User Manual Part III
3. Enter a name for the custom
EQ settings and select [Save].
Using the Device
47
User Guide
Equalizer Setup
1. Press and hold [ ] on the
notification bar, or turn on
[MENU - Settings - Equalizer].
2. Press [Pro EQ] and select [ + ].
Equalizer
Setup
4. Adjust the frequencies up and
down according to preference.
5. The number values at the lower-
left corner of the screen can be
adjusted for fine-tuning.
Using the Device
48
User Guide
6. Press the [Advanced] tab on the
top of the screen to view the PEQ
setting screen. Adjust Freq/Gain/Q.
Using the Device
49
User Guide
Deleting a Custom Equalizer Setting
1. Press [Pro EQ] at the upper-left
corner of the screen.
2. Press [ ] next to the EQ name
to delete the selected EQ setting.
Renaming an Equalizer Setting
1. Press [Pro EQ] at the upper-left
corner of the screen.
2. Press [ ] next to the EQ setting
name you wish to change and enter
a new name for the selected EQ.
3. Press [Rename] to save the
changes.
Miscellaneous
50
User Guide
Safety
Pre-
cautions
Device
Do not use excessive force when inserting a plug into the
earphones, balanced, or USB port.
Do not insert any metal objects (coins, hairpins, etc.) or
flammable items into the device.
Do not place heavy objects on the device.
If the device gets wet (rain, water, chemicals, medicine,
cosmetics, sweat, moisture, etc.), allow the device to dry
thoroughly before powering on. Contact the nearest iriver
Customer Support Center for service. (Damage due to liquid
exposure will be repaired for an additional fee even if the
device is under warranty. Damage may not be repairable.)
Avoid exposing the device to direct sunlight or extreme
temperatures (-10℃ - +50℃; 14℉~ 122℉) such as the
inside of a car during the summer.
Do not store or use in hot and humid places such as saunas.
Avoid use in places with excess moisture, dust, or smoke.
Do not use for extended periods on blankets, electric
blankets, or carpet.
Do not place near a fire or in a microwave.
Never attempt to disassemble, repair, or alter the product.
Do not store for extended periods of time in a confined
space with the power on.
Do not place the device near magnetic objects (magnets,
televisions, monitors, speakers, etc.).
Never use chemicals or cleaning products on the device
since they can damage the surface coating and finish.
Avoid dropping or subjecting the device to a strong impact
(excessive vibration, etc.).
Do not press multiple buttons simultaneously.
Do not disconnect the USB Type-C cable during data transfer.
When connecting the USB Type C cable, use the USB port
on the back of the PC. Connecting to a defective or damaged
USB port may damage the device.
Miscellaneous
51
User Guide
Other
Do not use earphones/headphones or operate the device
while operating any type of vehicle. It is not only dangerous,
but may be against the law in certain regions.
Do not use the product during physical activities (driving,
walking, hiking, etc.).
Be aware of your environment to avoid the risk of accidents.
Pay attention to your surroundings when using the device
while walking or moving.
Avoid using the device during thunderstorms to reduce
the possibility of electric shock.
If there is a ringing in your ears during or immediately
after use, lower the volume or discontinue use of the
device and seek medical advice.
Do not listen to music at excessive volumes for extended periods.
Do not use earphones/headphones at excessive volumes.
Be careful not to get the earphones/headphones caught
in other objects.
Do not sleep with earphones in your ears or leave them in
for extended periods.
Connecting to a defective or damaged USB port may
damage the device.
Displaying one static image for an extended period of time
may cause screen burn-in.
Use of poor quality protective films or adhesive stickers
on the screen may cause damage to the touchscreen.
Do not insert any foreign objects into the headphone port.
Playing and charging the device may generate heat, so
handle carefully.
Product’s corners may be sharp, so handle carefully.
Miscellaneous
52
User Guide
Trouble-
shooting
Solutions to common problems
1. The device won't turn on.
The battery may need to be recharged. Charge the device
for at least one hour and try again.
Reset the device. (See Page 5)
2. The device will not charge when connected to a computer
via USB cable.
Connect to the computer using a USB Type-C cable.
Connecting to the computer with a micro USB cable will
not charge the product.
Connect to a charging adapter using a USB Type-C cable.
3. The computer won't recognize the device or an error
message appears when connected.
Use a USB port on the back of the computer.
Check that the USB Type-C cable is properly connected.
For Windows XP, verify that Service Pack 2 (or higher)
and Windows Media Player 10 (or higher) are installed.
Check if the device connects properly on a different computer.
4. The screen turns off repeatedly.
The screen turns off automatically after a set time to
reduce battery consumption. Change the time setting in
[Menu- Settings - Power Saving - Screen Timeout].
5. The screen does not display images properly.
Check the screen for debris.
6. There is no sound, or there is static/interference.
Check that the volume setting is above [0].
Check that the earphones are plugged in properly, and
make sure nothing is obstructing the port connection.
Verify that the music file is not corrupt.
Verify that the audio settings have been set properly.
(Balanced out, line out, etc.)
Miscellaneous
53
User Guide
7. A file does not play, or the product becomes unstable
when a certain file is played.
File may be damaged or corrupt if the following occurs:
Playback stops or freezes.
Device may act erratically or freeze.
File may sound different on another device.
There may be a difference in the performance of
playback or other functions.
There may be differences in the file specs.
Converting the file to a different format or use of a different
file is recommended.
