Codan Radio HF Commercial Catalogue 2015

User Manual: Catalogues | LMR & HF Radio | Codan Radio

Open the PDF directly: View PDF PDF.
Page Count: 220 [warning: Documents this large are best viewed by clicking the View PDF Link!]

This is Issue 8 of the HF Codan Radio Communications Commercial Product Catalogue, January
2015.
No part of this product catalogue may be reproduced, transcribed, translated into any language
or transmitted in any form whatsoever without the prior written consent of Codan Limited.
Pictures shown in this product catalogue are for illustration purposes only — actual products,
colours and configurations may vary from the pictures shown.
The products in this catalogue are available with the NGT™ series Transceivers and / or the
Envoy™ series Transceivers as indicated by the following logos. A compatibility statement specifies
the transceiver models that are applicable.
Available with the NGT™ series Transceivers
Available with Envoy™ series Transceivers
CODAN™, Envoy™, NGT™, Easitalk™, CALM™ and Crosspatch™ are trademarks of Codan Limited.
Other brand, product and company names mentioned in this document are trademarks or
registered trademarks of their respective holders.
© Copyright 2015 Codan Limited.
NGT
TRANSCEIVER
HF Radio Communications International Product Catalogue Page I
Issue 8 January 2015
Envoy™ X1 Configurations ................................................................................................................................... 1
Envoy™ X1 Transceiver ........................................................................................................................................1
Envoy™ X1 Mobile .................................................................................................................................................2
Envoy™ X1 Base......................................................................................................................................................3
Envoy™ X1 Options ...............................................................................................................................................4
Envoy™ X2 Configurations ................................................................................................................................... 7
Envoy™ X2 Transceiver.........................................................................................................................................7
Envoy™ X2 Mobile .................................................................................................................................................8
Envoy™ X2 Base......................................................................................................................................................9
Envoy™ X2 Options ............................................................................................................................................ 10
Envoy™ X1 Configurations for Australia.........................................................................................................15
Envoy™ X1 Transceiver...................................................................................................................................... 15
Envoy™ X1 Packages.......................................................................................................................................... 16
Envoy™ X2 Configurations for Australia.........................................................................................................17
Envoy™ X2 Transceiver...................................................................................................................................... 17
Envoy™ X2 Packages.......................................................................................................................................... 18
NGT™ SR Configurations.....................................................................................................................................19
NGT™ SR Transceiver ......................................................................................................................................... 19
NGT™ SR Mobile .................................................................................................................................................. 20
NGT™ SR Base....................................................................................................................................................... 21
NGT™ SR Options ................................................................................................................................................ 22
NGT™ ASR Configurations ..................................................................................................................................25
NGT™ ASR Transceiver ...................................................................................................................................... 25
NGT™ ASR Mobile ............................................................................................................................................... 26
NGT™ ASR Base.................................................................................................................................................... 27
NGT™ ASR Options ............................................................................................................................................. 28
NGT™ SRx Configurations...................................................................................................................................31
NGT™ SRx Transceiver....................................................................................................................................... 31
NGT™ SRx Mobile ............................................................................................................................................... 32
NGT™ SRx Base .................................................................................................................................................... 33
NGT™ SRx Options.............................................................................................................................................. 34
NGT™ AR Configurations for Australia............................................................................................................37
NGT™ AR Transceiver......................................................................................................................................... 37
NGT™ AR Packages ............................................................................................................................................. 38
NGT™ AR Options ............................................................................................................................................... 39
NGT™ SRx Configurations for Australia ..........................................................................................................41
NGT™ SRx Transciever....................................................................................................................................... 41
NGT™ SRx Packages ........................................................................................................................................... 42
NGT™ SRx Options.............................................................................................................................................. 43
Page II HF Radio Communications International Product Catalogue
Issue 8 January 2015
Transceiver Accessories ...................................................................................................................................... 45
Transceiver Accessories .................................................................................................................................... 45
Base Accessories.................................................................................................................................................. 53
Data & Email ......................................................................................................................................................... 59
RC50-C HF Email Software .............................................................................................................................. 59
RC50-C Cable Options ....................................................................................................................................... 60
UUPlus™ Server Software................................................................................................................................. 61
UUPlus™ Server Cable Option......................................................................................................................... 62
UUPlus™ Client Software ................................................................................................................................. 63
UUPlus™ Client Cable Options....................................................................................................................... 64
RM50e HF Data Modem................................................................................................................................... 65
3012 HF Data Modem(No cables)................................................................................................................. 67
3012 HF Data Modem for NGT™ with 2 M RS232 cable ....................................................................... 68
3012 HF Data Modem for NGT™ with 6 M RS232 cable ....................................................................... 69
3012 Accessories................................................................................................................................................. 70
3212 HF Data Modem (No cables)................................................................................................................ 71
3212 HF Data Modem for NGT™/Envoy X2 with 2 M RS232 cable ................................................... 72
3212 HF Data Modem for NGT™/Envoy™ X2 with 6 M RS232 cable................................................ 73
3212 Accessories................................................................................................................................................. 74
High Power Amplifiers........................................................................................................................................ 75
3061 500 W Power Amplifier.......................................................................................................................... 75
3061 Accessories................................................................................................................................................. 76
3062 1 kW Power Amplifier ............................................................................................................................ 77
3062 Accessories................................................................................................................................................. 78
Crosspatch™/Phone/GPS Solutions ................................................................................................................ 79
Crosspatch™ for NGT™/Envoy™ .................................................................................................................... 79
Crosspatch™ Accessories.................................................................................................................................. 79
3033 Telephone Interconnect ........................................................................................................................ 80
3033 Accessories................................................................................................................................................. 81
GPS Tracking Software...................................................................................................................................... 82
GPS Accessories ................................................................................................................................................... 82
Transceiver Supplies............................................................................................................................................ 83
3020 Transceiver Supply .................................................................................................................................. 83
3020 Accessories................................................................................................................................................. 84
DC-DC Voltage Converter ................................................................................................................................ 84
Solar Power Supplies ......................................................................................................................................... 85
Solar Power Supplies Accessories.................................................................................................................. 85
Batteries................................................................................................................................................................. 86
Antennas ................................................................................................................................................................ 87
3040 Automatic Tuning Whip with 6 M Cables....................................................................................... 88
3040 Accessories................................................................................................................................................. 89
9350 Automatic Tuning Whip........................................................................................................................ 90
HF Radio Communications International Product Catalogue Page III
Issue 8 January 2015
9350 Automatic Tuning Whip with 6 M Cables....................................................................................... 91
9350 Accessories................................................................................................................................................. 92
3042 HF Antenna Tuner ................................................................................................................................... 93
3042 HF Antenna Tuner with 6 M Cables .................................................................................................. 94
Antennas.................................................................................................................................................................95
3042 Accessories................................................................................................................................................ 95
Tuners..................................................................................................................................................................... 97
Tuner Accessories ............................................................................................................................................... 97
Base Whip.............................................................................................................................................................. 98
Base Whip Accessories..................................................................................................................................... 98
Tuned Long Wire................................................................................................................................................. 99
3048 Tuned Dipole...........................................................................................................................................100
Travelling Wave Dipole...................................................................................................................................101
Delta......................................................................................................................................................................102
Semi-Delta ..........................................................................................................................................................103
TFD411 Broadband ..........................................................................................................................................104
TFD411 Broadband/Masts Kits....................................................................................................................106
Antenna Masts ..................................................................................................................................................107
Masts, Guyed 10 M ..........................................................................................................................................108
Coaxial Cables Type RG58 .............................................................................................................................109
Coaxial Cables Type RG213...........................................................................................................................109
Lightning Protection........................................................................................................................................110
Antennas for Australia ..................................................................................................................................... 112
3040 Automatic Tuning Whip Standard Package .................................................................................112
3040 Automatic Tuning Whip Explorer Package...................................................................................113
9350 Automatic Tuning Whip Standard Package .................................................................................114
9350 Automatic Tuning Whip Venturer Package..................................................................................115
Remote Control .................................................................................................................................................. 117
Envoy™ Remote Control Accessories — Ethernet .................................................................................117
NGT™ Remote Control Equipment—2-Wire...........................................................................................118
NGT™ Remote Control Accessories ............................................................................................................119
NGT™ Split-Site Equipment — 2-wire.......................................................................................................120
NGT™ Split-Site Equipment —4-wire........................................................................................................122
Split-site Accessories .......................................................................................................................................124
19" Racks & Accessories................................................................................................................................... 125
Standard Rack Configurations ....................................................................................................................125
19" Rack Cabinets .............................................................................................................................................127
19" Rack Mount System Trays.....................................................................................................................127
19" Rack Mount Blanking Panels.................................................................................................................128
19" Rack Mount Accessories ........................................................................................................................128
Page IV HF Radio Communications International Product Catalogue
Issue 8 January 2015
2110 Transceiver Configurations...................................................................................................................129
2110 Series Transceiver Kit............................................................................................................................129
2110 Series Patrol Configuration ................................................................................................................130
2110 Series Explorer Configuration ...........................................................................................................131
2110 Series Homeland Security Configuration......................................................................................133
2110 Transceiver ................................................................................................................................................135
2110 Transceiver Units ...................................................................................................................................135
2110 Options......................................................................................................................................................136
2110 Accessories...............................................................................................................................................139
Data & Email for 2110 ......................................................................................................................................143
RC50-C HF Email Software ............................................................................................................................143
UUPLUS™ Software..........................................................................................................................................144
3012 HF Data Modem (No cables)..............................................................................................................146
3012 HF Data modem for 2110 with 6 M RS232 Cable.......................................................................147
3012 Accessories...............................................................................................................................................148
3212 HF Data Modem (No cables)..............................................................................................................149
3212 HF Data Modem for 2110 with 2 M RS232 Cable.......................................................................150
3212 HF Data Modem for 2110 with 6 M RS232 Cable.......................................................................151
3212 Accessories...............................................................................................................................................152
Crosspatch™ for 2110 .......................................................................................................................................153
Crosspatch™ for 2110 .....................................................................................................................................153
Crosspatch™ Accessories................................................................................................................................153
Antenna Accessories .........................................................................................................................................155
Long Wire and Dipoles....................................................................................................................................155
Tactical Masts ....................................................................................................................................................156
Whip Antennas..................................................................................................................................................156
Cables....................................................................................................................................................................156
Earthing................................................................................................................................................................157
Battery & Charger Accessories .......................................................................................................................159
Batteries...............................................................................................................................................................159
DC-DC Voltage Converter ..............................................................................................................................159
Chargers...............................................................................................................................................................160
Charger Modules...............................................................................................................................................160
Charger Output Cables ...................................................................................................................................161
Charger Input Cables AC ................................................................................................................................162
Charger Input Cables DC................................................................................................................................162
Backpacks.............................................................................................................................................................163
Backpacks ............................................................................................................................................................163
Backpack & Mounting Accessories................................................................................................................164
Mounting Accessories.....................................................................................................................................164
HF Radio Communications International Product Catalogue Page V
Issue 8 January 2015
Language Support.....................................................................................................................................................165
English Manuals................................................................................................................................................165
French Manuals.................................................................................................................................................168
Spanish Manuals ..............................................................................................................................................169
Arabic Manuals..................................................................................................................................................170
Dari Manuals......................................................................................................................................................170
Portuguese Manuals........................................................................................................................................170
Russian Manuals...............................................................................................................................................170
Shipping Weights .............................................................................................................................................. 171
Shipping Weights .............................................................................................................................................171
Standard Packing Dimensions........................................................................................................................ 184
Standard Packing Dimensions .....................................................................................................................184
Standard Terms & Conditions of Supply ..................................................................................................... 186
Standard Terms & Conditions of Supply...........................................................................................................186
International Product Warranty provided by Codan................................................................................ 195
International Product Warranty provided by Codan.....................................................................................195
2240 SmartLink Accessory Addendum ................................................................................................................. 197
2240 SmartLink Accessory Addendum ..............................................................................................................197
Page VI HF Radio Communications International Product Catalogue
Issue 8 January 2015
2240 SmartLink Accessory Addendum
Please note that from pages 197 to 206 an addendum is included to cover details on the
Envoy SmartLink.
Codan Radio Communications Commercial Product Catalogue Page 1
Issue 8 January 2015
Envoy™ X1 Configurations
ENVOY™ X1 TRANSCEIVER Envoy X1 Transceiver
PRODUCT PART NO. DESCRIPTION
ENVOY-X1-TCVR Envoy Transceiver
08-07218-001
08-07000-001
15-00149
15-00649
08-06022-001
30-11208-000
15-04177-
##
06-02809-EN
Envoy™ X1 Transceiver
The Envoy™ X1 Transceiver is a state-of- the-art software
defined HF transceiver that delivers high performance but
cost-effective voice communications for both base and
mobile applications.
The X1 Transceiver can be used with the 2221 or 2220
Handset or 2230 Desk Console. Both handset types and
the desk console incorporate the new large format colour
display and intuitive icon based menu system providing
ease of use and programming.
NOTE: The GPIO connector on the Envoy™ X1 Transceiver
does not support any peripherals apart from a
Morse Code Key.
The standard transceiver consists of the parts listed
below. The following pages detail the parts required for
Envoy™ X1 Mobile and Base configurations.
COMPRISING:
•Envoy
TM X1 2210 RF Unit
•Envoy
TM 2220 Handset
•Envoy
TM 2220 Handset Cradle
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
• Self Adhesive Rubber Feet (x4)
•Envoy
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
•Envoy
TM Quick Reference Card
STANDARD FEATURES:
• 100 channels, 1.6 to 30 MHz, 10 scan groups
• 200 Contact List entries
• Simultaneous scanning of multiple scan groups
• 125 W PEP, 12 V DC, USB/LSB/AM
• Ethernet/USB connectivity
• English language graphical user interface
• Codan Selcall (including Diagnostic, Phone and
Emergency Call types)
•GPS receiver port
• In-built EasitalkTM speech noise reduction
• MIL-STD-810G for Drop, Dust, Shock, Vibration
AVAILABLE OPTIONS & ACCESSORIES:
See pages 4 and 45 for Envoy™ X1 Options and Transc eiv er
Accessories.
##
denotes language version
Page 2 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X1 Configurations
ENVOY™ X1 MOBILE Envoy X1 Mobile
PRODUCT PART NO. DESCRIPTION
ENVOY-X1-MOB Envoy™ X1 Mobile Configuration
The Envoy™ X1 Mobile Configuration consists of an
Envoy™ Transceiver, a 3040 Automatic Tuning Whip
Antenna and cables, and vehicle installation hardware kit.
08-07218-001
08-07000-001
15-00149
15-00649
08-06022-001
15-04177-
##
06-02809-EN
COMPRISING:
Envoy™ X1 Transceiver
•Envoy
TM X1 2210 RF Unit
•Envoy
TM 2220 Handset
•Envoy
TM 2220 Handset Cradle
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
•Envoy
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
•Envoy
TM Quick Reference Card
08-07007-001
08-05627-006
08-01503-006
08-07148-001
78-18058
78-23085
78-23086
15-60012
3040 Automatic Tuning Whip with 6 m Cables
The 3040 consists of the following parts. See page 89 for
additional 3040 accessories.
3040 Main Assembly
Control NGTTM /EnvoyTM to 9350/304X Cable, 6 m
Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
3040 Spring
Riser, Fibreglass
3040 Fibreglass Whip, 1.6 m
3040 Stainless Steel Whip, 1.65 m
3040 Automatic Whip Antenna Installation Handbook,
c/w antenna connector sealing kit
15-00130 RF Unit Cradle & Battery Cable
Includes mounting cradle, fuse holder and fuse, earth wire
and 6 m battery cable.
15-00112 Complete Vehicle Installation Hardware Kit
Includes assorted screws, cable ties and grommets.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 4 and 51 for Envoy™ X1 Options and Mobile
Accessories.
##
denotes language version
Codan Radio Communications Commercial Product Catalogue Page 3
Issue 8 January 2015
Envoy™ X1 Configurations
ENVOY™ X1 BASE Envoy X1 Base
PRODUCT PART NO. DESCRIPTION
ENVOY-X1-BASE Envoy™ X1 Base Station Configuration
The Envoy™ X1 Base Station Configuration consists of an
Envoy™ X1 Transceiver, a 2230 Desk Console, a TFD411
Antenna, 3020 Heavy Duty Transceiver Supply, and cables.
08-07218-001
08-07204-001
15-60025
08-07205-006
30-11208-000
15-04177-
##
06-02809-EN
COMPRISING:
Envoy™ Transceiver
•Envoy
TM X1 2210 RF Unit
•Envoy
TM 2230 Desk Console
• 2230 Desk Console Boom Microphone
• Envoy™ Console to RF Unit Cable, 6 m
• Self Adhesive Rubber Feet (x4)
•Envoy
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
•Envoy
TM Quick Reference Card
15-00411-004 TFD411 Antenna 125 W, 2–30 MHz, 34 m
The antenna can be mounted horizontally between two
support systems, or as an inverted “V” using a single
central support mast.
NOTE:
Mast is not included. For masts, see page 107,
Antenna Masts.
08-01503-030 Coax Assembly Cable, UHF Type Connectors, RG58, 30 m
30 m of high quality RG58 coaxial cable terminated with
waterproof UHF style connectors.
78-20022 3020 Transceiver Supply
Power supply to convert AC Mains into 13.8 V DC to power
the X1 Transceiver.
67-9030# Power IEC Cable, 2 m
Used to connect 3020 Transceiver Supply to AC Mains
source. For cable options, see page 83, 3020 Transceiver
Supply.
05-06374 Earth Braid, 1.5 m
Used to connect X1 RF Unit to ground point.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 4 and 53 for Envoy™ X1 Options and Base
Accessories.
# denotes the cable variant depending upon country of use
##
denotes language version
Page 4 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X1 Configurations
ENVOY™ X1 OPTIONS Envoy X1 Options
PRODUCT PART NO. DESCRIPTION
Envoy X1 Options
15-10560 Opt FED-STD-1045 ALE/CALM™
Fully compatible with FED-STD-1045 ALE capabilities and
enhanced with Codan Automated Link Management
(CALM™). Standard call types include: Selective Call, All Call,
Phone Call, Message Call, Diagnostic Call, Emergency Call.
15-10558 Opt, Default Open Selcall
15-10561 Opt GPS Calling
Enables sending and receiving of GPS position information
using Selcall or ALE (if enabled).
NOTE:
This feature is compatible with GPS receivers providing
NMEA 0183 V2.0 (or later) output format. A GPS receiver is
not supplied as part of this option.
For a description of the GPS receiver available from Codan,
see page 51, Mobile Accessories.
15-10518 Opt Amateur Mode
Enables transmit within designated HF Amateur frequency
bands when using the Free Tune Receiver mode.
15-10599 Opt Dari Language
Enables Dari Language user interface as a user selectable
option for any control point (2221/2220 Handset or 2230
Desktop Console) connected to the RF Unit.
15-10600 Opt Russian Language
Enables Russian Language user interface as a user selectable
option for any control point (2221/2220 Handset or 2230
Desktop Console) connected to the RF Unit.
15-10580 Opt Spanish Language
Enables Spanish Language user interface as a user selectable
option for any control point (2221/2220 Handset or 2230
Desktop Console) connected to the RF Unit.
15-10601 Opt French Language
Enables French Language user interface as a user selectable
option for any control point (2221/2220 Handset or 2230
Desktop Console) connected to the RF Unit.
15-10513 Opt 100 W
Sets maximum transmit power to 100 watts.
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 5
Issue 8 January 2015
Envoy™ X1 Configurations
ENVOY™ X1 OPTIONS cont. Envoy X1 Options
PRODUCT PART NO. DESCRIPTION
15-10481 Opt TxD, Tx Program Disabled
Disables keypad programming of new transmit frequencies.
For use in countries where front panel programming is
prohibited by regulatory authorities,
e.g. USA and Australia.
15-10491 Opt TxP, Tx Program Prohibited
Prohibits keypad programming of new transmit and receive
frequencies.
15-10582 Opt 500 Hz Filter
500 Hz filter software filter for narrow band operation
e.g. Morse Code.
15-10563 Opt Voice Scrambler (CIVS)
Codan Integrated Voice Scrambler used to provide basic level
voice security capability.
Envoy X1 Options
15-10591-000 Opt Digital Voice (Factory Fit)
Enables digital voice capability. Digital voice provides highly
intelligible audio, free from background noise, interference,
and fading effects often experienced with analogue voice.
Supplied standard with MELPe and TWELP vocoder types and
2400bps data rate as standard.
AES-256 Encryption (part number 15-10595) and 1200bps
and 600bps vocoder rate options (part numbers 15-10596 &
15-10597) may be added for additional capability.
NOTE:
• AES-256 Encryption option (15-10595) can be added.
• 1200 bps and Low rate Vocoder (15-10596, 15-10597) can
be added
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
• This option is also available as a retro fit kit (part number
15-10591).
Envoy X1 Options
15-10596 Opt 1200 bps Vocoder
Strongly recommended optional 1200 bps vocoder data rate
for Digital Voice option (part number 15-10591-000),
enabling digital voice to operate in highly degraded channel
conditions.
Envoy X1 Options
15-10597 Opt Low rate Vocoder
Optional 600 bps vocoder data rate for Digital Voice option
(part number 15-10591-000), enabling digital voice to
operate in highly degraded channel conditions.
Continued on the next page
Page 6 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X1 Configurations
ENVOY™ X1 OPTIONS cont. Envoy X1 Options
PRODUCT PART NO. DESCRIPTION
Envoy X1 Options
15-10595 Opt AES-256 Encryption
Adds AES-256 Encryption, with support for up to 256
preloaded keys. Suitable for use in conjunction with the MIL-
STANAG 2G Data and Digital Voice options (part numbers 15-
10591, 15-10589, 15-10590).
NOTE:
• KMS/KFS Key Fill Software recommended (see page 48, Key
Management Software).
15-10564-000 Opt CES-128 Encryptor Module (Factory Fit)
High grade Voice Encryptor Module that provides high grade
voice security with exceptional recovered audio quality.
NOTE:
• This option is also available as a retro fit kit (part number
15-10564).
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
15-10582 Opt 500 Hz Filter
500 Hz filter software filter for narrow band operation e.g.
Morse Code.
Codan Radio Communications Commercial Product Catalogue Page 7
Issue 8 January 2015
Envoy™ X2 Configurations
ENVOY™ X2 TRANSCEIVER Envoy X2 Transceiver
PRODUCT PART NO. DESCRIPTION
ENVOY-X2-TCVR
Envoy X2 Transceiver
08-07218-002
08-07000-001
15-00149
15-00649
08-06022-001
30-11208-000
15-04177-
##
06-02809-EN
Envoy™ X2 Transceiver
The Envoy™ X2 Transceiver is a state-of-the-art software
defined HF transceiver delivering high performance voice and
data communications and systems capabilities for both base
and mobile applications.
The X2 Transceiver can be used with the 2221 or 2220
Handset or 2230 Desk Console. Both handset types and the
desk console incorporate the new large format colour display
and intuitive icon based menu system providing ease of use
and programming.
The standard transceiver consists of the parts listed below.
The following pages detail the parts required for Envoy™ X2
Mobile and Base configurations.
COMPRISING:
•Envoy
TM X2 2210 RF Unit
•Envoy
TM 2220 Handset
•Envoy
TM 2220 Handset Cradle
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
• Self Adhesive Rubber Feet (x4)
•Envoy
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
•Envoy
TM Quick Reference Card
STANDARD FEATURES:
• 1000 channels, 1.6 to 30 MHz, 20 scan groups
• 500 Contact List entries
• Simultaneous scanning of multiple scan groups
• 125 W PEP, 12 V DC, USB/LSB/AM
• Ethernet/USB connectivity
• 15-way general purpose interface port (GPIO) for systems
and accessory connectivity
• English language graphical user interface
• Codan Selcall (including Diagnostic, Phone and Emergency
Call types)
•GPS receiver port
• In-built EasitalkTM speech noise reduction
• MIL-STD-810G for Drop, Dust, Shock, Vibration
AVAILABLE OPTIONS & ACCESSORIES:
See pages 10 and 45 for Envoy X2 Options and Transceiver
Accessories.
##
denotes language version
Page 8 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X2 Configurations
ENVOY™ X2 MOBILE Envoy X2 Mobile
PRODUCT PART NO. DESCRIPTION
ENVOY-X2-MOB Envoy™ X2 Mobile Configuration
The Envoy™ X2 Mobile Configuration consists of an Envoy™
Transceiver, a 3040 Automatic Tuning Whip Antenna and
cables, and vehicle installation hardware kit.
08-07218-002
08-07000-001
15-00149
15-00649
08-06022-001
15-04177-
##
06-02809-EN
COMPRISING:
Envoy™ X2 Transceiver
•Envoy
TM X2 2210 RF Unit
•Envoy
TM 2220 Handset
•Envoy
TM 2220 Handset Cradle
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
•Envoy
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
•Envoy
TM Quick Reference Card
08-07007-001
08-05627-006
08-01503-006
08-07148-001
78-18058
78-23085
78-23086
15-60012
3040 Automatic Tuning Whip with 6 m Cables
The 3040 consists of the following parts. See page 89 for
additional 3040 accessories.
3040 Main Assembly
Control NGTTM /EnvoyTM to 9350/304X Cable, 6 m
Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
3040 Spring
Riser, Fibreglass
3040 Fibreglass Whip, 1.6 m
3040 Stainless Steel Whip 1.65 m
3040 Automatic Whip Antenna Installation Handbook, c/w
antenna connector sealing kit
15-00130 NGT™/Envoy™ RF Cradle & Battery Cable
Includes mounting cradle, fuse holder and fuse, earth wire
and 6 m battery cable.
15-00112 Complete Vehicle Installation Hardware Kit
Includes assorted screws, cable ties and grommets.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 10 and 51 for Envoy X2 Options and Mobile
Accessories.
Codan Radio Communications Commercial Product Catalogue Page 9
Issue 8 January 2015
Envoy™ X2 Configurations
# denotes the cable variant depending upon country of use
##
denotes language version
ENVOY™ X2 BASE Envoy X2 Base
PRODUCT PART NO. DESCRIPTION
ENVOY-X2-BASE Envoy™ X2 Base Station Configuration
The Envoy™ Base Station Configuration consists of an Envoy™
Transceiver, a TFD411 Antenna, 3020 Heavy Duty Transceiver
Supply, and cables.
08-07218-002
08-07204-001
15-60025
08-07205-006
30-11208-000
15-04177-
##
06-02809-EN
COMPRISING:
Envoy™ X2 Transceiver
•Envoy
TM X2 2210 RF Unit
•Envoy
TM 2230 Desk Console
• 2230 Desk Console Boom Microphone
• Envoy™ Console to RF Unit Cable, 6 m
• Self Adhesive Rubber Feet (x4)
•Envoy
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
•Envoy
TM Quick Reference Card
15-00411-004 TFD411 Antenna 125 W, 2–30 MHz, 34 m
The antenna can be mounted horizontally between two
support systems, or as an inverted “V” using a single central
support mast.
NOTE:
Mast is not included. For masts, see page 107, Antenna Masts.
08-01503-030 Coax Assembly Cable, UHF Type Connectors, RG58, 30 m
30 m of high quality RG58 coaxial cable terminated with
waterproof UHF style connectors.
78-20022 3020 Transceiver Supply
Power supply to convert AC Mains into 13.8 V DC to power
the X2 Transceiver.
67-9030# Power IEC Cable, 2 m
Used to connect 3020 Transceiver Supply to AC Mains source.
For cable options, see page 83, 3020 Transceiver Supply.
05-06374 Earth Braid, 1.5 m
Used to connect X2 RF Unit to ground point.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 10 and 53 for Envoy X2 Options and Base
Accessories.
Page 10 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X2 Configurations
ENVOY™ X2 OPTIONS Envoy X2 Options
PRODUCT PART NO. DESCRIPTION
Envoy X2 Options
15-10560 Opt FED-STD-1045 ALE/CALM™
Fully compatible with FED-STD-1045 ALE capabilities and
enhanced with Codan Automated Link Management
(CALM™). Standard call types include: Selective Call, All Call,
Phone Call, Message Call, Diagnostic Call, Emergency Call.
15-10568 Opt MIL-STD-188-141B ALE Full
This option provides full MIL-STD-188-141B ALE capability,
including all capabilities provided by the
FED-STD-1045 (part number 15-10560) option above.
Additional call types include, NET Call, ANY Call, Group Call,
Wildcard Call, in-link AMD Message Calls, as well as an
advanced ALE beacon and Last Heard station log.
15-10569 Opt MIL-STD-188-141B Upgrade
This option is used to order a factory password to field
upgrade an Envoy Transceiver that already has FED-STD-1045
ALE/CALM™ enabled but requires MIL-STD-188-141B
capability.
NOTE:
This part should only be used for ordering field
upgrade passwords.
15-10558 Opt, Default Open Selcall
15-10561 Opt GPS Calling
Enables sending and receiving of GPS position information
using Selcall or ALE (if enabled).
NOTE:
This feature is compatible with GPS receivers providing
NMEA 0183 V2.0 (or later) output format. A GPS receiver is
not supplied as part of this option.For a description of the GPS
receiver available from Codan, see page 51, Mobile
Accessories.
15-10559 Opt 2400 bps Internal Data Modem
Enables the embedded software modem providing robust
error free point to point data communications. Supports
simple AT command interface or full feature HF Email/Chat
applications, see page 59, Data & Email for more details.
Recommend to include Option Fan (part number 15-10469-
000)
15-10518 Opt Amateur Mode
Enables transmit within designated HF Amateur frequency
bands when using the Free Tune Receiver mode.
15-10599 Opt Dari Language
Enables Dari Language user interface as a user selectable
option for any control point (2221/2220 Handset or 2230
Desktop Console) connected to the RF Unit.
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 11
Issue 8 January 2015
Envoy™ X2 Configurations
ENVOY™ X2 OPTIONS Envoy X2 Options
PRODUCT PART NO. DESCRIPTION
15-10600 Opt Russian Language
Enables Russian Language user interface as a user selectable
option for any control point (2221/2220 Handset or 2230
Desktop Console) connected to the RF Unit.
15-10580 Opt Spanish Language
Enables Spanish Language user interface as a user selectable
option for any control point (2221/2220 Handset or 2230
Desktop Console) connected to the RF Unit.
15-10601 Opt French Language
Enables French Language user interface as a user selectable
option for any control point (2221/2220 Handset or 2230
Desktop Console) connected to the RF Unit.
15-10513 Opt 100 W
Sets maximum transmit power to 100 watts.
15-10481 Opt TxD, Tx Program Disabled
Disables keypad programming of new transmit frequencies.
For use in countries where front panel programming is
prohibited by regulatory authorities, e.g. USA and Australia.
15-10491 Opt TxP, Tx Program Prohibited
Prohibits keypad programming of new transmit and receive
frequencies.
15-10582 Opt 500 Hz Filter
500 Hz filter software filter for narrow band operation e.g.
Morse Code.
15-10562 Opt 2.7 kHz Filter
2.7 kHz wideband software filter. Recommended for use with
2G data and Digital Voice options (15-10589-000, 15-10590-
000, 15-105491-000) and RM50e external data modem.
15-10583 Opt 3 kHz Filter
3 kHz wideband software filter.
15-10563 Opt Voice Scrambler (CIVS)
Codan Integrated Voice Scrambler used to provide basic level
voice security capability.
Continued on the next page
Page 12 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X2 Configurations
ENVOY™ X2 OPTIONS cont. Envoy X2 Options
PRODUCT PART NO. DESCRIPTION
15-10589-000 Opt MIL-STANAG 2G Data (Factory Fit)
Enables integrated data modem capability according to MIL-
STD-110-188A/B and STANAG 4539. This provides a range of
military spec data waveforms from 75 to 9600 bps
uncompressed, capable of operating across varying channel
conditions. The modem utilises adaptive equalisation and
turbo-decoding for maximum performance. Provides efficient
email over HF when used in conjunction with RC50-C email
gateway (part number 15-04161-CD), see page 58, “RC50-C
HF Email Software”.
NOTE:
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
• 2.7 kHz filter (15-10562) is recommended for optimum data
performance.
• AES-256 Encryption option (15-10595) can be added.
• Retro Kit: 15-10589.
