Users Manual

ProductionIntroduction

Modelname：QSPR‐303BT

Brandname：QUO

FCCID:2ACDEQSPR‐303BT



Thankyouforpurchasingourproducts.ThisisaBluetoothspeakersysteminfashionabledesign,withwirelessBluetoothstereo

sound.ItsupportsBluetooth2.1agreement,notonlybeingcompatiblewithmobilephones,tablets,laptopsandotherBluetooth

enableddevices,letyougetridofcablescompletely,enjoythejoyofmusicfreely,butalsoaudioinputfrommobilephones,laptops,

MP3,MP4andotherequipments.

Pleasereadthefollowinginstructionscarefullybeforeoperating.Keepthemsafeforfuturereference.



1. Play/Pause2.NextSong/VolumeIncrease

3. PreviousSong/VolumeDecrease4.IndicateLight

5．On/Off  6.MiniUSBDCIn

7.AUX‐inJack8.Microphone

9.TFCardSlot10.SpeakerUnit

ProductFeatures

● Gracefulsoundquality,smallsizebutgreatsoundvolume.

● Decorousandfashionablefacade.

● Thelatestblue‐toothtechnology,widebeused.

● ControlthemusicplayingbetweenspeakerandmobilephoneorotherequipmentswithBluetooth.

● Supportlotsofsoundsourcesinput.

● ReadmusicfilesfromTFcardandupdateonlineeasily

● USBpowersupplyorpoweradapter,built‐inrechargeablelithiumbattery,veryeasytouse.

● Supportanswercalling.

TechnicalParameters

 

● FrequencyResponse：100Hz～18KHz

● S/NRatio：≥70dB

● BluetoothStandard:2.1+EDR

● Bluetoothsignalpower：CLASSII

● Supports:A2DP,AVRCP,HFP,HSP,etc.

● SignalDistance：8‐10M

● SupportreadingMP3、WMA、WAV、AMRfromTFcard

● Power：DC5V500mA

● Built‐inBattery:3.7V400mAH,rechargeablelithiumbattery.

● PlayingTime:7hours(middlevolume)

● ProductSize(D*H):64X67mm

● Weight:195g



HowtoOperate

ChargeUp

ConnectexternalDC5V500mAtochargeupspeaker,indicatelightflashedinred.Finished,lightturnsoff

※Built‐inrechargeablelithiumbattery,pleasechargeupbeforeuse.

※Underoffstate,itwilltakeabout3hourstochargeup.Whenworking,itshouldbeabout5hoursforfullcharging.



ON/OFF

TurnOn：PushthebuttontoONposition,indicatelightisshining.

※Indicatelightwillbeindifferentcolors,whenit’sinBluetoothmode,AUXinmodeandTFmode.Pleasecheckbelowinstruction.



ChangeMode

ThisproductsupportsBluetoothmode,AUXinmodeandTFmode,easytochangebetweeneachotherbylongpressPlay/Pause

buttonfor2seconds.

WhenAUXcableconnected,themodeisconfirmedAUXinputmode;takeoutAUXcable,Bluetoothmodestarts.

OnceinsertedTFcard,enterTFmodeautomatically.

BluetoothMode

Whenturnson,itentersBluetoothmodeautomatically,workinglampflickerinblue:

•Pair:Itisnecessarytopairthisproductforthefirstoperating.

Operationasbelow:Turnonandenterpairingstatusautomatically,workinglightflashesinbluequickly;searchforBluetoothdevice,

untilfindoutpairingname“303”,selectit,thenlampkeepslightingblueinslowflash,pairsuccessfully.(Noted:ifthepasscodeis

required,entry"0000")

•Operation:Afterpaired,youcancontrolthemusicplaybybuttonsormobilephone.

Shortpress ,musicplayandpause.

Shortpress,previoussong,longpress,volumedecrease



Shortpress ,nextsong,longpress,volumeincrease

Duringincomingcalls,shortpresstoanswer.Finished,pressagaintodisconnectthecall.

LongpresstochangetoTFmode.

•Connected:Thisspeakercanstorethedeviceswhichhavepairedwithit.Ifdevicesclosetothisspeakerenough,Bluetoothmode

willstartandpairautomatically.Ifoutofrangeorhaven’topenedBluetoothfunctionondevices,thisspeakerwillenterthepairing

modeandsearchdevicesnearby.

Note：TheremaysomedifferencesinbetweensetupwithsomeBluetoothdevices.Weadviseyoureadtheseinstructionscarefully

beforepairingstarts.



AUXInputMode:

OnceinsertedAUXcableintothisspeaker,Indicatorlamplightsflashingreen,AUXmodestarts.Itcanplaymusicfromtheexternal

deviceconnected.Underthismode,youcancontrolthemusicoradjustvolumethroughpressingbuttons.Volumeincreasing(long

press)/nextsong,volumedecreasing(longpress)/previoussong.



TFMode:

WheninsertedTFcardintospeaker,itentersintoTFmodeautomatically.Theindicationlightingreen.Supportsmusicfilein

MP3,WAV,WMA,AMRformatfromTFcard.YoucaneasytocontrolthemusicVolumeUp/Down,Next/Previoussong,Play/Pausefrom

thespeaker.



LowPowerWarning

Theindicatorlightwillflashredwhenthepoweristoolowtoalarmusertochargeupspeaker.

Ifnotchargeupintime,thespeakerwillswitchoffautomatically.



InstructiononProductSafetyMaintenance



●Donotplacethisproductunderthehigh‐temperatureanddamp

environmentandmakeitbecaughtbyrainorimpactedbystrongforce.

● Ifthisproductgivesoutofsmokeorencountersotherexceptions,inordertoavoidaccidents,pulluptheDC‐USBpowercable

instantly.Contactlocalfranchiserordialthesellerforrepair.

●Theaudiosignalcableandpowercablecannotbepulled,tied,extruded,trampledorsuspendedwithheavyobjectstoavoid

damagingtheinsulationlayeroftheaudiosignalcableandUSBpowercable,whichwillleadtoshortcircuitorbadcontact,etc.

●Pleasepoweroffthisproductwhenitisnotoperatedforalongtime.

●WithBluetoothfunction,itcanbecompatiblewithcommonsmartphonesandtablets,buttheremaybesomedifferencesonce

makeuseofsomespecialdevicesorapplicationprogram.Somefunctionsmaybenotsupported.







PackageList

● BluetoothSpeaker………………………………1set

● UserManual……………………………………………1copy

● 3.5mmStereoAudioCable………………………………………1piece

● StandardUSBtoMiniUSBPowerCable………………………1piece

*Ifthematerialsinsidethepackagearenotconsistentwiththeaccompaniedlist,pleasecontactthemanufacturerorretailseller

whoyoupurchasedtheunitfrom.

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference

that may cause undesired operation.

Changes or modifications to this unit not expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.
