Contel Electronics Technology TAB720 7" Digix Tablet Model Number: Tab-720; Tab-710 User Manual TAB 720 manual 100x140 110927

Shenzhen Contel Electronics Technology Co.,LTD 7" Digix Tablet Model Number: Tab-720; Tab-710 TAB 720 manual 100x140 110927

Contents

TAB-720-User manual_Part2

11
6.4 Music
Click the icon , and then click to enter the music mode, and
then click one song to enjoy and the interface will be shown as below.
1. Click to enter party shuffle mode.
2. Click to switch over between Play All mode and Play Single
7.1 Some fast operations
To return to the home page, click.
To adjust the volume, click / .
7. Tips and other information
mode.
6.5 Camera
Click to enter the mode for shooting pictures.
To operate the device in this application:
1.Click the icon at the lower right angle to shoot the picture. You can
save the picture to DCIM/CAMERA under the SD root directory.
.
2.Move the slide block on the icon at the right, and you can change
from shoot mode to video mode.
3.Click the icon on the upper right corner to view the previous picture,
and where you can perform such operations as deletion, sharing and setting
as wallpaper or as a contact person icon the . Click Finish to return to
4.Move the left icon rightward, and you can set such items as storage
place, picture size and picture quality for the camera.
shooting interface.
12
The large-size LCD screen of the device will consume quite a lot electric
power. To extend the working time of the battery, you may reduce the use
of some functions.
1. Watch movies, listen to music or shoot pictures.
2.Brightness: Press Setup Display(display setting)Brightness
(lower the brightness).
7.3 About the battery
7.2 Setting for shortcut operations
7.2.1 Access to Internet in a wireless way
Click to enter the interface for wireless access to the internet,
as shown below:
7.2.2 Access to Internet
Click the internet access icon to access the internet. You can set
the IP address manually, with the interface shown below:
13
8.1 Wireless operation and network
8.2 Sound
To turn your WI-FI on or off, you can set the WIFI switch on the upper
right corner of the device as ON or OFF when the WIFI items are properly
Access to the Internet in a wireless way.
If you want to set and manage connection point designed for the
wireless Network.access to the Internet, please press Settings Wireless &
For details, please refer to the section "see 2.6".
Set the silent mode, notification ringtone and Audible selection.
1.Silent mode.
To set the system to silent, except for medium and alarm clock, you
can press Settings Sound Silent mode.
2.Notification ringtone.
To set the default notification ringtone, you can press Settings
Sound Notification ringtone.
3. Audile selection.
To make sound when you touch screen , you can select Audible selection.
To customize the settings, click on the shortcut menu.
8. Customized settings
3.Network search: Press Setup Wireless Network Connect to
Wireless Network WIFI Setting Notification.
4. In terms of WIFI use, please set the WIFI switch at the upper right
corner of the screen to OFF state (turn off WIFI).
configured.
14
3.Animation
To allow all or some window animations to be played, press Settings
Display Animation.
4. Screen timeout.
To set your screen time to sleep mode, press Settings Display
Screen timeout.
8.4 Location & security
1.Use wireless networks.
To see location in application (such as Maps) using wireless network,
press Setting Location & security Use wireless networks.
2. Visible passwords.
To show password as you type, press Setting Location & security
Visible passwords.
8.3 Display
1.Brightness.
To adjust the brightness
of the screen,
press Menu Settings
Display Brightness.
2.Auto-rotate screen.
To atuo-rotate screen, press Settings Display Auto-rotate screen.
15
8.6 Accounts & sync
1.To sync your data , you can select background and Auto-sync.
2.To add account, please press Settings Account & Sync Add account.
following instructions.
8.5 Application
1. Unknown resources.
Select this item to permit that application provided by the
unauthorized electronic market can be installed.
2. Management for application.
To manage or delete the installed application, press Settings
Management.
3. Running services.
To view or control the running service, press Settings Application
Running Services.
4. Development.
To set the option for development of application, press Settings
Development.Application
Application
16
8.7 Search
8.8 Privacy
8.9 SD card & device storage
To know your SD card information, press Settings SD card & device
8.9.1
8.9.2 If you want to mount your Micro SD card again ,click Mount SD card.
storage SD 1.
To reset your Digix Tablet, press Settings Privacy Factory data reset.
To set search, please press Settings Search.
17
8.11 Date and time
To set the date, time, time zone, time system and format, you can
press Settings Date and time.
8.10 Language and keyboard
In this item, you can set the language and region, character entering
and automatic correction.
1. Select language and region.
To select the language and region, press Settings language & keyboard
2. Android keyboard.
To set Android keyboard, press Settings language & keyboard
Android keyboard.
3. User dictionary.
To add words into or delete words from the user-defined dictionary,
press Settings language & keyboard User dictionary.
Select language.
18
8.12 Touch screen calibrate
8.13 G-Sensor calibrate
8.14 About the device
To calibrate the screen, press Settings Touch screen calibrate. Then
calibrate the touch screen by following the prompts. After that, the system
will prompt you to return to the settings list.
To calibrate the G-sensor of your tablet, Press Settings G-Sensor
calibrate, then calibrate your tablet G-Sensor following the prompts.
In this item, you can view the information on law, device status and
software version.
After that, the system will prompt you to return to the settings list.
19
With HDMI, video contents being played by your Digix tablet can be
transferred to other displays using the HDMI cable. Such as an LCD TV
that has an HDMI port. The outputs the tablet supports can offer a
maximum resolution of 720P. The related operations are as follows:
1. Power on your Digix tablet.
2. Connect Digix to HDMI monitor with HDMI cable and power on the
monitor. At that time, on the status bar messages about HDMI connection
3. Play the video files on your Digix tablet.
4. Press MENU, and your tablet screen will turn black, a process lasting
about 5 seconds during which the contents are being switched to HDMI
monitor. Please be patient.
5. You can transfer the contents to the tablet again by any of the four
1) System transfers to tablet automatically after the playing is completed.
2) Press Menu during playing to switch the video contents to the tablet.
3) Pull out the HDMI cable during playing, after which the video contents
will be transferred to the tablet.
4) Press Back to exit the playing mode, after which the video contents
will be transferred to the tablet.
9. Using HDMI
10. Locking the device
11. Troubleshooting
11.1 Turning off applications
Once an application is turned on, it will occupy some space, and if there
are too many applications that have been turned on, it will slow down the
running speed of the device. Therefore you should close applications not
being used in a timely manner, so that more space can be saved and the
To turn off the application, click at the shortcut bar, and the system
will enter the interface of system settings, where you can select Application
will be pop up.
ways below:
device run faster.
Services, as shown below:
Running
Unlocking screen/device:
When the system is the sleep mode, you can short press the power
switch to enter the interface for screen locking. To unlock the screen,
move the corresponding icon upward, and the system will enter the state
prior to sleep mode.
20
Click Stop, and the application will be closed and disappear within the window
being used.
11.2 Compulsory power-off
1. Press the power switch and hold down for 7 seconds, the device
will be powered off in a compulsory way.
2. Press Rest at the right lower part of the device, the device will be
powered off in a compulsory way.
11.3 Restore defaults
If you want to restore the factory defaults and delete all other data,
Once you select Reset, the Google account, data and settings of the
system and application and the downloaded applications will be deleted.
Thus, be careful when using this function.
Warning:
please press System Settings Privacy Factory data reset.
Click the application to be closed, and the system will pop up a window which
asks you if you need to stop the service window, as shown below:
www.digixmedia.com
