www.codanradio.com © Copyright 2014

 FEATURES AT A GLANCE

 Adaptive data rates up to 19200 bit/s

 NATO interoperable

 Data encryption

 Compatible with CALM™/ALE

 Intranet/Internet gateway

Codan’s RC50-C HF Email software provides fast, effi cient,

error free email capability over HF radio. Operating in

conjunction with Codan’s HF Transceivers and RM50 range

of Data Modems, the software operates on a standard

Windows™ PC using a single USB port with no specialised

PC hardware requirements. When installed, the software

runs in the background requiring no user interaction.

ADAPTIVE DATA RATES UP TO 19200 BIT/S

When used with a CODAN™ ISB capable Transceiver data rates up

to 19200 bit/s are possible. Data rates are fully adaptive to suit the

prevailing channel conditions ensuring the fastest possible data rate

is used at all times. Inbuilt compression and industry leading data

rates minimise station on-air time.

NATO INTEROPERABLE

Operator control via a standard POP3 email client and the use

of STANAG 5066 ensures the system is interoperable with other

manufacturer’s systems.

DATA ENCRYPTION

Over the air transmissions can be encrypted using AES-256 bit

encryption. Additionally, the RC50-C system has been designed to

support customer defi ned third party email encryption software for

full end-to-end email encryption.

SIMPLIFIED OPERATION USING CALM™ / ALE

The RC50-C HF Email software integrates with Codan’s enhanced

CALM™/ALE linking system, simplifying operation and ensuring the

best available channel is chosen for each data session.

INTRANET / INTERNET GATEWAY

RC50-C can be confi gured as a gateway to connect with a wider

Intranet/WAN providing a fully integrated fi eld email service.

12-20271-EN Issue 3 5/2014

RC50-C HF EMAIL SOFTWARE

www.codanradio.com

CODAN RADIO COMMUNICATIONS

Australia: +61 8 8305 0528

Canada: +1 250 382 8268

 US: +1 585 419 9970

 Dubai: +971 44 53 72 01

 UK: +44 1252 717 272

 sales@codanradio.com

SPECIFICATIONS

STANAG 5066 V1.2 Annex F.12 Compressed File Transport Protocol (CFTP)

SUPPORTED WAVEFORMS Modulation Data Rates

MIL-STD-188-110A Coded PSK

Uncoded PSK

75, 150, 300, 600, 1200, 2400

4800

MIL-STD-188-110B (serial tone) Coded PSK/QAM 3200, 4800, 6400, 8000, 9600

MIL-STD-188-110B (Appendix F) * Coded PSK/QAM ISB: 9600, 12800, 16000, 19200

STANAG 4539 Coded PSK/QAM

Uncoded PSK/QAM

75, 150, 300, 600, 1200, 2400

3200, 4800, 6400, 8000, 9600

12800

STANAG 4285 Coded PSK

Uncoded PSK

75, 150, 300, 600, 1200, 2400

1200, 2400, 3600

STANAG 4415 Coded PSK 75

STANAG 4529 Coded PSK

Uncoded PSK

75, 150, 300, 600, 1200

600, 1200, 1800

DATA RATE CONTROL Adaptive, controlled by BER measurements, ISB 75 to 19200 bit/s, SSB 75 to 9600 bit/s

DATA INTERFACE USB2.0 or 2 x RS232 Serial

MINIMUM PC SYSTEM REQUIREMENTS Windows™ XP Professional SP2 or Windows™ 2000 Professional SP4

Compatible with Windows™ 7

Intel Pentium IV 800 MHz or better

6 GB or more of free space for email storage

512 MB or more of RAM

CD-ROM drive

POP3 / SMTP compliant email client

Access to any commercial POP3 / SMTP compliant email server for internet connectivity

RECOMMENDED TRANSCEIVERS Envoy™ X2

NGT™ SR, SRx, MR, ASR, AR

Manpack 2110, 2110M

Consult Codan for confi guration options

RC50-C HF EMAIL SOFTWARE

CODAN™, Envoy™ and NGT™ are trademarks of Codan

Limited. Other brand, product and company names

mentioned in this document are trademarks or

registered trademarks of their respective holders.

Values noted are typical. Equipment descriptions and specifi cations subject to change without notice or obligation.

12-20271-EN Issue 3 5/2014

* Requires an ISB capable Transceiver
