Users Manual
Address : #1414 Hyundaiventureville 713 Suseo-Dong, Kangnam-Ku, Seoul, Korea
Tel : 82-2-2040-6212~2 Fax :82-2-2040-6213
Digiana Co., Ltd
•Functional iPod shuffle accessory
•Car docking for the iPod shuffle.
•Car power charging for the iPod shuffle
•Transmit the audio from the iPod shuffle to the car
•Full frequency range (88.1MHz ~ 107.9MHz)
•Auto on/off
•4 Channel preset memory function
FM Transmitter AudiaX(iTube-101)
iTube-101
AudiaX
For iPod Shuffle
4 Channel Preset Memory
Luxurious, Compact and Functional Design
Blue Backlit LCD
MODEL
iTube-101
iTube-101
FM Transmitter Built in Dock & Charger
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
Operation is subject to the following two conditions; (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
Address : #1414 Hyundaiventureville 713 Suseo-Dong, Kangnam-Ku, Seoul, Korea
Tel : 82-2-2040-6212~2 Fax :82-2-2040-6213
Digiana Co., Ltd
Specification
General Specification
Preset4 ChannelsChannel Memory
12.5 * 1 * 2 Size (inch)
40dBStereo Separation
RF FM (F3E)Transfer Mode
250uV/MOutput power
10mOutput Range
-10 ~ 50 ℃Operating Temp
-20 ~ 70 ℃Storage Temp
20mA@12VFMT Operating
Power Consumption
5V, 500mAOut Power
10~24VPower Supply
68Weight (g)
100Hz~ 15KHzAudio input Range
100mV ~ 1.5VAudio Input Level
199Channel
88.1MHz ~ 107.9MhzFrequency
RemarkSpecificationIndex
RemarkSpecificationIndex
BlueLCD backlight
BlueDeco Light
Frequency, 4 Channel Preset MemoryLCD Display
iTube-101
Address : #1414 Hyundaiventureville 713 Suseo-Dong, Kangnam-Ku, Seoul, Korea
Tel : 82-2-2040-6212~2 Fax :82-2-2040-6213
Digiana Co., Ltd
Composition
Key Function
Main Body
USB Port
Cigarette Lighter Adapter
Frequency Button (UP)
►Short : 0.1MHz UP
►Long : 1 MHz UP
Frequency Button (DOWN)
►Short : 0.1MHz DOWN
►Long : 1MHz DOWN
Memory Button
►Short : Convert Memory Mode
►4 Channels preset Memory Display
(whenever push the short term, move to existing memory channels (A,B, C, D)
►Long : Current frequency memory
iTube-101
LCD Display
Memory Button
Frequency Button
(DOWN)
Frequency Button
(UP)
USB Port
connector
Cigarette Lighter
Connector
Address : #1414 Hyundaiventureville 713 Suseo-Dong, Kangnam-Ku, Seoul, Korea
Tel : 82-2-2040-6212~2 Fax :82-2-2040-6213
Digiana Co., Ltd
Function
* FM FULL BAND
(Multi Channel Support:199 Channel)
* 1 MHz/0.1MHz
(Precision Frequency Control)
* FULL STEREO SOUND
* Luxurious, Compact and Functional
Design
* Dock & Charger with FM transmitter
* Deco light
* Back light
* LCD DISPLAY
(Frequency,
4 Channel Preset memory)
iTube-101
Address : #1414 Hyundaiventureville 713 Suseo-Dong, Kangnam-Ku, Seoul, Korea
Tel : 82-2-2040-6212~2 Fax :82-2-2040-6213
Digiana Co., Ltd
User Manual
5. Control the music player from
iPod Shuffle
iTube-101
1. Plug the unit into the car cigarette lighter
2. Plug the iPod shuffle onto it
(The unit will automatically be
turned on)
3. Select an empty channel frequency
that public radio stations do not use
4. Set the same channel frequency by
pressing the upper(0.1/1MHZ) or the
lower(0.1/1MHZ) button of
Audiax(iTube-101)