15-10590-000 Opt MIL-STANAG 2G Data and Digital Voice (Factory Fit)
Integrates the MIL/STANAG 2G Data and Digital Voice
options. Requires RC50-C email gateway (part number 15-
04161-CD) for data operation, see page 58, “RC50-C HF Email
Software”.
NOTE:
• AES-256 Encryption option (15-10595) can be added.
• 1200 bps and Low rate Vocoder (15-10596, 15-10597) can
be added.
• 2.7 kHz filter (15-10562) is recommended for optimum data
and digital voice performance.
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
• Retro Kit: 15-10590.
15-10598 Opt ISB
Enables Independent Sideband operation when used in
conjunction with 2G data options (15-10589-000 and 15-
10590-000) and RC50-C HF Email Software. Provides data
rates of up 19200 bps.
NOTE:
• On air compatible with ISB data option in the NGT SRx
transceiver, see page 35
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 13
Issue 8 January 2015
Envoy™ X2 Configurations
ENVOY™ X2 OPTIONS cont. Envoy X2 Options
PRODUCT PART NO. DESCRIPTION
Envoy X1 Options
15-10591-000 Opt Digital Voice (Factory Fit)
Enables digital voice capability. Digital voice provides highly
intelligible audio, free from background noise, interference,
and fading effects often experienced with analogue voice.
Supplied standard with MELPe and TWELP vocoder types and
2400 bps data rate as standard.
NOTE:
• AES-256 Encryption option (15-10595) can be added.
• 1200 bps and Low rate Vocoder (15-10596, 15-10597) can
be added.
• 2.7 kHz filter (15-10562) is recommended for optimum
digital voice performance.
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
• This option is also available as a retro fit kit (part number
15-10591).
Envoy X1 Options
15-10596 Opt 1200 bps Vocoder
Strongly recommended optional 1200 bps vocoder data rate
for Digital Voice option (part number 15-10590-000 or 15-
10591-000), enabling digital voice to operate in highly
degraded channel conditions.
Envoy X1 Options
15-10597 Opt Low rate Vocoder
Optional 600 bps vocoder data rate for Digital Voice option
(part number 15-10590-000 or 15-10591-000), enabling
digital voice to operate in highly degraded channel
conditions.
Envoy X1 Options
15-10595 Opt AES-256 Encryption
Adds AES-256 Encryption, with support for up to 256
preloaded keys. Suitable for use in conjunction with the MIL-
STANAG 2G Data and Digital Voice options (part numbers 15-
10591, 15-10589, 15-10590).
NOTE:
• KMS/KFS Key Fill Software recommended (see page 48, Key
Management Software).
Continued on the next page
Page 14 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X2 Configurations
Digital Voice and 2G Data Upgrade Selection Matrix
15-10564-000 Opt CES-128 Encryptor Module (Factory Fit)
High grade Voice Encryptor Module that provides high grade
voice security with exceptional recovered audio quality.
NOTE:
• This option is also available as a retro fit kit (part number
15-10564).
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
15-10469-000 Opt Fan (Factory Fit)
Fan unit for continuous data transmission for Envoy™/NGT™
series Transceivers.
NOTE:
This option is also available as a retro fit kit (part number
15-10469).
2G Data and DV Options
Upgrade Capabilities
1200 bps Vocoder data
rate (15-10596)
Low rate Vocoder
(15-10597)
AES-256 Encryption
(15-10595)
15-10591-000 (DV) 
15-10590-000 (2G Data & DV) 
15-10589-000 (2G Data) 
Codan Radio Communications Commercial Product Catalogue Page 15
Issue 8 January 2015
Envoy™ X1 Configurations for Australia
ENVOY™ X1 TRANSCEIVER
PRODUCT PART NO. DESCRIPTION
ENVOY-X1-TCVR-AUS Envoy X1 Transceiver
(Australia)
08-07218-001
08-07000-001
15-00149
15-00649
08-06022-001
30-11208-000
15-10572
15-04177-EN
06-02809-EN
Envoy™ X1 Transceiver
The Envoy™ X1 Transceiver is a state-of- the-art software
defined HF transceiver that delivers high performance but
cost-effective voice communications for both base and
mobile applications.
The X1 Transceiver can be used with the 2221 or 2220
Handset or 2230 Desk Console. Both handset types and
the desk console incorporate the new large format colour
display and intuitive icon based menu system providing
ease of use and programming.
NOTE: The GPIO connector on the Envoy™ X1 Transceiver
does not support any peripherals apart from a
Morse Code Key.
The standard transceiver consists of the parts listed
below. The following pages detail the parts required for
Envoy™ X1 Mobile and Base configurations.
NOTE:
• In Envoy™ X1 Mobile configurations, rubber feet
(part number 30-11208-000) are not included.
• In the Envoy™ X1 Base (with Console) configuration
(ENVOY-X1-CONS-AUS), the handset cradle, external
speaker and control cable (part numbers 15-00149,
15-00649 and 08-06022-001) are not included.
COMPRISING:
•Envoy
TM X1 2210 RF Unit
•Envoy
TM 2221 Limited Keyset Handset
•Envoy
TM 2220 Handset Cradle
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
• Self Adhesive Rubber Feet (x4)
• Option for Australia, X1
•Envoy
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
•Envoy
TM Quick Reference Card
STANDARD FEATURES:
• 400 channels, 1.6 to 30 MHz, 20 scan groups
• 250 Contact List entries
• Simultaneous scanning of multiple scan groups
• 100 W PEP, 12 V DC, USB/LSB/AM
• Ethernet/USB connectivity
• English language graphical user interface
• Codan Selcall (including Diagnostic, Phone and
Emergency Call types)
•GPS receiver port
• In-built EasitalkTM speech noise reduction
• MIL-STD-810G for Drop, Dust, Shock, Vibration
AVAILABLE OPTIONS & ACCESSORIES:
See pages 4 and 45 for Envoy™ X1 Options and Transc eiv er
Accessories.
Page 16 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X1 Configurations for Australia
Envoy X1 Packages for Australia
PART PART NO. ENVOY™ X1 PACKAGES
Explorer
Mobile
ENVOY-X1-
MOB-EXPLORER-
AUS
Mobile
(3040)
ENVOY-X1-
MOB-3040-AUS
Venturer
Mobile
ENVOY-X1-
MOB-
VENTURER-AUS
Mobile
(9350)
ENVOY-X1-
MOB-9350-AUS
Base
ENVOY-X1-
BASE-AUS
Base (with
Console)
ENVOY-X1-
CONS-AUS
CONSOLE
2230 Desk Console &
Boom Microphone 08-07204-001
15-60025
Cable, Envoy™ Console to
RF Unit, 6 m 08-07205-006
ANTENNAS
3040 Main Assembly 08-07007-001 
Riser, Fibreglass, 0.8 m 78-18058 
3040 Fibreglass Whip,
1.6 m 78-23085
3040 Stainless Steel
Whip, 1.65 m 78-23086 
3040 Spring 08-07148-001 
9350 Main Assembly 08-05063-001 
9350 Fibreglass Whip,
1.6 m 78-23007-003
9350 Tapered Stainless
Steel Whip, 1.65 m 78-23056
9350 Tapered Stainless
Steel Whip, 1.2 m 78-23025
9350 Spring 08-05140-001
Ant, TFD411, 125 W,
2–30 MHz, 34 m 15-00411-004 
INSTALLATION HARDWARE
NGT™/Envoy™ RF Cradle
& Battery Cable 15-00130 
Complete Vehicle
Installation Hardware Kit 15-00112 
3040 Installation
Handbook (includes
sealing kit)
15-60012 
Automatic Tuning Whip
Antenna 9350
Installation Handbook
15-04142-EN 
CABLES
Control NGT™/Envoy™ to
9350/304X Cable, 6 m 08-05627-006 
Coax Assembly Cable,
UHF Connectors RG58,
6 m
08-01503-006 
Coax Assembly Cable,
UHF Type Connectors,
RG58, 30 m
08-01503-030 
Earth Braid, 1.5 m 05-06374 
TRANSCEIVER SUPPLY
3020 Transceiver Supply 78-20022 
Power IEC Cable 67-90305 
Codan Radio Communications Commercial Product Catalogue Page 17
Issue 8 January 2015
Envoy™ X2 Configurations for Australia
ENVOY™ X2 TRANSCEIVER
PRODUCT PART NO. DESCRIPTION
ENVOY-X2-TCVR-AUS
Envoy X2 Transceiver (Australia)
08-07218-002
08-07000-001
15-00149
15-00649
08-06022-001
30-11208-000
15-10573
15-04177-EN
06-02809-EN
Envoy™ X2 Transceiver
The Envoy™ X2 Transceiver is a state-of-the-art software
defined HF transceiver delivering high performance voice and
data communications and systems capabilities for both base
and mobile applications.
The X2 Transceiver can be used with the 2221 or 2220
Handset or 2230 Desk Console. Both handset types and the
desk console incorporate the new large format colour display
and intuitive icon based menu system providing ease of use
and programming.
The standard transceiver consists of the parts listed below.
The following pages detail the parts required for Envoy™ X2
Mobile and Base configurations.
NOTE:
• In Envoy™ X2 Mobile configurations, rubber feet
(part number 30-11208-000) are not included.
• In the Envoy™ X2 Base (with Console) configuration
(ENVOY-X2-CONS-AUS), the handset cradle, external
speaker and control cable (part numbers 15-00149,
15-00649 and 08-06022-001) are not included.
COMPRISING:
•Envoy
TM X2 2210 RF Unit
•Envoy
TM 2220 Handset
•Envoy
TM 2220 Handset Cradle
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
• Self Adhesive Rubber Feet (x4)
• Option for Australia, X2
•Envoy
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
•Envoy
TM Quick Reference Card
STANDARD FEATURES:
• 1000 channels, 1.6 to 30 MHz, 20 scan groups
• 500 Contact List entries
• Simultaneous scanning of multiple scan groups
• 100 W PEP, 12 V DC, USB/LSB/AM
• Ethernet/USB connectivity
• 15-way general purpose interface port (GPIO) for systems
and accessory connectivity
• English language graphical user interface
• Codan Selcall (including Diagnostic, Phone and Emergency
Call types)
•GPS receiver port
• In-built EasitalkTM speech noise reduction
• MIL-STD-810G for Drop, Dust, Shock, Vibration
AVAILABLE OPTIONS & ACCESSORIES:
See pages 10 and 45 for Envoy X2 Options and Transceiver
Accessories.
##
denotes language version
Page 18 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Envoy™ X2 Configurations for Australia
Envoy X2 Packages for Australia
PART PART NO. ENVOY™ X2 PACKAGES
Mobile (3040)
ENVOY-X2-MOB-
3040-AUS
Mobile (9350)
ENVOY-X2-MOB-
9350-AUS
Base
ENVOY-X2-
BASE-AUS
Base (with
Console)
ENVOY-X2-
CONS-AUS
CONSOLE
2230 Desk Console & Boom
Microphone 08-07204-001
15-60025
Cable, Envoy™ Console to RF
Unit, 6 m 08-07205-006
ANTENNAS
3040 Main Assembly 08-07007-001
Riser, Fibreglass, 0.8 m 78-18058
3040 Fibreglass Whip, 1.6 m 78-23085
3040 Stainless Steel Whip,
1.65 m 78-23086
3040 Spring 08-07148-001
9350 Main Assembly 08-05063-001
9350 Fibreglass Whip, 1.6 m 78-23007-003
9350 Tapered Stainless
Steel Whip, 1.2 m 78-23025
9350 Spring 08-05140-001
Ant, TFD411, 125 W,
2–30 MHz, 34 m 15-00411-004 
INSTALLATION HARDWARE
NGT™/Envoy™ RF Cradle &
Battery Cable 15-00130 
Complete Vehicle
Installation Hardware Kit 15-00112 
3040 Installation Handbook
(includes sealing kit) 15-60012
Automatic Tuning Whip
Antenna 9350 Installation
Handbook
15-04142-EN
CABLES
Control NGT™/Envoy™ to
9350/304X Cable, 6 m 08-05627-006 
Coax Assembly Cable, UHF
Connectors RG58, 6 m 08-01503-006 
Coax Assembly Cable, UHF
Type Connectors, RG58,
30 m
08-01503-030 
Earth Braid, 1.5 m 05-06374 
TRANSCEIVER SUPPLY
3020 Transceiver Supply 78-20022 
Power IEC Cable 67-90305 
##
denotes language version
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 19
Issue 8 January 2015
NGT™ SR Configurations
NGT™ SR TRANSCEIVER
PRODUCT PART NO. DESCRIPTION
NGT-SR-TCVR
NGTTM SR Transceiver
NGT™ SR Transceiver
The NGTTM SR Transceiver is the ideal solution to meet all your
advanced system requirements, including remote control,
split-site, high power communications, or base and mobile
applications. It also accommodates the use of multiple
control points for simultaneous connection of peripheral
equipment like data modems and telephone interconnects.
The NGT™ SR comes with an RF unit, junction box, handset,
speaker, cables, and mounting accessories for easy
installation.
The transceiver incorporates the exceptional features
renowned in all Codan NGT™ Transceivers, plus advanced
calling capabilities including Emergency call, Selective call,
Phone call, Message call, Diagnostics, Remote disable and
Remote configuration.
Excellent options are available including Automatic Link
Establishment (ALE) capabilities, voice encryption, and GPS,
plus additional mounting accessories for multiple control
points.
The standard transceiver consists of the parts listed below.
The following pages detail the parts required for NGT™ SR
Mobile and Base configurations.
08-05628-001
08-05629-001
08-05630-001
15-00129
15-00649
08-05610-006
30-11208-000
15-04127-
##
COMPRISING:
•NGT
TM SR 2010 RF Unit
•NGT
TM SR 2020 Handset
•NGT
TM SR 2030 Junction Box
•NGT
TM Handset Cradle Kit
• External Speaker with 4 m Lead
• CIB Interface Cable, 6 m
• Self Adhesive Rubber Feet (x4)
•NGT
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
STANDARD FEATURES:
• 400 channels, 1.6–30 MHz, 10 networks
• Scanning of multiple networks
• 125 W PEP, 12 V DC, USB/LSB/AM
• In-built EasitalkTM speech noise reduction
• Meets MIL-STD-810F for shock, vibration and dust
AVAILABLE OPTIONS & ACCESSORIES:
See pages 22 and 45 for NGT™ SR Options and Tran sceiver
Accessories.
# denotes the cable variant depending upon country of use
##
denotes language version
Page 20 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ SR Configurations
NGT™ SR MOBILE NGT™ SR Mobile
PRODUCT PART NO. DESCRIPTION
NGT-SR-MOB NGT™ SR Mobile Configuration
The NGTTM SR Mobile Configuration consists of an NGTTM SR
Transceiver, a 3040 Automatic Tuning Whip Antenna and
cables, and vehicle installation hardware kit.
08-05628-001
08-05629-001
08-05630-001
15-00129
15-00649
08-05610-006
15-04127-
##
COMPRISING:
NGT™ SR Transceiver
•NGT
TM SR 2010 RF Unit
•NGT
TM SR 2020 Handset
•NGT
TM SR 2030 Junction Box
•NGT
TM Handset Cradle Kit
• External Speaker with 4 m Lead
• CIB Interface Cable, 6 m
•NGT
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
08-07007-001
08-05627-006
08-01503-006
08-07148-001
78-18058
78-23085
78-23086
15-60012
3040 Automatic Tuning Whip with 6 m Cables
The 3040 consists of the following parts. See page 89 for
additional 3040 accessories.
3040 Main Assembly
Control NGTTM /EnvoyTM to 9350/304X Cable, 6 m
Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
3040 Spring
Riser, Fibreglass
3040 Fibreglass Whip, 1.6 m
3040 Stainless Steel Whip, 1.65 m
3040 Automatic Whip Antenna Installation Handbook, c/w
antenna connector sealing kit
15-00130 NGT™/Envoy™ RF Cradle & Battery Cable
Includes mounting cradle, fuse holder and fuse, earth wire
and 6 m battery cable.
15-00112 Complete Vehicle Installation Hardware Kit
Includes assorted screws, cable ties and grommets.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 22 and 51 for NGT™ SR Options and Mobile
Accessories.
Codan Radio Communications Commercial Product Catalogue Page 21
Issue 8 January 2015
NGT™ SR Configurations
NGT™ SR BASE NGT™ SR Base
PRODUCT PART NO. DESCRIPTION
NGT-SR-BASE NGT™ SR Base Station Configuration
The NGTTM SR Base Station Configuration consists of an NGTTM
SR Transceiver, a a TFD411 Antenna, 3020 Heavy Duty
Transceiver Supply, desk console, and cables.
08-05628-001
08-05629-001
08-05630-001
15-10471-000
08-05610-006
30-11208-000
15-04127-
##
COMPRISING:
NGT™ SR Transceiver
•NGT
TM SR 2010 RF Unit
•NGT
TM SR 2020 Handset
•NGT
TM SR 2030 Junction Box
•NGT
TM SR Desk Console
• CIB Interface Cable, 6 m
• Self Adhesive Rubber Feet (x4)
•NGT
TM Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
15-00411-004 TFD411 Antenna 125 W, 2–30 MHz, 34 m
The antenna can be mounted horizontally between two
support systems, or as an inverted “V” using a single central
support mast.
NOTE:
Mast is not included. For masts, see page 107, Antenna Masts.
08-01503-030 Coax Assembly Cable, UHF Type Connectors, RG58, 30 m
30 m of high quality RG58 coaxial cable terminated with
waterproof UHF style connectors.
78-20022 3020 Transceiver Supply
Power supply to convert AC Mains into 13.8 V DC to power
the Transceiver.
67-9030# Power IEC Cable, 2 m
Used to connect 3020 Transceiver Supply to AC Mains source.
For cable options, see page 83, 3020 Transceiver Supply.
05-06374 Earth Braid, 1.5 m
Used to connect the RF Unit to ground point.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 22 and 53 for NGT™ SR Options and Base
Accessories.
Page 22 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ SR Configurations
NGT™ SR OPTIONS NGT™ SR Options
PRODUCT PART NO. DESCRIPTION
15-10479 Opt FED-STD-1045 ALE/CALM™
Fully compatible with FED-STD-1045 ALE capabilities and
enhanced with Codan Automated Link Management
(CALM™). Standard call types include: Selective Call, All Call,
Phone Call, Message Call, Diagnostic Call, Emergency Call.
15-10558 Opt, Default Open Selcall
15-10486 Opt GPS Calling
Enables sending and receiving of GPS position information
using Selcall or ALE (if enabled).
NOTE:
This feature is compatible with GPS receivers providing
NMEA 0183 V2.0 (or later) output format. A GPS receiver is
not supplied as part of this option.
For a description of the GPS receiver available from Codan,
see page 51, Mobile Accessories.
15-10504-000 Opt External ALC (Factory Fit)
Required when using an NGTTM high power system.
NOTE:
This option is also available as a retro fit kit (part number
15-10504).
15-10513 Opt 100 W
Reduces maximum transceiver output power to 100 W.
15-10481-000 Opt TxD, Tx Program Disabled (Factory Fit)
Disables keypad programming of new transmit frequencies.
For use in countries where front panel programming is
prohibited by regulatory authorities,
e.g. USA and Australia.
15-10491-000 Opt TxP, Tx Program Prohibited (Factory Fit)
Prohibits keypad programming of new transmit and receive
frequencies.
15-10541-000 Opt High Speed Data (Factory Fit)
Hardware modification required for use with Codan HF Data
Modems using high speed waveforms (RM50e, 3212).
15-10551 Opt Voice Scrambler (CIVS)
Codan Integrated Voice Scrambler used to provide basic level
voice security capability.
NGT™ SR Options Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 23
Issue 8 January 2015
NGT™ SR Configurations
NGT™ SR OPTIONS cont. NGT™ SR Options
PRODUCT PART NO. DESCRIPTION
15-10507-000 Opt Voice Encryptor (Factory Fit)
High grade Voice Encryptor Module for NGTTM series
Transceivers. Provides high grade voice security with
exceptional recovered audio quality.
NOTE:
• This option is also available as a retro fit kit (part number
15-10507).
• This option is subject to Australian Defence Export Controls.
A signed End-User Declaration must be provided for supply
of this option.
15-10552-000 Opt AES-256 DV Encryptor Module (Factory Fit)
Digital Voice Encryptor module providing excellent digital
voice quality and high grade AES-256 bit encryption.
Selectable vocoder rates of 1200 and 2400 bps are available
as standard.
NOTE:
• This option is also available as a retro fit kit (part number
15-10552).
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
15-10506-000 Opt 500 Hz BW Filter (Factory Fit)
500 Hz narrow band filter. Recommended for use with CW
(morse code).
15-10514-000 Opt 2.7 kHz BW Second Filter (Factory Fit)
2.7 kHz wide band filter. Required for use with Codan RM50e
HF Data Modems.
15-10469-000 Opt Fan (Factory Fit)
Fan unit for continuous data transmission for EnvoyTM /NGTTM
series Transceivers.
NOTE:
This option is also available as a retro fit kit (part number
15-10469).
Page 24 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ SR Configurations
This page has been intentionally left blank.
Codan Radio Communications Commercial Product Catalogue Page 25
Issue 8 January 2015
NGT™ ASR Configurations
NGT™ ASR TRANSCEIVER
PRODUCT PART NO. DESCRIPTION
NGT-ASR-TCVR
NGT™ ASR Transceiver
NGT™ ASR Transceiver
The NGTTM ASR Transceiver is specifically designed for
interoperability with non-Codan HF transceiver systems. The
NGT™ ASR supports MIL-STD-188-141B advanced Automatic
Link Establishment, which has been certified for
interoperability by the US Joint Interoperability Test
Command (JITC). It is suitable for advanced system
configurations in base and mobile applications, and supports
HF data modems using advanced military waveforms.
The NGT™ ASR comes with an RF unit, junction box, handset,
speaker, cables, and mounting accessories for easy
installation. It incorporates the exceptional features
renowned in all Codan NGT™ Transceivers, plus GPS, high
power, encryption, and advanced calling capabilities.
The standard transceiver consists of the parts listed below.
The following pages detail the parts required for NGT™ ASR
Mobile and Base configurations.
08-05628-007
08-05629-007
08-05630-007
15-00129
15-00649
08-05610-006
30-11208-000
15-10486
15-10514-000
15-10541-000
15-04137-EN
COMPRISING:
•NGT
TM ASR 2010 RF Unit
•NGT
TM ASR 2020 Handset
•NGT
TM ASR 2030 Junction Box
•NGT
TM Handset Cradle Kit
• External Speaker with 4 m Lead
• CIB Interface Cable, 6 m
• Self Adhesive Rubber Feet (x4)
• Opt GPS Calling
• Opt 2.7 kHz BW Second Filter (Factory Fit)
• Opt High Speed Data (Factory Fit)
•NGT
TM ASR Transceiver Getting Started Guide, includes
Reference Manual on CDROM (English)
STANDARD FEATURES:
• US FCC and NTIA approved
• MIL-STD-188-141B ALE included
• Last Heard Log and manual sounding
• 600 channels, 1.6–30 MHz, 20 networks
• Scanning of multiple networks
• 125 W PEP, 12 V DC, USB/LSB/AM
• In-built EasitalkTM speech noise reduction
• Meets MIL-STD-810F for shock, vibration and dust
AVAILABLE OPTIONS & ACCESSORIES:
See pages 28 and 45 for NGT™ ASR Options and Transceiver
Accessories.
# denotes the cable variant depending upon country of use
Page 26 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ ASR Configurations
NGT™ ASR MOBILE NGT™ ASR Mobile
PRODUCT PART NO. DESCRIPTION
NGT-ASR-MOB NGT™ ASR Mobile Configuration
The NGTTM ASR Mobile Configuration consists of an NGTTM ASR
Transceiver, a 3040 Automatic Tuning Whip Antenna and
cables, and vehicle installation hardware kit.
08-05628-007
08-05629-007
08-05630-007
15-00129
15-00649
08-05610-006
15-10486
15-10514-000
15-10541-000
15-04137-EN
COMPRISING:
NGT™ ASR Transceiver
•NGT
TM ASR 2010 RF Unit
•NGT
TM ASR 2020 Handset
•NGT
TM ASR 2030 Junction Box
•NGT
TM Handset Cradle Kit
• External Speaker with 4 m Lead
• CIB Interface Cable, 6 m
• Opt GPS Calling
• Opt 2.7 kHz BW Second Filter (Factory Fit)
• Opt High Speed Data (Factory Fit)
•NGT
TM ASR Transceiver Getting Started Guide, includes
Reference Manual on CDROM (English)
08-07007-001
08-05627-006
08-01503-006
08-07148-001
78-18058
78-23085
78-23086
15-60012
3040 Automatic Tuning Whip with 6 m Cables
The 3040 consists of the following parts. See page 89 for
additional 3040 accessories.
3040 Main Assembly
Control NGTTM /EnvoyTM to 9350/304X Cable, 6 m
Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
3040 Spring
Riser, Fibreglass
3040 Fibreglass Whip, 1.6 m
3040 Stainless Steel Whip, 1.65 m
3040 Automatic Whip Antenna Installation Handbook, c/w
antenna connector sealing kit
15-00130 NGT™/Envoy™ RF Cradle & Battery Cable
Includes mounting cradle, fuse holder and fuse, earth wire
and 6 m battery cable.
15-00112 Complete Vehicle Installation Hardware Kit
Includes assorted screws, cable ties and grommets.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 28 and 51 for NGT™ ASR Options and Mobile
Accessories.
Codan Radio Communications Commercial Product Catalogue Page 27
Issue 8 January 2015
NGT™ ASR Configurations
NGT™ ASR BASE NGT™ ASR Base
PRODUCT PART NO. DESCRIPTION
NGT-ASR-BASE NGT™ ASR Base Station Configuration
The NGTTM ASR Base Station Configuration consists of an
NGTTM ASR Transceiver, a TFD411 Antenna, 3020 Heavy Duty
Transceiver Supply, desk console, and cables.
08-05628-007
08-05629-007
08-05630-007
15-10471-000
08-05610-006
30-11208-000
15-10486
15-10514-000
15-10541-000
15-04137-EN
COMPRISING:
NGT™ ASR Transceiver
•NGT
TM ASR 2010 RF Unit
•NGT
TM ASR 2020 Handset
•NGT
TM ASR 2030 Junction Box
•NGT
TM ASR Desk Console
• CIB Interface Cable, 6 m
• Self Adhesive Rubber Feet (x4)
• Opt GPS Calling
• Opt 2.7 kHz BW Second Filter (Factory Fit)
• Opt High Speed Data (Factory Fit)
•NGT
TM ASR Transceiver Getting Started Guide, includes
Reference Manual on CDROM (English)
15-00411-004 TFD411 Antenna 125 W, 2–30 MHz, 34 m
The antenna can be mounted horizontally between two
support systems, or as an inverted “V” using a single central
support mast.
NOTE:
Mast is not included. For masts, see page 107, Antenna Masts.
08-01503-030 Coax Assembly Cable, UHF Type Connectors, RG58, 30 m
30 m of high quality RG58 coaxial cable terminated with
waterproof UHF style connectors.
78-20022 3020 Transceiver Supply
Power supply to convert AC Mains into 13.8 V DC to power
the Transceiver.
67-9030# Power IEC Cable, 2 m
Used to connect 3020 Transceiver Supply to AC Mains source.
For cable options, see page 83, 3020 Transceiver Supply.
05-06374 Earth Braid, 1.5 m
Used to connect the RF Unit to ground point.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 28 and 53 for NGT™ ASR Options and Base
Accessories.
Page 28 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ ASR Configurations
NGT™ ASR OPTIONS NGT™ ASR Options
PRODUCT PART NO. DESCRIPTION
15-10504-000
NGT™ ASR Options
Opt External ALC (Factory Fit)
Required when using an NGTTM high power system.
NOTE:
This option is also available as a retro fit kit (part number
15-10504).
15-10513 Opt 100 W
Reduces maximum transceiver output power to 100 W.
15-10481-000 Opt TxD, Tx Program Disabled (Factory Fit)
Disables keypad programming of new transmit frequencies.
For use in countries where front panel programming is
prohibited by regulatory authorities, e.g. USA and Australia.
15-10491 Opt TxP, Tx Program Prohibited
Prohibits keypad programming of new transmit and receive
frequencies.
15-10541-000 Opt High Speed Data (Factory Fit)
Hardware modification required for use with Codan HF Data
Modems using high speed waveforms (RM50e, 3212).
15-10551 Opt Voice Scrambler (CIVS)
Codan Integrated Voice Scrambler used to provide basic level
voice security capability.
15-10507-000 Opt Voice Encryptor (Factory Fit)
High grade Voice Encryptor Module for NGTTM series
Transceivers. Provides high grade voice security with
exceptional recovered audio quality.
NOTE:
• This option is also available as a retro fit kit (part number
15-10507).
• This option is subject to Australian Defence Export Controls.
A signed End-User Declaration must be provided for supply
of this option.
15-10552-000 Opt AES-256 DV Encryptor Module (Factory Fit)
Digital Voice Encryptor module providing excellent digital
voice quality and high grade AES-256 bit encryption.
Selectable vocoder rates of 1200 and 2400 bps are available
as standard.
NOTE:
• This option is also available as a retro fit kit (part number
15-10552).
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 29
Issue 8 January 2015
NGT™ ASR Configurations
NGT™ ASR OPTIONS CONT. NGT™ ASR Options
PRODUCT PART NO. DESCRIPTION
15-10506-000 Opt 500 Hz BW Filter (Factory Fit)
500 Hz narrow band filter. Recommended for use with CW
(morse code).
15-10514-000 Opt 2.7 kHz BW Second Filter (Factory Fit)
2.7 kHz wide band filter. Required for use with Codan RM50e
HF Data Modems.
15-10469-000 Opt Fan (Factory Fit)
Fan unit for continuous data transmission for EnvoyTM /NGTTM
series Transceivers.
NOTE:
This option is also available as a retro fit kit (part number
15-10469).
##
denotes language version
Page 30 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ ASR Configurations
This page has been intentionally left blank.
##
denotes language version
Codan Radio Communications Commercial Product Catalogue Page 31
Issue 8 January 2015
NGT™ SRx Configurations
NGT™ SRx TRANSCEIVER
PRODUCT PART NO. DESCRIPTION
NGT-SRX-TCVR
08-05628-009
08-05629-009
15-00129
15-00649
08-06022-001
30-11208-000
15-04140-
##
NGT™ SRx Transceiver
The NGTTM SRx Transceiver, capable of voice, email, fax, GPS
tracking, telephone interconnection and high power
communications, is the ideal solution to meet your modern
HF needs — all in a single cost effective unit.
The SRx comes with an RF unit, handset, speaker, cables, and
mounting accessories for easy installation.
The transceiver incorporates the exceptional features
renowned in all Codan NGT™ Transceivers, plus advanced
calling capabilities including Emergency call, Selective call,
Phone call, Message call, Diagnostics, Remote disable and
Remote configuration.
Excellent options are available including Automatic Link
Establishment (ALE) capabilities, voice encryption, and GPS,
plus additional mounting accessories.
The standard transceiver consists of the parts listed below.
The following pages detail the parts required for NGT™ SRx
Mobile and Base configurations.
COMPRISING:
•NGT
TM SRx 2012 RF Unit
•NGT
TM SRx 2020 Handset
•NGT
TM Handset Cradle Kit
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
• Self Adhesive Rubber Feet (x4)
•NGT
TM SRx Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
STANDARD FEATURES:
• General Purpose Interface Port (GPIO)
• 400 channels, 1.6–30 MHz, 10 networks
• Scanning of multiple networks
• 125 W PEP, 12 V DC, USB/LSB/AM
• In-built EasitalkTM speech noise reduction
• Morse capability
• Meets MIL-STD-810F for shock, vibration and dust
AVAILABLE OPTIONS & ACCESSORIES:
See pages 34 and 45 for NGT™ SRx Options and Transceiver
Accessories.
# denotes the cable variant depending upon country of use
##
denotes language version
DISCONTINUED
Page 32 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ SRx Configurations
NGT™ SRx MOBILE NGT™ SRx Mobile
PRODUCT PART NO. DESCRIPTION
NGT-SRX-MOB NGT™ SRx Mobile Configuration
The NGTTM SRx Mobile Configuration consists of an NGTTM SRx
Transceiver, a 9350 Automatic Tuning Whip Antenna and
cables, and vehicle installation hardware kit.
