Contents
Users Manual-Website contents
Professional installation warning
This device is point-to-multi-point device. The general user should not attempt to install or change settings, it
needs to be installed by a qualified personal who has RF exposure and related rule knowledge or technology.
The device for operation in the band 5150–5250 MHz is only for indoor use, band 5725~5850 MHz for outdoor
& indoor use.
The installation position and output power does not exceed the limit set forth in US Rule CFR 47 part 15
section 15.247 & 15.407. If violate the rule, could lead to serious federal penalty.
Use PIFA type antenna specifications. One antenna model name is 6525A0042300 with peak gain 4.1dBi and
2.9 dBi for 2.4GHz; 4.2 dBi and 4.1dBi for 5725-5850MHz. Other type antenna model name is 6525A0041300
with peak gain 4.4dBi and 3.6dBi for 5150-5250MHz. Only use manufacturer approved antenna type of
antennas.
Federal Communication Commission
Interference Statement
Any changes or modifications not expressly approved by the party responsible for compliance could void your
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
RF exposure statements
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the
radiator and your body or nearby persons.
Applicant: Datto, Inc.
Address: 101 Merritt 7 Norwalk, CT 06851, United States
TEL: 2038227722
RED Compliance Statement
EU Countries Intended for Use
The ETSI version of this device is intended for home and office(5150-5350MHz) use in Austria, Belgium,
Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain,
Sweden, and the United Kingdom.
Canadian Compliance Statement
This product meets the applicable Innovation, Science and Economic Development Canada technical
specifications.
Ce produit repond aux specifications techniques applicables a l'innovation, Science et Developpement
economique Canada.
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two
conditions:
1) This device may not cause interference, and
2) This device must accept any interference, including interference that may cause undesired operation
of the device.
Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisee aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est
susceptible d’en compromettre le fonctionnement.
Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Declaration d’exposition aux radiations:
Cet equipement est conforme aux limites d’exposition aux rayonnements IC etablies pour un environnement
non controle. Cet equipement doit etre installe et utilise avec un minimum de 20 cm de distance entre la
source de rayonnement et votre corps.
The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for
harmful interference to co-channel mobile satellite systems.
Le fonctionnement sur la bande 5150–5250 MHz est limite a une utilisation interieure uniquement.
Tune-up Range:
Antenna
Mode
Frequency/Band
Rate/RB/Modulation
Tune-up tolerance (dBm)
Max
WLAN_MIMO_BF
OFF
IEEE 802.11b
2.4GHz
1M
27.3
IEEE 802.11g
2412
6M
22
2437
27
2462
22.3
IEEE 802.11n 2.4GHz
20MHz (256QAM)
2412
13M
22
2437
27
2462
21.5
IEEE 802.11n 2.4GHz
40MHz (256QAM)
2422
27M
20
2437
22.6
2452
19.9
IEEE 802.11a
5180-5240
6M
23.3
5745-5825
23
IEEE 802.11ac 5GHz
20MHz
5180-5240
13M
23.5
5745-5825
22.8
IEEE 802.11ac 5GHz
40MHz
5190-5230
27M
23.3
5755-5795
23.3
IEEE 802.11ac 5GHz
80MHz
5210
58.6M
20.1
5775
22.9
WLAN_MIMO_BF
ON
IEEE 802.11b
2.4GHz
1M
23.9
IEEE 802.11g
2412
6M
18.8
2437
23.7
2462
19.1
IEEE 802.11n 2.4GHz
20MHz (256QAM)
2412
13M
18.6
2437
23.6
2462
18.1
IEEE 802.11n 2.4GHz
40MHz (256QAM)
2422
27M
16.9
2437
19.2
2452
16.8
IEEE 802.11a
5180-5240
6M
20.3
5745-5825
19.8
IEEE 802.11ac 5GHz
20MHz
5180-5240
13M
20.3
5745-5825
19.7
IEEE 802.11ac 5GHz
40MHz
5190-5230
27M
19.8
5755-5795
19.8
IEEE 802.11ac 5GHz
80MHz
5210
58.6M
17
5775
19.4
