PRINTED IN U.S.A.
Operator's Manual
FRONT SCOOP TRACTOR ATTACHMENT
Model No. 486.248475
FORM NO. 42620 (12/30/13)
CAUTION:
Before using this product, read
this manual and follow all Safety
Rules and Operating Instructions.
• Safety
• Assembly
• Operation
• Maintenance
• Parts
STOP
DO NOT RETURN TO STORE
For Missing Parts or Assembly
Questions Call 1-866-576-8388
Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
www.sears.com/craftsman
Wantmoreinformationorassemblytips?
ScanwithfreeShowUHowMobileApp
availableatiTunesStoreorGooglePlay.
2
WARRANTY ....................................................................2
SAFETY RULES ..............................................................3
FULL SIZE HARDWARE CHART ....................................4
CARTON CONTENTS .....................................................6
ASSEMBLY ......................................................................7
OPERATION ..................................................................17
ONE YEAR FULL WARRANTY
When operated and maintained according to the instructions supplied with it, if this Front Scoop Tractor Attachment fails
due to a defect in material or workmanship within one year from the date of purchase, call 1-888-331-4569 to arrange for
freerepair(orreplacementifrepairprovesimpossible).
If this product is used for commercial or rental purposes, this warranty applies for only 90 days from the date of purchase.
Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrightswhichvaryfromstatetostate.
Sears, Roebuck and Co., D817WA, Hoffman Estates, IL 60179
TABLE OF CONTENTS
WARRANTY
MAINTENANCE ............................................................18
TROUBLESHOOTING ...................................................19
REPAIR PARTS ILLUSTRATION ..................................20
REPAIR PARTS LIST.....................................................21
SLOPEGUIDE ..............................................................23
PARTSORDERING/SERVICE .........................Back Page
MODEL NUMBER: 486.248475
SERIAL NUMBER: __________________
DATE OF PURCHASE: __________________
Themodelnumberandserialnumberwillbefoundona
decalattachedtothebucket.
Youshouldrecordboththeserialnumberandthedateof
purchase and keep in a safe place for future reference.
3
Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment.
Exercise caution at all times when using power equipment.
• Readthisoperator'smanualbeforeattemptingto
assembleoroperatethescoopattachment.
• Read the vehicle owner's manual and know how
tooperateyourvehiclebeforeusingthescoop
attachment.
• Nevercarrypassengersinthescoopbucket.Ithas
notbeendesignedtocarrypassengers.
• Never allow children to operate the vehicle or the
scoop attachment.
• Do not allow adults to operate the vehicle or scoop
attachment without proper instructions.
• Alwaysbeginwiththetransmissioninrst(low)and
gradually increase speed as conditions permit.
• Drive the tractor at reduced speed over rough terrain
and hillsides or near creeks and ditches to prevent
tipping over and loss of control. Do not drive too close
to a creek or ditch.
• Never ram the scoop into material at high speed.
• Vehiclebrakingandstabilitymaybeaffectedwith
theattachmentofthisscoop.Donotllthescoop
to maximum weight capacity without checking the
capabilityofthevehicletosafelydriveandstopwith
the scoop attached.
• Before operating vehicle on any grade (hill) refer
to the safety rules in the vehicle owner's manual
concerning safe operation on slopes. Refer also to the
slope guide on page 23 of this manual. Stay off steep
slopes!
• Followmaintenanceandlubricationinstructionsas
outlined in this manual.
SAFETY RULES
Lookforthissymboltopointoutimportantsafetyprecautions.Itmeans—Attention!! Become
alert!! Your safety is involved.
ACCESSORIES AND ATTACHMENTS
WHEEL WEIGHT TIRE CHAINS
Theseandotheraccessoriesarerecommendedforusewithyourunit.Call1-888-331-4569tondoutiftheyareavailable.
Ifavailable,theymaybepurchasedatmostCraftsmanoutletsorbycalling1-888-331-4569.
4
FULL SIZE HARDWARE CHART
W
X
AA
EE
L
JK
I
H
N
ABCDEFG
O
Q
R
S
P
CC
V
DD
M
FF GG
II
HH
JJ
LL
Y
T
Z
BB KK
U
5
PARTS BAG CONTENTS
Not all parts will be needed for t-up to any one tractor.
Discardunneededpartsafterassemblyisnished.
