Datalogic S r l JTAWB Multi-purpose device with barcode reader User Manual 822002540

Datalogic S.r.l. Multi-purpose device with barcode reader 822002540

User manual

Datalogic S.r.l.Via San Vitalino 1340012 Calderara di Reno (BO) ItalyTel. +39 051 3147011Fax +39 051 31472052017 Datalogic S.p.A. and/or its affiliates  All rights reserved.  Without limiting the rights under copyright, no part of this documen-tation may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means, or for any purpose, without the express written permission of Datalogic S.p.A. and/or its affiliates. Owners of Datalogic products are hereby granted a non-exclusive, revocable license to reproduce and transmit this documentation for the pur-chaser's own internal business purposes. Purchaser shall not remove or alter any propri-etary notices, including copyright notices, contained in this documentation and shall ensure that all notices appear on any reproductions of the documentation. Should future revisions of this manual be published, you can acquire printed versions by contacting your Datalogic representative. Electronic versions may either be downloadable from the Datalogic website (www.datalogic.com) or provided on appropriate media. If you visit our website and would like to make comments or suggestions about this or other Datalogic publications, please let us know via the "Contact Datalogic" page.DisclaimerDatalogic has taken reasonable measures to provide information in this manual that is complete and accurate, however, Datalogic reserves the right to change any specification at any time without prior notice.Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. The Joya logo is a trademark of Datalogic S.p.A. and/or its affiliates, registered in the U.S. and the E.U. All other trademarks and brands are property of their respective owners.PatentsSee www.patents.datalogic.com for patent list.Reference DocumentationFor further information regarding JOYA TOUCH A6 refer to the SDK Help on-line and to theJOYA TOUCH A6 User’s Manual, downloadable from our website www.datalogic.com.Support Through the WebsiteDatalogic provides several services as well as technical support through its website. Log on to www.datalogic.com and click on the SUPPORT > STORE AUTOMATION categorylink. From this page you can select your product model from the dropdown list which givesyou access to:Downloads including Data Sheets, Manuals, Software & Utilities, and Drawings;Repair Program for On-Line Return Material Authorizations (RMAs) plus Repair Centercontact information;Service Program containing details about Maintenance Agreements;Technical Support through email or phone.Warranty Terms and ConditionsThe warranty period is 1 year for the device and 90 days for consumables (e.g. battery,power supply, cable etc.) from date of purchase at our company. Multi-Purpose Device for Retail Quick Start Guide 822002540 (Rev. A) June 2017Out of the BoxThe JOYA TOUCH A6 package contains: • JOYA TOUCH A6 (device)• Rechargeable battery•Safety RecommendationsRemove all the components from their packaging; check their integrityand compare them with all the packing documents.General ViewFront ViewBack ViewCAUTIONKeep the original packaging for use when sending products tothe technical assistance center. Damage caused by improperpackaging is not covered under the warranty.Touch Panel DisplayHome KeyLaser Safety LabelProduct LabelCold Boot ButtonTop ViewSide ViewData Capture WindowPistol Grip ModelsHandheld ModelsMicro USB PortScan Trigger©2017 Datalogic S.p.A. and/or its affili-ates. All rights reserved. Datalogic and the Datalogic logo are registered trade-marks of Datalogic S.p.A. in many coun-tries, including the U.S. and the E.U.www.datalogic.com
Battery InstallationTo install the battery pack, follow the steps below:1.2.3.4.NOTERequired torque of the screws is 35 cNm.Handheld Models Pistol Grip ModelsHandheld Models Pistol Grip ModelsHandheld Models Pistol Grip ModelsHandheld Models Pistol Grip ModelsCharging InstructionsThe battery pack is not initially fully charged. After installing the battery, charge it with the 3-slotcradle. The device needs to be inserted head down into the cradle.There are two options to connect the cradle to the power supply: fast charge and standard charge.Fast ChargeThe fast charge connection allows to power one cradle with one power supply. Plug the power supply cable into the power connector on the back of the cradle, then plug the powersupply into the AC/DC plug using a Datalogic power cable. Please see below an example of how toinsert the power supply cable through the wall mounting metal bracket:Standard ChargeThe standard charge connection allows to power two cradles with one power supply. To connect a second cradle use the JOYA TOUCH Cradle Power Jumper, available as optional accessory(P/N 91ACC0049).1. Connect the first cradle to the second cradle using the power jumper.2. Connect the power supply to the first cradle.3. Plug the power supply into the AC/DC plug using a Datalogic power cable.NOTECharge the battery for a minimum of 7 hours in standard charge and 3 hours in fast charge.NOTEFor further information on the JOYA TOUCH 3-Slot Cradle, refer to the JOYA TOUCH 3-SlotCradle Quick Start Guide, included in the cradle’s box, and to the JOYA TOUCH 3-Slot CradleInstallation Guide, downloadable from our website www.datalogic.com.High Visibility High DensityScanning and ImagingImager Data CaptureRelative Size and Location of Aiming System PatternLINEAR BARCODE 2D MATRIX SYMBOL