08-05628-009
08-05629-009
15-00129
15-00649
08-06022-001
15-04140-
##
COMPRISING:
NGT™ SRx Transceiver
•NGT
TM SRx 2012 RF Unit
•NGT
TM SRx 2020 Handset
•NGT
TM Handset Cradle Kit
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
•NGT
TM SRx Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
08-07007-001
08-05627-006
08-01503-006
08-07148-001
78-18058
78-23085
78-23086
15-60012
3040 Automatic Tuning Whip with 6 m Cables
The 3040 consists of the following parts. See page 89 for
additional 3040 accessories.
3040 Main Assembly
Control NGTTM /EnvoyTM to 9350/304X Cable, 6 m
Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
3040 Spring
Riser, Fibreglass
3040 Fibreglass Whip, 1.6 m
3040 Stainless Steel Whip, 1.65 m
3040 Automatic Whip Antenna Installation Handbook, c/w
antenna connector sealing kit
15-00130 NGT™/Envoy™ RF Cradle & Battery Cable
Includes mounting cradle, fuse holder and fuse, earth wire
and 6 m battery cable.
15-00112 Complete Vehicle Installation Hardware Kit
Includes assorted screws, cable ties and grommets.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 34 and 51 for NGT™ SRx Options and Mobile
Accessories.
DISCONTINUED
Codan Radio Communications Commercial Product Catalogue Page 33
Issue 8 January 2015
NGT™ SRx Configurations
NGT™ SRx BASE NGT™ SRx Base
PRODUCT PART NO. DESCRIPTION
NGT-SRX-BASE NGT™ SRx Base Station Configuration
The NGTTM SRx Base Station Configuration consists of an
NGTTM SRx Transceiver, a TFD411 Antenna, 3020 Heavy Duty
Transceiver Supply, and cables.
08-05628-009
08-05629-009
15-00766
30-11208-000
15-04140-
##
COMPRISING:
NGT™ SRx Transceiver
•NGT
TM SRx 2012 RF Unit
•NGT
TM SRx 2020 Handset
•NGT Desk Console
• Self Adhesive Rubber Feet (x4)
•NGT
TM SRx Transceiver Getting Started Guide, includes
Reference Manual on CDROM (see page 165, Language
Support for translations of this guide)
15-00411-004 TFD411 Antenna 125 W, 2–30 MHz, 34 m
The antenna can be mounted horizontally between two
support systems, or as an inverted V using a single central
support mast.
NOTE:
Mast is not included. For masts, see page 107, Antenna Masts.
08-01503-030 Coax Assembly Cable, UHF Type Connectors, RG58, 30 m
30 m of high quality RG58 coaxial cable terminated with
waterproof UHF style connectors.
78-20022 3020 Transceiver Supply
Power supply to convert AC Mains into 13.8 V DC to power
the Transceiver.
67-9030# Power IEC Cable, 2 m
Used to connect 3020 Transceiver Supply to AC Mains source.
For cable options, see page 83, 3020 Transceiver Supply.
05-06374 Earth Braid, 1.5 m
Used to connect the RF Unit to ground point.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 34 and 53 for NGT™ SRx Options and Base
Accessories.
##
denotes language version
DISCONTINUED
Page 34 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ SRx Configurations
NGT™ SRx OPTIONS NGT™ SRx Options
PRODUCT PART NO. DESCRIPTION
NGT™ SRx Options
15-10479 Opt FED-STD-1045 ALE/CALM™
Fully compatible with FED-STD-1045 ALE capabilities and
enhanced with Codan Automated Link Management
(CALM™). Standard call types include: Selective Call, All Call,
Phone Call, Message Call, Diagnostic Call, Emergency Call.
15-10532 Opt MIL-STD-188-141B ALE Full
This option provides full MIL-STD-188-141B ALE capability,
including all capabilities provided by the
FED-STD-1045 (part number 15-10560) option above.
Additional call types include, NET Call, ANY Call, Group Call,
Wildcard Call, in-link AMD Message Calls, as well as an
advanced ALE beacon and Last Heard station log.
15-10558 Opt, Default Open Selcall
15-10486 Opt GPS Calling
Enables sending and receiving of GPS position information
using Selcall or ALE (if enabled).
NOTE:
This feature is compatible with GPS receivers providing
NMEA 0183 V2.0 (or later) output format. A GPS receiver is
not supplied as part of this option.
For a description of the GPS receiver available from Codan,
see page 51, Mobile Accessories.
15-10504-000 Opt External ALC (Factory Fit)
Required when using an NGTTM high power system.
NOTE:
This option is also available as a retro fit kit (part number
15-10504).
15-10513 Opt 100 W
Reduces transceiver output power to 100 W.
15-10481-000 Opt TxD, Tx Program Disabled (Factory Fit)
Disables keypad programming of new transmit frequencies.
For use in countries where front panel programming is
prohibited by regulatory authorities,
e.g. USA and Australia.
15-10491 Opt TxP, Tx Program Prohibited
Prohibits keypad programming of new transmit and receive
frequencies.
Continued on the next page
##
denotes language version
DISCONTINUED
Codan Radio Communications Commercial Product Catalogue Page 35
Issue 8 January 2015
NGT™ SRx Configurations
NGT™ SRx OPTIONS CONT. NGT™ SRx Options
PRODUCT PART NO. DESCRIPTION
15-10541-000 Opt High Speed Data (Factory Fit)
Hardware modification required for use with Codan HF Data
Modems using high speed waveforms (RM50e, 3212).
15-10551 Opt Voice Scrambler (CIVS)
Codan Integrated Voice Scrambler used to provide basic level
voice security capability.
15-10507-000 Opt Voice Encryptor (Factory Fit)
High grade Voice Encryptor Module for NGTTM series
Transceivers. Provides high grade voice security with
exceptional recovered audio quality.
NOTE:
• This option is also available as a retro fit kit (part number
15-10507).
• This option is subject to Australian Defence Export Controls.
A signed End-User Declaration must be provided for supply
of this option.
15-10556-000
Opt ISB Processor
2012 (Factory Fit)
Opt ISB Processor 2012 (Factory Fit)
This option is used to provide Independent Sideband (ISB)
high speed data capability when the transceiver is combined
with an ISB capable RM50e HF Data Modem. Data rates of up
to 19200 bps are possible in this configuration.
NOTE:
• This option is also available as a retro fit kit
(part number 15-10556).
• Codan 3012 & 3212 HF Data Modems are not supported
when the ISB Option is fitted.
• This option is only available with NGT™ SRx &
MR Transceivers.
• On-air compatible with ISB data option in Envoy X2
transceiver, see page 12
15-10552-000 Opt AES-256 DV Encryptor Module (Factory Fit)
Digital Voice Encryptor module providing excellent digital
voice quality and high grade AES-256 bit encryption.
Selectable vocoder rates of 1200 and 2400 bps are available
as standard.
NOTE:
• This option is also available as a retro fit kit (part number
15-10552).
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
Continued on the next page
# denotes the cable variant depending upon country of use
##
denotes language version
DISCONTINUED
Page 36 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ SRx Configurations
NGT™ SRx OPTIONS CONT. NGT™ SRx Options
PRODUCT PART NO. DESCRIPTION
15-10506-000 Opt 500 Hz BW Filter (Factory Fit)
500 Hz narrow band filter. Recommended for use with CW
(morse code).
15-10514-000 Opt 2.7 kHz BW Second Filter (Factory Fit)
2.7 kHz wide band filter. Required for use with Codan RM50e
HF Data Modems.
15-10469-000 Opt Fan (Factory Fit)
Fan unit for continuous data transmission for EnvoyTM /NGTTM
series Transceivers.
NOTE:
This option is also available as a retro fit kit (part number
15-10469).
DISCONTINUED
Codan Radio Communications Commercial Product Catalogue Page 37
Issue 8 January 2015
NGT™ AR Configurations for Australia
NGT™ AR TRANSCEIVER
PRODUCT PART NO. DESCRIPTION
NGT-AR-TCVR
08-05628-003
08-05629-003
08-05630-003
15-00129
15-00649
08-05610-006
30-11208-000
15-04127-EN
NGT™ AR Transceiver
The NGTTM AR Transceiver is the ideal solution to meet all your
modern HF needs from voice, email, fax, GPS tracking, and
telephone interconnection to remote control, split-site and
high power communications. It is suitable for base and vehicle
applications, and is easy to use with an innovative, mobile
phone-like handset with one-button shortcuts. Plus Codan’s
Easitalk™ guarantees clear communications.
The AR Transceiver comes with an NGT™ RF unit, junction box,
speaker, and mounting accessories for easy installation.
The radio incorporates the exceptional features renowned in
all Codan NGT™ Transceivers, plus advanced calling capabilities
including Emergency call, Selective call, Phone call, Message call,
Diagnostics, Remote Disable and Remote Configuration.
Excellent options are available including Automatic Link
Establishment (ALE), voice encryption, and GPS, plus additional
mounting accessories.
The standard transceiver consists of the parts listed below.
The following pages detail the additional parts required for
NGT™ AR Mobile and Base configurations.
NOTE:
•In NGT™ AR Mobile configurations, rubber feet (part number
30-11208-000) are not included.
•In the NGT™ AR Base configuration (NGT-AR-BASE-CON), the
handset cradle and external speaker (part numbers 15-00129
and 15-00649) are not included.
COMPRISING:
•NGT
TM AR 2010 RF Unit
•NGT
TM AR 2020 Handset
•NGT
TM AR 2030 Junction Box
•NGT
TM Handset Cradle Kit
• External Speaker with 4 m Lead
• CIB Interface Cable, 6 m
• Self Adhesive Rubber Feet
•NGT
TM Transceiver Getting Started Guide, includes Reference
Manual on CDROM
STANDARD FEATURES:
• 400 channels, 1.6–30 MHz, 20 networks
• Scanning of multiple networks
•100WPEP, 12VDC, USB
•In-built EasitalkTM speech noise reduction
•Phone call
• Selective call
• Message call (64 characters)
• Morse capability
• Remote diagnostics with remote configuration and transmit
disable capability
• Meets MIL-STD-810F for shock, vibration and dust
AVAILABLE OPTIONS & ACCESSORIES:
See pages 39 and 45 for NGT™ AR Options and Transceiver
Accessories.
Page 38 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ AR Configurations for Australia
PART PART NO. NGT™ AR PACKAGES
Mobile (3040)
NGT-AR-MOB-3040
Mobile (9350)
NGT-AR-MOB
Base
NGT-AR-BASE-CON
CONSOLE
NGT™ AR Desk Console 15-10471-000 NGT AR Packages for Australia
ANTENNAS
3040 Main Assembly 08-07007-001
Riser, Fibreglass, 0.8 m 78-18058
3040 Fibreglass Whip, 1.6 m 78-23085
3040 Stainless Steel Whip,
1.65 m 78-23086
3040 Spring 08-07148-001
9350 Main Assembly 08-05063-001
9350 Fibreglass Whip, 1.6 m 78-23007-003
9350 Tapered Stainless
Steel Whip, 1.65 m 78-23056
9350 Tapered Stainless
Steel Whip, 1.2 m 78-23025
9350 Spring 08-05140-001
Ant, TFD411, 125 W,
2–30 MHz, 34 m 15-00411-004
INSTALLATION HARDWARE
NGT™/Envoy™ RF Cradle &
Battery Cable 15-00130 
Complete Vehicle
Installation Hardware Kit 15-00112 
3040 Installation Handbook
(includes sealing kit) 15-60012
Automatic Tuning Whip
Antenna 9350 Installation
Handbook
15-04142-EN
CABLES
Control NGT™/Envoy™ to
9350/304X Cable, 6 m 08-05627-006 
Coax Assembly Cable, UHF
Connectors RG58, 6 m 08-01503-006 
Coax Assembly Cable, UHF
Type Connectors, RG58,
30 m
08-01503-030
Earth Braid, 1.5 m 05-06374
TRANSCEIVER SUPPLY
3020 Transceiver Supply 78-20022
Power IEC Cable 67-90305
Codan Radio Communications Commercial Product Catalogue Page 39
Issue 8 January 2015
NGT™ AR Configurations for Australia
NGT™ AR OPTIONS NGT AR Options
PRODUCT PART NO. DESCRIPTION
15-10479
NGT AR
Options
Opt FED-STD-1045 ALE/CALM™
Fully compatible with FED-STD-1045 ALE capabilities and enhanced
with Codan Automated Link Management (CALM™). Includes
facilities for Selective Calls, All Calls, Phone Calls, Text Messaging
and GPS Position Calls.
15-10486 Opt GPS Calling
Enables sending and receiving of GPS position information using
Selcall or ALE (if enabled).
NOTE:
This feature is compatible with GPS receivers providing
NMEA 0183 V2.0 (or later) output format. A GPS receiver is not
supplied as part of this option.
For a description of the GPS receiver available from Codan, see
page 51, Mobile Accessories.
15-10480 Opt E
Enables digital Selective Emergency call. This is not required for
RFDS Emergency calling.
15-10504-000 Opt External ALC (Factory Fit)
Required when using an NGTTM high power system.
NOTE:
This option is also available as a retro fit kit (part number
15-10504).
15-10551 Opt Voice Scrambler (CIVS)
Codan Integrated Voice Scrambler used to provide basic level voice
security capability.
15-10469-000 Opt Fan (Factory Fit)
Fan unit for continuous data transmission for EnvoyTM /NGTTM series
Transceivers.
NOTE:
This option is also available as a retro fit kit (part number
15-10469).
Continued on the next page
Page 40 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ AR Configurations for Australia
NGT™ AR OPTIONS CONT. NGT AR Options
PRODUCT PART NO. DESCRIPTION
15-10507-000 Opt Voice Encryptor (Factory Fit)
High grade Voice Encryptor Module for NGT™ series Transceivers.
Provides high grade voice security with exceptional recovered
audio quality.
NOTE:
• This option is also available as a retro fit kit (part number
15-10507).
• This option is subject to Australian Defence Export Controls.
A signed End-User Declaration must be provided for supply of
this option outside of Australia.
15-10552-000 Opt AES-256 DV Encryptor Module (Factory Fit)
Digital Voice Encryptor module providing excellent digital voice
quality and high grade AES-256 bit encryption. Selectable vocoder
rates of 1200 and 2400 bps are available as standard.
NOTE:
• This option is also available as a retro fit kit (part number
15-10552).
• This option is subject to Australian Government Export Controls. A
signed End-User Declaration must be provided for supply of this
option.
Codan Radio Communications Commercial Product Catalogue Page 41
Issue 8 January 2015
NGT™ SRx Configurations for Australia
NGT™ SRx TRANSCEIVER NGT SRx Transceiver
PRODUCT PART NO. DESCRIPTION
NGT-SRX-TCVR-AUS
08-05628-009
08-05629-009
15-00129
15-00649
08-06022-001
30-11208-000
15-10540
15-04140-EN
NGT™ SRx Transceiver
The NGTTM SRx Transceiver is the ideal solution to meet your modern
HF needs including voice, email, fax, GPS tracking and telephone
interconnection — all in a single cost effective unit.
The SRx Transceiver comes with an NGT™ RF unit, speaker, and
mounting accessories for easy installation, and is suitable for base
and vehicle applications.
The radio incorporates the exceptional features renowned in all
Codan NGT™ radios, plus advanced calling capabilities including
Emergency call, Selective call, Phone call, Message call, Diagnostics,
Remote disable and Remote configuration. Excellent options are
available including Automatic Link Establishment (ALE) capabilities,
voice encryption, and GPS, plus additional mounting accessories.
The standard transceiver consists of the parts listed below.
The following pages detail the additional parts required for
NGT™ SRx Mobile and Base configurations.
NOTE:
In NGT™ SRx Mobile configurations, rubber feet (part number
30-11208-000) are not included.
COMPRISING:
•NGT
TM SRx 2012 RF Unit
•NGT
TM SRx 2020 Handset
•NGT
TM Handset Cradle Kit
• External Speaker with 4 m Lead
• Envoy™/NGT™ Handset Control Cable, 6 m
• Self Adhesive Rubber Feet
•Opt SRx for Australia
•NGT
TM SRx Transceiver Getting Started Guide, includes Reference
Manual on CDROM
STANDARD FEATURES:
• General Purpose Interface Port (GPIO)
• 400 channels, 1.6–30 MHz, 10 networks
• Scanning of multiple networks
• 100 W PEP, 12 V DC, USB
• In-built EasitalkTM speech noise reduction
• Phone call
•Selective call
•Message call (64 characters)
• Morse capability
• Remote diagnostics with remote configuration and transmit
disable capability
Meets MIL-STD-810F for shock, vibration and dust
AVAILABLE OPTIONS & ACCESSORIES:
• See pages 49 and 45 for NGT™ SRx Options and Transceiver
Accessories.
DISCONTINUED
Page 42 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ SRx Configurations for Australia
NGT SRx Packages for Australia
PART PART NO. NGT™ SRx PACKAGES
Mobile (3040)
NGT-SRX-MOB-3040
Mobile (9350)
NGT-SRX-MOB-AUS
Base
NGT-SRX-BASE-AUS
CONSOLE
NGT™ SRx Desk Console 15-00766 NGT AR Packages for Australia
ANTENNAS
3040 Main Assembly 08-07007-001
Riser, Fibreglass, 0.8 m 78-18058
3040 Fibreglass Whip, 1.6 m 78-23085
3040 Stainless Steel Whip,
1.65 m 78-23086
3040 Spring 08-07148-001
9350 Main Assembly 08-05063-001
9350 Fibreglass Whip, 1.6 m 78-23007-003
9350 Tapered Stainless
Steel Whip, 1.2 m 78-23025
9350 Spring 08-05140-001
Ant, TFD411, 125 W,
2–30 MHz 15-00411-004
INSTALLATION HARDWARE
NGT™/Envoy™ RF Cradle &
Battery Cable 15-00130 
Complete Vehicle
Installation Hardware Kit 15-00112 
3040 Installation Handbook
(includes sealing kit) 15-60012
Automatic Tuning Whip
Antenna 9350 Installation
Handbook
15-04142-EN
CABLES
Control NGT™/Envoy™ to
9350/304X Cable, 6 m 08-05627-006 
Coax Assembly Cable, UHF
Connectors RG58, 6 m 08-01503-006 
Coax Assembly Cable, UHF
Type Connectors, RG58,
30 m
08-01503-030
Earth Braid, 1.5 m 05-06374
TRANSCEIVER SUPPLY
3020 Transceiver Supply 78-20022
Power IEC Cable 67-90305
DISCONTINUED
Codan Radio Communications Commercial Product Catalogue Page 43
Issue 8 January 2015
NGT™ SRx Configurations for Australia
NGT™ SRx OPTIONS NGT SRx Options
PRODUCT PART NO. DESCRIPTION
15-10540
NGT SRx
Options
Opt SRx for Australia
This option provides Australian compliance for NGT™ SRx
Trans ceive rs.
NOTE:
• This option also includes digital Selective Emergency call
(Opt E, part number 15-10480).
• This option is for Australian customers only.
15-10479 Opt FED-STD-1045 ALE/CALM™
Fully compatible with FED-STD-1045 ALE capabilities and enhanced
with Codan Automated Link Management (CALM™). Includes
facilities for Selective Calls, All Calls, Phone Calls, Text Messaging
and GPS Position Calls.
15-10486 Opt GPS Calling
Enables sending and receiving of GPS position information using
Selcall or ALE (if enabled).
NOTE:
This feature is compatible with GPS receivers providing
NMEA 0183 V2.0 (or later) output format. A GPS receiver is not
supplied as part of this option.
For a description of the GPS receiver available from Codan, see
page 51, Mobile Accessories.
15-10551 Opt Voice Scrambler (CIVS)
Codan Integrated Voice Scrambler used to provide basic level voice
security capability.
15-10469-000 Opt Fan (Factory Fit)
Fan unit for continuous data transmission for EnvoyTM /NGTTM series
Transceivers.
NOTE:
This option is also available as a retro fit kit (part number
15-10469).
Continued on the next page
DISCONTINUED
Page 44 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
NGT™ SRx Configurations for Australia
NGT™ SRx OPTIONS CONT. NGT SRx Options
PRODUCT PART NO. DESCRIPTION
15-10507-000 Opt Voice Encryptor (Factory Fit)
High grade Voice Encryptor Module for NGT™ series Transceivers.
Provides high grade voice security with exceptional recovered
audio quality.
NOTE:
• This option is also available as a retro fit kit (part number
15-10507).
• This option is subject to Australian Defence Export Controls.
A signed End-User Declaration must be provided for supply of
this option outside of Australia.
15-10552-000 Opt AES-256 DV Encryptor Module (Factory FIt)
Digital Voice Encryptor module providing excellent digital voice
quality and high grade AES-256 bit encryption. Selectable vocoder
rates of 1200 and 2400 bps are available as standard.
NOTE:
• This option is also available as a retro fit kit (part number
15-10552).
• This option is subject to Australian Government Export Controls. A
signed End-User Declaration must be provided for supply of this
option.
DISCONTINUED
Codan Radio Communications Commercial Product Catalogue Page 45
Issue 8 January 2015
Transceiver Accessories
TRANSCEIVER ACCESSORIES Transceiver Accessories
PRODUCT PART NO. DESCRIPTION
08-07000-001
For ENVOY SERIES
Envoy™ 2220 Handset
The 2220 Handset provides full programming and operation
of the Envoy™ X1 and X2 Transceivers from the handset. It
features a large format colour screen, easy-to-use navigation
keys, and a full alphanumeric keypad including special
function macros. The handset also features a micro USB port
for PC (TPS-3250) and memory stick programming/firmware
upgrade and control of the embedded transceiver modem (if
enabled).
08-07000-002
For ENVOY SERIES
Envoy™ 2221 Limited Keyset Handset
The 2221 reduced keypad Handset is compatible with Envoy™
X1 and X2 Transceivers and supports the same capabilities as
the 2220 Handset but is tailored for basic operation. The 2221
Handset is most suited for transceivers that will be
configured by PC (TPS-3250) or memory stick prior to
deployment but handset based programming is available.
08-06022-002
08-06022-001
08-06022-003
For ENVOY SERIES
Cable, NGT / Envoy™ Handset Control, 0.5 m
Cable, NGT / Envoy™ Handset Control, 6 m
Cable, NGT / Envoy™ Handset Control, 30 m
08-07205-001
08-07205-006
08-07205-030
For ENVOY SERIES
Cable, Envoy™ Console to RF Unit, 1 m
Cable, Envoy™ Console to RF Unit, 6 m
Cable, Envoy™ Console to RF Unit, 30 m
08-05610-001
08-05610-002
08-05610-006
08-05610-030
For SR, ASR, AR
Cable, CIB Interface, 0.5 m
Cable, CIB Interface, 2 m
Cable, CIB Interface, 6 m
Cable, CIB Interface, 30 m
Transceiver Accessories
08-06213-001
For ASR
Cable, VP-116 Interface
Interface cable for connecting a VP-116 Voice Privacy Unit to
an NGTTM ASR VP-116 Junction Box.
Continued on the next page
Page 46 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Accessories
TRANSCEIVER ACCESSORIES CONT. Transceiver Accessories
PRODUCT PART NO. DESCRIPTION
08-06222-001
For ASR
Junction Box, NGT™ ASR VP-116
NGTTM ASR Junction Box suitable for interfacing with a VP-116
Voice Privacy Unit. Replaces the standard NGTTM ASR Junction
Box.
08-06330-001
For ASR
Cable, NGT™ to Q9600 Modem, 1 m
Interface cable for an NGTTM ASR Junction Box to a Rockwell-
Collins Q9600 Modem.
Codan Radio Communications Commercial Product Catalogue Page 47
Issue 8 January 2015
Transceiver Accessories
TRANSCEIVER ACCESSORIES CONT. Transceiver Accessories
PRODUCT PART NO. DESCRIPTION
08-03255
For ALL TCVRS
Cable, Battery, 6 m
08-03255-008
For ALL TCVRS
Cable, Battery, 8 m
08-04515-001
For ALL TCVRS
Earth Wire, 0.5 m
05-06374
For ALL TCVRS
Earth Braid, 1.5 m
15-04178-CD
For ENVOY SERIES
TPS-3250 Envoy™ Programming Software CD
Software used to program Envoy™ series Transceivers.
Envoy™ Programming Cable (part number 08-07214-001)
needs to be ordered separately.
08-07214-001
For ENVOY SERIES
Cable, Envoy™ USB Programming
Interface cable to program Envoy™ series Transceivers from
a PC.
67-90406
For ENVOY SERIES
Cable, USB Adaptor for Memory Stick Programming
Enables connection of a conventional USB memory stick to
Envoy™ series Handset or Desk Console.
08-07318-001
08-07318-002
For ENVOY SERIES
USB to 6-way data interface cable for use with MIL-STANAG
2G Data (using RC50-C application). Cable connects to 6-way
serial port on Envoy transceiver RF unit.
Cable, USB to 6-way (6 m)
Cable, USB to 6-way (2 m)
Continued on the next page
Page 48 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Accessories
TRANSCEIVER ACCESSORIES CONT. Transceiver Accessories
PRODUCT PART NO. DESCRIPTION
08-06952-001
08-06952-002
For ENVOY SERIES
USB to 15-way data interface cable for use with MIL-STANAG
2G Data (using RC50-C application), and Opt 2400 bps
Internal Data Modem (using UUPlus applications). Cable
connects to 15-way GP port on Envoy transceiver RF unit.
Cable, USB to 15-way (2 m)
Cable, USB to 15-way (6 m)
15-04168-EN
For ALL TCVRS
Key Management
Software
Key Management Software (KMS)
Key Management Software (KMS) enables you to manage
and program encryption keys for Codan’s NGT™/2110/
Envoy™ series Transceivers and stand-alone encrypted
devices, e.g. RM50e HF Data Modem.
NOTE:
• This product is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
15-04171-EN
For ALL TCVRS
Key Fill Software (KFS)
Key Fill Software (KFS) enables you to program encryption
keys into Codan’s NGT™/2110/Envoy™ series Transceivers
and stand-alone encryption devices, e.g. RM50e HF Data
Modem.
NOTE:
• This product is subject to Australian Government Export
Controls. A signed End-User Declaration must be provided
for supply of this option.
08-06380-001
For SRx, AR Voice &
ENVOY SERIES
Cable, Serial 6-way to D9F
9-way D to 6-way Molex Interface Cable for transceiver serial
control of NGT™ SRx, AR Voice and Envoy™ X1 & X2
Transceivers.
08-06266-001
For SRx, SR, ASR, AR
& ENVOY X2
Cable, Data Interface D9F to D15M
9-way D to 15-way D Interface Cable for transceiver serial
control for Envoy™ X2 Transceivers. The cable can also be
used for key programming (KMS/KFS) for NGT™ SRx, SR, ASR,
AR .
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 49
Issue 8 January 2015
Transceiver Accessories
TRANSCEIVER ACCESSORIES CONT. Transceiver Accessories
PRODUCT PART NO. DESCRIPTION
15-04164-EN
For NGT SERIES
NSP Software CD Package
Software used to program NGTTM series Transceivers. NSP
interface cable (part number 08-05123-001) needs to be
ordered separately.
08-05123-001
For NGT SERIES
Cable, NSP Interface
Interface cable to program NGTTM series Transceivers from a
PC.
78-01031
For NGT SERIES
Adaptor, USB to DB-9, Serial Port
USB V1.1 compliant and supports Microsoft WindowsTM 2000/
XP/Vista/WIN7.
Not suitable to be used when upgrading transceiver
firmware.
Page 50 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Accessories
TRANSCEIVER ACCESSORIES Transceiver Accessories
PRODUCT PART NO. DESCRIPTION
15-00662
For SRx, SR, ASR &
ENVOY SERIES
Morse Key for NGT™/Envoy™
Morse Key to suit NGT™/Envoy™ for desktop operation.
Terminated to 15-way GP port connector.
15-00668
For ENVOY SERIES
Morse Key, 2230 Desk Console
Morse key for use with the Envoy 2230 Desk Console.
Connects to the 8 pin accessory connector.
08-06262-001
For NGT and
ENVOY SERIES
Dual Antenna Selector
Antenna selector switch used for connecting two antennas to
an NGT/Envoy RF Unit. The dual antenna switch connects to
the RF coax and antenna control connectors of the RF Unit.
The switch supports the connection of one 9103 tuner and an
HF broadband antenna or two HF broadband antennas.
Coaxial connectors are UHF type.
15-10469-000 Opt Fan (Factory Fit)
Fan unit for continuous data transmission for Envoy™/NGT™
series Transceivers.
NOTE:
This option is also available as a retro fit kit (part number
15-10469).
15-04177-EN
For ENVOY SERIES
Getting Started Guide, Envoy™ Transceiver, includes
Reference Manual on CDROM
Printed Getting Started Guide for the Envoy™ Transceiver.
See page 165, Language Support for translations of this guide.
15-04143-EN
For NGT SERIES
Repair Guide, NGT™ Transceiver (English)
Printed Repair Guide for the NGT™ series Transceiver.
15-04143-CD
For NGT SERIES
Repair Guide, NGT™ Transceiver, on CDROM (English)
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 51
Issue 8 January 2015
Transceiver Accessories
TRANSCEIVER ACCESSORIES CONT. Transceiver Accessories
PRODUCT PART NO. DESCRIPTION
15-04127-
##
For NGT SERIES
Getting Started Guide, NGT™ Transceiver, includes Reference
Manual on CDROM
Printed Getting Started Guide for the NGTTM Transceiver.
See page 165, Language Support for translations of this guide.
15-04137-
##
For ASR
Getting Started Guide, NGT™ ASR Transceiver, includes
Reference Manual on CDROM
Printed Getting Started Guide for the NGTTM Transceiver.
See page 165, Language Support for translations of this guide.
MOBILE ACCESSORIES Transceiver Mobile Accessories
PRODUCT PART NO. DESCRIPTION
Mobile Accessories
15-00771
For SR, ASR, AR
GPS Receiver/Antenna
Includes:
• Receiver/antenna
• Magnetic mounting bracket
• NGT™ Transceiver interconnecting cables to suit 15 pin
NGT™ Junction Box connector
Features:
• Integrated antenna and GPS receiver
• Tracking up to 12 satellites
Envoy X1 Mobile Accessories
15-00765
For SRx, AR Voice,
SRx (AUS) &
ENVOY SERIES
GPS Receiver/Antenna
Includes:
• Receiver/antenna
• Magnetic mounting bracket
• NGT™/Envoy™ Transceiver interconnecting cables
Features:
• Integrated antenna and GPS receiver
• Tracking up to 12 satellites
08-05847-001
For SR, ASR, AR
Interface Adaptor
Interface adaptor to enable simultaneous connection of a
GPS receiver and a 3012 HF Data Modem to the NGT™
Transceiver.
15-00704
For ALL TCVRS
Vehicle Interference Suppression Kit
Comprises of interference filters, copper braid, earth strap
and fitting instructions.
Continued on the next page
Page 52 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Accessories
MOBILE ACCESSORIES CONT. Transceiver Mobile Accessories
PRODUCT PART NO. DESCRIPTION
15-00508
For ALL TCVRS
Voltage Regulator (24 V to 12 V operation 20 A)
Enables the operation of NGT™/Envoy™ series Transceivers in
24/26 V based systems. Protected from faults such as voltage
spikes, overload, short circuits and low voltage input. The unit
automatically resets once a fault is removed.
15-00130
For ALL TCVRS
NGT™/Envoy™ RF Cradle & 6 m Battery Cable
Includes mounting cradle, fuse holder and fuse, earth wire
and 6 m battery cable.
15-60031
For ALL TCVRS
NGT™/Envoy™ RF Cradle & 8 m Battery Cable
Includes mounting cradle, fuse holder and fuse, earth wire
and 8 m battery cable.
15-00112
For ALL TCVRS
Complete Vehicle Installation Hardware Kit
Includes assorted screws, cable ties and grommets.
