Contents

MENU MAP .................................................... 11

SAFETY ...........................................................17

Traffic Safety..................................................17

Do Not Use in Hospitals................................. 17

Do Not Use in Airplanes ................................17

Do Not Use in Gasoline Stations ................... 17

Do Not Use in Explosive Sites.......................18

Operating Environment..................................18

Standard Usage.............................................18

Accessories ...................................................18

Appropriate Maintenance .............................. 18

Emergency Calls (SOS) ................................18

Use with proper care to reduce electromagnetic

interference (EMI) ..................................................19

GETTING STARTED .......................................20

PHONE OVERVIEW.............................................20

INSTALLATION & REMOVING................................21

Installing the battery........................................21

Removing the battery......................................21

Installing the SIM Card.................................... 22

Removing the SIM Card.................................. 22

Connecting the Charger..................................23

Removing the Charger....................................23

KEYPAD DESCRIPTION .......................................23

ALPHANUMERIC MAPPING ..................................26

DISPLAY INDICATORS. ........................................27

BASIC OPERATION .......................................29

Making a Call ..................................................29

The SIM Card..................................................29

Battery and Charger........................................ 29

Turning on the Phone......................................30

PIN and PIN2 (4 to 8 digits) ............................30

PUK1 and PUK2 (8 digits) ..............................31

Calling ............................................................. 31

Dialing Emergency Numbers ..........................31

Changing an Entry .......................................... 31

Answering a Call .............................................32

Recent Calls....................................................32

Speed Dial ...................................................... 32

Holding a Call.................................................. 33

Multi-party Calls .............................................. 34

Voice-activated Dialing ...................................34

Method of Input ............................................... 35

1. T9 English .................................................................. 36

MENU FUNCTION ...........................................37

PHONE BOOK ....................................................37

Search............................................................. 37

Add Entry ........................................................ 38

Edit .................................................................. 39

Delete.............................................................. 39

Copy................................................................ 40

P.Book Setting................................................. 40

1. Caller Group............................................................... 40

2. Sorting........................................................................ 40

3. Display SIM Records.................................................. 40

Memory ...........................................................40

MESSAGE .........................................................41

SMS ................................................................41

1. Write........................................................................... 41

2. Inbox .......................................................................... 42

3. Outbox ....................................................................... 42

4. Delete......................................................................... 42

5. Free Count................................................................. 43

6. Setting........................................................................ 43

~ Pre-Message ............................................................. 43

~ SMS Center ............................................................... 43

~ Valid Time .................................................................. 43

~ Auto Display............................................................... 43

~ Status Report ............................................................. 44

Broadcast ........................................................ 44

1. Read .......................................................................... 44

2. Filter........................................................................... 44

3. Auto Display ............................................................... 44

VOICE MAIL.......................................................45

1. Call V-mail..........................................................45

2. Voice Mail...........................................................45

PROFILE............................................................45

Adjust .............................................................. 45

1. Activate ...................................................................... 45

2. Ringtone and Volume................................................. 45

3. Key Sound ................................................................. 46

4. Crescendo.................................................................. 46

5. SMS Rec Tone ........................................................... 46

6. Vibrator ...................................................................... 46

7. Service Tone .............................................................. 46

8. Auto Answer ............................................................... 46

9. Rename (Only in Customer mode)............................. 46

CALL LISTS........................................................47

Missed Call ..................................................... 47

Incoming .........................................................47

Outgoing .........................................................47

Call Info ...........................................................47

1. Last Call..................................................................... 47

2. Total Calls................................................................... 47

3. 1-minute Beep............................................................ 48

4. Charge Info ................................................................ 48

~ Total Charge............................................................... 48

~ Max Charge ............................................................... 48

~ Unit Price ................................................................... 48

SETTINGS..........................................................48

Personal .......................................................... 48

1. Language................................................................... 49

2. Greetings ................................................................... 49

3. Power On/Off Melody................................................. 49

4. Folder On/Off Melody................................................. 49

5. Hot Key Setting .......................................................... 49

6. Own Number.............................................................. 50

Clock ...............................................................50

1. Set Date ..................................................................... 50

2. Set Alarm ................................................................... 50

3. Power Off ................................................................... 50

Screen............................................................. 51

1. Standby mode ............................................................ 51

2. Color Theme .............................................................. 51

3. Network Name ........................................................... 51

4. Show Clock ................................................................ 51

5. Standby LED .............................................................. 51

Call Setting...................................................... 51

1. Call Waiting................................................................ 51

~ Activate ...................................................................... 51

~ Cancel........................................................................ 51

~ Status......................................................................... 51

2. Divert.......................................................................... 52

~ Forward to.................................................................. 52

~ Unreachable .............................................................. 52

~ If No Reply ................................................................. 52

~ All Calls ...................................................................... 52

~ If Busy........................................................................ 52

~ Status......................................................................... 52

~ Cancel All................................................................... 52

3. Answer Mode ............................................................. 52

4. Present Number......................................................... 52

Network...........................................................53

1. Select Method ............................................................ 53

2. New Search ............................................................... 53

3. Select Sequence........................................................ 53

Security ...........................................................53

1. Bar Calls .................................................................... 53

~ All Out ........................................................................ 53

~ Out Intl ....................................................................... 53

~ Out X Home ............................................................... 53

~ All In ........................................................................... 53

~ In If Abr ...................................................................... 54

~ Status......................................................................... 54

~ Cancel All................................................................... 54

2. PIN Check.................................................................. 54

3. PIN Change ............................................................... 54

4. PIN2 Change ............................................................. 54

5. Fixed Numbers........................................................... 54

6. SIM Lock.................................................................... 54

~ Set Lock..................................................................... 54

~ Change PCK.............................................................. 54

Reset Setting .................................................. 55

MMEDIA............................................................55

File Manager ...................................................55

~ Open File ................................................................... 55

~ Send MMS ................................................................. 55

~ Save as Wallpaper..................................................... 55

~ Save to P.Book........................................................... 55

~ Rename ..................................................................... 55

~ Delete ........................................................................ 55

~ Delete all file .............................................................. 56

~ File Sort ..................................................................... 56

　 By Name............................................................ 56

　 By Date.............................................................. 56

　 By Type.............................................................. 56

~ View........................................................................... 56

　 List..................................................................... 56

　 Icon.................................................................... 56

~ Detail Info................................................................... 56

Image ..............................................................56

Audio ............................................................... 56

Free Space...................................................... 56

Game ..............................................................57

1. Game ......................................................................... 57

~ Puzzle ........................................................................ 57

~ Hostage Salvation...................................................... 57

~ Reversi....................................................................... 57

~ Coin Elf ...................................................................... 58

Tone Edit ......................................................... 58

1. Play............................................................................ 58

2. Edit............................................................................. 58

~ Keypad functions ....................................................... 58

~ Edit............................................................................. 59

3. Reset.......................................................................... 59

4. Tempo ........................................................................ 59

5. Instrument.................................................................. 59

6. Rename ..................................................................... 60

CALCUATOR ......................................................60

Calendar................................................................. 61

1. View Day Note ...................................................61

2. Make Note.......................................................... 61

3. Erase Note .........................................................62

4. View All Notes .................................................... 62

5. Go To Date......................................................... 62

Exchange Rate ............................................... 62

Voice Memos ..................................................62

1. Record ....................................................................... 63

2. Playback .................................................................... 63

~ Playback .................................................................... 63

~ Delete One................................................................. 63

~ Label.......................................................................... 63

3. Options....................................................................... 63

~ Self Only .................................................................... 63

~ Other Party Only ........................................................ 63

~ Both ........................................................................... 63

World clock...................................................... 64

~ Set Location............................................................... 64

　 Automatic........................................................... 64

　 Manual............................................................... 64

WAP................................................................64

Access WAP ...................................................64

Favorites .........................................................65

1. New Bookmark........................................................... 66

2. New Folder................................................................. 66

3. Delete all.................................................................... 67

4. Hotkeys ...................................................................... 67

Go To URL ......................................................67

WAP Settings ..................................................67

1. Connection................................................................. 67

~ Add New .................................................................... 67

