34 MIPS32® Architecture For Programmers Volume II, Revision 2.50

ADD

Format: ADD rd, rs, rt MIPS32

Purpose:

To add 32-bit integers. If an overﬂow occurs, then trap.

Description: GPR[rd] ←GPR[rs] + GPR[rt]

The 32-bit word value in GPR rt is added to the 32-bit value in GPR rs to produce a 32-bit result.

• If the addition results in 32-bit 2’s complement arithmetic overﬂow, the destination register is not modiﬁed and

an Integer Overﬂow exception occurs.

• If the addition does not overﬂow, the 32-bit result is placed into GPR rd.

Restrictions:

None

Operation:

temp ← (GPR[rs]31||GPR[rs]31..0) + (GPR[rt]31||GPR[rt]31..0)

if temp32 ≠ temp31 then

SignalException(IntegerOverflow)

else

GPR[rd] ← temp

endif

Exceptions:

Integer Overﬂow

Programming Notes:

ADDU performs the same arithmetic operation but does not trap on overﬂow.

31 26 25 21 20 16 15 11 10 6 5 0

SPECIAL

000000 rs rt rd 0

00000

ADD

100000

655556

Add Word ADD

36 MIPS32® Architecture For Programmers Volume II, Revision 2.50

ADDI

Format: ADDI rt, rs, immediate MIPS32

Purpose:

To add a constant to a 32-bit integer. If overflow occurs, then trap.

Description: GPR[rt] ¨ GPR[rs] + immediate

The 16-bit signed immediate is added to the 32-bit value in GPR rs to produce a 32-bit result.

• If the addition results in 32-bit 2’s complement arithmetic overﬂow, the destination register is not modiﬁed and

an Integer Overﬂow exception occurs.

• If the addition does not overﬂow, the 32-bit result is placed into GPR rt.

Restrictions:

None

Operation:

temp ← (GPR[rs]31||GPR[rs]31..0) + sign_extend(immediate)

if temp32 ≠ temp31 then

SignalException(IntegerOverflow)

else

GPR[rt] ← temp

endif

Exceptions:

Integer Overﬂow

Programming Notes:

ADDIU performs the same arithmetic operation but does not trap on overﬂow.

31 26 25 21 20 16 15 0

ADDI

001000 rs rt immediate

655 16

Add Immediate Word ADDI

42 MIPS32® Architecture For Programmers Volume II, Revision 2.50

AND

Format: AND rd, rs, rt MIPS32

Purpose:

To do a bitwise logical AND

Description: GPR[rd] ←GPR[rs] AND GPR[rt]

The contents of GPR rs are combined with the contents of GPR rt in a bitwise logical AND operation. The result is

placed into GPR rd.

Restrictions:

None

Operation:

GPR[rd] ← GPR[rs] and GPR[rt]

Exceptions:

None

31 26 25 21 20 16 15 11 10 6 5 0

SPECIAL

000000 rs rt rd 0

00000

AND

100100

655556

And AND

60 MIPS32® Architecture For Programmers Volume II, Revision 2.50

BEQ

Format: BEQ rs, rt, offset MIPS32

Purpose:

To compare GPRs then do a PC-relative conditional branch

Description: if GPR[rs] = GPR[rt] then branch

An 18-bit signed offset (the 16-bit offset ﬁeld shifted left 2 bits) is added to the address of the instruction following

the branch (not the branch itself), in the branch delay slot, to form a PC-relative effective target address.

If the contents of GPR rs and GPR rt are equal, branch to the effective target address after the instruction in the delay

slot is executed.

Restrictions:

Processor operation is UNPREDICTABLE if a branch, jump, ERET, DERET, or WAIT instruction is placed in the

delay slot of a branch or jump.

Operation:

I: target_offset ← sign_extend(offset || 02)

condition ← (GPR[rs] = GPR[rt])

I+1: if condition then

PC ← PC + target_offset

endif

Exceptions:

None

Programming Notes:

With the 18-bit signed instruction offset, the conditional branch range is ±128 Kbytes. Use jump (J) or jump register

(JR) instructions to branch to addresses outside this range.

BEQ r0, r0 offset, expressed as B offset, is the assembly idiom used to denote an unconditional branch.

