iFP-900
Instruction Manual
Thank you for your purchase.
Please read this manual carefully
before using your new player.
http://www.iriver.com
MP3PLAYER/FMTUNER
Model iFP-900
http://www.iriver.com
GettingStarted
Copyrights/Certification/Trademarks/LimitedLiability
Copyrights
1-
Welcome
GettingStarted
1-
Thank your for your iRiver purchase.
The iFP-900 comes complete with a long list of advanced features.
It is important that you read the manual to ensure that you get the most out
of your new player.
URL : www.iRiver.com
Find information on our company, products, and customer and technical support.
Update your player with firmware downloads. Firmware upgrades offer
Consult the product FAQ.
Register your iRiver product online so that our Customer Service is able to
provide support as efficiently as possible.
All contents contained in this manual subject to change without notice to
improve ability of this player or according to changing of specification.
http://www.iRiver.com
iRiver Limited has all the rights of the patent, trademark, literary property and
intellectual property related to this manual. You may not reproduce any part of this manual
unless authorized by iRiver Limited. You can be punished by using any part of this manual
illegally.
The software, audio and video which have an intellectual property are protected
by copyright and international laws. It is user s responsibilities when he/she reproduce or
distribute the contents created by this product.
The companies, institutions, products, people and events used in examples are
not real data. We don t have any intension to be related with any companies, institutions,
products, people and events through this manual and should not draw inferences. Users
are responsible for observing the copyrights and intellectual properties.
1999~2004 iRiver Limited, All right reserved
Windows, Windows 98 SE, Windows ME, Windows 2000, Windows XP and Windows Media
Player are the registered trademarks of Microsoft Corp.
CE, FCC, MIC
Certification
Trademarks
Neither the Manufacturer, importers nor dealers is responsible for any accidental damage
including bodily injury or any damage resulting from misuse or unsuitable operation by you.
The information on this manual is prepared with the current product specifications. The
manufacturer, iRiver Limited, is adding new features to the product and may persistently
apply new technologies hereafter.
All standards may be changed at any time without notice.
LimitedLiability
WelcometoiRiverWebsite
Getting started
Locating the controls
PC software installation
Basic operation
Convenient Functions
Additional information
1
2
3
4
5
6
Contents
This manual covers the installation and use of the player hardware. For details
regarding the software operation including transferring music to the player, please see
the Software Instruction Manual.
Getting started
Gettingstarted
Contents
1
Handling Notices for Safety
Features
About power supply
1-1
1-3
1-4
1-5
Getting started
HandlingNoticesforSafety
1-2
HandlingNoticesforSafety
Getting started
1-1
Keep out of direct sunlight.
Damage to your player may result from
improper use.
Do not use water or chemicals to clean the
player. Clean the surface with a soft cloth.
Damage to your player may result from
improper use.
Do not disassemble or modify.
Damage to your player may result from
improper use.
Keep out of extreme heat and cold.
Damage to your player may result from
improper use.
Do not place objects inside the device.
Damage to your player may result from
improper use.
Do not use excessive force on the buttons
or attempt to disassemble the device.
Damage to your player may result from
improper use.
Keep away from harsh environments
including humid, dusty, and smoky areas.
Damage to your player may result from
improper use.
Avoid falling over a stone or other material
with putting the player in your pocket
Damage to your player may result or injury
from improper use.
Keep headphones / earphones cords
under control at all times.
Cords may get caught on a variety of objects
and cause damage or injury.
Avoid contacting the player with water or
chemicals.
Damage to the internal parts of the player
may occur. If your player gets wet, dry the
outside with a soft cloth as soon as possible.
Avoid running with hanging the player in
your neck.
Damage to your player may result or injury
from improper use.
Keep the player away from strong magnets
or excessive violation or dropping any
material.
Damage to your player may result from
improper use.
Getting started
FeaturesofiFP-900
1-4
Getting started
1-3
Multi-Codec Player : Supports MP3, WMA, OGG and ASF formats.
Firmware Upgrade
Provides the latest updated features via firmware upgrade.
260,000 color graphic LTPS LCD supporting Multiple Languages(40 languages)
iFP-900 Series comes with 260,000 color graphic LTPS (Low Temperature Poly Silicon) LCD
which can support multiple languages.
FM Function
You can easily listen to FM stations and set your favorite stations by using Auto Preset and
Frequency Memory functions.
6 Preset EQ : Normal, Rock, Jazz, Classic, U Bass, Metal
Xtreme EQ and Xtreme 3D
Customize your own EQ with Xtreme EQ and enhance bass and surround sound with Xtreme
3D.
GUI (Graphic User Interface) Menu System
Easy Navigation
The simple navigation makes it easy to find any song.
Supports 8 levels of subfolders, 500 folders total and up to 1500 files at one time.