　 Name................................................................. 67

　 Homepage ......................................................... 68

　 IP Address ......................................................... 68

　 Bearer................................................................ 68

　 User name......................................................... 68

　 Password........................................................... 68

　 DNS IP address................................................. 68

　 Linger Time........................................................ 68

　 APN ................................................................... 68

　 Security.............................................................. 68

　 Store .................................................................. 68

~ Add from List.............................................................. 69

　 BeeLine WAP .................................................... 69

　 MIS WAP ........................................................... 69

　 MegaFon WAP .................................................. 69

2. Color Scheme ............................................................ 69

3. Clear Cache ............................................................... 69

4. Reset all..................................................................... 69

GPRS Setting..................................................69

1. Permanent............................................................... 69

2. Needed.................................................................... 69

STK( SIM TOOLKIT ). ..................................... 69

BATTERY .......................................................71

CARE AND MAINTENANCE .........................72

FCC Regulation ……………………………73

FCC RF Exposure Information .….………74

Menu Map

P. Book

zSearch

zAdd Entry

zEdit

zDelete

zCopy

zP. Book Setting

1. Caller Groups

2. Sorting

3. Display SIM Records

zMemory Status

Messages

z SMS

1. Write

2. Inbox

3. Outbox

4. Delete

5. Free Count

6. Setting

~ Pre-Message

~ SMS Center

~ Valid Time

~ Auto Display

~ Status Report

zBroadcast

1. Read

2. Filter

3. Auto Dispaly

z Voice Mail

1. Call V-mail

2. Voice Mail

Profile

zTypical

zSilent

zOutdoor

zHandsfree

zMeeting

zCustomer

1. Activate

2. Ringtone and Volume

3. Key Sound

4. Crescendo

5. SMS Rec Tone

6. Vibrator

7. Service Tone

8. Auto Answer (Only in Handsfree mode)

9. Rename (Only in Customer mode)

Call Lists

zMissed Call

zIncoming

zOutgoing

zCall Info

1. Last Call

2. Total Calls

3. 1-minute Beep

5. Charge Info

~ Total Charge

~ Max Charge

~ Unit Price

Settings

zPersonal

1. Language

2. Greetings

3. Power On/Off Melody

4. Folder On/Off Melody

5. Hot Key Setting

6. Own Number

zClock

1. Set Date/Time

2. Set Alarm

3. Power Off

zScreen

1. Standby mode

~ Pic & Text

~ Digital Clock

~ Calendar

2. Color Theme

3. Network Name

4. Show Clock

5. Standby LED

zCall Setting

1. Call Waiting

~ Activate

~ Cancel

~ Status

2. Divert

~ Forward to

~ Unreachable

~ If No Reply

~ All Calls

~ IF Busy

~ Status

~ Cancel All

3. Answer Mode

~ Normal answer

~ Any key answer

~ Folder answer

4. Present Number

zNetwork

1. Select Method

2. New Search

3. Select Sequence

zSecurity

1. Bar Calls

~ All Out

~ Out Intl

~ Out x Home

~ All In

~ In If Abr

~ Status

~ Cancel All

2. PIN Check

3. PIN Change

4. PIN2 Change

5. Fixed Numbers

6. SIM Lock

~ Set Lock

~ Change PCK

zReset Setting

MMedia

zFile Manager

1. Image

~ Open file

~ Save as Wallpaper

~ Rename

~ Delete file

~ Delete all files

~ File Sort

~ View

~ Detail Info

2. Audio

~ Open file

~ Rename

~ Delete file

~ Delete all files

~ File Sort

~ Detail Info

3. Free Space

zTone Edit

1. Play

2. Edit

~ Keypad function

~ Edit

~ Save

3. Reset

4. Tempo

5. Instrument

6. Rename

zGame

1. Hostage Salvation

2. Reversi

PIM

zCalculator

zCalendar

1. View DayNote

2. Make Note

3. Erase Note

4. View All Notes

5. Go To Date

zExchange Rate

zVoice Memos

1. Record

2. Playback

~ Playback

~ Delete One

~ Rename

3. Options

~ Self Only

~ Other Party Only

~ Both

zWorld Clock

~ Auto

~ Manual

WAP

zAccess WAP

zFavorites

1. New Bookmark

2. New Folder

3. Delete all

4. Hotkeys

zGo To URL

zWAP Setting

1. Connection

~ Add New

~ Add from List

2. Color Scheme

3. Clear Cache

4. Reset all

zGPRS Setting

1. Permanent

2. Needed

STK

Safety

Read carefully the following important safety and regulations

before you use the phone. Failure of obeying these instructions

may lead to suspension of mobile telephone services, or broke

the law. Most of all, it will cause your personal in danger.

Always adhere to the following:

Traffic Safety

Avoid using a hand-held phone while driving. For your safety,

you should park the vehicle before making or answering a call.

Using a hand-free car kit or earpiece is recommended.

Do Not Use in Hospitals

The use of mobile telephones may interfere with the

functionality of some medical devices in the hospital. Check the

law and regulations or posted notices. To avoid

electromagnetic interference (EMI) with medical devices,

please power off your phone when it is necessary.

Do Not Use in Airplanes

The use of mobile phones in an aircraft may disrupt radio

transmissions and signals. This, therefore, can be dangerous to

the operation of the aircraft. Be sure to turn off your mobile

phone when on board an aircraft. It is recommended to detach

the battery pack from the handset to prevent accidentally

turning on the phone by miss-touching the power key.

Do Not Use in Gasoline Stations

It is advisable that users switch off their mobile phones when

refueling is in process. It is dangerous that any spark may

cause an explosion or fire.

Safety

Do Not Use in Explosive Sites

The use of mobile phones should be restricted in potential

explosive atmosphere sites such as chemical plants, fuel

storage, or the area where blasting operations are in process.

Operating Environment

Mobile radio transmitting equipment, including mobile phones,

may be subject to interference and may cause danger.

Therefore, it is recommended that you follow any special

regulations in any area. Switch off your mobile phone whenever

the use is forbidden.

Standard Usage

For the satisfactory operation of the mobile phone, it should be

used in a normal operating position. Do not touch the antenna

while making a call.

Accessories

This phone can only be connected to approved accessories and

batteries. Do not connect the phone to incompatible products.

Appropriate Maintenance

Only qualified and authorized personnel should service the

mobile phone. Faulty installation or repair may be hazardous.

Emergency Calls (SOS)

An emergency call “112” can be made from the mobile phone

under any circumstances, and even the phone is locked. When

making an emergency call, you must be sure to give all the

necessary information, such as your name, your mobile phone

number, the location and the crisis situation, as accurately as

Safety

possible. In order to deliver the sufficient information to a rescue

institute, do not disconnect your phone immediately.

Use with proper care to reduce

electromagnetic interference (EMI)

This product has passed the inspection of the

Directorate-General of Telecommunications, Ministry of

Transportation and Communication. The highest reported

SAR values which are: Head 1.18 W/kg; Body-worn 0.225 W/kg

are lower than the standard value at 1.6 W/kg, maximum.

Basic Operation

Getting Started

Phone Overview

Warning: Please do not detach any parts and only use

manufacturer original component to keep the quality call phone.

Basic Operation

Installation & Removing

Installing the battery

1. Press the lock on the bottom and then slide the battery cover

backward and lift up battery cover.

2. Hold the battery and wedge it under two up corners and

press the battery pack into place. Make sure that golden

connector are facing the connector on the phone.

3. Place the cover into the track and slide it forward and lock

with cover latch.

Removing the battery

1. Turn phone off and repeat the above item 1 to open the

battery cover.

2. Lift up the bottom of the battery pack and pull battery by

sliding backward to detach the battery from phone.

