Section 1 - Product Overview
• D-Link DSM-510 High-Definition Media Player
• Quick Install Guide
• Manual, QIG, software, and warranty on CD
• 2dBi Wireless Antenna
• Ethernet (CAT5-UTP/Straight-Through) Cable
• Composite RCA Audio/Video Cable
• Remote Control with 2AAA Batteries
• Power Adapter
• Vertical Stand
If any of the above items are missing, please contact your reseller.
Minimum System Requirements
• PC with:
Windows® XP/2000
1GHz plus processor
Memory Size: 512MB or above
100MB of available hard drive space and a wireless or Ethernet network.
• TV with Composite Video, or HDMI Input.
• Stereo or A/V Receiver with Composite Audio, or Optical Digital.
• If you want to connect the DSM-510 to a Windows® XP-based PC without Intel® Viiv™ technology,
use the included CD to install the Nero MediaHome software and refer to this manual.
Product Overview
Package Contents
Recommended
• Windows XP/MCE-based PC with Intel® Viiv™ technology.
• An Intel® Viiv™ technology verified router.
• Broadband Connection for Accessing Online Content.
• Wired or Wireless Network (Wired network is recommended for video streaming).
9D-Link DSM-510 User Manual
Section 1 - Product Overview
Introduction
D-Link® introduces the latest addition to its multimedia family of products: the D-Link® DSM-510 High-Definition Media
Player. The DSM-510 is a device that plays back video, audio, and photos that are stored on a Media Server.
The DSM-510 integrates home computer systems and home entertainment centers. Digital media content can be
accessed directly from a computer, so that movies, music, and photos can be enjoyed from the comfort of your living
room. The DSM-510 connects easily to a wired or wireless network, and features 802.11g wireless technology for transfer
speeds on a wireless network. These options provide you with the maximum throughput for sharing and transferring
digital media.
Simple to setup with a sleek design that makes it a natural addition to any home entertainment center. The AV jacks
on the back panel of the DSM-510 allow for direct connection to your television. Use the included remote control to
access media content stored on your PC. Browse music files, watch videos, and display photos, all on your television!
In addition, the DSM-510 lets you access online media content through Intel® Viiv™ Zone with an existing broadband
Internet connection.
The DSM-510 adheres to the universal Plug-&-Play AV specification, allowing it to communicate with other UPnP AV
media devices.
The DSM-510 supports the majority of audio, video, and image file formats and streams them directly from your PC.
You can stream MP3, WMA, WAV, OGG Vorbis, and AIFF files from your computer and enjoy them on your home stereo
system. Watch stored videos in DVR-MS, MPEG1/2/4, AVI, or Xvid format on your television. Enjoy slideshows of your
favorite photos in JPEG, TIFF, GIF, BMP or PNG formats. Better yet, it’s easy to access the files through the television
interface using the remote control included with the DSM-510.
Experience digital media like never before with the DSM-510 High-Definition Media Player. The DSM-510 includes
everything you need to instantly access and play music, videos, and photos using your home entertainment center.
10D-Link DSM-510 User Manual
Section 1 - Product Overview
• Stream media content from a PC or D-Link Network Attached Storage to your entertainment center.
• Listen to digital music on your stereo system.
• View digital photos, slideshows with music, and high-definition videos on TV.
• Easily connect to your wireless network using 802.11g at up to 54Mbps.
• Connect using an Ethernet network cable at up to 100Mbps.
• UPnP AV compliant for maximum compatibility.
• Support for most popular digital media formats, including Microsoft Windows® recorded TV files (DVR-MS).
• Remote controlled TV interface for quick access to your media content.
• Experience a world of online media content through Intel® Viiv™ Zone.
• Sleek design complements your existing audio/video equipment.
• Optical digital audio output.
• HDMI output.
• 64-bit or 128-bit WEP & WPA security.
• Supports DHCP for easy connection to your home network.
• Color coded one-touch shortcut buttons on the remote, for quick access to music, photos, and videos.
Features
11D-Link DSM-510 User Manual
Section 2 - Installation
Wireless Installation Considerations
The D-Link High-Definition Media Player lets you access your network using a wireless connection from virtually anywhere
within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location
of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary
depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to
maximizing wireless range is to follow these basic guidelines:
1. Keep the number of walls and ceilings between the D-Link adapter and other network devices to a
minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position
your devices so that the number of walls or ceilings is minimized.