15-00136
For ALL TCVRS
Cradle, Envoy™/NGT™ RF Unit Mounting
15-00129
For NGT SERIES
Cradle Kit, NGT™ Handset
15-00149
For ENVOY SERIES
Cradle Kit, Envoy™ Handset
08-03255
For ALL TCVRS
Cable, Battery, 6 m
08-03255-008
For ALL TCVRS
Cable, Battery, 8 m
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 53
Issue 8 January 2015
Transceiver Accessories
MOBILE ACCESSORIES CONT. Transceiver Mobile Accessories
PRODUCT PART NO. DESCRIPTION
15-00702
For ALL TCVRS
Cable Kit for Float Charge
Cable kit for float charging lead-acid storage battery for
uninterrupted supply.
For batteries, see page 86, Batteries.
15-00711
For ALL TCVRS
Fuse Holder with 32 A Fuse
15-00712
For ALL TCVRS
Fuse, 32 A
BASE ACCESSORIES Transceiver Base Accessories
PRODUCT PART NO. DESCRIPTION
08-07204-001
For ENVOY SERIES
Base Accessories
Desk Console 2230, Envoy™
An optional Envoy™ Desk Console for the Envoy™ Transceiver,
incorporating an in-built speaker, hand PTT switch, in-built
headphone output, and a 2 m transceiver interface cable.
NOTE:
The standard microphone for the 2230 Desk Console is the
Boom Microphone (part number 15-60025) and must be
ordered separately to the main console unit. The 2230 Desk
Console may connect to the Envoy™ RF Unit via a dedicated
control cable (part number 08-07205-00X), see page 45,
Transceiver Accessories, or via Ethernet, see page 117, Envoy
Remote Control Accessories — Ethernet.
15-10471
For SR, ASR, AR
Desk Console, NGT™ SR/ASR/AR
An optional NGT™ SR/ASR/AR Desk Console for the NGT™
Transceiver, incorporating an in-built speaker, hand PTT
switch, goose-neck microphone, and in-built headphone
output.
NOTE:
When an SR/ASR/AR Transceiver is ordered with a desk
console, part number 15-10471-000 should be used for the
console so that the junction box will be fitted to the console
at the factory.
Continued on the next page
Page 54 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Accessories
BASE ACCESSORIES CONT. Transceiver Base Accessories
PRODUCT PART NO. DESCRIPTION
15-00766
For VR, SRx, AR Voice,
SRx (AUS)
Desk Console, NGT™ VR/SRx/AR Voice
An optional NGT™ VR/SRx/AR Voice Desk Console for the
NGT™ VR/SRx/AR Voice Transceiver, incorporating an in-built
speaker, hand PTT switch, goose-neck microphone, in-built
headphone output, and a 2 m transceiver interface cable.
NOTE:
When the transceiver is ordered with an optional desk
console (part number 15-00766), an NGT™ handset cradle
(part number 15-00129), external speaker (part number
15-00649) and NGT™ Control cable (part number
08-06022-001) are not included.
15-00602
For NGT SERIES
Desk Console Headphones, NGT™
Headphones suitable for the NGTTM ASR Desk Console.
15-60028
For ENVOY SERIES
Desk Console Headphones, Envoy™
Headphones suitable for the Envoy™ Desk Console.
15-60026
For ENVOY SERIES
Desk Console Headset, Envoy™
15-60025
For ENVOY SERIES
Desk Console Boom Microphone, Envoy™
##
denotes language version
Codan Radio Communications Commercial Product Catalogue Page 55
Issue 8 January 2015
Transceiver Accessories
BASE ACCESSORIES CONT. Transceiver Base Accessories
PRODUCT PART NO. DESCRIPTION
15-60024
For ENVOY SERIES
Desk Console Hand-held Microphone, Envoy™
15-60027
For ENVOY SERIES
Desk Console PTT footswitch, Envoy™
15-00668 Morse Key, 2230 Desk Console
Morse key for use with the Envoy 2230 Desk Console.
Connects to the 8 pin accessory connector.
CONTROL-POINT-ASR-6M
NGT™ ASR Base Accessories
For ASR
08-05629-007
08-05630-007
15-00129
15-00649
08-05610-006
NGT™ ASR Control Point Kit
An additional control point incorporating the following parts.
COMPRISING:
NGTTM ASR 2020 Handset
NGTTM ASR 2030 Junction Box
NGTTM Handset Cradle Kit
External Speaker with 4 m Lead
CIB Interface Cable, 6 m
Continued on the next page
Page 56 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Accessories
BASE ACCESSORIES CONT. Transceiver Base Accessories
PRODUCT PART NO. DESCRIPTION
CONTROL-POINT-SR-6M
NGT™ SR Base Accessories
For SR
08-05629-001
08-05630-001
15-00129
15-00649
08-05610-006
NGT™SR Control Point Kit
An additional control point incorporating the following parts.
COMPRISING:
NGTTM SR 2020 Handset
NGTTM SR 2030 Junction Box
NGTTM Handset Cradle Kit
External Speaker with 4 m Lead
CIB Interface Cable, 6 m
CONTROL-POINT-AR-6M For AR
08-05629-003
08-05630-003
15-00129
15-00649
08-05610-006
NGT™ AR Control Point Kit
An additional control point incorporating an NGT™ AR 2020
Handset and cradle, NGT™ AR 2030 Junction Box, loudspeaker
and 6 m CIB cable.
COMPRISING:
NGTTM AR 2020 Handset
NGTTM AR 2030 Junction Box
NGTTM Handset Cradle Kit
External Speaker with 4 m Lead
CIB Interface Cable, 6 m
Codan Radio Communications Commercial Product Catalogue Page 57
Issue 8 January 2015
Transceiver Accessories
This page has been intentionally left blank.
Page 58 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Accessories
This page has been intentionally left blank.
Codan Radio Communications Commercial Product Catalogue Page 59
Issue 8 January 2015
Data & Email
RC50-C HF EMAIL SOFTWARE
PRODUCT PART NO. DESCRIPTION
RC50-C HF Email Software
15-04161-CD
RC50-C HF Email
Software
RC50-C HF Email Software
Codan’s RC50-C HF Email software provides fast, efficient,
error free email capability over HF radio. Operating in
conjunction with Codan’s HF Transceivers and 2G Data
Modems, the software operates on a standard Windows™ PC
using a single USB port with no specialised
PC hardware requirements. When installed, the software runs
in the background requiring no user interaction.
Data & Email COMPATIBILITY:
For use with external RM50e HF Data Modem (NGT™ AR, SRx,
SR, ASR, Envoy™ X2 Transceivers) and 2G embedded data
modem (Envoy X2 and 2110 Manpack transceiver)
COMPRISING:
• CD-ROM with RC50-C software and documentation
STANDARD FEATURES:
• Adaptive rates up to 19200 bit/s (ISB only) or 9600 bit/s
• Compatible with ALE/CALM™
• Intranet/Internet gateway
• NATO interoperable
• ISB capable
SYSTEM REQUIREMENTS:
• Windows™ XP Professional SP2 or Windows™ 7
• Intel Pentium IV 800 MHz or better
• 6 GB or more of free space for email storage
• 512 MB or more of RAM
•CD-ROM drive
• POP3 / SMTP compliant email client
• Access to any commercial POP3 / SMTP compliant email
server for internet connectivity
• Serial/USB port for connecting the HF modem to the PC
NOTE:
• The ISB capability is only supported by an NGT™ SRx
Transceiver fitted with the ISB Option, see page 35, Opt ISB
Processor 2012 (Factory Fit) or Envoy X2 fitted with 2G data
options (15-10589-000 or 15-10590-000) and the ISB
option (15-10598).
• Requires Data Interface Cable (part number 08-06901-001)
for connecting PC to an RM50e data modem.
• Requires Data Interface Cable (08-06952
or 08-07318) for connecting the PC to an Envoy with
2G Data Modem option (part number 15-10589).
NGT
TRANSCEIVER
Page 60 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email
RC50-C CABLE OPTIONS
PRODUCT PART NO. DESCRIPTION
08-07318-001
08-07318-002
For ENVOY SERIES
USB to 6-way data interface cable for use with MIL-STANAG
2G Data (using RC50-C application). Cable connects to 6-way
serial port on Envoy transceiver RF unit.
Cable, USB to 6-way (2 m)
Cable, USB to 6-way (6 m)
08-06952-001
08-06952-002
For ENVOY SERIES
USB to 15-way data interface cable for use with MIL-STANAG
2G Data (using RC50-C application) cable connects to 15-way
GP port on Envoy transceiver RF unit.
Cable, USB to 15-way (2 m)
Cable, USB to 15-way (6 m)
08-06901-001
USB to 19-way MIL Interface Cable for use with RM50e HF
Data Modem (using RC50-C application. Cable connects to
19-pin connector on RM50e HF Data Modem.
Cable, Data Interface 19-way MIL to USB A, (2 m)
Codan Radio Communications Commercial Product Catalogue Page 61
Issue 8 January 2015
Data & Email
UUPLUS™ SOFTWARE
PRODUCT PART NO. DESCRIPTION
UUPlus Software
08-05981-001
UUPlus ™ Email for HF
Server Software
Data & Email
UUPlus™ Email for HF Server Software
Provides HF and Internet email access for up to 25 users. It
works in conjunction with UUPlusTM Email for HF Codan Client
software, used by each remote station. It has been specifically
designed for use with Codan’s HF equipment.
NOTE:
• One copy of UUPlusTM Codan Client is required for each user
that is to connect to UUPlusTM Codan Server.
•A UUPlus
TM Codan Server cannot communicate directly to
other UUPlusTM Codan Server stations.
COMPATIBILITY:
• For use with 3012 and 3212 HF Data Modems, and Envoy™
X2 2400 bit/s embedded modem
COMPRISING:
•CD-ROM with UUPlus
TM Codan Server software and
documentation
• Single user licence for installation on one machine
STANDARD FEATURES:
• Simple to install and maintain.
• Works with POP3/SMTP PC email clients such as Outlook
Express™.
• Reduces connection time by compressing and combining
messages
• Automatically resumes interrupted file transfers
• Capable of automatically calling the remote user at preset
times to deliver mail and collect outgoing mail, or enables
the user to check mail manually
SYSTEM REQUIREMENTS:
• Codan HF SSB Transceiver
•Microsoft Windows
TM XP/WIN7
• Internet email client with support of POP3 and SMTP
protocols
• Serial/USB port for connecting the HF modem to the PC
• Optional LAN, dialup networking card or line modem for
connecting local email clients and server to the internet
• Codan 3012, 3212 HF Data Modems or Envoy X2
2400 bit/s embedded modem
Continued on the next page
Page 62 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email
UUPLUS CABLE OPTIONS
PRODUCT PART NO. DESCRIPTION
08-06952-001
08-06952-002
For ENVOY SERIES
USB to 15-way data interface cable for use with 2400 bit/
embedded data modem (using UUPlus applications) cable
connects to 15-way GP port on Envoy transceiver RF unit.
Cable, USB to 15-way (2 m)
Cable, USB to 15-way (6 m)
08-05086-001
08-05086-006
9-way to 9-way serial data interface cable to connect PC
(using UUPlus applications) to 3012 data modem.
Data Interface Cable (2 m)
Data Interface Cable (6 m)
78-01031 Adaptor, USB to DB-9, Serial
USB to 9-way serial adaptor cable.
USB V1.1 compliant and supports Microsoft WindowsTM 2000/
XP/Vista/WIN7.
Codan Radio Communications Commercial Product Catalogue Page 63
Issue 8 January 2015
Data & Email
UUPLUS™ SOFTWARE
PRODUCT PART NO. DESCRIPTION
08-05980-001
UUPlus™ Email for HF
Client Software
UUPlus™ Email for HF Client Software
Simple and reliable solution for sending email over HF from
remote areas. It works in conjunction with UUPlusTM Codan
Server software and has been specifically designed for use
with Codan’s HF equipment.
COMPATIBILITY:
• For use with 3012 and 3212 HF Data Modems, and Envoy™
X2 2400 bit/s embedded modem
COMPRISING:
•CD-ROM with UUPlus
TM Codan Client software and
documentation
• Single user licence for installation on one machine
STANDARD FEATURES:
• Simple to install and maintain.
• Works with POP3/SMTP PC email clients such as Outlook
Express™.
• Reduces connection time by compressing and combining
messages
• Automatically resumes interrupted file transfers
• Capable of automatically answering calls from the server to
exchange mail at preset times, or enables the user to check
for mail manually
• Able to send files directly to other stations
SYSTEM REQUIREMENTS:
• Codan HF SSB Transceiver
•Microsoft Windows
TM XP/WIN7
• Internet email client with support of POP3 and SMTP
protocols
• Codan 3012, 3212 HF Data Modem or Envoy X2 2400 bit/s
embedded modem
• Serial/USB port for connecting the HF modem to the PC
Page 64 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email
UUPLUS CABLE OPTIONS
PRODUCT PART NO. DESCRIPTION
08-06952-001
08-06952-002
For ENVOY SERIES
USB to 15-way data interface cable for use with 2400 bit/s
internal data modem (using UUPlus applications) cable
connects to 15-way GP port on Envoy transceiver RF unit.
Cable, USB to 15-way (2 m)
Cable, USB to 15-way (6 m)
08-05086-001
08-05086-006
9-way to 9-way serial data interface cable to connect PC
(using UUPlus applications) to 3012 data modem.
Data Interface Cable (2 m)
Data Interface Cable (6 m)
78-01031 Adaptor, USB to DB-9, Serial
USB to 9-way serial adaptor cable.
USB V1.1 compliant and supports Microsoft WindowsTM 2000/
XP/Vista/WIN7.
Codan Radio Communications Commercial Product Catalogue Page 65
Issue 8 January 2015
RM50e HF DATA MODEM
PRODUCT PART NO. DESCRIPTION
08-06978-001
RM50e HF Data Modem
RM50e HF Data Modem
The RM50e is a high performance MIL-spec HF modem
designed to connect to the NGT™/Envoy™ family of radios.
Compatible with the RM50 in the 2110 series Manpack, this
modem provides legacy interoperability with systems
running Fixed Frequency and ALE networks operating
STANAG 5066 email.
The RM50e operates using the most highly advanced Military
Standard (MIL-STD) waveforms, including STANAG 4539 and
MIL-STD-188-110A/B, providing adaptive rates from 75–9600
bit/s coded. When used in conjunction with an ISB capable
NGT™, even higher rates of up to 19200 bit/s are available
using MIL-STD-188-110B Appendix F waveforms.
COMPATIBILITY:
• With NGT™ series and Envoy™ X2 Transceivers
NOTE:
• For use in ISB mode, an NGT™ SRx Transceiver must be used
and fitted with Opt ISB Processor (part number
15-10556-000), see page 35, Opt ISB Processor 2012 (Factory
Fit).
• ISB mode using the RM50e HF Data modem is not
supported when combined with an Envoy X2 transceiver
• This product is subject to Australian Government Export
Controls.
• A signed End-User Declaration must be provided for supply
of this product.
STANDARD FEATURES:
• Compatible with RM50 (2110M Manpack Internal Modem)
• MIL-STD Waveforms (MIL-STD-188-110A, MIL-STD-188-
110B (Inc. Appendix F), STANAG 4285, STANAG 4529,
STANAG 4415, STANAG 4539)
• ISB capable
• Data Encryption (AES-256 bit Algorithm, up to 256 stored
keys, Key fill via Codan Key Management Software (KMS))
• MIL-STD-810F Immersion, Dust, Vibration
Continued on the next page
NGT
TRANSCEIVER
Page 66 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email
RM50e HF DATA MODEM CONT.
PRODUCT PART NO. DESCRIPTION
AVAILABLE OPTIONS:
• Support for RC50-C software, see page 59, RC50-C HF Email
Software.
08-07167-001 RM50e to NGT™/Envoy™ Transceiver Interface Cable, 1 m
08-07167-006 RM50e to NGT™/Envoy™ Transceiver Interface Cable, 6 m
08-06901-001 Data Interface 19way MIL to USB A Cable
15-04167-EN RM50e HF Data Modem Operator Guide
NGT
TRANSCEIVER
##
denotes language version
Codan Radio Communications Commercial Product Catalogue Page 67
Issue 8 January 2015
Data & Email
3012 HF DATA MODEM (NO CABLES)
PRODUCT PART NO. DESCRIPTION
MODEM-3012-NC 3012 HF Data Modem
(no cables)
3012 HF Data Modem (No
Cables)
3012 HF Data Modem (No Cables)
The 3012 HF Data Modem provides reliable and cost-effective
computer text and data communication capabilities for
organisations operating in remote areas with little or no
telecommunications infrastructure.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR Transceivers
08-05877-004
08-04515-001
30-11208-000
15-04104-CD
COMPRISING:
• 3012 HF Data Modem
•Earth Wire, 0.5m
• Self Adhesive Rubber Feet (x4)
• 3012 HF Data Modem User Guide on CDROM (English)
STANDARD FEATURES:
• Up to 6000 bit/s, error-free data transmission with
compression
• In-built data compression
• Backwards compatible with the Codan 9001/9002 HF Data
Modems
• Data scrambled for security
• In-built serial port optical isolator
• Easy to use AT command interface
AVAILABLE OPTIONS:
• Support for UUPlusTM Email for HF Client or Server software,
see page 61, UUPlus Software.
NGT
TRANSCEIVER
Page 68 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email
3012 HF DATA MODEM FOR NGT™ WITH
2 M RS232 CABLE
PRODUCT PART NO. DESCRIPTION
MODEM-3012-NGT-2M 3012 HF Data Modem for
NGT™ with 2 m RS232
Cable
3012 HF Data Modem with 2 m RS232 Cable
This configuration consists of a 3012 HF Data Modem,
2 m Data Interface Cable, and 1 m NGT™ Junction Box to
3012 Modem Cable.
NOTE:
This configuration replaces previous part number
08-05877-001.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR Transceivers
08-05877-004
08-04515-001
30-11208-000
15-04104-CD
COMPRISING:
• 3012 HF Data Modem
•Earth Wire, 0.5m
• Self Adhesive Rubber Feet (x4)
• 3012 HF Data Modem User Guide on CDROM (English)
08-05086-001 Data Interface Cable, 2 m
08-05712-001 NGT™ to 3012 Modem Cable, 1 m
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 69
Issue 8 January 2015
Data & Email
3012 HF DATA MODEM FOR NGT™ WITH
6 M RS232 CABLE
PRODUCT PART NO. DESCRIPTION
MODEM-3012-NGT-6M 3012 HF Data Modem for
NGTTM with 6 m RS232
Cable
3012 HF Data Modem with 6 m RS232 Cable
This configuration consists of a 3012 HF Data Modem,
6 m Data Interface Cable, and 1 m NGT™ Junction Box to
3012 Modem Cable.
NOTE:
This configuration replaces previous part number
08-05877-002.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR Transceivers
08-05877-004
08-04515-001
30-11208-000
15-04104-CD
COMPRISING:
• 3012 HF Data Modem
•Earth Wire, 0.5m
• Self Adhesive Rubber Feet (x4)
• 3012 HF Data Modem User Guide on CDROM (English)
08-05086-006 Data Interface Cable, 6 m
08-05712-001 NGT™ to 3012 Modem Cable, 1 m
NGT
TRANSCEIVER
Page 70 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email
3012 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
3012 Accessories
15-00136 Cradle, HF Data Modem Vehicle Mounting
78-01031 Adaptor, USB to DB-9, Serial
USB V1.1 compliant and supports Microsoft WindowsTM 2000/
XP/Vista/WIN7.
60-00098-590 Adaptor, 9-pin D PIug to 25-pin D Socket
08-05086-001
08-05086-006
Cable, Data Interface, 2 m
Cable, Data Interface, 6 m
08-05712-001
08-05712-006
Cable, NGT™ to 3012 Modem, 1 m
Cable, NGT™ to 3012 Modem, 6 m
15-04104-
##
User Guide, HF Data Modem 3012
Printed User Guide for the 3012 HF Data Modem.
See page 165, Language Support for translations of this guide.
08-05980-001 UUPlus™ Email for HF Client Software
Single user access to UUPlusTM Email for HF Server Software.
For use with the 3012 and 3212 HF Data Modems and
embedded 2400 bit/s data mode option offered with Envoy
X2 Transceivers.
08-05981-001 UUPlus™ Email for HF Server Software
Email server with support for up to 25 remote or local users
and Internet email access. For use with the 3012 and 3212 HF
Modems and embedded 2400 bit/s data mode option offered
with Envoy X2 Transceivers.
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 71
Issue 8 January 2015
Data & Email
3212 HF DATA MODEM (NO CABLES)
PRODUCT PART NO. DESCRIPTION
MODEM-3212-NC
3212 HF Data Modem (No Cables)
3212 System
Requirements
3212 HF Data Modem (No Cables)
The 3212 HF Data Modem provides reliable and cost-effective
computer text and data communication capabilities for
organisations operating in remote areas with little or no
telecommunications infrastructure.
The 3212 HF Data Modem uses waveforms derived from
Military Standard (MIL-STD) waveforms, which are based on
STANAG 4539 and modified to provide optimal performance
over commercial channel bandwidths.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR and Envoy™ X2 Transceivers
08-06274-001
08-04515-001
30-11208-000
15-04146-CD
COMPRISING:
• 3212 HF Data Modem
•Earth Wire, 0.5m
• Self Adhesive Rubber Feet (x4)
• 3212 HF Data Modem User Guide on CDROM (English)
STANDARD FEATURES:
• Up to 7200 bit/s error free on-air data rate without
compression
• Backwards compatible with Codan 3012 HF Data Modem
• Designed to operate on standard bandwidth commercial
HF channels
• In-built DC isolation on all available ports
• Modem control via RS232 or ethernet port
SYSTEM REQUIREMENTS:
The following Options are required for operation with the
3212 HF Data Modem:
15-10541-000 Opt High Speed Data (Factory Fit) (NGT™)
15-10469-000 Opt Fan (Factory Fit) (NGT™ & Envoy X2™)
NOTE:
2.7 kHz Filter is not required for the 3212 HF Data Modem.
AVAILABLE OPTIONS:
• Support for UUPlus™ Email for HF Client or Server software,
see page 61, UUPlus™ Software.
NGT
TRANSCEIVER
Page 72 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email
3212 HF DATA MODEM FOR NGT™/ENVOY X2
WITH 2 M RS232 CABLE
PRODUCT PART NO. DESCRIPTION
MODEM-3212-NGT-2M 3212 HF Data Modem for
NGT™/Envoy™ with 2 m
RS232 Cable
3212 HF Data Modem with 2 m RS232 Cable
This configuration consists of a 3212 HF Data Modem,
2 m Serial Cable, and 1 m Transceiver to 3212 Modem Cable.
The 3212 HF Data Modem uses waveforms derived from
Military Standard (MIL-STD) waveforms, which are based on
STANAG 4539 and modified to provide optimal performance
over commercial channel bandwidths.
See page 71, 3212 System Requirements for the NGT™/
Envoy X2 Transceiver Options that are required for operation
with the 3212 HF Data Modem.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR and Envoy™ X2 Transceivers
08-06274-001
08-04515-001
30-11208-000
15-04146-CD
COMPRISING:
• 3212 HF Data Modem
•Earth Wire, 0.5m
• Self Adhesive Rubber Feet (x4)
• 3212 HF Data Modem User Guide on CDROM (English)
08-06359-002 Serial D9M-D9F Isol Shield Cable, 2 m
08-06356-001 NGT™/Envoy™ X2 to 3212 Modem Cable, 1 m
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 73
Issue 8 January 2015
Data & Email
3212 HF DATA MODEM FOR NGT™/ENVOY™ X2
WITH 6 M RS232 CABLE
PRODUCT PART NO. DESCRIPTION
MODEM-3212-NGT-6M 3212 HF Data Modem for
NGT™/Envoy™ X2 with 6 m
RS232 Cable
3212 HF Data Modem with 6 m RS232 Cable
This configuration consists of a 3212 HF Data Modem,
6 m Serial Cable, and 1 m NGT™/Envoy™ X2 to 3212 Modem
Cable.
The 3212 HF Data Modem uses waveforms derived from
Military Standard (MIL-STD) waveforms, which are based on
STANAG 4539 and modified to provide optimal performance
over commercial channel bandwidths.
See page 71, 3212 System Requirements for the NGT™/
Envoy™ X2 Transceiver Options that are required for
operation with the 3212 HF Data Modem.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR and Envoy™ X2 Transceivers
08-06274-001
08-04515-001
30-11208-000
15-04146-CD
COMPRISING:
• 3212 HF Data Modem
•Earth Wire, 0.5m
• Self Adhesive Rubber Feet (x4)
• 3212 HF Data Modem User Guide on CDROM (English)
08-06359-006 Serial D9M-D9F Isol Shield Cable, 6 m
08-06356-006 NGT™/Envoy™ X2 to 3212 Modem Cable, 6 m
NGT
TRANSCEIVER
Page 74 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email
3212 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
15-00136
3212 Accessories
3212 Accessories
Cradle, HF Data Modem Vehicle Mounting
78-01031 Adaptor, USB to DB-9, Serial
USB V1.1 compliant and supports Microsoft WindowsTM 2000/
XP/Vista/WIN7.
60-00098-590 Adaptor, 9-pin D PIug to 25-pin D Socket
39-79150-080 Ferrite Bead Clamp
08-06359-002
08-06359-006
Cable, Serial D9M-D9F Isol Shield, 2 m
Cable, Serial D9M-D9F Isol Shield, 6 m
67-90800
67-90801
Cable, Ethernet Crossover CAT-5E, 2 m Red
Cable, Ethernet Crossover CAT-5E, 10 m Red
67-90802
67-90803
Cable, Ethernet Straight CAT-5E, 2 m Blue
Cable, Ethernet Straight CAT-5E, 10 m Blue
08-06356-001
08-06356-006
Cable, NGT™/Envoy™ X2 to 3212 Modem, 1 m
Cable, NGT™/Envoy™ X2 to 3212 Modem, 6 m
15-04146-EN User Guide, 3212 HF Data Modem (English)
Printed User Guide for the 3212 HF Data Modem.
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 75
Issue 8 January 2015
High Power Amplifiers
3061 500 W POWER AMPLIFIER
PRODUCT PART NO. DESCRIPTION
HIGH-PWR-500 3061 500 W Power
Amplifier 3061 500 W Power Amplifier
A reliable and affordable high power solution for voice and
data communication.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR and Envoy™ series Transceivers
08-05974-001
08-06067-001
15-10504
05-06374
08-01503-002
08-05956-001
15-04131-EN
67-90308
COMPRISING:
• 3061 500 W Power Amplifier
• 3061 500 W Power Supply Unit
• Opt External ALC (Retro Fit) (only required for NGT™)
•Earth Braid, 1.5m
• Coaxial Assembly Cable, 2 m
• High Power Amplifier Controller Cable
• High Power Amplifiers 3061/3062 Reference Manual (see
page 165, Language Support for translations of this guide)
• Power IEC Cable, 2 m (for cable options, see page 76, 3061
Accessories)
NOTE:
• Specify the mains cable (AU, EU, UK or US) at the time of
ordering the 3061 Power Amplifier and Power Supply Unit.
• The 3061 Power Amplifier is suitable for use with NGT™
SRx, SR, ASR, AR systems, and Envoy™ series Transceivers.
• Order Option External ALC (Factory Fit), part
number 15-10504-000, when purchasing the power
amplifier with an NGTTM Transceiver.
• Ensure the antenna used is suitable for 500 W operation.
• The Power Amplifier and Power Supply Unit are each 5RU in
height and will fit a standard 19" wide rack with depth of
400 mm or greater.
STANDARD FEATURES:
• 500 W PEP/300 W average output power
• 100% continuous mode
• 100–270 V AC 50/60 Hz supply voltage
• Fully protected against all load conditions
• Fan forced cooling with thermostatically controlled fans
• 125 W PEP in bypass mode
• 19" rack mount (5RU + 5RU)
• Interface cables for transceiver (coaxial and control cables)
NGT
TRANSCEIVER
Page 76 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
High Power Amplifiers
3061 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
NOTE:
This is a typical high power rack
configuration. For illustrative
purposes only.
3061 Accessories
3061 Accessories
Standard Rack Configurations
Standard rack configurations are 27RU free standing 19" rack
cabinets. They are supplied preassembled and fitted with a
range of mounting trays and panels to suit the equipment as
indicated.
Radio equipment is packed separately to the rack unit to
prevent damage in transit.
For rack options, see pages 125 and 126, Standard Rack
Configurations.
67-90305 Cable, 3C Blk Mld IEC AUS, 2 m
67-90306 Cable, 3C Blk Mld IEC UK, 2 m
67-90307 Cable, 3C Blk Mld IEC US, 2 m
67-90308 Cable, 3C Blk Mld IEC EU, 2 m
08-05920-001 Cable, DC Extension, 1 m
NOTE:
Required for the transceiver when it is rack mounted.
05-06374 Earth Braid, 1.5 m
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 77
Issue 8 January 2015
High Power Amplifiers
3062 1 kW POWER AMPLIFIER
PRODUCT PART NO. DESCRIPTION
HIGH-PWR-1000 3062 1 kW Power
Amplifier 3062 1 kW Power Amplifier
A reliable and affordable high power solution for voice and
data communication.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR and Envoy™ series Transceivers
08-05975-001
08-06102-001
15-10504
05-06374
08-01503-002
08-05956-001
15-04131-EN
67-90309
COMPRISING:
• 3062 1 kW Power Amplifier
• 3062 1 kW Power Supply Unit
• Opt External ALC (Retro Fit) (only required for NGT™)
•Earth Braid, 1.5m
• Coaxial Assembly Cable, 2 m
• High Power Amplifier Controller Cable
• High Power Amplifiers 3061/3062 Reference Manual (see
page 165, Language Support for translations of this guide)
• Power IEC 320 Cable, 2 m (for cable options, see page 78,
3062 Accessories)
NOTE:
• Specify the mains cable (AU, EU, UK or US) at the time of
ordering the 3062 Power Amplifier and Power Supply Unit.
• The 3061 Power Amplifier is suitable for use with NGT™
SRx, SR, ASR, AR systems, and Envoy™ series Transceivers.
• Order Option External ALC (Factory Fit), part
number 15-10504-000, when purchasing the power
amplifier with an NGTTM Transceiver.
• Ensure the antenna used is suitable for 1 kW operation.
• The Power Amplifier and Power Supply Unit are each 5RU in
height and will fit a standard 19" wide rack with depth of
400 mm or greater.
STANDARD FEATURES:
• 1 kW PEP/600 W average output power
• 100% continuous mode
• 100–270 V AC 50/60 Hz supply voltage
• Fully protected against all load conditions
• Fan forced cooling with thermostatically controlled fans
• 125 W PEP in bypass mode
• 19" rack mount (5RU + 5RU)
• Interface cables for transceiver (coaxial and control cables)
NGT
TRANSCEIVER
Page 78 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
High Power Amplifiers
3062 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
NOTE:
This is a typical high power rack
configuration. For illustrative
purposes only.
3062 Accessories
3062 Accessories
Standard Rack Configurations
Standard rack configurations are 27RU free standing 19" rack
cabinets. They are supplied preassembled and fitted with a
range of mounting trays and panels to suit the equipment as
indicated.
Radio equipment is packed separately to the rack unit to
prevent damage in transit.
For rack options, see pages 125 and 126, Standard Rack
Configurations.
67-90309 Cable, 3C Blk Mld IEC 320-UK, 2 m
NOTE:
This is the only mains cable available for use with the 3062
1 kW Power Amplifier. If required for use in countries other
than the UK, the cable will need to be reterminated
accordingly.
08-05920-001 Cable, DC Extension, 1 m
NOTE:
Required for the transceiver when it is rack mounted.
05-06374 Earth Braid, 1.5 m
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 79
Issue 8 January 2015
Crosspatch™/Phone/GPS Solutions
CROSSPATCH™ FOR NGT™/ENVOY™
PRODUCT PART NO. DESCRIPTION
XPATCH-NGT Crosspatch™ for NGT™/
Envoy™ 3031 Crosspatch™
Codan’s leading edge 3031 CrosspatchTM enables you to carry
‘HF on your belt’ using a VHF/UHF radio and a Codan
NGT™/Envoy™ Transceiver. It is the practical, effective and
affordable solution for any organisation that needs to extend
their current HF or VHF/UHF networks.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR and Envoy™ X2 Transceivers
08-06730-001
08-06766-001
15-04148-CD
06-02489-EN
15-00145
COMPRISING:
• 3031 VHF/UHF to HF Crosspatch™ for NGT™/Envoy™
• 3031 to VHF/UHF Transceiver Generic Cable, 2 m
•Crosspatch
TM 3031 CD Package (English)
•Crosspatch
TM 3031 Quick Reference Cards, English (x2)
•Crosspatch
TM 3031 Installation Kit
CROSSPATCH™ ACCESSORIES
PRODUCT PART NO. DESCRIPTION
08-06766-001
Crosspatch™ Accessories
Cable, 3031 to VHF/UHF Transceiver Generic
06-02489-EN Quick Reference Card, Crosspatch™ 3031
15-04148-EN User Guide, Crosspatch™ 3031 (English)
Printed User Guide for the 3031 Crosspatch™.