3. Repeat above item 3 to recover the battery cover.

Basic Operation

Important! : Risk of explosion if battery is replaced

by an incorrect type.

Installing the SIM Card

1. Power off the phone and remove the battery. Make the

SIM card golden contact points face downward and the

oblique-angle edge align to up left.

2. Hold the SIM around 30° into SIM card slot and slight push

the SIM card bottom into the SIM card holder. Place the

card inside the SIM holder completely and make sure the

SIM latch fixes SIM card.

Removing the SIM Card

Power off the phone and remove the battery. Press down the

SIM latch and slide SIM upward to remove SIM from holder and

slot as shown in the figure.

Basic Operation

Connecting the Charger

To connect the travel charger to the mobile phone, you should

install the battery first. Follow the travel charger instruction, and

plug the connector with the ∩ sigh upside into mobile phone.

See below figure.

Note:

1. Do not remove your

battery or SIM card while

charging.

2. Use a compatible or

appropriate charger for the

phone.

3. Manipulate the charger

carefully, the connector might

be damage easy.

Removing the Charger

When removing the charger from battery, disconnect the plug

from the electrical outlet. Press the release buttons on two

sides of the connector simultaneously and pull out the

connector from mobile phone.

Keypad Description

Basic Operation

Button Description

Accept call and call hold.

Affirmative inputs: OK, Select, Call, save

and Reply.

Negative inputs: End, No, Cancel, Abort,

Quit.

As call is in progress, press this key to mute

the microphone so the other party would not

listen to your voice. Press again to

activate Microphone.

In standby mode, press the key to fast

access Inbox, Profile, hot key setting and

Softkey switch.

Affirmative inputs OK.

In standby mode, press the key to connect

to the internet to view and access Web and

WAP pages. (WAP connection should be

preset in advance.)。

Press the key to activate the voice recording

as call in progress.

Press this key to dial out a call.

In standby mode, press this key to view the

list of the last 30 phone numbers of

incoming, outgoing and missed calls.

End a call. Press and hold this key to turn

on/off your phone.

Press this key to swap input methods.

Press this key to delete single character,

number, or symbol from the right to left.

Long press this key will enable to delete all

texts and phone numbers.

Push keys to scroll up, down, left and right

for entering function menus, submenus and

setup selections.

Short Cut functions:

Up –swap standby mode pictures.

Down – Phone book list

Basic Operation

Button Description

Left – stay in the 1st layer of SMS list menu.

Right – Melody list in Profile.

The symbol of numerals and letters.

Keypads 2~9 are set as hotkeys; refer to

hotkey setup instructions for details.

Push and hold this key for 2 seconds to

launch voice mail box function. Enter the

voice box number (general 3 digits) of your

service provider before using for the first

time.

Push and hold it for 2 seconds and the “+”

will be automatically turn to an international

dial-up code. If you are in Taiwan, “+”

represents the international dial-up code

“002”.

Press this key, and “#” sign will be shown on

the screen; then enter phonebook address

number (SIM: 1 to 3 digits, depend on SIM

capacity, Phone Memory: 2001~2250) and

press the key to dial out this call as

the other quick way to making a call.

Press and hold it for 2 seconds and then “P”

sign will be shown on the screen; then to

launch Voice Dial function as a hotkey.

Fast access to make a call with extension

number – Input phone number and long

press this key to pop-up character “P” then

key-in extension number and then press

dialing key.

In editing mode, press the key to switch

input methods.

Press this button to activate and disable

vibration function.

Basic Operation

Button Description

In English Mode, press this key to switch

English letter between upper and lower

case. In T9 input Method, press this key to

switch input methods and symbols.

Adjust volume during a call.

In folder close mode, press Up key to

activate the backlight of Sub_LCM.

Alphanumeric Mapping

The alphabetical and numerical keypad mapping relations are

listed on the following table:

Upper Case Mode Lower Case Mode

1 Space .: /\│1[]{}() Space .: /\│1[]{}()

2 A B C 2 Ä Å Æ ç a b c 2 ä å à æ ç

3 D E F 3 É d e f 3 é è

4 G H I 4 g h i 4 ì

5 J K L 5 J k l 5

6 MNO6ÑÖ m n o 6 ñ ö ò

7 P Q R S 7 β p q r s 7 β

8 T U V 8 Ü t u v 8 ü ù

9 W X Y Z 9 w x y z 9

0 Space + - * / ( ) 0 Space + - * / ( ) 0

* : * . , “_ @ <> !； : * . , “_ @ <> !；

# # / =? % # / =? %

Note:

Basic Operation

1. Press button to switch between upper and lower

case letters and symbols.

2. By pressing and holding , you can exchange the

input mode among Chinese input, English input, and

numeric key input.

3. Pressing a number key in the editing mode will result in the

character appeared on the display.

4. Press again the button immediately after releasing, and it

goes to the next character in sequence as above table.

Switching characters will depend upon the duration of the

key press.

5. After releasing the button and wait for a second, the cursor

will move to next spot for new input.

6. If there are any differences between the character sets

listed in the table and on the phone, please refer to the

displayed characters on the phone.

Display Indicators.

Indicator Description

The battery level indicator. The more the battery

cell is, the stronger the battery is charged. The

battery cell flashes right and left when charging,

until it is full.

Basic Operation

Indicator Description

The earpiece has been inserted and used.

Indicates that the phone is using a roaming

network.

The vibration function is on.

The mute function is activated. (with blue color)

Both mute and vibration functions are activated.

Alarm is activated.

New message is in mailbox.

Messages are full of inbox.

Shows the signal strength of network connection at

your current location. The more the bar is, the

stronger the signal is received. (The total is four

cell.)

Shows that the data transmission cord has been

inserted.

Basic Operation

Indicator Description

CSD Connection is on.

WAP browsing is in connection.

Basic Operation

Making a Call

1. Power off the phone and install your SIM card.

2. If the battery is out of power, you can still connect to your

travel charger and use the phone normally.

3. Press to turn on. If the display indicates “Enter PIN ”,

key in the PIN number of your SIM card, (please refer to the

Manual provided by the telecommunication company for details)

and press .

4. Key in the area code and telephone number, and press

to dial the number.

The SIM Card

Your telecommunication company provides the SIM card.

Please use a small SIM card to fit the design of this phone. For

the SIM installation, please refer to page 22. This phone can

be used only with legally issued SIM cards and can receive or

send the calls only within the SIM network service range.

Battery and Charger

Basic Operation

The Li-ion battery that comes with this phone is rechargeable.

Please use the charger and the battery provided by the original

manufacturer to ensure a long lifetime for the cellular phone.

1. Plug the charger into an appropriate outlet that meets the

requirements of this phone. The other end is connected to

the phone. While the phone is recharging, the screen will

automatically display the current power recharge status of

the battery via a flashing signal. The phone can still function

normally if it is turned on while being recharged. Once the

recharging process is finished, the flashing signal will stop.

2. Once the recharging process is completed, the charger can

be disconnected from the phone and electrical outlet.

3. Use only chargers certified by the original mobile phone

manufacturer. This is an international charger (Model:

KWS05C is subject to change in different countries). Read

instructions on the charger label before use.

4. A ‘battery low’ message will be displayed on the screen to

alert you of battery low condition. The mobile phone will

automatically shut down when the battery is exceptionally

low.

5. If the battery is totally out of power, the battery requires to be

recharged at least ten minutes. Otherwise, it might have

difficulty to turn on.

Turning on the Phone

To turn the phone on, hold the key for about 2~3

seconds. If the message “Enter PIN:” shows on the screen, the

preset “PIN:” code of the SIM card must be keyed in (please

refer to the Manual provided by the telecommunication

company for details). Then, press the key.

PIN and PIN2 (4 to 8 digits)

A PIN (Personal Identification Number) code is stored in your

SIM card and is supplied by your SIM card network provider.