2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a
45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet
(14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead
of at an angle) for better reception.
3. Building Materials make a difference. A solid metal door or aluminum studs may have a negative effect on
range. Try to position access points, wireless routers, and computers so that the signal passes through
drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water
(fish tanks), mirrors, file cabinets, brick, and concrete will degrade your wireless signal.
4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that
generate RF noise.
5. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and
home security systems), your wireless connection may degrade dramatically or drop completely. Make
sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits
a signal even if the phone in not in use.
Note: For best video quality, a wired connection is recommended.
12D-Link DSM-510 User Manual
Section 2 - Installation
Intel® Viiv™ technology-based PCs have this logo on
them.
Setup Your DSM-510 Using an Intel® Viiv™
Technology-Based PC
To use this setup guide, you must have an Intel® Viiv™ technology-based PC featuring the Intel® Viiv™ logo below. If
you do not have an Intel® Viiv™ technology-based PC at this time, please see the D-Link Media Server Installation
section on page 32.
Your device has been designed to work with Intel® Viiv™ technology-based PCs, which helps you add this device
to your network and enjoy content from your PC. To enjoy these features, you may need to update the Intel® Viiv™
software on your PC.
Insert the CD that came with your DSM-510 into your Intel® Viiv™ technology-based PC, and follow the on-screen
instructions to guide you through the update process.
IMPORTANT:
•This software will enable the instant on/off power management features of your computer, which allows your new
device to “wake-up” your PC to access content and services marked “Enjoy with Intel® Viiv™ technology”.
•You may need to restart your PC to begin using the Intel® Viiv™ software.
13D-Link DSM-510 User Manual
Section 2 - Installation
At the Intel® Viiv™ setup screen, select the option Yes, start Intel Viiv Settings
now (recommended).
Click Next
Click Next
Turn on the computer and insert the D-Link DSM-510 Driver CD into the CD-ROM
drive.
If the CD Autorun function does not automatically start on your computer, click
Windows® Start > Run. In the Run command box type “D:\DSM510.exe”, where D:
represents the drive letter of your CD-ROM.
Click Install Media Server
14D-Link DSM-510 User Manual
Section 2 - Installation
After the installation, the following screens will appear.
Click add a device
Click start
Note: Intel® Viiv™ technology continuously scans the network for new devices. If a new device is found, a pop-up alert
is displayed on the desktop.
15D-Link DSM-510 User Manual
Section 2 - Installation
If the Intel® Viiv™ software does not find an Intel® Viiv™ technology verified router, then connect your DSM-510 (see page
17). Power on your DSM-510 (see page 21) and follow the instructions that apply to finalizing your wireless connection
without an Intel® Viiv™ technology verified router.
If an Intel® Viiv™ technology verified router is detected, you should see the adding
a device to your home network screen. Proceed to page 17 to connect your
DSM-510 and power it up for the first time.
Click next
Wireless Connection
Connect your DSM-510, please continue to page 17.
Select the option wirelessly.
If you select connecting it to the router with an Ethernet network cable, please
skip to “Wired Connection” on page 16.
Intel® Viiv™ technology verified routers have
this logo on them.
16D-Link DSM-510 User Manual
Section 2 - Installation
Click next
Wired Connection
Connect your DSM-510, please continue to page 17.
At the adding a device to your home network screen, leave your PC and connect
your DSM-510 (see page 17).
For a wired connection, select the option connecting it to the router with an
Ethernet network cable.
17D-Link DSM-510 User Manual
Section 2 - Installation
All audio, video, and networking connections are located on the rear panel of the DSM-510.
Composite Audio/Video Connector
•
Plug the supplied 3.5mm mini-jack connector into the DSM-510. Plug the opposite end
(the yellow video cable and the red and white audio cables) into your television input.
Video Connections
Select one of two ways to connect video to your DSM-510:
Connecting the DSM-510
HDMI
• Plug the HDMI cable into the HDMI connector on the back panel of the DSM-510.
Plug the opposite end to the matching HDMI connector on your television or audio/video
system.
Note: This cable is not supplied.