NGT
TRANSCEIVER
NGT
TRANSCEIVER
™
Page 80 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Crosspatch™/Phone/GPS Solutions
3033 TELEPHONE INTERCONNECT
PRODUCT PART NO. DESCRIPTION
RTI-3033-NGT 3033 Telephone
Interconnect 3033 Telephone Interconnect
Codan’s telephone interconnect equipment can link into the
telephone system enabling you to make or receive telephone
calls on your HF transceiver.
Comes with all cables and Reference Manual.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR and Envoy™ X2 Transceivers
08-06797-001
08-06820-001
08-06819-001
15-04156-CD
COMPRISING:
• 3033 Telephone Interconnect
• 3033 to Transceiver Interface Cable
• 3033 to 3020 Power Supply Cable
• 3033 Telephone Interconnect User Guide on CD (English)
STANDARD FEATURES:
• Fully automated and intuitive operation
• Multilingual voice prompts
• Flexible configuration and remote management
• Worldwide compliance (Telephone and EMC)
• Radio user can access public telephone network
• Telephone users can contact radio users
• Designed for extreme conditions
ADDITIONAL FEATURES AVAILABLE THROUGH
ATTACHED NGT™ TRANSCEIVER:
• Choice of pre-programmed telephone numbers or free
dialling
• Accessible for user with only selective calling capability
(non-telcall users)
• Access control to restrict access to individual users, groups
of users, and the number of digits that can be dialled
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 81
Issue 8 January 2015
Crosspatch™/Phone/GPS Solutions
3033 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
08-04146-001
3033 Accessories
Cable, 6-way Phone
08-04515-001 Earth Wire, 0.5 m
67-90800 Cable, Ethernet Crossover CAT-5E, 2 m Red
67-90801 Cable, Ethernet Crossover CAT-5E, 10 m Red
67-90802 Cable, Ethernet Straight CAT-5E, 2 m Blue
67-90803 Cable, Ethernet Straight CAT-5E, 10 m Blue
15-04156-EN User Guide, 3033 Telephone Interconnect (English)
Printed User Guide for the 3033 Telephone Interconnect.
NGT
TRANSCEIVER
Page 82 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Crosspatch™/Phone/GPS Solutions
GPS TRACKING SOFTWARE
PRODUCT PART NO. DESCRIPTION
GPS Tracking Software InterNav-CHF GPS Tracking Software
The InterNav-CHF GPS Tracking Software is a computerised
map positioning system for up to 100 users. It requires a
Windows™ 2000/XP/Vista/WIN7 operating system.
Includes: software, user manual and hardware security
dongle
NOTE:
Interface cable must be ordered separately.
COMPATIBILITY:
•With NGT™ SRx, SR, ASR, AR and Envoy™ series Transceivers
78-07003-990
78-07003-010
78-07003-025
78-07003-050
78-07003-100
InterNav-CHF™ GPS Tracking Software – 1 User (Dealer)
InterNav-CHF™ GPS Tracking Software – 10 User
InterNav-CHF™ GPS Tracking Software – 25 User
InterNav-CHF™ GPS Tracking Software – 50 User
InterNav-CHF™ GPS Tracking Software – 100 User
Setup
Three day on-site installation, commissioning and training
visit by a Codan engineer.
78-07004 GPS, Map scanning per A4 page
Includes: Scanning and registration of maps, chart purchase
and copyright fee
SPECIFY:
• Geographic areas to be mapped
• Scale(s) required
GPS ACCESSORIES
PRODUCT PART NO. DESCRIPTION
08-05086-001
GPS Accessories Cable, Data Interface, 2 m
Interface cable for computer control via CICS or GPS Tracking
software, and NGT™ Transceivers that have a junction box.
Cable connects to 9 pin serial port on NGT™ Junction Box.
COMPATIBILITY:
•With NGT™ SR, ASR, AR and Envoy™ series Transceivers
08-06380-001 Cable, Serial 6-way to D9F
Interface cable for computer control via CICS or GPS Tracking
software and security key programming using KMS/KFS on
the NGT™ SRx and Envoy™ series Transceivers.
Cable connects to 6-pin serial port on NGT™/Envoy™ RF Unit.
COMPATIBILITY:
•With NGT™ SRx, AR Voice and Envoy™ series Transceivers
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 83
Issue 8 January 2015
Transceiver Supplies
3020 TRANSCEIVER SUPPLY
PRODUCT PART NO. DESCRIPTION
78-20022
3020 Transceiver
Supply
3020 Transceiver Supply
3020 Transceiver Supply
Designed for environments with unreliable and fluctuating
mains systems. Suitable for use with either voice or data
stations.
Nominal input: 100 to 240 V AC ±10% (50/60 Hz)
Nominal output: 13.8 V DC, 16 A continuous, 20 A peak
Mains connection: IEC socket on rear of unit
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
67-90305 Cable, 3C Blk Mld IEC AUS, 2 m
67-90306 Cable, 3C Blk Mld IEC UK, 2 m
67-90307 Cable, 3C Blk Mld IEC US, 2 m
67-90308 Cable, 3C Blk Mld IEC EU, 2 m
NGT
TRANSCEIVER
Page 84 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Supplies
3020 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
15-00702
3020 Accessories
3020 Accessories
Cable Kit for Float Charge
Cable kit for float charging lead-acid storage battery for
uninterrupted supply.
15-00175 3RU Rack-mounting Frame for 3020
NOTE:
For additional racking accessories, see page 125, 19" Racks &
Accessories.
DC-DC VOLTAGE CONVERTER
PRODUCT PART NO. DESCRIPTION
15-00508
DC-DC Voltage Converter
Voltage Regulator (24 V to 12 V operation 20 A)
Enables the operation of NGT™ and Envoy™ series
Transceivers in 24 V based systems. Protected from
faults such as voltage spikes, overload, short circuits and low
voltage input. The unit automatically resets once a fault is
detected.
Nominal Input: 24 V DC
Nominal Output: 12 V @20 A
Efficiency: Greater than 90% at full load
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 85
Issue 8 January 2015
Transceiver Supplies
SOLAR POWER SUPPLIES
PRODUCT PART NO. DESCRIPTION
15-00531
Solar Power Supplies
Solar Power Supply 40 W
Recommended for voice (light duty).
COMPRISING:
• Single 40 W solar panel
• Mounting frame complete with anti-bird spikes
• Solar battery regulator
•Heavy duty twin core cable
•Battery lugs
15-00532 Solar Power Supply 80 W
Recommended for voice (heavy duty).
COMPRISING:
• Single 80 W solar panel
• Mounting frame complete with anti-bird spikes
• Solar battery regulator
•Heavy duty twin core cable
•Battery lugs
15-00533 Solar Power Supply 240 W
Recommended for fax and data (heavy duty).
COMPRISING:
• Three 80 W solar panels
• Mounting frame complete with anti-bird spikes
• Solar battery regulator
•Heavy duty twin core cable
•Battery lugs
SOLAR POWER SUPPLY ACCESSORIES
PRODUCT PART NO. DESCRIPTION
08-05399-001
Solar Power Supply
Accessories
Cable, Battery Paralleling (+ve)
08-05399-002 Cable, Battery Parallelling (–ve)
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Page 86 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Transceiver Supplies
BATTERIES Batteries
PRODUCT PART NO. DESCRIPTION
65-72000-012
Batteries
Battery, Lead acid 12 V 90Ah (supplied dry charged)
NOTE:
This battery is classified as dangerous goods and requires a
special permit to air freight.
65-72003 Battery, 12 V 100Ah Gelcell
NOTE:
This battery can be air freighted without a permit.
65-72004 Battery, 12 V 185Ah Gelcell
NOTE:
This battery can be air freighted without a permit.
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 87
Issue 8 January 2015
Antennas
3040 AUTOMATIC TUNING WHIP
PRODUCT PART NO. DESCRIPTION
ANT-3040-NC 3040 Automatic Tuning
Whip (No Cables)
3040 Automatic
Tuning Whip Antenna
3040 Automatic Tuning Whip (No Cables)
The 3040 Automatic Whip Antenna is a low profile, rugged,
lightweight unit designed for mobile installations. It provides
fast automated tuning across the HF band.
The 3040 is easy to install and meets MIL-STD-810F for shock,
immersion, dust and vibration.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
08-07007-001
08-07148-001
78-18058
78-23085
78-23086
15-60012
COMPRISING:
• 3040 Main Assembly
• 3040 Spring
• Riser, Fibreglass
• 3040 Fibreglass Whip, 1.6 m
• 3040 Stainless Steel Whip, 1.65 m
• 3040 Automatic Whip Antenna Installation Handbook, c/w
antenna connector sealing kit
STANDARD FEATURES:
•2.5 to 30 MHz
• 125W PEP voice or data
• Fast tuning typically < 1sec
• Tune from memory
AVAILABLE ACCESSORIES:
See page 89, 3040 Accessories for cables and other parts used
with the 3040.
NGT
TRANSCEIVER
Page 88 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
3040 AUTOMATIC TUNING WHIP WITH
6 M CABLES
PRODUCT PART NO. DESCRIPTION
ANT-3040-6M 3040 Automatic Tuning
Whip Antenna with 6 m
Cables
3040 Automatic
Tuning Whip Antenna
3040 Automatic Tuning Whip with 6 m Cables
The 3040 Automatic Whip Antenna is a low profile, rugged,
lightweight unit designed for mobile installations. It provides
fast automated tuning across the HF band.
The 3040 is easy to install and meets MIL-STD-810F for shock,
immersion, dust and vibration.
NOTE:
Supplied with 6 m cables to connect the 3040 Antenna to an
NGT™/Envoy™ Transceiver. See page 89, 3040 Accessories for
additional 3040 accessories.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
08-07007-001
08-05627-006
08-01503-006
08-07148-001
78-18058
78-23085
78-23086
15-60012
COMPRISING:
• 3040 Main Assembly
•Control NGT
TM /EnvoyTM to 9350/304X Cable, 6 m
• Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
• 3040 Spring
• Riser, Fibreglass
• 3040 Fibreglass Whip, 1.6 m
• 3040 Stainless Steel Whip, 1.65 m
• 3040 Automatic Whip Antenna Installation Handbook, c/w
antenna connector sealing kit
STANDARD FEATURES:
• 2.5 to 30 MHz
• 125 W PEP voice or data
• Fast tuning typically < 1sec
• Tune from memory
AVAILABLE ACCESSORIES:
See page 89, 3040 Accessories for cables and other parts used
with the 3040.
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 89
Issue 8 January 2015
Antennas
3040 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
08-07148-001
3040 Accessories
3040 Accessories
3040 Spring
Flexible mounting for whip antennas. The spring is highly
recommended when using the fibreglass whip and/or riser.
78-23086 3040 Stainless Steel Whip
A stainless steel whip offered as a more flexible and less
visually obstructive alternative to the fibreglass version.
The whip is 1.65 m in length.
78-23085 3040 Fibreglass Whip
This is a 1.6 m fibreglass whip and is recommended to be
used with the spring and the riser section. In this
configuration the antenna will operate over a transmit
frequency range of 2.5 to 30 MHz.
78-18058 Riser, Fibreglass
A 0.8 m fibreglass section used to extend the overall length of
the antenna element when using the 1.6 m fibreglass or
stainless steel whips to achieve maximum possible frequency
range (2.5 to 30 MHz) and radiation performance.
78-14010 3040/3042 NVIS Antenna Kit
Suits the 3040 Automatic Tuning Whip Antenna/3042
Antenna Tuner for improved short range (0 to 500 km) near
vertical incidence skywave communications mode over
frequency range 2 to 12 MHz.
Includes: 2 section lightweight NVIS whip antenna sections,
tie down cord kit, instruction card and canvas storage bag.
08-05627-002
08-05627-006
08-05627-010
08-05627-020
Cable, Control NGT/Envoy to 9350/304X, 2m
Cable, Control NGT/Envoy to 9350/304X, 6 m
Cable, Control NGT/Envoy to 9350/304X, 10 m
Cable, Control NGT/Envoy to 9350/304X, 20 m
08-01503-006
08-01503-008
08-01503-020
08-01503-030
Cable, Coax Assembly, UHF Type Connectors, RG58, 6 m
Cable, Coax Assembly, UHF Type Connectors, RG58, 8 m
Cable, Coax Assembly, UHF Type Connectors, RG58, 20 m
Cable, Coax Assembly, UHF Type Connectors, RG58, 30 m
NGT
TRANSCEIVER
Page 90 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
9350 AUTOMATIC TUNING WHIP
PRODUCT PART NO. DESCRIPTION
ANT-9350-NC 9350 Automatic Tuning
Whip (No Cables)
9350 Automatic Tuning
Whip Antenna
9350 Automatic Tuning Whip (No Cables)
A robust antenna designed for mobile installations requiring
flexible, high performance HF communications. It provides
fast automated tuning over the entire HF frequency range.
The 9350 is easy to install, and meets MIL-STD-810F for shock
and vibration.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
08-05063-001
08-05140-001
78-23007-003
78-23025
15-04142-
##
COMPRISING:
• 9350 Main Assembly
• 9350 Spring
• 9350 Fibreglass Whip, 1.6 m
• 9350 Tapered Stainless Steel Whip, 1.2 m
• Automatic Tuning Whip Antenna 9350 Installation
Handbook (see page 165, Language Support for translations
of this handbook)
STANDARD FEATURES:
• 125 W PEP voice or data
•Tuning time typically 2 seconds
• Transmit frequency range 2 to 30 MHz depending
on antenna
• Receive frequency range 250 kHz to 30 MHz
AVAILABLE ACCESSORIES:
See page 92, 9350 Accessories for cables to connect the 9350
Antenna to an NGT™ or Envoy™ Transceiver.
NGT
TRANSCEIVER
##
denotes language version
Codan Radio Communications Commercial Product Catalogue Page 91
Issue 8 January 2015
Antennas
9350 AUTOMATIC TUNING WHIP WITH
6 M CABLES
PRODUCT PART NO. DESCRIPTION
ANT-9350-6M 9350 Automatic Tuning
Whip Antenna with 6 m
Cables
9350 Automatic
Tuning Whip Antenna
9350 Automatic Tuning Whip with 6 m Cables
A robust antenna designed for mobile installations requiring
flexible, high performance HF communications. It provides
fast automated tuning over the HF range.
The 9350 is easy to install, and meets MIL-STD-810F for shock
and vibration.
NOTE:
Supplied with 6 m cables to connect the 9350 Antenna to an
NGT™/Envoy™ Transceiver, see page 92 for additional 9350
accessories.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
08-05063-001
08-05627-006
08-01503-006
08-05140-001
78-23007-003
78-23025
15-04142-
##
COMPRISING:
• 9350 Main Assembly
• Control NGTTM /EnvoyTM to 9350/304X Cable, 6 m
• Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
• 9350 Spring
• 9350 Fibreglass Whip, 1.6 m
• 9350 Tapered Stainless Steel Whip, 1.2 m
• Automatic Tuning Whip Antenna 9350 Installation
Handbook (see page 165, Language Support for translations
of this handbook)
STANDARD FEATURES:
• 125 W PEP voice or data
• Tuning typically 2 seconds
• Transmit frequency range 2 to 30 MHz depending
on antenna
• Receive frequency range 250 kHz to 30 MHz
NGT
TRANSCEIVER
##
denotes language version
Page 92 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
9350 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
08-05140-001
9350 Accessories
9350 Spring
Strain relief for 9350 Fibreglass Whip.
9350 Accessories
78-23007-003 9350 Fibreglass Whip, 1.6 m
This is the primary whip normally supplied with the 9350. It is
a copper wire encased in a polyurethane covered fibreglass
rod. The whip is designed to withstand substantial flexing
and rugged conditions. It operates over the transmit
frequency range of 2 to 30 MHz.
NOTE:
Must be used with the spring (part number 08-05140-001).
78-23056 9350 Tapered Stainless Steel Whip, 1.65 m
This whip enables use over the transmit frequency range of
2 to 30 MHz and provides a more flexible and less visible
alternative to the fibreglass whip.
NOTE:
Can be used without the spring (part number 08-05140-001).
78-23025 9350 Tapered Stainless Steel Whip, 1.2 m
This whip is designed as an emergency backup to the primary
whip (part number 78-23007-003) in case of damage. It is
only suitable for operation over a transmit frequency range of
2.5 to 30 MHz and is less efficient than the primary whip.
NOTE:
Can be used without the spring (part number 08-05140-001).
15-00323 NVIS Antenna Kit
Suits the 9350 Automatic Tuning Whip Antenna for improved
short range (0 to 500 km) near vertical incidence skywave
(NVIS) communications over frequency range 2 to 12 MHz.
Includes: two piece whip antenna, angle adaptor, extension
riser, tie down cord kit and fitting instructions in a canvas bag
08-05627-006
08-05627-008
08-05627-030
Cable, Control NGT/Envoy to 9350/304X, 6 m
Cable, Control NGT/Envoy to 9350/304X, 8 m
Cable, Control NGT/Envoy to 9350/304X, 30 m
08-01503-006
08-01503-008
08-01503-020
08-01503-030
Cable, Coax Assembly, UHF Type Connectors, RG58, 6 m
Cable, Coax Assembly, UHF Type Connectors, RG58, 8 m
Cable, Coax Assembly, UHF Type Connectors, RG58, 20 m
Cable, Coax Assembly, UHF Type Connectors, RG58, 30 m
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 93
Issue 8 January 2015
Antennas
3042 HF ANTENNA TUNER
PRODUCT PART NO. DESCRIPTION
ANT-3042-NC 3042 HF Antenna Tuner
(No Cables) 3042 HF Antenna Tuner (No Cables)
The 3042 is a low profile, 125 W HF antenna tuning unit
designed to deliver high performance and reliability in the
world’s harshest environments. It provides high speed and
efficient tuning of short whip antennas across the full
operational HF band.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
08-07154-001
15-00146
15-04174-EN
COMPRISING:
• 3042 HF Antenna Tuner
• Installation Kit
• 3042 Automatic Antenna Tuner Installation Handbook
STANDARD FEATURES:
•2 to 30 MHz
• 125 W RF power handling
• Fast tuning typically < 1sec
• High efficiency
•Waterproof
• MIL-STD-810G Environmentals
• N-type RF Connector
• Used with Vertical & NVIS Whip Antennas
• Flexible mounting
•ALE compatible
• Internal receive mode amplifier
AVAILABLE ACCESSORIES:
See page 95, 3042 Accessories for cables and other parts used
with the 3042.
NGT
TRANSCEIVER
Page 94 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
3042 HF ANTENNA TUNER WITH 6 M CABLES
PRODUCT PART NO. DESCRIPTION
ANT-3042-6M 3042 HF Antenna Tuner
with 6 m Cables 3042 HF Antenna Tuner with 6 m Cables
The 3042 is a low profile, 125 W HF antenna tuning unit
designed to deliver high performance and reliability in the
world’s harshest environments. It provides high speed and
efficient tuning of short whip antennas across the full
operational HF band.
NOTE:
Supplied with 6 m cables to connect the tuner to the antenna.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
08-07154-001
08-05627-006
08-05837-006
15-00146
15-04174-EN
COMPRISING:
• 3042 HF Antenna Tuner
•Control NGT
TM /EnvoyTM to 9350/304X Cable, 6 m
• Coax Assembly Cable with UHF to N-type Connectors,
RG58, 6 m
• Installation Kit
• 3042 Automatic Antenna Tuner Installation Handbook
STANDARD FEATURES:
•2 to 30 MHz
• 125 W RF power handling
• Fast tuning typically < 1sec
• High efficiency
• Waterproof
• MIL-STD-810G Environmentals
• N-type RF Connector
• Used with Vertical & NVIS Whip Antennas
•Flexible mounting
• ALE compatible
• Internal receive mode amplifier
AVAILABLE ACCESSORIES:
See page 95, 3042 Accessories for cables and other parts used
with the 3042.
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 95
Issue 8 January 2015
Antennas
3042 ACCESSORIES
PRODUCT PART NO. DESCRIPTION
15-60020 Single Hole Mount Base
The single hole mount antenna base is designed for lighter
duty installations, and provides the convenience of a small
footprint requiring only a single 14 mm mounting hole.
15-60021
3042 Accessories
3042 Accessories
Flange Mount Base
The flange mount antenna base is designed to provide a
sturdy antenna mount for installations requiring the high
voltage feed line to pass through a vehicle panel. Flange
mount includes rubber gasket and mounting hardware.
15-60022 Flange Mount Bracket
The flange mount bracket provides external side mounting of
the flange mount antenna base. Mounting fasteners must be
provided separately.
08-07148-001 3042 Spring
Flexible mounting for whip antennas. The spring is highly
recommended when using the fibreglass whip and/or riser.
15-60023 3042 Shock Mount
The shock mount for the 3042 Antenna Tuner is
recommended for installations likely to experience extreme
levels of vibration or shock. The mount features quick fit/
release fasteners that require no tools to use. Fitting
instructions are supplied, and an installation kit that will suit
most applications.
78-23086 3042 Stainless Steel Whip
A stainless steel whip offered as a more flexible and less
visually obstructive alternative to the fibreglass version.
The whip is 1.65 m in length.
78-23085 3042 Fibreglass Whip
This is a 1.6 m fibreglass whip and is recommended to be
used with the spring and the riser section. In this
configuration the antenna will operate over a transmit
frequency range of 2.5 to 30 MHz.
78-18058 Riser, Fibreglass
A 0.8 m fibreglass section used to extend the overall length of
the antenna element when using the 1.6 m fibreglass or
stainless steel whips to achieve maximum possible frequency
range (2 to 30 MHz) and radiation performance.
Continued on the next page
NGT
TRANSCEIVER
Page 96 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
3042 ACCESSORIES CONT.
PRODUCT PART NO. DESCRIPTION
15-00146 Installation Kit
Kit containing a selection of fasteners for mounting the
3042 Antenna Tuner.
78-14010 3040/3042 NVIS Antenna Kit
Suits the 3040 Automatic Tuning Whip Antenna/3042
Antenna Tuner for improved short range (0 to 500 km) near
vertical incidence skywave communications mode over
frequency range 2 to 12 MHz.
Includes: 2 section lightweight NVIS whip antenna sections,
tie down cord kit, instruction card and canvas storage bag.
08-05627-002
08-05627-006
08-05627-010
08-05627-020
Cable, Control NGT/Envoy to 9350/304X, 2m
Cable, Control NGT/Envoy to 9350/304X, 6 m
Cable, Control NGT/Envoy to 9350/304X, 10 m
Cable, Control NGT/Envoy to 9350/304X, 20 m
08-05837-002
08-05837-006
08-05837-010
08-05837-020
Cable, Coax Assembly, UHF to N-type Connectors, RG58, 2 m
Cable, Coax Assembly UHF to N-type Connectors, RG58, 6 m
Cable, Coax Assembly UHF to N-type Connectors, RG58, 10 m
Cable, Coax Assembly UHF to N-type Connectors, RG58, 20 m
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 97
Issue 8 January 2015
Antennas
TUNERS Tuners
PRODUCT PART NO. DESCRIPTION
Tuners
08-04835-013 Tuner, 9103 Automatic Antenna with 10 m Cables
Designed to suit NGT™/Envoy™ Transceivers. Rated to
150 W PEP voice or data.
Includes: mounting bracket, control cable (10 m) to suit NGTTM
Transceiver, coaxial cable (10 m) and installation/operation
handbook
08-04835-015 Tuner, 9103 Automatic Antenna with 30 m Cables
Designed to suit NGT™/Envoy™ series Transceivers. Rated to
150 W PEP voice or data.
Includes: mounting bracket, control cable (30 m) to suit NGTTM
Transceiver, coaxial cable (30 m) and installation/operation
handbook
08-06739-001 Tuner, SG235C 500 W PEP
Designed to suit 500 W high power NGT™/Envoy™ systems.
Includes: mounting bracket and installation/operation
handbook
NOTE:
• Maximum power input in data mode 300 W average.
• Control and coaxial cables are not supplied. For the control
cable, see Tuner Accessories below. For coaxial cables, see
page 109, Coaxial Cables.
TUNER ACCESSORIES Tuner Accessories
PRODUCT PART NO. DESCRIPTION
30-37601-002
Tuner Accessories
Copper Earth Strip
50 mm x 0.46 mm (26 gauge) supplied in units of 1 m
08-06740-030 Cable, SG235C Control, 30 m
08-01503-030 Cable SG235C Coax Assembly, UHF type connectors, RG58,
30 m
NOTE:
For coaxial cables, see page 109, Coaxial Cables.
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Page 98 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
BASE WHIP
PRODUCT PART NO. DESCRIPTION
Base Whip Antenna The Base Whip Antenna is 9.5 m (31 ft) in height, and requires
an automatic antenna tuner. It is mounted vertically on a
suitable ground plane or metal roof. An earth mat may be
required where a suitable ground plane cannot be found.
This antenna may be used where space is restricted and
omnidirectional coverage is required.
Antenna rated to 500 W PEP. See page 97, Tuners for available
tuner options.
15-00406-001 Ant, Base Whip, Ground Mounting (9.5 m/31 ft Unloaded)
Comes complete with ground mounting plate, guy kit and
guy clamps, guy anchors, HV lead and installation
instructions.
NOTE:
• Coaxial cable and tuner are not supplied.
• May require radial ground plane for ground installations.
• Compatible with 9103 and SG235C Antenna tuners, see
page 96 for more details on tuners
• Guying details: One guy set with four guy wires. 4 m guy
radius.
• Guy anchor points not supplied.
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
15-00406-002 Ant, Base Whip, Roof Mounting (9.5 m/31 ft Unloaded)
Comes complete with roof mounting bracket, guy kit and guy
clamps, HV lead and installation instructions.
NOTE:
• Coaxial cable and tuner are not supplied.
• Compatible with 9103 and SG235C Antenna tuners, see
page 96 for more details on tuners
• Requires radial ground plane for non-metallic roof
installations.
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
• Guying details: One guy set with four guy wires. 4 m guy
radius.
BASE WHIP ACCESSORIES
PRODUCT PART NO. DESCRIPTION
15-00158 Earth Mat for Base Whip Antenna, Ground Installations
15-00159
Base Whip Accessories Radial Ground Plane for Base Whip Antenna, Roof
Installations
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 99
Issue 8 January 2015
Antennas
TUNED LONG WIRE Tuned Long Wire
Antenna
PRODUCT PART NO. DESCRIPTION
15-00403 Ant, Tuned Long Wire (2–30 MHz)
This antenna exhibits a good combination of space efficiency
and broadband capability. It is designed to be used with an
antenna tuner.
A suitable antenna where space is limited. The Long Wire
antenna may be deployed in a sloping wire or Inverted-L
configuration.
NOTE:
• Compatible with 9103 and SG235C Antenna tuners, see
page 96 for more details on tuners.
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
• When installed as an Inverted-L configuration the
minimum recommended height is 6 m.
• When installed as a sloping long wire the minimum height
at the high end should be 6 m but can be as high as 15 m
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
NGT
TRANSCEIVER
Page 100 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
3048 TUNED DIPOLE Tuned Long Wire
Antenna
PRODUCT PART NO. DESCRIPTION
ANT-3048-20M 3048 Tuned Dipole Antenna with 20 m cables
The 3048 Tuned Dipole is an HF antenna solution designed
for base station use. When compared to wire broadband
antennas the 3048 has a significantly reduced installed
footprint, which is a benefit for installations where space is
restricted.
The 3048 antenna system comprises a main tuner unit and 4
element antenna assembly mounted on top of a 6 m mast. A
control cable and coaxial cable run down from the tuner unit
to an interface box mounted at the base of the mast. The
interface box provides connection points for the transceiver
antenna control and RF cables as well as the RF ground.
NOTE:
• Interface box coaxial connection uses a UHF type RF
connector
• 6 m mast uses two guys sets, each with 4 guy wires and guy
radius of 4 m
• Maximum recommended control cable length between the
interface box and transceiver is 20 m
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
08-07324-001
15-04185-EN
78-13038
08-01503-020
08-05627-020
COMPRISING:
• Antenna, Tuned Diopole, 3048
• 3048 Tuned Dipole Installation Handbook
• 6 m guyed mast for 3048 Tuned Dipole
• Coax assembly cable with UHF connectors, RG58, 20 m
• Control NGT/Envoy to 9350/304X Cable, 20 m
FEATURES:
•2.5-30 MHz
• 125 W power handling (voice and data)
• Fast tune typically <1 sec
• Unlimited memory tune
• High efficiency
• Waterproof
• Designed to MIL-STD-810G
• Internal receive mode amplifier
• Small installed footprint
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 101
Issue 8 January 2015
Antennas
TRAVELLING WAVE DIPOLE
PRODUCT PART NO. DESCRIPTION
Travelling Wave Dipole
Antenna The Travelling Wave Dipole Antenna is efficient for short to
medium distance communications. Its radiation patterns are
generally omni-directional, resulting in a consistent coverage
over the frequency range. Designed for 100% duty cycle voice
and data operation at the rated power level.
This antenna requires a substantial cleared area at ground
level for installation, and is more suitable for permanent fixed
site installations. Refer to the antenna data sheet for more
details.
Includes: pulleys, halyards and installation hardware
NOTE:
• Recommended mast for the 53 m antenna variants is the
15-00422-015, 15 m guyed mast. For further information
on masts see page 107, Antenna Masts.
• Recommended mast for the 40 m variants is the 15-00422-
012, 12 m guyed mast
• Coaxial cable and masts not supplied. For coaxial cables,
see page 109, Coaxial Cables.
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
• Antenna lengths quoted are required mast to mast
distances.
• Antenna is fitted with UHF type RF connector.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
78-01248 Ant, Travelling Wave Dipole (2–30 MHz, 125 W PEP), 53 m
78-01249 Ant, Travelling Wave Dipole (3–30 MHz, 125 W PEP), 40 m
78-01250 Ant, Travelling Wave Dipole (2–30 MHz, 1000 W PEP), 53 m
78-01251 Ant, Travelling Wave Dipole (3–30 MHz, 1000 W PEP), 40 m
NGT
TRANSCEIVER
Page 102 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
DELTA
PRODUCT PART NO. DESCRIPTION
Delta Antenna The Delta Antenna is a high performance, omni-directional
broadband antenna that performs well over very short to
medium distances. Designed for 100% duty cycle voice and
data operation at the rated power level.
This antenna requires a substantial cleared area at ground
level for installation, and is more suitable for permanent fixed
site installations. Refer to the antenna data sheet for more
details.
NOTE:
• Recommended mast is 15-00422-015, 15 m guyed mast.
For further information on masts see page 107,
Antenna Masts.
• Distance between antenna guy anchors is 46 m.
• Antenna is fitted with UHF type RF connector.
•The Delta Antenna is not recommended for rooftop
installations.
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
• Coaxial cable and mast not supplied. For coaxial cables, see
page 109, Coaxial Cables.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
78-01022 Ant, Full Delta (3–30 MHz, 125 W)
78-01247 Ant, Full Delta (3 –30 MHz, 1000 W PEP)
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 103
Issue 8 January 2015
Antennas
SEMI-DELTA
PRODUCT PART NO. DESCRIPTION
Semi-delta Antenna The Semi-delta Antenna is a high performance,
omnidirectional broadband antenna that performs well over
short to medium distances.
This antenna requires a large cleared area at ground level for
installation, and is more suitable for permanent fixed
site installations.
NOTE:
• Recommended mast is 15-00422-015, 15 m guyed mast
however the 15-00422-012 12 m guyed mast may also be
used. Using the 12 m mast will increase the required
distance between the main mast and stub mast.
