Country Mate Technology CAHBTSPORT Bluetooth Earbuds User Manual NS CAHBTEP01 NS CAHBTEP01 C 16 0044 QSG V1 TRI ai

Country Mate Technology Ltd Bluetooth Earbuds NS CAHBTEP01 NS CAHBTEP01 C 16 0044 QSG V1 TRI ai

Users Manual

Final flat size: 400 × 240 mm
Final fold size: 80 × 120 mm
Quick Setup Guide |
NS-CAHBTSPORT/NS-CAHBTSPORT-C NS-CAHBTSPORT/NS-CAHBTSPORT-C
Bluetooth Earbuds
PACKAGE CONTENTS
CHARGING YOUR EARBUDS
• When the red indicator LED blinks three times every one minute, the battery is low. To
charge the battery, plug the microUSB charging cable into your computer and into the
microUSB port on your earbuds. The red LED turns on to indicate that the battery is
USING YOUR EARBUDS
1 Place the earbud cable around your neck, then clip the cable clamp to your collar. The inline
control falls naturally in front of your right shoulder.
2 Press and hold the MFB for three seconds. The LED blinks blue (when turned on) or red
BLUETOOTH BASIC INDICATION
Bluetooth version:
Frequency spectrum:
Working distance:
Operating
temperature:
Bluetooth 4.1
A2DP, AVRCP, HFP, HSP
2.4 ~ 2.4835 GHz
ISM Band
Up to 33 ft. (10 m)
23 ~ 122° F
(-5 ~ 50° C)
Operating time:
Standby time:
Weight:
Average charging
time:
Talk: 8 hours
Music: 8 hours,
playback music track
100 hours
0.388 oz (11g)
2 hours
PAIRING YOUR EARBUDS
Notes:
• Range is 33 feet (10 meters)
• Supports easy pairing
• Prompts you by saying “Device Connected,” when connected
• Supports a battery indicator icon on an iOS device
Pairing with a cell phone or MP3 player
1MFB for four seconds. The blue and red LEDs blink
alternately.
2 On your phone or MP3 player, select NS-CAHBTSPORT
NS-CAHBTSPORT
from the list of discovered devices,
then enter the password 0000 (four zeros) (if required) to pair your earbuds.
For more
information on pairing Bluetooth devices to your cell phone or MP3 player, see the device’s
documentation.
Note: After the earbuds have been successfully paired with the cell phone or MP3 player, the earbuds will
automatically reconnect to the phone or MP3 player.
Pairing with a computer running Windows
Note: Before you pair the earbuds with the computer, make sure that the computer is equipped with Bluetooth. Refer
to the computer’s documentation or contact the computer manufacturer for more information. If your computer is not
Bluetooth compatible, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For instructions, see the computer’s documentation or contact
the computer manufacturer.
2 Double-click the Bluetooth icon in the system tray, then click Add a device (Add Wireless
Device using Windows Vista).
3MFB for four seconds. The LED blinks blue and red
alternately. Pairing mode is activated.
4 Double-click the NS-CAHBTSPORT icon on the computer or highlight the icon, then click
Next.
Note: If you are unable to locate the NS-CAHBTSPORT icon, click the Search Again button.
5 If required, enter 0000 (four zeros) in the Bluetooth security code Next.
6 After the earbuds have been paired, click Close. If you are using Windows XP, continue with steps 7
through 9.
7 Select one of the Bluetooth hands-free types shown on the Add a Bluetooth Device Wizard screen,
then click Next.
8 Select the services shown on the wizard screen to use with your Bluetooth earbuds, then click Finish.
9 To connect the device, double-click the NS-CAHBTSPORT Hands-Free Unit icon or the
NS-CAHBTSPORT Stereo Audio icon.
Note: The earbuds should be automatically selected as the default playback device (Windows® 8, Windows® 7, or
Windows Vista®) or the default recording and playback device (Windows XP). To make those settings manually,
refer to the User Guide.
Pairing with a Mac computer
Note: Before you pair the headphones with the computer, make sure that the computer is Bluetooth compatible.
Refer to the computer’s documentation or contact the computer manufacturer for more information. If your computer
is not Bluetooth compatible, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For instructions, see the computer’s documentation or
contact the computer manufacturer.
2 Click the Bluetooth status menu.
3 Click Set up Bluetooth Device. The Bluetooth Setup Assistant opens.
4 Click Continue.
5 Select Headset as the device type, then click Continue.
6 MFB for four seconds. The LED blinks blue and red
alternately. Pairing mode is activated.
7 Select NS-CAHBTSPORT, then click Continue. The computer gathers information.
8 Click Continue.
9 Enter 0000 (four zeros) into the Passkey Continue.
10 Click Quit
Note: To use the earbuds, they must be selected as the default input and output device on the computer.
11 Click System Preferences, then click Sound.
12 Under Input, select NS-CAHBTSPORT, then under Output, select NS-CAHBTSPORT.
For more information on using your headphones with Skype, refer to your User Guide.
RESETTING YOUR EARBUDS
•MFB for 10 seconds.
SPECIFICATIONS
Before using your new product, please read these instructions to prevent any damage.
ACTION
Power on
Pairing mode
Play/Pause
Volume Up/Down
Next Track/
Previous Track
Incoming call
Answer call
Reject call
Redial
Reset device list
OPERATION
Press and hold MFB more than
two seconds
Press and hold MFB more than
three seconds
Press and hold MFB more than
mode
Press and release MFB button
Press and release / button
Press and hold button
Press and release MFB when a
call is incoming
Press and hold MFB when a
call is incoming
Double press MFB
Press and hold MFB more than
LED INDICATION
Blue LED on 1.5 seconds
Red LED on 1.5 seconds
Blue and red LED
blinking alternately
Blue LED blinks three
when a call is received
SOUND
“power on”
Two short beeps
o
Tw highbeeps for
maximum volume.
Ring tones
One short beep
T
Red LED falsh 10 times
when reset to default
Two short beeps
wo short beeps
TROUBLESHOOTING
• Reset your BT headphone • Plug microUSB cable for charging
LEGAL NOTICES
FCC statement:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Caution:
te the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, maybe cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipme
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
RSS-Gen & RSS-247 Statement:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
RSS-102 Statement
This equipment complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment.
Cet équipement est conforme à l'exposition aux rayonnements Industry Canada limites établies pour un environnement non contrôlé.
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
1-877-467-4289 (U.S. and Canada)
01-800-926-3000 (Mexico)
www.insigniaproducts.com
©2016 Best Buy. All rights reserved. Made in China
Guide d’installation rapide |
Écouteurs Bluetooth
NS-CAHBTSPORT_NS-CAHBTSPORT-C_16-0044_QSG_V1_TRI.ai 1 4/29/2016 6:14:56 PM
# DESCRIPTION
1
2
Multi-function button
(MFB) (Power/Talk/Play/
Pause/Pairing)
3
5
Volume Down
Previous Track
6
FUNCTION
Volume Up
Next Track
Press to increase the volume.
Press to skip to the next track.
Press to turn on your earbuds. If you receive a phone call,
Press to decrease the volume.
Press to skip to the previous track.
Micro USB port Plug the micro USB connector into this port to charge
your earbuds.
Microphone Allows you to talk on the telephone.
4
1
2
3
6
4
5
/
V1
