Compal Electronics MPX001 Portable Cellular / PCS GSM Transceiver User Manual Exhibit 8 Users Manual

Compal Electronics Inc Portable Cellular / PCS GSM Transceiver Exhibit 8 Users Manual

Exhibit 8 Users Manual

FCC ID: GKRMPX001

User’s Manual

A preliminary draft copy of the manual follows:

EXHIBIT 8

START HERE >

MPx

GSM

Welcome

Welcome to the world of Motorola MOTOPro devices. Your

selection, the Motorola MPx, delivers to you simplified

communications, increased productivity, and the control to

develop a superior mobile experience whether at work, at

home, on the road or at play.

Phone Mode

Main Screen

Ear Piece

Voice Dia l

Button

Talk Button

Contacts Button

Game Pad

Keypad

Landscape Mode

Button

Inbox

Button

Start

Button

Camera

Button

Power/End

Button

Front Panel

Back Panel

Motorola, Inc.

Consumer Advocacy Office

1307 East Algonquin Road

Schaumburg, IL 60196

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States)

1-800-461-4575 (Canada)

www.motorola.com

(United States)

www.motorola.ca

(Canada)

MOTOROLA and the Stylized M Logo are registered in the US Patent &

Trademark Office. The Bluetooth trademarks are owned by their proprietor and

used by Motorola, Inc. under license. Java and all other Java-based marks are

trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and

other countries. All other product or service names are the property of their

respective owners.

The information contained in Motorola's user's guides is believed to be correct

at the time of printing. Motorola reserves the right to change or modify any

information or specifications without notice. The contents of Motorolas user's

guides are provided as is. Except as required by applicable law, no warranties

of any kind, either express or implied, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose, are made in

relation to the accuracy, reliability, or contents of this guide.

Caution:

Changes or modifications made in the radio phone, not expressly

approved by Motorola, will void the user’s authority to operate the equipment.

Manual number:O

Contents

Welcome

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Phone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Landscape Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Safety and General Information

. . . . . . . . . . . . . . . . . . . 11

Getting Started

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Package Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Installing and Removing the SIM Card . . . . . . . . . . . . . . 19

Installing and Removing the SD/MMC Card . . . . . . . . . . 21

Battery Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Charging the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Removing the Stylus. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Opening the Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Turning the Phone On and Off . . . . . . . . . . . . . . . . . . . . 30

Calibrating the Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Answering an Incoming Call . . . . . . . . . . . . . . . . . . . . . . 34

Ending a Call

/!/!/!/!/!/!/!/!/!/!/!/!/!/!/!/!/!/!!45

Learning to Use Your MPx Pocket PC Phone

. . . . . . . . 35

Using Your Phone’s Menus and Features. . . . . . . . . . . . 35

Entering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Adjusting Phone Volume. . . . . . . . . . . . . . . . . . . . . . . . . 48

Using the External Display . . . . . . . . . . . . . . . . . . . . . . . 50

Checking Your Phone Connection . . . . . . . . . . . . . . . . . 50

Setting Your Phone to Flight Mode . . . . . . . . . . . . . . . . . 51

Using a Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Using a Remote PTT Button . . . . . . . . . . . . . . . . . . . . . 52

Programs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Using the External Display . . . . . . . . . . . . . . . . . . . . . . 55

Setting Up Your Phone

. . . . . . . . . . . . . . . . . . . . . . . . . . 61

Device Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Calling Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

The Dialer Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Taking a Note during a Call . . . . . . . . . . . . . . . . . . . . . . 70

Putting a Call on Hold . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Managing Your Contacts . . . . . . . . . . . . . . . . . . . . . . . . 73

Additional Dialing Information . . . . . . . . . . . . . . . . . . . . 79

Messaging Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Email Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

SMS Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

MMS Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Viewing Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Personalizing Your MPx

. . . . . . . . . . . . . . . . . . . . . . . . . 97

Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Getting More Out of Your Phone

. . . . . . . . . . . . . . . . . 108

Dialing Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Managing Your Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Monitoring Phone Use. . . . . . . . . . . . . . . . . . . . . . . . . 109

Network Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Using ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Synchronizing Information. . . . . . . . . . . . . . . . . . . . . . 112

Synchronizing Using an Infrared Connection . . . . . . . 115

ActiveSync Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Personal Organizer Features

. . . . . . . . . . . . . . . . . . . . . 119

Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Converting Currency. . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Using the Stop Watch . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Security

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Setting PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Locking and Unlocking Your Phone . . . . . . . . . . . . . . . 121

Changing Your Unlock Code. . . . . . . . . . . . . . . . . . . . . 123

Protecting the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . 124

Microsoft Pocket Outlook

. . . . . . . . . . . . . . . . . . . . . . . 125

Calendar: Scheduling Appointments and Meetings . . . 126

Contacts: Tracking Friends and Colleagues . . . . . . . . . 128

Tasks: Keeping a To Do List . . . . . . . . . . . . . . . . . . . . . 131

Notes: Capturing Thoughts and Ideas . . . . . . . . . . . . . 133

Using Applications

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Communicating with MSN Messenger . . . . . . . . . . . . . 135

Pocket Word . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Pocket Excel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Windows Media Player . . . . . . . . . . . . . . . . . . . . . . . . . 143

Pictures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Using the Camera

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Photo Album . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Getting Connected

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

Wi-Fi Wireless LAN (IEEE802.11b) . . . . . . . . . . . . . . . 161

Bluetooth Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Pocket Internet Explorer: Browsing Web and WAP

Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Games

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

Troubleshooting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

Specific Absorption Rate Data

. . . . . . . . . . . . . . . . . . 189

Safety and General

Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.

READ THIS INFORMATION BEFORE USING YOUR PHONE.

The information provided in this document supersedes the general safety

information in user’s guides published prior to December 1, 2002.

Exposure To Radio Frequency (RF) Energy

Your phone contains a transmitter and a receiver. When it is ON, it

receives and transmits RF energy. When you communicate with your

phone, the system handling your call controls the power level at which

your phone transmits.

Your Motorola phone is designed to comply with local regulatory

requirements in your country concerning exposure of human beings to RF

energy.

Operational Precautions

To assure optimal phone performance and make sure human exposure to

RF energy is within the guidelines set forth in the relevant standards,

always adhere to the following procedures.

External Antenna Care

Use only the supplied or Motorola-approved replacement antenna.

Unauthorized antennas, modifications, or attachments could damage the

phone.

DO NOT hold the external antenna when the phone is IN USE. Holding

the external antenna affects call quality and may cause the phone to

operate at a higher power level than needed. In addition, use of

unauthorized antennas may result in non-compliance with the local

regulatory requirements in your country.

Phone Operation

When placing or receiving a phone call, hold your phone as you would a

wireline telephone.

Body-Worn Operation

To maintain compliance with RF energy exposure guidelines, if you wear a

phone on your body when transmitting, always place the phone in a

Motorola-supplied or approved clip, holder, holster, case, or body harness

for this phone, if available. Use of accessories not approved by Motorola

may exceed RF energy exposure guidelines. If you do not use one of the

body-worn accessories approved or supplied by Motorola, and are not

using the phone held in the normal use position, ensure the phone and its

antenna are at least 1 inch (2.5 centimeters) from your body when

transmitting.

Data Operation

When using any data feature of the phone, with or without an accessory

cable, position the phone and its antenna at least 1 inch (2.5 centimeters)

from your body.

Approved Accessories

Use of accessories not approved by Motorola, including but not limited to

batteries and antennas, may cause your phone to exceed RF energy

exposure guidelines. For a list of approved Motorola accessories, visit our

website at www.Motorola.com.

RF Energy Interference/Compatibility

Nearly every electronic device is susceptible to RF energy interference

from external sources if inadequately shielded, designed, or otherwise

configured for RF energy compatibility. In some circumstances your

phone may cause interference.

Facilities

Turn off your phone in any facility where posted notices instruct you to do

so. These facilities may include hospitals or health care facilities that may

be using equipment that is sensitive to external RF energy.

Aircraft

When instructed to do so, turn off your phone when on board an aircraft.

Any use of a phone must be in accordance with applicable regulations per

airline crew instructions.

Medical Devices

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 6

inches (15 centimeters) be maintained between a handheld wireless

phone and a pacemaker.

Persons with pacemakers should:

•

ALWAYS keep the phone more than 6 inches (15 centimeters) from

your pacemaker when the phone is turned ON.

•

NOT carry the phone in the breast pocket.

•

Use the ear opposite the pacemaker to minimize the potential for

interference.

•

Turn OFF the phone immediately if you have any reason to suspect

that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the

event of such interference, you may want to consult your hearing aid

manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of

your device to determine if it is adequately shielded from RF energy. Your

physician may be able to assist you in obtaining this information.

Use While Driving

Check the laws and regulations on the use of phones in the area where

you drive. Always obey them.

When using your phone while driving, please:

•

Give full attention to driving and to the road.

•

Use handsfree operation, if available.

•

Pull off the road and park before making or answering a call if driving

conditions so require.

Responsible driving best practices may be found in the “Wireless Phone

Safety Tips” at the end of this manual and at the Motorola website:

www.Motorola.com/callsmart.

Operational Warnings

For Vehicles With an Air Bag

Do not place a phone in the area over an air bag or in the air bag

deployment area. Air bags inflate with great force. If a phone is placed in

the air bag deployment area and the air bag inflates, the phone may be

propelled with great force and cause serious injury to occupants of the

vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially explosive

atmosphere. Do not remove, install, or charge batteries in such areas.

Sparks in a potentially explosive atmosphere can cause an explosion or

fire resulting in bodily injury or even death.

Note: T

he areas with potentially explosive atmospheres referred to above

include fueling areas such as below decks on boats, fuel or chemical

transfer or storage facilities, areas where the air contains chemicals or

particles, such as grain, dust, or metal powders. Areas with potentially

explosive atmospheres are often but not always posted.

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF your

phone when you are near electrical blasting caps, in a blasting area, or in

areas posted “Turn off electronic devices.” Obey all signs and instructions.

Batteries

Batteries can cause property damage and/or bodily injury such as burns if

a conductive material such as jewelry, keys, or beaded chains touch

exposed terminals. The conductive material may complete an electrical

circuit (short circuit) and become quite hot. Exercise care in handling any

charged battery, particularly when placing it inside a pocket, purse, or

other container with metal objects.

Use only Motorola original batteries

and chargers.

Your battery or phone may contain symbols, defined as follows:

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when

exposed to flashing lights, such as when watching television or playing

video games. These seizures or blackouts may occur even if a person

never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family

history of such occurrences, please consult with your doctor before

playing video games on your phone or enabling a flashing-lights feature

on your phone. (The flashing-light feature is not available on all products.)

Parents should monitor their children's use of video game or other

features that incorporate flashing lights on the phones. All persons should

discontinue use and consult a doctor if any of the following symptoms

occur: convulsion, eye or muscle twitching, loss of awareness, involuntary

movements, or disorientation.

Symbol Definition

Important safety information will follow.

Your battery or phone should not be disposed of in

afire.

Your battery or phone may require recycling in

accordance with local laws. Contact your local

regulatory authorities for more information.

Your battery or phone should not be thrown in the

trash.

Your phone contains an internal lithium ion battery.

To limit the likelihood of such symptoms, please take the following safety

precautions:

•

Do not play or use a flashing-lights feature if you are tired or need

sleep.

•

Take a minimum of a 15-minute break hourly.

•

Play in a room in which all lights are on.

•

Play at the farthest distance possible from the screen.

Repetitive Motion Injuries

When you play games on your phone, you may experience occasional

discomfort in your hands, arms, shoulders, neck, or other parts of your

body. Follow these instructions to avoid problems such as tendonitis,

carpal tunnel syndrome, or other musculoskeletal disorders:

•

Take a minimum 15-minute break every hour of game playing.

•

If your hands, wrists, or arms become tired or sore while playing,

stop and rest for several hours before playing again.

•

If you continue to have sore hands, wrists, or arms during or after

play, stop playing and see a doctor.

Getting Started

Welcome to the world of Motorola digital wireless

communications! We are pleased that you have chosen

the Motorola MPx Pocket PC phone.

Package Content

Your MPx Pocket PC phone comes with a replaceable

internal battery and is typically equipped with a charger.

Other accessories can enhance your phone’s performance

and portability.

About This Guide

This guide describes the basic features of your Motorola

MPx Pocket PC phone.

Optional Features

This label identifies an optional network, SIM

card, or subscription-dependent feature that may

not be offered by all service providers in all

geographical areas. Contact your service

provider for more information.

032380o

Getting Started

Optional Accessories

This label identifies a feature that requires an

optional Motorola Original

accessory.

Installing and Removing the

SIM Card

Your SIM (Subscriber Identity Module) card contains your

phone number, service details, and phonebook/ message

memory.

Caution:

Do not bend or scratch your SIM card. Avoid

exposing your SIM card to static electricity, water, or dirt.

Inserting the SIM Card

Action

Locate the SIM card slot on

the side of the device.

Getting Started

Removing the SIM Card

Open the rubber door, and

insert the SIM card into the

slot.

Note:

Position the SIM card

as shown, with the chip

facing the back of the device

and the notched corner to

the outside of the slot.

Close the rubber door.

Action

Open the battery door and

remove the battery.

Action

Getting Started

Installing and Removing the

SD/MMC Card

Your Pocket PC phone has a SD/MMC card slot for a SD

(Secure Digital) memory card. An SD/MMC card expands

the memory capacity of your Pocket PC phone. You can

purchase SD/MMC cards from a computer store.

Caution:

Make sure that no foreign objects enter the SD/

MMC card slot of your Pocket PC phone.