To prevent unauthorized use, your PIN1 code will be required

every time while you turn on your phone. Key-in the correct

Basic Operation

PIN1 code and press .

Important! :

1. If a wrong PIN code is entered three

consecutive times, the phone becomes

locked or disabled. You must ask for your

network provider to use the PUK code to

unlock or enable the phone again.

2. PIN2 code is for other functions, such as

certain number dialing and barring.

PUK1 and PUK2 (8 digits)

To enable a locked PIN code, the PUK (Personal Unblocking

Key) code is required. Check with your network provider for the

code. After getting the PUK1 code and unlocking the PIN1, you

can reset your PIN1.

Calling

Enter the area code and phone number, the press

button to dial out a call.

Dialing Emergency Numbers

1. Please turn the power on first. Enter an emergency

number 112; and press to dial out.

2. Most networks allow users to make emergency calls

without inserting a SIM card. In the case of no SIM card,

you’ll see the indicator on the down-left corner

after turning on your phone.

3. In the case of SIM card inserted, SOS sign will be

displayed on the down-left corner and without enter 112

number, press or keys to dial out.

Changing an Entry

Basic Operation

Pressing the will delete the last letter or number keyed

which you entered.

Answering a Call

Your phone rings or/and vibrates when receiving a call. Press

or to answer the call. Press to end the

call. If you are using an earpiece, you can press the button of

the earpiece to answer or terminate the call.

Recent Calls

The phone will record all the recent calls in which you received,

dial out, and unanswered calls. After pressing to enter

menu and to select submenu “Call List”, you can find

out all recent calls. The recent calls can accommodate up to 30

numbers. Press either button to browse numbers and

select a number to dial out by pressing button. There

are five choices you can select. They are “Call”, “Edit

Phonebook” and “Remove”.

Speed Dial

You may quickly search a number stored in SIM card by

entering the address (SIM Card: depend on SIM card capacity,

Phone memory address: 2001~2250) of a certain phone. Every

phone number comes with an address number in phone book.

Under standby mode, you can press button to get a “#”

sign on the screen and type in the address of the phone number

which you want to dial after the “#” sign. Then, press

button to dial a call.

Basic Operation

Holding a Call

Pressing allows you to put the on-line call on hold while

you make another call. When the second call is connected,

pressing allows you to switch between these two calls.

Basic Operation

Multi-party Calls

1. If, while talking to a party, you would like a third party to

join the conversation, press the key and dial the

number of the third party. Once the call goes through,

press and to conduct a three-party call.

2. If you would like to talk to a fourth party, repeat step one to

conduct a four-party call. (This system allows a maximum

6-party call.)

3. If you want to end the connection with any one of the

parties during a multi-party call, you can follow the steps

as below:

(1). Press

(2). Press the sequence number in which the party joined

the conversation. (For example, the sequence number of

the first call is 1 and the one of the second call is 2)

(3). After pressing , the party now can leave this

multi-party conversation.

Important! :

Before you make a multi-party call, make

sure you do not have a call on hold.

Voice-activated Dialing

Steps for using voice-activated dialing：

1. Store phone data in the phone book.

2. To set up voice calling function:

In the phone book menu, select the number and enter Edit

mode. Use key to switch each field. In the

voice-dial filed, press right key to create a new

record of voice. The message “Say Name After Beep”

prompts up on the screen. Follow the instructions and voice

Basic Operation

the name, in which you want to save, to microphone. After

first time input, the system will play back it for you to

recognize the voice. With your confirmation, the system will

request you to input the second time. If the voice-activated

name is already used in the phone book, then repeat the

above procedure and recreate it. After done, press

right key to Modify, Play and Delete.

3. Using the voice dialing：

(1). Press and hold key for two seconds or when the

screen is on.

(2). After the beep, voice the name for the number you want

to call, into the phone.

(3). The mobile phone will play the sample first. After your

confirmation, the number will be dialed.

Method of Input

Only under edit mode, you can input the content by various

methods. This mobile phone has ten fields for edit; that is;

name field of Phonebook and name search, content of

Message, rename file name of tone edit, note making in the

calendar, notes for alarm, rename of voice memo files, power

on greeting, WAP file name, rename file name of customer in

the Profile, and the rename of audio and image file names in

File Manager. After enter these items, press to enter edit

mode. According to the setup of language, you can have

default setting of input method in your own language.

However, if you want to change to other methods, press to

enter submenu. For characters input, you can have T9

English, ABC(English), 123 (numeric), T9 Russian and Russian

Symbols. By using key to select the input method you

want. No matter that T9 English or ABC English methods,

Basic Operation

press turn on function for upper case and lower case。

By pressing and holding , you can switch to Symbols.

By pressing and holding , you can switch among Chinese,

English, and Numeric methods.

1. T9 English

While inputting, you can only press the button of letter without

selecting particular one. The T9 English will smartly detect what

you want for written wording. Switch upper case and lower

case by press ; for example, you can have upper case of

first letter 『Eng』, or all in upper case 『ENG』, or all in lower

case 『eng』by switching and pressing numeric button

『123』.

Example：Smart

Button pressed as follows as below：

Æ press onceÆ press once Æ

press once Æ press once Æ press

once

Only six steps to have a word “Smart” completely. After keying

in 7、6、2、7、8, two words can be selected. One is Smart and

the other is Roast. Press to select the wording such

as “Roast”. Use right key to deselect the yellow

highlight. If you want to re-highlight the whole wording, press

down key to recover it.

Menu Function

For speedy access with certain options, press to proceed

with Inbox, Profile, Hot Key Setting, and Soft Key Switch. This

mobile phone provides different features and several options to

meet your needs by manipulating ：

Phone Book

The phonebook menu lets you save the

names and phone numbers in the SIM

card or in the memory of the phone,

press to enter this menu. You

may also have Search, Add Entry, Edit,

Delete, Copy, P. Book Setting and

Memory Status. This menu will show the

records according to the sort you selected, and the detail window

will show the content of current record. Depended on the

selection of SIM or phone itself, phone memory module has 10

fields, and SIM module has 6 fields. You can use to

move forward and backward to those fields. If you want to get

into the submenu, press left/right key. With inputting

completely, press to save or discard this record.

If there are three sets of phone number, press , and then

press to select the one you want to dial out.

Menu Function

In search function, the “search name” input window will be

displayed on the screen. After typing in the name that you want

to search for, then press . If the input methods are

needed, press to enter it. When the first letter you typed fits

in with your list, the first one will be highlighted and all matched

data will be listed down. You can use to browser and

view the rest data.

Add Entry

After pressing key to launch the function, items of new

record including memory type SIM/Phone, name, tel. number,

caller groups, voice dial, e-mail, address record number, and

birthday, will be displayed on the screen. Blank is not allowed in

both name and phone fields.

1. The phone will automatically assign a memory location to

store the data on the SIM or phone itself according to your

selection.

2. You will need to enter both the phone number and name, and

no data will be stored if you leave any of these two items in

blank. In the name field, press to enter text entry mode,

and press again for input methods selection. See on

page 34.

3. Empty filed is not allowed in phone number. Three sets of

phone numbers can be input for handset setting (NVM), and

one phone number is for SIM card setting

4. You may assign a caller group to a phone number, so that you

can identify it next time when it comes in. There are 7 default

choices accessible by pressing right/left key and

choosing from the submenu; that is, Family, VIP, Colleagues,

Menu Function

Friend, Classmates, Business, and None.

5. Move to the field of Voice Dial and press to start this

function to record the voice into your voice record. Refer to

page 33.

6. Enter E-mail address to the field with handset setting (NVM).

By pressing to search _ underscore, and ”.” dot can be

found and entered into it

7. Normally, the phone will automatically generate an address

number on input field. If you want to assign a memory

address to the data, you may enter the address and the

phone will store the data to the address you assign. However,

if you put it empty, no data can be stored.