31 26 25 21 20 16 15 0

BEQ

000100 rs rt offset

655 16

Branch on Equal BEQ

MIPS32® Architecture For Programmers Volume II, Revision 2.50 69

BGTZ

Format: BGTZ rs, offset MIPS32

Purpose:

To test a GPR then do a PC-relative conditional branch

Description: if GPR[rs] > 0 then branch

An 18-bit signed offset (the 16-bit offset ﬁeld shifted left 2 bits) is added to the address of the instruction following

the branch (not the branch itself), in the branch delay slot, to form a PC-relative effective target address.

If the contents of GPR rs are greater than zero (sign bit is 0 but value not zero), branch to the effective target address

after the instruction in the delay slot is executed.

Restrictions:

Processor operation is UNPREDICTABLE if a branch, jump, ERET, DERET, or WAIT instruction is placed in the

delay slot of a branch or jump.

Operation:

I: target_offset ← sign_extend(offset || 02)

condition ← GPR[rs] > 0GPRLEN

I+1: if condition then

PC ← PC + target_offset

endif

Exceptions:

None

Programming Notes:

With the 18-bit signed instruction offset, the conditional branch range is ±128 KBytes. Use jump (J) or jump register

(JR) instructions to branch to addresses outside this range.

31 26 25 21 20 16 15 0

BGTZ

000111 rs 0

00000 offset

655 16

Branch on Greater Than Zero BGTZ

72 MIPS32® Architecture For Programmers Volume II, Revision 2.50

BLEZ

Format: BLEZ rs, offset MIPS32

Purpose:

To test a GPR then do a PC-relative conditional branch

Description: if GPR[rs] ≤ 0 then branch

An 18-bit signed offset (the 16-bit offset ﬁeld shifted left 2 bits) is added to the address of the instruction following

the branch (not the branch itself), in the branch delay slot, to form a PC-relative effective target address.

If the contents of GPR rs are less than or equal to zero (sign bit is 1 or value is zero), branch to the effective target

address after the instruction in the delay slot is executed.

Restrictions:

Processor operation is UNPREDICTABLE if a branch, jump, ERET, DERET, or WAIT instruction is placed in the

delay slot of a branch or jump.

Operation:

I: target_offset ← sign_extend(offset || 02)

condition ← GPR[rs] ≤ 0GPRLEN

I+1: if condition then

PC ← PC + target_offset

endif

Exceptions:

None

Programming Notes:

With the 18-bit signed instruction offset, the conditional branch range is ±128 KBytes. Use jump (J) or jump register

(JR) instructions to branch to addresses outside this range.

31 26 25 21 20 16 15 0

BLEZ

000110 rs 0

00000 offset

655 16

Branch on Less Than or Equal to Zero BLEZ

MIPS32® Architecture For Programmers Volume II, Revision 2.50 81

BNE

Format: BNE rs, rt, offset MIPS32

Purpose:

To compare GPRs then do a PC-relative conditional branch

Description: if GPR[rs] ≠ GPR[rt] then branch

An 18-bit signed offset (the 16-bit offset ﬁeld shifted left 2 bits) is added to the address of the instruction following

the branch (not the branch itself), in the branch delay slot, to form a PC-relative effective target address.

If the contents of GPR rs and GPR rt are not equal, branch to the effective target address after the instruction in the

delay slot is executed.

Restrictions:

Processor operation is UNPREDICTABLE if a branch, jump, ERET, DERET, or WAIT instruction is placed in the

delay slot of a branch or jump.

Operation:

I: target_offset ← sign_extend(offset || 02)

condition ← (GPR[rs] ≠ GPR[rt])

I+1: if condition then

PC ← PC + target_offset

endif

Exceptions:

None

Programming Notes:

With the 18-bit signed instruction offset, the conditional branch range is ±128 KBytes. Use jump (J) or jump register

(JR) instructions to branch to addresses outside this range.

31 26 25 21 20 16 15 0

BNE

000101 rs rt offset

655 16

Branch on Not Equal BNE

122 MIPS32® Architecture For Programmers Volume II, Revision 2.50

DIV

Format: DIV rs, rt MIPS32

Purpose:

To divide a 32-bit signed integers

Description: (HI, LO) ←GPR[rs] / GPR[rt]

The 32-bit word value in GPR rs is divided by the 32-bit value in GPR rt, treating both operands as signed values.

