R1 User Manual

Pleasereadbelowcontentcarefullybeforeusing

ThanksforpurchasingR1,mayyouwillenjoyit.Pleasereadthe“SafetyInstructions”

beforeusingtheproductforyoursafetyandcorrectuse.

Caution

Donotimmerseinwatertoavoiddamagingtheproductaswellasshorteningitslifetime.

DONOTdroporapplyshocktotheproduct.Suchactmaycauseirreparabledamagetothe

product.

DONOTexposetheproducttoopenflameorunderthedirectsunlightforaprolongedperiodof

thetime.Suchenvironmentmaycausemalfunctionorfire.



Pleasedonotchangethesettingortalkonthecellphonewhiledriving.Itmaycauseanaccident.

Pleasenote:innoeventourproductshallbeliableforanyspecial,indirect,punitive,incidental,

exemplaryorconsequentialdamages,oranydamageswhatsoeverresultingfromtheusageof

thisproduct.

Conversationonthecellphonewhendrivingisextremelydangerous.Pleasegooutoftheroad

fordoingthetelephonecall.

Ifanythingunusualsuchassmoke,heatorbadsmellisdetected,pleasedisconnectimmediately

thepowerandstoptheusage.Continuingtheusemaycauseelectricshockorfire.



DONOTlick,biteorputtheproductintothemouth.Suchactmayresultinserious

injuries/accidents.Takeutmostcautionaroundchildren.

DONOTchangethemicwhenitgetswet.Withwaterexposure,itmaycausefire,electrification

orfailure.

Temperaturerangeofuse:‐15℃‐50℃

Pleaseuseonlyqualifiedaccessorieswhichhavebeenauthenticatedbyus,inordertoguarantee

theproductcorrectfunctioning.



Noteonbatterycharge

Forbatterycharge,useUSBterminalorUSBadaptoratnormaltemperature.

UseregulationUSBterminalonly.Otherwiseitmaycausesmokegenerationorfire.

Whenchargingthebattery,ifanystrangeodororhighheatshouldbrokenout,please

immediatelypulltheplugfromthebody.Itmaycausesmokegenerationorfire.

Donotleavetheproductinastateofchargelongafterthechargingiscompleted.Suchcondition

maycausesmoking/ignition.

Chargebatteryatleastonceeverysixmonthseveniftheproductisnotuseforanextended

periodoftime.Overdischargemayrequirebatteryreplacement.



Productdescription:

Function:

‐PTTfunction



Operation

Poweron



Inpoweroffstate,pressPTTbuttonandholditforabout3seconds,releasethebutton,blue

indicatorwillflashslowlytoindicatepoweronsuccessfully.

Poweroff



Therearetwomethodsforpoweroffoperation.

1. Theremotecontrollerwillautomaticallypoweroffaftermobilephone5minsBluetooth

disconnectlater.

2. UsetheUSBchargingcableconnectwithpower,chargingtheR1powerwilloff.

Pairingwithmobilephone

①PlacetheR1andthemobilephoneinavisibleareawithin1meterrange.

②MakesuretheBluetoothremotecontrollerisinpoweroffstate.

③PressandholdPTTButtonforabout8seconds,whentheBlueLEDandtheRedLEDflashing

alternately,releasethebuttonthentheR1isinpairingstate.

④Followtheusermanualofyourmobilephone,turnontheBluetoothfunction,andsearching

thePTTR1devices

⑤Fromthefounddevicesinyourmobilephone,selectthedevicenamed“R1”andthentryto

pairwithit,whenitpromptstoenterpassword,enterpincode<0000>.Oncepairedsuccessful,

LEDIndicatorwillchangefromBlue/RedalternatelytoBlueflashing,tonotethattheBluetooth

remotecontrollerhasconnectedwithyourmobilephone.Nowyoucanusetheremote

controllertopushtotalkoransweryouphonecall.