P A R TS N O T SH O WN FULL SIZ E
NN OO
SS
PP
RR
QQ
MM
REF PART NO. QTY DESCRIPTION
A 710-0367 2 Hex Bolt, 5/8" x 1-1/2"
B R74780828 2 Hex Bolt 1/2" x 1-3/4"
C 710-0865 3 Hex Bolt, 1/2" x 1"
D 43087 2 Hex Bolt, 3/8" x 1-1/4"
E 43001 6 Hex Bolt, 3/8" x 1"
F 43063 4 Hex Bolt, 5/16" x 1"
G43084 5 Hex Bolt, 5/16" x 1-3/4"
H 47025 1 Hex Bolt, 5/16" x 3-1/2"
I 1509-69 3 Hex Bolt, 1/4" x 1-3/4"
J 43350 8 Bolt, Carriage 3/8"x 1"
K 44326 2 Carriage Bolt, 5/16" x 1"
L 43346 1 Truss-Head Bolt #10-32 x 5/8"
M 712-0261 2 Nylock Nut, 5/8"
N 43262 1 Hex Lock Nut, 1/2"
O 712-3083 2 Nylock Nut, 1/2"
P 48115 2 Nylock Jam Nut, 1/2"
Q 43015 2 Hex Nut, 3/8"
R HA21362 10 Nylock Nut, 3/8"
S 47810 11 Nylock Nut, 5/16"
T 43064 2 Nut, Hex 5/16"
U 47189 3 Nylock Nut, 1/4"
V43178 1 Nut, Hex 1/4"
W 47171 1 Nylock Nut, #10-32
REF PART NO. QTY DESCRIPTION
X 23658 2 Spacer, 5/8" Long
Y 24817 4 Spacer, 1/2"
Z 43343 4 Hairpin Cotter, Long
AA 43055 4 Hairpin Cotter, Short
BB 43010 6 Cotter Pin, 1/8" x 1-1/4"
CC 43093 2 Cotter Pin, 1/8" x 1-1/2"
DD 43003 6 Lock Washer, 3/8"
EE 43081 8 Washer, 5/16"
FF 43070 8 Washer, 3/8" (Small)
GG R19171616 3 Washer, 1/2" (Small)
HH 736-0247 2 Washer, 3/8" (Large)
II R19212016 6 Washer, 5/8"
JJ R19172410 8 Washer, 1/2" (Large)
KK 43009 2 Washer, 3/4"
LL 43601 2 Washer, 1"
MM 44062 2 Clevis Pin, 1/2" x 1"
NN 711-0309 2 Clevis Pin, 5/8" x 1-1/4"
OO 48905 1 Compression Spring, Short
PP 732-0306 1 Compression Spring, Long
QQ 726-0178 6 CableTie
RR 26481 2 Tilt Stop Bracket
SS HA23761 1 Hose Clip
6
CARTON CONTENTS
1
3
4 5
11
12
8
9
6 13
14
16
17
18
15
7
2
19
10
REF PART NO. QTY DESCRIPTION
1 64962 1 BucketAssembly
2 25335 1 Pin Stop Bracket
3 64963 1 LiftFrameAssembly
4 ----- 1 LiftBracketAssembly
5 66258 1 TiltAnchorAssembly
6 25562 1 Right (Long) Side Plate
7 25563 1 Left (Long) Side Plate
8 63568 1 Right (Short) Side Plate
9 63569 1 Left (Short) Side Plate
10 25722 1 Frame Brace
REF PART NO. QTY DESCRIPTION
11 49273 1 Dump Control Rod
12 ----- 2 LiftStrapAssembly
13 ----- 1 TiltBracketAssembly
14 49271 1 DumpHandleTube
15 49264 1 LiftHandleTube
16 49268 1 Dump Control Pin
17 64968 1 Dump Pivot Bracket
18 ----- 1 DumpHandleTubeExtension
19 ----- 1 LiftHandleTubeExtension
7
TOOLS REQUIRED FOR ASSEMBLY
(1) Standard Screwdriver
(2) 15/16"Wrenches(oneshouldbebox-end)
(2) 3/4" Wrenches
(2) 9/16" Wrenches
(2) 1/2" Wrenches
(2) 7/16" Wrenches
(1) 3/8" Wrench
ADDITIONAL ITEMS NEEDED
Ruler or Tape Measure
Grease
5/16" x 1"
HEX BO L T (F)
PIN S T O P
BR A CKE T
3/8" NYLOCK NUT (R)
3/8" x 1-1/4"
HEX BO L T (D)
3/8" HEX NUT (Q)
B UCKE T
ASSEMB L Y
5/16" WASHERS (EE)
5/16"
NYLOCK
NUT (T)
FIGURE 1
5/8" x 1-1/2"
HEX BO L T (A)
APP L Y
GREASE
5/8" x 1-1/2"
HEX BOLT (A)
5/8" NYLOCK
NUTS (M) APP L Y GREAS E
APP L Y
GREASE
LIFT FRAME
ASSEMB L Y
FIGURE 2
REMOVE PARTS FROM CARTON
• Removethehardwarepackandallloosepartsfrom
the carton.
• Laycardboardonoortohelppreventscratchingof
painted parts.
• Layoutandidentifyallthepartsandhardwareas
shown on pages 4 through 6.
ASSEMBLE SCOOP
ASSEMBLY
STEP 1: INSTALL TWO BOLTS
(SEE FIGURE 1)
• Assembletwo3/8"x1-1/4"hexbolts(D)and3/8"hex
nuts(Q),threadingthenutallthewayontothebolt
untilitistightagainsttheheadofthebolt.
• Installanut/boltassemblyintothebucketassembly
and fasten using a 3/8" nylock nut (R). Tighten.
Repeat for the other side.
STEP 2: INSTALL PIN STOP BRACKET
(SEE FIGURE 1)
• Installthepinstopbrackettothetopofthebucket
assemblyusingfour5/16"x1"hexbolts(F),eight
5/16" washers (EE) and four 5/16" nylock nuts (T).
Leavetheboltslooseenoughthatthepositionofthe
pinstopbracketcanbeadjustedlater.
STEP 3: INSTALL LIFT FRAME ASSEMBLY
(SEE FIGURE 2)
• Applygreasetothemountingsurfaceofthebucket
assemblyandtheinsideoftheliftframearms.
• Assembletheliftframeassemblytothebucket
assemblyusingtwo5/8"x1-1/2"hexbolts(A)and
5/8" nylock nuts (M). Tighten, then loosen the nuts
1/4 turn, or until the lift frame pivots freely.
8
FIGURE 3
5/8" W ASHER (II)
1/8" x 1-1/4"
C O TTE R
PIN (BB)
LIFT BR A CKE T
ASSEMB L Y
LIFT FRAME
ASSEMB L Y
FIGURE 4
FIGURE 5 Bucket removed for clarity
STEP 4: INSTALL LIFT BRACKET ASSEMBLY
(SEE FIGURE 3)
 Assembletheliftbracketassemblytotheliftframe
assemblyusingtwo5/8"washers(II)and1/8"x1-1/4"
cotter pins (BB).
