Users Manual
BTN 1 BTN 2
Press NA Find
Press 2X Start NA
Press & Hold Stop Panic
Mopar 2-way HHU Operational Specification
1. HHU button #1 (Start)
1.1. Double-press for start (second press must be within 3 seconds of first press).
1.2. Single press and hold to remote stop (at least 1.6 seconds).
1.3. Single LED (visible through case plastic) must light with each press of the button for
visual confirmation that signal was sent from HHU.
2. IVU receives signal and responds
2.1. "Handshake confirmation" - HHU button #1 confirms signal receipt by vehicle via
2.2. "Handshake confirmation" - HHU Piezo buzzer confirms signal receipt by vehicle via
1 beepsimultaneous with LED flashes
2.3. "Engine Start confirmation" - HHU button #1 confirms start via 2 flashes
of a green backlit LED.
2.4. "Engine Start confirmation" - HHU Piezo buzzer confirms start via 2 beeps
simultaneous with LED flashes.
2.5. Upon remote stop, HHU button #1 confirms stop via 3 long flashes of a backlit
green LED.
2.6. Upon remote stop, HHU Piezo buzzer confirms stop via 3 long beeps simultaneous
with LED flash.
2.7 Engine Stall or Fail to Start
3. HHU button #2 (Find/Panic)
3.1. Single press for Find (5 short horn honks/parking light flashes). There will be no confirmation
back to the HHU for this function.
3.2. Single press and hold (at least 1.6 seconds) for Panic (continuous horn honks & parking light
flashes) until any button on the transmitter is pushed to stop function. There will be no
confirmation back to the HHU for this function.
confirmation that signal was sent from HHU.
3.3. Single LED (visible through case plastic) must light with each press of the button for visual
Engine Stop
Signal receive
Engine Start
1 flash of a green backlit LED
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions.
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause undesired
operation.
Per FCC 15.21, you are cautioned that changes or modifications not expressly approved by the part responsible
for compliance could void the user’s authority to operate the equipment.