8. Enter the birthday and date format will be dd/mm/yyyy.

Edit

This function is for you to modify or edit an existed record. Use

to select the field you want to modify. All fields and

items should be manipulated as the same as above “New

function”. In the Voice Dial field, Modify, Play, and Delete can be

selected in the submenu to record the voice, play and remove the

voice from this field

Delete

Select this function to remove the phone record from your

address book. After launching this function, three selections are

“Delete One”, “Delete All in SIM Card”, and “Delete All in Phone”

in submenu by press . A message prompt will ask for

your confirmation of this deletion before execute deleting. Press

to save data or to discard.

Menu Function

Copy

You may use this function to copy single or all phone records to

SIM or handset memory at your will. On launching this function,

the system will automatically provide you an available position.

You may also give a designated position to save your data instead

of system assigned number.

P.Book Setting

1. Caller Group

It is for setting a ring tone in corresponsive with a specific

incoming call. After entering into this option, select one of the six

ring tone groups to setup such as Family, VIP, Colleagues,

Friends, Classmates, and Business by key. Press the

key to enter this option, the key to select the ring

tone from the list, and press to play the tone. Press the

key to switch the selected tone.

2. Sorting

This function is for you to select the way phone number is sorted

in your phone list. You may sort By Pinyin (Chinese Phonetic Alp)

or By Alphabet and save the sort setting into the handset.

3. Display SIM Records

There are two display modes. One is to display the phone

numbers that are restored in handset only. The other is to

display all the phone numbers no matter that are saved in handset

or SIM card. You can switch your screen to show the phone

numbers by handset only or by all at your willing.

Memory

Menu Function

This provides inquiry about the total number of records and the

empty spaces left for the phone records in the current SIM and the

memory of the handset. Also, you can know how many Voice Dial

numbers is in phone list.

At this stage, memory size of SIM is 100 records in total and that

of handset is 250. Voice Dial only is sum up to 20.

Message

The phone allows you to send and edit

Short Messages (SMS). Whenever you

receive a text or voice message, an

indicator will appear on the display. The

messages might have problems to

deliver between different network

services. Please contact with your

service provider.

SMS

Selecting this menu allows you to input a phone number you

would like to send, together with a message. After editing, press

to enter submenu for Send, Send & Store, Send & Save to

Pre-Message, and Store. Send function can deliver out the

message, and Send & Store can complete both delivering and

saving. Store function only save the message into the SIM card.

Currently, handset memory is not supported to store messages.

1. Write

Under Write item, press button to enter content edit mode as

well as press button again, you can have Input Mode,

Pre-Message, Bitmap, Animation, and sound in the message

content to send.

If you want to add text, pre-message, picture, animation, or sound,

Menu Function

use keys to move on selected items such as picture, and

then press to confirm.

For text input method, refer to page 34 for detail.

After confirming OK by pressing , in the field of phone

number, you can press down key to enter phonebook

and search the number directly.

2. Inbox

After launching the Inbox, details of all messages stored in the

SIM will be displayed on the screen. Details include the name,

phone number of the sender, and the sending time of message.

All unread messages will be indicated by an envelope sign “”.

Press the key to select and display a message on the

screen. If the content of message is too large, you can press

to browse message. Also, press key to enter the

submenu including Delete, Forward, Reply, Call and Store. The

Delete function can erase the record of message in the SIM card;

the Forward function can forward a message to other people; the

Reply function can reply to the sender of the message; The Call

function will allow you to dial out the phone number directly and

the Store function can save the phone of message to the SIM card

or handset.

3. Outbox

Same functions as above.

4. Delete

This menu provides the same interface to operate as described in

the Read menu, with the exception of the key denoting a

delete confirm dialog. Or, you can select “Delete All” at the

bottom of list, and it will allow you to delete all the files after

Menu Function

confirming deletion. Both messages of Inbox and Outbox can be

deleted.

5. Free Count

This menu tells you the total messages stored on the SIM card

and how much free memory space is available on the SIM card.

For this handset, it allows you to keep 10 messages in SIM card

space.

Important! : When size of the message is too large and over a

regular store space, this message might be identified as two or

three, or even over three. Therefore, the free space in reality will

be less than that displayed on the screen.

6. Setting

The following items can be setup:

~ Pre-Message

This menu allows you to set up eight sets of user pre-defined text

in a prompt window of Pre-Message. On the indicated items,

press to have the input window to key in pre-message

text and press again to save it.

~ SMS Center

This menu item allows you to enter SMS center phone number.

Messages will be sent to and received from other users through

exchange center of the network’s message service, although this

service may not necessarily be supported by your network.

~ Valid Time

This menu allows you to specify the time in which your messages

are going to be stored at the message service center or network

service. You can select between numbers of predefined periods. If,

however, nothing is selected the phone will automatically choose

a sensible default value for you.

~ Auto Display

The menu controls actions when incoming messages come in. If it

is switched on, you have the option to read the message

immediately. If it is switched off, you are notified on the display by

Menu Function

a “” indicator.

~ Status Report

When sending out a message, the receiver will return a receipt to

SMS and SMS will forward it back to sender.

Broadcast

The Broadcast function is to send the message to all users in a

certain region via the telecommunication network. This function is

provided by telecommunication company. Please contact you

supplier.

1. Read

This allows you to read the last broadcast message received. The

phone stores this last message only when it is switched on.

2. Filter

This allows you to select the type of cell broadcast message you

want to receive. The filter menu contains a list of codes for CB

type of messages, which are defined by the network service.

~ All

Receive all broadcast messages.

~ None

Receive no messages.

~ List

List all the channels in which you want the messages to be

received. Depended on different broadcast area, the number of

the channel will be different. By pressing the key, you can

enter selection menu to add or delete.

3. Auto Display

This allows you to switch the auto display function on/off. When

the function is set on, broadcast messages will automatically be

displayed. Using the arrow keys allows you to scroll the

messages. Pressing OK or NO allows you to exit. Broadcast

messages automatically disappear after a short period of time.

(Note: The function requires the support by telecommunication

network service. Contact you telecommunication service

Menu Function

provider if you want to use this service.)

Voice Mail

1. Call V-mail

This menu allows you to enter your voice mailbox and listen to

calls. (You need to set the number of your mailbox before you use

this function.)

Important! : You can also enter your voice mailbox

by pressing in the idle mode.

2. Voice Mail

Enter you voice mail dial-in number which is always provided by

mobile phone company.

Profile

There are 6 profiles (Typical, Silent,

Outdoor, Handsfree, Meeting, and

Customer) to meet your different needs.

After selecting a suitable profile, push

Activate to enable profile. If you want to

personalize the profile, launch the

Adjust menu and select the item you

want to personalize.

Adjust

You can change the setting of the follow profiles with this function.

1. Activate

Activate all settings under the selected profile.

2. Ringtone and Volume

Menu Function

Using the keys allows you to select the ringing tone

pattern. When the tone is selected and is played, you can set up

the volume of tone at the same time. There are 34 different

ringing tones or melodies for your selection.

3. Key Sound

You can set on/off the volume of the keypad tones. They are

DTMF, Silent, Normal.

4. Crescendo

In this menu, the ring tone is adjusted to ascending. It can be

turn on or off.

5. SMS Rec Tone

When receiving SMS message, the phone will alert you with ring.

You can select to turn it on or off.

6. Vibrator

You may switch on/off the vibrator. This feature depends on which

model you are using.

7. Service Tone

When this function is set on, the phone will generate a tone when

a network is available.

8. Auto Answer

Under this menu selection, you may enable or disable the auto

receiving function for incoming calls while you are using an

earpiece.

9. Rename (Only in Customer mode)

On the selected file, enter dialogue box to rename the file name.

Under the edit mode, press to enter Input Mode on page

34.

Menu Function

Call Lists

This menu records the charges and the

length of time or duration of all incoming

and outgoing calls in hours, minutes,

and seconds. Please contact with your

telecommunication company for

providing charge information.