STEP 5: INSTALL TILT ANCHOR ASSEMBLY
(SEE FIGURE 4)
• Assemblethetiltanchorassemblytotheliftbracket
assemblyusingtwo1/2"x1"hexbolts(C)and1/2"
nylock jam nuts (P). Tighten.
STEP 6: INSTALL LIFT STRAP ASSEMBLIES
(SEE FIGURE 5)
• Loosen the bolts and nuts on the lift strap
assemblies1/4turnoruntilthestrapswillslideback
and forth. You will retighten them later in step 26.
• Turntheliftstrapassembliesasshown.Installeachlift
strapassemblytoanarmoftheliftbracketassembly
andthensecurewithasmall1/2"washer(GG)anda
short hairpin cotter (AA).
• Positionthelowerendofeachliftstrapassemblyto
the outside of the lift frame. Fasten to the upper front
holes in the lift frame using a clevis pin (MM), 1/2"
long spacer (Y) and short hairpin cotter (AA) for each
assembly.
NOTE:Theliftstrapassembliesmaybeinstalledinthe
rear mounting holes of the lift frame to increase the lift
height,butthiswillalsoincreasetheliftingeffort.The
frontholesgivealiftheightofabout6-1/2"andrequire28
lbs.offorcetolifta150lbload.Therearholeswillgivea
liftheightofabout8-1/2"andrequire35lbs.offorce.
1/2" NYLOCK
JAM NUTS (P)
TI L T ANCHO R
ASSEMB L Y
LIFT
BR A CKE T
ASSEMB L Y
1/2" x 1"
HEX BO L T (C)
1/2" x 1"
HEX BO L T (C)
SHORT
HAIRPIN
COTTER (AA)
CLEVIS PIN (MM)
1/2" S P A CE R (Y)
1/2" WASHER
(SMALL) (GG)
SHO R T HAIRPI N
C O TTE R (AA)
LIFT STRAP
ASSEMB L Y
UPPER F R ON T
MOUNTING HOLE
ARM
ARM
9
STEP 7: INSTALL EXTENSION SPRING
(SEE FIGURE 6)
• Lightlyapplygreasetotheendofthearmonthetilt
anchorassemblyandinstallthetiltbracketassembly
tothearmusinga1/2"x1"hexbolt(C)and1/2"hex
lock nut (N). Tighten then loosen the nut 1/4 turn, or
untilthetiltbracketassemblypivotsfreely.
• Installa1/4"x1-3/4"hexbolt(I)throughtheendof
theextensionspringonthetiltbracketassemblyand
theninstalla1/4"hexnut(V)ontothebolt.Next,
inserttheendoftheboltintotheholeinthearmof
thetiltanchorassemblyandinstalla1/4"nylocknut
(U)ontothebolt.Tightenthenutstosecurethebolt
to the arm.
FIGURE 6
1/4" NYLOCK NUT (U)
1/4" HEX NUT (V)
1/4" x 1-3/4"
HEX BOLT (I)
1/2" x 1" HEX BOLT (C)
1/2" HEX LOCK
NUT (O)
ARM
EXTENSION SPRING
5/16" HEX NUTS (T)
5/8" SPACERS (X)
5/16" x 3-1/2"
HEX BOLT (H)
STOP
BRACKET
LONG COMPRESSION
SPRING (PP)
FIGURE 7A
FIGURE 7B
STEP 8: INSTALL STOP BRACKET BOLT
(SEE FIGURE 7A)
For lift straps installed in front holes
• Installthelongcompressionspring(PP)andthenthe
two5/8"spacers(X)ontothe5/16"x3-1/2"hexbolt(H).
Inserttheboltintothestopbracketandinstalltwo5/16"
hexnuts(T)ontothebolt.Adjustnutslaterinstep29.
5/16" HEX NUTS (T)
5/8" SPACERS (X)
5/16" x 3-1/2"
HEX BOLT (H)
STOP
BRACKET
LONG COMPRESSION
SPRING (PP)
(SEE FIGURE 7B)
For lift straps installed in rear holes
• Installthelongcompressionspring(PP)andthena5/8"
spacer(X)ontothe5/16"x3-1/2"hexbolt(H).Insert
theboltintothestopbracketandinstalla5/8"spacer
(X)andtwo5/16"hexnuts(T)ontothebolt.Adjustnuts
later in step 29.
10
FIGURE 11
STEP 12: INSTALL LIFT HANDLE TUBE
(SEE FIGURE 11)
• Installthelifthandletubeintotheindexbracketusing
two5/16"x1-3/4"hexbolts(G)and5/16"nylocknuts
(S).
TILT STOP
BRACKET (RR)
3/8" NYLOCK
NUT (R)
3/8" W ASHER (FF) 3/8" x 1"
CARRI A GE BO L T (J)
FIGURE 10
STEP 11: INSTALL TILT STOP BRACKETS
(SEE FIGURE 10)
• Installatiltstopbracket(RR)toeachsideofthe
bucketusinga3/8"x1"carriagebolt(J),asmall3/8"
washer (FF) and 3/8" nylock nut (R). Do not tighten
the nuts until step 28.
5/8" W ASHERS (II)
5/8" WASHERS (II)
1/8" x 1-1/4"
COTTER PIN (BB)
1/8" x 1-1/4"
C O TTER PI N (BB) DUMP
CONT R O L
R O D
1/8" x 1-1/4"
C O TTE R
PINS (BB)
FIGURE 9
STEP 10: INSTALL DUMP CONTROL ROD
(SEE FIGURE 9)
• Installa1/8"x1-1/4"cotterpin(BB)intotheinsidehole
in each end of the dump control rod. Spread the ends
of the cotter pins and wrap around the rod. Install a 5/8"
washer (II) onto each end of the control rod.
