Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com
CCUUBBEERR DDIIMMEENNSSIIOONNSS
W x D x H
KM-61BAH
4/08
Item # 13216
SELF-CONTAINED CUBER WITH BUILT-IN STORAGE BIN
Warranty
Valid in United States, Canada, Puerto Rico, & U.S. Territories. Contact factory for warranty in
other countries.
Three Year - Parts & Labor on entire machine.
Five Year - Parts on compressor and air-cooled condenser coil.
Five Year - Parts on evaporator.
KM-61BAH
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
KM-61BAH
173/4 x 24 x 39*
* with 6" legs
*AutoCad available on KCL
KM-61BAH
Air-Cooled
Shown
•Up to 71 lbs. of ice production per 24 hours
• Up to 38 lbs. of built-in storage capacity
• Individual crescent cube
•Durable stainless steel exterior
• CycleSaver®Design
• EverCheck®alert system
• Front in, front out airflow
• Stainless steel evaporator
• Slide in door
• Removable air filter
• Power switch accessible without panel removal
• Built-in installation possible
• R-134a Refrigerant
®
Hoshizaki
DIMENSIONS
W x D x H
KM-61BAH
173/4 x 24 x 39*
*with 6" legs
©HOSHIZAKI AMERICA, INC.
KM-61BAH
SELF-CONTAINED CUBER WITH BUILT-IN STORAGE BIN
UTILITY CONSUMPTION
Model Number Ice Production
Per Cycle
KWH per
100 LBS.
Potable
Water
Gal. per
100 lbs.
Lbs. Cubes
KM-61BAH
SPECIFICATIONS
Model Number Condenser Amperage Min. Circuit
Ampacity Shipping
Weight
3.4 15A 117 lbs.
KM-61BAH
10.5 20.3
Air-Cooled
1.7 80
Condenser
Water
Gal. per
100 lbs.
N/A
O P E R AT I N G L I M I T S
• Ambient Temp Range 45 - 100˚F
• Water Temp Range 45 - 90˚F
• Water Pressure 10 - 113psig
• Voltage Range 104 - 127V
ELECTRICAL&PLUMBING/KM-61BAH
• 115V/60/1
• 15 amp Max Fuse/HACR Breaker Size
• 3/8” OD copper or equivalent independent potable water supply
• 3/4” independent drain connection
• 1/2” FPT Water Inlet
618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com Printed in U.S.A.
FRONT DIMENSIONS
BACK DIMENSIONS
SIDE DIMENSIONS
KM CUBE DIMENSIONS
• Air-cooled
AIR-COOLED
70˚
50˚ 70˚
71
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
66
65
65
56
58
51
43
49
