Continental Automotive Systems GNOV1B GSM/GPRS/EDGE Module User Manual GNOV1B User Manual v4
Continental Automotive Systems, Inc. GSM/GPRS/EDGE Module GNOV1B User Manual v4
User Manual
User Manual for GNOV1B Doc No.:
Rev: 0.4
Page 1 of 2
GNOV1B GSM/GPRS/EDGE Module
(For use in models: FullSVTI, FullSTVX, GISVTI,
GKSVTI, GCSVTI, FKSVTI, NKSVTX)
User Manual for GNOV1B Doc No.:
Rev: 0.4
Page 2 of 2
1. Product Overview
GNOV1B is an embedded GSM/GPRS/EDGE module for use within Stolen Vehicle Tracking products (SVT). This
is a Quad-Band GSM device.
SVT is a module that performs the functions of tracking and also antitheft. This is accomplished with GPS and
GSM/GPRS technologies and vehicle blocking circuitry. The module can receive binary SMS messages from a
server and communicate with a server using packet data thus allowing a Service Provider (SP) to monitor the vehicle
and obtain the actual position coordinates.
SVT allows receiving of GPS satellite signals to determine the position of a vehicle and to transmit it at
programmable time intervals to a SP by means of a GSM/GPRS modem radio.
2. Device Installation and User Manual
The GNOV1B device is a proprietary GSM module to be used for integration into Telematics devices designed and
manufactured by Temic Automotive North America, brand name Continental. Because the GNOV1B is not
intended for sale as a stand-alone device or offered for sale to general public, the owner’s manual and sales brochure
are not applicable to this product.
GNOV1B is a GSM engine which is integrated into stolen vehicle tracking (SVT) products. The SVT devices are
designed for use by automotive OEMs. The SVT device will be installed into vehicles by automotive OEMs. The
SVT device does not have any user interface and requires no interaction with users. Its operation is fully automated.
3. FCC Note
This device complies with Part 15 of the FCC Rules. The FCC ID for this device is LHJGNOV1B. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications to this system by other than an authorized service facility could void authorization to use
this equipment.
Please note that if the GNOV1B module is integrated into a host device, second label must be placed on the outside
of the final device that contains the following text: "FCC ID: LHJGNOV1B".
The device must be installed to provide a separation distance of at least 20cm from all persons and must not be co-
located or operating in conjunction with any other antenna or transmitter.