Recommended stub mast height is 2 m. For further
information on masts see page 107, Antenna Masts.
• Distance between main mast and stub mast is 20 m with
15 m main mast and 24 m with 12 m main mast.
• Antenna is fitted with UHF type RF connector.
• An antenna counterpoise/ground is required when
mounted on non-metallic roofs or the ground where soil
conductivity conditions are very poor.
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
• Coaxial cable and masts not supplied. For coaxial cables,
see page 109, Coaxial Cables.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
78-01012 Ant, Semi-delta (2–14 MHz, 125 W PEP)
Includes: pulleys, halyards, basic installation hardware, and
installation instructions
78-01246 Ant, Semi-delta (2–14 MHz, 1000 W PEP)
Includes: pulleys, halyards, basic installation hardware, and
installation instructions
NGT
TRANSCEIVER
Page 104 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
TFD411 BROADBAND
PRODUCT PART NO. DESCRIPTION
TFD411 Broadband
Antenna The Code 411 TFD is a 2-wire terminated folded dipole
antenna designed for broadband operation. Designed for
100% duty cycle voice and data operation at the rated
power level.
The antenna is easy to install and can be mounted
horizontally between two support systems, or as an inverted
V using a single central support mast. A large cleared area at
ground level is required for installation. Refer to the antenna
data sheet for more details.
Includes: stainless steel antenna wiring, pulleys, rope,
halyard, UHF coaxial connector and installation instructions
NOTE:
• Recommended mast for the 27 m and 34 m variants of this
antenna for horizontal and inverted V configurations is the
10 m Premium Mast (15-60033 or 15-60034).
• The masthead gibbet (15-60035) is also required if
installing the 27 m and 34 m variants of these antennas on
the 10 m mast as inverted V.
• Recommended mast for the 43 m variant of this antenna
for horizontal and inverted V configurations is the 12 m
Mast (15-00422-012).
• For further information on masts see page 107,
Antenna Masts.
• Always select the longest antenna variant possible to
maximise propagation efficiency and performance.
• Antenna is fitted with UHF type RF connector.
• Coaxial cable and masts not supplied. For coaxial cables,
see page 109, Coaxial Cables.
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
15-00411-005 Ant, TFD411, 125 W, 2–30 MHz, 27 m
15-00411-004 Ant, TFD411, 125 W, 2–30 MHz, 34 m
15-00411-003 Ant, TFD411, 125 W, 2–30 MHz, 43 m
15-00411-011 Ant, TFD411, 1000 W, 2–30 MHz, 34 m
15-00411-012 Ant, TFD411, 1000 W, 2–30 MHz, 43 m
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 105
Issue 8 January 2015
Antennas
Horizontal Mounting
Inverted ‘V’ Mounting
NOTE:
• Antenna installation dimensions for inverted V assume stub mast heights of 2 m with guy radius of 2 m
• Installation dimensions assume level surface and may vary with sloping or irregular sites
• Mast height (c) for inverted V mounting assumes a masthead gibbet which effectively increases the mast height
by 0.5 m
TFD411 BROADBAND
Length Part Numbers Dimensions (m)
abcdefg
43 m 15-00411-003 / 012 12 47 12.5 2 20 22 2
34 m 15-00411-004 / 011 10 37 10.5 2 16 18 2
27 m 15-00411-005 10 30 10.5 2 11.7 13.7 2
NGT
TRANSCEIVER
Page 106 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
TFD411 BROADBAND/MAST KITS
PRODUCT PART NO. DESCRIPTION
TFD411 Broadband/Mast
Kits The Terminated Folded Dipole 411 Antenna and Mast Kit
provides an easy to deploy and economical antenna solution
for 125 W base station applications. The kits are available
with different mast finishes and antenna lengths to meet
customer requirements. The kits are designed for inverted V
antenna configuration to minimise installation footprint and
optimise short to medium distance HF communications.
NOTE:
• The 10 m premium guyed mast is included as part of this
antenna. For further information on masts see page 107,
Antenna Masts.
• Always select the longest antenna variant possible to
maximise propagation efficiency and performance.
• Antennas are fitted with a UHF type RF connector.
• Coaxial cable is not supplied. For coaxial cables, see
page 109, Coaxial Cables.
• Lightning protection is recommended for fixed base station
installations, see page 110, Lightning Protection.
COMPATIBILITY:
• With ALL NGT™ and Envoy™ series Transceivers
15-60018-005
Antenna/Mast — Mast Bare Aluminium Finish
Ant, TFD411, 125 W, 2–30 MHz, 27 m c/w Lightweight
Premium Mast, 10 m
15-60018-004 Ant, TFD411, 125 W, 2–30 MHz, 34 m c/w Lightweight
Premium Mast, 10 m
15-60018-003 Ant, TFD411, 125 W, 2–30 MHz, 43 m c/w Lightweight
Premium Mast, 10 m
15-60018-105
Antenna/Mast — Mast Matt Black Paint Finish
Ant, TFD411, 125 W, 2–30 MHz, 27 m c/w Lightweight
Premium Black Painted Mast, 10 m
15-60018-104 Ant, TFD411, 125 W, 2–30 MHz, 34 m c/w Lightweight
Premium Black Painted Mast, 10 m
15-60018-103 Ant, TFD411, 125 W, 2–30 MHz, 43 m c/w Lightweight
Premium Black Painted Mast, 10 m
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 107
Issue 8 January 2015
Antennas
NOTE: Pictures for illustrative purposes only.
ANTENNA MASTS Antenna Masts
PRODUCT PART NO. DESCRIPTION
15-00422-012
Antenna Masts Mast, Guyed 12 m with Erection Kit
Four section 12 m mast.
Guyed tubular aluminium mast with ground plate, halyard
pulley, RF transparent guy kit, full erection kit, mast head
gibbet and erection instructions.
Designed to withstand wind speeds up to 144 kph (40 m/s) in
clear air with head loads up to 12 kg, subject to ground
anchoring.
NOTE:
• Guying details: Four guy sets, each with four guy wires. 6 m
guy radius.
• Mast suitable for air freight.
COMPATIBILITY:
• Compatible with Tuned Long Wire (15-00403), Travelling
Wave Dipole (78-01248, 78-01249, 78-01250), Semi Delta
(78-01012 and 78-01246) TFD411 (15-00411-0XX series).
Check antenna section for specific details of antennas see
page 97.
15-00422-015 Mast, Guyed 15 m with Erection Kit
Five section 15 m mast.
Guyed tubular aluminium mast with ground plate, halyard
pulley, RF transparent guy kit, full erection kit, mast head
gibbet and erection instructions.
Designed to withstand wind speeds up to 144 kph (40 m/s) in
clear air with head loads up to 12 kg, subject to ground
anchoring.
NOTE:
• Guying details: Five guy sets, each with four guy wires. 7 m
guy radius.
• Mast suitable for air freight.
COMPATIBILITY:
• Compatible with Tuned Long Wire (15-00403), Travelling
Wave Dipole (78-01248, 78-01249, 78-01250), Full Delta
(78-01012 and 78-01246) TFD411 (15-00411-0XX series).
Check antenna section for specific details of antennas see
page 97.
NGT
TRANSCEIVER
Page 108 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
MASTS, GUYED 10 M Antenna Masts
PRODUCT PART NO. DESCRIPTION
15-60013 Mast, Guyed 10 m, Lightweight Mast
Lightweight guyed aluminium mast, halyard, and all
hardware for ground mounting.
NOTE:
• Guy details: Two guy sets, each with three guy wires and
one back stay guy. 5 m guy radius.
• Mast suitable for air freight.
COMPATIBILITY:
• Compatible with Tuned Long Wire (15-00403), TFD411
(15-00411-0XX series). Check antenna section for
recommended masts for these antennas.
15-60033
15-60034
Mast, Guyed 10 m, Premium Mast (Raw)
Mast, Guyed 10 m, Premium Mast (Black)
Lightweight guyed aluminium mast available in raw finish or
painted black. This mast features full stainless steel guys with
rope tails and turnbuckles for quicker and easier installation.
Mast kit includes rope halyard, guy anchors (for ground
mount) hammer, spintight for cable clamps, and installation
instructions.
NOTE:
• Guy details: Two guy sets, each with three guy wires and
one back stay guy. 5 m guy radius.
• Mast suitable for air freight.
COMPATIBILITY:
• Compatible with Tuned Long Wire (15-00403), TFD411
(15-00411-0XX series). Check antenna section for
recommended masts for these antennas.
ACCESSORIES:
15-60035 Gibbet, 10 m Mast
Gibbet assembly for mounting antennas to the 10 m
Premium mast in Inverted V configuration.
NOTE:
Required when mounting the TFD411 series antenna (15-
00411-0XX) in inverted V using the 10 m Lightweight (15-
60013) or 10 m Premium masts (15-60033 or 15-60034)
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 109
Issue 8 January 2015
Antennas
COAXIAL CABLES TYPE RG58
PRODUCT PART NO. DESCRIPTION
Coaxial Cable
08-01503-002 Cable, Coax Assembly, UHF Type Connectors, RG58, 2 m
08-01503-006 Cable, Coax Assembly, UHF Type Connectors, RG58, 6 m
08-01503-008 Cable, Coax Assembly, UHF Type Connectors, RG58, 8 m
08-01503-020 Cable, Coax Assembly, UHF Type Connectors, RG58, 20 m
08-01503-030 Cable, Coax Assembly, UHF Type Connectors, RG58, 30 m
08-05837-002 Cable, Coax Assembly, UHF to N-type Connectors, RG58, 2 m
08-05837-006 Cable, Coax Assembly UHF to N-type Connectors, RG58, 6 m
08-05837-010 Cable, Coax Assembly UHF to N-type Connectors, RG58, 10 m
08-05837-020 Cable, Coax Assembly UHF to N-type Connectors, RG58, 20 m
08-05837-030 Cable, Coax Assembly UHF to N-type Connectors, RG58, 30 m
60-11163-221
Coaxial Cables Type RG58
Plug, UHF (RG58) W/proof
COAXIAL CABLES TYPE RG213
PRODUCT PART NO. DESCRIPTION
08-04971-006 Cable, Coax Assembly, UHF Type Connectors, RG213, 6 m
08-04971-010 Cable, Coax Assembly, UHF Type Connectors, RG213, 10 m
08-04971-030 Cable, Coax Assembly, UHF Type Connectors, RG213, 30 m
08-04971-050 Cable, Coax Assembly, UHF Type Connectors, RG213, 50 m
08-04971-100 Cable, Coax Assembly, UHF Type Connectors, RG213, 100 m
08-01233
Coaxial Cables Type
RG213
Strain Relief
Reduces strain on connector when supporting RG213 cable
assemblies.
30-38000-002 Shackle
Used to attach strain relief to the antenna.
60-11163-204 Plug, UHF (RG213) W/proof
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Page 110 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas
LIGHTNING PROTECTION
PRODUCT PART NO. DESCRIPTION
15-00464
Lightning Protection Lightning Arrestor
Self-resetting spark gap arrestor. Requires a good earth to
divert energy from a nearby lightning strike.
NOTE:
Extra length of coaxial cable or extra UHF plug may need to
be ordered to fit lightning arrestor into RF feed system.
30-37601-002 Copper Earth Strip
50 mm x 0.46 mm (26 gauge) supplied in units of 1 m
15-00163 Earth Stake
1.8 m long x 13 mm with clamp for earth wire/strip.
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 111
Issue 8 January 2015
Antennas
This page has been intentionally left blank.
Page 112 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas for Australia
3040 AUTOMATIC TUNING WHIP
STANDARD PACKAGE
PRODUCT PART NO. DESCRIPTION
ANT-3040-STD 3040 Automatic Tuning
Whip Antenna Standard
Package for Australia
3040 Automatic Tuning Whip Standard Package
The 3040 Automatic Whip Antenna is a low profile, rugged,
lightweight unit designed for mobile installations. It provides
fast automated tuning across the HF band.
The 3040 is easy to install and meets MIL-STD-810F for shock,
immersion, dust and vibration.
NOTE:
Supplied with 6 m cables to connect the 3040 Antenna to an
NGT™ Transceiver.
08-07007-001
08-05627-006
08-01503-006
08-07148-001
78-18058
78-23085
78-23086
15-60012
COMPRISING:
• 3040 Main Assembly
•Control NGT
TM /EnvoyTM to 9350/304X Cable, 6 m
• Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
• 3040 Spring
• Riser, Fibreglass
• 3040 Fibreglass Whip, 1.6 m
• 3040 Stainless Steel Whip, 1.6 m
• 3040 Installation Handbook (includes sealing kit)
STANDARD FEATURES:
• 2.5 to 30 MHz
• 125 W PEP voice or data
• Fast tuning typically < 1sec
• Tune from memory
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 113
Issue 8 January 2015
Antennas for Australia
3040 AUTOMATIC TUNING WHIP
EXPLORER PACKAGE
PRODUCT PART NO. DESCRIPTION
ANT-3040-EXP 3040 Automatic Tuning Whip Explorer Package
The 3040 Automatic Whip Antenna is a low profile, rugged,
lightweight unit designed for mobile installations. It provides
fast automated tuning across the HF band.
The 3040 is easy to install and meets MIL-STD-810F for shock,
immersion, dust and vibration.
NOTE:
Supplied with 6 m cables to connect the 3040 Antenna to an
NGT™ Transceiver.
08-07007-001
08-05627-006
08-01503-006
08-07148-001
78-18058
78-23086
15-60012
COMPRISING:
• 3040 Main Assembly
• Control NGTTM /EnvoyTM to 9350/304X Cable, 6 m
• Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
• 3040 Spring
• Riser, Fibreglass
• 3040 Stainless Steel Whip, 1.6 m
• 3040 Installation Handbook (includes sealing kit)
STANDARD FEATURES:
•2.5 to 30 MHz
• 125 W PEP voice or data
• Fast tuning typically < 1sec
• Tune from memory
NGT
TRANSCEIVER
Page 114 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antennas for Australia
9350 AUTOMATIC TUNING WHIP
STANDARD PACKAGE
PRODUCT PART NO. DESCRIPTION
ANT-9350-STD 9350 Automatic Tuning
Whip Standard Package for
Australia
9350 Automatic Tuning Whip Standard Package
A robust antenna designed for mobile installations requiring
flexible, high performance HF communications. It provides
fast automated tuning over the HF range.
The 9350 is easy to install, and meets MIL-STD-810F for shock
and vibration.
NOTE:
Supplied with 6 m cables to connect the 9350 Antenna to an
NGT™ Transceiver.
08-05063-001
08-05627-006
08-01503-006
08-05140-001
78-23007-003
78-23025
15-04142-EN
COMPRISING:
• 9350 Main Assembly
•Control NGT
TM /EnvoyTM to 9350/304X Cable, 6 m
• Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
• 9350 Spring
• 9350 Fibreglass Whip, 1.6 m
• 9350 Tapered Stainless Steel Whip, 1.2 m
• Automatic Tuning Whip Antenna 9350 Installation
Handbook
STANDARD FEATURES:
• 125 W PEP voice or data
•Tuning typically 2 seconds
• Transmit frequency range 2 to 30 MHz depending on
antenna
• Receive frequency range 250 kHz to 30 MHz
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 115
Issue 8 January 2015
Antennas for Australia
9350 AUTOMATIC TUNING WHIP
VENTURER PACKAGE
PRODUCT PART NO. DESCRIPTION
ANT-9350-VENT 9350 Automatic Tuning
Whip Venturer Package for
Australia
9350 Automatic Tuning Whip Venturer Package
A robust antenna designed for mobile installations requiring
flexible, high performance HF communications. It provides
fast automated tuning over the HF range.
The 9350 is easy to install, and meets MIL-STD-810F for shock
and vibration.
NOTE:
Supplied with 6 m cables to connect the 9350 Antenna to an
NGT™ Transceiver.
08-05063-001
08-05627-006
08-01503-006
78-23056
15-04142-EN
COMPRISING:
• 9350 Main Assembly
• Control NGTTM /EnvoyTM to 9350/304X Cable, 6 m
• Coax Assembly Cable, UHF Type Connectors, RG58, 6 m
• 9350 Tapered Stainless Steel Whip, 1.6 m
• Automatic Tuning Whip Antenna 9350 Installation
Handbook
STANDARD FEATURES:
• 125 W PEP voice or data
• Tuning typically 2 seconds
• Transmit frequency range 2 to 30 MHz depending on
antenna
• Receive frequency range 250 kHz to 30 MHz
NGT
TRANSCEIVER
Page 116 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
fThis page has been intentionally left blank.
Antennas for Australia
Codan Radio Communications Commercial Product Catalogue Page 117
Issue 8 January 2015
Remote Control
ENVOY™ REMOTE CONTROL ACCESSORIES—
ETHERNET
PRODUCT PART NO. DESCRIPTION
REMOTE-ENVOY-ETH Ethernet Remote Control
Accessories — Ethernet
Envoy Remote
Control Accessories
— Ethernet
Envoy Remote Control Accessories — Ethernet
These parts are required to facilitate connection of a
2230 Desktop Console to an X1 or X2 RF Unit via Ethernet
cable. The transceiver to Ethernet adaptor is used to convert
the 10-pin RF Unit control connector to RJ45 Ethernet socket.
The power supply is required to provide power to the
2230 Desktop Console as the Ethernet cable does not provide
power from the RF Unit.
08-07215-001
78-16019
67-9020#
COMPRISING:
Cable, Tcvr to Ethernet Adaptor
Desk Console AC Mains Power Supply
2C IEC C7 Cable, 2 m (for cable options, see page 119, NGT™
Remote Control Accessories)
67-90802 Cable, Ethernet Straight CAT-5E, 2 m Blue
67-90803 Cable, Ethernet Straight CAT-5E, 10 m Blue
67-90805 Cable, Ethernet Straight CAT-5E, 100 m Blue
# denotes the cable variant depending upon country of use
Page 118 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Remote Control
NGT™ REMOTE CONTROL EQUIPMENT—2-WIRE
PRODUCT PART NO. DESCRIPTION
NGT™ Remote Control
Equipment — 2-wire
Interface
NGT™ Remote 2-wire Interface
An NGT™ Remote Control System is the smart and easy way
to achieve clear and reliable communications when your
transceiver site is located in an area affected by electrical
interference. The NGT™ HF transceiver is relocated to a ‘quiet’
area, while the transceiver is fully operated from a convenient
location, such as an office or communication centre.
To create a remote control system, an NGT™ Base Station
configuration is extended with a 3030 NGT
™
Remote
Interface (NRI), which converts both audio and control into
RS232 signals. A line modem is required for 2-wire leased line
operation.
NOTE:
• Remote control configurations can only be used with NGTTM
SR and ASR Transceivers.
• Only used with the 3012 HF Data Modem.
• Two NRIs are required for a complete remote control
system.
• Specify the mains connector type (AU, EU, UK or US),
seepage119, NGT™ Remote Control Accessories.
REMOTE-NRI-CTRL-2W
08-05864-001
15-00135
78-13016
78-16019
60-00063-501
08-04146-001
08-05858-001
08-05859-001
67-90203
30-11208-000
15-04102-EN
COMPRISING:
Control Site
• 3030 NGTTM Remote Interface
•NGT
TM Remote Control Earth Kit for the Control Site
•Leased Line Modem
• Power Supply Unit, 90 to 264 V AC
• 6-way Modular Wall Mounting Socket
• 6-way Phone Cable
• NRI to Line Modem Cable
• NRI to Line Modem Power Cable
• 2C IEC C7 Cable, 2 m (for cable options, see page 119, NGT™
Remote Control Accessories)
• Self Adhesive Rubber Feet (x4)
•Remote Control NGT
TM Systems Reference Manual (see
page 165, Language Support for translations of this manual)
REMOTE-NRI-TCVR-2W
08-05864-001
15-00134
78-13016
60-00063-501
08-05610-001
08-04146-001
08-05858-001
08-05868-001
08-05859-001
30-11208-000
Transceiver Site
• 3030 NGTTM Remote Interface
•NGT
TM Remote Control Earth Kit for the Remote Site
•Leased Line Modem
• 6-way Modular Wall Mounting Socket
• CIB Interface Cable, 0.5 m
• 6-way Phone Cable
• NRI to Line Modem Cable
• Power Cable to RF Unit and NRI
• NRI to Line Modem Power Cable
• Self Adhesive Rubber Feet (x4)
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 119
Issue 8 January 2015
Remote Control
NGT™ REMOTE CONTROL ACCESSORIES
PRODUCT PART NO. DESCRIPTION
08-05920-001
NGT™ Remote Control
Accessories
Cable, DC Extension, 1 m
The extra length this cable provides may be needed to
connect the power supply to the RF Unit in rack
configurations.
NGT™ Remote Control Accessories
08-05610-001
08-05610-002
08-05610-006
08-05610-030
Cable, CIB Interface, 0.5 m
Cable, CIB Interface, 2 m
Cable, CIB Interface, 6 m
Cable, CIB Interface, 30 m
08-05086-001
08-05086-006
Cable, Data Interface, 2 m
Cable, Data Interface, 6 m
67-90200 Cable, 2C IEC C7 AUS, 2 m
67-90201 Cable, 2C IEC C7 UK, 2 m
67-90202 Cable, 2C IEC C7 US, 2 m
67-90203 Cable, 2C IEC C7 EU, 2 m
15-00172-001 NGT™ Universal 19" Rack-mounting Tray 3RU with Blank
Front Panel
Suitable for a 3030 NRI.
NGT
TRANSCEIVER
Page 120 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Remote Control
NGT™ SPLIT-SITE EQUIPMENT — 2-WIRE
PRODUCT PART NO. DESCRIPTION
NGT™ Split-site
Equipment — 2-wire
Interface
NGT™ Split-site System — 2-wire Interface
An NGT™ Split-site Remote System consists of two or three
sites. Each site consists of the split-site equipment listed
below, in addition to the transceiver equipment.
An NGT™ Split-site Remote System can be used to split
control, transmit and receive functions of an NGT™ SR or ASR
Transceiver system into one of the following basic
configurations:
• NGT™ remote transmitter and remote receiver system
(3 sites)
• NGT™ remote transceiver system (2 sites)
• NGT™ local transmitter, remote receiver system (2 sites)
The system operates with a standard 2-wire interface.
Contact Codan for detailed system configurations.
NOTE:
• Split-site configurations can only be used with NGTTM SR
and ASR Transceivers, and requires one transceiver at each
site.
• All NGTTM SR and ASR Transceiver functions available.
• Existing transceivers may require modifications for use in
split-site configurations. Contact Codan for details.
• Suitable for use with the 3012 HF Data Modem.
REMOTE-SPLIT-CTRL-8571-2W
08-05630-005
08-05994-001
08-04515-001
08-05610-001
08-05989-001
08-05990-001
15-10509-000
15-30067
15-04125-EN
COMPRISING:
Control Site
• Split-site Interface Control Junction Box
• 8571 NGTTM Remote Control Interface
•Earth Wire, 0.5m (x5)
• CIB Interface Cable, 0.5 m
• Split-site Power Adaptor Cable
• 8571 NGTTM Interface Controller Cable
• Opt 2 W, 2-wire (Factory Fit) (x2)
•NGT
TM Audio Mute Modification
• Split-site Remote Control NGTTM Systems Reference Manual
(English)
NOTE:
Control Site can only used for transmitting.
Continued on the next page
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 121
Issue 8 January 2015
Remote Control
NGT™ SPLIT-SITE EQUIPMENT—2-WIRE cont.
PRODUCT PART NO. DESCRIPTION
REMOTE-SPLIT-RX-8571-2W
08-05630-005
08-05994-001
08-04515-001
08-05610-001
08-05989-001
08-05990-001
15-10509-000
15-30068
Receive Site
COMPRISING
• Split-site Interface Control Junction Box
• 8571 NGTTM Remote Control Interface
•Earth Wire, 0.5m (x5)
• CIB Interface Cable, 0.5 m
• Split-site Power Adaptor Cable
• 8571 NGTTM Interface Controller Cable
• Opt 2 W, 2-wire (Factory Fit)
•NGT
TM Disable PA Modification
NOTE:
Receive Site can only be used for receiving, transmitter is
disabled.
REMOTE-SPLIT-TX-8571-2W
08-05630-005
08-05994-001
08-04515-001
08-05610-001
08-05989-001
08-05990-001
15-10509-000
Transmit Site
COMPRISING
• Split-site Interface Control Junction Box
• 8571 NGTTM Remote Control Interface
•Earth Wire, 0.5m (x5)
• CIB Interface Cable, 0.5 m
• Split-site Power Adaptor Cable
• 8571 NGTTM Interface Controller Cable
• Opt 2 W, 2-wire (Factory Fit)
NOTE:
Transmit Site is configured for transmitting only but can be
switched to either receive, or transmit and receive.
REMOTE-SPLIT-TXRX-8571-2W
08-05630-005
08-05994-001
08-04515-001
08-05610-001
08-05989-001
08-05990-001
15-10509-000
Transmit & Receive Site
COMPRISING
• Split-site Interface Control Junction Box
• 8571 NGTTM Remote Control Interface
•Earth Wire, 0.5m (x5)
• CIB Interface Cable, 0.5 m
• Split-site Power Adaptor Cable
• 8571 NGTTM Interface Controller Cable
• Opt 2 W, 2-wire (Factory Fit)
NOTE:
Transmit and Receive Site is configured for transmitting
and receiving but can be switched to either receive or
transmit only.
NGT
TRANSCEIVER
Page 122 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Remote Control
NGT™ SPLIT-SITE EQUIPMENT—4-WIRE
PRODUCT PART NO. DESCRIPTION
NGT™ Split-site
Equipment — 4-wire
Interface
NGT™ Split-site System — 4-wire Interface
An NGT™ Split-site Remote System consists of two or three
sites. Each site consists of the split-site equipment listed
below, in addition to the transceiver equipment.
An NGT™ Split-site Remote System can be used to split
control, transmit and receive functions of an NGT™ SR or ASR
Transceiver system into one of the following basic
configurations:
• NGT™ remote transmitter and remote receiver system
(3 sites)
• NGT™ remote transceiver system (2 sites)
• NGT™ local transmitter, remote receiver system (2 sites)
The system operates with a standard 4-wire interface.
Contact Codan for detailed system configurations.
NOTE:
• Split-site configurations can only be used with NGTTM SR
and ASR Transceivers, and requires one transceiver at each
site.
• All NGTTM SR and ASR Transceiver functions available.
• Existing transceivers may require modifications for use in
split-site configurations. Contact Codan for details.
• Suitable for use with the 3012 HF Data Modem.
REMOTE-SPLIT-CTRL-8571-4W
08-05630-005
08-05994-001
08-04515-001
08-05610-001
08-05989-001
08-05990-001
15-10510-002
15-30067
15-04125-EN
Control Site
COMPRISING:
• Split-site Interface Control Junction Box
• 8571 NGTTM Remote Control Interface
•Earth Wire, 0.5m (x5)
• CIB Interface Cable, 0.5 m
• Split-site Power Adaptor Cable
• 8571 NGTTM Interface Controller Cable
• Opt 4 W, 4-wire Interface Master Site (x2)
•NGT
TM Audio Mute Modification
• Split-site Remote Control NGTTM Systems Reference Manual
(English)
Continued on the next page
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 123
Issue 8 January 2015
Remote Control
NGT™ SPLIT-SITE EQUIPMENT—4-WIRE cont.
PRODUCT PART NO. DESCRIPTION
REMOTE-SPLIT-RX-8571-4W
08-05630-005
08-05994-001
08-04515-001
08-05610-001
08-05989-001
08-05990-001
15-10510-004
15-30068
Receive Site
COMPRISING:
• Split-site Interface Control Junction Box
• 8571 NGTTM Remote Control Interface
•Earth Wire, 0.5m (x5)
• CIB Interface Cable, 0.5 m
• Split-site Power Adaptor Cable
• 8571 NGTTM Interface Controller Cable
• Opt 4 W, 4-wire Interface Slave Receive Site
•NGT
TM Disable PA Modification
NOTE:
Receive Site is only used for receiving, transmitter is disabled.
REMOTE-SPLIT-TX-8571-4W
08-05630-005
08-05994-001
08-04515-001
08-05610-001
08-05989-001
08-05990-001
15-10510-003
Transmit Site
COMPRISING:
• Split-site Interface Control Junction Box
• 8571 NGTTM Remote Control Interface
•Earth Wire, 0.5m (x5)
• CIB Interface Cable, 0.5 m
• Split-site Power Adaptor Cable
• 8571 NGTTM Interface Controller Cable
• Opt 4 W, 4-wire Interface Slave Transmit Site
NOTE:
Transmit Site is configured for transmitting only but can be
switched to either receive, or transmit and receive.
REMOTE-SPLIT-TXRX-8571-4W
08-05630-005
08-05994-001
08-04515-001
08-05610-001
08-05989-001
08-05990-001
15-10510-003
Transmit & Receive Site
COMPRISING
• Split-site Interface Control Junction Box
• 8571 NGTTM Remote Control Interface
•Earth Wire, 0.5m (x5)
• CIB Interface Cable, 0.5 m
• Split-site Power Adaptor Cable
• 8571 NGTTM Interface Controller Cable
• Opt 4 W, 4-wire Interface Slave Transmit Site
NOTE:
Transmit and Receive Site is configured for transmitting
and receiving but can be switched to either receive or
transmit only.
NGT
TRANSCEIVER
Page 124 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Remote Control
SPLIT-SITE ACCESSORIES
PRODUCT PART NO. DESCRIPTION
15-00164-010
Split-site Accessories 19" Rack-mounting Frame for 8571 Split-site Remote
Interface
08-04146-001 Cable, 6-way Phone
08-04284 Cable, Phone Plug Adaptor Modular to 604 Plug
08-05610-001
08-05610-002
08-05610-006
08-05610-030
Cable, CIB Interface, 0.5 m
Cable, CIB Interface, 2 m
Cable, CIB Interface, 6 m
Cable, CIB Interface, 30 m
08-05086-001
08-05086-006
Cable, Data Interface, 2 m
Cable, Data Interface, 6 m
15-10509 Opt 2 W, 2-wire (Retro Fit)
15-10510 Opt 4 W, 4-wire (Retro Fit)
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 125
Issue 8 January 2015
19" Racks & Accessories
STANDARD RACK CONFIGURATIONS Standard Rack Configurations
PRODUCT PART NO. DESCRIPTION
08-06130-001
Standard Rack
Configurations
Basic High Power Rack Configuration
Designed to rack mount a basic NGT™/Envoy™ High Power
500 W/1000 W system.
COMPRISING:
• 19" 27RU rack complete with rear door, vented top and side
panels
• NGT™/Envoy™ universal rack mount tray for an NGT™/
Envoy™ Transceiver
• NGT™/Envoy™ rack mount tray for 3020 Transceiver Supply
• Rack mount blanking panels 1RU, 2RU and 3RU supplied
• Rack mount vent panels 1RU and 4RU supplied
• Pre-fitted equipment rails
• Assorted cable ties, screws, washers and cage nuts
NOTE:
• Rack comes pre-assembled ready for a NGT™/Envoy™
Transceiver and high power amplifier to be mounted.
• 6RU of space available for additional equipment.
• NGT™/Envoy™ Transceiver, power amplifier and power
supply units are ordered separately.
• Does not include a 1 m DC Extension Cable for the
NGT™/Envoy™ Transceiver.
19" Racks & Accessories
08-06130-002 Remote Control, High Power Rack Configuration
Designed to rack mount a NGT™ High Power Remote Control
system.
COMPRISING:
• 19" 27RU rack complete with rear door, vented top and side
panels
• NGT™ universal rack mount tray for a NGT™ Transceiver
• NGT™ universal rack mount tray for NGT™ Remote
Interface (NRI) remote control
• NGT™ rack mount tray for a 3020 Heavy Duty Transceiver
Supply
• Rack mount blanking panels 1RU and 2RU supplied
• Rack mount vent panels 1RU and 4RU supplied
• Pre-fitted equipment rails
• Assorted cable ties, screws, washers and cage nuts
NOTE:
• Rack comes pre-assembled ready for a NGT™ Transceiver
and high power amplifier to be mounted.
• 3RU of space available for additional equipment.
• NGT™ Transceiver, NRI remote control, high power
amplifier and power supply units are ordered separately.
• Does not include a 1 m DC Extension Cable for the
NGT™ Transceiver.