• Installthedumpcontrolrodtothedumppivotbracket
andbucket.Fastenusingtwo5/8"washers(II)and
1/8" x 1-1/4" cotter pins (BB). Spread the ends of the
cotter pins and wrap around the rod.
1" W ASHERS (LL)
1/8" x 1-1/2"
C O TTER PI N (CC)
APP L Y
GREASE
DUMP PI V O T
BR A CKE T
1/8" x 1-1/2"
C O TTER PI N (CC)
FIGURE 8
STEP 9: INSTALL DUMP PIVOT BRACKET
(SEE FIGURE 8)
• Installa1/8"x1-1/2"cotterpin(CC)totheinsidehole
intheshaftshowningure8,andtheninstalla1"
washer (LL) onto the shaft. Apply grease to the end of
theshaftandinstallthedumppivotbracketassembly
onto the shaft. Install a 1" washer (LL) onto the shaft
and secure it using a 1/8" x 1-1/2" cotter pin (CC).
11
5/16"
NYLOCK
NUTS (S)
5/16" x 1-3/4"
HEX BO L T S (G)
5/16"
NYLOCK
NUT (S)
DUMP
HANDLE
TUBE
DUMP PI V O T
BR A CKE T
FIGURE 14
DUMP HANDLE
TUBE EXTENSION
DUMP HANDLE TUBE
1/4" NYLOCK
NUT (U)
1/4" x 1-3/4"
HEX BOLT (I)
DUMP CABLE
USE THIS HOLE
FIGURE 15
STEP 15: INSTALL DUMP HANDLE TUBE
(SEE FIGURE 14)
• Installthedumphandletubetothedumppivotbracket
assemblyusingthree5/16"x1-3/4"hexbolts(G)and
5/16" nylock nuts (S).
STEP 16: INSTALL DUMP HANDLE TUBE EXTENSION
(SEE FIGURE 15)
• Installthedumphandletubeextensiononthedump
handletubeusinga1/4"x1-3/4"hexbolt(I)and1/4"
nylock nut (U).
• Attachthedumpcabletothedumphandletubeusing
threecableties(QQ).
LIFT HANDLE
TUBE EXTENSION
1/4" NYLOCK NUT (U)
1/4" x 1-3/4"
HEX BOLT (I) LIFT HANDLE
TUBE
FIGURE 12
FIGURE 13
INDEX ROD
LIFT CABLE
CABLE
ADJUSTMENT
NUTS
HOOK
LIFT TRIGGER
STEP 13: INSTALL LIFT HANDLE TUBE EXTENSION
(SEE FIGURE 12)
• Installthelifthandletubeextensiononthelifthandle
tubeusinga1/4"x1-3/4"hexbolt(I)and1/4"nylock
nut (U).
STEP 14: INSTALL LIFT CABLE
(SEE FIGURE 13)
• Connectthehookedendoftheliftcableintotheindex
rod,andinstallthethreadedcableadjusterintothe
notchinthetopoftheindexbracket,placinganuton
each side of the notch.
• Adjustthecableadjustmentnutssothatwhenthelift
triggerissqueezed,thebottomoftheindexrodraises
enough to release from the latched position. The index
rod should also lower far enough to lock in the latched
position when the trigger is released.
• Attachtheliftcabletothelifthandleusingthreecable
ties (QQ).
12
#10 x 5/8"
T R US S
HEAD BO L T (L)
HOSE
CLIP (SS)
#10-32 NYLOCK
NUT (W)
FIGURE 17
INSTALL FRONT SCOOP ON TRACTOR
STEP 19: IDENTIFY YOUR TRACTOR TYPE
(SEE FIGURE 18)
• Lookunderneaththefrontaxleofyourtractor.Ifthere
isasinglemowerdecksuspensionbracketlocated
under the middle of the front axle, continue on to
step 20. If your tractor does not have a mower deck
suspensionbracketunderneaththemiddleofthe
front axle, skip to step 22 on page 14 or step 24 on
page14fortractorswithdualsuspensionbrackets.
MOWER DECK
SUSPENSION
BRACKET
FIGURE 18
STEP 18: INSTALL HOSE CLIP AND SPACER
(SEE FIGURE 17)
• Securethedumpcabletothebackofthebucket
usingahoseclip(SS),a#10x5/8"truss-headbolt(L)
and a #10-32 nylock nut (W).
SPRING (OO)
SMALL 1/2" W ASHER (GG)
CABLE
ADJUSTER
HOOK
DUMP CONT R OL PI N
PIN S T O P
BR A CKE T
3/4"
DUMP CONT R OL PI N
PIN S T O P
BR A CKE T
FIGURE 16
STEP 17: INSTALL DUMP CONTROL PIN
(SEE FIGURE 16)
• Installasmall1/2"washer(GG)andthentheshort
compression spring (OO) onto the dump control pin.
Installthedumpcontrolpinintothepinstopbracket.
Makesuretheatsideofthepinfacestothefront
whennished.
• Connectthehookedendofthedumpcableintothe
holeinthedumpcontrolpin.Installthethreadedcable
adjusterdownintothenotchinthepinstopbracket,
placing a nut on each side of the notch. Adjust and
tighten the adjuster nuts so that the tapered end of
the dump control pin extends 3/4" through the side of
thepinstopbracket.