The 32-bit quotient is placed into special register LO and the 32-bit remainder isplaced into special register HI.

No arithmetic exception occurs under any circumstances.

Restrictions:

If the divisor in GPR rt is zero, the arithmetic result value is UNPREDICTABLE.

Operation:

q← GPR[rs]31..0 div GPR[rt]31..0

LO ← q

r← GPR[rs]31..0 mod GPR[rt]31..0

HI ← r

Exceptions:

None

31 26 25 21 20 16 15 6 5 0

SPECIAL

000000 rs rt 0

00 0000 0000

DIV

011010

655 10 6

Divide Word DIV

MIPS32® Architecture For Programmers Volume II, Revision 2.50 123

Programming Notes:

No arithmetic exception occurs under any circumstances. If divide-by-zero or overﬂow conditions are detected and

some action taken, then the divide instruction is typically followed by additional instructions to check for a zero divi-

sor and/or for overﬂow. If the divide is asynchronous then the zero-divisor check can execute in parallel with the

divide. The action taken on either divide-by-zero or overﬂow is either a convention within the program itself, or more

typically within the system software; one possibility is to take a BREAK exception with a code ﬁeld value to signal

the problem to the system software.

As an example, the C programming language in a UNIX®environment expects division by zero to either terminate

the program or execute a program-speciﬁed signal handler. C does not expect overﬂow to cause any exceptional con-

dition. If the C compiler uses a divide instruction, it also emits code to test for a zero divisor and execute a BREAK

instruction to inform the operating system if a zero is detected.

In some processors the integer divide operation may proceed asynchronously and allow other CPU instructions to

execute before it is complete. An attempt to read LO or HI before the results are written interlocks until the results are

ready. Asynchronous execution does not affect the program result, but offers an opportunity for performance

improvement by scheduling the divide so that other instructions can execute in parallel.

Historical Perspective:

In MIPS 1 through MIPS III, if either of the two instructions preceding the divide is an MFHI or MFLO, the result of

the MFHI or MFLO is UNPREDICTABLE. Reads of the HI or LO special register must be separated from subse-

quent instructions that write to them by two or more instructions. This restriction was removed in MIPS IV and

MIPS32 and all subsequent levels of the architecture.

Divide Word (cont.) DIV

138 MIPS32® Architecture For Programmers Volume II, Revision 2.50

Format: J target MIPS32

Purpose:

To branch within the current 256 MB-aligned region

Description:

This is a PC-region branch (not PC-relative); the effective target address is in the “current” 256 MB-aligned region.

The low 28 bits of the target address is the instr_index ﬁeld shifted left 2 bits. The remaining upper bits are the corre-

sponding bits of the address of the instruction in the delay slot (not the branch itself).

Jump to the effective target address. Execute the instruction that follows the jump, in the branch delay slot, before

executing the jump itself.

Restrictions:

Processor operation is UNPREDICTABLE if a branch, jump, ERET, DERET, or WAIT instruction is placed in the

delay slot of a branch or jump.

Operation:

I+1:PC ← PCGPRLEN-1..28 || instr_index || 02

Exceptions:

None

Programming Notes:

Forming the branch target address by catenating PC and index bits rather than adding a signed offset to the PC is an

advantage if all program code addresses ﬁt into a 256 MB region aligned on a 256 MB boundary. It allows a branch

from anywhere in the region to anywhere in the region, an action not allowed by a signed relative offset.

This deﬁnition creates the following boundary case: When the jump instruction is in the last word of a 256 MB

region, it can branch only to the following 256 MB region containing the branch delay slot.

31 26 25 0

000010 instr_index

626

Jump J

MIPS32® Architecture For Programmers Volume II, Revision 2.50 139

JAL

Format: JAL target MIPS32

Purpose:

To execute a procedure call within the current 256 MB-aligned region

Description:

Place the return address link in GPR 31. The return link is the address of the second instruction following the branch,

at which location execution continues after a procedure call.

This is a PC-region branch (not PC-relative); the effective target address is in the “current” 256 MB-aligned region.

