Off.
Spectre 1 Alert
Detector is undetectable by Spectre 1 detection devices. An alert is given
when such a device is in use near the vehicle. When Spectre 1 Detect mode is
On, Spectre 1 signals are detected and an alert given. During alert unit
continues to detect other signals. Factory setting is Spectre 1 Detect Off.
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 27
FOURTH DRAFT
28 English
Settings
Spectre 1 Audio Mode
Spectre 1 Audio mode is only available if Spectre 1 Alert is on. Alerts are
audio and displayed on screen. Safety Alert radar signals are detected and
alerts given when Safety Alert mode is on. Factory setting is Spectre 1 Audio
Off.
Safety Alert
When Safety Alert mode is On, Safety Alert radar signals are detected and an
alert is given. During alert unit continues to detect other signals. Factory
setting is Safety Alert On.
Low Car Voltage Warning
Many U.S. cars have continuous power to 12V outlet and if a device is
connected/kept on, it will drain vehicle’s battery. To avoid this, XRS R7/R9G
comes with Smart Power and Low Car Voltage Warning features.
The detector emits a car battery low alert when voltage drops below 11.9
volts. The detector enters SmartPower mode to avoid further battery draining.
Factory setting is Car Battery Low On.
The following functions are available only if a Global Positioning System
Locator is connected to the system.
Speed Alert
The Speed Alert with the GPSL module tracks vehicle speed and sounds an
alert when set speed is exceeded. Speed settings increase or decrease in
5 MPH or km/h increments, depending upon Speed Units chosen in User
Settings. Speed alert must be turned on to see Adjust Speed Setting screen.
Factory setting is off.
Display GPS Database Date
The GPS database screen is only informational. The screen changes only
when databases are updated.
Delete all User Locations
Delete all user-programmed location alerts with this screen.
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 28
FOURTH DRAFT
Nothing Comes Close to a Cobra®29
Detection Alerts
Detection Alerts •
Alert Screens
All alerts have a unique tone and a vocal alert if the Voice
Alert feature is activated.
Radar Alerts
Radar alerts for X band, Ku band, K band and Ka band
generate a screen display “RADAR,” signal type and a
number (1-5) indicating the signal strength. A unique
tone sounds with a vocal alert if the Voice Alert feature is
activated.
POP, VG2 or SP1 display depending on signal type
detected.
Laser Alerts
Laser alerts are indicated by an “L” and laser signal type.
Ka1K 1Ku1
RADAR
RADARRADAR
X 1
RADAR
POP SP1
VG2
RADAR RADAR
RADAR
L
20 / 20
L
L
PRO LASER 3
PRO LASER
L
ULTRA LYTE
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 29
FOURTH DRAFT
30 English
Detection Alerts
Emergency Vehicle Alerts
Emergency vehicle alerts are indicated by “EV” and the
label “EMERGENCY.”
Road Hazard Alerts
Road Hazard alerts show “RH” and “ROAD HAZARD.”
Railroad Alerts
Railroad alerts generate “RR” and “RAILROAD.”
Low Car Voltage Alert
The detector emits a car battery low alert when voltage
drops below 11.9 volts. The detector enters SmartPower
mode to avoid further battery draining. Factory setting is
Car Battery Low Off.
The following screens are shown only if a Global Positioning System
Locator (GPSL) is connected to the system.
A detector system with a GPSL also receives alerts based on vehicle location
and information in its databases.
Photo Enforcement Alerts
An alert to a Photo Enforcement area is indicated by a
camera surrounded by a circle. As you get closer to the
location, the circle and the camera get progressively
larger and you hear a unique chime. If the Voice Alert is
activated you will also hear a voice alert.
EV
EMERGENCY
RH
ROAD HAZARD
RR
RAILROAD
CAR VOLTAGE
LOW
WARNING
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 30
FOURTH DRAFT
Nothing Comes Close to a Cobra®31
User Location Alerts
The system can store up to 1,000 User programmable
Location Alerts set to give hazard warnings not known to
the GPSL. The screen displays a flag surrounded by a
circle. When approaching a stored location, the circle
and flag get progressively larger. In addition, a unique
tone sounds as vehicle approaches location. A voice alert
sounds if Voice Alert is activated.