13
1/2" NYLOCK
NUT (O)
FRAME BRACE
HOLE FOR LT
HOLE FOR GT
1/2" x 1-3/4"
HEX BOLT (B)
1/2" SPACER (Y)
1/2" LARGE
WASHER (JJ)
STEP 21: INSTALL FRAME BRACE
(SEE FIGURE 20)
• Installtheframebracetotheinsideofthesideplates
usingtwo1/2"x1-3/4"bolts(B),large1/2"washers
(JJ), 1/2" spacers (Y) and 1/2" nylock nuts (O).
InstallthebraceinthebottomholesforGarden(GT)
TractorsandthesecondfrombottomholesforLawn
(LT) Tractors. Do not tighten yet.
• Tightenallnutsonsideplatesandframebrace.
• Skip to step 25 on page 15.
FIGURE 20
LEFT (LONG)
SIDE PLATE
5/16" x 1"
CARRI A GE BO L T (K)
5/16"
NYLOCK
NUT (S)
(3) 3/8" x 1"
CARRIAGE BOLTS (J)
(3) 3/8" NYLOCK
NUTS (R)
ENGINE
MOUNTING
PLATE
(3) 1/2" LARGE
WASHERS (JJ)
(SEE NOTE)
FIGURE 19
LAWN TRACTORS AND GARDEN TRACTORS
WITH SINGLE SUSPENSION BRACKETS
STEP 20: INSTALL SIDE PLATES
(SEE FIGURE 19)
• Removeanyboltspresentinthemountingholeson
the left side of the tractor frame. Do not removebolts
fromrightsideofframeuntilleftsideplatehasbeen
installed.
• Installtheleft(long)sideplateonthetractorframe
usingthree3/8"x1"carriagebolts(J),three3/8"
nylocknuts(R),one5/16"x1"carriagebolt(K),one
5/16" nylock nut (S) and three large 1/2" washers (JJ)
if needed (see note). Do not tighten yet. Repeat for
the right (long) side plate.
NOTE: If an engine mounting plate is present (shown with
dottedlines)thatpreventsthesideplatefromrestingat
against the tractor frame, place 1/2" washers (II) on the
fronttwo3/8"boltsandontherear5/16"bolttoserveas
shimsbetweenthesideplateandtheframe.
14
(2) 3/8" x 1"
HEX BO L T S (E)
LEFT (GT)
SIDE PL A T E
(2) 3/8" LOCK
W ASHER S (DD)
LONG
HAIRPIN
C O TTE R (Z)
3/4" W ASHER (KK)
FIGURE 23
STEP 24: INSTALL SIDE PLATES
(SEE FIGURE 23)
• Removeanyboltspresentinthemountingholeson
the left side of the tractor frame. Do not removebolts
fromrightsideofframeuntilleftsideplatehasbeen
installed.
• Installtheleft(short)sideplatewiththepintothe
outsideusingtwo3/8"x1"hexbolts(E)and3/8"lock
washers(DD).Tightenonlyuntilboltsaresnugand
lockwashersareattened.Repeatfortherightside
plate.
• Installa3/4"washer(KK)andalonghairpincotter
(Z) to the pin in each side plate. Remove them while
mounting the scoop.
GARDEN TRACTORS WITH DUAL
SUSPENSION BRACKETS
FIGURE 22
1/2" NYLOCK NUT (O)
FRAME BRACE
1/2" x 1-3/4"
HEX BOLT (B)
1/2" SPACER (Y)
1/2" LARGE
WASHER (JJ)
38/" x 1"
HEX BOLTS
STEP 23: INSTALL FRAME BRACE
(SEE FIGURE 22)
• Installtheframebracebetweenthesideplatesusing
two1/2"x1-3/4"bolts(B),large1/2"largewashers
(JJ), 1/2" spacers (Y) and 1/2" nylock nuts (O). Fasten
thebracetothesecondfrombottomholesintheside
plates. Tighten.
• Tighten3/8"x1"hexbolts(E)insideplatesonlyuntil
theyaresnugandthelockwashersareattened.
• Skip to step 25 on page 15.
LAWN TRACTORS WITH DUAL SUSPENSION
BRACKETS
LEFT (LONG)
SIDE PLATE
(3) 3/8" x 1"
HEX BO L T S (E)
(3) 3/8" SMALL
WASHERS (FF)
3/8" LARGE
WASHER (HH)
(if needed)
(3) 3/8" LOCK
WASHERS (DD)
FIGURE 21
STEP 22: INSTALL SIDE PLATES
(SEE FIGURE 21)
• Removeanyboltspresentinthemountingholeson
the left side of the tractor frame. Do not removebolts
from right side of frame until done with left side plate.
• Fastentheleft(long)sideplatetothetractorframe
usingthree3/8"x1"hexbolts(E),3/8"smallwashers
(FF),and3/8"lockwashers(DD).Ifthereisabracket
like the one shown with dotted lines, use a 3/8" large
washer(HH)asashimontherearbolt.Do not
tighten yet. Repeat for the right (long) side plate.
STEP 23: INSTALL FRAME BRACE
(SEE FIGURE 22)
• Installtheframebracebetweenthesideplatesusing
two1/2"x1-3/4"bolts(B),large1/2"largewashers
(JJ), 1/2" spacers (Y) and 1/2" nylock nuts (O). Use the
secondholefromthebottomintheplates.Tighten.
• Tighten3/8"x1"hexbolts(E)insideplatesonlyuntil
theyaresnugandthelockwashersareattened.
• Skip to step 25 on page 15.
15
SMALLER BOLTS
TILT BRACKET
DUMP
CONTROL PIN
PIN STOP BRACKET
FIGURE 25
FIGURE 24
STEP 25: MOUNT SCOOP TO TRACTOR
(SEE FIGURE 24)
• Alignthescoopwiththesideplatesonthefrontofthe
tractor. Lift the rear of the scoop and slide the notches
inthescoopframeontotheboltsorpinsinthetractor
side plates. Stand on the left side of the tractor and
push down on the scoop dump handle until the holes
in the scoop frame and the holes in the side plates are
aligned. Install two clevis pins (NN) through the holes
and secure with two hairpin cotters (Z).
