Digi X2EWIFI ConnectPort X2e Wi-Fi User Manual 90001281 A

Digi International Inc ConnectPort X2e Wi-Fi 90001281 A

Contents

Quick Start Guide

Quick Start Guide
ConnectPort X2e Wi-Fi
Smart Energy
Power Supply
Ethernet Cable
ConnectPort X2e Wi-Fi SE
1 Verify Contents
2 Write Down the Serial Number
®
Model: ConnectPort X2e Wi-Fi SE
Part Number: 50X2E-Z1C-002-01
Serial Number: 00409D50E9BB
Model: ConnectPort X2e Wi-Fi SE
Part Number: 50X2E-Z1C-002-01
Serial Number: 00409D 50E9BB
3 Connect Hardware
Power ZigBee Network
(WAN)
Button
aConnect the power supply
Write down the ConnectPort X2e Wi-Fi SE Serial Number:
00409D:
NOTE: The serial number
is also the Ethernet
MAC address, which
can be used to identify
the device during the
installation process.
b
aConnect the power supply
Startup Sequence - After connecting the power
supply, the Power LED will be solid green, the ZigBee
LED will be blinking green, and the Network LED (WAN)
will be blinking orange.
NOTE: Once the Wi-Fi conguration is complete, the
Network (WAN) LED will change from blinking orange
to solid green.
a
4 Congure your Device Using the Wi-Fi Interface
a
c
Enable Access Point mode on your device by pressing
the button.
b
d
Congure the Wi-Fi interface of your laptop to connect to
the ConnectPort X2e gateway’s access point.
The name
(SSID) of the access point will be cpx2e-se-xxxxxxxxxx,
where xxxxxxxxxxxx is the serial number of the gateway.
cc Go to your web browser, and enter the URL of the gateway:
http://192.168.100.1
NOTE: If the ConnectPortX2e has already been congured
to connect to an access point, it will need to be set back to
factory defaults to use the following procedure. See the
troubleshooting section below to return the gateway back
to its initial state.
Navigate to Conguration > Wireless Wizard.
Follow the steps in the wizard to congure your device.
eOnce the conguration is complete, your device will connect
to your home access point and attempt to connect to
Smartlee. You can track its progress by observing the network
LED behavior. Once the connection to your access point and
gateway is connected to Smartlee, all the LED’s will be solid
green.
90001281_A
Network
Description
Status
No power
Solid green Device is powered
OFF
Description
Status
Radio disabled
Blinking green (slow) Searching for other ZigBee devices on the network
OFF
Blinking green (fast) Establishing a Smart Energy network
Solid green Connected to a Smart Energy network
Description
Status
Powered OFF
Blinking yellow (slow) Powered ON, no Wi-Fi link
OFF
Blinking yellow (fast) Wi-Fi link, no IP address
Solid yellow IP address assigned
Blinking green (slow) Attempting a connection to Smartlee
Blinking green (fast) Smartlee found, authenticating
Solid green Connected to Smartlee
© 2012 Digi International, Inc.
Digi, Digi International, Inc., ConnectPort, iDigi, and the Digi and iDigi logos are trademarks or registered trademarks of Digi International, Inc., in the United States and other countries worldwide. All other trademarks are the property of their respective owners.
Button - The button is intended for advanced conguration or as directed in the online setup. To restart Wi-Fi conguration, hold
the button down for 10 seconds to initiate a factory reset.
Need Help? Call 1-877-693-7849 or visit www.digi.com/support.
6 Troubleshooting
Power
ZigBee
5 Online Installation
Browse to
www.livesmartlee.com
and follow the step-by-step instructions to completion.
7 Regulatory Information
For ConnectPort X2e Wi-Fi regulatory information and certications, please refer to the document at the following URL:
http://ftp1.digi.com/support/documentation/x2e_wifi_reg.htm