Missed Call

After entering this menu selection, the screen will display all the

missed call. You can use select one of records, press

to call, move to phonebook into your SIM or handset

memory for save and remove.

Launching the menu and listing all the missed call. One more

function is listed on the manual “Delete All” records of call lists.

Incoming

List all of answered calls. The functions are the same with above.

Outgoing

List all of dial-out calls. The function is the same with above.

Call Info

This menu records the charges and the length of time or duration

of all incoming and outgoing calls in hours, minutes, and seconds.

1. Last Call

This displays the duration of the last call.

2. Total Calls

Menu Function

This displays the total duration of all incoming and outgoing calls.

3. 1-minute Beep

This sends you a warning beep every minute (Beep will be

activated at the 55 seconds), while a call is in progress.

4. Charge Info

This function allows you to calculate telephone fee to facilitate

cost control.

Note : This function including Total Charge, Max Charge and

Unit Price will be supported by telecommunication service

provider. Please contact with your supplier for detail.

~ Total Charge

This displays the total charge of all calls. Pressing allows

you to reset the value, but it requires entering PIN2 before you do.

~ Max Charge

This allows you to set a maximum limit to your total cost. You can’t

dial any number if you go over your limit until the total charge has

been reset. As similar to total charge, you need to enter PIN2 for

setting.

~ Unit Price

This allows you to enter the unit price. After entering your PIN 2

code you can input price and unit. Pressing allows you

to select different entry fields.

Settings

Your phone offers many options, making

it your best partner.

Personal

Menu Function

1. Language

You may select the display language in this menu. There are

English, and Russian.

2. Greetings

You may enter greeting words in the edit window so that the

phone will display greetings each time you turn it on.

3. Power On/Off Melody

You may select the melody that will play each time you turn the

phone on.

4. Folder On/Off Melody

You may select the melody that will play each time you open or

close the folder.

5. Hot Key Setting

Reset shortcut keys have the following functions:

Long Key 1 is predefined as Call Voice Mail Box.

2. Messages ------------------ Long Key 2

3. Silent ----------------------- Long Key 3

4. Show Clock ------------------- Long Key 4

5. Calendar -------------- Long Key 5

6. Calculator ------------------ Long Key 6

7. Record ----------------- Long Key 7

8. Voice Dial----------------- Long Key 8

9. Standby Mode ----------------- Long Key 9

This function allows you to press a designated key for 2 seconds,

while in idle mode, to activate a function.

If users want to change the programming of shortcut keys, please

follow the procedures described below:

a. Enter the menu. Use to select the numeric key to be

used for setting. Press to confirm.

Menu Function

b. Then use again to choose the function to be set. Press

to confirm.

6. Own Number

You may store the SIM number in the phone.

Clock

You may set time, date, alarm and auto on with the clock setting

function.

1. Set Date

After launching the menu, push the keys arrow to select

setting date, time, data format and time format. If you select

12-hour system, the cursor will stop at AM/PM, push the

arrow keys to select AM/PM. You may push the arrow

keys to select date and time formats.

Available date formats: yy/ mm/ dd or dd/ mm/ yy or mm/ dd/ yy.

Available time formats: 24-hour or 12-hour

2. Set Alarm

It provides a set of alarm ring tone. The user may set the date,

time, melody, snooze and note of the alarm by using .

You may select three different modes: Disabled, Once, and

Daily.

3. Power Off

In this menu, you may set the function and the time of turning off

Menu Function

your handset daily.

Screen

1. Standby mode

There are 3 standby screen modes: picture and text, clock, digital

clock and calendar.

2. Color Theme

You may adjust the color background, and wording for the

subjects of menu functions.

3. Network Name

You can decide whether display the name of the networking

phone company on the screen.

4. Show Clock

Set “show clock” to display time and date on the screen.

5. Standby LED

After this Standby LED function is enabled, the standby flash will

be around 5 Sec to discharge interval.

Call Setting

1. Call Waiting

You may set the call waiting function on and off in this menu.

~ Activate

After you have set the call waiting to Activate, you will be alerted

by audio and video signals when another call is coming in while

you are making a call.

~ Cancel

If you set this function to Cancel, the phone will not alert you of

another incoming call but directly divert that call to other number

or your voice mailbox.

~ Status

It reports current status for Activate or Cancel

Menu Function

2. Divert

Call divert is a common telecommunication service, when you are

unable to answer a call or the signal is out of service range, you

can divert all incoming calls to another number.

~ Forward to

Set the number you want your calls be diverted to and the Delay

before divert (default is 15 seconds). When a call comes in, the

phone will divert the call to the preset number after the delay time.

~ Unreachable

Set “divert when not reached” function on or off.

~ If No Reply

Set ‘divert if not answered’ function on or off.

~ All Calls

Set ‘divert all calls’ on or off.

~ If Busy

Set ‘divert when busy’ function to on or off.

~ Status

Get status of all divert functions.

~ Cancel All

The function of this option will cancel the setting for diverting all

incoming calls.

3. Answer Mode

Press any key to receive the incoming call when this function is

enabled.

~ Normal answer

Press to answer when this function is enabled.

~ Any key answer

Press any key to receive the incoming call.

~ Folder answer

Open folder to answer incoming call.

4. Present Number

This option sets the handset to show or not to show its phone

Menu Function

number when dialing out a call.

Network

This menu allows you to select and register with the network

that you want the phone to use.

1. Select Method

When the phone is switched on, it looks for available networks

and then selects one of them. You can also manually select the

desired network from the list.

2. New Search

You can search available networks and manually select one of

them.

3. Select Sequence

You can add the networks by manually. Enter the Country Code

and Network Code to add the new network into the list.

Security

1. Bar Calls

Call barring is a telecommunication network function to enable

users to bar both incoming and outgoing calls in different

conditions. Enter the Supplementary Services Password

(obtainable from service provider) before setting up call barring.

Please set mailbox to OFF before applying call barring.

~ All Out

You may bar all out calls (except emergency call) with this

function.

~ Out Intl

You may bar all out international calls with this function.

~ Out X Home

You may bar all out international calls during roaming except calls

to home country.

~ All In

Menu Function

You may bar all ingoing calls with this function.

~ In If Abr

You may bar all ingoing calls (roaming) when you are abroad with

this function.

~ Status

You may check the status of call barring with this function.

~ Cancel All

You may cancel all barrings this function.

Note: The availability of barring services is subject to the

network functions.

2. PIN Check

This function provides you with two options. One is to make PIN

Enable, and the other is to make PIN Disable.

3. PIN Change

Make sure that you have PIN enabled. When you switch the

power on, the phone will prompt you to input the PIN number.

4. PIN2 Change

Changes the PIN2 number. You need to input the original PIN2

number before you make changes. (Please contact your

telecommunication company for detail.)

5. Fixed Numbers

This function only dials the numbers in the fixed dialing

phonebook. (It needs the PIN2 number).

6. SIM Lock

This function allows you to lock the phone with a specific SIM card.

This feature is designed to prevent somebody else from using

your lost or stolen SIM card(s).

~ Set Lock

To activate the SIM lock function.

~ Change PCK

This allows you to change PCK code.

Note: The factory default PCK is supported by the

Menu Function

manufacturer is (0000).

Reset Setting

After entering into this option, you may select whether or not to

convert the settings of your handset to the reset settings.

MMedia

File Manager

Under file manager menu, Image, Audio,

and OSD frames can be manipulated as

below functions.

~ Open File

On the selected file, press to open it as full screen display.

~ Send MMS

By using to select the file, press to send MMS.

Refer to page 53 for detail.

~ Save as Wallpaper

You can save the file as wallpaper.

~ Save to P.Book

You can save the file as picture displayed when the call is coming.

~ Rename

On the selected file, enter dialogue box to rename the file name.

Under the edit mode, press to enter Input Mode on page

38. Chinese file name is not supported.

~ Delete

Delete the selected file.