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Page 126 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
19" Racks & Accessories
STANDARD RACK CONFIGURATIONS
PRODUCT PART NO. DESCRIPTION
08-06130-003
Standard Rack
Configurations2
Remote Control and Data Modem High Power Rack
Configuration
Designed to rack mount a NGT™ High Power Remote Control
Data system.
COMPRISING:
• 19" 27RU rack complete with rear door, vented top and side
panels
• NGT™ universal rack mount tray for a NGT™ Transceiver
• NGT™ universal rack mount system tray for
NRI remote control
• NGT™ universal rack mount system tray for a HF data
modem
• NGT™ rack mount tray for a 3020 Heavy Duty
Transceiver Supply
• Rack mount vent panels 1RU and 4RU supplied
• Pre-fitted equipment rails
• Assorted cable ties, screws, washers and cage nuts
NOTE:
• Rack comes pre-assembled ready for a NGT™ Transceiver
and high power amplifier to be mounted.
• No space available for additional equipment.
• NGT™ Transceiver, NRI remote control, high power
amplifier and power supply units are ordered separately.
• Does not include a 1 m DC Extension Cable for the
NGT™ Transceiver.
08-06130-004 Split-site Remote Control High Power Rack
Configuration
Designed to rack mount a NGT™ High Power Split-Site
Remote Control system.
COMPRISING:
• 19" 27RU rack complete with rear door, vented top and side
panels
• NGT™ universal rack mount tray for a NGT™ Transceiver
• NGT™ rack mount tray for a 3020 Power supply
• Rack mount blanking panels 1RU and 2RU supplied
• Rack mount vent panels 1RU and 4RU supplied
• Pre-fitted equipment rails
• Assorted cable ties, screws, washers and cage nuts
NOTE:
• Rack comes pre-assembled ready for a NGT™ Transceiver
and high power amplifier to be mounted.
• 3RU space available for additional equipment.
• NGT™ Transceiver, NRI remote control, high power
amplifier and power supply units are ordered separately.
• Does not include a 1 m DC Extension Cable for the NGT™
Transceiver.
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 127
Issue 8 January 2015
19" Racks & Accessories
19" Rack Cabinets
19" Rack Mount System Trays
19" RACK CABINETS
PRODUCT PART NO. DESCRIPTION
08-05288-008 Rack Cabinet, 8RU High, 19" Format, 500 mm Deep
08-05288-012 Rack Cabinet, 12RU High, 19" Format, 500 mm Deep
08-05288-018 Rack Cabinet, 18RU High, 19" Format, 500 mm Deep
19" RACK MOUNT SYSTEM TRAYS Rack Mounts
PRODUCT PART NO. DESCRIPTION
15-00172-001 NGT™ Universal 19" Rack-mounting Tray 3RU with Blank
Front Panel
Suitable for NGT™ RF units, 3030 NGT™ Remote Interface.
15-00172-002 NGT™/Envoy™ Universal 19" Rack-mounting Tray 3RU, Front
Panel with Speaker Grill and Mounting Holes
Suitable for NGT™/Envoy™ RF unit. Speaker can be mounted
behind grill and handset can be mounted on front panel
using cradle.
NOTE:
Speaker and handset cradle not included.
15-00176 19" Rack-mounting Frame suitable for 3020 Transceiver
Supply, and 3012 or 3212 HF Data Modems
15-00164-010 19" Rack-mounting Frame for 8571 Split-site Remote
Interface
NGT
TRANSCEIVER
NGT
TRANSCEIVER
NGT
TRANSCEIVER
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Page 128 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
19" Racks & Accessories
19" Rack Mount Accessories
19" RACK MOUNT BLANKING PANELS
PRODUCT PART NO. DESCRIPTION
15-00173 Set of 1RU + 2RU Blank Front Panels
Suitable for covering gaps or holes in rack facia.
19" Rack Mount Blanking Panels
30-35002-019 19" 4RU Vent Panel
30-35002-006 19" 1RU Vent Panel
19" RACK MOUNT ACCESSORIES
PRODUCT PART NO. DESCRIPTION
30-35002-020 Fixed Equipment Rail, 457 mm Long
NOTE:
Suitable for 27RU rack cabinet only.
08-05920-001 Cable, DC Extension, 1 m
NOTE:
Required for the transceiver when it is rack mounted.
05-06374 Earth Braid, 1.5 m
NGT
TRANSCEIVER
NGT
TRANSCEIVER
Codan Radio Communications Commercial Product Catalogue Page 129
Issue 8 January 2015
2110 Transceiver Configurations
2110 SERIES TRANSCEIVER KIT 2110 Series Transceiver Kit
PRODUCT PART NO. DESCRIPTION
2110-TCVR
NET WEIGHT: 3.28 kg (7.23 lbs)
2110v & 2110 Transceiver Kits
08-06155-001
08-06155-008
08-06155-002
08-06155-009
08-06155-003
78-08000
08-06259-001
15-00446
15-04136-
##
2110 series Transceiver Kit
The 2110 series Transceivers are ideal for your long
distance portable communications. They are designed to
meet the most demanding mission and user
requirements. Available in two versions, the 2110v is for
basic voice only operations and the 2110 has additional
interface and interoperability capabilities.
The 2110 Transceiver is now available with a front panel
mounted socket for connection of an external GPS
antenna, e.g. for mobile or indoor applications where GPS
signal reception is required.
A 2110 series Transceiver Kit consists of a transceiver unit
and standard accessories listed below. The following
pages detail the parts required for a fully operational
manpack system.
TRANSCEIVER UNITS:
• 2110 SSB Transceiver Unit (1.5 ppm) — std frequency
stability
• 2110 SSB Transceiver (1.5 ppm) — std frequency
stability, with front panel GPS connector
• 2110 SSB Transceiver Unit (0.5 ppm) — high frequency
stability
• 2110 SSB Transceiver (0.5 ppm) — high frequency
stability, with front panel GPS connector
• 2110v SSB Transceiver Unit (1.5 ppm) — std frequency
stability
STANDARD ACCESSORIES:
• H-250/U Telephone Handset
• Earth wire with clip
• Counterpoise 4-wire kit
• 2110 series Manpack Transceiver Getting Started Guide,
includes Reference Manual on CDROM (see page 165,
Language Support for translations of this guide)
STANDARD FEATURES:
• 1.6–30 MHz, 400 channels, 10 networks
• 25 W/5 W (PEP) selectable output power
• 12 V DC, USB/LSB/AM
• Internal automatic antenna tuner
• Multi-net scanning
• In-built Easitalk™ speech noise reduction
• Comprehensive calling capabilities, including
emergency call, phone call, selective call, message call,
remote diagnostics
• Call logging
• Up to 65 hours use on a single charge (17Ah battery)
• Selectable output power
• Computer interface (RS232) for PC control
• Front panel programming (where permitted)
• Extensive Built-In-Test functions
• Meets MIL-STD-810F for shock, vibration, immersion
and dust
AVAILABLE OPTIONS & ACCESSORIES:
• See pages 136 and 139 for 2110 Options and Accessories.
##
denotes language version
Page 130 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
2110 Transceiver Configurations
PATROL CONFIGURATION Patrol Configuration
PRODUCT PART NO. DESCRIPTION
2110-TCVR-PATROL The Patrol Configuration provides the bare essentials for
basic manpack operation.
NOTE:
An appropriate battery charger needs to be ordered
separately.
NET WEIGHT: 3.72 kg (8.2 lbs)
08-06155-
###
78-08000
08-06259-001
15-00446
15-04136-
##
COMPRISING:
2110 series Transceiver Kit
• Transceiver Unit (see page 135, 2110 Transceiver Units
for descriptions of the transceiver units)
• H-250/U Telephone Handset
• Earth wire with clip
• Counterpoise 4-wire kit
• 2110 series Manpack Transceiver Getting Started Guide,
includes Reference Manual on CDROM (see page 165,
Language Support for translations of this guide)
NET WEIGHT: 0.4kg (0.88lbs)
15-00452 Collapsible Whip Antenna 3 m (10')
Extremely quick-to-erect whip antenna for use while
stationary. Comes with a goose neck base to adjust the
antenna angle.
NET WEIGHT: 0.44 kg (0.97 lbs)
15-00454 Long Wire Antenna and Adaptor (1.6–30 MHz)
Kevlar reinforced tactical wire antenna with throw rope
and accessories.
NET WEIGHT: 2.1kg (4.63lbs)
08-06185-001 Battery Pack 12 V 8Ah NiMH
Lightweight, robust and waterproof battery pack. Provides
for up to 30 hours of continuous operation (Rx/Tx 9:1).
NET WEIGHT: 1.23 kg (2.71 lbs)
15-00218 Softpack Backpack
Ultra-lightweight economy backpack with extra pockets
for transceiver accessories.
AVAILABLE OPTIONS & ACCESSORIES:
See pages 136 and 139 for 2110 Options and Accessories.
##
denotes language version
### denotes the type of transceiver unit
Codan Radio Communications Commercial Product Catalogue Page 131
Issue 8 January 2015
2110 Transceiver Configurations
EXPLORER CONFIGURATION Explorer Configuration
PRODUCT PART NO. DESCRIPTION
2110-TCVR-EXP The Explorer Configuration provides all the requirements
for a complete stand-alone HF communications system
suitable for a range of uses.
NET WEIGHT: 3.72 kg (8.2 lbs)
08-06155-
###
78-08000
08-06259-001
15-00446
15-04136-
##
COMPRISING:
2110 series Transceiver Kit
• Transceiver Unit (see page 135, 2110 Transceiver Units
for descriptions of the transceiver units)
• H-250/U Telephone Handset
• Earth wire with clip
• Counterpoise 4-wire kit
• 2110 series Manpack Transceiver Getting Started Guide,
includes Reference Manual on CDROM (see page 165,
Language Support for translations of this guide)
NET WEIGHT: 0.02 kg (0.04 lbs)
15-10525-000 Opt GPS Receiver (Factory Fit)
Enables GPS location and tracking capabilities in the
2110 series Transceivers.
NET WEIGHT: 0.28 kg (0.62 lbs)
15-00459 Knock Over Whip Antenna 1.5 m (5')
Robust short whip antenna suitable for communications
while on foot.
NET WEIGHT: 0.4 kg (0.88 lbs)
15-00452 Collapsible Whip Antenna 3 m (10')
Extremely quick-to-erect whip antenna for use while
stationary. Comes with a goose neck base to adjust the
antenna angle.
NET WEIGHT: 0.44 kg (0.97 lbs)
15-00454 Long Wire Antenna and Adaptor
Kevlar reinforced tactical wire antenna with throw rope
and accessories.
NET WEIGHT: 2.1 kg (4.63 lbs)
08-06185-001 Battery Pack 12 V 8Ah NiMH
Lightweight, robust and waterproof battery pack. Provides
for up to 30 hours of continuous operation (Rx/Tx 9:1).
Continued on the next page
##
denotes language version
### denotes the type of transceiver unit
Page 132 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
2110 Transceiver Configurations
EXPLORER CONFIGURATION CONT.
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.37 kg (0.82 lbs)
78-02007 2110 Battery Charger AC 1 A
Used to charge the 2110 battery via the front panel or
directly. Supplied with one AC mains cable.
NOTE:
When ordering, please specify the required AC input cable
(AUS, UK, USA or EU), see page 162, Charger Input Cables
AC.
NET WEIGHT: 0.08 kg (0.18 lbs)
08-06215-001 19-way battery charger output cable for 2110
Used to charge the 2110 series Transceivers via the front
panel.
NET WEIGHT: 0.08 kg (0.18 lbs)
08-06214-001 6-way battery charger output cable
Used to charge the battery directly.
NET WEIGHT: 4.3kg (9.48lbs)
15-00216-001 External Frame Backpack
AVAILABLE OPTIONS & ACCESSORIES:
See pages 136 and 139 for 2110 Options and Accessories.
Codan Radio Communications Commercial Product Catalogue Page 133
Issue 8 January 2015
2110 Transceiver Configurations
HOMELAND SECURITY CONFIGURATION Homeland Security Configuration
PRODUCT PART NO. DESCRIPTION
2110-TCVR-HS The Homeland Security Configuration provides the
complete package for a quick deploy communications
solution. It features comprehensive interoperability, GPS
location and tracking, and extra long battery life.
NET WEIGHT: 3.72 kg (8.2 lbs)
08-06155-002
78-08000
08-06259-001
15-00446
15-04136-
##
COMPRISING:
2110 series Transceiver Kit
• Transceiver Unit
• H-250/U Telephone Handset
• Earth wire with clip
• Counterpoise 4-wire kit
• 2110 series Manpack Transceiver Getting Started Guide,
includes Reference Manual on CDROM (see page 165,
Language Support for translations of this guide)
15-10532 Opt MIL-STD-188-141B ALE
Comprehensive ALE interoperability, fully compliant with
MIL-STD-188-141B ALE and JITC certified. Includes the
features of FED-STD-1045 ALE available in option
15-10479.
NET WEIGHT: 0.02 kg (0.04 lbs)
15-10525-000 Opt GPS Receiver (Factory Fit)
Enables GPS location and tracking capabilities in the
2110 series Transceivers.
NET WEIGHT: 0.4 kg (0.88 lbs)
15-00452 Collapsible Whip Antenna 3 m (10')
Extremely quick-to-erect whip antenna for use while
stationary. Comes with a goose neck base to adjust the
antenna angle.
NET WEIGHT: 0.44 kg (0.97 lbs)
15-00454 Long Wire Antenna and Adaptor
Kevlar reinforced tactical wire antenna with throw rope
and accessories.
NET WEIGHT: 2.9 kg (6.39 lbs)
08-06186-001 Battery Pack 12 V 13Ah NiMH
Heavy duty, waterproof battery pack. Provides for up to 50
hours of continuous operation (Rx/Tx 9:1).
Continued on the next page
##
denotes language version
Page 134 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
2110 Transceiver Configurations
HOMELAND SECURITY CONFIGURATION CONT.
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.37 kg (0.82 lbs)
78-02007 2110 Battery Charger AC 1 A
Used to charge the 2110 battery via the front panel or
directly. Supplied with one AC mains cable.
NOTE:
When ordering, please specify the required AC input cable
(AUS, UK, USA or EU), see page 162, Charger Input Cables
AC.
NET WEIGHT: 0.08 kg (0.18 lbs)
08-06215-001 19-way battery charger output cable
Used to charge the 2110 series Transceivers via the front
panel.
NET WEIGHT: 0.08 kg (0.18 lbs)
08-06214-001 6-way battery charger output cable
Used to charge the battery directly.
NET WEIGHT: 4.3kg (9.48lbs)
15-00216-001 External Frame Backpack
AVAILABLE OPTIONS & ACCESSORIES:
See pages 136 and 139 for 2110 Options and Accessories.
Codan Radio Communications Commercial Product Catalogue Page 135
Issue 8 January 2015
2110 Transceiver
2110 TRANSCEIVER UNITS Transceiver Units
PRODUCT PART NO. DESCRIPTION
2110 Transceiver
Units
NOTE:
Options and accessories for the manpack transceivers
need to be ordered separately.
NET WEIGHT: 2.5 kg (5.51 lbs)
08-06155-001
08-06155-008
2110 SSB Tcvr Unit (1.5 ppm)
2110 SSB Tcvr Unit (1.5 ppm with front panel GPS
connector)
The 2110 has additional interface and interoperability
capabilities, and is fitted with a 19-way expansion
connector for a range of external accessories. It is fully
interoperable with Codan’s NGT™/Envoy™ series
Transceivers and other commercial and military
transceivers.
NET WEIGHT: 2.5 kg (5.51 lbs)
08-06155-002
08-06155-009
2110 SSB Tcvr Unit (0.5 ppm)
2110 SSB Tcvr Unit (0.5 ppm with front panel GPS
connector)
This transceiver is similar to 08-06155-001 except it is
fitted with a 0.5 ppm high stability reference oscillator.
This version of the 2110 Transceiver is required to meet
full MIL-STD-188-141B ALE requirements.
NET WEIGHT: 2.5 kg (5.51 lbs)
08-06155-003 2110v SSB Tcvr Unit (1.5 ppm)
This transceiver is similar to 08-06155-001 except it is not
fitted with the 19-way external expansion port. The 2110v
is a voice-only manpack transceiver. It is fully
interoperable with Codan’s NGT™/Envoy™ series
Transceivers and other commercial transceivers.
STANDARD FEATURES:
• 1.6 to 30 MHz, 400 channels, 10 networks
• 25 W/5 W (PEP) selectable output power
• 12 V DC, USB/LSB/AM
• 1.5 ppm (parts per million) standard frequency stability
• Internal automatic antenna tuner
• Multi-net scanning
• In-built Easitalk™ speech noise reduction
• Comprehensive calling capabilities, including
emergency call, phone call, selective call, message call,
remote diagnostics
• Call logging
• Selectable output power
• RS232 interface for PC programming
• Front panel programming
• Extensive Built-In-Test functions
• Meets MIL-STD-810F for shock, vibration,
immersion and dust
• Front panel GPS connector (with relevant variants of
2110 only)
Page 136
Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
2110 Transceiver
2110 OPTIONS
2110 Options
PRODUCT PART NO. DESCRIPTION
15-10558 Opt, Default Open Selcall
NET WEIGHT: 0.02 kg (0.04 lbs)
15-10525-000 Opt GPS Receiver (Factory Fit)
Internally fitted 16-channel GPS receiver module, which
enables use with GPS location tracking systems and shows
remote locations with distance and bearing.
NET WEIGHT: 0.01 kg (0.02 lbs)
15-10530-000 Opt 500 Hz Filter (Factory Fit) (2110 only)
500 Hz narrow IF filter that improves performance with
morse (CW) and narrow FSK data modems like Pactor-II.
NOTE:
This filter is fitted in addition to the standard 2 kHz filter.
Only one filter in addition to the standard filter is possible.
NET WEIGHT: 0.01 kg (0.02 lbs)
15-10529-000 Opt 2.7 kHz BW Filter (Factory Fit) (2110 only)
2.7 kHz wide band filter.
NOTE:
This filter is fitted in addition to the standard 2 kHz filter.
Only one filter in addition to the standard filter is possible.
NET WEIGHT: 0.15 kg (0.33 lbs)
15-10584-000 2G Data
Enables integrated data modem capability according to
MIL-STD-110-188A/B and STANAG 4539. This provides a
range of military spec data waveforms from 75 to 9600
bit/s uncompressed, capabile of operating across varying
channel conditions. The modem utilises adaptive
equalisation and turbo-decoding for maximum
performance. Provides efficient email over HF when used
in conjunction with RC50-C email gateway (part number
15-04161-CD), see page 58, “RC50-C HF Email Software”.
AES-256 Encryption option (15-10595) can be added.
NOTE:
• This option is also available as a retro fit kit (part
number 15-10584).
• The 2.7 kHz BW filter option (15-10529-000) is
recommended for optimum data throughput
performance.
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be
provided for supply of this option.
Codan Radio Communications Commercial Product Catalogue Page 137
Issue 8 January 2015
2110 Transceiver
2110 OPTIONS cont.
2110 Options
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.15 kg (0.33 lbs)
15-10587-000 S4538 3G ALE
Enables third-generation (3G) Automatic Link
Establishment (ALE) according to STANAG 4538. This
provides superior calling performance including faster
linking, and the ability to link in extermely poor channel
conditions. A variety of call types are supported including
voice, message, over-the-air sync and GPS positioning.
AES-256 Encryption option (part number 15-10595) can
be added.
NOTE:
• The 2.7 kHz filter (15-10529-000) is fitted as part of the
3G ALE option.
• Only recent build standard 2110 Transceivers can
support the S4538 retrofit kit. Consult your Codan
representative for further information.
• The 3G ALE and 2G data capability cannot be used
simultaneously.
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be
provided for supply of this option.
Envoy X1 Options
15-10595 Opt AES-256 Encryption
Adds AES-256 Encryption, with support for up to 256
preloaded keys. Suitable for use in conjunction with the
MIL-STANAG 2G Data and 3G ALE options (part numbers
15-10584-000 and 15-10587-000).
NOTE:
• KMS/KFS Key Fill Software recommended (see page 139,
Key Management Software).
NET WEIGHT: 0.04 kg (0.09 lbs)
15-10531-000 Opt CES-128 Encryptor Module (Factory Fit)
High grade Voice Encryptor Module that provides high
grade voice security with exceptional recovered audio
quality.
NOTE:
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be
provided for supply of this option.
Continued on the next page
Page 138
Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
2110 Transceiver
2110 OPTIONS cont.
2110 Options
PRODUCT PART NO. DESCRIPTION
15-10553-000 Opt AES-256 DV Encryptor Module (Factory Fit)
Digital Voice Encryptor module providing excellent digital
voice quality and high grade AES-256 bit encryption.
Selectable vocoder rates of 1200 and 2400 bit/s are
available as standard.
NOTE:
• This option is also available as a retro fit kit (part
number 15-10553).
• This option is subject to Australian Government Export
Controls. A signed End-User Declaration must be
provided for supply of this option.
15-10551 Opt Voice Scrambler (CIVS)
Codan Integrated Voice Scrambler used to provide basic
level voice security capability.
15-10479 Opt FED-STD-1045 ALE/CALM™
Fully compatible with FED-STD-1045 ALE capabilities and
enhanced with Codan Automated Link Management
(CALM™). Includes facilities for Selective Calls, All Calls,
Phone Calls, Text Messaging and GPS Position Calls.
15-10532 Opt MIL-STD-188-141B ALE Full
Only available for the 2110 Transceiver, this option
provides full FED-STD-1045 and MIL-STD-188-141B ALE
capabilities, including NET call, ALL call, ANY call, Group
Call, Wildcard Call, advanced ALE beacon, in-link AMD
messaging and a Last Heard station log. With this option
the transceiver has 20 networks and 600 available
channels.
15-10544 Opt MIL-STD-188-141B Upgrade
Used to upgrade a 2110 Transceiver that already
has FED-STD-1045 ALE/CALM™ enabled to full
MIL-STD-188-141B capability.
NOTE:
This part should only be used for ordering field
upgrade passwords.
15-10518 Opt Amateur Mode
Enables transmit capability with free dial frequencies
within Amateur frequency bands. For use by licensed
operators only.
15-10481 Opt TxD, Tx Program Disable
Disables front panel programming of new transmit
frequencies. For use in countries where front panel
programming is prohibited by regulatory authorities,
e.g. USA and Australia.
Codan Radio Communications Commercial Product Catalogue Page 139
Issue 8 January 2015
2110 Transceiver
2110 ACCESSORIES 2110 Accessories
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.35 kg (0.77 lbs)
78-08000
2110 Accessories
Handset H-250/U
Lightweight military handset with noise cancelling
microphone and push-to-talk switch. Includes a coiled
cord with a standard H-229 military audio connector.
15-04168-EN Key Management Software (KMS)
Key Management Software (KMS) enables you to manage
and program encryption keys for Codan’s NGT™/2110/
Envoy™ series Transceivers and stand-alone encrypted
devices, e.g. RM50e HF Data Modem.
NOTE:
• This product is subject to Australian Government Export
Controls.
• A signed End-User Declaration must be provided for
supply of this option.
15-04171-EN Key Fill Software (KFS)
Key Fill Software (KFS) enables you to program encryption
keys into Codan’s NGT™/2110/Envoy™ series Transceivers
and stand-alone encryption devices, e.g. RM50e HF Data
Modem.
NOTE:
• This product is subject to Australian Government Export
Controls.
• A signed End-User Declaration must be provided for
supply of this option.
08-06901-001 Cable, Data Interface 19way MIL to USB A
USB to 19-way MIL Interface Cable for PC control (using
RC50-C) and security key programming (KMS/KFS) of the
RM50e HF Data Modem and embedded 2G Data Modem
(2110 only). Also used for programming of the 2110
Transceiver using NSP.
NET WEIGHT: 0.12 kg (0.26 lbs)
08-06237-001 Cable, Data Interface 19way MIL to D9F
9-way D to 19-way MIL Interface Cable for PC control
(using RC50-C) and security key programming (KMS/KFS)
of the RM50e HF Data Modem and embedded RM50
Modem (2110 only). Also used for programming the 2110
Transceiver using NSP.
NET WEIGHT: 0.13 kg (0.29 lbs)
08-06737-001 Cable, Data Interface 5way MIL to D9F
9-way D to 5-way MIL Interface Cable for security key
programming (KMS/KFS) and programming of the 2110v
Transceiver using NSP.
##
denotes language version Continued on the next page
Page 140 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
2110 Transceiver
2110 ACCESSORIES cont. 2110 Accessories
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.09 kg (0.2 lbs)
15-04164-EN System Programmer CD
Programming software to program 2110 and NGT™ series
Transceivers. Programmer interface cable (part number
08-06237-001 or 08-06737-001) needs to be ordered
separately.
NET WEIGHT: 0.2kg (0.44lbs)
78-01031 Adaptor, USB to DB-9, Serial Port
USB V1.1 compliant and supports Microsoft WindowsTM
2000/XP/Vista/WIN7.
NET WEIGHT: 0.2kg (0.44lbs)
15-00665 Morse Key, Desktop
Morse key for desktop use with the 2110 transceiver.
Connects to the 19 pin front panel connector.
NET WEIGHT: 0.2kg (0.44lbs)
78-13039 Morse Key, Leg Moun
Leg mounted Morse key suitable for man portable use
with the 2110 transceiver. Connects to the 19 pin front
panel connector.
NET WEIGHT: 0.26 kg (0.57 lbs)
08-06213-001 Cable, VP-116 Interface
Interface cable connecting the VP-116 Voice Privacy Unit
to the 2110 Transceiver.
78-01253 Antenna, Active GPS, SMB, 5 m
External GPS antenna for use with 2110 series Manpack
variants fitted with front panel GPS connector.
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 141
Issue 8 January 2015
2110 Transceiver
2110 ACCESSORIES cont. 2110 Accessories
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.22 kg (0.49 lbs)
15-04136-
##
Getting Started Guide, 2110 series Manpack Transceiver,
includes Reference Manual on CDROM
Printed Getting Started Guide for the 2110 Transceiver.
See page 165, Language Support for translations of this
guide.
NET WEIGHT: 2.4 kg (5.29 lbs)
15-04139-EN Repair Guide, Manpack Transceiver 2110 series
Printed Repair Guide for the 2110 series.
15-04139-CD Repair Guide, Manpack Transceiver 2110 series,
on CDROM
Page 142 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
2110 Transceiver
fThis page has been intentionally left blank.
Codan Radio Communications Commercial Product Catalogue Page 143
Issue 8 January 2015
Data & Email for 2110
RC50-C HF EMAIL SOFTWARE
PRODUCT PART NO. DESCRIPTION
15-04161-CD
RC50-C HF Email
Software
RC50-C HF Email Software
Codan’s RC50-C HF Email software provides fast, efficient,
error free email capability over HF radio. Operating in
conjunction with Codan’s HF Transceivers and 2G Embedded
Data and External RM50e Modem, the software operates on a
standard Windows™ PC using a single USB port with no
specialised
PC hardware requirements. When installed, the software
runs in the background requiring no user interaction.
COMPATIBILITY:
• For use with external RM50e HF Data Modem (NGT™ SRx,
SR, ASR, Envoy™ X2 Transceivers) and 2G Embedded Data
Modem (Envoy X2 and 2110 Manpack transceiver)
COMPRISING:
• CD-ROM with RC50-C software and documentation
STANDARD FEATURES:
• Adaptive rates up to 9600 bit/s
• Compatible with ALE/CALM™
• Intranet/Internet gateway
• NATO interoperable
• ISB capable
SYSTEM REQUIREMENTS:
• Windows™ XP Professional SP2 or Windows™ 7
• Intel Pentium IV 800 MHz or better
• 6 GB or more of free space for email storage
• 512 MB or more of RAM
•CD-ROM drive
• POP3 / SMTP compliant email client
• Access to any commercial POP3 / SMTP compliant email
server for internet connectivity
• Serial/USB port for connecting the HF modem to the PC
NOTE:
• Requires Data Interface Cable (part number 08-06901-001)
for connecting the PC to a 2110 series Manpack Transceiver
or RM50e HF Data Modem.
NGT
TRANSCEIVER
Page 144 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email for 2110
UUPLUS™ SOFTWARE UUPlus™ Email for HF Server Software
PRODUCT PART NO. DESCRIPTION
UUPlus Software
08-05981-001 UUPlus™ Email for HF Server Software
Provides HF and Internet email access for up to 25 users. It
works in conjunction with UUPlusTM Email for HF Codan Client
software, used by each remote station. It has been specifically
designed for use with Codan’s HF equipment.
NOTE:
• One copy of UUPlusTM Codan Client is required for each user
that is to connect to UUPlusTM Codan Server.
•A UUPlus
TM Codan Server cannot communicate directly to
other UUPlusTM Codan Server stations.
COMPATIBILITY:
• For use with 3012 and 3212 HF Data Modems
COMPRISING:
•CD-ROM with UUPlus
TM Codan Server software and
documentation
• Single user licence for installation on one machine
STANDARD FEATURES:
• Works with POP3/SMTP PC email clients such as Outlook
Express™.
• Capable of interfacing with an Internet Service Provider or
Mail Server
• Reduces connection time by compressing and combining
messages
• Automatically resumes interrupted file transfers
• Capable of automatically calling the remote user at preset
times to deliver mail and collect outgoing mail, or enables
the user to check mail manually
SYSTEM REQUIREMENTS:
• Codan HF SSB Transceiver
• Codan 3012 or 3212 HF Data Modems
•Microsoft Windows
TM XP/WIN7
• Internet email client with support of POP3 and SMTP
protocols
• Serial/USB port for connecting the HF modem to the PC
• Optional LAN, dialup networking card or line modem for
connecting local email clients and server to the internet
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 145
Issue 8 January 2015
Data & Email for 2110
UUPLUS™ SOFTWARE CONT. UUPlus™ Email for HF Client Software
PRODUCT PART NO. DESCRIPTION
08-05980-001 UUPlus™ Email for HF Client Software
Simple and reliable solution for sending email over HF from
remote areas. It works in conjunction with UUPlusTM Codan
Server software and has been specifically designed for use
with Codan’s HF equipment.
COMPATIBILITY:
• For use with 3012 and 3212 HF Data Modems
COMPRISING:
•CD-ROM with UUPlus
TM Codan Client software and
documentation
• Single user licence for installation on one machine
STANDARD FEATURES:
• Works with POP3/SMTP PC email clients such as Outlook
Express™.
• Reduces connection time by compressing and combining
messages
• Automatically resumes interrupted file transfers
• Capable of automatically answering calls from the server to
exchange mail at preset times, or enables the user to check
for mail manually
• Able to send files directly to other stations
SYSTEM REQUIREMENTS:
• Codan HF SSB Transceiver
• Codan 3012 or 3212 HF Data Modems
•Microsoft Windows
TM XP/WIN7
• Internet email client with support of POP3 and SMTP
protocols
• Serial/USB port for connecting the HF modem to the PC
Page 146 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email for 2110
3012 HF DATA MODEM (NO CABLES) 3012 HF Data Modem (No Cables)
PRODUCT PART NO. DESCRIPTION
MODEM-3012-NC
3012 HF Data Modem (No
Cables)
08-05877-004
08-04515-001
30-11208-000
15-04104-CD
3012 HF Data Modem (No Cables)
The 3012 HF Data Modem provides reliable and cost-effective
computer text and data communication capabilities for
organisations operating in remote areas with little or no
telecommunications infrastructure.
COMPRISING:
• 3012 HF Data Modem
•Earth Wire, 0.5m
• Self Adhesive Rubber Feet (x4)
• 3012 HF Data Modem User Guide on CDROM (English)
STANDARD FEATURES:
• Up to 6000 bit/s, error-free data transmission with
compression
• In-built data compression
• Backwards compatible with the Codan 9001/9002 HF Data
Modems
• Data scrambled for security
• In-built serial port optical isolator
• Easy to use AT command interface
AVAILABLE OPTIONS:
• Support for UUPlusTM Email for HF Client or Server software,
see page 144, UUPlus™ Software.