Create your own playlists.
Direct MP3 Encoding
11.025KHz ~44.1KHz, 8Kbps ~ 320Kbps
Record FM Radio, Voice, or line-in from another device
Voice record level is automatically controlled by AGC function.
Convenient neck strap.
Built-in Rechargeable battery that charges directly from the USB port as well as AC Adapter.
Supports USB 2.0 (Maximum transferring speed : 480MBit/Sec.)
AboutPowerSupply
ChargingfromthePC
Connect the player to the PC with USB cable.
The player will charge automatically when the player is connected to the PC.
Use only the AC Power Adapter supplied with the player for safety.
Connect the AC adapter to the USB port on the player first and then into AC outlet.
(AC adapter of this player is for 100~240V, 50~60Hz.)
ChargingwithACAdapter
Charging time
Approx. 4 hours
(At full discharge, Stop mode)
Note
Charging is also doing when the
player turns off.
Charging indicator is disappeared
when charging is done.
Note
Getting started
AboutPowerSupply
ManagingtheRechargeableBattery
1-6
Getting started
1-5
Charge and store the battery at room temperature.
It may not charge properly in hot or cold temperature environments.
Do to attempt to disassemble the battery.
Do not expose the battery to open flame.
These activities may cause the battery to explode resulting in serious injury.
Do not contact the connectors of the battery to metal objects, or an
electrical short may occur.
When do not use the player for a long time, store the player with full
charged condition.
Use the player after full charge.
The rechargeable battery is expendables and life of battery shorten
with the lapse of time.
Keep the player and battery away from children or animal.
Biting the player or battery may cause exposure, electric shock or exposure
to electrical fields.
Note
Locating the controls
Locatingthecontrols
Contents
2
Front View
Rear View / Side View
LCD screen
2-1
2-2
2-3
Getting started
1-7
Locating the controls
Locatingthecontrols
RearView/SideView
2-2
Locatingthecontrols
Locating the controls
FrontView
2-1
USB Connection Port Hold
LINE IN/OPTICAL IN
Power ON/OFF
(Play/Stop)
STEREO A-B (Interval repeat)
EQ/MEMORY
MODE/REC
Xtreme 3D sound
Earphones
MIC
RESET
Earphones
USB Connection Port
(Previous / Fast Reverse)
(Next / Fast forward)
Volume +
LCD Screen
NAVI/MENU
Hold Charging indicator
Volume -
Mode/REC
Power ON/OFF
(Play/Stop)
STEREO A-B (Interval repeat)
EQ/MEMORY
Xtreme 3D sound
MIC
LINE IN/OPTICAL IN
PC software installation
PCsoftware installation
Contents
3
Note
Locatingthecontrols
Locating the controls
LCDScreen
2-3
File number
Bit rate
Playing time
Playback mode
Battery indicator
Volume
Folder name
Sampling rate
Program/file icon
File format
Artist/title name
Hold
Equalizer
Visualization
Clock
Operation Status
Current bar
Folder icon
ASF : ASF
IRM : IRM
MP3 : MP3
OGG : OGG
WMA : WMA
According to file type displayed as follows :
IRM (iRiver Rights Management) : iRiver Rights Management is a digital music
format.
PC software installation
Attach the player
3-1
3-4
This section covers the installation for Windows operating systems only.
For installation instructions for Mac OS, please see the Software Instruction
First, install iRiver Music Manager program BEFORE ATTACHING YOUR
PLAYER TO YOUR PC.
Note
PC software installation
PCsoftwareinstallation
Softwareinstallation
3-2
PCsoftwareinstallation
PC software installation
Softwareinstallation
3-1
Click “Next” to Install iRiver Music Manager.
Insert the Installation CD into the CD-ROM
drive. Installation start automatically.
Select the folder to Install. Click “OK”.
2
2
1
1
3
34
4
Click “Next” after selecting the language to
install.
Insert the Installation CD into the CD-ROM drive.
The following screen appears after inserting the CD.
If the installation doesn't automatically begin,
execute the "setup.exe" file in the installation CD.
The installation program will begin.
The installation CD contains the following
contents :
- Device Driver
- iRiver Music Manager
- Manager Program for Mac
Please be sure your login has Administrator privileges if using Windows 2000 or Windows XP.
The player can store MP3 files or files of any type.
You can upload files, other than music (MP3, WMA, OGG, ASF), to the PC using the iRiver
Music Manager Program.
Download latest versions of drivers and iRiver Music Manager at www.iRiver.com
System Requirements (Windows)
Pentium 133MHz or faster
USB port
Window 98SE / ME / 2000 / XP
CD-ROM drive
10MB free hard disk space
Note
Please note that the installation screens may differ slightly from those appearing
here, as software may be of a more recent version. If your screens differ, please
visit www.iRiver.com/software for an updated user guide
PC software installation
Attachtheplayer
ConnectingtothePC
3-4
PCsoftwareinstallation
PC software installation
Softwareinstallation
3-3
Installation is in progressing.