Note:

For more information, refer to the documentation for

the SD/MMC card.

Insert the tip of the stylus

into the hole in the battery

compartment, as shown.

Use the stylus to push the

SIM card out, then remove

the card.

Action

Getting Started

Installing the Card

Action

Locate the SD/MMC card

slot and open the rubber

door.

Insert the SD/MMC card as

shown, with its label facing

the front and the connector

pointing to the slot.

Push the card into the slot

until it fits into place.

Getting Started

Removing the Card

Battery Use

Battery performance depends on many factors, including

your wireless carrier’s network configuration; signal

strength; the temperature at which you operate your

phone; the features and/or settings you select and use;

Action

Close any application that uses the SD/MMC card.

Press the memory card

down. When you release it, it

pops up.

Remove the card and close

the cover.

Getting Started

items attached to the phone’s accessory connector port;

and your voice, data, and other application usage patterns.

Caution:

To prevent injuries or burns, do not allow

metal objects to contact or short-circuit the battery

terminals.

To maximize your battery’s performance:

•

Always use Motorola Original batteries and battery

chargers. The phone warranty does not cover damage

caused from using non-Motorola batteries and/or

battery chargers.

•

New batteries or batteries that have been stored for a

long time may require a longer charge time.

•

Maintain the battery at or near room temperature

when charging.

•

Do not expose batteries to temperatures below -10°C

(14°F) or above 45°C (113°F). Always take your

phone with you when you leave your vehicle.

•

When you do not intend to use a battery for a while,

store it uncharged in a cool, dark, dry place, such as a

refrigerator.

•

Batteries gradually wear down and require longer

charging times. This is normal. If you charge your

battery regularly and notice a decrease in talk time or

an increase in charging time, then it is probably time

to purchase a new battery.

The rechargeable batteries that power this phone

must be disposed of properly and may need to be

recycled. Refer to your battery’s label for battery

Getting Started

type. Contact your local recycling center for proper

disposal methods.

Warning:

Never dispose of batteries in a fire because

they may explode.

Installing the Battery

Your Pocket PC phone is designed to use only Motorola

Original batteries and accessories.

Action

Press the battery clip, slide

the battery cover outward,

and lift the battery cover.

Insert the battery into the

battery compartment.

Getting Started

Charging the Battery

New batteries are shipped partially charged. Before you

can use your phone, you need to install and charge the

battery as described below. Some batteries perform best

after several full charge/discharge cycles.

Replace the cover.

Action

Plug the travel charger into

the phone, with the release

tab facing up.

Action

Getting Started

Tip:

You can safely leave the travel charger connected to

the phone after charging is complete. This will

not

damage

the battery.

Plug the other end of the

travel charger into the

appropriate electrical outlet.

When the Notification LED

on the phone lights green

(full-charged), press the

release tab and remove

the travel charger.

Action

Getting Started

Removing the Stylus

The stylus for your MPx Pocket PC Phone fits into a

slot on the back of the phone. When you need to use

the stylus:

Action

Press the top of the stylus.

When you release it, it pops

up.

Pull the stylus from the slot.

Getting Started

Opening the Phone

Your MPx Pocket PC Phone allows you to operate in 2

modes:

Portrait

and

Landscape

(see pages 2 and 3).

Portrait mode is typically used for phone functions.

Landscape mode is typically used for Pocket PC

functions.

Action

To open the phone for Portrait

mode

, push the cover from the

outside (near the speaker).

To open the phone for

Landscape mode

, press the

release button on the hinge

and lift the cover from the

right side.

Getting Started

Turning the Phone On and Off

Notes:

•

Pressing the Power/End key longer than 7 seconds

can suspend the device. The following events will

wake up a suspended device: receiving an MT call or

an SMS or MMS message; plugging in a USB cable or

AC adapter; pressing a phone or application key

Action

Open the phone.

Press and hold the Power/

End key for 7 seconds to

turn on the device.

If necessary, enter your SIM card PIN code to

unlock the

SIM card

Caution:

If you enter an incorrect PIN code 3 times in

a row, your SIM card is disabled and your phone

displays

SIM Blocked

If necessary, enter your 4-digit unlock code to

unlock the phone.

Getting Started

(Power/End, Talk, Camera, or Inbox); pressing the

Reset button; inserting a SIM card (which resets the

phone).

•

While an AC adapter is inserted, the phone cannot

be suspended.

•

When the battery cover is removed, Flight Mode is

activated.

•

If the phone responds slowly or stops responding,

press the Reset button to reset the phone.

•

If necessary, you can perform a Hardware reset.

To perform a software Hardware reset, simultaneously

press the Talk and Reset buttons.

Calibrating the Screen

You must calibrate the screen response of our MPx Pocket

PC phone to ensure proper operation. This process

ensures that, when you tap an item on the screen, the item

is activated.

Note:

With use, the tip of the stylus may become worn or

may pick up foreign particles that scratch the screen. A

damaged stylus may not move smoothly and can cause

unpredictable results when used. If your stylus exhibits

these problems, replace the stylus by contacting your

reseller.

Getting Started

Calibrating the Screen for the First Time

When you power on your MPx Pocket PC Phone for the

first time:

Recalibrating the Screen

Recalibrating the screen may be required in these

situations:

•

You use the stylus differently (for example, with the

opposite hand) than whoever used the phone last.

•

The screen has not been recalibrated for a long time.

If the phone fails to respond appropriately when you

tap an item, the phone has lost calibration.

To recalibrate the screen:

Action

Using your stylus, tap the

center of the cross as it

moves around the screen.

Action

Using your stylus, tap

Start

Settings

Select the

System

tab.

Ta p t he

Screen

item.

Getting Started

Making a Call

Ta p t he

Align Screen

button.

Using your stylus, tap the

center of the cross as it

moves around the screen.

Action

On the phone’s keypad, press the number keys to

enter the number you want to call.

Note:

Make sure the

phone is set to

Symbolic input mode

. (Press [Fn] +

[Shift] to change between Symbolic and Alpha

input mode .)

Press the button.

Action

Getting Started

Answering an Incoming Call

Tip:

If you receive an incoming call when the flip is closed,

you can also press the right button to reject the call.

Ending a Call

Press To

Answer

/ answer the call

Ignore

/ reject the call

Action

Press .

Tap

End

Learning to Use Your MPx Pocket PC Phone

Learning to Use Your

MPx Pocket PC Phone

Using Your Phone’s Menus and

Features

The Today Screen

When you turn on your MPx which is the standard

display. The Today screen contains important information

of your device, including today’s appointments and status

icons. Tap the information listed on the Today screen to

open the associated program, you see the Today screen.

This is the standard display you see when you are not on a

call or using the menu. The Today screen displays

important information about your phone, including today’s

appointments and status icons.

Learning to Use Your MPx Pocket PC Phone

The following status indicators can display:

The Command Bar

At the bottom of the screen is the

Command

bar with menus

and buttons you can use to perform tasks in programs.

Status

Icon

Description

System sound is on/off. To switch the

sound mode, tap the icon and select

from the 3 options:

Vibrate

, and

Off

The main battery is low or very low.

Current input mode is

Symbolic mode

Alpha mode

The connection to your mobile phone

service provider is on or off, and the

strength of the signal.

1 or more instant messages has been

received.

1 or more e-mail, SMS, or MMS

messages has been received.

Internet (GPRS) Connection is active.

Server synchronization is occurring.

Learning to Use Your MPx Pocket PC Phone

Depending upon which program you are using, the buttons

may vary from those shown.

The Start Menu

The

Start

menu allows you to select programs for use,

access settings, or open Help topics. To display the

Start

Menu, tap

Start

from the top of any screen.

Learning to Use Your MPx Pocket PC Phone

Pop-up Menus

Pop-menus allow you to quickly perform an action on an

item. For example, you can use a pop-up menu to delete or

make a copy of an item.

To access a pop-up menu, tap and hold (continue

touching) the item on which you want to perform the action

or use the “pop-up menu” button on the keyboard. When

the menu appears, tap the action you want to perform, or

tap anywhere outside the menu to close the menu without

performing an action.

Learning to Use Your MPx Pocket PC Phone

The Keypad

Your phone contains a keypad with the full functionality of a

computer keyboard.

Typewriter Keys

Use the typewriter keys to enter letters and numbers.

Game Pad

Use the Game Pad to:

•

scroll up, down, left, or right through the menu system

•

highlight menu items—press the

Center

button to

select a highlighted menu item

•

change feature settings

•

play games

•

move the cursor during text entry

Easy

Access

Buttons

Ty p e w r i t e r

Keys

Easy

Access

Buttons

Game Pad

Easy

Access

Buttons

Learning to Use Your MPx Pocket PC Phone

Easy Access Buttons

Entering Information

You can enter information into your MPx Pocket PC phone

in the following ways:

Press To

Start

open the

Start

Inbox

launch the messaging function

display a shortcut menu with

control options for the selected item

Camera

activate the camera

cancel the current option

Talk

make and answer calls, view

recently dialed calls list

Voice Dial

use voice dialing

Contacts

open the

Contacts

folder

Power/End

turn the phone on and off, suspend

the device, end calls, and exit menu

system

Entry Method Description

Typing

Type with the keypad/Input

panel.

Learning to Use Your MPx Pocket PC Phone

Entering Text with the Typewriter Keys

You can type letters and numbers on the keypad just as

you would on a typical computer keyboard. Use the 4-way

navigation keys on the Game Pad to move the cursor as

you type.

A 12-key numeric keypad is embedded in the keypad. To

enter a number, press and hold [Fn], then press the

desired digit(s).

Writing

Write directly on the screen

with the stylus.

Drawing

Draw directly on the screen

with the stylus.

Recording

Use the microphone to record

a spoken message or note.

Synchronizing

Use Microsoft ActiveSync to

exchange or copy information

between your PC and device.

Entry Method Description

Move the cursor

up for one line.

Move the cursor

down for one line.

Game Pad (Landscape Mode)

Move the cursor left

for one space.

Move the cursor

right for one space.

Learning to Use Your MPx Pocket PC Phone

The following table lists all special keys and their functions:

Entering Text with the Input Panel

To show or hide the selected input method, tap on

the command bar. To select a different input panel, tap

the arrow and then tap the input panel that you want.

When you use the input panel, your device anticipates the

word you are typing or writing and displays it above the

input panel. When you tap the displayed word, it is inserted

into your text at the insertion point. The more you use your

device, the more words it learns to anticipate.

Press To

[Fn] toggle between letters and numbers

[shift] toggle between uppercase and lowercase

[tab] insert a tab

Learning to Use Your MPx Pocket PC Phone

To type with the soft keyboard:

Action

Tap the arrow beside the

Input Panel

button, then tap

Keyboard

Enter text by tapping the appropriate characters.

To type a single uppercase letter or symbol, tap the

Shift key. To tap multiple uppercase letters or

symbols, tap the CAP key.

For uppercase, tap and hold the stylus on a key, then

drag up.

To add a space, tap and hold any key, then drag the

stylus to the right across at least 2 others.

To backspace 1 character, tap and hold any key, then

drag the stylus to the left across at least 2 others.

To insert a carriage return, tap and hold the stylus

anywhere on the keyboard and drag down.

Learning to Use Your MPx Pocket PC Phone

Writing on the Screen

In any program that accepts writing, such as

Notes

, the

Notes

tab in

Calendar

Contacts

, and

Tasks

, you can use your

stylus to write directly on the screen, just as you write on

paper. You can edit and format what you have written and

convert the information to text at a later time.

Entering New Text

Note:

Some programs that accept writing may not have

the pen button. See the documentation for that program to

find out how to switch to writing mode.

Editing or Formatting Text

To edit or format writing.

Action

ap the pen button to

enter writing mode.

Your phone displays lines

to help you write.

Use the stylus to write directly on the screen.

Learning to Use Your MPx Pocket PC Phone

If you accidentally write on the screen, tap

Tools

, then tap

Undo

, and try again.

You can also select text by tapping

the pen button to exit writing

mode, then dragging the stylus

across the screen.

Drawing on the Screen

When you enter writing mode, you can create a drawing

instead of writing text.

Action

Tap and hold the stylus beside the text you want to

select until the insertion point appears.

Without lifting the stylus, drag it across the text you

want to select.

To cut, copy, or paste the text, tap and hold the

selected text, then tap the desired editing command

on the pop-up menu.

Tap the desired editing command on the

Edit

menu.

Learning to Use Your MPx Pocket PC Phone

Creating a Drawing

Action

Tap the pen button to enter writing mode.

Your phone displays several horizontal lines.

With 1st stroke of

your stylus, cross 3

ruled lines.

A drawing box

appears.

Note:

A stylus stroke

that does not cross 3

ruled lines is entered

as writing.

Use your stylus to create the drawing inside the

drawing box. (All subsequent strokes inside the

box or touching it become part of the drawing.)

Learning to Use Your MPx Pocket PC Phone

Editing or Formatting a Drawing

Tip:

To change the zoom level, tap

Tools

, then select a

zoom level.

Action

Tap and hold the stylus on the drawing until the

selection handle appears.

To select multiple drawings, deselect the pen button,

then drag to select the drawings you want.

To cut, copy, or paste the

drawing, tap and hold it, then

select the desired editing

command on the pop-up menu.

Tap the desired editing

command on the

Edit

menu.

To resize the drawing, tap the

pen button , then drag a selection handle.

Learning to Use Your MPx Pocket PC Phone

Adjusting Phone Volume

Adjusting System Volume

You can adjust the volume of system notifications, such as

the sound you hear when you tap on program names and

menu options.

Changing Ringer Volume

Action

Tap the icon.

Move the system volume slider

to the desired volume level.

