Coros Wearables COROS Smart Cycling Helmet User Manual
Coros Wearables Inc. Smart Cycling Helmet
User manual
OMNI
Quick Start Guide
www.coros.com
OMNI
Smart Cycling Helmet
Strap
Tri-glide splitters
Buckle
O-Ring
Over ear bone
conduction headset
Power button
LED light
Expanded polystyrene
Padding
Polycarbonate shell
Wind Resistant
Microphone
List of Contents
Smart Helmet, Smart Remote and Mount, Micro-USB Charging
Cable, Emergency Identification Card, COROS™ Helmet Bag,
Reflective Decal, Visor
PAGE 1 PAGE 2
Bone Conduction Audio.
The integrated open ear
Bone Conduction Audio system delivers precision
audio and full environmental awareness. No ear buds
and no wires means you can direct your attention where
it should be - on the road!
Smart Communication.
Precision audio for music,
phone calls, ride data, and voice navigation.
Voice Navigation.
Allows you to set up and record
turn by turn directions to your destination and
receive audio instruction from start to finish.
Music Player.
Bluetooth connection is integrated
with the mobile app.
Emergency Alert System.
When the helmet
experiences an impact, it will send a SMS text alert to
your pre-selected emergency contact.
Tail Light.
Tail light for safe cycling day or night.
Light activation is automatic based on ambient light.
Automatic feature can be disabled via smart remote.
How to Wear Your Helmet How to Wear Your Helmet, cont.
PAGE 3 PAGE 4
Warning: Please do not wear an improperly sized helmet even
after adjusting its fastening system.
Put the helmet on your head as shown in Fig.1. Slide the
tri-glide splitters just below your earlobes. Next, adjust the
location of the buckle to provide even tension between your
neck and head. Finally, adjust the knob on the regulator for
proper integration.
• Fig.1 shows the correct way to wear the helmet. Always wear
the helmet with the strap and buckle fastened, and with the
strap pulled tight and positioned back against the throat. The
leading edge of the helmet should land just above the
eyebrows.
• Fig. 2 illustrates the incorrect position for the helmet. Failure
to wear the helmet properly may cause discomfort to the rider
or even cause the helmet to shift or fall off during an accident.
• The tri-glide splitter as shown in Fig. 3 is a key component for
positioning the helmet. Adjust the tri-glide splitters on each
side of the helmet so that the left strap and right strap come
together just under the earlobes.
• Fig. 4 shows how the chin strap also plays an important part
role in positioning the helmet. Adjust the length of the strap
and the location of the buckle to create a comfortable, yet firm
tightness around your chin and head.
Fig. 1. Correct Fig. 2. Incorrect Tri-glide
splitters
Fig. 3. Fig. 4.
O-Ring
• The COROS™ helmet is equipped with an adjustable fit
system which helps stabilize the helmet when worn in the
correct position while riding. Fig. 5 shows where to locate the
adjustable knob. Turn the knob clockwise to tighten and
counter-clockwise to loosen.
Charging
Please fully charge up your OMNI helmet before using. To
charge the helmet, open the Micro USB protective cover,
located at the back of helmet. Next, plug the data line into the
Micro USB interface, as shown in Fig. 7.
Turning On/Off
To turn the helmet ON, hold the Power button for 3 seconds
until you hear the word “pairing”. To turn the helmet OFF, hold
the Power button for 3 seconds until the LED indicator light
turns off.
• Fig. 6 shows how the helmet
will look from the front when
adjusted correctly.
How to Wear Your Helmet, cont. How to Operate Smart Functions
PAGE 5 PAGE 6
Control knob
Fig. 6.
Fig. 5.
Fig. 7.
4. To connect to COROS™ smart devices, launch the COROS™
Helmet App. Wait for a few seconds, the App will automatically
connect to the COROS Helmet. (see Fig. 10)
Connecting the Smart Remote
1. Pairing: Tap on Smart Remote under Device to enter the
Pair interface (see Fig. 11). Click the “Match” button (see Fig. 12)
and then press and hold any key on the Smart Remote until the
“Successfully Paired” message appears.
Pairing your COROS Helmet
1. See www.coros.com for compatible IOS and Andriod devices.
2. To pair your helmet to your phone, first power on the helmet.
On your phone, turn Bluetooth “On”. To enter the Bluetooth
Pairing interface, find OTHER DEVICES, and select “COROS™
Helmets”. (See Fig. 8)
3. Download the COROS™ Helmet APP. (see Fig. 9).
PAGE 7 PAGE 8
Fig. 9.
Fig. 8.
Fig. 10. Fig. 11. Fig. 12.
CorosHelmet Go
Option1: Search and Download >
Option 2:
Scan Quick Response Code >
In the App Store, search and find
“Coros Helmet”. Download and
save it directly to your phone.