Click “Finish” after the installation is completed.
Click “Next” after confirming the
installation folder. Click “Install” to begin the installation.
5
56
6
7
7
Connect the USB cable (provided) to the USB port of your computer.
Lift the protective cover over the USB port
and connect the USB cable to the player. “USB CONNECTED” will appear on the
LCD screen of the player.
1
1
2
23
3
Type “A”
Type “B”
USBportonthePC
USB port on the player
USB cable
Type “A”
Type “B”
Connect the USB cable to the PC after playback stops to avoid errors.
Note
PC software installation
Attachtheplayer
Installationof“NewHardware”
3-6
Attachtheplayer
PC software installation
Installationof“NewHardware”
3-5
Select “Install the software automatically
(Recommended)” and click “Next”. If a "Hardware Installation" warning
message appears, click "Continue
Anyway". (Windows XP)
The iRiver software driver will not cause
any damage to your computer.
1
1
3
34
4
After installing iRiver Music Manager from
the CD and connecting the player to your
PC, "Found New Hardware" screen is
displayed. (Windows XP)
2
2
The computer will automatically search to
find your new hardware.
Information screen is displayed on the PC. New hardware is installed successfully and
ready to use.
5
5
7
7
The installation will continue. Click “Finish”
Completed the installation of “New
hardware”.
6
6
Windows 98SE, Windows ME, Windows 2000 O.S do not need any other device
driver installation.
Install New Hardware after installing iRiver Music Manager program.
Note
Basic operation
Basicoperation
Contents
4
Basic Operation
Listening to Music
Listening to the FM radio
Recording
4-1
4-7
4-8
4-13
Attachtheplayer
PC software installation
SafelyRemovingtheplayerfromthePC
3-7
Click the “OK” after confirming the
hardware to remove. Click the “Close” after confirming the
Safely Remove Hardware message.
(In case of Windows XP)
1
1
3
34
4
Select the “Safely Remove hardware”
after clicking the “Safe To Remove
Hardware” by using the right button of
mouse.
2
2
Click the “Stop” after selecting the device
to remove.
Remove the player from the PC after safe remove to avoid errors.
Note
Basic operation
Basicoperation
4-2
Basicoperation
Basic operation
Turningontheplayer
4-1
Put the HOLD switch to “OFF”.
Connect the earphones as shown below.
Press the PLAY/STOP button to turn on the player. The “My Image” appears on the LCD.
Press it again to play.
Click
Press and hold the PLAY/STOP button to turn the player off.
Click
Long Click
Push
Turningofftheplayer
To increase volume
To decrease volume
Push the NAVI/MENU button to the VOL + direction to increase volume.
Push the NAVI/MENU button to the VOL – direction to decrease volume.
Adjustingthevolume
Changingfunctions
Press and hold MODE button to appears current function on the LCD screen.
Push the NAVI/MENU button toward or to select the desired function, then click the
NAVI/MENU button to enter that mode.
Click
Push
Push
Long Click
Basic operation
Basicoperation
4-4
Basicoperation
Basic operation
Listeningtomusic
4-3
1234
5
6
789
1. Displays the operating status of the player.
2. To skip to previous file, folder, FM station or value.
3. To increase volume.
4. To skip forward to the next file, folder, FM station or value.
5. To select NAVI/MENU function.
6. To decrease volume.
7. To turn on/off, to play or stop playback or to select FM mode
8. To select EQ mode, A-B repeat, or automatically store FM stations.
EQ:NORMAL ROCK JAZZ CLASSIC U BASS METAL Xtrm EQ Xtrm 3D
9. To select function, playback mode,record/stop recording.
Long Click
Navigation Menu
Press the NAVI/MENU button and find the desired music file by pushing the NAVI/MENU button
to VOL + or VOL – direction. To play the files, press the NAVI/MENU button, push the
NAVI/MENU button to the direction or the PLAY/STOP button. To move to the upper folder,
the NAVI/MENU button to the direction. If there is no upper folder, NAVIGATION stops.
Navigation
Up/Down
To upper folder
While an audio file is playing or the player is in stop mode, press MODE/REC to activate
selected modes, such as Repeat or Shuffle.
Click
Repeat :
Shuffle :
Intro :
Changingtheplaybackmode
Select the folder to delete in stop mode. Then Click the “MODE” button.
“FILE(or FOLDER) DELETE ARE YOU SURE?” is displayed on the screen. Select “YES” by
using or (VOL + or VOL -) to delete. Then press the NAVI/MENU button.
Delete
Delete
Click
Play
Click
Push

Navigation menu