INSTRUCTIONS FOR ALL TRACTORS STEP 26: ADJUST TILT AND PIN STOP BRACKETS
(SEE FIGURE 25)
• Lowerthescoopassemblyontoasmoothlevelsurface.
Fornormaluse,letthebottomofthebucketrestaton
the ground. For more aggressive scraping action, place
1/4"shimsundertherearofthebucketateachend.
• Makesurethetwosmallerboltsinthetiltbracket
andthefourboltsinthepinstopbracketareslightly
loosened.
• Swingthetiltbracketforwardandpositionthepinstop
bracketsotheendofthedumpcontrolpininsertsinto
theholeinthetiltbracket.
• Adjustthepinstopbracketsothatitisushandsquare
withthefrontofthebucket.Leaveasmallgapbetween
thesideofthepinstopbracketandthetiltbracket.The
taper on the end of the dump control pin should now
extendallthewaythroughthetiltbracket.TIGHTEN the
boltsandnutsinthepinstopbracket
• TIGHTEN thetwoboltsandnutsinthetiltbracket.
LONG
HAIRPIN
COTTER (Z)
SCOOP
ASSEMBLY
BOLT OR
PIN
DUMP HANDLE
CLEVIS PIN (NN)
5/8" x 1-1/4"
16
TIGHTEN
NUTS LIFT STRAP
ASSEMBLIES
LIFT HANDLE
TI L T S T O P
BR A CKE T (RR)
LIFT FRAME ARM
FIGURE 26
FIGURE 27
STEP 27: ADJUST LIFT STRAPS
(SEE FIGURE 26)
• Makesurethenutsandboltsintheliftstrapsare
looseenoughtoturnbyhand.Standbesidetheright
side of the scoop and hold the lift handle as far
forward as it will go until you tighten one of the nuts
in the lift straps. Let go of the lift handle and tighten
the other three nuts in the lift straps.
STEP 28: ADJUST TILT STOP BRACKETS
(SEE FIGURE 27)
• RaisethescoopuntilitlocksintheTRANSPORT
position.Pushthetiltstopbrackets(RR)oneachside
ofthebucketdownagainsttheliftframearms,and
tighten the nuts.
NOTE:Readjustthetiltstopbracketsifyoumovethelift
strapassembliesfromthefronttorearholesorfrom
the rear to front holes. Refer to step 6 on page 8.
STOP BOLT
TIGHTEN
BOLT
TILT BRACKET
DUMP CONTROL PIN
FIGURE 28
STEP 29: ADJUST STOP BOLT
(SEE FIGURE 28)
• KeepthescooplockedintheTRANSPORTposition.
Adjustthenutsonthestopboltinoroutuntilthe
dump control pin is centered in the slot of the tilt
bracketwhenthetiltbracketispulledbackagainstthe
stopbolt.Securely tighten the two nuts together.
NOTE:Iftheliftstrapassembliesaremovedtotherear
mountingholes,oneofthespacersonthestopbolt
willneedtobemovedtothebacksideoftheboltstop
bracket.Refertostep8onpage9.
STEP 30: CHECK DUMPING OPERATION
• Withthescoopinthetransportposition,squeezethe
dump trigger and push down on the dump handle
todumpthebucket.Releasethedumptriggerand
liftuponthehandletolockthebucketintheupright
position. If the dump control pin does not lock into the
tiltbracket,loosentheboltstightenedinsteps26,27
and 28 and then repeat steps 26, 27 28 and 29.
17
OPERATION
KNOW YOUR FRONT END SCOOP
Read this owner's manual and safety rules before
operating your front end scoop.
Comparetheillustrationbelowwithyourfrontendscoop
to familiarize yourself with the various controls and their
locations.
LIFT
HANDLE
DUMP
HANDLE
DUMP
TRIGGER
LEVER
LIFT
TRIGGER
LEVER
DUMP TRIGGER LEVER Press to release the dump pin.
DUMP HANDLE Pressdowntodumpthebucket.
LIFT TRIGGER LEVER Press to release the index pin.
LIFT HANDLEPressdowntoliftthebucketassembly.
• Alwaystesttomakesureyourvehiclehasadequate
powerandbrakingcapabilitieswheneverhaulinga
substantialamountofweightinyourfrontendscoop.
Use extra caution when operating on slopes.
• Forbesthandlingandtraction,distributetheweightof
theloadevenlyinthebucket.
CAUTION: NEVER RAM THE SCOOP INTO
MATERIAL AT HIGH SPEEDS.
• Keepthelifthandlelockedintheraisedpositionwhen
tiltingthescoopbucketforwardtodump.
• Thelifthandlemustbelockedintheraisedpositionto
allowthedumphandletolockthescoopbucketback
in the upright position after dumping.
• Donotscrapeorpushmaterialwiththescoopbucket
while it is tilted forward.
• Addwheelweightsforimprovedtractionwhenusing
the scoop.
• Todumpmaterialfromthebucket,squeezethedump
triggerandpushthedumptubehandledown.Release
thetriggerbeforereturningthebuckettotheupright
position.
• Tolowerthebucket,squeezethelifttriggerand
then lift up on the lift handle. If the trigger is hard
to depress, you may need to push down on the lift
handle while squeezing, and then lift up. Release
thetriggerbeforeretuningthebuckettotheraised
position.
• Donotexceedmowingspeed(3mph)whenthefront
end scoop is attached to the tractor.
