Connecting to the power supply
(1) Connect the output plug of the AC adapter into the power inlet connector of the CU/CH.
(2) Connect the AC adapter to a wall socket.
Note: The above diagram is that of the CH-851.
Power inlet connector
Plug the AC adapter into this connector.
Without using the AC adapter, the CU-821
can work if the power (5V, 500 mA) is
su
pp
lied via the USB.
CU-801, CU-811, CU-821, CH-851
A
C adapter
Handy Terminal "BHT-800" will be supplied with this AC adaptor.
As you can see in the drawing below, this AC adaptor has Standard Ferrite Core.