The low 28 bits of the target address is the instr_index ﬁeld shifted left 2 bits. The remaining upper bits are the corre-

sponding bits of the address of the instruction in the delay slot (not the branch itself).

Jump to the effective target address. Execute the instruction that follows the jump, in the branch delay slot, before

executing the jump itself.

Restrictions:

Processor operation is UNPREDICTABLE if a branch, jump, ERET, DERET, or WAIT instruction is placed in the

delay slot of a branch or jump.

Operation:

I: GPR[31]← PC + 8

I+1:PC ← PCGPRLEN-1..28 || instr_index || 02

Exceptions:

None

Programming Notes:

Forming the branch target address by catenating PC and index bits rather than adding a signed offset to the PC is an

advantage if all program code addresses ﬁt into a 256 MB region aligned on a 256 MB boundary. It allows a branch

from anywhere in the region to anywhere in the region, an action not allowed by a signed relative offset.

This deﬁnition creates the following boundary case: When the branch instruction is in the last word of a 256 MB

region, it can branch only to the following 256 MB region containing the branch delay slot.

31 26 25 0

JAL

000011 instr_index

626

Jump and Link JAL

MIPS32® Architecture For Programmers Volume II, Revision 2.50 145

Format: JR rs MIPS32

Purpose:

To execute a branch to an instruction address in a register

Description: PC ←GPR[rs]

Jump to the effective target address in GPR rs. Execute the instruction following the jump, in the branch delay slot,

before jumping.

For processors that implement the MIPS16e ASE, set the ISA Mode bit to the value in GPR rs bit 0. Bit 0 of the target

address is always zero so that no Address Exceptions occur when bit 0 of the source register is one

Restrictions:

The effective target address in GPR rs must be naturally-aligned. For processors that do not implement the MIPS16e

ASE, if either of the two least-signiﬁcant bits are not zero, an Address Error exception occurs when the branch target

is subsequently fetched as an instruction. For processors that do implement the MIPS16e ASE, if bit 0 is zero and bit

1 is one, an Address Error exception occurs when the jump target is subsequently fetched as an instruction.

In release 1 of the architecture, the only deﬁned hint ﬁeld value is 0, which sets default handling of JR. In Release 2

of the architecture, bit 10 of the hint ﬁeld is used to encode an instruction hazard barrier. See the JR.HB instruction

description for additional information.

Processor operation is UNPREDICTABLE if a branch, jump, ERET, DERET, or WAIT instruction is placed in the

delay slot of a branch or jump.

Operation:

I: temp ← GPR[rs]

I+1:if Config1CA = 0 then

PC ← temp

else

PC ← tempGPRLEN-1..1 || 0

ISAMode ← temp0

endif

Exceptions:

None

31 26 25 21 20 11 10 6 5 0

SPECIAL

000000 rs 0

00 0000 0000 hint JR

001000

65 10 56

Jump Register JR

146 MIPS32® Architecture For Programmers Volume II, Revision 2.50

Programming Notes:

Software should use the value 31 for the rs ﬁeld of the instruction word on return from a JAL, JALR, or BGEZAL,

and should use a value other than 31 for remaining uses of JR.

Jump Register, cont. JR

MIPS32® Architecture For Programmers Volume II, Revision 2.50 159

LUI

Format: LUI rt, immediate MIPS32

Purpose:

To load a constant into the upper half of a word

Description: GPR[rt] ←immediate || 016

The 16-bit immediate is shifted left 16 bits and concatenated with 16 bits of low-order zeros. The 32-bit result is

placed into GPR rt.

Restrictions:

None

Operation:

GPR[rt] ← immediate || 016

Exceptions:

None

31 26 25 21 20 16 15 0

LUI

001111

00000 rt immediate

655 16

Load Upper Immediate LUI

MIPS32® Architecture For Programmers Volume II, Revision 2.50 161

Format: LW rt, offset(base) MIPS32

Purpose:

To load a word from memory as a signed value

Description: GPR[rt] ←memory[GPR[base] + offset]

The contents of the 32-bit word at the memory location speciﬁed by the aligned effective address are fetched,

sign-extended to the GPR register length if necessary, and placed in GPR rt. The 16-bit signed offset is added to the

contents of GPR base to form the effective address.

