Finalized Manual
D
elta Networks, Inc.
WLAN PCMCIA Card
L
M-WP200
M
A401 rev. B
D
elta Networks, Inc.
DNI
252, Shang Ying Road, Kuei Shan
Taoyuan Shien, Taiwan, R.O.C.
Tel: +886 2 8797 2088
Fax: +886 2 2659 1462
D
elta Networks, Inc.
Installation Guide for the RF Module
This module has been authorized under FCC ID: PD5LMWP200A under mobile module
approval category. The integrator of this module has to be aware that this module can
only be used in mobile host equipment such as Access Point or Router.
The host equipment should provide an internal mini-pci interface for the main board of
this module. Also the housing of the host equipment should provide an antenna socket
for the installation of the filed antenna.
The folded part of these antennas has to be fixed with the housing of the host equipment,
which makes the end users impossible to remove the antenna unless destroy the housing.
The photo of this antenna is shown below, also the folded part of each antenna type has
been indicated.
Folded Part
D
elta Networks, Inc.
Warning Statement
Since this module is authorized under module approval category. So, the end product
integrator should be aware that the antenna of the end product has to be kept at least
20cm away from the human being under normal use condition.
Also the end product integrator has to label the end product to insure that the end user is
aware of a wireless module has been installed. The statement could be “ This product
contains an FCC certified wireless module with FCC ID: PD5LMWP200A” or similar
wording.