By default the DSM-510 will automatically detect and switch between Digital (HDMI)
and Analog (Composite) modes.
High-Definition Multimedia Interface (HDMI) supports standard, enhanced, or high-definition video, plus multi-channel
digital audio on a single cable.
18D-Link DSM-510 User Manual
Section 2 - Installation
Audio Connections
Select one of two ways to connect audio to your DSM-510:
Optical Digital Audio
•
Connect an optical audio connector into the S/PDIF connector on the DSM-510 and the
matching opposite end of the cable to the audio input of your audio system.
Note: This cable is not supplied.
Composite Audio/Video Connector
•
Plug the supplied 3.5mm mini-jack connector into the DSM-510. Plug the opposite end
(the yellow video cable and the red and white audio cables) into your television/receiver
input.
19D-Link DSM-510 User Manual
Section 2 - Installation
RJ-45 Ethernet Connector
• Connect the supplied Ethernet cable to the network cable connector, and attach the
other end to a router or hub on your network.
Network Connections
Select one of two ways to connect your DSM-510 to your network:
Wireless Antenna
• Attach the supplied antenna by threading it onto the antenna connector. Be sure the
antenna is secure and in an upright position.
20D-Link DSM-510 User Manual
Section 2 - Installation
Using the Remote Control
1. Power
2. Alphanumeric Keys
3. HOME
4. SHIFT
5. DELETE
6. VOLUME + & -
7. PAGE UP & DOWN
8. MUTE
9. BACK
10. Enter & Navigation Buttons
11. MENU
12. SETUP
13. Color-Coded Shortcut Keys
14. USB
15. Stop, Play/Pause, REV,
FF, PREV, and NEXT
16. REPEAT
17. SHUFFLE
18. SEARCH
19. INFO
20. SLOW
21. A-B
22. L/R
13
2
4
8
5
67
9
11
10
12
13
14
15
16
17
18
19
20
22
21
Note: Please see the Remote Control Table in the Appendix on page 83 for more information on the functionality of
the DSM-510 remote control..
21D-Link DSM-510 User Manual
Section 2 - Installation
Power on the DSM-510
Plug in the DSM-510’s power cable into the back panel connector, the unit should power
on immediately.
Note: If you are using the composite or HDMI video connection, the DSM-510 will automatically
detect the correct video signal.
If you are connecting through a wired Ethernet cable, please continue to page 26.
If you are connecting the DSM-510 wirelessly and do not have an Intel® Viiv™ technology verified
router, please continue to page 24.
If you are connecting the DSM-510 wirelessly and have an Intel® Viiv™ technology verified router,
please continue to page 22.
22D-Link DSM-510 User Manual
Section 2 - Installation
Note: Skip to page 24, if you do not have an Intel® Viiv™ technology verified router.
After clicking OK, the next screen will provide you with a temporary four-character
passcode. Please memorize or write down this passcode.
Finalizing Your Wireless Connection with an Intel® Viiv™
Technology Verified Router
Click next
Return to your PC and follow the on-screen instructions to complete the addition
of your device to the network.
Click OK
Click Yes, if you have an Intel® Viiv™ technology verified router. Adding a device to
a wireless network using the Intel® Viiv™ Settings requires an Intel® Viiv™ technology
verified router featuring the logo on page 15. If you do not have a verified router,
please see the D-Link Media Server Installation section in this manual.
23D-Link DSM-510 User Manual
Section 2 - Installation
Click OK
Please Continue to page 30!
Note: If the timer expires before you enter the temporary passcode, you can obtain
a new passcode by starting the timer again from the DSM-510.
After the device has been added to the network, return to your DSM-510.
After you have clicked OK, a home page will appear. Please return to your PC to complete the addition of your
device.
Click next
Enter the passcode before the 10-minute timer expires.
24D-Link DSM-510 User Manual
Section 2 - Installation
Finalizing Your Wireless Connection without an
Intel® Viiv™ Technology Verified Router
At the next screen, select Scan for wireless LANs and click OK.
Click CANCEL
Click CANCEL, if you do not have an Intel® Viiv™ technology verified router.
Using your remote control, select a wireless
network from the list and press ENTER.
25D-Link DSM-510 User Manual
Section 2 - Installation
Please return to your PC to complete the addition of your device.
