Users Manual
MiniMax II Manual
Preliminary version
Start read
button
Display 32
characters
(2x16)
FDX-B
Transponde
How to operate the MiniMax II :
MiniMax II A00
read
y
Push the start read button once
Software version
The display indicates :
Point the top of the MiniMax II close to the transponder
Push the start read button once
*reading*
The display indicates :
A
lpha country code
according to
ISO3166,
ISO11784/5
If a Transponder is present
The display indicates : Country : CHE
276098101420465
Id code number
according to
ISO11784/5
If a Transponder is not read
The display indicates :
Tag not found
ready
If the MiniMax is left at power on and not used for more than 90 sec. It will beep and indicate a battery
sign on the display.
When the battery voltage is less than 7 Volts the reader after 3 seconds turn off.
If the display indicates:
Battery low
Replace the battery with a 9 Volts block battery Alkaline or Lithium.
Another type of battery will not function properly.
INFORMATION TO USER
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures.
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