Restrictions:

The effective address must be naturally-aligned. If either of the 2 least-signiﬁcant bits of the address is non-zero, an

Address Error exception occurs.

Operation:

vAddr ← sign_extend(offset) + GPR[base]

if vAddr1..0 ≠ 02 then

SignalException(AddressError)

endif

(pAddr, CCA)← AddressTranslation (vAddr, DATA, LOAD)

memword← LoadMemory (CCA, WORD, pAddr, vAddr, DATA)

GPR[rt]← memword

Exceptions:

TLB Reﬁll, TLB Invalid, Bus Error, Address Error, Watch

31 26 25 21 20 16 15 0

100011 base rt offset

655 16

Load Word LW

MIPS32® Architecture For Programmers Volume II, Revision 2.50 181

MFHI

Format: MFHI rd MIPS32

Purpose:

To copy the special purpose HI register to a GPR

Description: GPR[rd] ←HI

The contents of special register HI are loaded into GPR rd.

Restrictions:

None

Operation:

GPR[rd] ← HI

Exceptions:

None

Historical Information:

In the MIPS I, II, and III architectures, the two instructions which follow the MFHI must not moodify the HI register.

If this restriction is violated, the result of the MFHI is UNPREDICTABLE. This restriction was removed in MIPS

IV and MIPS32, and all subsequent levels of the architecture.

31 26 25 16 15 11 10 6 5 0

SPECIAL

000000

00 0000 0000 rd 0

00000

MFHI

010000

610556

Move From HI Register MFHI

182 MIPS32® Architecture For Programmers Volume II, Revision 2.50

MFLO

Format: MFLO rd MIPS32

Purpose:

To copy the special purpose LO register to a GPR

Description: GPR[rd] ←LO

The contents of special register LO are loaded into GPR rd.

Restrictions: None

Operation:

GPR[rd] ← LO

Exceptions:

None

Historical Information:

In the MIPS I, II, and III architectures, the two instructions which follow the MFHI must not moodify the HI register.

If this restriction is violated, the result of the MFHI is UNPREDICTABLE. This restriction was removed in MIPS

IV and MIPS32, and all subsequent levels of the architecture.

31 26 25 16 15 11 10 6 5 0

SPECIAL

000000

00 0000 0000 rd 0

00000

MFLO

010010

610556

Move From LO Register MFLO

MIPS32® Architecture For Programmers Volume II, Revision 2.50 209

MULT

Format: MULT rs, rt MIPS32

Purpose:

To multiply 32-bit signed integers

Description: (HI, LO) ←GPR[rs] ×GPR[rt]

The 32-bit word value in GPR rt is multiplied by the 32-bit value in GPR rs, treating both operands as signed values,

to produce a 64-bit result. The low-order 32-bit word of the result is placed into special register LO, and the

high-order 32-bit word is splaced into special register HI.

No arithmetic exception occurs under any circumstances.

Restrictions:

None

Operation:

prod ← GPR[rs]31..0 × GPR[rt]31..0

LO ← prod31..0

HI ← prod63..32

Exceptions:

None

Programming Notes:

In some processors the integer multiply operation may proceed asynchronously and allow other CPU instructions to

execute before it is complete. An attempt to read LO or HI before the results are written interlocks until the results are

ready. Asynchronous execution does not affect the program result, but offers an opportunity for performance

improvement by scheduling the multiply so that other instructions can execute in parallel.

Programs that require overﬂow detection must check for it explicitly.

Where the size of the operands are known, software should place the shorter operand in GPR rt. This may reduce the

latency of the instruction on those processors which implement data-dependent instruction latencies.

31 26 25 21 20 16 15 6 5 0

SPECIAL

000000 rs rt 0

00 0000 0000

MULT

011000

655 10 6

Multiply Word MULT

216 MIPS32® Architecture For Programmers Volume II, Revision 2.50

NOP

Format: NOP Assembly Idiom

Purpose:

To perform no operation.

Description:

NOP is the assembly idiom used to denote no operation. The actual instruction is interpreted by the hardware as SLL

r0, r0, 0.