Note:1.Passwordcodemaybenotnecessaryforsomemobilephones.

2.Thepairingwillberememberedafterthefirstpair,sowhenyousecondornexttime

usethedevice,donotneedtopairagain.

PushToTalkFunctionForPocApp

①AfterconnectedtoyourcellphonePoc(PttOverCellphone)app,justpushthePTTbuttonto

remotecontrolthePTTfunction.SomePocappmayneedsomesettingchangetoBluetooth

beforeuse.DetailspleaserefertotheuserguideofPocApp.



Note:PocmeansPTTOverCellPhone.



TechnicalSpecification:



About Led Indicatoer and Charging

Bluetooth remote control Specifications

Bluetooth Chip: BC4_08

Bluetooth Version: Bluetooth 2.1

Supported Bluetooth Profiles: SPP

Bluetooth RF Spec: Class 2

RF Power: 1.47 dBm

RF Sensitivity: -75db

RF Frequecy: 2.402GHZ-2.480GHZ

Operation Range With DellKing Dongle: 5 Meters

Battery Capacity:200mA

Charging Time:3 Hours

Working Time:60H

Stand by Time:80H

Appearance Colour: Black

Operating temperature: -15℃ ~50 ℃

Storage Temperature: -25℃ ~60℃

LEDindicatorflashmodeStateofindication

LEDindicatorflashesblueevery6sWorking/Standbymode

LEDindicatorflashesred/blue

alternatelyandquickly

Pairingmode

LEDindicatorflashesredtwice

every1min

Batterylow

LEDindicatorflashesredevery1sCharging

LEDindicatorkeepsred Chargingcompleted

PressPTTbuttonwithblue Connectwithphone,PTTfunctionnormal

PressPTTbuttonwithredConnectwithphone,PTTfunctionnormal,power

low

FAQ:

1,Cannotpoweron

Itmightlowbattery,pleasetryagainafterchargingfor3hours,thenpoweronagain.

2,Nosound

Pleasecheckifthespeakermichaveconnectedtothedeviceorthevolumetoolow?

3,Disconnectwithmobilephone,BtAdapter/dongle,orGPS

Makesureifitislowbattery,ifnot,thedistancebetweenthespeakermicandmobilephone

within10m?Orbetweenthemexistobstaclesthatabsorbfrequencysignalslikemetalsorwater?

4,Failtore‐connectorautomaticallyre‐connectwithmobilephone

FirstmakesureyourBluetoothfunctionininyourmobilephonehavebeenturnedon,then

removeallthepairedBluetoothdeviceinyoucellphone.Thenturnoffyourmobilephone,

restartmobilephoneandpairwithBluetoothspeaker‐micandsettheR1readas

“default/trust/test/permitautomaticallyconnection/alwaysvisible/allowtobefound”device,

andfurtherensurethatthephoneprompttoneisnotvibratingmode(becausethevibrating

impulsewavewouldinterferewithBluetoothfrequencysignalsometimes),thenrepairand

connectwithyourmobilephone.Forandroidsystem,pleasemakesureintheBluetoothdevice

optionlist,youhave“Phone”optionsselected.

5,Systemhalted

UseUSBcabletochargetheremotecontrolleroncethentheremotecontrollerwillresetitself..

6,AbnormalinstructionofChargingindicator

1）Whentheremotecontrollerhaven’tbeenusedforlongtimeoroverused,itneedtobe

pre‐chargeforanhour,thenpulloutandinthecharger,itwillindicatenormalcharging.Please

don’tcountthepre‐chargingtimeintonormalchargingtime.

2）Tryanotherchargingcableorcharger.

7,Cracklesound

PutQ0R1nearer(lessthan10meterrange)toyourcellphone.PutQ0andcellphoneinaleast

obstacleblockingrange.



8,PleasesendbackyourR1settoourafter‐salesservicedepartmentforhelpifabove1to7

suggestionsfailtosolveyourproblem.
