HEOS 1 Go Pack QUICK START GUIDE
HEOS 1 GP EM QSG WT 150317.indd 1 2015/03/17 17:58:15
1
Make sure you have the following items in working order:
Apple iOS or Android mobile device
connected to your network
HEOS 1 Speaker
BEFORE YOU BEGIN
Before using a new HEOS 1 speaker with Bluetooth, we recommend you fi rst connect
your HEOS 1 Speaker to your home network to get the latest speaker updates and newest
features.
A home network is not required for every day Bluetooth functionality.
HEOS 1 GP EM QSG WT 150317.indd 1 2015/03/17 17:58:16
HEOS 1 Go Pack QUICK START GUIDE
2
Français Español Deutsch Nederlands Italiano Svenska Dansk Norsk Pусский Polski
English
Carefully unpack your HEOS 1 Go Pack.
Verify that the following items are included in the box.
STEP 1: UNPACK
HEOS 1 GP EM QSG WT 150317.indd 2 2015/03/17 17:58:17
3
STEP 2: PREPARE
Remove the cap from the bottom of the HEOS 1 speaker by turning the cap
counter-clockwise and pulling it away from the speaker.
HEOS 1 GP EM QSG WT 150317.indd 3 2015/03/17 17:58:17
HEOS 1 Go Pack QUICK START GUIDE
4
Français Español Deutsch Nederlands Italiano Svenska Dansk Norsk Pусский Polski
English
Align the red dots on the top of the battery and bottom of the speaker.
1
STEP 3: ATTACH
Turn the battery clockwise so that it is aligned with the shape of the
speaker.
2
HEOS 1 GP EM QSG WT 150317.indd 4 2015/03/17 17:58:18
5
To charge the battery, connect the HEOS 1 power adapter between the
speaker and a wall outlet. Four blue LEDs indicate a full charge.
STEP 4: CHARGE
HEOS 1 GP EM QSG WT 150317.indd 5 2015/03/17 17:58:19
HEOS 1 Go Pack QUICK START GUIDE
6
Français Español Deutsch Nederlands Italiano Svenska Dansk Norsk Pусский Polski
English
Once your battery is fully charged, attach the Bluetooth Adapter to the back of
the speaker.
STEP 5: GO WIRELESS
HEOS 1 GP EM QSG WT 150317.indd 6 2015/03/17 17:58:20
7
STEP 6: PAIRING
Pairing the HEOS 1 with your Devices
Bluetooth
Press and hold the Connect button located on the back of the HEOS 1
speaker (under the right side of the cap) for 3 seconds and release the
button when you see a pattern of two fl ashes on the status LED.
Activate the Bluetooth setting on your mobile device.
2
1
HEOS 1 GP EM QSG WT 150317.indd 7 2015/03/17 17:58:20
HEOS 1 Go Pack QUICK START GUIDE
8
Français Español Deutsch Nederlands Italiano Svenska Dansk Norsk Pусский Polski
English
HEOS 1
Select “HEOS 1“ from the list of available Bluetooth devices. In a few
seconds your mobile device will indicate that it is connected to your
speaker.
Play music using any app on your device. The sound will now play from
the HEOS 1 speaker.
4
3
HEOS 1 GP EM QSG WT 150317.indd 8 2015/03/17 17:58:21
9
STEP 7: CLOSE SPLASHGUARD
Press in the Splashguard so that it is fi rmly and evenly attached.
Remove the power connector from the speaker.
2
1
Properly attaching the splashguard will make your HEOS 1 speaker waterproof
to the IPX4 standard. DO NOT submerge the speaker in water!
HEOS 1 GP EM QSG WT 150317.indd 9 2015/03/17 17:58:22
HEOS 1 Go Pack QUICK START GUIDE
10
Français Español Deutsch Nederlands Italiano Svenska Dansk Norsk Pусский Polski
English
TURNING OFF THE BATTERY
To turn off the battery, press and hold the button on the back of the battery
for 2 seconds. The LEDs will fl ash quickly then turn off , indicating that the
battery is off .
Turning off the battery will conserve battery power while you are not playing
music and HEOS 1 is not plugged in to AC power.
To turn the battery back on, press and hold the button again for 2 seconds.
Note: while the battery is disconnected from HEOS 1, it is always off .
HEOS 1 GP EM QSG WT 150317.indd 10 2015/03/17 17:58:22
11
• For more information, visit www.HEOSbyDenon.com
• Refer to the Online Manual for other functions information and operation
procedure details.
manuals.denon.com/HEOS1/ALL/EN
OWNER'S MANUAL
HEOS 1 GP EM QSG WT 150317.indd 11 2015/03/17 17:58:23
HEOS 1 Go Pack QUICK START GUIDE
12
Français Español Deutsch Nederlands Italiano Svenska Dansk Norsk Pусский Polski
English
BASIC TROUBLESHOOTING
Cannot pair a Bluetooth mobile device with the speaker
•The connection from the mobile Bluetooth device is malfunctioning. Power cycle the mobile device, remove the pairing information
and re-pair the HEOS 1 speaker to the mobile device.
•Press and hold the connect button for 3 seconds and release the button when you see a pattern of two fl ashes on the status LED.
Make sure your mobile device has Bluetooth turned on and select “HEOS 1“ from the list of Bluetooth devices.
Cannot hear Bluetooth music
•Your Bluetooth mobile device is not paired with HEOS 1. Follow the pairing procedure.
•HEOS 1 is off . Connect HEOS 1 to AC power or turn on the HEOS 1 battery by pressing battery power button for 2 seconds.
Check the AC power outlet is working.
•HEOS 1 battery is fully depleted. Check the battery gauge. Recharge the battery.
•The HEOS 1 is Wi-Fi mode or Aux-in mode etc. Pair and connect Bluetooth device to HEOS 1.
•The Bluetooth mobile device is connected to another audio device. Make sure your Bluetooth device is connected to HEOS 1.
•The volume on Bluetooth mobile device is too low. Check the volume on the Bluetooth mobile device. Check the volume on the
HEOS 1 speaker.
Cannot attach battery
•Make sure bottom cover not is installed on HEOS 1 speaker.
•Make sure no foreign object stuck in speaker/battery connection mechanism.
•Be sure to line up red dots before attempting clockwise rotation to lock.
Google Play is a trademark of Google Inc.
Apple, the Apple logo, iPad, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc.
Wi-Fi Protected Setup™ logo is trademark of Wi-Fi Alliance.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by D&M Holdings Inc. is under lice nse. Other
trademarks and trade names are those of their respective owners.
HEOS 1 GP EM QSG WT 150317.indd 12 2015/03/17 17:58:24
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following tow conditions:
(1)this device may not cause interference, and(2) this device must
accept any interference, includinginterference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables auxappareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes :(1) l'appareil ne doit
pas produire de brouillage, et(2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre lefonctionnement.
FCC Statement:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Note: Modifications to this product will void the user’s authority to operate this equipment.