Copyright iriver Limited retains the rights to patents, trademarks,
copyrights, and other intellectual property rights related to
this manual. No contents of this user manual may be
duplicated or reproduced in any format or by any means
without the prior approval of iriver.
Using or reproducing, in whole or part, the contents of this
document is subject to penalties. Software, audio, video,
and any other copyrighted contents are protected in
accordance with relevant copyright laws.
The user accepts all legal responsibility for the unauthorized
reproduction or distribution of the copyrighted contents from
this product.
Companies, organizations, products, people, and events
used in the examples are not based on actual data. iriver has
no intention to be associated with any company, institution,
product, person, or incident through this instruction manual,
and no such inference should be made. It is the responsibility
of the user to comply with applicable copyright laws.
©1999~2017 iriver Limited. All rights reserved.
The PPR11 was designed and audio-tuned under the
advisement of MSD.
Miscellaneous
54
User Guide
Certifica-
tions
KC / FCC / CE / TELEC
Class B Device (Communication equipment for residential
use): This is a Class B Device and is registered for EMC
requirements for residential use. This device can be used in
residential areas and all other areas.
FCCID: QDMPPR11
This device complies with Part 15 of the FCC Rules, Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
FCC Caution Any changes or modifications not expressly
approved by the party responsible for compliance could void
the user's authority to operate this equipment.
(b) For a Class B digital device or peripheral, the instructions furnished
the user shall include the following or similar statement, placed in a
prominent location in the text of the manual: NOTE: This equipment
has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help
Body-Worn operation
This device was tested for typical body-worn operations with the back
of the portable music player kept 5mm. from the body. To maintain
compliance requirements, use only belt-clips, holsters or similar
accessories that maintain a 5mm separation distance between the
user’s Body and the back of the Portable music player, including the
antenna. The use of belt-clips, holsters and similar accessories should
not contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply
with CE RF exposure requirements, and should be avoided.
Body-worn accessory exposure conditions “Specific information must
be included in the operating manuals to enable users to select
body-worn accessories that meet the minimum test separation
distance requirements. Users must be fully informed of
the operating requirements and restrictions, to the extent that the
typical user can easily understand the information, to acquire the
required body-worn accessories to maintain compliance. Instructions
on how to place and orient a device in body-worn accessories, in
accordance with the test results, should also be included in the user
instructions. All supported bodyworn accessory operating
configurations must be clearly disclosed to users through conspicuous
instructions in the user guide and user manual to ensure unsupported
operations are avoided. All body-worn accessories containing metallic
components must be tested for compliance and clearly identified in the
operating manual. The instruction must inform users to avoid using
other body-worn accessories containing metallic components to
ensure RF exposure compliance.”
Miscellaneous
55
User Guide
Registered
Trademarks
Windows 2000, Windows XP, Windows 7, Windows 8, Windows
10, and Windows Media Player are registered trademarks of
Microsoft corp.
Miscellaneous
56
User Guide
Disclai-
mers
The manufacturer, importer, and distributor shall not be liable
for damages including accidental and personal injury due to
the improper use or operation of this product. The information
in this user manual was written based on current product
specifications. The manufacturer, iriver Limited, is adding
new complementary features and will continue to apply new
technologies in the future. All specifications may be changed
without prior notice. There is no warranty against data loss
due to the use of this product.
The device must be used a minimum of 5mm away from the body in
normal use conditions.
Miscellaneous
57
User Guide
Specifi-
cations PPR11
Aluminum
5.0inch HD 720 x 1280 touch screen
WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF,
DFF, DSF
PCM : 8kHz ~ 384kHz (8/16/24/32bits per Sample)
DSD Native: DSD64(1bit 2.8MHz), Stereo/
DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo
Unbalance 2.0Vrms / Balance 4.1Vrms (Condition No Load)
ESS9038PRO x1 (8-channel DAC)
Support up to 32bit / 384kHz Bit to Bit playback
USB Type-C input (for charging & PC & MAC)
PHONES (3.5mm) / Optical Out (3.5mm) /
Balanced Out (2.5mm, only 4-pole supported)
802.11 b/g/n (2.4GHz)
V4.1 (A2DP, AVRCP, aptX™ HD)
2.98”(75.85mm)[W] x 5.22”(132.7mm)[H] x 0.60”(15.3mm)[D]
8.5oz (241g)
Firmware upgrade supported(OTA)
-10℃ ~ + 50℃ (14℉~ 122℉)
±0.09dB (Condition : 20Hz~20kHz) Unbalance /
±0.08dB (Condition : 20Hz~20kHz) Balance,
122dB @ 1kHz, Unbalance / 123dB @ 1kHz, Balance
137dB @ 1kHz, Unbalance / 144dB @ 1kHz, Balance
128GB[NAND]
microSD(Max. 256GB) x 1
3,700mAh 3.8V Li-Polymer Battery
Windows XP, Windows 7,8,10(32/64bit)
MAC OS X 10.7.
General Specifications
Model
Body Material
Display
Supported
Audio Formats
Sample rate
Output Level
DAC
Decoding
Input
Outputs
Wi-Fi
Bluetooth
Dimensions
Weight
Feature Enhancements
Operating Temperature
Audio Specifications
Frequency Response
S/N
Crosstalk
Storage Capacity
Built-in Memory
External Memory
Battery
Capacity
Supported OS
Supported OS