Action

Tap the icon.

Move the ringer volume slider

to the desired volume level.

Learning to Use Your MPx Pocket PC Phone

Muting the Sound

To mute system sounds or phone ringer, or to activate

vibrate mode:

Tip:

You can adjust phone earpiece volume only during a

call. Adjusting the volume at another time affects the ring

and notification levels.

Action

Tap the icon.

To turn off the volume, select

Off

To activate vibrate mode, select

Vibration

Learning to Use Your MPx Pocket PC Phone

Using the External Display

When your phone is turned on and the flip is closed, the

external display shows the phone status, including battery

and network signal status. It also shows the time. When

you receive an incoming call, the external display shows

the caller's number or name. To answer the incoming call,

open the flip.

Note:

A caller's name appears on the external display

only if the caller's number matches an entry in your

phonebook.

Checking Your Phone

Connection

Your MPx Pocket PC Phone is set to establish an

automatic mobile phone connection to your service

provider’s network.

The icon indicates that you are connected to the

network of your service provider's network. A full strength

signal is indicated by the icon. As the strength of the

signal diminishes so will the number of vertical bars in the

icon, with no bars indicating no signal.

Learning to Use Your MPx Pocket PC Phone

Setting Your Phone to Flight

Mode

To turn off your wireless connection to your operator’s

network, you can set your phone connection to

Flight

mode.

You can turn on/off

Flight

mode without turning off your

IN MANY COUNTRIES YOU ARE

REQUIRED BY LAW TO TURN OFF

YOUR PHONE WHEN YOU FLY.

TURNING OFF YOUR POCKET PC

DOESN’T TURN OFF YOUR PHONE;

YOU MUST TURN

THE FLIGHT MODE

IN ORDER TO DISCONNECT THE

WIRELESS CONNECTION TO YOUR

OPERATOR’S NETWORK.

Learning to Use Your MPx Pocket PC Phone

phone. This feature enables you to continue using other

programs on your MPx Pocket PC Phone.

To receive calls when your Pocket PC Phone is turned off,

leave the

Turn on flight mode

Using a Headset

If you use a headset or similar device with your phone,

your phone will send incoming sound to the headset only.

Using a Remote PTT Button

If you are using a headset or other accessory with a

remote push-to-talk (PTT) button, you can use the remote

PTT button to answer calls, switch between calls, and end

calls.

Action

While using any program on your MPx Pocket

PC Phone, tap in the title bar at the top of the

display.

In the pop-up menu, tap

Turn on flight mode

Turn

off flight mode

Learning to Use Your MPx Pocket PC Phone

Programs

The following is a partial list of programs available on your

MPx Pocket PC Phone.

Icon Program Description

ActiveSync

Synchronize information

between your device and

desktop computer.

Calendar

Keeps track of

appointments, creates

meeting requests.

Contacts

Keep track of your friends

and colleagues.

Messaging

Send and receive e-mail/

SMS/MMS messages.

Pocket Internet

Explorer

Browse Web and WAP

sites, download new

programs and files from the

Internet.

Notes

Create handwritten or typed

notes, drawings, and

recordings.

Phone

Make and receive calls,

switch between calls, set up

conference calling.

Tasks

Keep track of your tasks.

Windows Media

Player

Enable multimedia function.

Learning to Use Your MPx Pocket PC Phone

Check the Pocket PC Companion CD for additional

programs that you can install onto your device.

You can switch 1 program to another by selecting it from

Start

menu. To access more programs, tap

Start

Programs

, and then tap the desired program icon.

Pocket Excel

Create new workbooks,

view and edit Excel

workbooks created on your

desktop computer.

MSN Messenger

Send and receive instant

messages with MSN

Messenger contacts.

Pocket Word

Create new documents,

view and edit Word

documents created on your

desktop computer.

Camera

Take new photos, view

photos and send them via

MMS to friends.

Calculator

Perform basic arithmetic.

SIM Manager

Collect, organize, sort

Contacts

list stored in your

SIM card.

Icon Program Description

Learning to Use Your MPx Pocket PC Phone

Using the External Display

When your phone is turned on and the flip is closed, the

external display shows the phone status, including battery

and network signal status. It also shows the time. When

you receive an incoming call, the external display shows

the caller's number or name. To answer the incoming call,

open the flip.

Note:

To see a caller's name on the external display,

the caller's number must match an entry in your

phonebook External Display

The external display allows you to open and control

some programs quickly by using the control buttons at the

bottom of the external display.

Learning to Use Your MPx Pocket PC Phone

External Display Components

Main Screen

The following table lists the icons that may appear on the

main screen of the external display.

Icon Meaning

No radio signal

Flight mode

Searching radio signal

Radio signal strength

New message

Battery status

Roaming

Keylock enabled

Silent

Vibrate

Vibrate then ring

Ring loud (Ringer volume 3

Ring soft (Ringer volume < 3)

Learning to Use Your MPx Pocket PC Phone

Control Buttons and Command Bar

There are three control buttons located below the main

screen of the external display. Each of the control buttons

performs the command displayed in the command bar at

the bottom of the main screen.

To display the command bar, press the

button located

in the middle of the control buttons. The following table

displays the common buttons and their meanings.

Easy Program Operations

Through the external display and the control buttons, you

can easily use the some programs, including Profiles, MP3

Player, Voice Notes, Wallpaper, Ring Tones and Exit.

Press the button, then the button to select a

program, and then press the button to open the

selected program.

Icon Meaning

Menu/Select

Apply

Learning to Use Your MPx Pocket PC Phone

The following table displays the icons and meanings of

these programs.

Profiles

You can change the profile of your MPx Pocket PC Phone

in the Profiles program.

Ring Tones

You can change the ring tone of your MPx Pocket PC

Phone in the Ring Tones program.

Icon Program

Profiles

MP3 Player

Voice Notes

Wallpaper

Ring Tones

Learning to Use Your MPx Pocket PC Phone

MP3 Player

The following table displays the available buttons for use in

the MP3 Player program.

Icon Meaning

Play

Pause

Stop

Volume

Volume Up

Volume Down

Exit

Learning to Use Your MPx Pocket PC Phone

Voice Notes

The following table displays the available buttons for use in

the Voice Notes program.

Icon Meaning

Record

Exit

Stop

Delete

Pause

Recording

Playback

Setting Up Your Phone

Device Settings

You can adjust device settings to suit the way you work.

Action

Ta p

Start

Settings

Ta p

Personal

System

. You will see displayed icons

representing settings that can be adjusted.

Setting Up Your Phone

Personal Tab

System Tab

Icon Program

Description

Buttons

Assign an application to

hardware button.

Input

Set up the input options.

Menus

Customize items in

Start

menu, enable access to items

from

New

button.

Owner

Information

Display personal information.

Password

Limit access to device.

Phone

Configure phone functions.

Sounds and

notifications

Set up notification type,

event, and volume.

Today

Customize

Today

screen

appearance.

Icon Program

Description

About

Display important device

information.

Certificates

Display name of certificate

issuer and expiration date.

Setting Up Your Phone

CLI

Provides adjustments for

settings on the external

display.

Clock & Alarms

Change time, set alarms.

Memory

Display memory allocation

status and current running

programs.

Power

Displays battery life.

Profiles

Displays a selectin of audio

settings called profiles.

Regional

Settings

Customize region and

relative format for region you

use.

Remove

Programs

Create more memory by

removing programs.

Screen

Re-calibrate screen, enable/

disable

lear Type

Screen light

Customize backlight and

brightness to save power.

System

Viewer

Find information about

version, hardware, and

system.

Icon Program

Description

Calling Features

The Dialer Screen

To access the

Dialer

screen, tap

Start

Phone

, or press

the button.

From this screen, you can access

Call History

Speed Dial

and

Phone Setting

. This screen also includes signal

status information and important icons that tell you

about signal strength:

•

last number details are displayed here.

•

keypad for entering information

•

task bar to access phone setting

•

history iinformation. ncluding all received, dialed and

missed calls

•

frequently-called numbers

Calling Features

Making a Call

Your MPx Pocket PC Phone provides you with several

ways to make a call:

•

keypad (see x)

•

Dialer screen

•

Call History

•

Contacts

•

Speed Dial

•

SIM Manager

•

Voice Command

Calling Features

Calling from the Dialer

Action

Press to display

the

Dialer

screen.

Tap the number on the

Dialer

keypad.

Tip:

If you tap a wrong

number, tap the backspace

button to erase

individual numbers 1 at a

time. You can also delete all

the numbers in the window

by tapping

Edit

, then

Clear

Tap or press the button.

Calling Features

Calling from Call History

You can quickly call someone you have recently called or

someone who has recently called you.

Action

From the

Dialer

keypad,

tap

Call History

View call details by selecting the category under

which it is filed.

For example, if th desired call is in

All calls

, select

All calls

from the drop down menu.

Scroll to the number, then press the button

or the icon to the left of the number.

Calling Features

Calling from Contacts

You can make a call from

Contacts

without having to look up

or manually enter the number.

Calling from Speed Dial

Speed dials function allows you to call frequently-used

numbers with a single tap.

Action

Press the

Contacts

button

on the phone’s keypad.

Ta p

Start

and select

Contacts

From the

Contacts

list, tap and hold the contact.

On the popup window, tap

Call Work

Call Home

, or

Call

Mobile

Tap the number you want to call.

Calling Features

Note:

Before you can create a speed dial entry for a phone

number, that number must already exist in

Contacts

Tip:

You can dial a contact with a 1-

digit speed dial number directly

from the keypad on the screen by

pressing and holding the 1-digit

number.

For example, to dial the number at

location number 3, tap and hold 3

on the dialer keypad.

Note:

To dial a 2-digit speed dial

number from the keypad, tap the 1st digit, then tap and

hold the 2nd digit.

Action

From the

Dialer

keypad, tap

Speed Dial

From the

Contacts

list, tap and hold the contact.

On the popup window, tap

Call Work

Call Home

, or

Call

Mobile

Select the speed dial location number of the

desired contact.

Calling Features

Calling from SIM Manager

Using Voice Command

Your MPx Pocket PC Phone provides an innovative and

intelligent method to enter your phone number:

Voice

Command

. For instructions on using

Voice Command

, see xx.

Taking a Note during a Call

You can take a note during an active call. When you finish

the note, your phone saves it as an attachment to your call

in the appropriate Call History folder.

Action

Ta p

Start

Programs

Select

SIM Manager

Tap and hold the name or phone number of the

person you wish to call.

Select

Call

from the pop-up menu.

Calling Features

To take a note:

To access a note you created during a call:

Action

Tap the icon at the bottom of the screen.

Enter the note.

Action

From the

Dialer

keypad, tap

Call History

Select the list where the call is filed.

Tap and hold the name or number of the call that

includes the note.

Ta p

View Note

Calling Features

Tip:

You can also access the note directly from

Notes

in the

Calls

folder.

Putting a Call on Hold

Your device will notify you when you

have another incoming call. If you

accept the call, tap

Answer

to take the

second call and put the first on hold.

To end up the second call and go back to the first call, tap

End or press .

You can also choose to swap

between the two calls by tapping

Swap

Setting Up a Conference Call.

You can create a three-way phone session between

yourself and two other parties. A conference call can

include up to six people.

Calling Features

From the Phone keypad, dial the

first number, tap

Hold

, dial the

second number, and then tap

Conference

You can also set up a

conference call by accepting

2nd incoming call when you

already have one in progress.

To add additional people to your conference call, tap

Hold

, key in the number, and then

Resume

to return and

continue.

Managing Your Contacts

You can either import the contacts from your

SIM

card or

the

Call History

SIM Manager

To open SIM manager, tap

Start

Programs

SIM

Manager

. Wait for your SIM card contents to load.

Calling Features

Creating a SIM contact:

Action

After the SIM contacts complete loading, tap

New

Fill in the Name and

Phone information then

tap

Add

Calling Features

Saving contacts from SIM to Contacts:

On SIM Manager screen, tap

Tools

Select All

> and then

Save to Contacts

Tap and hold a contact from the list,

and then select

Save to Contacts

from

the pop-up menu.

Calling Features

Saving personal numbers:

You can save your personal phone numbers in a separate

screen in

SIM Manager

Action

Ta p

Start

Programs

SIM Manager

Tools

, and then

select

List of Own Numbers

Add a number to the screen

and then press

Calling Features

Call History

From the Dialer's keypad, tap

Call

History

to open Call History. It details

all incoming, outgoing, and missed

calls.

Adding a record to Contacts from Call History:

Tip:

The call details in the Call History will then be

amended and displayed under the name of the contact, not

their telephone number.

Action

Find the call record you

want to add in the Contacts.

Using the stylus, tap and hold the item to bring

up the pop-up menu, and select Save to

Contacts

You can add additional contact details in the

Save to

Contacts

screen.

Calling Features

Viewing duration of a Call:

Deleting individual calls from Call History:

Deleting all calls from Call History:

Setting limits on the size of your Call History:

Action

In Call History screen, find the call you are looking

in, and then tap it once.

Action

Using the stylus, tap and hold on the call you want to

delete, and then select

Delete

from the pop-up menu.

Action

Ta p

Tools

Delete all Calls

Action

Ta p

Call History

Call Timers

and then the box under

Delete call history items older than

. In the drop down

menu select a time period then press

Calling Features

Additional Dialing Information

Calling an Emergency Number

Your service provider programs one or more emergency

phone numbers, such as

911

, that you can call under any

circumstances, even when your phone is locked or the SIM

card is not inserted.

Action

Enter the international

emergency number, and

then tap or press

button.