Please Continue to page 27!
Select the Encryption Type and the Cryptography Key to configure your wireless
settings. Once you’ve completed all of your settings, please click OK.
If you need to manually configure the IP Settings, click the IP Address Settings
button. You will see a new screen appear.
To manually enter the IP address information, select NO from Get IP Address
and press the ENTER button on your remote control. The navigation arrows on
your remote control will allow you to select the corresponding field that needs to
be updated. Press the ENTER button on your remote control to select the field
and use the number keys to input the information. Press ENTER when you have
completed entering the information. Click OK after you’ve finished updating the IP
Address Settings screen.
Click OK
Click OK
26D-Link DSM-510 User Manual
Section 2 - Installation
If you connected to your network using a wired Ethernet cable, you will see this
screen.
Finalizing Your Wired Connection
Click Finish
Click next
After you have clicked OK, a home page will appear. Please return to your PC to
complete the addition of your device.
Please Continue to page 30!
27D-Link DSM-510 User Manual
Section 2 - Installation
Note: Your device may have a “?” on it, this means that it is not approved yet.
After clicking on the device, the next screen will provide details about this
device.
Adding a Device without an Intel® Viiv™ Technology
Verified Router
Click next
Click your media device
Click view network map
28D-Link DSM-510 User Manual
Section 2 - Installation
Select approved if you want the media device to allow access to the network.
The media device should be automatically selected.
When you see this screen, click yes to grant access for your media device.
Click next
Click next
Click next
29D-Link DSM-510 User Manual
Section 2 - Installation
After you’ve clicked the back button you will be returned to the main menu. Click
the update media library button to set up your Intel® Viiv™ Media Library.
After you granted access to the media device you should be returned to the network
map menu. Notice that the “?” no longer appears on your media device.
Please Continue to page 31!
Click back
Click update media library
30D-Link DSM-510 User Manual
Section 2 - Installation
Your PC will begin adding the device. Please wait…this may take up to five minutes.
When it has been added, you will see this screen, listing the device name and type.
Click next
Adding a Device
The media device should be automatically selected.
When you see this screen, you have successfully added your device to the
network.
Click next
Click next
31D-Link DSM-510 User Manual
Section 2 - Installation
In order to access the media content on your PC, you must setup your Intel® Viiv™
Media Library.
It is recommended to select Standard Update.
Setting Up the Intel® Viiv™ Media Library
Click next
Click next
32D-Link DSM-510 User Manual
Section 2 - Installation
Return to your DSM-510 unit and you should see the following menu. Use your
remote control to navigate through the menu.
When you see this screen, you have successfully completed the setup of your
Intel® Viiv™ Media Library.
You are now ready to use your DSM-510!
Click finish
Navigating to the Intel® Viiv™ Technology Settings Screen
and Images on Your PC
You may navigate to the Intel® Viiv™ settings window either by selecting the Intel® Viiv™ logo on your desktop or system
tray. The logo can also be found in the More Programs area in Windows® XP Media Center Edition 2005.
33D-Link DSM-510 User Manual
Section 2 - Installation
Note: Do not install the Media Server software if you have an Intel® Viiv™ technology verified PC, because you
can use the Intel® Viiv™ Media Server that is included with your Intel® Viiv™ technology verified PC.
To share audio, video, and photo files from your computer, it is necessary to install the Nero MediaHome software
on any PC that is not Intel® Viiv™ technology verified. The Nero MediaHome software allows you to point to the folders
on your PC’s hard drive that contain the audio, video, and photo files you want to share. The Nero MediaHome software
then streams the content to your DSM-510 via your wired/wireless network connection.
Currently the DSM-510 only connects to one Media Server at a time. If more than one PC contains files you want to
share, you can select one of the following options:
1. Copy all of the files to one computer designated to run the Nero MediaHome software.
2. Map network drives from the computer with the Nero MediaHome software to additional computers that contain files
you want to share. This method also allows you to share files from computers that cannot run the Nero MediaHome
software such as Macintosh systems. The computer running the Nero MediaHome software must always be on
when streaming content from any computer.
3. Install the Nero MediaHome software on each computer. You can only connect to one server at a time. To connect
to another server, you must press the Media Server key on the remote control, or go to the home screen and select
Server.