Android / IOS - Apple
2. Mounting your Smart Remote: Your package contains the
Smart Remote, plus the remote holder and 2 rubber rings. Find
a spot on your bicycle handlebar to mount the holder, near
your right or left hand (Fig. 14, Image 1). Position the first
rubber ring at one corner of the holder and stretch the ring
diagonally to catch on the opposite corner as shown in Image
2. Attach the second rubber ring to the other two corners.
Image 3 shows the holder installed correctly, with the Smart
Remote placed into position. Note: the orientation of the Smart
Remote is flexible based upon the rider’s preference.
Smart Remote Functions
PAGE 9 PAGE 10
Fig. 14.
Image 1.
Image 2.
Image 3.
Function Status Audible Reminder
Play or pause music
Pick up or hang up call1
2
3
4
5
Refuse call
Pause cycling
Resume cycling
Volume up
Previous track
Volume down
Next track
Light manually on
Light manually off
Auto light
Press Button 1
Press Button 1
Press button 1 for 2 seconds
Press button 2
Press button 2
Press button 3
Press button 3 for 2 seconds
Press button 4
Press button 4 for 2 seconds
Press Button 5
Press Button 5
Press Button 5
One beep
-
two beeps
one beep with voice
"cycling paused"
one beep with voice
"cycling resumed"
One beep
One beep
One beep
One beep
With voice "light on"
With voice "light off"
With voice "Auto light"
1
3
5
4
2
Specifications
Safety Tail Light
PAGE 11 PAGE 12
Visor
MIC
LED
Bone Conduction
Speaker
PCBA
Switch button
Removable visor, interchangeable accessory
Latest silicon mic, improved call and wind
resistance quality
Safety cycling light and light sensor. Light
activated based on daylight and onset of
darkness. 3 RGB LED per side.
Improved 2nd generation bone conduction
audio
Main PCBA, Power controller PCBA, Power
switch PCBA
Improved and convenient user operation
Battery 700mAh Li-thion battery
Adjust System Adjustable fit system
Padding Hot-press lining + EVA padding
Helmet
/Chin Strap
Adjustable strap helps properly position the
helmet for safety and audio operation.
LED light
Function
Safety light for day or
night cycling Red light On: 1s / Off: 1s
Working Status Green light
(lowest brightness)
Flash every 15s
(remaining 500ms)
Charging
Charging --Red light
(lowest brigtness)
Fully charged-- Green light
(lowest brigtness)
Charging --
Flash every 15s
Fully charged --
Flash every 15s
Power on Green light Light on for 1s
Power off Red light Light on for 3s
Bluetooth connected Blue light Light on for 1s
Lighting color Frequency
1. Unable to power on helmet
Try charging the helmet from 1 to 2 hours.
2. After power on, the helmet automatically powers off
after a shortperiod of use.
Perform a “hard reset” by pressing the power button for a
period of 10 seconds.
3. No response for remote pair and operation.
After several failed attempts to pair the helmet, please contact
COROS™ support at www.coros.com
For complete troubleshooting information, please visit
www.coros.com
Troubleshooting of Electronic
Functions
COROS™ warrants the original purchaser of this product that
the product is free of defects in material and workmanship for
a period of one year(US & CA & AU)/two years(EU) from the
original date of purchase. This warranty does not apply to
defects of physical damage resulting from neglect, abuse,
improper repair, use, or fit, alterations, or any use unintended
by the manufacturer. COROS™ does not warranty any helmet
damaged due to heat or contact with solvents. This warranty is
in lieu of all other agreements and warranties, general or
special, express or implied and no representative or person is
Limited Warranty
PAGE 13 PAGE 14
Music Play Time 8+ hours play / talk
Charge Interface Micro USB
Electrical Input DC 5V / 1A
Charging Time 2 hours
Standby Time Up to 180 days
Bluetooth Profile
Speaker Output
Speaker Volume
Mic Sensitivity
BLE, A2DP, HFP, SPP, AVRCP, HSP
0.5W*2
85±3dB
﹣42± 3dB
Bluetooth Operational
Distance Up to 33 feet
Model: OMNI
C.P.S.C.16 CFR Part 1203
United States Federal Safety Standard for Bicycle Helmets
(Consumer Product Safety Commission)
CE, EN1078 (Europe Safety Standard)
FCC ID: YNGHA002-0001
FCC Part 15B,Part 15C
CE R&TTE Directive 1999/5/EC
AS/NZS 2063:2008 (Australia/New Zealand Bicycle Helmet
Safety Standard)
Safety Certifications
This manual covers important information with respect to
safety, operation and maintenance of the helmet, please read it
carefully before initial use.
1. No helmet can protect its user from all unforeseeable
accidents, including those involving bicycle-to-motor vehicle
collisions. The COROS™ helmet is designed to protect the head
and cannot guard against cervical, spine or other body injuries
that may result from an accident.
2. The helmet is designed to be retained by a strap under the
lower jaw. It is not intended for motorsport, moped or other
uses.