CAUTION: TO AVOID POSSIBLE INJURY,
MAKE SURE THAT NO ONE IS NEAR
THE BUCKET BEFORE DUMPING THE
BUCKET.
CAUTION: ALWAYS LOWER THE SCOOP
BUCKET TO THE GROUND BEFORE
LEAVING THE TRACTOR.
HOW TO USE YOUR SCOOP
DO NOT EXCEED 200 LB. CAPACITY OF BUCKET
One cubic foot of dirt weighs approximately 80 lbs.
One cubic foot of dry sand or gravel weighs
approximately 100 lbs.
CAUTION: VEHICLE BRAKING AND
STABILITY MAY BE AFFECTED WITH THE
ADDITION OF AN ACCESSORY OR AN
ATTACHMENT. BE AWARE OF CHANGING
CONDITIONS ON SLOPES.
• Refertothevehicleowner'smanualforinstructionson
safe operation on slopes.
• Usetheslopeguideprovidedonpage23ofthismanual
to determine whether slope angle is too steep for safe
operation.
18
CUSTOMER RESPONSIBILITIES
• Readandfollowthemaintenancescheduleandthemaintenanceprocedureslistedinthissection.
CHECK FOR LOOSE FASTENERS
Before each use make a thorough visual check of
thefrontendscoopforanyboltsandnutswhichmay
haveloosened.Retightenanylooseboltsandnuts.
CLEANING
• Aftereachuse,cleanoffanydirtanddebrisfromthe
scoopbucketliftframe.
• Beforestoringattheendofeachseason,rinseoff
thescoopbucketandscoopliftframe.Allowtodry
thoroughly. Paint any exposed metal surfaces to
protect from rust.
• Storeinaclean,dryarea.
MAINTENANCE
Service Dates
Check for loose fasteners X
Cleaning X
Lubrication    X
Before each use
After each use
Every season
Before storage
MAINTENANCE SCHEDULE
Fill in dates as you
complete regular service.
LUBRICATION
• Lightlyoilallpivotpointsonthescoopliftmechanism.
• Lightlyoilthesurfaceonthescoopbucketwherethe
attachment lift frame pivots.
• Applyagoodgradeofspraylubricanttothetrigger
assembliesonthelifthandleanddumphandle.
19
TROUBLESHOOTING
PROBLEM CAUSE CORRECTION
Scoop won't lock into
raised/transport position.
Scoopbucketwon'tlockintolevel
position after dumping.
Lift handle trigger won't release
scoop from the transport position.
Dump handle trigger won't
releasebuckettodump.
Bucketisbecomingmoredifcult
to tilt up or down.
1. Index rod is jamming.
2. Frame is hitting tilt stop
brackets.
1. Dump control pin does not align
withthetiltbracket.
1. Index rod is jamming.
2. Liftcableisnotadjustedproperly.
1. Dumpcontrolcableisnotadjusted
properly.
2. Pinstopbracketisnotadjusted
properly side to side.
1. Debrisislodgedbetweenbucket
assemblyandliftframe.
1. Applygreasetothebottomslotinthe
liftbracket,wheretheindexrodslides
2. Adjustthetiltstopbracketsas
instructed on page 16.
1. Adjustthetiltbracketandliftstrapsas
instructed on page 16.
2. Adjustthestopboltasinstructedon
page 16.
1. Applygreasetothebottomslotinthe
liftbracket,wheretheindexrodslides.
2. Adjustcablenutsasinstructedonpage
11.
1. Adjust parts as instructed in step 17 on
page 12.
2. Adjust parts as instructed in step 26 on
page 15.
1. Removealldebrisfrombetweenthe
bucketassemblyandtheliftframe.
20
REPAIR PARTS FOR MODEL 486.248475
PARTS
37
36
22
49
34
30
31
32
33 67
79
5
4
38
1
10
29
19
4 5
2
1
9
78
23
75
77
11
12
13
51
76
17
18
73
14
15
20
21
16
22
15
15
28
13
27
28
19 42 43 44
45 52
43 42
13
13
52
45
51
42
51
52 45
43
41
54
45
52
40
32
21
70
50
20 56
57
58
68
17
66
49
64 63
14 35
61
60
59
52 45
15 14
13
68
62
10
3
75
74
53
80 29
7
69
13
14
31
71
55
48
83
15
64 15
65
44
47
46
1
72
24
8
623
26
25 81
10
82
83
39
29
39
21
REPAIR PARTS FOR MODEL 486.248475
* Purchase Common Hardware Locally
REF PART NO. QTY DESCRIPTION
1 1509-69 3 HexBolt,1/4-20x1-3/4"(Grade5)
2 726-0178 6 CableTie
3 49265 1 Lift Handle Extension
4 49266 2 Oval Screw, 10-24 x 1-1/2"
5 47674 2 PlasticPlug,1-1/4"O.D.Tube
6 47025 1 HexBolt,5/16-18x3-1/2"(Gr.5)
7 43009 2 Flat Washer, 3/4"
8 23658 2 Spacer, .39" x .56" x .62" L
9 49912 1 Cable,Lift
10 47189 3 Nylock Nut, 1/4"
11 47369 1 Roll Pin, 3/16" x 1-3/4"
12 47368 1 Roll Pin, 5/16" x 1-3/4"
13 47810 14 Nylock Nut, 5/16-18
14 HA21362 14 Nylock Nut, 3/8-16
15 43070 14 Flat Washer, 3/8"
16 25350 4 Lift Strap
17 43063 7 HexBolt,5/16-18x1"(Grade5)
18 25343 1 Lift Bracket
19 741-0192 2 Flange Bearing with Flats
20 R19171616 4 Flat Washer, 1/2" x 1" (Small)
21 43055 4 Hairpin Cotter, 3/32" x 1.8"
22 43001 10 HexBolt,3/8-16x1"(Grade5)
23 732-0306 2 Spring, Compression
24 43262 1 Hex Lock Nut, 1/2-13
25 66258 1 TiltAnchorAssembly
26 48115 2 Nylock Jam Nut, 1/2-13
27 63675 1 LiftArmAssembly
28 25510 2 Mounting Bracket
29 43343 4 Hairpin Cotter, 3/32" x 2-5/16"
30 R74780828 2 HexBolt1/2-13x1-3/4"(Grade5)
31 R19172410 8 Flat Washer, 1/2" x 1-1/2" (Large)
32 24817 4 Spacer, 0.52" x 0.75" x 0.5"
33 712-3083 2 Nylock Nut, 1/2-13
34 43003 6 Lock Washer, 3/8"
35 712-0261 2 Nylock Nut, 5/8-11
36 63568 1 Right (Short) Side Plate
37 63569 1 Left (Short) Side Plate
38 49270 1 DumpHandleTubeExtension
39 711-0309 2 Clevis Pin, 5/8" x 1-1/4"
40 49271 1 DumpHandleTube
41 40173 1 DumpControlCable
42 43601 3 Washer, 1.59" x 1.032" x 0.60"
REF PART NO. QTY DESCRIPTION
43 43093 3 Cotter Pin, 1/8" x 1-1/2"
44 710-0865 3 HexBolt,1/2-13x1"(Grade5)