4. Power on your DSM-510, and do the following based on your network connection:
• Wireless: Select the option
Cancel.
Connect to your network by selecting a network name and by providing the
necessary information for authentication. Please refer to page 24 for step-by-step instructions.
• Wired: After powering on your DSM-510 your network will automatically be detected. Click Finish.
D-Link® Media Server Installation
34D-Link DSM-510 User Manual
Section 3 - Configuration
Network Settings:
TV Settings:
Audio Output
Settings:
Language Settings:
Settings for Ease of
Use:
Reset Settings:
Wireless LAN
Profile Settings:
Software Update:
Device Information:
This option allows you to modify your wireless and wired settings. You can
also access your WCN® setup wizard from this screen.
This option allows you to change your video output type between Digital
(HDMI) and Analog (Composite), as well as the resolution size.
Select the audio output type for different audio formats.
This option allows you to choose the language that the interface is
displayed in.
Here you can configure settings for your device’s startup, which will allow
easier access to your media.
This will restart your device to factory settings.
Here you can view previously accessed wireless connections as well as choose between which one to connect to.
This option allows you to update the DSM-510.
This option displays information concerning the DSM-510.
Press the Setup button on your remote control to configure your DSM-510.
Options
Settings
35D-Link DSM-510 User Manual
Section 3 - Configuration
In order to input information, you must use the DSM-510 keyboard interface.
When information is needed within an input box, click the MENU key on your
remote control and select the Keyboad Input option.
Use the selection arrows and the ENTER button to select from Numbers,
Lower (lower case alphabet), Upper (upper case alphabet), or Symbol. The
SHIFT key on your remote control can also toggle between these options
if pressed repeatedly. Once you’ve selected your character type, use the
selection arrows on your remote control to select the characters you want to
input. When you have finished, select OK.
On-Screen Keyboard
36D-Link DSM-510 User Manual
Section 3 - Configuration
Wired LAN Settings:
Wireless LAN
Settings:
If you want to connect through an Ethernet cable, then select this
option.
Select this option if you are using the antenna to connect wirelessly to a
server.
Network Settings
Wired LAN Settings
Get IP Address:
IP Address:
Subnet Mask:
Default Gateway:
DNS Server:
MAC Address:
Clicking this button will retrieve the IP address automatically.
Input the IP Address.
Input the Subnet Mask.
Input the Default gateway.
In case a DNS server exists in the network, input the IP Address of the DNS
server.
Input the MAC Address.
37D-Link DSM-510 User Manual
Section 3 - Configuration
Wireless LAN Settings
Scan for wireless
LANs:
Manual
Configuration:
Windows Connect
Now:
Click this button to search for wireless LANs, and select your Access
Point.
Click this button to manually connect to the network (see the following
screen).
Click this option if you want to use Windows Connect Now® to configure
your device’s wireless connection. If you want to configure your device’s
wireless connection, please continue to page 42.
MODE:
Wireless LAN Type:
SSID:
Encryption Type:
Cryptography Key:
Choose between Ad-Hoc or Infrastructure.
Ad-Hoc should be selected when the DSM-510 is directly connected to
other wireless network devices without an access point.
Infrastructure should be selected when the DSM-510 is connected to
the wireless LAN where an accesss point device exists.
Select between either 802.11b/g or 802.11a.
Using the software keyboard input the SSID, which should be used by
the existing wireless network.
Select between None, WEP, or WPA.
When WEP or WPA is selected in Encryption Type, two boxes will appear (the Index Selection box and the
Cryptography Key input box.
Index Selection box allows you to select an Index number from 1 to 4. Each index number saves a Cryptography
Key.
Cryptography Key allows you to enter the WEP or WPA key used in the existing wireless network.
Manual Configuration
38D-Link DSM-510 User Manual
Section 3 - Configuration
TV Settings
Output Type:
Screen Size:
Resolution:
Select between Digital (HDMI) and Analog (Composite).
Select between 4:3 or 16:9.
If the output type is set to Digital (HDMI), select between Auto, 480i, 480p,
1080i, and 720p. If the output type you selected is Analog (Composite),
select between 480i, 480p, 1080i, and 720p.