Menu Function

~ Delete all file

~ File Sort

Enables all files sorting.

By Name

By Date

By Type

~ View

List

Press to display selected image.

Icon

Display 9 image files on the screen at the same time.

~ Detail Info.

The detail information will include image type, file name, file date,

and file size.


In the phonebook, there are image files will be displayed on the

screen when you review or browse it or when you receive the

calls. Those images will be managed and stored under this

folder.

Audio

Ring tones or download audio file are stored under this folder.

Free Space

This menu tells you the total space stored and how much free

memory space is available.

Menu Function

Game

1. Game

~ Puzzle

Choose your own picture from camera snapshot, last game, or file

manager to start game. By using to move empty grid

till the whole picture is well compiled. Press left soft key

for viewing the picture and press to exit the game.

Enable the user to turn on or off the game sound.

~ Hostage Salvation

Choose the picture for bad guy from camera snapshot, last game

or file manager to start game. By pressing 1 to 9 numeric keys,

shoot the bad guy and win 10 points for each shoot. In case

innocent figure shot, 5 points is deducted. Total time is 2

minutes. Enable the user to turn on or off the game sound.

~ Reversi

Before starting a game, the sequence order must be selected

(“Play First” or “Player Later”). When the game starts, you can use

keys to position the black piece. Press to confirm

the surrounding of white piece. When the chessboard is full of

pieces, if there are more blacks than whites, black wins the game.

The game under this section allow you to save and continue the

game without restart over every time. Press to save your

score and pause. Press the same button to continue the

game. You may also save the score and exit the game by

pressing to leave. When you next time enter to the

Menu Function

same game, select stored game to continue the game when you

left last time. Any incoming calls while playing games, you may

press button to answer the call and save the game that is

been played.

~ Coin Elf

Before the game, you can read the help. When the game start,

the coin should be selected on the screen, The money master will

follow the coin to move, the player have to move and lead the

money master to win the treasure. Press to pause the

game,, and use to move.

Tone Edit

Under this function, you can create your own tone and setup them

as your ring tone under Audio Profile. There are total 5 tones are

allowed you to edit. Press to enter edit mode including

play, edit, reset, tempo, instrument, and name。

1. Play

This section sllows you to display the edited melody from the

mobile phone. Press to exit while playing. Otherwise,

the system will exit until the melody is complete played.

2. Edit

~ Keypad functions

Numeric 1-7 represent the musical notation from Do toSi, 60

notes can be entered.

High octave

Delay in one beat for previous note

A rest

Menu Function

Raise half tone or a dot to extend half beat for previous

note.

One extend (half beat or a quarter beat) and lower.

~ Edit

follow the steps below：

a. Press numeric pads 1~7 to select note. Press to delay in

one beat for previous note, display on screen as”-“. Press

to enter a rest note displayed as”0 “

b. Press to switch into higher octave

c. Press to raise or lower half tone, “#” or “.” is displayed

on screen.

d. Press to switch for long note “-half tone = a quarter tone”

and for lower octave “.” If higher octave is selected, there won’t be

any mark for lower octaves.

e. After a tone is edited, press to shift the cursor to the

next position, and then continue editing the next tone.

f. If the setting is not correct, please move the cursor to the

incorrect symbol to have direct revision or move the cursor to last

the note and press to delete the note and re-enter.

g. Once editing is complete, press to exit. If users want to

restore the original setting, press to cancel the editing.

3. Reset

After confirming to tone reset settings, the defined tone will be

clear.

4. Tempo

There are 5 modes: More slowly, Slowly, Normal, Fast, More fast.

You can select any of the modes to adjust the rhythm.

5. Instrument

Select the instrument to edit the tone including BritePno, Marimba,

Menu Function

Harp, Crystal, and Banjo.

6. Rename

Allow you to enter the name for the tone. Under dialogue box,

press to enter edit mode. For Input methods, refer to

page on page 38.

PIM

Under this function, you can do simple

mathematical calculations and currency

exchanges.

Calcuator

1. When “ 0 ” is shown enter the

operational digits. (press key for

decimal point)

2. Choose operational sign: See on the screen

shown + ~addition; shown -~ subtraction,

shown *~ multiplication, and /~division

3. Enter second number.

4. Press or key to get the result. If a mistake is

made during the operation, press key to make a

correction. Holding key for few seconds clears all the

digits.

Menu Function

Calendar

You may check your reminders in this menu. First, the current

date will be displayed.

Push the arrow keys to select

date, push to launch calendar menu,

and push to exit menu. You may push

the arrow keys to select a reminder, and then push to

launch the selected reminder menu (View Day Note, Make Note,

Erase Note, View All Notes, Go To Date).

1. View Day Note

Select today’s reminder to view content, and push to edit

or erase content.

2. Make Note

You may select reminder type (reminder, phone, meeting,

Birthday).

Push the arrow keys to select reminder types which

including Meeting, Birthday, Anniversary, and Customize.

Set date:

Set time:

Set alarm: After the time and date of the reminder are keyed

in, press the key to set the alarm for the reminder, and

the key to shut off the alarm of the reminder.

Menu Function

In the reminder field, you can input the memo. Refer to text input

methods on page 38.

3. Erase Note

Select erase types: erase reminders of chosen day, erase one by

one, erase all, and auto delete. In auto delete, there are 3 items;

they are auto del 1 month before, auto del 2 month before, and

auto del 3 month before.

4. View All Notes

While checking all the notes, press to enter the delete,

modify or move data menu option. Press to view the

content of each individual note. If the content is over a page long,

press key to change pages.

5. Go To Date

Enter the date on which you want to receive the reminder.

Exchange Rate

For first time users, push buttons to move cursor to Set

Rate to key in exchange rate for Domestic and Foreign. After

setting, enter the Domestic currency value, the Foreign exchange

value will be automatically calculated on the screen.

Voice Memos

Voice reminder allows users to record a maximum 20-second

audio input. The main advantage of this function is to assist users

Menu Function

in record messages when they do not have a pen and paper at

hand.

1. Record

When users want to record messages, they simply enter this

menu and press the “Record” key to start the recording process.

2. Playback

~ Playback

When users want to play the messages, they simply enter this

menu and press the “Play” key to listen to the recorded message.

If there is a * mark before a certain record, it means the message

has not been played before.

~ Delete One

In this menu, users can delete the saved records individually.

~ Label

When users enter this menu, they can check the time, date and

record length when a certain record was recorded.

3. Options

In this menu, users can select one of the following methods of

recording:

~ Self Only

When this function is on, it can only record the conversation of this

phone content.

~ Other Party Only

When this function is on, it can only record the conversation of the

call content.

~ Both

This function enables users to record directly from the callers and

the content of conversation.

Note: The ‘2-way recording’ (default) will be resumed after each

recording.

When on the line, press to enter record item, and press

to confirm recording.

Menu Function

World clock

After entering into this option, you may press keys to

browse the current time of the place over the world.

~ Set Location

You may set your present location to browse the time in

different countries with the time display function.

Automatic

The mobile phone will automatically set the location for you.

Manual

You may select your own location with the manual setup.

WAP

Access WAP

You can use this function to browse the

World Wide Web to get the latest

information. The data will appear in a

special format compatible with your

mobile phone. You might have to

provider to be able to connect to the World Wide Web.

Menu Function

Graphic and Message of Browser

Shows the version of OPENWAVE and Copyrights.

Definition of WAP Keys

Button General Long Key

Clear input. Clear all inputs.

Return to

pecious page. End WAP.

Open inbox.

Favorites

You can connect with the Internet immediately by using the

bookmarks.

There are 1-12 my Favorites are set on screen. Browser them

by using . On the selected item, press to access

internet.

Menu Function

Press to select other function such as New Bookmark,

New Folder, Delete all, and Hotkeys.

If there is not existed bookmark within folder, manipulate

to move the cursor to the context, and build new bookmark and

Hotkeys. If the bookmark is existed, then it will display with title,

URL, and folder name that can be modified and saved.