Notes:

Emergency numbers

vary by country. Your phone's

preprogrammed emergency

number(s) may not work in all locations, and

sometimes an emergency call cannot be placed due

to network, environmental, or interference issues.

Calling Features

Dialing International Numbers:

Action

Tap and hold the key until the

sign

appears. The

replaces the international prefix

of the country of where you are calling.

Enter the full phone number you want to dial. It

includes country code, area code (without the

leading zero) and phone number.

Tap or press button.

Messaging Features

You can receive Internet e-mail messages and SMS

messages in Inbox. Internet e-mail messages are sent by

using an address you receive from your Internet service

provider (ISP) or your employer. SMS messages are sent

and received through your wireless phone service provider

by using a phone number as the message address.

Email Messages

You can use Inbox to send and receive e-mail messages in

either of these ways:

•

Synchronize e-mail messages with Microsoft

Exchange or Microsoft Outlook on your PC.

•

Send and receive e-mail messages by connecting

directly to an e-mail server through an Internet

Service Provider (ISP) or a network.

Setting Up an Email Service

Open

Inbox

, tap

Accounts

, and then

New Account

Enter your email address and then tap

Then

Auto-configuration

will attempt to connect to

the e-mail server and configure the necessary e-

mail settings automatically.

Enter an unique name for the account,

User name

and

Password

, then tap

Messaging Features

Note:

•

If auto-configuration is not successful, you need to

manually enter the settings.

•

For more explanation, tap

Start

Help

Synchronizing Email Messages

E-mail messages can be synchronized as part of the

general synchronization process. You will need to enable

Inbox synchronization in

ActiveSync

. For information on

enabling

Inbox

synchronization, see

ActiveSync Help

on the

PC.

During synchronization:

•

Messages are copied from the Inbox folder on your

PC or Exchange server to the Inbox folder on your

device. When synchronizing Inbox with your PC,

ActiveSync synchronizes the first .5 KB of each new

message sent to you within the last three days each

time you synchronize. When synchronizing Inbox

with a server, ActiveSync synchronizes the first

500 bytes of each new message.

In the

Account type

, tap POP3 or IMAP4. (POP3 is

the most common mail protocol for ISPs.)

Enter your ISP's e-mail server name of

Incoming

mail

and

Outgoing mail

, then tap

Finish

Connect to your email server by tapping

Accounts

Connect

Messaging Features

•

Messages in the

Outbox

folder on your device are

transferred to Exchange or Outlook and then sent

from those programs.

•

The messages on the two computers are linked.

When you delete a message on your device, it's

deleted from your PC the next time you synchronize.

•

Messages in subfolders or other e-mail folders in

Outlook should be selected in

ActiveSync

for

synchronization.

Using the Message List

Messages you receive are

displayed in the message list. By

default, the most recently

received messages are displayed

first in the list.

Messaging Features

When you receive a message,

tap it to open it. Unread

messages are displayed in bold.

You can mark the messages that you want to retrieve in full

during your next synchronization or e-mail server

connection. In the message list, tap and hold the message

you want to retrieve. On the pop-up menu, tap

Mark for

Download

. The icons in the Inbox message list give you

visual indications of message status.

You specify your downloading preferences when you set

up the account or select your synchronization options. You

can change them at any time:

•

Change options for Inbox synchronization using

ActiveSync options. For more information, see

ActiveSync Help

•

Change options for direct e-mail server connections in

Inbox on your device. Tap

Tools

and then tap

Options

On the

Account

tab, tap the account you want to

change. Tap and hold the account and select

Delete

to remove an account.

Messaging Features

Composing an Email Messages

Action

In the message list, tap

New

In the

field, enter the e-mail address of one or

more recipients, separating them with a

semicolon, or select a name from the contact list

by tapping the

Address Book

button. All e-mail

addresses entered in the e-mail fields in

Contacts appear in the Address Book.

Compose your message. To enter preset or

frequently used messages, tap

My Text

and

select a message.

Tap Send when you've finished the message. If

you are working offline, the message is moved to

the Outbox folder and will be sent the next time

you connect. If you are working online, it is sent

immediately.

Messaging Features

Managing Messages and Folders

Each email, SMS and MMS account has its own folder

hierarchy with five default folders:

Inbox

Outbox

Deleted

Items,

Drafts

, and

Sent Items

. The messages you receive

and send through the service account are stored in these

folders. You can also create additional folders within each

hierarchy.

SMS Messages

You can send an SMS Message from Inbox or from Phone

dialer screen. All the SMS messages received will be

stored in the Inbox.

Sending SMS

Find the Feature

•

In the

Inbox

, open a new email message and select

SMS

account in the

Account

type options.

•

In the Phone dialer screen, tap

Tools

Send SMS

In the

field, enter the SMS number of one or more

recipients, using “;” to separate them. Or select a contact

by tapping the

Address Book

button.

When you have finished the message, tap

Send

. If you are

working offline, the message will be stored in the

Outbox

folder and will be sent when next time you connect.

Messaging Features

MMS Messages

MMS Composer is incorporated into your device's “Inbox,”

which can be accessed either from the Start menu or the

Today screen. Once the Inbox is open, you can access

your MMS message boxes from the top-left pull-down:

Exiting MMS Composer

To quit, tap the “

” in the top-

right corner of the screen while

viewing any message box.

Message Boxes

Use the pull-down to select the

MMS message box that you

wish to view:

Entry Method Description

Deleted Items

Contains messages you've discarded.

Drafts

Stores work-in-progress messages.

Inbox

Stores messages that you receive.

Outbox

Stores messages that are currently

being sent, or those that were unable

to be sent.

Sent

Stores messages that have been

successfully sent.

Messaging Features

Creating a Message

Messages are created by combining various slides. Each

slide can consist of a photo or video, audio, and text.

Select “New” from the menu of any message box screen to

compose a new message*. Follow this procedure to create

a new message:

Note:

You may not automatically be taken to a blank

message. If you are instead taken to a page that displays

Action

When you’re ready to

send your message,

tap here.

Here you can enter your recipients and subject.

Tap the double down arrow to view the Cc and

Bcc fields.

Tap here to insert a photo or video.

Tap here to input a text message.

Tap here to include an audio clip.

The menu lets you do a number of things, such

as preview and organize your message.

Messaging Features

pre-made templates, choose the template you want. If you

would prefer to create a blank message next time, check

the “Always choose custom” box.

Adding a Photo or Video

You can add either a still image or a video clip to each

individual slide. After you’ve tapped the area to add a

photo or video, you'll be allowed to select exactly what you

want to include.

Tap and hold on a file to see the “File Info” and “Delete”

options. “File Info” displays the file name, resolution,

date, and size of a photo. When viewing video file

information, the duration of the video is also listed.

Action

This pull-down lets you

select a specific

location that contains

photos/videos.

Choose either “Photos” or “Videos” from this pull-

down. You can only add either a single photo or

video clip to each individual slide.

Tap the specific photo or video clip that you want

to add.

Messaging Features

“Delete” deletes the file.

Adding Text

You can add text to any slide. You can either enter in new

text with the keyboard, or use “canned” text. Canned text

are previously saved words or phrases.

Press To

Adds the selected photo/video to

the slide.

Takes you to the previous screen.

Displays photos/videos as a file list.

Displays thumbnails (as shown

here).

Action

Tap the Canned Text

icon to see a list of

pre-saved text

messages. Tap the

one you want, and

then choose “Select.”

Tap and hold on the

Canned Text screen to view additional options:

New:

Lets you enter in a new canned text message.

Edit:

Lets you modify an existing canned text

message.

Delete:

Removes the selected canned text from the

list.

Messaging Features

Adding Audio

Single audio clips can be added to each slide. You can

either include an existing sound file, or record a new one.

You can view file information similarly to the way you can

with photos and videos. Tap and hold on a file, then

choose “File info” (you can also delete the file). The file

name, duration, date, and size are shown.

You can use the playback controls to preview the audio:

(Play/Pause and Stop controls are available.)

If you're happy with your choice, tap “Select.” Otherwise,

tap “Cancel.”

Action

From the pull-down,

select a location that

contains audio files.

Tap the file you’d like to use.

Messaging Features

MMS Settings

To view and edit your MMS

settings, choose “MMS Settings”

from the “Tools” menu that appears

at the bottom of the screen while

viewing any message box:

Entry Method Description

Connect Via

Select your type of network

connection from the pull-

down.

Retrieve Messages

Immediately

Typically, you receive a

notification whenever a new

message is available.

Checking this box downloads

new messages automatically.

You can also choose to

download messages while

roaming.

Save Sent Messages

Check this option to save a

copy of messages that you

send.

Attempts Before Giving

This value sets the number of

times the program will

attempt to send your

message before stopping.

Messaging Features

The “Servers” tab lists your available servers.

The “About” tab lists various program information.

Viewing Messages

When viewing messages that you receive or send, or when

previewing a message you're working on, you have a

variety of options.

Use the Play/Pause/Stop buttons

to view the message. Use the Left/

Right Arrow buttons to skip among

the various slides (if applicable).

You don't need to see the message

straight through; you can skip

among the various slides.

Photo Resolution

Choose the resolution for

images that you send. You

may want to decrease below

the original resolution to help

the send/receive time.

Entry Method Description

Messaging Features

Tapping “Objects” on the menu

displays a list of all the message

components. Tap any component

to open/view it. From the “Tools”

menu, you can choose to save an

object. You can also view the

component’s file properties.

Personalizing Your MPx

Personalizing Your

MPx

Buttons

To customize the functions of buttons, open the “Buttons”

control panel.

Find the Feature

Start

Settings

Personal

Buttons

Action

Select a button.

Select a program in

Button Assignment

Ta p

Personalizing Your MPx

Input

Find the Feature

Start > Settings > Personal > Input

Note:

You can also change the input options by tapping

the arrow and then Options.

Menus

You can add the programs you use most often to Start

menu.

Action

On the Input Method tab, you can select an input

method and changed preferred options.

On the Word Completion tab, you can select

desired options for word completion.

On the Options tab, you can select preferred

options for recording and writing. These options

apply to any program on the device where you

can record and write.

Personalizing Your MPx

Find the Feature

Start

Settings

Personal

Menus

Owner Information

You can set your owner information using this control

panel.

Find the Feature

Start

Settings

Personal

Owner Information

Action

On the

Start Menu

tab, select the programs you

want, and then tap OK.

On the

New Menu

tab, you can select

Turn on New

button menu

and then select the items to appear

on the menu. When you do this, you can create

certain programs such as Pocket Word, Pocket

Excel, Contacts, Calendar and Tasks by using

the New menu in the command bar.

Action

On the

Identification

tab, enter your personal

information. Select

Show information when device is

turned on

so that if you lose your device, it can be

returned to you.

On the

Notes tab

, enter any additional text you

want to display when the device is turned on,

such as: Reward if found.

Personalizing Your MPx

Password

You can set a power-on password for your device with this

control panel.

Find the Feature

Start

Settings

Personal

Password

Notes:

If your device is configured to connect to a

network, use a strong password to help protect network

security.

Action

To select how long your

mobile device must be

turned off before a

password must be

entered, check

Prompt if

device unused for

Select the type of password you would like to

use. A strong password must have at least

seven

characters that are a combination of uppercase

and lowercase letters, numerals, and

punctuation.

Enter the password and, if necessary, confirm

the password.

Personalizing Your MPx

Sounds and Notifications

To customize the way the device sounds during certain

events, open this control panel.

Find the Feature

Start

Settings

Personal

Sounds and Notifications

Tip:

Turning off sounds and the notification light helps

conserve battery power.

Today

This contorl panel allows you to customize the look of the

Today screen.

Find the Feature

Start

Settings

Personal

Today

Action

On the

Sounds

tab, you can select the actions for

which you want to hear sounds.

On the

Notifications

tab, you can customize how

you are notified about different events. Select the

event name and then select the type of reminder.

You can select a special sound, a message, or a

flashing light.

100

Personalizing Your MPx

Changing the background:

Tip:

Recommend picture size for the background is

240x320 pixels in.jpg file.

Action

On the

Appearance

tab, select

the desired theme for the

background. To use your

own background, select Use

this picture as the

background then tap Browse

to locate the desired file.

Choose a folder and then tap the file you want.

Ta p

101

Personalizing Your MPx

Customizing the information you want displayed:

Tip:

You can select Tasks or Calendar, and then Options to

further customize the information you want displayed.

Action

Uncheck a box to remove its

information.

To change an item's position select it then tap

Move Up

Move Down

To choose how long the

Today

screen is

displayed, select/deselect

Today timeout

, then the

number of hours.

102

Personalizing Your MPx

Power

This control panel allows you to view the status of the

battery and adjust other power settings.

Find the Feature

Start

Settings

System

Power

Phone Settings

You can customize phone settings, such as the ring type

and ring tone to be used for incoming calls, and the keypad

tone to be used when entering phone numbers. You can

also protect your phone from unauthorized use.

Action

The

Power

option displays the amount of battery

power remaining. Battery power depends on the

battery type and how the device is being used.

You can tap

screen light

to enter the

Screen light

option, allowing you to select options for turning

off your device to conserve battery power. To

conserve the most power, select the option that

turns off the device after 3 minutes or less.

103

Personalizing Your MPx

Changing Ring Type

You can change the way that you are notified of incoming

calls. For example, you can choose to be notified by a

ring, a vibration, or a combination of both.

Action

From the Phone keypad, tap

Tools

Options

Phone

tab.

Ta p t he

Ring type

list, and select the desired

option.

104

Personalizing Your MPx

Changing Ring Tone

You can select a different sound to notify you of incoming

calls.

Note:

You can also use

.wav

.mid

, or

.wma

files as ring tones.

