DASAN Network Solutions H660W G-PON ONT User Manual H660W CHT QIG EN 140828 V1
DASAN Network Solutions, Inc. G-PON ONT H660W CHT QIG EN 140828 V1
User Manual
H660W
Power Adapter
RJ45 UTP Cable (CAT5e)
QIG (Quick Guide)
2.3 Rear View
④ Connect the Ethernet cable from LAN port to PC.
⑤ Connect a power adapter from power port to a live AC outlet.
⑥ Turn on the unit by pushing the power buon.
⑦ Push WLAN buon to enable WiFi.
① Remove the protecve cap of GPON port.
② Connect an SC/UPC connector opc cable to the port.
③ And then arrange opc line on splice tray, not to give damage to
GPON connecon due to any possible pull.
3. Installaon
GPON Opcal Network Terminal (ONT) with Wi-Fi
QIG (Quick Guide)
Informaon furnished by Dasan Networks, Inc. is believed to be accurate and reliable. However, no responsibility
is assumed by Dasan Networks for its use, nor for any infringements of patents or other rights of third pares which
may result from its use. No license is granted by implicaon or otherwise under any patent or patent rights of DASAN
Networks. DASAN Networks reserves the rights to change specificaons at any me without noce.
Copyright © 2014 by DASAN Networks, Inc. All rights reserved.
DASAN Networks, Inc. www.dasannetworks.com/en
Item Descripon
① OPTIC LINE Connect the network.
② LAN1~4 Connect PC or LAN.
③ Power Port Connect power adapter.
④ ON/OFF Turn on/off the unit.
⑤ RESET Reboot the unit.
⑥ WPS Enable WPS process.
⑦ WLAN Enable WiFi funcon.
V1
2.2 Specificaon
Item Specificaon
System Memory 128MB DDR3
Flash Memory 128MB Nand Flash
1 GPON port (1G, SC/UPC)
Uplink Interface
Service Interface 4 10/100/1000Base-T ports (RJ45)
Wireless
Internal antenna
IEEE 802.11b/g/n compliant
Bandwidth: 2.4GHz
Two Transmit and Two Receive path (2T2R)
LED PWR, PON, ALM, WLAN, WPS, LAN1~4
Power Adapter
Operang Temp.
Output: 12VDC/1A
0 to 40°C
Operang Humidity 5 to 95% (non-condensing)
Dimensions
(W x D x H) 160 x 125 x 43 mm
Buon ON/OFF power, WLAN, WPS, RESET
2.4 Front View (LEDs)
4. Inial Web Access
You can access the unit through a web browser by using the “inial
LAN IP” at first. The detail procedure is as follows:
① Connect LAN1 port of the unit to your PC using Ethernet cable.
② Configure IP assignment of your PC to DHCP (dynamic assignment).
How to configure dynamic IP on your PC is as follows:
For Windows XP:
Start > Seng > Network Connecons > Local Area Connecon
double click > Internet Protocol (TCP/IP) double click > Obtain an
IP address automacally and Obtain DNS server address
automacally selecon > OK
For Windows 7:
Start > Control Panel > View network status and tasks under
Network and Internet (View by: Category) > Change adapter
sengs on the le menu > Local Area Connecon right-click >
Properes > Internet Protocol Version 4 (TCP/IPv4) double click >
> Obtain an IP address automacally and Obtain DNS server
address automacally selecon > OK
The PC will be allocated IP address automacally through the unit.
③ Open a web browser, and enter hp://192.168.1.100:8080 in a
URL field.
④ Type “user/user” in user name/password field, and log into the
system. Inial page is displayed.
※ The default SSID and its password are as follows:
SSID: DASAN_GONTxxxxxx
(xxxxxx is the last 6 digit/leers of MAC address of your unit.)
Password: 1234567890a
※ To change the SSID and/or password, move onto Basic Sengs > Wireless
LAN > SSID Seng on the web, and click Modify. And change them and
click Apply. And then click Apply Config on top of page, and reboot the unit.
DASAN Tower, 49, Daewangpangyo-ro 644 Beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 KOREA
Label Light Status Descripon
PWR Green On
Off The system is turned off.
The system is turned on.
No opcal signal, Firmware update fail or other faults.
Error rate high. Required to check opc cable roung
or vending.
ONT normally operang.
Loopback test being performed.
PON
ALM
Red
Green
Orange
Orange
On No opc signal.
On Opc signal normal. Normally registered.
Blink
On
Blink
Blink
Blink
Firmware being downloaded. Do not turn off the unit.
Service held aer registered normally.
ONT not registered. Keep blinking before registraon
process finished.
Red
On
WLAN Green On WiFi funcon enabled.
Off WiFi funcon disabled.
WPS Green
Blink In progress.
On Success (for 5 seconds)
Off Disabled or process finished.
Off
Off
Link is down.
LAN
1~4
Green
On The 1G port link is up.
Blink on the service port.
Orange
On The 10/100M port link is up.
Blink on the service port.
The 1G transmit or receive acvity is present
The 10/100M transmit or receive acvity is present
2.1 Package Contents
2. Introducon
GPON Port
Splice Tray
3
2
1
4
567
4
5
67
1. Cauon
- This unit is indoor use and all the communicaon wirings are limited to inside of the building.
- Never look directly at the fiber TX port and fiber cable ends when they are powered on.
- DO NOT use near water.
- DO NOT place near high temperature source.
- DO NOT disassemble the unit.
- DO NOT operate the unit in a locaon where the maximum ambient temperature exceeds 104°F.
- Open opcal connecons must use a protecve cap under all circumstances to protect against
physical damage and dirt.
- Avoid impact stresses when handling connectors. Physical damage to the faces of opcal
connecons impairs transmission quality (higher aenuaon).
- Avoid a bend radius in excess of 1.18 in for fiber opc links.
- Check the available voltage supply.
- It may only be repaired by authorized service personnel.
FCC Cerficaon Requirements
● Cauon
Any changed or modificaons not expressly approved by the party responsible for
compliance could void the user`s authority to operate this equipment.
● FCC RF exposure requirements
The antenna used with this module must be installed to provide a separaon distance of
at least 20cm from all persons, and must not transmit simultaneously with any other
antenna or transmier except in accordance with FCC mul-transmier product
procedures.
● User Informaon
This device complies with Part 15 of the FCC`s Rule. Operaon is subject to the following
to condions;
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesirable operaon.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not occur in a
parcular installaon. If this equipment does cause harmful interference to radio or
television recepon, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separaon between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