NOTE: A particular User Location can be deleted only when the vehicle
returns to that location and receives a User Location Alert. Press
MENU/SAVE to delete that location. A confirmation screen displays with
“Yes” and “No” selections. Press “Yes” to confirm User Location
Deleted. Press “No” to cancel delete.
Speed Alerts
Speed alerts are generated when the GPSL senses the
vehicle is going faster than the speed setting
programmed in the Alert Setting menu. The display
indicates actual vehicle speed and a tone sounds. All
radar, laser, strobe and safety alerts have priority and
override this alert. Factory default is Off.
Detection Alerts
Speed Alert
55
m
p
h
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 31
FOURTH DRAFT
32 English
Radar/Laser and GPS
Understanding Radar and Laser •
Radar Speed Monitoring Systems
Four band frequencies have been approved by the Federal Communications
Commission (FCC) for use by speed monitoring radar equipment:
X band 10.525 GHz
K band 24.150 GHz
Ka band 33.400 – 36.000 GHz
Ku band 13.435 GHz
Your detector detects signals in all four radar bands.
VG-2 and Spectre 1
VG-2 and Spectre 1 are “detector detectors” that work by detecting low-level
signals emitted by most radar detectors. Your detector does not emit signals
that can be detected by VG-2 or Spectre 1, but does detect VG-2 and
Spectre 1 signals and alerts you when a device is in use near your vehicle.
Safety Alert Traffic Warning System
FCC-approved Safety Alert transmitters emit microwave radar signals that
indicate the presence of a safety-related concern. Depending on the
frequency of the signal emitted, it can indicate a speeding emergency vehicle,
train or a stationary road hazard.
Because these microwave signals are within the K band frequency, most
conventional radar detectors detect Safety Alert signals as standard K band
radar. Your detector, however, is designed to differentiate between standard
K band and Safety Alert signals, and give separate alerts for each.
Safety Alert technology is relatively new. Safety Alert transmitters can be
found in limited numbers in all 50 states, but the number is growing.
Depending on your location, you may not receive these alerts regularly and
may often encounter emergency vehicles, trains and road hazards without
being alerted. As the number of transmitters increases, these alerts will
become more common.
When you receive such an alert, watch for emergency vehicles ahead of you,
on cross streets or behind you. If you see an emergency vehicle
approaching, pull over to the right side of the road and allow it to pass.
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 32
FOURTH DRAFT
Nothing Comes Close to a Cobra®33
Radar and Laser
Strobe Alert
Special strobes mounted on the light bars of authorized emergency vehicles
(fire trucks, police cars, ambulances) automatically change traffic signals as
the vehicle approaches an intersection. These strobes and the special strobe
detectors located on the traffic signals are already in use in more than 1000
cities nationwide. Cobra’s exclusive Strobe Alert detector detects these
special strobes and sounds an emergency vehicle alert.
When you receive such an alert, watch for an approaching emergency vehicle
and pull over to allow it to pass. Contact your local fire and police
departments for information about coverage in your area.
LIDAR (Laser)
The correct name for the technology that most people refer to as “laser” is
actually LIDAR, Light Detection And Ranging. LIDAR operates much like
radar. Its signal spreads out like a radar signal, though not as widely. Unlike
radar, LIDAR must have a clear line of sight to its target vehicle throughout
the entire measurement interval. Obstructions such as sign posts, utility
poles or tree branches prevent valid speed measurement.
Some common questions about LIDAR include:
IDoes weather have any affect on LIDAR?
Yes.Rain, snow, smoke, fog or airborne dust particles reduce the
effective range of LIDAR and can, with dense conditions, prevent its
operation.
ICan LIDAR operate through glass?
Yes.Newer LIDAR guns can obtain readings through most types of
glass. However, the laser pulse also can be received through glass to
trigger an alarm by your detector.
ICan LIDAR operate while in motion?
No.Because LIDAR operates by line of sight, the person using it cannot
drive the vehicle, aim and operate the gun all at the same time.
IIs LIDAR legal to use?
Yes.It is legal in all 50 states.