Copy the files to the

/Windows/Rings

folder on your device.

Then, select the sound from the

Ring tone

list.

Action

From the Phone keypad, tap

Tools

Options

Phone

tab.

Tap the

Ring tone

list, and select the sound you

want to use.

105

Personalizing Your MPx

Changing Keypad Tone

You can change the tone you hear when entering a phone

number on the keypad. If set to

Tones

, the tone is heard

continuously for as long as the number on the keypad

is pressed. If set to

Beep

, the tone is heard only for one

or two seconds.

Action

From the Phone keypad, tap

Tools

Options

Phone

tab.

Ta p t he

Keypad

list, and select the option you

want.

106

Getting More Out of Your Phone

Getting More Out of

Your Phone

Dialing Options

Fixed Dialing

When you activate the fixed dial feature, users can only

call the number in the fixed dial list.

Note:

Employers can use fixed dial to limit employees'

phones to a predefined list of numbers, country codes, or

other prefixes.

Activating Fixed Dial

Find the Feature

Settings

Security

Fixed Dial

Creating and Calling Fixed Dial Entries

Fixed Dial list entries can be any length. You must enter

your SIM PIN2 code, from your network service provider,

to edit fixed dial entries. To open the fixed dial list:

Find the Feature

Fixed Dial

In the fixed dial list, you can create, edit, delete, and sort

entries just like in the phonebook list. Fixed dial list entries

are stored on your SIM card.

Service Dialing

Dial preprogrammed numbers stored on your SIM card.

Your Service provider can program your SIM card with

107

Getting More Out of Your Phone

phone numbers for services such as taxi companies,

restaurants, and hospitals.

Find the Feature

Service Dial

Managing Your Calls

Calling a number in a Text Message

If you receive a text message with an embedded phone

number, you can dial the number directly.

Find he Feature

Message

Inbox

If the message contains more than 1 phone number, scroll

to the desired number and press

SELECT

to dial.

Monitoring Phone Use

Viewing and Resetting Call Timers

Your phone tracks and records call times. Use the recent

calls menu to view and reset a call timer.

Network connection time is the elapsed time from the

moment you connect to your service provider's network to

the moment you end the call by pressing the

End

key. This

time includes busy signals and ringing.

Action

Scroll to the message with the number.

Tap to open the message.

Tap the response icon and then Call to dial the

number in the message.

108

Getting More Out of Your Phone

The amount of network connection time you track on your

resettable timer may not be equal the amount of time for

which you are billed by your service provider. For billing

information, please contact your service provider directly.

To view a call timer:

Find the Feature

Phone

Call History

Tools

Call

Timers

To reset the call timer, tap Reset.

You can view the approximate network connection time

elapsed during the following calls:

Network Features

Network Selection

Find the Feature

Settings

Other Setting

Network

Your service provider registers your phone to a network.

You can view information about the current network,

change how your phone searches for a network, specify

Timer

Description

All Calls

shows all calls made to and

from the phone in chronological

order.

Missed

only shows calls that were not

answered.

Outgoing

only shows calls made from the

phone.

Incoming

only shows call made to the

phone.

109

Getting More Out of Your Phone

your preferred networks, and activate alerts that indicate

when a call is dropped or network registration changes.

Using ActiveSync

With

Microsoft ActiveSync

on both your PC and mobile

device, you can exchange information between your PC

and your device.

Using ActiveSync, you can:

•

Keep

Pocket Outlook

data up-to-date by

synchronizing your device with

Microsoft Outlook

data on your PC.

•

Change synchronization settings and synchronization

schedule.

•

Copy files between your device and PC.

•

Back up and restore device information.

•

Add and remove programs on your device.

Note:

You can directly synchronize information with a

Microsoft Exchange Server if your company is running

Microsoft Mobile Information Server 2002 or later.

Installing ActiveSync

To synchronize your device with your PC, you must install

ActiveSync on your PC from the Pocket PC Phone 2003

Companion CD.

Creating a Partnership

Once ActiveSync is installed on your PC, you will be

prompted to connect and create a partnership with your

110

Getting More Out of Your Phone

device by using a cable, cradle, or infrared connection.

During this partnership you can decide exactly which types

of information you want to synchronize with your PC and/or

a server.

Your first synchronization will

automatically begin when you

finish using the wizard. After the

first synchronization, you will

notice that your Outlook

information now appears on

your device.

Synchronizing Information

You can synchronize the following types of Outlook

information:

•

Inbox

•

Calendar

•

Contacts

•

Tasks

•

Notes

By default, ActiveSync doesn't automatically synchronize

all types of Outlook information. You can use ActiveSync

options to select what information types you want to

synchronize.

111

Getting More Out of Your Phone

Synchronizing Inbox

When you select Inbox for synchronization in ActiveSync,

e-mail messages are synchronized as part of the general

synchronization process. During synchronization, the

following events occur:

•

Messages are copied from the

Outlook Inbox

folder on

your desktop computer, or from a Microsoft Exchange

Server, to the Inbox folder on your device.

•

By default, when synchronizing

Inbox

information

with your desktop computer, you will receive only

messages from the last three days and the first

500 bytes of each new message. You can also choose

to download file attachments.

•

The messages on your device and on your desktop

computer are linked. When you delete a message

your device, it is deleted from your desktop computer

the next time you synchronize, and vice versa.

•

Messages in subfolders in other e-mail folders in

Outlook

are synchronized only if the folders have been

selected for synchronization in the

Inbox

on your

device.

Synchronizing Calendar

•

Calendar

items stored on your device can be

synchronized with calendar items stored on your

desktop PC and/or on a Microsoft Exchange Server.

By default, calendar items from the last two weeks will

be synchronized.

112

Getting More Out of Your Phone

•

Calendar

items created on your device are copied to

your desktop PC and/or server during

synchronization, and vice versa. Similarly,

Calendar

items that are deleted from your device are deleted

from your desktop computer and/or server during

synchronization, and vice versa. This keeps your

information up-to-date in all locations.

Synchronizing Contacts

•

Contacts

stored on your device can be

synchronized with contacts stored on your desktop

computer or on a Microsoft Exchange Server. By

default, all of your

contacts

will be synchronized.

•

Contacts

created on your device are copied to your

desktop computer and/or server during

synchronization, and vice versa. Similarly,

contacts

that are deleted from your device are deleted from

your desktop computer and/or server during

synchronization, and vice versa. This keeps your

information up-to-date in all locations.

Synchronizing Tasks

•

Tasks

stored on your device can be synchronized with

tasks stored on your desktop computer. Task

synchronization is automatically selected in

ActiveSync

By default, all of your incomplete tasks will be

synchronized.

•

Tasks

created on your device are copied to your

desktop computer during synchronization, and vice

versa. Similarly, tasks that are deleted from your

113

Getting More Out of Your Phone

device are deleted from your desktop computer during

synchronization, and vice versa. This keeps your

information up-to-date in all locations.

Synchronizing Using an

Infrared Connection

You can use an infrared connection to create a direct

connection between your device and another mobile

device or desktop computer quickly. This method is

ideal for quickly switching between multiple devices

since there are no cables or adapters to change. When

creating a partnership, you must connect using infrared, a

cable, or a cradle connection.

Using infrared (IR), you can also send and receive

information, such as contacts and appointments, between

two devices.

Sending information

Switch to the program where you created the

item you want to send and locate the item in the

list.

Align the IR ports so that they are unobstructed

and within close range.

Tap and hold the item, and tap

Beam

Item on the

pop up menu.

114

Getting More Out of Your Phone

ActiveSync Errors

Whenever ActiveSync cannot successfully synchronize

your information, it displays an error on your device.

Notes:

Some types of errors can interfere with automatic

synchronization. If you suspect that a scheduled automatic

synchronization has not occurred, you should attempt to

manually synchronize your information. Successfully

completing manual synchronization will reset automatic

synchronization.

Receiving information

Align the IR ports so that they are unobstructed

and within close range.

Have the owner of the other device send the

information to you. Your device will automatically

receive it.

To view ActiveSync error information

Press the Action button when the error text is

displayed. ActiveSync will then display more

information about the error that occurred.

115

Getting More Out of Your Phone

Services

Service settings are used to set options for incoming/or

outgoing calls, such as

Call Waiting

Call Forwarding

Call

Barring

, and

Caller ID

From the Phone keypad, tap

Tools

Options

Services

tab.

Select a service and then tap

Get Settings

to access the

settings for a service.

Option

Description

Call Waiting Notifies you of incoming calls when you

are already in a phone session. Keep

with reset of chart.

Call

Forwarding

Forwards all

incoming calls to a

different number.

Call Barring Blocks certain types of incoming and/

or outgoing calls.

Caller ID Shows or hides your identity when

calling other people

116

Getting More Out of Your Phone

Network

You can view available networks, determine the order in

which your phone accesses another network if the current

one is unavailable, and specify whether you want to

change networks manually or automatically. The current

network will remain active until you change it, lose your

signal, or change your SIM card.

Find the Feature

From the Phone keypad,

tap

Tools

Options

Network tab

Action

The network your device is currently using will be

listed at the top of the screen.

When your current network is unavailable, tap

Select Network

, and manually select a different

network to use.

117

Personal Organizer Features

Personal Organizer

Features

Alarm Clock

Find the Feature

Alarm Set

Note:

Your phone must be powered

in order for any

alarm that you may have set to be activated.

Press

1>select

[New Alarm]

create/edit alarm item

Alarm content list:

Name :

Time:

Alert:

Volume:

2>EDIT

same as above

3>DELECT

delete 1 alarm item

4>DELECT

ALL

delete all alarm items

118

Personal Organizer Features

Calculator

Find the Feature

Calculator

Converting Currency

Find the Feature

Calculator

Currency Rate

Using the Stop Watch

Your phone provides you with a Stop Watch, allowing you

to count the time.

Find the Feature

Stop Watch

Press

number

keys enter a number in the calculator

highlight a calculator function

3Select

perform the highlighted function

Press

number

keys enter the exchange rate

2OK

store the exchange rate

Press

1Start

start counting the time

2Stop

stop counting the time

3Reset

reset the Stop Watch

119

Security

Setting PIN

You can protect your phone from unauthorized use by

assigning a type of password called a PIN (Personal

Identification Number). Your first PIN will be given to you

by your mobile phone service provider.

Note:

Emergency calls can be placed at any time, without

requiring a PIN.

Locking and Unlocking Your

Phone

You can look your phone manually or set your phone to

lock automatically whenever you turn it off.

When you try to use a locked phone, it asks you to enter

the unlock code. A locked phone still rings or vibrates for

incoming calls or messages, but you must unlock it to

answer.

Action

From the Phone keypad, tap

Tools

Options

Phone

tab.

Select

Require PIN

when phone is used

To change the PIN at any time, tap

Change PIN

120

Security

You can make emergency call on your phone even when it

is locked.

Lock your Phone Manually

Find the Feature

Settings

Security

Phone Lock

Lock Now

Set Your Phone to Lock Automatically

Find the Feature

Settings

Security

Phone Lock

Auto Lock

Press

keypad keys enter your 4-digit unlock code

2OK

lock the phone

Press

keypad keys enter your 4-digit unlock code

2OK

set the phone to lock

automatically

121

Security

Unlock Your Phone

Changing Your Unlock Code

Find the Feature

Settings

Security

New

Passwords

Press

keypad keys enter your 4-digit unlock code

The unlock code is originally set

to 1234.

2OK

unlock your phone

Press

scroll to the code or password

you want to change

3Change

select the code or password

keypad keys enter your old code

5OK

submit your old code

keypad Keys enter the new code

7OK

assign the new code

keypad keys re-enter the new code

9OK

confirm the new code

122

Security

If you forget a code or password

Protecting the SIM Card

Find the Feature

Settings

Security

SIM PIN

Unlock the SIM card PIN Code

Press

go to the unlock code bypass

screen

keypad keys enter your security code

3OK

submit your security code

Press

open the PIN unblocking editor

keypad keys enter the PIN code

3OK

submit the PIN code

keypad keys enter a new SIM card PIN code

5OK

assign the new SIM PIN code

keypad keys re-enter your SIM card PIN code

7OK

confirm the new SIM PIN code

and unblock the SIM card

123

Microsoft Pocket Outlook

Microsoft Pocket

Outlook

Microsoft Pocket Outlook includes

Calendar

Contacts

Tasks

Inbox

, and

Notes

.You can use these programs individually or

together. For example, e-mail addresses stored in

Contacts can be used to address e-mail messages in

Inbox.

Using ActiveSync

, you can synchronize information in

Microsoft Outlook or Microsoft Exchange on your desktop

computer with your device. You can also synchronize this

information directly with a Microsoft Exchange server.

Each time you synchronize, ActiveSync compares the

changes you made on your device and PC or server and

updates both computers with the latest information.

For information on using ActiveSync, see ActiveSync Help

on the PC.

124

Microsoft Pocket Outlook

Calendar: Scheduling

Appointments and Meetings

Use Calendar to schedule

appointments, including meetings

and other events. You can check

your appointments in one of several

views (Agenda, Day, Week, Month,

and Year) and set Calendar to

remind you of appointments with a

sound or other method.

Note:

You can customize the

Calendar display, such as changing

the first day of the week, by tapping

Options

on the

Tools

menu.

To create an appointment:

Action

If you are in Day or Week

view, tap the desired date

and time for the

appointment.

Ta p

New

Using the input panel, enter a description and a

location. Tap

first

to select the field.