3. To be effective, the helmet must fit properly and be worn
correctly. Securely fasten retention system as shown on page
3-5. Grasp the helmet and try to rotate it to front and rear. A
correctly fitted helmet should be comfortable and should not
move forward to obscure vision or rearward to expose the
forehead.
4. No attachments should be made to the helmet except those
recommended by the helmet manufacturer.
5. The helmet is designed to absorb shock by partial
destruction of the shell and liner. This damage may not be
visible. Therefore, if subjected to a severe blow, the helmet
should be returned to coros under the impact replacement
program. visit www.coros.com for more information.
General Safety, Use and Care
PAGE 15 PAGE 16
authorized to assume liability on behalf of COROS™ in
connection with the sale or use of this product. This warranty
program covers all parts of your COROS™ product and applies to
all types of defects or failure, except for loss. If your COROS™
helmet is found to be defective in materials or workmanship
within one year(US & CA & AU)/two years(EU) from the date of
purchase, COROS™ or the country distributor will at its sole
option either repair or replace the helmet free of charge.
6. The helmet may be damaged and rendered ineffective by
petroleum and petroleum products, cleaning agents, paints,
adhesives, etc., without the damage being visible to the user.
7. A helmet has a limited lifespan and should be replaced when it
shows obvious signs of wear.
8. This helmet should not be used by children while climbing or
doing other activities where there is a risk of hanging or
strangulation should the child become trapped Please keep the
helmet out of reach from children under fi ve.
9. Please exercise care and good judgment whenever you ride.
Comply with all traffic laws and regulations and do your part to
avoid accidents of any kind.
10. Do not modify or remove any original components of your
helmet, other than as recommended by COROS™. Doing so will
void all COROS™ warranties.
11. Keep your helmet charged with the USB charging adapter.
12. Please mount the Smart Remote into the holder before
each use.
13. The product can be upgraded online through the COROS™
Application. Do not terminate power or force the helmet to turn
off in the course of upgrading; this could lead to booting failures.
14. The COROS™ helmet is water resistant.
Clean the helmet with mild soapy water. Avoid use of specific
solvents such as ammonia, bleach, paints, abrasives or
hydrocarbons which may damage the helmet and cause it to
fail to protect the head in the accident.
COROS™ Wearables Inc.
3310 Noble Pond Way, Suite 207 Woodbridge, VA 22193 USA
info@coros.com
For updated product and mobile app information, please visit
www.coros.com
Maintenance
1. Keep the helmet far away from high temperatures over 65.5C
or 149.9F, as it may cause damage to the helmet. Do not place
the helmet into dark colored vehicles or store it in tightly sealed
containers or bags where high heat can accumulate and cause
damage to the helmet. Do not use the helmet if it has been
deformed by heat.
2. Make sure the helmet is clean and dry after each use. Store
the helmet in a dry and ventilated location.
Storage
Contact
PAGE 17 PAGE 18
This manual covers important information with respect to
safety, operation and maintenance of the helmet, please read it
carefully before initial use.
1. No helmet can protect its user from all unforeseeable
accidents, including those involving bicycle-to-motor vehicle
collisions. The COROS™ helmet is designed to protect the head
and cannot guard against cervical, spine or other body injuries
that may result from an accident.
2. The helmet is designed to be retained by a strap under the
lower jaw. It is not intended for motorsport, moped or other
uses.
3. To be effective, the helmet must fit properly and be worn
correctly. Securely fasten retention system as shown on page
3-5. Grasp the helmet and try to rotate it to front and rear. A
correctly fitted helmet should be comfortable and should not
move forward to obscure vision or rearward to expose the
forehead.
4. No attachments should be made to the helmet except those
recommended by the helmet manufacturer.
5. The helmet is designed to absorb shock by partial
destruction of the shell and liner. This damage may not be
visible. Therefore, if subjected to a severe blow, the helmet
should be returned to coros under the impact replacement
program. visit www.coros.com for more information.
6. The helmet may be damaged and rendered ineffective by
petroleum and petroleum products, cleaning agents, paints,
adhesives, etc., without the damage being visible to the user.
7. A helmet has a limited lifespan and should be replaced when it
shows obvious signs of wear.
8. This helmet should not be used by children while climbing or
doing other activities where there is a risk of hanging or
strangulation should the child become trapped Please keep the
helmet out of reach from children under fi ve.
9. Please exercise care and good judgment whenever you ride.
Comply with all traffic laws and regulations and do your part to
avoid accidents of any kind.
10. Do not modify or remove any original components of your
helmet, other than as recommended by COROS™. Doing so will
void all COROS™ warranties.
11. Keep your helmet charged with the USB charging adapter.
12. Please mount the Smart Remote into the holder before
each use.
13. The product can be upgraded online through the COROS™
Application. Do not terminate power or force the helmet to turn
off in the course of upgrading; this could lead to booting failures.
14. The COROS™ helmet is water resistant.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