Restrictions:

None

Operation:

None

Exceptions:

None

Programming Notes:

The zero instruction word, which represents SLL, r0, r0, 0, is the preferred NOP for software to use to ﬁll branch and

jump delay slots and to pad out alignment sequences.

31 26 25 21 20 16 15 11 10 6 5 0

SPECIAL

000000

00000

SLL

000000

655556

No Operation NOP

218 MIPS32® Architecture For Programmers Volume II, Revision 2.50

Format: OR rd, rs, rt MIPS32

Purpose:

To do a bitwise logical OR

Description: GPR[rd] ←GPR[rs] or GPR[rt]

The contents of GPR rs are combined with the contents of GPR rt in a bitwise logical OR operation. The result is

placed into GPR rd.

Restrictions:

None

Operation:

GPR[rd] ← GPR[rs] or GPR[rt]

Exceptions:

None

31 26 25 21 20 16 15 11 10 6 5 0

SPECIAL

000000 rs rt rd 0

00000

100101

655556

Or OR

234 MIPS32® Architecture For Programmers Volume II, Revision 2.50

ROTR

Format: ROTR rd, rt, sa SmartMIPS Crypto, MIPS32 Release 2

Purpose:

To execute a logical right-rotate of a word by a ﬁxed number of bits

Description: GPR[rd] ←GPR[rt] ↔(right) sa

The contents of the low-order 32-bit word of GPR rt are rotated right; the word result is placed in GPR rd. The

bit-rotate amount is speciﬁed by sa.

Restrictions:

Operation:

if ((ArchitectureRevision() < 2) and (Config3SM = 0)) then

UNPREDICTABLE

endif

s← sa

temp ← GPR[rt]s-1..0 || GPR[rt]31..s

GPR[rd]← temp

Exceptions:

Reserved Instruction

31 26 25 22 21 20 16 15 11 10 6 5 0

SPECIAL

000000 0000 R

1rt rd sa SRL

000010

641555 6

Rotate Word Right ROTR

254 MIPS32® Architecture For Programmers Volume II, Revision 2.50

SLL

Format: SLL rd, rt, sa MIPS32

Purpose:

To left-shift a word by a ﬁxed number of bits

Description: GPR[rd] ←GPR[rt] << sa

The contents of the low-order 32-bit word of GPR rt are shifted left, inserting zeros into the emptied bits; the word

result is placed in GPR rd. The bit-shift amount is speciﬁed by sa.

Restrictions:

None

Operation:

s← sa

temp ← GPR[rt](31-s)..0 || 0s

GPR[rd]← temp

Exceptions:

None

Programming Notes:

SLL r0, r0, 0, expressed as NOP, is the assembly idiom used to denote no operation.

SLL r0, r0, 1, expressed as SSNOP, is the assembly idiom used to denote no operation that causes an issue break on

superscalar processors.

31 26 25 21 20 16 15 11 10 6 5 0

SPECIAL

000000

00000 rt rd sa SLL

000000

655556

Shift Word Left Logical SLL

256 MIPS32® Architecture For Programmers Volume II, Revision 2.50

SLT

Format: SLT rd, rs, rt MIPS32

Purpose:

To record the result of a less-than comparison

Description: GPR[rd] ←(GPR[rs] < GPR[rt])

Compare the contents of GPR rs and GPR rt as signed integers and record the Boolean result of the comparison in

GPR rd. If GPR rs is less than GPR rt, the result is 1 (true); otherwise, it is 0 (false).

The arithmetic comparison does not cause an Integer Overﬂow exception.

Restrictions:

None

Operation:

if GPR[rs] < GPR[rt] then

GPR[rd] ← 0GPRLEN-1 || 1

else

GPR[rd] ← 0GPRLEN

endif

Exceptions:

None

31 26 25 21 20 16 15 11 10 6 5 0

SPECIAL

000000 rs rt rd 0

00000

SLT

101010

655556

Set on Less Than SLT

MIPS32® Architecture For Programmers Volume II, Revision 2.50 263

SRL

Format: SRL rd, rt, sa MIPS32

Purpose:

To execute a logical right-shift of a word by a ﬁxed number of bits

Description: GPR[rd] ←GPR[rt] >> sa (logical)

The contents of the low-order 32-bit word of GPR rt are shifted right, inserting zeros into the emptied bits; the word

result is placed in GPR rd. The bit-shift amount is speciﬁed by sa.