AAC:
Dolby Digital:
WMA:
Auto Volume Control
Strength:
You can choose to output audio in LPCM or have it turned off to the digital
output.
You can choose to output audio in 2 channel or 5.1 for analog. You can
also change the digital output from LPCM to Dolby Digital or off.
You can choose to output audio in 2 channel or 5.1 for analog. You can
also change the digital output from LPCM to off.
There are three variable settings to select from: Small, Moderate, and
Strong. These control tha audio output depending on the strength of the
media file.
Audio Output Settings
39D-Link DSM-510 User Manual
Section 3 - Configuration
Select the available language that best fits your interface.
Language Settings
Connect to last
accesed server
automatically:
Connect to single
server/USB
automatically:
Resume last screen
from standby:
On startup your DSM-510 will try to access the last media source it was
connected to.
If only one media source or USB is detected the media server will connect
to it automatically.
After turning on the unit, the last screen accessed will be displayed.
Settings for Ease of Use
40D-Link DSM-510 User Manual
Section 3 - Configuration
You can reset the DSM-510’s settings through this screen.
Reset Settings
Pick the wireless access point that you want to exchange connection
priorites.
This option will initialize the move between wireless access points.
This will remove the wireless access point profile from the list.
Note: In order for the exchange to take effect, you must power cycle the
DSM-510 (meaning you must turn off the DSM-510 and turn it back on
again).
Wireless LAN Profile Settings
Set to Exchange:
Exchange:
Remove:
To exchange connection priorites, click the MENU button on your remote control.
41D-Link DSM-510 User Manual
Section 3 - Configuration
Update over
Internet:
Update from USB:
Select this option to update the DSM-510 through an Internet
connection.
Select this option to update the DSM-510 through a USB device.
Software Update
Displays the name of the device.
This will show the current version of the software that the device is
using.
Shows the Wired and Wireless MAC address of the DSM-510.
Device Information
Device Name:
Version:
MAC Address:
This screen will display information about the DSM-510.
42D-Link DSM-510 User Manual
Section 3 - Configuration
If you already have wireless settings configured on your PC, instead of using the Intel® Viiv™ setup , you can use
Windows® Connect Now (WCN) to configure the wireless settings on your DSM-510.
Note: WCN is only available on PCs running Windows® XP with Service Pack 2 installed.
Go to Start > All Programs > Accessories > Communications and click Wireless
Network Setup Wizard.
Your system will display the Setup Wizard Welcome screen. Click Next to continue.
Windows® Connect Now
Click Next
43D-Link DSM-510 User Manual
Section 3 - Configuration
Select to add a new device to your existing wireless network and click Next to
continue.
The wizard provides two methods for setting up a wireless network. Select to use a
USB flash drive to save your wireless network settings and click Next to continue.
Note: Using a USB flash drive is recommended.
Click Next
Click Next
44D-Link DSM-510 User Manual
Section 3 - Configuration
Plug your flash drive into a USB port on this computer. The drive letter will appear
in the pull down menu. You can choose to use this drive or select another drive.
Click Next to save your wireless settings to the USB flash drive. This may take a
few seconds.
Click Next
This screen will appear when the wireless settings have been saved to the USB
flash drive.
Next, remove the USB Flash Drive from your PC and insert into the USB port on the back panel of the DSM-510.
Click Next
45D-Link DSM-510 User Manual
Section 3 - Configuration
The following screen will appear, prompting you to wait for the detection to take
place.
The following screen confirms that your wireless settings have been applied.
Click OK.
46D-Link DSM-510 User Manual
Section 3 - Configuration
Next, remove the USB Flash Drive from the DSM-510 and insert it back into the USB
port on your PC. Click Next to continue.
Wireless configuration using WCN is now complete. The setup wizard will display
the devices that have been setup with your wireless network. Click Finish.
Click Next
Click Finish
Windows® Connect Now has been configured!
47D-Link DSM-510 User Manual
Section 4 - Operation
VIDEO:
MUSIC:
PHOTO:
SERVER:
USB:
OPTION:
Click Enter on your remote control to show the Video Contents selection
screen.
Click Enter on your remote control to show the Music Contents selection
screen.
Click Enter on your remote control to show the Photo Contents selection
screen.
Click Enter on your remote control to show the Server selection screen.