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 33
FOURTH DRAFT
34 English
Radar and Laser
Pop Radar Guns
The Pop Mode Radar Gun is a single-pulse Doppler radar that is a feature of
a K and Ka (Bee III Ka radar gun) band Instant-On radar gun. It uses a single,
short-time pulse to measure the target vehicle’s speed.
The Pop mode receiver senses Pop signals beyond the effective range of Pop
radar guns. As the Pop mode receiver is so sensitive, you should limit the
use of Pop Detect mode to highway and rural driving.
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 34
FOURTH DRAFT
Nothing Comes Close to a Cobra®35
Maintenance
Maintenance •
Detector is designed and built to give years of trouble-free performance
without service. No routine maintenance is required.
Follow these steps if unit is not operating properly:
IMake sure power cord is properly connected.
IMake sure lighter/accessory outlet of vehicle is clean and free of
corrosion.
IMake sure power cord’s accessory adapter is firmly seated in
lighter/accessory outlet.
ICheck power cord fuse (unscrew ribbed end cap of accessory adapter
and examine fuse) or in-line fuse of cable to fuse box, depending on
cord used. If required, replace with 2-amp fuse only.
NOTE: Rechargeable battery packs should be recycled or disposed of
properly in compliance with all applicable laws. Certain states or
municipalities provide recycling and have established collection
programs. Please contact your local waste removal authority for
instructions.
WARNING
Do Not put battery packs into fire or expose to high heat. They may
explode.
WARNING
To reduce risk of damage, use only approved battery packs.
Your Detector
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 35
FOURTH DRAFT
36 English
Specifications
Your Detector
Band and Frequencies •
Band Frequencies
X Band 10.525 ± 0.050 GHz
K Band 24.125 ± 0.125 GHz
Safety Alert 24.070 ± 0.010 GHz
Traffic Warning 24.110 ± 0.010 GHz
System
24.190 ± 0.010 GHz
24.230 ± 0.010 GHz
Ka Band 34.700 ± 1.300 GHz
Ku Band 13.435 ± 0.050 GHz
Laser 910 ± 50 nm
Strobe 700 ± 300 nm
This radar detector is covered by one or more of the following U.S. patents: 5,497,148; 5,594,432;
5,612,685; 6,078,279; 6,094,148; 6,621,447. Additional patents may be listed inside the product
or pending.
NOTE: This device complies with part 15 of FCC rules: Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference
received including interference that may cause undesired operation.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 36
FOURTH DRAFT
Nothing Comes Close to a Cobra®37
Warranty
Warranty •
COBRA ELECTRONICS CORPORATION warrants that its products, and the
component parts thereof, will be free of defects in workmanship and
materials for a term of one year from the date of first consumer purchase.
This warranty may be enforced by the first consumer purchaser, provided
that the product is used solely within the U.S.A and Canada.
Cobra will, without charge, repair or replace, at its option, defective products
or component parts upon delivery to the Cobra Factory Service Department,
accompanied by proof of the date of first consumer purchase, such as a
duplicated copy of a sales receipt. The consumer must pay any initial
shipping charges required to ship the product for warranty service. Return
charges will be at Cobra’s expense, if the product is repaired or replaced
under warranty.
This warranty gives the consumer specific rights, and he or she may also
have other rights which vary from state to state.
NOTE: Cobra makes no warranty as to the accuracy or completeness
of the data in the products and disclaims any and all express, implied
or statutory warranties, including any implied warranty of
merchantability or fitness for a particular purpose.
EXCLUSIONS – This limited warranty does not apply:
1. To any product damaged by accident;
2. In the event of misuse or abuse of the product or as a result of
unauthorized alterations or repairs;
3. If the serial number has been altered, defaced or removed;
4. If the owner of the product resides outside the U.S.A and Canada.
Warranty
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 37
FOURTH DRAFT
38 English
All implied warranties, including warranties of merchantability and fitness for
a particular purpose are limited in duration to the length of this warranty.
COBRA SHALL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL OR
OTHER DAMAGES; INCLUDING, WITHOUT LIMITATION, DAMAGES
RESULTING FROM LOSS OF USE OR COST OF INSTALLATION. Some states
do not allow limitations on the duration of an implied warranty and/or do not
allow the exclusion or limitation of incidental or consequential damages, so
the above limitations may not apply to some consumers.