Restrictions:

None

Operation:

s← sa

temp ← 0s || GPR[rt]31..s

GPR[rd]← temp

Exceptions:

None

31 26 25 22 21 20 16 15 11 10 6 5 0

SPECIAL

000000 0000 R

0rt rd sa SRL

000010

641555 6

Shift Word Right Logical SRL

266 MIPS32® Architecture For Programmers Volume II, Revision 2.50

SUB

Format: SUB rd, rs, rt MIPS32

Purpose:

To subtract 32-bit integers. If overﬂow occurs, then trap

Description: GPR[rd] ←GPR[rs] - GPR[rt]

The 32-bit word value in GPR rt is subtracted from the 32-bit value in GPR rs to produce a 32-bit result. If the sub-

traction results in 32-bit 2’s complement arithmetic overﬂow, then the destination register is not modiﬁed and an Inte-

ger Overﬂow exception occurs. If it does not overﬂow, the 32-bit result is placed into GPR rd.

Restrictions:

None

Operation:

temp ← (GPR[rs]31||GPR[rs]31..0)− (GPR[rt]31||GPR[rt]31..0)

if temp32 ≠ temp31 then

SignalException(IntegerOverflow)

else

GPR[rd] ← temp31..0

endif

Exceptions:

Integer Overﬂow

Programming Notes:

SUBU performs the same arithmetic operation but does not trap on overﬂow.

31 26 25 21 20 16 15 11 10 6 5 0

SPECIAL

000000 rs rt rd 0

00000

SUB

100010

655556

Subtract Word SUB

270 MIPS32® Architecture For Programmers Volume II, Revision 2.50

Format: SW rt, offset(base) MIPS32

Purpose:

To store a word to memory

Description: memory[GPR[base] + offset] ←GPR[rt]

The least-signiﬁcant 32-bit word of GPR rt is stored in memory at the location speciﬁed by the aligned effective

address. The 16-bit signed offset is added to the contents of GPR base to form the effective address.

Restrictions:

The effective address must be naturally-aligned. If either of the 2 least-signiﬁcant bits of the address is non-zero, an

Address Error exception occurs.

Operation:

vAddr ← sign_extend(offset) + GPR[base]

if vAddr1..0 ≠ 02 then

SignalException(AddressError)

endif

(pAddr, CCA)← AddressTranslation (vAddr, DATA, STORE)

dataword← GPR[rt]

StoreMemory (CCA, WORD, dataword, pAddr, vAddr, DATA)

Exceptions:

TLB Reﬁll, TLB Invalid, TLB Modiﬁed, Address Error, Watch

31 26 25 21 20 16 15 0

101011 base rt offset

655 16

Store Word SW

MIPS32® Architecture For Programmers Volume II, Revision 2.50 285

SYSCALL

Format: SYSCALL MIPS32

Purpose:

To cause a System Call exception

Description:

A system call exception occurs, immediately and unconditionally transferring control to the exception handler.

The code ﬁeld is available for use as software parameters, but is retrieved by the exception handler only by loading

the contents of the memory word containing the instruction.

Restrictions:

None

Operation:

SignalException(SystemCall)

Exceptions:

System Call

31 26 25 6 5 0

SPECIAL

000000 code SYSCALL

001100

620 6

System Call SYSCALL

MIPS32® Architecture For Programmers Volume II, Revision 2.50 313

XOR

Format: XOR rd, rs, rt MIPS32

Purpose:

To do a bitwise logical Exclusive OR

Description: GPR[rd] ←GPR[rs] XOR GPR[rt]

Combine the contents of GPR rs and GPR rt in a bitwise logical Exclusive OR operation and place the result into

GPR rd.

Restrictions:

None

Operation:

GPR[rd] ← GPR[rs] xor GPR[rt]

Exceptions:

None

31 26 25 21 20 16 15 11 10 6 5 0

SPECIAL

000000 rs rt rd 0

00000

XOR

100110

655556

Exclusive OR XOR

Annexe2 Instructions MIPS
