MONARCH ONE BUTTON - Type:
433TSPW1K
Annex 8 : User manual
1A - General information
The Transmitter Solutions - Monarch transmitter is a key chain style mini
transmitter operating at 433,92 MHz. It has been designed for the
control of automatic closing systems and anti-burglar systems, thanks
to its very high security coding system (KeeLoq® Hopping code).
The code sent by the transmitter changes at each activation, avoiding
any scanning and copying risk. A special algorithm allows to keep
synchronized transmitter and receiver.
CONTENTS
1A - General information
1B - Technical specifications
1C - Main components
1 - TRANSMITTER OVERVIEW
2 - NUMBERING
3 - PROGRAMMING
4 - OPERATION
5 - BATTERY ACCESS
1B - Technical specifications
Operating frequency 433,92 MHz
Number of keys: 1
Battery life: 18 24 months
Security code: Keeloq Hopping code
Number combinations : 2exp64
Operating temperature: -20°F÷+131°F (-20°C
Overall dimensions: 2.4”x1.4”x0.51” (61x36x13 mm)
Weight: 0.49 oz. (14 gr.)
Battery : 2 x 3V lithium batteries CR2016
÷
®
÷+55°C)
The transmitter can operate with many receivers of the range
Transmitter Solutions - 433R. Ask your installer or reseller the product
which best fits your application. The output of the receivers can be either
wiegand 26 bit ( to communicate with access control systems ) or 1-2-4
relay with NO - NO/NC output. The CR 2016 lithium batteries of the
transmitter have a shelf life of about 6 months.
Part 15 of FCC Regulations and
The product fully
complies with the European Directives
99/05/CE, 89/336/CEE, 73/23/CEE.
1C - Main components
Red
LED
Key
holder
ring
Dark red
push-button
6 - TROUBLESHOOTING
Dark grey
case
Fig. 2
Transmitter
Solutions
Thank you for choosing a Transmitter Solutions product .
Please read this manual carefully before using the product.
Made in Italy. Copyright
© 2006 by Transmitter Solutions
2 - NUMBERING 6 - TROUBLESHOOTING
PROBLEM SOLUTION
The operating range is reduced
Check to verify the
transmitter is programmed
into your system
Replace the transmitter
batteries
IS-TM143CCUK Rev. 1 del 19.05.2006
To access the battery open the case with a screwdriver acting on the slot between
the cover and the bottom and remove the bottom, as shown in fig. 3a and 3b.
Slide out the old batteries and replace them with the new ones ]
respecting the polarity, with the positive (+) side upward.
[CR2016
NOTE: Please dispose of the batteries properly according to local laws and
regulations.
Test proper battery installation by verifying that the red LED illuminates when
the button is pushed.
5 - BATTERY ACCESS
3 - PROGRAMMING
Each transmitter is manufactured and sold with a different factory-set serial
number .
The transmitter must be programmed into your system memory.
Your own installer or reseller will provide you the necessary instructions for your
system.
Replace the transmitter
batteries
The warranty period of 433 transmitters is 24 months,
beginning from the manufacturing date of the transmitter. During this period, if the
product does operate correctly, due to a defective component, the product will be
repaired or replaced at the sole discretion of .
The warranty does not extend to the transmitter case which can be damaged by
conditions outside the control of Transmitter Solutions or to battery life.
Transmitter Solutions
Transm itter Solutions
WARRANTY
Transmitter Solutions - Type : 433TSPW1K
FCC ID : SU7433TSPW1K
This device complies with FCC Rules
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept interference received, including
interference that may cause undesired operation.
Part. 15 of the
Notice
Any changes or modification to equipment not expressly
approved by could void the manufacturer’s warranty.
Transmitter Solutions
Transmitter Solutions
The system does not receiver the
transmitter signal.
The transmitter LED is ON
The system does not receiver the
transmitter signal.
The transmitter LED will not light
4 - OPERATION
A - Firmly depress the button until the small red LED illuminates.
B - After the LED has illuminated, release the button.
If the device you are attempting to activate does not respond, repeat steps A and B
or consult section 6 ( Troubleshooting ) of this manual.
Fig. 3a
Fig. 3b
TRANSMITTER SOLUTIONS
2505 Chandler Avenue, Suite, 1
Las Vegas, NV 89120 -
(866) 975-0101 - (866) 975-0404 Fax
sales@transmittersolutions.com