1. New Bookmark

Press numeric key 1, and enter Title and URL to save as a

bookmark. To enter the field of Title, press to enter edit

mode first, and press button to select T9 English, symbol,

numbers, Emotions, and abc input method. You may also press

keys to select a exist Title. When using T9 English and

ABC method to input, you can press to switch upper case

and lower case or first letter capital.

Press to go to the bottom of screen, a Save button appears

on screen, press to save the bookmark; press to

go back to Bookmarks menu.

2. New Folder

Press to enter Folder edit mode. Press numeric key 2 to

create a new folder. After entering edit mode, use the same

input methods as above. After entering complete text, repeat

pressing until a “Save” button shown on screen, press

to save data. Or you can press button to go back to

Bookmark menu.

Menu Function

3. Delete all

Allows you to delete all folders and bookmarks.

4. Hotkeys

There are 1-9 numeric keys enable to be set as hotkeys. If you

wan to assign numeric key 1 as a hotkey for the specific website,

use to move the cursor to “1 Unassigned” and press

button to go to bookmark list. Press to select

that specific website URL. Then press to select the

bookmark to complete the hotkey setting.

Go To URL

This allows you to set up the protocol web site.

WAP Settings

After entering this menu selection, users can program the mobile

phone to search for the SIM card to see if it is equipped with

GPRS function.

1. Connection

You can select one of the six files preset in the menu to connect.

The connection will be made through the chosen file.

~ Add New

Name

Enter the “name” function screen, you can clear the preset file

(press the key), name and rename it.

Menu Function

Homepage

You can reset the homepage by pressing the key to

clear the preset Web address and keying in the new web

address you want.

IP Address

This function allows you to set the IP web address you want to

connect to.

Bearer

Supports both GPRS, and CSD.

User name

This function allows you to set a username to register to the WAP

website. The function need to be supported by your

telecommunication service provider.

Password

Set the password for logging in the WAP website.

DNS IP address.

Set DNS IP address to register to WAP website. The service is

provided by telecommunication company.

Linger Time

Modify Linger Time for connection, press button to enter

Linger Time field. The default setting is 90 seconds. (Unit:

second)

APN

If you select GPRS to browse, you need to input the Access Point

Name of your system service provider.

Security

This function provides the Internet security service, you can select

on or off.

Store

Save all settings.

Menu Function

~ Add from List

BeeLine WAP

MIS WAP

MegaFon WAP

2. Color Scheme

Color palette will provide three colors: Blue, Red and Green.

3. Clear Cache

This option allows you to clear all data from Cache temporary

memory.

4. Reset all

Select this option to go back to WAP default setting.

GPRS Setting

Two functions under GPRS setting menu:

1. Permanent

2. Needed

STK( SIM

TOOLKIT ).

This selection menu can only be

displayed if your SIM card supports

Value-added Services. Regarding the

details as to how to use SIM services,

as well as price and other information,

please contact your telecommunication Service Company.

Important :

Menu Function

The STK service is provided by your

telecommunication company. The name of

menu, title, and content are defined by your

telecommunication company. Due to the

content size may be too big to fit into the

screen of your mobile phone, some of text

may not be displayed.

Battery

 The battery is rechargeable up to hundreds of times, but it

capacity will reduce. You may need to replace a new battery

when the operation duration (calling and standing duration)

reduces evidently.

 Remove charger from the source each time after charging.

Over charging will shorten the life of the battery. Avoid

charging a battery for over 24 consecutive hours.

 Use only batteries certified by the mobile phone

manufacturer.

 Extreme temperatures will affect charging performance. The

desirable ambient temperature for charging is 0°C-45°C

(32°F-113°F).

 Do not use damaged or old batteries.

 Avoid contacts of the + and – poles of the battery with metals,

such as coins, scissors, and pens. It will damage or cause

short circuit to the battery. Place spare batteries in a safe

place or wrap them up with insulated materials before putting

inside your pocket or handbags.

 Extreme temperatures will reduce the capacity or shorten the

life of batteries. Avoid placing batteries in extreme

temperatures, such as inside vehicles or near air-conditioner

outlets. The desirable battery storage temperature is

15°C-25°C (59°F-77°F). Batteries that have been charged

may not work properly in extreme temperatures.

 Keep batteries away from water or fire.

 Dispose batteries according to local environmental

regulations.

Care and Maintenance

Follow the instructions below to take care of your mobile phone.

They will help you to enjoy life with this product.

 Keep the mobile phone and its accessories out of children’s

reach.

 Keep the mobile phone dry. Rain, moisture and liquid contain

minerals which will corrode the circuit of the mobile phone.

 Keep the mobile phone away from dirt or dust.

 Keep the mobile phone away from heat. Heat will shorten the

life of electronics, damage the battery, or even deform or

corrode the shell of the mobile phone.

 Keep the mobile phone away from coldness. Condensation

takes place and the moisture will damage the circuit board

when the mobile phone resumes normal temperature.

 Do not open the mobile phone. Non-professional treatment

may cause damage to the mobile phone.

 Avoid falling, impact or vibration of the mobile phone.

Improper external force may damage the circuit of the mobile

phone.

 Do not clean the mobile phone with chemical solutions or

detergents. Gently wipe the shell of the mobile phone with a

soft cotton cloth and clear water or mild soap.

 Use accessories and batteries from the manufacturer.

 Contact your nearest service station if the mobile phone is

out of order. Our well-trained technicians will provide you the

best service.

FCC Regulations

Conditions of Use

Operation of this TG7 mobile phone is subject to the following two

conditions; (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including

interference that may cause undesired operation.

This TG7 mobile phone generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

If this device does cause harmful interference to radio or television

reception, which can be determined by turning the device on and off,

the user is encouraged to try to correct the interference by one or more

of the following measures:

1). Reorient or relocate the receiving antenna.

2). Increase the distance between the device and receiver.

3). Connect the device into an outlet on a circuit different from that to

which the receiver is connected.

4). Consult the dealer or an experienced radio/TV technician for help.

The radiated output power of this internal wireless radio is far below

the FCC radio frequency exposure limits. Nevertheless, the wireless

radio shall be used in such a manner that the radio is 1.5 cm or further

from the human body. However, the user of wireless radios may be

restricted in some places or situations, such as aboard airplanes. If

you are unsure of restrictions, you are encouraged to ask for

authorization before turning on the wireless radio. Several restrictions

and cautions of using mobile phone are listed in the Safety.

FCC RF Exposure Information

Read this information before using your handset

In August 1996 the Federal Communication Commission (FCC) of

the United States with its action in Report and Order FCC 96-326

adopted an updated safety standard for human exposure to radio

frequency (RF) electromagnetic energy emitted by FCC regulated

transmitters. Those guidelines are consistent with the safety

standard previously set by both U.S and international standards

bodies. The design of this phone complies with the FCC guidelines

and these international standards.

Use only the supplied or an approved antenna. Unauthorized

antennas, modifications, or attachments could impair call quality,

damage the phone, or result in violation of FCC regulations.

Do not use the phone with a damaged antenna. If a damaged

antenna comes into contact with the skin, a minor burn may result.

Please contact your local dealer for replacement antenna.

Body-worn Operation

This device was tested for typical body-worn operations. To comply

with FCC RF exposure requirements, a minimum separation

distance of 1.5 cm must be maintained between the user’s body

and the handset, including the antenna. Third-party belt-clips,

holsters, and similar accessories used by this device should not

contain any metallic components. Body-worn accessories that do

not meet these requirements may not comply with FCC RF

exposure requirements and should be avoided.

For more information about RF exposure, please visit the FCC

website at www.fcc.gov

Compal Electronics TG7 PCS Band GSM Phone User Manual Manual

Compal Electronics Inc PCS Band GSM Phone Manual

Manual

Navigation menu

Namespaces

Views

Navigation