125

Microsoft Pocket Outlook

Tip:

If you select Remind me in an appointment, your

device will remind you according to the options set in

Start

Settings

Personal tab

Sounds & Notifications

Using the Summary Screen

When you tap an appointment in

Calendar, a summary screen is

displayed. To change the

appointment, tap

Edit

Creating Meeting Requests

You can use Calendar to set up meetings with users of

Outlook or Pocket Outlook. The meeting request will be

created automatically and sent either when you

synchronize Inbox or when you connect to your e-mail

server. Indicate how you want meeting requests sent by

If needed, tap the date and time to change them.

Enter other desired information. You will need to

hide the input panel to see all available fields.

To add notes, tap the Notes tab. You can enter

text, draw, or create a recording. For more

information on creating notes, see “Notes:

Capturing Thoughts and Ideas,” later in this

chapter.

When finished, tap

to return to the calendar.

126

Microsoft Pocket Outlook

tapping

Tools

and then Options. If you send and receive e-

mail messages through ActiveSync, select

ActiveSync

To schedule a meeting:

Contacts: Tracking Friends and

Colleagues

Contacts maintains a list of your

friends and colleagues so that you

can easily find the information you're

looking for, whether you're at home or

on the road. Using the device infrared

(IR) port, you can quickly share

Contacts information with other

device users.

Note:

To change the way

information is displayed in the list, tap

Tools

and then

Options

Action

Create an appointment by tapping New.

In the appointment details, hide the input panel,

and then tap Attendees.

From the list of e-mail addresses you've entered

in Contacts, select the meeting attendees.

The meeting notice is created automatically and

placed in the Outbox folder. For more information

on sending and receiving meeting requests, see

Calendar Help and Inbox Help on the device.

127

Microsoft Pocket Outlook

To create a contact

Ta p

New

Using the input panel, enter a name and other

contact information. You will need to scroll down

to see all available fields.

To assign the contact to a category, scroll to and

tap Categories and select a category from the

list. In the contact list, you can display contact by

category.

To add notes, tap the Notes tab. You can enter

text, draw, or create a recording. For more

information on creating notes, see “Notes:

Capturing Thoughts and Ideas,” later in this

chapter.

When finished, tap OK to return to the contact

list.

128

Microsoft Pocket Outlook

Finding a contact

There are 4 ways to find a contact:

Action

Ta p

Start

Contact

, then

Find

enter

the contact

name (first, last, or middle), phone number, or

address, select

Contacts

for the type, and then tap

From Contacts, start typing a contact name until

you see it displayed on the screen. To show all

contacts again, tap the text box at the top of the

screen and clear the text, or tap the arrow icon to

the right of the text box.

In the contact list, tap the category list (labeled

All Contacts

by default) and tap the category to

which you’ve assigned a contact. To show all

contacts again, select

All Contacts

To view the names of companies your contacts

work for, in the contact list, tap

View

By Company

The number of contacts that work for that

company will be displayed to the right of the

company name.

129

Microsoft Pocket Outlook

Using the Summary Screen

When you tap a contact in the

contact list, a summary screen is

displayed. To change the contact

information, tap

Edit

Tasks: Keeping a To Do List

Use Tasks to keep track of things

you need to do.

Note:

To change the way

information is displayed in the list,

tap

Tools

and then

Options

130

Microsoft Pocket Outlook

To create a task:

Note:

To quickly create a task with only a subject, tap

Entry Bar

on the

Tools

menu. Then, tap

Tap here to add a new

task

and enter your task information.

Action

Ta p

New

Using the input panel, enter a description.

You can enter a start date and due date or enter

other information by first tapping the field. If the

input panel is open, you will need to hide it to see

all available fields.

To assign the task to a category, tap Categories

and select a category from the list. In the task

list, you can display tasks by category.

To add notes, tap the Notes tab. You can enter

text, draw, or create a recording. For more

information on creating notes, see “Notes:

Capturing Thoughts and Ideas,” later in this

chapter.

When finished, tap OK to return to the task list.

131

Microsoft Pocket Outlook

Using the Summary Screen

When you tap a task in the task list,

a summary screen is displayed. To

change the task, tap

Edit

Notes: Capturing Thoughts and

Ideas

Quickly capture thoughts,

reminders, ideas, drawings, and

phone numbers with Notes. You

can create a written note or a

recording. You can also include a

recording in a note. If a note is

open when you create the

recording, it will be included in

the note as an icon. If the note

list is displayed, it will be created

as a stand-alone recording.

132

Microsoft Pocket Outlook

To create a note:

Action

Ta p

New

Create your note by writing, drawing, typing, and

recording.

133

Using Applications

You can launch a companion program by tapping

programs on the

start

menu, and then select the

program name.

Communicating with MSN

Messenger

Find the Feature

Start

Programs

MSN Messenger

MSN

Messenger on your device provides the same chat

environment as MSN Messenger on your desktop

computer. These features include:

•

See who is online.

•

Send and receive instant messages.

•

Have an instant message conversation with a group of

contacts.

•

Tell contacts that you are unavailable.

•

Block contacts from seeing your status or sending you

messages.

Before you can use MSN Messenger, you must set up the

instant messaging account(s) to use. For MSN Messenger

Service, you must have a

Microsoft Passport

Hotmail

account. For Exchange Instant Messaging, you must have

Exchange

account.

134

Using Applications

Setting Up

•

In the

Tools

menu, tap

Options

and then

Accounts

tab.

•

Select

Enable MSN Messenger Service

and/or

Enable

Exchange Instant Messaging

•

Enter your sign-in

name

and

password

for the

selected account.

•

To sign in, tap the sign-in screen and then

button.

Working with Contacts

The MSN Messenger window shows all of your messenger

contacts at a glance and are divided into Online and Not

Online categories. To change your status, select your

name from the Messenger contacts list, and press the

Action button. Select a status description, such as

Away

and press the Action button.

Tip:

To see others online without being seen, change your

status to Appear Offline.

f you block a contact, it appears offline but remains on

the blocked contact's list. To unblock a contact, select

the contact, press the Action button, select Unblock

from the list and press the Action button.

135

Using Applications

Chatting with Contacts

In MSN Messenger, select a contact name and press the

Send

to open a chat window. Enter your message in the

text entry area at the bottom of the screen, or tap

Text

to choose a preset message, and then press the

Send

. To invite another contact to a multi-user chat,

open the

Tools

menu and tap

Invite

to select a contact.

To know if the contact you are chatting with is responding,

look for the message under the text entry area.

Pocket Word

Find the Feature

Start

Programs

Pocket Word

Pocket Word works with Microsoft Word on your PC to give

you easy access to copies of your documents. You can

create new documents on your device, or you can copy

documents from your PC to your device. Synchronize

documents between your PC and your device so that you

have the most up-to-date content in both locations.

136

Using Applications

To create a new file:

Tip:

You can select a template for new documents in the

Options

dialog box. The template appears comes with

appropriate text and formatting already provided.

Pocket Word

contains a list of the files stored on your device.

Tap a file in the list to open it. To delete, make copies of,

Action

Ta p

Start

Programs

Pocket Word

, and then

New

. A blank document

appears.

If you have selected a template for new

documents in the

Tool

Options

dialog box, that

template appears with appropriate text and

formatting already provided.

Note:

You can open only one document at a time;

when you open a second document, you'll be asked

to save the first. You can save a document you

create or edit in a variety of formats, including

Word

(.doc),

Pocket Word

(.psw),

Rich Text Format

(.rtf), and

Plain Text

(.txt).

137

Using Applications

and send files, tap and hold a file in the list. Then, select

the appropriate action on the pop up menu.

Tip:

You can change the zoom magnification by tapping

View

and then

Zoom

. Then select the percentage you want.

Select a higher percentage to enter text and a lower one to

see more of your document. If you're opening a

Word

document created on a PC, select

Wrap to Window

on the

View

menu so that you can see the entire document.

Action

Select the folder type you want displayed in the

list.

Tap to change the sort order of the list.

Tap to open a document.

Tap and hold an item to see a pop-up menu of

actions.

Tap to create a new document.

138

Using Applications

Entering Information in a New File

You can enter information in

Pocket Word

in one of four

modes (typing, writing, drawing, and recording), which

are displayed on the

View

menu. Each mode has its

own toolbar, which you can show and hide by tapping

the

Show/Hide Toolbar

button on the command bar.

1 Typing Mode

•

Using the input panel, enter typed text into the

document.

•

Toformat or edit existing text, first select it by using

your stylus to drag through the text. You can search a

docu-ment for text by tapping Edit and then Find/

Replace.

2 Writing Mode

In writing mode, use your stylus to write directly on the

screen. Ruled lines are displayed as a guide, and the

zoom magni-fication is greater than in typing mode to allow

you to write more easily.

3 Drawing Mode

In drawing mode, use your stylus to

draw on the screen. Gridlines

appear as a guide. When you lift

your stylus off the screen after the

first stroke, you'll see a drawing box

indicating the boundaries of the

drawing. Every subsequent stroke

within or touching the drawing box

becomes part of the drawing.

139

Using Applications

4 Recording Mode

In recording mode, you can embed a recording into your

document. Recordings are saved as

.wav

files.

Pocket Excel

Find the Feature

Start

Programs

Pocket Excel

Pocket Excel works with Microsoft Excel on your PC to

provide easy access to copies of your workbooks. You can

create new workbooks on your device, or you can copy

workbooks from your PC to your device. Synchronize

workbooks between your PC and your device so that you

have the most up-to-date content in both locations.

140

Using Applications

To create a new file:

Tips for Working in Pocket Excel

Note the following when working in large worksheets in

Pocket Excel:

•

View in full screen mode to see as much of your

worksheet as possible. Tap

View

and then

Full Screen

To exit full screen mode, tap

Restore

•

Show and hide window elements. Tap

View

and then

tap the elements you want to show or hide.

Action

Ta p

Start

Programs

Pocket Excel

, and then

New

. A

blank workbook appears.

If you have selected a

template for new workbooks in

the

Tool

Options

dialog box,

that template appears with

appropriate text and

formatting already provided.

Pocket Excel provides

fundamental spreadsheet

tools, such as formulas,

functions, sorting, and filtering.

To display the toolbar, tap

View

and then

Toolbar

141

Using Applications

•

Freeze panes on a worksheet. First select the cell

where you want to freeze panes. Tap

View

and then

Freeze Panes

. You might want to freeze the top and

leftmost panes in a worksheet to keep row and

column labels visible as you scroll through a sheet.

•

Split panes to view different areas of a large

worksheet. Tap

View

and then

Split

. Then drag the split

bar to where you want it. To remove the split, tap View

and then

Remove Split

•

Show and hide rows and columns. To hide a hidden

row or column, select a cell in the row or column you

want to hide. Then tap

Format

, then

Row

Column

, and

then

Hide

. To show a hidden row or column, tap

Tools

then

Go To

, and then type a reference that are in the

hidden row or column. Then tap

Format

, then

Row

Column

, and then

Unhide

Windows Media Player

Find the Feature

Start

Programs

Windows Media

Use Microsoft Windows Media Player for Pocket PC to play

digital audio and video files that are stored on your device

or on a network.

142

Using Applications

Using Windows Media Player:

Pictures

Find the Feature

Start

Programs

Pictures

Pictures collects, organizes and sorts

.jpg

picture files on

your device. You can download images to your PC, and

then use ActiveSync to copy the files to your device. After

that, you can view the images as a slide show.

Tip:

Pictures can also be stored and transferred to your

device from an MMC, SD or digital camera card. Insert a

card into the memory card slot and then copy or drag the

pictures from your PC to the

My Documents

directory on the

memory card (If the memory card does not have a My

Documents directory you must create one first).

Action

Ta p

Start

Programs

Windows Media

Use Microsoft Windows Media Player on your PC

to copy digital audio and video files to your

Pocket PC. You can play Windows Media and

MP3 files on your Pocket PC.

143

Using Applications

Transferring Pictures

Finding and listing pictures

Viewing Pictures

Action

Pictures stored on your PC can be synchronized

with Pictures on your device. Picture synchronization

is not automatically selected in ActiveSync, you

need to tap the sync option

Files

in ActiveSync on

your desktop PC to activate this function.

Action

Ta p

Start

Programs

Pictures

Ta p

My Pictures

and select a folder from the drop-

down menu.

144

Using Applications

In the picture:

Action

Tap to view pictures as a

slide show.

Tap to view pictures stored in your My Picture

folder.

Tap to view pictures

stored on a storage card.

Tip:

Tap anywhere on the screen to display the Slide

show toolbar, which you can use to pause the slide

show, rotate the view, and more. Press the Left/Right

controls to move forward or backward through the

slides.

145

Using Applications

Sorting Pictures

Deleting a Picture

Action

Ta p

Start

Programs

Pictures

Ta p

Name

and select an

option from the drop-

down menu.

Action

Hold the stylus firmly on the file name of the picture

you want to delete, and then select Delete from the

pop up menu.

146

Using Applications

Editing Pictures

You can rotate, crop, zoom and adjust the brightness and

color contrast of your .jpg pictures.

Action

Tap to rotate a

picture 90 degrees

counter-clockwise.

Tap to crop a picture by dragging and

selecting the crop area. Tap outside of the box to

stop cropping.

Tap to display the Zoom panel, from which

you can zoom in or out of a picture, or return a

picture to full-screen size.

Ta p

Edit

Brightness and Contrast

to adjust the

brightness and contrast levels of a picture.

147

Using Applications

Setting Pictures as Background

You can use one of your own .jpg pictures as the

background on the

Today

screen, and specify how you

want it displayed on the screen, such as adjusting the

transparency level.

Customizing Pictures

You can choose to launch the Pictures program

automatically when a digital camera storage card is

inserted and decide on a time delay length between slides

when showing a slide show.