It is the user’s responsibility to use this product prudently and responsibly.
This product is intended to be used only as a travel aid and must not be used
or any purpose requiring precise measurement of direction, distance, location
or topography.
Warranty
Warranty
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 38
FOURTH DRAFT
Nothing Comes Close to a Cobra®39
User License •
This document and the software and data described in it are furnished under
license and may be used or copied only in accordance with such license.
Except as permitted by such license, the contents of this document, software
and data may not be disclosed to third parties, copied or duplicated in any
form, in whole or in part, without the prior written permission of Cobra
Electronics Corporation. This document, software and DATA contain
proprietary and confidential information of Cobra Electronics Corporation and
its licensors.
Cobra grants the purchaser a limited license for use of this document,
software and data incorporated in its products for personal use, and not for
resale, sublicense or commercial use. By using this product, the purchaser
agrees to be bound by the terms and conditions of this license agreement.
The purchaser acknowledges that the content of this document, software and
data are the property of Cobra and its licensors and are protected by
copyright laws of the USA and international treaties. The purchaser agrees
not to modify, decompile, disassemble, reverse engineer or reduce to human
readable form the software, DATA or any part thereof, nor to create derivative
works based on the contents of the document, software or data, nor remove
or obscure any copyright, trademark notice, or restrictive legend. The
purchaser agrees not to export or re-export this document or this product to
any country in violation of the export control laws of the U.S.A.
The contents of this document, software and data are for informational use
only and are subject to change without notice. Cobra and its licensors intend
to provide their customers the most complete and accurate location database
for red light/speed cameras available from government and private data
sources. However, all data sources have limitations and some have
inaccuracies or are incomplete to some degree. These characteristics carry
over to this product as well. As such, COBRA AND ITS LICENSORS SHALL
NOT BE LIABLE TO THE USER FOR ANY INCIDENTAL, CONSEQUENTIAL,
SPECIAL, INDIRECT OR EXEMPLARY DAMAGES ARISING FROM THE USE
OF ITS PRODUCTS.
THIS PRODUCT IS PROVIDED ON AN “AS IS” AND “WITH ALL FAULTS
BASIS” AND COBRA AND LICENSORS EXPRESSLY DISCLAIM ALL
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY,
QUALITY, ACCURACY, TITLE AND FITNESS FOR A PARTICULAR PURPOSE.
User License
User License
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 39
FOURTH DRAFT
40 English
NO ORAL OR WRITTEN ADVICE OR INFORMATION PROVIDED BY COBRA
AND/OR ITS LICENSORS OR ANY OF THEIR AGENTS, EMPLOYEES OR
THIRD PARTY PROVIDERS SHALL CREATE A WARRANTY AND USER IS
NOT ENTITLED TO RELY ON ANY SUCH ADVICE OR INFORMATION. THIS
DISCLAIMER OF WARRANTIES IS AN ESSENTIAL CONDITION OF THE
AGREEMENT.
Cobra encourages customers to report any errors found in our data by
contacting technical assistance (available in English and Spanish) at
product info@cobra.com (e-mail), by visiting our website: www. cobra.com,
or by calling customer assistance (available in English and Spanish) at
773-889-3087 between 8:00 a.m. and 6:00 p.m. Central Time, Monday
through Friday (except holidays).
User License
User License
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 40
FOURTH DRAFT
Nothing Comes Close to a Cobra®41
Product Service
Customer Assistance
Product Service •
For questions about operating or installing this new Cobra product, or if
parts are missing…CALL COBRA FIRST…do not return this product to the
store.
If this product should require factory service, call Cobra before sending the
product. This will ensure the fastest turn-around time on any repair. If Cobra
asks that the product be sent to its factory, the following must be furnished
to have the product serviced and returned.
1. For Warranty Repair, include some form of proof-of-purchase, such as a
mechanical reproduction or carbon of a sales receipt. Make sure the date
of purchase and product model number is clearly readable. If the originals
are sent, they cannot be returned.
2. Send the entire product.
3. Enclose a description of what is happening with the product. Include a
typed or clearly printed name and address of where the product is to be
returned, with phone number (required for shipment).