Click Enter on your remote control to show the Connected USB Device
List.
Click Enter on your remote control to show the Options screen.
Operating the DSM-510
Note: To directly access this screen, press the Server button on the remote control.
Note: If the Intel® Viiv™ technology verified PC is powered down, selecting the Intel® Viiv™ Media Server will power it back up to provide
access to music, photo, video, and the Intel® Viiv™ Zone.
The DSM-510 uses an on-screen menu interface. As you move through the menus, you will use the selection arrows
on the remote control to move up, down, right and left. The highlight bar moves from item to item as you press the
selection arrows. You will need to press ENTER on the remote control to access the item. The Page Up and Page Down
buttons can be used to navigate through the track list one page at a time. Once you are in a particular category, you
can press the MENU button on your remote control to access the pulldown menu within that category.
Menu Basics
48D-Link DSM-510 User Manual
Section 4 - Operation
Music Quality
Your music listening experience on the media player depends upon the quality of your digital music files on your PC.
Avoid quality settings below 48kbps as they create low quality audio. For CD quality music, rip your MP3s at 128kbps
or higher, with a sample rate of 44.1kHz.
Supported Music Formats
The following music file formats are supported:
• MP3 (up to 320 kbps)
MPEG-1, Layer 3 Audio file -The standard Internet
music file format. This is the most commonly used audio
format.
• WMA (Does not support WMA lossless, WMA Pro)
Windows Media Audio file - Supported by the Microsoft
Windows Media player and some music jukebox programs.
Also supports WMDRM protected WMA files downloaded
from online services.
• WAV
WAV was developed by Microsoft and IBM. WAV sound files
end in .wav and are compatible with Windows applications
supporting audio.
• AIFF (AIFF files must be encoded in PCM format only.)
AIFF (Audio Interchange File Format) was developed by Apple Computers and is the standard audio format for
Macintosh computers. File extensions are .AIF or .IEF.
• MPEG 1 and MPEG 2
Moving Pictures Experts Group created standards for compressing audio and video. Audio uses the file extension
.mp3.
• OGG Vorbis
Open source audio format. Uses the file extension .ogg.
Music
49D-Link DSM-510 User Manual
Section 4 - Operation
Playing a Track
Once you enter the music menu, there are several ways that you can view tracks. You can view Playlist, Genre, Artist,
Album, All Music, Folders, or Favorites.
If you select to view All Music (see the following menu), then use
the selection arrows to navigate to the track you wish to play.
Once you have located the appropriate track, highlight it and
press ENTER or Play on the remote control. The track will begin
playing on your stereo or television speakers.
To play all of the tracks visible in this category, simply press
Play.
Select the MUSIC category from the HOME page or click the MUSIC button on the remote control. Select a category,
by using the down arrow and up arrow on the remote control to navigate (choose from Playlist, Genre, Artist, Album,
All Music, Folders, or Favorites). Select your option by clicking ENTER. If you want to play all of the tracks within the
category you selected, simply press the Play button. If you want to play just one track, use the up arrow and down
arrow buttons to navigate one track at a time. After the appropriate track is highlighted, press ENTER on the remote
control. The Page Up and Page Down buttons can be used to navigate through the track list one page at a time.
Accessing Music
50D-Link DSM-510 User Manual
Section 4 - Operation
Playing a Group of Songs
Select a music folder and press the Play button on the remote control, all of the songs within the selected folder will
be played. You can highlight a genre of music and all files that are associated with that genre will be displayed. Genre
categories are defined when an audio file is created.
You can play songs within a folder from a specified track forward. For instance, if you have a folder with ten tracks and
select Track 3, clicking on the Play button will play tracks 3 through 10.
Creating Music Playlists using 3rd Party Software
Use your favorite music software on your PC to create music playlists. A playlist allows you to specify exactly what tracks
to play and in what order to play them. For example, create a “favorites” playlist and just listen to your favorite tracks.
The DSM-510 will play tracks from playlists you create on your computer. The media player supports playlists in three
standard formats:
• m3u Playlist File
• pls Playlist File
• wpl Playlist File
Software for playing music on your PC can be used to create playlists. WinAmp™ and Microsoft Windows® Media
Player™ are two examples.

Navigation menu