Action

Pictures

, tap the picture

you want to set as the

background.

Ta p

Tools

Set as Today Wallpaper

148

Using Applications

To select launch automatically:

To select the time delay between slides:

Action

Ta p

Start

Programs

Pictures

Ta p

Tools

Options

General

. Then, check the box

next to

Detect digital camera storage cards

Action

Ta p

Start

Programs

Pictures

Ta p

Tools

Options

Slide Show

. Then, select a

number of seconds then tap

149

Using the Camera

Your Pocket PC Phone features a built-in camera for you to

take photos. After taking a photo, you can view it directly

on the Pocket PC Phone, or send it via MMS to your

friends.

Camera

To take photos:

Action

If you want to save your

photos in a memory card,

insert it in the SD/MMC

card slot first.

There are two ways to open the Camera

program:

Ta p

Start

Programs

Camera

Press the

Camera

button on the keypad.

Use the camera to target your subject.

150

Using the Camera

Hold the Pocket PC Phone steadily and position

the subject in the center of the screen.

To zoom in/out (100% ~ 400%), tap / on

the lower right of the screen.

Tap on the bottom right corner of the screen,

or press the

Center

button of the Game Pad to

take the photo.

After taking the photo, you

can do one of the

following:

•

Tap to save it in the

selected folder

•

Tap to send it via

MMS

•

Tap to set it as the

wallpaper of the Pocket

PC Phone

•

Tap to delete it

151

Using the Camera

Setting Items on the Camera Screen

After opening the Camera program, there are several

setting items on the main screen of the Camera program

for you to view and change the settings of the photo:

Option

Description

Mode You can select to use the

Normal

Timer

, or

Burst mode

Resolution The resolution options are

1280x960(SXVGA)

640x480(VGA)

320X240(QVGA)

176X144(QCIF)

160X120(QQVGA)

and

128X96(SQCIF)

Flash Turn on or off the flash.

Brightness You can use the slider bar to

adjust the brightness value of

the photo.

Contrast You can use the slider bar to

adjust the contrast value of the

photo.

Settings You can tap this icon to access

more Camera settings.

152

Using the Camera

More Camera Settings

Cost Tracker

Description

Mode option You can set the time lag

between releasing the shutter

and shooting the photo (in the

Timer mode), or set the

maximum number of continuous

photos (in the Burst mode).

Size restriction If the remaining space of the

Pocket PC Phone has reached

the size limit you set, you cannot

take new photos.

Name prefix By default, the filename of each

new photo will be the prefix

following by a sequential

number. For example,


. You can change

the default prefix to your desired

characters.

153

Using the Camera

Photo Album

You can use the Photo Album program to view the photos.

In Photo Album, four view modes are available: Thumbnail

view, Detailed view, Slide Show view, and Full Screen.

White balance The white balance options are

Automatic

Night

Fluorescent

Incandescent

Sunlight

and

Cloudy

Storage folder By default, the photos you take

will be saved to your

\My

Documents\My Pictures

folder in

ResidentFlash. You can change

the storage location.

Max idle time You can set the idle period for

the Camera program to enter

the standby mode. The options

range from 20 seconds to 1

minute.

Action

There are two ways to open

the Photo Album program:

Ta p

Start

Programs

Photo Album

Tap on the upper right of

the Camera screen.

154

Using the Camera

Thumbnail View Mode

By default, Photo Album will display the photos in the

\My

Documents\My Pictures

folder in ResidentFlash.

You can change the display mode in this view mode:

Tap

Tools

to do the following functions:

•

Check All Pictures

•

Rename/Move Checked Pictures

•

Delete Checked Pictures

Display the filenames of

the photos

Ta p

View

Show Name

Under Thumbnails

Change the display

mode of the thumbnails

Ta p

View

Thumbnails

Display the photos in

the List mode

Ta p

View

List

Change the folder of

photos

Ta p

View

Select a Folder

155

Using the Camera

Detailed View Mode

To enter the Detailed view mode, simply tap a photo in the

Thumbnail view mode.

In this view mode, you can Tap

Edit

to edit the photo:

Option

Description

Rotate/Flip/

Crop

allows you to rotate, flip or crop

the photo.

Edit Sound

allows you to add an audio

recording to the photo.

Draw

allows you to draw on the photo.

Add Text

allows you to add a text note to

the photo.

Add Clip Art

allows you to add a clip art

drawing on the photo.

156

Using the Camera

You can also do the following:

Funhouse

allows you to add a funny frame

for the photo.

Photo Greeting

allows you to select a card

background for the photo.

Warp

allows you to twist the photo.

Move to the previous/

next photo in the

current folder

Tap or .

Change the Orientation

of the photo

Ta p

View

Show in Actual

Orientation

Show in Rotated

Orientation

Show in Best

Orientatio

Zoom the photo Ta p

View

Zoom In

(or )

Zoom Out

(or ) /

Zoom To

View the photo in the

Full Screen mode

Ta p

View

Full Screen

Send the photo via

MMS

Ta p

Tools

Send via MMS

Send the photo via e-

mail

Ta p

Tools

Send via E-mail

Send the photo via IR

to another device

Ta p

Tools

Beam Picture

Set the photo as the

wallpaper of the Pocket

PC Phone

Ta p

Tools

Set as

Wallpaper

157

Using the Camera

Slide Show View Mode

To enter the Slide Show view mode, tap in the

Thumbnail view mode. By default, you will enter the slide

show setting screen before the slide show starts. After the

slide show starts, tap anywhere on the screen to return to

the Thumbnail view mode.

Save the photo in

another location in the

Pocket PC Phone

Ta p

Tools

Save Picture As

Rename/Move the


Ta p

Tools

Rename/Move

View the information of

the photo

Ta p

Tools

Information

, or

Delete the photo Ta p

Tools

Delete

, or .

158

Using the Camera

Full Screen Mode

To enter the Full Screen mode, tap

View

Full Screen

in the

Detailed view mode. Tap anywhere on the screen to return

to the Detailed view mode.

159

Getting Connected

Wi-Fi Wireless LAN

(IEEE802.11b)

Your Pocket PC Phone is equipped with a built-in wireless

network module to connect to an 802.11b wireless LAN

(WLAN) or connect directly to other WLAN-enabled

devices.

Turning the WLAN On or Off

Action

Ta p

Start

WLAN Utility

Ta p

Turn ON

to turn on the WLAN module. The

Pocket PC Phone will start to scan the wireless

networks available in your environment.

160

Getting Connected

Viewing the WLAN Status and Settings

To view the WLAN status and settings:

If one or more networks are available, the Pocket

PC Phone will ask you to select the network you

want to connect to and whether the network

connects to the Internet or Work.

If you are prompted for a Network Key (WEP),

enter it and then tap

Connect

. If you are not sure,

contact your network administrator.

To turn off the WLAN, tap the WLAN icon on the

bottom right corner of the display and tap

Wireless

Off

to turn it off.

Action

Ta p

Start

WLAN Utility

Tap the

Status

Setting

Security

Information

tab to

view the WLAN status and settings.

161

Getting Connected

Bluetooth

Find the Feature

Start

Settings

Connections

Bluetooth

Bluetooth is a short-range wireless communications

technology. Devices with Bluetooth capabilities can

exchange information over a distance of about 10 meters

(30 feet) without requiring a physical connection.

Unlike infrared, you don’t need to line up the devices to

beam information with Bluetooth. The devices only need to

be within a range of about 10 meters. You can even beam

information to a device in a different room, as long as it's

within range. The software included with your Pocket PC

Phone allows you to use Bluetooth in the following ways:

•

Beam information, such as files, appointments,

tasks, and contact cards, between devices that

have Bluetooth capabilities. For example, if you

and a co-worker each have a device with

Bluetooth, you can beam items between your devices,

such as files, contact cards, appointments, tasks, and

so forth.

•

Create a dial-up modem connection between your

device and a Bluetooth phone. You can then use the

Bluetooth phone as a modem.

162

Getting Connected

To access to the Bluetooth settings screen:

Action

Ta p

Start

Settings

Connections tab

Bluetooth

Tap the small icon and

select the

Bluetooth Setting

option

163

Getting Connected

Bluetooth Modes

Bluetooth operates in three different modes:

Mode Description

ON:

The Bluetooth radio

is turned on and

you can use

Bluetooth features.

Discove-

rable:

The Bluetooth radio is turned on, and

all of the other Bluetooth devices within

range (about 10 meters) can detect

your device and attempt to beam

information to it, establish a bond, or

use a Bluetooth service. In this mode,

other devices can detect your device

whether or not a bond has been

created; however, in order to receive a

beam from another device, you must

accept it on your device.

Off:

The Bluetooth radio is turned off. In

this mode, you can neither send nor

receive information by using Bluetooth.

You might want to turn the radio off at

times in order to conserve battery

power, or in situations where radio use

is prohibited, for example on airplanes

and in hospitals.

164

Getting Connected

To turn your Bluetooth radio on or off:

To make your device discoverable:

Action

Ta p

Start

Settings

Connections

tab >

Bluetooth

Select

Off

. The Bluetooth radio is turned on

or off according to your selection.

Tip:

By default the Bluetooth radio is turned off. If

you turn it on, and then turn off your device, the

Bluetooth radio also turns off. When you turn on your

device again, the Bluetooth radio automatically turns

on.

Action

Ta p

Start

Settings

Connections

tab >

Bluetooth

Select

Discoverable

. (Selecting

Discoverable

also

turns on your Bluetooth radio.)

Now, other Bluetooth devices can detect your device

and attempt to beam information to it, establish a

bond, or use a Bluetooth service. Note that to

receive beamed information, you must accept it on

your device.

165

Getting Connected

Bonds

A bond is a relationship that you create between your

device and another Bluetooth device in order to exchange

information in a secure manner. Creating a bond involves

entering the same personal identification number (PIN) on

the two devices you want to bond. You need only create a

bond once between two devices. Once a bond is created,

the devices recognize the bond and are able to exchange

information without your entering a PIN again.

To create a bond:

You can create a bond between your device and another

device that has Bluetooth. Once you do this, Bluetooth

doesn't need to be in discoverable mode in order for you to

beam information between the two devices; the

Bluetooth radio only needs to be turned on.

Action

Make sure that the two

devices are within 10

meters of one another

and that Bluetooth is in

discoverable mode on

both devices.

Ta p

Start

Settings

Connections

tab.

166

Getting Connected

Ta p

Bluetooth

Bonded Devices

tab >

New

. Your device

searches for other Bluetooth devices and

displays them in the list.

Tap the name of the other device in the list, and

then

, enter a PIN of

between 1 and 16

characters and tap

Enter the same PIN on the other device.

If you want, in

Name

, edit the name of the other

device.

Ta p

Finish

167

Getting Connected

To accept a Bond:

Action

Make sure that Bluetooth

is turned on and in

discoverable mode.

When prompted to bond with the other device,

tap

, enter a PIN of between 1 and 16

characters, and tap

. You must enter the

same PIN that was entered on the device

requesting the bond.

If you want, in Name, edit

the name of the device

requesting the bond.

Ta p

Finish

Now, the bond is created. You can now exchange

information with the other device.

168

Getting Connected

To rename a Bond:

To delete a Bond:

Action

Ta p

Start

Settings

Connections

tab.

Ta p

Bluetooth

Bonded Devices

tab.

Tap the bond to rename.

Name

, enter a new name for the bond.

Ta p

Finish

Action

Ta p

Start

Settings

Connections

tab.

Ta p

Bluetooth

Bonded Devices

tab.

Tap and hold the bond to delete.

Ta p

Delete

169

Getting Connected

Beaming Information with Bluetooth

Tip:

If the device that you want to beam to does not

appear in the list, make sure that it is turned on, in

discoverable mode, and within 10 meters (10 meters) of

your device. Also, make sure you're your Bluetooth radio is

turned on.

Action

Tap and hold an item to

beam, such as an

appointment in Calendar,

a task in Tasks, a contact

card in Contacts, or a file

in File Manager.

Ta p

Beam [type of item]

Tap the device to which you want to send the

beam.

The item is beamed to the device you selected.

170

Getting Connected

Receiving a Bluetooth Beam

The information is now stored on your device.

Using a Bluetooth Phone as a Modem

You can use a phone that has Bluetooth capabilities as a

modem for your device. To do this, you create a Bluetooth

modem connection on your device and then send

information to the phone by using Bluetooth. The phone

relays the information over the phone line and then sends

back to your device any information that you had

requested over the connection.

Action

Make sure that your

device is configured to

receive incoming beams

and that

Bluetooth

is in

discoverable mode.

Make sure that your device is within 10 meters of

the device beaming the information.

When prompted to receive an incoming beam,

tap

Yes

171

Getting Connected

Once you create a modem connection to the Bluetooth

phone, you can reuse it whenever you want to use the

phone as a modem.

Action

Make sure that the

Bluetooth phone is turned

on, that your device's and

the phone's Bluetooth

radios are turned on, and

that your device and the

phone are within 10

meters (10 meters) of one

another.

If you have not already done so, create a

Bluetooth phone connection by following steps 3

through 16. Otherwise, skip to step 17.

Ta p

Start

Settings

Connections

tab.

Ta p

Connections

Add a new modem connection

Enter a name for the connection.

In the

Select a modem

list, tap

Bluetooth

Make sure that the phone is discoverable. Some

phones may also need to be pairable in order to

accept a bonding request.

If the phone appears in the

My Connections

list, skip

to step 14. If not, tap

New

and follow the

remaining steps.