45 R19212016 6 FlatWasher,5/8"x1-1/4"x16Ga.
46 25852 1 Tilt Bracket Extension Strap
47 25851 1 Tilt Bracket
48 43062 1 HexBolt,3/8-16x1-1/2"(Grade5)
49 43350 8 Bolt,Carriage3/8-16x1"(Grade5)
50 64963 1 LiftFrameAssembly
51 43084 5 HexBolt,5/16-18x1-3/4"(Grade5)
52 43010 6 Cotter Pin, 1/8" x 1-1/4"
53 64968 1 Dump Pivot Bracket
54 49273 1 Dump Control Rod
55 49268 1 Dump Control Pin
56 48905 1 Compression Spring
57 46055 1 Spring Pin, 1/8" x 1"
58 25335 1 Pin Stop Bracket
59 47171 1 Nylock Nut, #10-32
60 HA23761 1 Hose Clamp
61 43346 1 Truss-Head Bolt #10-32 x 5/8"
62 64962 1 BucketAssembly
63 43015 2 Hex Nut, 3/8-16
64 43087 3 HexBolt,3/8-16x1-1/4"(Grade5)
65 47572 1 Nut, Hex 3/8-16 Lock Flanged
66 26481 2 Tilt Stop Bracket
67 25722 1 Frame Brace
68 43081 8 Flat Washer, 5/16"
69 44326 2 CarriageBolt,5/16"x1"(Grade5)
70 710-0367 2 HexBolt,5/8-11x1-1/2"(Grade5)
71 736-0247 2 Washer, .41" x 1.25" x .156"
72 43000 1 Extension Spring
73 44062 2 Clevis Pin, 1/2" x 1"
74 142 1 Cotter Pin, 1/8" x 3/4"
75 R19131316 2 Flat Washer, 3/8" x 13/16" x 1/16"
76 63773 1 IndexBracketAssembly
77 48049 1 Index Rod
78 49264 1 LiftHandleTube
79 25562 1 Right (Long) Side Plate
80 25563 1 Left (Long) Side Plate
81 43064 2 Nut, Hex 5/16-18
82 43178 1 Nut, Hex 1/4-20
83 42210 2 Nylock Jam Nut, 3/8-16
42086 Owner's Manual
22
NOTES
23
WARNING: To avoid serious injury, operate your tractor up and
down the face of slopes, never across the face. Do not operate
on slopes greater than 10 degrees. Make turns gradually to
prevent tipping or loss of control. Exercise extreme caution
when changing direction on slopes. Braking may be affected by
tractor attachment. Reduce speed on slopes.
1. Fold this page along dotted line indicated above.
2. Hold page before you so that its left edge is vertically parallel to a tree
trunk or other upright structure.
3. Sight across the fold in the direction of hill slope you want to measure.
4. Compare the angle of the fold with the slope of the hill.
ONLY RIDE UP AND DOWN HILL,
NOT ACROSS HILL
FO
LD
A
LON
G
D
O
T
TED LI
N
E
T
H
IS
I
S
A
1
0
DEG
R
E
E
SL
O
P
E
10 DEGREES MAX.
SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION
OF TRACTOR WITH ATTACHMENT
® Registered Trademark /
TM
Trademark of KCD IP, LLC in the United States, or Sears Brands, LLC in other countries
® Marca Registrada /
TM
MarcadeFábricadeKCDIP,LLCenEstadosUnidos, o Sears Brands, LLC in otros países
Product questions or problems?
1-888-331-4569
Customer Care Hot Line
Get answers to questions, troubleshoot problems,
order parts, or schedule repair service.
Pararespuestasapreguntasoproblemas,yordenar
piezas o pedir servicio para la reparación de su equipo.
To help us help you, register your product at www.craftsman.com/registration
Para poderte ayudar mejor, registra tu producto en www.craftsman.com/registration
Join the Craftsman Club today!
Receive exclusive member benefits including special pricing and offers,
project sharing, expert advice, and SHOP YOUR WAY REWARDS!
Comomiembroexclusivo,recibediversosbeneficioscomo ofertas, precios especiales, proyectos
nuevos, consejos de expertos y nuestro programa de puntos SHOP YOUR WAY REWARDS!

Navigation menu