4. Pack product securely to prevent damage in transit. If possible, use the
original packing material.
5. Ship prepaid and insured by way of a traceable carrier such as United
Parcel Service (UPS) or Priority Mail to avoid loss in transit to:
Cobra Factory Service
Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707 U.S.A.
6. If the product is in warranty, upon receipt of the product, it will either be
repaired or exchanged depending on the model. Please allow
approximately 3 – 4 weeks before contacting Cobra for status. If the
product is out of warranty, a letter will automatically be sent with
information as to the repair charge or replacement charge.
For any questions, please call 773-889-3087 for assistance.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 41
FOURTH DRAFT
42 English
Trademark Acknowledgement
Customer Assistance
Trademark Acknowledgement •
Cobra®, 6 Band®, 9 Band®, DigiView®, EasySet®, Extra Sensory Detection®,
IntelliMute®, IntelliShield®, LaserEye®, Nothing Comes Close to a Cobra®,
Safety Alert®Traffic Warning System, Strobe Alert®, VG-2 Alert®, Xtreme
Range Superheterodyne®and the snake design are registered trademarks of
Cobra Electronics Corporation, USA.
Cobra Electronics Corporation™, 11 Band™, 12 Band™, Extreme Bright
DataGrafix™, Revolution™ Series, SmartPower™, Spectre Alert™, Super-
Xtreme Range Superheterodyne™, S-XRS™, UltraBright™, and Voice Alert™
are trademarks of Cobra Electronics Corporation, USA.
Opticom™ is a trademark of 3M Corporation.
Instaclear®for Ford is a registered trademark of Ford Motor Company, Inc.
Electriclear®for GM is a registered trademark of General Motors Corporation.
20-20™ and Ultra-Lyte™ are trademarks of Laser Technology, Inc.
ProLaser™ and ProLaser III™ are trademarks of Kustom Signals, Inc.
Bee III™ and Pop™ are trademarks of MPH Industries.
Spectre™ is a trademark of Stalcar.
Interceptor VG-2™ is a trademark of TechniSonic Industries LTD.
Tomar®is a registered trademark of TOMAR Electronics, Inc.
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:15 PM Page 42
FOURTH DRAFT
Nothing Comes Close to a Cobra®43
Dual Port Power Adapter
Includes adjustable plug (up to 90˚)
and fuse
Item #CLP-2B
THIS
SURFACE
TOWARDS
SKY
GPS Locator (w/cable) Upgrade Kit
(for Model XRS R7 Only)
Item #RDA GPSL
Optional Accessories
Customer Assistance
LiON Replacement Battery
Item #RDA LIBP
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:42 PM Page 43
FOURTH DRAFT
Nothing Comes Close to a Cobra®44
Accessories Order Info
Customer Assistance
Ordering From U.S.A.
Call 773-889-3087 for pricing or visit www.cobra.com.
For Credit Card Orders
Call 773-889-3087 [Press one from the main menu] 8:00 a.m. to 6:00 p.m. Central Time,
Monday through Friday.
Make Check or Money Order Payable To
Cobra Electronics, Attn: Accessories Dept.,
6500 West Cortland Street, Chicago, IL 60707 U.S.A.
To Order Online
Please visit our website: www.cobra.com
Item # Description
CLP-2B Dual Port Power Adapter
RDA GPSL GPS Locator (w/cable) Upgrade Kit (for Model XRS R7 Only)
RDA LIBP LiON Replacement Battery
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page 44
FOURTH DRAFT
Nothing Comes Close to a Cobra®English
For more information or to
order any of our products,
please visit our website:
www.cobra.com
CB Radios
microTALK®Radios
Radar/Laser Detectors
Safety Alert®Traffic Warning Systems
Handheld GPS Receivers
Mobile GPS Navigation Systems
HighGear®Accessories
CobraMarine®VHF Marine Radios
CobraMarine®Chartplotters
Power Inverters
Accessories
The Cobra line of quality products includes:
XRS_R7_R9G_1-5-07.qxd:Layout 1 1/9/07 5:14 PM Page BC1
FOURTH DRAFT