In the list, tap the phone and then

172

Getting Connected

Pocket Internet Explorer:

Browsing Web and WAP Pages

Find the Feature

Start

Internet Explorer

You can use

Microsoft Pocket Internet Explorer

to view Web

HTML, cHTML, xHTML and WAP pages. You can browse

in either of these ways:

•

During synchronization with your PC, download your

favorite links and mobile favorites that are stored in

the Mobile Favorites folder in Internet Explorer on the

PC.

, enter a PIN of between 1 and 16

characters, and tap

Enter the same PIN on the phone.

If you want, in

Name

, edit the name of the phone.

Ta p

Finish

In the

My Connections

list, tap the phone, and then

Enter the phone number to dial for this

connection and tap

User name

Password

, and

Domain

, enter the logon

information for this connection and tap

Finish

Start using the program that uses the Bluetooth

phone connection; for example Inbox to send

and receive e-mail, or Internet Explorer to

browse the Web.

173

Getting Connected

•

Connect to an Internet service provider (ISP) or

network and browse the Web.

Tip:

To synchronize and download your favorite links from

your desktop computer, tap the sync option

Favorites

ActiveSync

on your desktop PC.

When connected to an ISP or network, you can also

download files and programs from the Internet or intranet.

Using Pocket Internet Explorer

You can use Pocket Internet Explorer to browse mobile

favorites and channels that have been downloaded to your

device without connecting to the Internet. You can also

connect to the Internet through an ISP or a network

connection and browse the Web/ WAP page(s).

To browse the Internet:

Action

In the address bar

that appears at the

top of the screen,

enter the Web

address you want to

visit.

Tap to go to the web address you entered.

174

Getting Connected

To view mobile favorites and channels :

Tap , the

Favorites

button, then tap the

favorite you want to view.

Tap to go back to the Homepage you set.

Tap to refresh the web page on the screen.

Tap the arrow to choose from previously

entered addresses.

Action

To display your list of

favorites, tap .

Tap the page you want to view.

You will see the page that was downloaded the

last time you synchronized with your PC. If the

page is not on your device, the favorite will be

dimmed. To download the page to your device,

you will need to synchronize with your PC again,

or connect to the Internet to view the page.

175

Getting Connected

Tip:

To add a favorite link while using the device, go to the

page you want to add, tap and hold on the page, and tap

Add to Favorites

The Mobile Favorites Folder

Only items stored in the

Mobile Favorites

folder in the

Favorites

folder in Internet Explorer on your PC will be synchronized

with your device. This folder was created automatically

when you installed ActiveSync.

Favorite Links

During synchronization, the list of favorite links in the

Mobile

Favorites

folder on your PC is synchronized with

Pocket

Internet Explorer

on your device. Both PC and your device are

updated with changes made to either list each time you

synchronize. Unless you mark the favorite link as a

mobile favorite, only the link will be downloaded to your

device, and you will need to connect to your ISP or

network to view the content. For more information on

synchronization, see ActiveSync Help on the PC.

Mobile Favorites

If you are using Microsoft Internet Explorer 5.0 or later

on your PC, you can download mobile favorites to your

device. Synchronizing mobile favorites downloads Web

content to your device so that you can view pages

while you are disconnected from your ISP and PC.

Use the Internet Explorer plug in installed with

ActiveSync to create mobile favorites quickly.

176

Getting Connected

Creating a mobile favorite:

If you did not specify an update schedule in step 3, you will

need to manually download content to keep the

information updated on your desktop computer and device.

Before synchronizing with your device, in Internet Explorer

on your desktop computer, click

Tools

and then

Synchronize

You will see the last time content was downloaded to the

Action

In Internet Explorer on your desktop computer,

click

Tools

and then

Create Mobile Favorite

To change the link name, enter a new name in

the

Name

box.

Optionally, in

Update

, select a desired update

schedule.

Click

. Internet Explorer downloads the latest

version of the page to your desktop computer.

To limit the number of download links, open

Internet Explorer on your desktop PC then

Favorites

. Then, move your mouse through

Mobile

Favorites

to the mobile favorite you want to

change. Finally, right-click the mobile favorite and

then

Properties

; in the

Download

tab, specify 0 or 1

for the number of linked pages you want to

download.

Synchronize your device and desktop computer.

Mobile favorites that are stored in the Mobile

Favorites folder in Internet Explorer are

downloaded to your device.

177

Getting Connected

desktop computer, and you can manually download

content if needed.

You can add a button to the Internet Explorer toolbar for

creating mobile favorites. In Internet Explorer on your

desktop computer, click

View

Toolbars

, and then

Customize

Saving Device Memory:

Mobile favorites take up storage memory on your device.

To minimize the amount of memory used:

•

ActiveSync

on your desktop, click

Options

, select

Favorites/Internet Explorer

, tap

Settings

and then

Customize

You can then deselect

Synchronize Images

Synchronize Sound

and/or

Synchronize offline content pages

, to stop pictures

and sounds, or some mobile favorites from being

downloaded to the device.

•

Limit the number of downloaded linked pages. In

Internet Explorer on the desktop computer, click

Favorites

; then move your mouse through

Mobile Favorites

to the mobile favorite you want to change. Finally,

right-click the mobile favorite and then

Properties

. In the

Download

tab, specify 0 or 1 for the number of linked

pages you want to download.

Using AvantGo Channels

AvantGo is a free interactive service that gives you access

to personalized content and thousands of popular Web

sites. You subscribe to AvantGo channels directly from

your device. Then, you synchronize your device and PC, or

connect to the Internet to download the content. For more

information, visit the AvantGo Web site.

178

Getting Connected

To sign up for AvantGo:

Action

ActiveSync

options on the desktop computer,

turn on synchronization for the

AvantGo

information type.

Pocket Internet Explorer

on your device, tap the

Favorites

button to display your list of favorites.

Tap the

AvantGo Channels

link.

Follow the directions on the screen. You will need

to synchronize your device with your desktop

computer and then tap the

My Channels

button to

complete the

AvantGo

setup.

When synchronization is complete, tap the

AvantGo Channels

link in your list of favorites to see a

few of the most popular channels. To add or

remove channels, tap the

Add

Remove

link.

179

Games

Your phone comes with three games. If you get an

incoming call, message, alarm or alert, the game ends

automatically.

Find the Feature

Games

To end a game at any time:

Press

scroll to the game of your choice

2SELECT

start the game

Press

BACK/NO

end the game session or return

to the game menu

180

Troubleshooting

Check these questions first if you have problems with your

phone:

Question Answer

How do I know if

my battery is

charged?

The battery level indicator

should show at least one bar

(segment) of power. If it does

not, please recharge your

phone’s battery (see “Charging

Your Phone” on page 15). If the

battery level indicator has three

(3) bars showing, then your

phone’s battery is fully charged.

Do you have a

valid SIM card

inserted in your

phone?

If necessary, turn off your phone

and make sure that you have

inserted a valid SIM card.

Does the

handset have a

signal? Do you

see a signal

showing in the

display?

The signal strength indicator

should have at least one

segment showing. If it does not,

move to an area with a stronger

signal to use your phone.

Is the earpiece

volume too low?

While on a call, scroll up.

181

Troubleshooting

Question Answer

Is the other party

unable to hear

you?

Your phone may be muted. You

may take the call off of mute by

making the appropriate soft key

selection.

Also, you and/or the person you

are speaking with may be in a

weak network coverage area.

Make sure that your phone’s

microphone is not obstructed.

Has the phone

been damaged,

dropped or

gotten wet?

Dropping your phone, getting it

wet, or using a non-Motorola

battery charger can damage the

phone. The phone's limited

warranty does not cover liquid

damage or damage caused

from using non-Motorola

accessories.

I can’t hear my

phone ring.

Ensure that your phone is not

set to Silent or Vibrate. See

page 20 on how to modify your

phone’s Alert and Ring Tone

profiles: Ring, Vibrate, Vibrate &

Ring, Flashing, and Silent.

182

Troubleshooting

The following referring to specific problems:

Question Answer

My phone was

stolen. To whom

should I report

this?

Report a stolen phone to the

police and to your service

provider.

I forgot my

password

See “Changing Your Unlock

Code” on page 66.

I pressed the

End/Power key,

but nothing

happened.

To either turn your phone

Off

, you must

Press and Hold

the

End/Power Key

for a couple

of seconds. If your phone will

still not turn

when you do

this, then check to see if your

phone’s battery is charged.

The Display

says

Insert SIM

card or Check

SIM Card

even

though I have

inserted my

SIM card in the

phone.

The SIM card may be incorrectly

inserted. Check the SIM card to

make sure that it is inserted

properly.

The display

says

SIM

Blocked

. How

do I unblock my

SIM card?

Call your service provider to

obtain the PIN unblocking code.

183

Troubleshooting

Question Answer

The display

says

Enter

Unlock code

How do I unlock

my phone?

Enter the factory-preset unlock

code, 1234, or the last 4 digits

of your phone number.

If you changed the default

unlock code in your phone,

please enter the unlock code

that you defined to unlock it.

My phone asks

for an unlock

code when I try

to open a

feature.

The application you want is

locked. If you own the phone but

do not know the unlock code,

see “Changing Your Unlock

Code” on page 66.

My phone rings

even though I

selected the

silent or vibrate

alert profile.

The ringer may be set to play a

tone even though your phone is

set to a silent alert profile.

I tried to place a

call and heard

an alternating

high/low tone.

Your call did not reach the

wireless system. You may have

dialed the number too soon

after turning the phone on. Wait

until the display shows the

name of your service provider

before making a call.

184

Troubleshooting

Question Answer

I cannot make/

answer calls.

Make sure that you have a

phone signal. Avoid electrical or

radio interference, and

obstructions such as bridges,

parking garages, or tall

buildings.

Your phone may also have the

Call Barring feature turned on. If

you know the unlock code, you

can change this setting in the

security menu. > Settings >

Security.

Also, check and make sure your

SIM card is inserted and

working.

My phone has

poor reception

and drops calls.

Make sure you have a phone

signal. Stay clear of any

obstructions such as bridges,

parking garages, or tall

buildings.

I cannot hear

others on my

phone.

While on a call, adjust the

volume by scrolling with the

Navigation Key to either the

right (to increase) or to the left

(to decrease) the phone volume

in my earpiece. Also, make sure

that your phone's earpiece is

not blocked by its carrying case.

185

Troubleshooting

Question Answer

I cannot open my

inbox.

Before you can use text or

information services messages,

you must set up the appropriate

inbox.

How do I see the

calls I sent or

received?

To see the most recent calls you

dialed or received, open the list:

> Recent calls > Received Calls

or Dialed calls.

My phone will

not dial

voicemail

commands,

passwords, or

other codes.

Your phone sends commands

and passwords as DTMF tones.

You can set your phone's DTMF

tones to be Long, Short or Off. If

you have trouble sending

numbers, check your DTMF

setting.

From the idle display, press: >

Settings > Other Setting > Initial

Setup > DTMF.

Press to scroll to Long DTMF or

Short DTMF and press Select to

confirm.

My phone's

display is too

light.

You can change the level of

contrast in your phone display.

186

Troubleshooting

Question Answer

What can I do to

extend battery

life?

Your battery's performance is

affected by charge time, feature

use, temperature changes, and

other factors.

You may also select

Battery

Save

to help maximize the

amount of time that your battery

will last between charges (see

Setting Battery Save on page

22).

How do I remove

the battery?

Remove it by opening the back

cover of the phone.

My phone is

stuck and none

of the buttons I

push will do

anything. How

do I make my

phone work?

You may need to reset your

phone. To reset your phone

(without changing any of the

defaults that you currently

have), remove your replaceable

battery from your phone and

then insert it back into your

phone. This will reset your

phone and you should be able

to power your phone back on

and use it again.

187

Specific Absorption

Rate Data

This model phone meets the government's requirements for

exposure to radio waves.

Your mobile phone is a radio transmitter and receiver. It is

designed and manufactured not to exceed limits for exposure

to radio frequency (RF) energy. These limits are part of

comprehensive guidelines and establish permitted levels of

RF energy for the general population. The guidelines are

based on standards that were developed by independent

scientific organizations through periodic and thorough

evaluation of scientific studies. The guidelines include a

substantial safety margin designed to assure the safety of all

persons, regardless of age and health.

The exposure standard for mobile phones employs a unit of

measurement known as the Specific Abortion Rate, Or SAR.

Under the guideline for your phone model, the SAR limit is

2.0 W/kg. Tests for SAR are conducted in accordance with

CENELEC testing procedures using standard operating

positions with the phone transmitting at its highest certified

power level in all tested frequency bands. Although the SAR

is determined at the highest certified power level, the actual

SAR of the phone while operating can be well below the

maximum value. This is because the phone is designed to

operate at multiple power levels so as to use only the power

required to reach the network. In general, the closer you are

to a base station, the lower the power output of the phone.

188

Before a phone model is available for sale to the public. it is

tested to confirm compliance with the guidelines. The tests

are performed in positions and locations (e.g., at the ear and

work on the body) that conform to a uniform testing

methodology determined by an expert standards body. The

highest SAR value for this model phone when tested for use

at the ear is __ W/kg.

While there may be differences between the SAR levels of

various phones and at various positions, they all meet the

governmental requirements for safe exposure. Please note

that improvements to this product model could cause

differences in the SAR value for later products; in all cases,

products are designed to be within the guidelines.

motorola.com

Compal Electronics MPX001 Portable Cellular / PCS GSM Transceiver User Manual Exhibit 8 Users Manual

Compal Electronics Inc Portable Cellular / PCS GSM Transceiver Exhibit 8 Users Manual

Contents

Exhibit 8 Users Manual

Navigation menu

Namespaces

Views

Navigation
