Cross Point XM1356 Inductive proximity card reader User Manual

Cross Point b.v. Inductive proximity card reader

user manual

Version 1.0: October 2003 page 1 - 2
Quick Guide XM13.56 Reader/Writer
QUICK GUIDE XM13.56 READER/WRITER
INTRODUCTION
Thank you for using the XM13.56 Reader/Writer. This product offers:
Reading and writing for ISO14443 compliant and Mifare tag technology (1KB, 4KB and
Ultralight)
Reading and writing for ISO15693 compliant tag technology (e.g. I-CODE and Tag-it)
Upgradeable firmware
ISO track 2, Clock & Data, ABA and Wiegand Interface (serial number reading only)
Programmable via RS485
4 IOs
Buzzer
and more.
This Quick Guide describes the connections and specifications of the reader. For detailed
programming information, please refer to the API Manual.
CONNECTIONS
In the following table, the connections of the reader/writer are listed.
Wire Mifare Reader XM13.56
Brown Extra Ground
Violet Optional Power (+5 VDC)
Black Ground
Red Power (+12 VDC)
Yellow RS-485B in +
Blue RS-485B out -
White RS-485A in +
Pink RS-485A out -
Grey IO-1 Magstripe Data / Wiegand Data 0
Green IO-2 Magstripe Clock / Wiegand Data 1
Grey/Pink IO-3 Magstripe CLS / Wiegand Strobe
Red/Blue IO-4 Magstripe Access / Wiegand Access
Note
IO1-4 are buffered IOs. Output is an open collector with a pull up resistor (10KOhm) to 5 Volt (via a
diode). The output current is 50 mA maximum. The maximum current for the IOs together is 100mA.
The outputs are not protected against a too large current draw or transients/spikes.
The reader must not be mounted on metal.
Version 1.0: October 2003 page 2 - 2
Quick Guide XM13.56 Reader/Writer
SPECIFICATIONS
In the following table the specifications of the reader/writer are listed.
Feature Description
Operating Frequency 13.56 MHz ± 7 KHz
Operating voltage +5V (via a special wire), or
+7.5V … +15.5 VDC stabilized.
Current consumption 100 mA ± 5 mA
Operating temperature -20°C to +60°C
IP Rating IP67
Cable length 3 meters
Certification CE and FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
Consult the dealer or an experienced radio/TV technician for help