Codan Radio Communications Commercial Product Catalogue Page 147
Issue 8 January 2015
Data & Email for 2110
3012 HF DATA MODEM FOR 2110 WITH
6 M RS232 CABLE
3012 HF Data Modem for 2110 with 6 m RS232 Cable
PRODUCT PART NO. DESCRIPTION
MODEM-3012-2110-6M 3012 HF Data Modem for 2110 with 6 m RS232 Cable
This configuration consists of a 3012 HF Data Modem,
6 m Data Interface Cable, and 1 m 2110 Manpack to
3012 Modem Cable.
08-05877-004
08-04515-001
30-11208-000
15-04104-CD
COMPRISING:
3012 HF Data Modem
Earth Wire, 0.5 m
Self Adhesive Rubber Feet(x4)
3012 HF Data Modem User Guide on CDROM (English)
08-05086-006 Data Interface Cable, 6 m
08-06422-001 2110 Manpack to 3012 Modem Cable, 1 m
Page 148 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email for 2110
3012 ACCESSORIES 3012 Accessories
PRODUCT PART NO. DESCRIPTION
15-00136
3012 Accessories
Cradle, HF Data Modem Vehicle Mounting
78-01031 Adaptor, USB to DB-9, Serial
USB V1.1 compliant and supports Microsoft WindowsTM 2000/
XP/Vista/WIN7.
60-00098-590 Adaptor, 9-pin D PIug to 25-pin D Socket
08-05086-001
08-05086-006
Cable, Data Interface, 2 m
Cable, Data Interface, 6 m
08-06422-001 Cable, 2110 Manpack to 3012 Modem, 1 m
15-04104-
##
User Guide, HF Data Modem 3012
Printed User Guide for the 3012 HF Data Modem.
See page 165, Language Support for translations of this guide.
08-05980-001 UUPlus™ Email for HF Client Software
Single user access to UUPlusTM Email for HF Server Software.
For use with the 3012 or 3212 HF Data Modems.
08-05981-001 UUPlus™ Email for HF Server Software
Email server with support for up to 25 remote or local users
and Internet email access. For use with the 3012 or 3212 HF
Data Modems.
##
denotes language version
Codan Radio Communications Commercial Product Catalogue Page 149
Issue 8 January 2015
Data & Email for 2110
3212 HF DATA MODEM (NO CABLES) 3212 System Requirements
PRODUCT PART NO. DESCRIPTION
MODEM-3212-NC
3212 HF Data Modem (No Cables)
08-06274-001
08-04515-001
30-11208-000
15-04146-CD
3212 HF Data Modem (No Cables)
The 3212 HF Data Modem provides reliable and cost-effective
computer text and data communication capabilities for
organisations operating in remote areas with little or no
telecommunications infrastructure.
The 3212 HF Data Modem uses waveforms derived from
Military Standard (MIL-STD) waveforms, which are based on
STANAG 4539 and modified to provide optimal performance
over commercial channel bandwidths.
COMPRISING:
• 3212 HF Data Modem
•Earth Wire, 0.5m
• Self Adhesive Rubber Feet (x4)
• 3212 HF Data Modem User Guide on CDROM (English)
STANDARD FEATURES:
• Up to 7200 bit/s error free on-air data rate without
compression
• Backwards compatible with Codan 3012 HF Data Modem
• Designed to operate on standard bandwidth commercial
HF channels
• In-built DC isolation on all available ports
• Modem control via RS232 or ethernet port
AVAILABLE OPTIONS:
• Support for UUPlus™ Email for HF Client or Server software,
see page 144, UUPlus™ Software.
Page 150 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email for 2110
3212 HF DATA MODEM FOR 2110 WITH 2 M RS232
CABLE
3212 HF Data Modem for 2110 with 2 m RS232 Cable
PRODUCT PART NO. DESCRIPTION
MODEM-3212-2110-2M 3212 HF Data Modem for 2110 with 2 m RS232 Cable
This configuration consists of a 3212 HF Data Modem,
2 m Serial Cable, and 1 m 2110 Manpack to 3212 Modem
Cable.
The 3212 HF Data Modem uses waveforms derived from
Military Standard (MIL-STD) waveforms, which are based on
STANAG 4539 and modified to provide optimal performance
over commercial channel bandwidths.
08-06274-001
08-04515-001
30-11208-000
15-04146-CD
COMPRISING:
3212 HF Data Modem
Earth Wire, 0.5 m
Self Adhesive Rubber Feet (x4)
3212 HF Data Modem User Guide on CDROM (English)
08-06359-002 Serial D9M-D9F Isol Shield Cable, 2 m
08-06786-001 2110 Manpack to 3212 Modem Cable, 1 m
Codan Radio Communications Commercial Product Catalogue Page 151
Issue 8 January 2015
Data & Email for 2110
3212 HF DATA MODEM FOR 2110 WITH
6 M RS232 CABLE
3212 HF Data Modem for 2110 with 6 m RS232 Cable
PRODUCT PART NO. DESCRIPTION
MODEM-3212-2110-6M 3212 HF Data Modem for 2110 with 6 m RS232 Cable
This configuration consists of a 3212 HF Data Modem,
6 m Serial Cable, and 1 m 2110 Manpack to 3212 Modem
Cable.
The 3212 HF Data Modem uses waveforms derived from
Military Standard (MIL-STD) waveforms, which are based on
STANAG 4539 and modified to provide optimal performance
over commercial channel bandwidths.
08-06274-001
08-04515-001
30-11208-000
15-04146-CD
COMPRISING:
3212 HF Data Modem
Earth Wire, 0.5 m
Self Adhesive Rubber Feet (x4)
3212 HF Data Modem User Guide on CDROM (English)
08-06359-006 Serial D9M-D9F Isol Shield Cable, 6 m
08-06786-001 2110 Manpack to 3212 Modem Cable, 1 m
Page 152 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Data & Email for 2110
3212 ACCESSORIES 3212 Accessories
PRODUCT PART NO. DESCRIPTION
15-00136
3212 Accessories Cradle, HF Data Modem Vehicle Mounting
78-01031 Adaptor, USB to DB-9, Serial
USB V1.1 compliant and supports Microsoft WindowsTM 2000/
XP/Vista/WIN7.
60-00098-590 Adaptor, 9-pin D PIug to 25-pin D Socket
39-79150-080 Ferrite Bead Clamp
08-06359-002
08-06359-006
Cable, Serial D9M-D9F Isol Shield, 2 m
Cable, Serial D9M-D9F Isol Shield, 6 m
67-90800
67-90801
Cable, Ethernet Crossover CAT-5E, 2 m Red
Cable, Ethernet Crossover CAT-5E, 10 m Red
67-90802
67-90803
Cable, Ethernet Straight CAT-5E, 2 m Blue
Cable, Ethernet Straight CAT-5E, 10 m Blue
08-06786-001 Cable, 2110 Manpack to 3212 Modem, 1 m
15-04146-EN User Guide, 3212 HF Data Modem (English)
Printed User Guide for the 3212 HF Data Modem.
Codan Radio Communications Commercial Product Catalogue Page 153
Issue 8 January 2015
Crosspatch™ for 2110
CROSSPATCH™ FOR 2110 Crosspatch™ for 2110
PRODUCT PART NO. DESCRIPTION
XPATCH-2110
08-06730-002
08-06766-001
15-04148-CD
06-02489-EN
15-00145
3031 Crosspatch™ for 2110
Codan’s leading edge 3031 CrosspatchTM enables you to carry
‘HF on your belt’ using a VHF/UHF radio and a Codan NGT™
Transceiver. It is the practical, effective and affordable
solution for any organisation that needs to extend their
current HF or VHF/UHF networks.
COMPRISING:
• 3031 VHF/UHF to HF Crosspatch™ for 2110
• 3031 to VHF/UHF Transceiver Generic Cable, 2 m
•Crosspatch
TM 3031 CD Package (English)
•Crosspatch
TM 3031 Quick Reference Cards, English (x2)
•Crosspatch
TM 3031 Installation Kit
CROSSPATCH™ ACCESSORIES Crosspatch™ Accessories
PRODUCT PART NO. DESCRIPTION
08-06766-001 Cable, 3031 to VHF/UHF Transceiver Generic
06-02489-EN Quick Reference Card, Crosspatch™ 3031 (English)
15-04148-EN User Guide, Crosspatch™ 3031 (English)
Printed User Guide for the 3031 Crosspatch.
Page 154 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Crosspatch™ for 2110
This page has been intentionally left blank.
Codan Radio Communications Commercial Product Catalogue Page 155
Issue 8 January 2015
Antenna Accessories
LONG WIRE & DIPOLES Long Wire & Dipoles
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.44 kg (0.97 lbs)
15-00454
Long Wire & Dipoles
Ant, Long Wire and Adaptor 25 W PEP (1.6–30 MHz)
Lightweight Kevlar reinforced Tactical Long Wire antenna.
Includes: throw rope, antenna adaptor, winding spool,
anchor peg and antenna deployment quick reference card.
NET WEIGHT: 1.1 kg (2.43 lbs)
15-00458 Ant, End-fed Broadband 25 W PEP (3–30 MHz)
Lightweight Kevlar reinforced End-fed Broadband Dipole
Antenna.
Includes: 3 m (10') coaxial feeding cable terminated with
BNC connectors with protective caps, broadband antenna
balun, throw rope, counterpoise kit, winding spool, anchor
peg and antenna deployment quick reference card.
NET WEIGHT: 2.6 kg (5.73 lbs)
15-00456 Ant, Broadband Dipole 25 W PEP (3–30 MHz)
Lightweight Kevlar reinforced Tactical Broadband Dipole
Antenna.
Includes: 10 m (30') coaxial feeding cable terminated with
BNC connectors with protective caps, broadband antenna
balun, two lots of termination resistors, throw ropes,
counterpoise kits, winding spools, anchor pegs and
antenna deployment quick reference card.
NET WEIGHT: 2.7 kg (5.95 lbs)
15-00455 Ant, Wire Dipole 25 W PEP (3–30 MHz)
Lightweight Kevlar reinforced Tactical Dipole Antenna
with tactile length markings.
Includes: 10 m (30') coaxial feeding cable terminated with
BNC connectors with protective caps, dipole antenna
balun, throw rope, antenna adaptor, winding spools,
anchor peg and antenna deployment quick reference card.
NET WEIGHT: 3.3 kg (7.28 lbs)
15-00457 Ant, Dipole and Broadband kit 25 W PEP (2–30 MHz)
Lightweight Kevlar reinforced Universal HF Dipole and
HF Broadband Dipole Antenna kit.
Includes: 10 m (30') coaxial feeding cable terminated with
BNC connectors with protective caps, broadband antenna
balun, dipole antenna balun, two lots of termination
resistors, throw ropes, counterpoise kits, winding spools,
anchor pegs and antenna deployment quick reference
cards.
Page 156 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antenna Accessories
TACTICAL MAST Tactical Mast
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 5.0 kg (11.02 lbs)
78-13035 Mast, Man-portable 6 m Tactical
Lightweight, compact man-portable mast system.
The kit includes, multi section mast, guy ropes, guy stakes,
halyard, base plate stakes and installation instructions.
This mast is most suitable for use with lightweight, low
power (25 W) antennas used with the 2110 series
Manpack Transceiver (see page 155, Long Wire & Dipoles).
NOTE:
• The 6 m mast is not suitable for use with full size 125 W/
1 kW Broadband Antennas.
• Certain Manpack Transceiver antennas may require
more than one mast. Please check specific mast
requirements for each antenna before ordering.
WHIP ANTENNAS Whip Antennas
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.4kg (0.88lbs)
15-00452 Ant, 3 m (10’) Collapsible Whip 25 W
Lightweight collapsible 6 section whip antenna with
flexible gooseneck.
NET WEIGHT: 0.25 kg (0.55 lbs)
15-00453 Ant, 1.5 m (5’) Tape Whip 25 W
Foldable tape whip antenna with flexible gooseneck.
NET WEIGHT: 0.28 kg (0.62 lbs)
15-00459 Ant, 1.5 m (5’) Knock Over Whip 25 W
Lightweight collapsible 3 section knock over whip antenna
with flexible gooseneck.
CABLES Cables
PRODUCT PART NO. DESCRIPTION
08-07010-006 Antenna Tuner Control Cable, 6 m
Interface cable for direct connection of antenna tuner to
19-pin front panel connector on 2110 (not suitable for
2110v).
08-06357-001 BNC to UHF Coaxial Cable, 1 m
Used to adapt BNC connector on 2110/2110v to UHF
socket. Requires additional coaxial cable length for
connection to antenna, see page 109, Coaxial Cables.
Codan Radio Communications Commercial Product Catalogue Page 157
Issue 8 January 2015
Antenna Accessories
EARTHING Earthing
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.16 kg (0.35 lbs)
15-00446 Counterpoise 4-wire kit
Lightweight counterpoise and earthing kit.
NET WEIGHT: 0.08 kg (0.18 lbs)
15-00462 Anchor peg
Used in antenna kits to anchor the antenna wires.
NET WEIGHT: 0.05 kg (0.11 lbs)
08-06259-001 Earth Wire with Clip
Earthing wire 1 m (3') with spring clip.
Page 158 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Antenna Accessories
This page has been intentionally left blank.
Codan Radio Communications Commercial Product Catalogue Page 159
Issue 8 January 2015
Battery & Charger Accessories
BATTERIES Batteries
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 2.1 kg (4.63 lbs)
08-06185-001 Battery Pack 12 V 8Ah NiMH
Waterproof 2110 Transceiver battery pack with 12 V, 8Ah
rechargeable Nickel Metal Hydride battery and battery
management controller.
Recharges: ~500 (80% capacity)
Useable hours: ~30 hrs (using Rx/Tx 9:1)
NET WEIGHT: 2.9 kg (6.39 lbs)
08-06186-001 Battery Pack 12 V 13Ah NiMH
Waterproof 2110 Transceiver battery pack with 12 V,
13Ah rechargeable Nickel Metal Hydride battery and
battery management controller.
Recharges: ~500 (80% capacity)
Useable hours: ~50 hrs (using Rx/Tx 9:1)
NET WEIGHT: 2.5 kg (5.5 lbs)
08-07009-001 Battery Pack 12 V 17 Ah LiFePO4
Waterproof 2110 Transceiver battery pack with 12 V, 17
Ah rechargeable battery using lithium iron phosphate
chemistry that is safe and has excellent shelf life.
Recharges: 2000 (80% capacity)
Useable hours: 65 hrs (using Rx/Tx 9:1)
NOTE:
This battery is classified as dangerous goods and may
impact freight cost and method. Please contact your
Codan Sales Representative for further details.
DC-DC VOLTAGE CONVERTER DC-DC Voltage Converter
PRODUCT PART NO. DESCRIPTION
15-00576
DC-DC Voltage
Converter
Voltage Regulator (24 V to 12 V operation 7 A)
Enables the operation of 2110 series Transceivers in 24/
26 V based systems. Protected from faults such as voltage
spikes, overload, short circuits and low voltage input. The
unit automatically resets once a fault is removed.
Nominal Input: 24 V DC
Nominal Output: 12 V @ 7 A
Efficiency: Greater than 90% at full load
NOTE:
The voltage regulator is not waterproof.
Page 160 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Battery & Charger Accessories
CHARGERS Chargers
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 3.7kg (8.16lbs)
15-00578 2110 Hand-powered Battery Charger
A portable hand-powered battery charger that is compact
and lightweight, and encased in a robust and waterproof
aluminium housing.
The charger comes with easy to use accessories for simple
operation, and a convenient carrying case.
A suitable charger output cable must be ordered
separately, see page 161, Charger Output Cables.
NET WEIGHT: 1 kg (2.2 lbs)
15-00577 2110 Solar Battery Charger (Black)
A portable solar-powered 20 W battery charger that uses
solid state, thin film solar technology to meet your mobile
power needs. It is lightweight, weatherproof and
UV resistant, and durable with a tough rip-stop
nylon backing.
A suitable charger output cable must be ordered
separately, see page 161, Charger Output Cables.
15-00581 2110 Solar Battery Charger (Digital Camo)
A portable solar-powered 20 W battery charger that uses
solid state, thin film solar technology to meet your mobile
power needs. It is lightweight, weatherproof and
UV resistant, and durable with a tough rip-stop
nylon backing.
A suitable charger output cable must be ordered
separately, see page 161, Charger Output Cables.
CHARGER MODULES Charger Modules
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.25 kg (0.55 lbs)
78-02007 Battery Charger AC-DC 3121
Low noise 2110 battery charger (90–240 V AC input, 15.5 V
@ 1 A output). Suitable for charging while operating the
transceiver,
NOTE:
Suitable AC input cable (with AUS, UK, USA or EU plug)
and output cable for AC-DC 3121 charger module must be
ordered separately.
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 161
Issue 8 January 2015
Battery & Charger Accessories
CHARGER MODULES CONT. Charger Modules
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.4 kg (0.88 lbs)
78-02012 Battery Charger AC-DC 3123
Fast 2110 battery pack charger (90–240 V AC input, 15.5 V
@ 3 A output) with output cable. Suitable for direct
connection to the battery pack only.
NOTE:
Suitable AC input cable (with AUS, UK, USA or EU plug)
must be ordered separately.
NET WEIGHT: 0.24 kg (0.53 lbs)
78-02008 Battery Charger DC-DC 3122
Low noise 2110 battery charger (12–60 V DC input, 15.5 V
@ 1 A output). Suitable for charging while operating the
transceiver.
NOTE:
Suitable DC input cable (with vehicle lighter plug or spring
clips adaptor) and output cable for DC-DC 3122 charger
module must be ordered separately.
CHARGER OUTPUT CABLES Charger Output Cables
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.08 kg (0.18 lbs)
08-06215-001 Cable, charger O/P, 19way
Used to charge the 2110 series Transceivers via the front
panel. Can be used with 3121 and 3122 Battery Chargers,
and handcrank and solar chargers.
Charger Output Cables
NET WEIGHT: 0.08 kg (0.18 lbs)
08-06738-001 Cable, charger O/P, 5way
Used to charge the 2110v transceiver via the front panel.
Can be used with 3121 and 3122 Battery Chargers, and
handcrank and solar chargers.
NET WEIGHT: 0.08 kg (0.18 lbs)
08-06214-001 Cable, Charger O/P, 6way
Used to charge the battery directly. Can be used with 3121
and 3122 Battery Chargers, and handcrank and solar
chargers.
Page 162 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Battery & Charger Accessories
CHARGER INPUT CABLES AC Charger Input Cables AC
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.1kg (0.22lbs)
67-90200 Cable, 2C AUS IEC C7 2 m
IEC 2-wire mains cable with AUS plug.
Charger Input Cables AC
NET WEIGHT: 0.13 kg (0.29 lbs)
67-90201 Cable, 2C UK IEC C7 2 m
IEC 2-wire mains cable with UK plug.
NET WEIGHT: 0.16 kg (0.35 lbs)
67-90202 Cable, 2C USA IEC C7 2 m
IEC 2-wire mains cable with USA plug.
NET WEIGHT: 0.09 kg (0.198 lbs)
67-90203 Cable, 2C EU IEC C7 2 m
IEC 2-wire mains cable with EU plug.
CHARGER INPUT CABLES DC Charger Input Cables DC
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 0.11 kg (0.24 lbs)
08-06216-001 Cable, DC Charger I/P, Lighter Adaptor
DC input cable to connect an in-vehicle lighter socket to
DC-DC 3122 charger module.
NET WEIGHT: 0.15 kg (0.33 lbs)
08-06217-001 Cable, DC Charger I/P, Clips Adaptor
DC input cable with spring clips to connect DC power
source to DC-DC 3122 charger module.
Codan Radio Communications Commercial Product Catalogue Page 163
Issue 8 January 2015
Backpack & Mounting Accessories
BACKPACKS Backpacks
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 4.3 kg (9.48 lbs)
15-00216-001 Backpack, External Frame
Heavy duty backpack with external frame and ergonomic
shoulder harness with ventilation panel for comfort. It has
side, bottom and front pockets for transceiver accessories,
reference materials, and personal items. The modular
external frame allows for additional loads of up to 50 kg.
Made from 1000 Denier Black bulked filament nylon, black
co-polymer frame.
NET WEIGHT: 1.23 kg (2.71 lbs)
15-00218 Backpack, Softpack
Lightweight, compact and comfortable backpack
providing storage for transceiver, all accessories as well as
personal items.
Made from Black Cordura.
Page 164 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Backpack & Mounting Accessories
MOUNTING ACCESSORIES Mounting Accessories
PRODUCT PART NO. DESCRIPTION
NET WEIGHT: 1.7kg (3.75lbs)
15-00139 Cradle, 2110/2110v with Screws
Heavy duty docking cradle used to secure the 2110 or
2110v transceiver in a vehicle. With quick release latches
and screw kit, the radio can be easily docked with the
battery pack attached.
NET WEIGHT: 2.5kg (5.51lbs)
15-00140 Cradle, 2110 with Interface Adpaptor
Transceiver cradle (part number 15-00139) plus an
interface adaptor for external antenna, GPS, data
interfaces, and DC battery charger. Includes a speaker
amplifier and external speaker, and can be adapted to
interface with a VP-116 Voice Privacy Unit via an NGT™
VP-116 Interface cable (part number 08-06213-001).
NOTE:
Cannot be used with the 2110v Transceiver.
NET WEIGHT: 1.9kg (4.19lbs)
15-00141 Cradle, 2110 with 9350 Interface
Suitable for interfacing with the 9350 Automatic Tuning
Whip Antenna and a DC battery charger. For 9350
ordering details, see page 91, 9350 Automatic Tuning Whip
Antenna.
NOTE:
Cannot be used with the 2110v Transceiver.
NET WEIGHT: 0.3kg (0.66lbs)
15-00143 2110 External DC for Cradle
Backpanel for the transceiver cradle that provides DC
connection for the transceiver directly to the vehicle
battery.
NOTE:
• The transceiver cradle is only shown for illustration
purposes.
• Voltage regulator (part number 15-00576) is available
for 24 V vehicle operation. See page 159, DC-DC Voltage
Converter.
NET WEIGHT: 1.7kg (3.75lbs)
15-00144 2110 External DC Vehicle Kit
Complete vehicle installation kit incorporating the
external DC backpanel (part number 15-00143). It
provides DC connection for the transceiver directly to the
vehicle battery.
NOTE:
Voltage regulator (part number 15-00576) is available for
24 V vehicle operation. See page 159, DC-DC Voltage
Converter.
Codan Radio Communications Commercial Product Catalogue Page 165
Issue 8 January 2015
Language Support
ENGLISH MANUALS English Manuals
PRODUCT PART NO. DESCRIPTION
15-04177-EN Getting Started Guide, Envoy™ Transceiver, includes Reference
Manual on CDROM
06-02809-EN Quick Reference Card, Envoy X1 and X2
15-04127-EN Getting Started Guide, NGT™ Transceiver, includes Reference
Manual on CDROM
15-04140-EN Getting Started Guide, NGT™ SRx Transceiver, includes Reference
Manual on CDROM
15-04137-EN Getting Started Guide, NGT™ ASR Transceiver, includes Reference
Manual on CDROM
15-04136-EN Getting Started Guide, 2110 series Manpack Transceiver, includes
Reference Manual on CDROM
15-04104-EN User Guide, HF Data Modem 3012 a
15-04104-CD User Guide, HF Data Modem 3012, on CDROM
Continued on the next page
Page 166 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Language Support
ENGLISH MANUALS CONT. English Manuals
PRODUCT PART NO. DESCRIPTION
15-04146-EN User Guide, 3212 HF Data Modem
15-04146-CD User Guide, 3212 HF Data Modem, on CDROM
15-04148-EN User Guide, Crosspatch™ 3031
15-04148-CD User Guide, Crosspatch™ 3031, on CDROM
15-04131-EN Reference Manual, High Power Amplifiers 3061/3062
15-04156-EN User Guide, 3033 Telephone Interconnect
15-04156-CD User Guide, 3033 Telephone Interconnect, on CDROM
15-04102-EN Reference Manual, Remote Control NGT™ Systems
Continued on the next page
Codan Radio Communications Commercial Product Catalogue Page 167
Issue 8 January 2015
Language Support
ENGLISH MANUALS CONT. English Manuals
PRODUCT PART NO. DESCRIPTION
15-04125-EN Reference Manual, Split-site Remote Control NGT™ Systems
15-04142-EN Installation Handbook, Automatic Tuning Whip Antenna 9350
15-04143-EN Repair Guide, NGT™ Transceiver
15-04143-CD Repair Guide, NGT™ Transceiver, on CDROM
15-04139-EN Repair Guide, Manpack Transceiver 2110 series
15-04139-CD Repair Guide, Manpack Transceiver 2110 series on CDROM
15-60012 Installation Handbook, 3040 Automatic Whip Antenna, c/w
antenna connector sealing kit
Continued on the next page
Page 168 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Language Support
FRENCH MANUALS French Manuals
PRODUCT PART NO. DESCRIPTION
15-04127-FR Getting Started Guide, NGT™ Transceiver, includes Reference
Manual on CDROM
15-04140-FR Getting Started Guide, NGT™ SRx Transceiver, includes Reference
Manual on CDROM
15-04136-FR Getting Started Guide, 2110 series Manpack Transceiver, includes
Reference Manual on CDROM
15-04104-FR User Guide, HF Data Modem 3012
15-04102-FR Reference Manual, Remote Control NGT™ Systems
15-04142-FR Installation Handbook, Automatic Tuning Whip Antenna 9350
Codan Radio Communications Commercial Product Catalogue Page 169
Issue 8 January 2015
Language Support
SPANISH MANUALS Spanish Manuals
PRODUCT PART NO. DESCRIPTION
15-04127-ES Getting Started Guide, NGT™ Transceiver, includes Reference
Manual on CDROM
15-04137-ES Getting Started Guide, NGT™ ASR Transceiver, includes Reference
Manual on CDROM
15-04140-ES Getting Started Guide, NGT™ SRx Transceiver, includes Reference
Manual on CDROM
15-04136-ES Getting Started Guide, 2110 series Manpack Transceiver, includes
Reference Manual on CDROM
15-04131-ES Reference Manual, High Power Amplifiers 3061/3062
15-04142-ES Installation Handbook, Automatic Tuning Whip Antenna 9350
06-02809-ES Quick Reference Card, Envoy X1 and X2
Page 170 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Language Support
ARABIC MANUALS Arabic Manuals
PRODUCT PART NO. DESCRIPTION
15-04140-AR Getting Started Guide, NGT™ SRx Transceiver, includes Reference
Manual on CDROM
15-04136-AR Getting Started Guide, 2110 series Manpack Transceiver, includes
Reference Manual on CDROM
DARI MANUALS Arabic Manuals
PRODUCT PART NO. DESCRIPTION
06-02809-FA Quick Reference Card, Envoy X1 and X2
PORTUGUESE MANUALS Portuguese Manuals
PRODUCT PART NO. DESCRIPTION
15-04140-PT Getting Started Guide, NGT™ SRx Transceiver, includes Reference
Manual on CDROM
RUSSIAN MANUALS Arabic Manuals
PRODUCT PART NO. DESCRIPTION
06-02809-RU Quick Reference Card, Envoy X1 and X2
Codan Radio Communications Commercial Product Catalogue Page 171
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
2110-TCVR 2110 SSB Transceiver Kit B2 5.0
2110-TCVR-PATROL 2110 Patrol Configuration CMR 11.0
2110-TCVR-EXP 2110 Explorer Configuration AA + BPK 14.5
2110-TCVR-HS 2110 Homeland Security Configuration AA + BPK 16.0
ANT-3040-NC 3040 Automatic Tuning Whip (No Cables) B + Tube 5.07
ANT-3040-6M 3040 Automatic Tuning Whip with 6 m Cables B + Tube 5.75
ANT-3042-NC 3042 HF Antenna Tuner with 6 m Cables B 4.12
ANT-3042-6M 3042 HF Antenna Tuner (No Cables) B 3.6
ANT-9350-NC 9350 Automatic Tuning Whip (No Cables) D 8.6
ANT-9350-6M 9350 Automatic Tuning Whip with 6 m Cables D 9.28
CONTROL-POINT-ASR-
6M NGTTM ASR Control Point Kit B 2.5
CONTROL-POINT-SR-
6M NGTTM SR Control Point Kit B 2.5
ENVOY-X1-BASE Envoy™ X1 Base Station Configuration B, PSU, T 14.02
ENVOY-X1-BASE-AUS Envoy™ X1 Base Configuration for Australia B, PSU, T 14.02
ENVOY-X1-CONS-AUS Envoy™ X1 Base (with Console) Configuration for
Australia
B, PSU, T 15.12
ENVOY-X1-MOB Envoy™ X1 Mobile Configuration B 4.23
ENVOY-X1-MOB-3040-
AUS Envoy™ X1 Mobile (3040) Configuration for Australia B, B, TUBE 14.58
ENVOY-X1-MOB-9350-
AUS Envoy™ X1 Mobile (9350) Configuration for Australia B, D 16.46
ENVOY-X1-MOB-
EXPLORER-AUS Envoy™ X1 Explorer Mobile Configuration for Australia B, B, TUBE 14.45
ENVOY-X1-MOB-
VENTURER-AUS Envoy™ X1 Venturer Mobile Configuration for Australia B, D 15.06
ENVOY-X1-TCVR Envoy™ X1 Transceiver B 4.23
ENVOY-X1-TCVR-AUS Envoy™ X1 Transceiver for Australia B 4.23
ENVOY-X2-BASE Envoy™ X2 Base Station Configuration B 4.23
ENVOY-X2-BASE-AUS Envoy™ X2 Base Configuration for Australia B, PSU, T 14.02
ENVOY-X2-CONS-AUS Envoy™ X2 Base (with Console) Configuration for
Australia
B, PSU, T 15.12
ENVOY-X2-MOB Envoy™ X2 Mobile Configuration B 4.23
Page 172 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
ENVOY-X2-MOB-3040-
AUS Envoy™ X2 Mobile (3040) Configuration for Australia B, B, TUBE 14.58
ENVOY-X2-MOB-9350-
AUS Envoy™ X2 Mobile (9350) Configuration for Australia B, D 16.46
ENVOY-X2-TCVR Envoy™ X2 Transceiver B 4.23
ENVOY-X2-TCVR-AUS Envoy™ X2 Transceiver for Australia B 4.23
HIGH-PWR-500 3061 500 W Power Amplifier HPPA1, HPPA2 35.0
HIGH-PWR-1000 3062 1 kW Power Amplifier HPPA1, HPPA2 47.0
MODEM-3012-NC 3012 HF Data Modem (No Cables) PSU 2.99
MODEM-3012-NGT-
2M 3012 HF Data Modem for NGTTM with 2 m RS232 Cable PSU 3.37
MODEM-3012-NGT-
6M 3012 HF Data Modem for NGTTM with 6 m RS232 Cable PSU 3.59
MODEM-3012-2110-
6M 3012 HF Data Modem for 2110 with 6 m RS232 Cable PSU 3.56
MODEM-3212-NC 3212 HF Data Modem (No Cables) B 3.0
MODEM-3212-NGT-2
M3212 HF Data Modem for NGTTM with 2 m RS232 Cable B 4.39
MODEM-3212-NGT-6
M3212 HF Data Modem for NGTTM with 6 m RS232 Cable B 5.74
MODEM-3212-2110-
2M 3212 HF Data Modem for 2110 with 2 m RS232 Cable B 4.74
MODEM-3212-2110-
6M 3212 HF Data Modem for 2110 with 6 m RS232 Cable B 5.74
NGT-AR-BASE-CON NGT™ AR Base Configuration for Australia B 15.47
NGT-AR-MOB NGT™ AR Mobile Configuration for Australia B, D 16.46
NGT-AR-MOB-3040 NGT™ AR Mobile (3040) Configuration for Australia B, B, TUBE 14.58
NGT-AR-TCVR NGT™ AR Transceiver Configuration for Australia B 7.0
NGT-ASR-BASE NGTTM ASR Base Station Configuration A, PSU, T463 20.0
NGT-ASR-MOB NGTTM ASR Mobile Configuration B, D 18.0
Codan Radio Communications Commercial Product Catalogue Page 173
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
NGT-ASR-TCVR NGTTM ASR Transceiver B 7.0
NGT-SR-BASE NGTTM SR Base Station Configuration A, PSU, T463 20.0
NGT-SR-MOB NGTTM SR Mobile Configuration B, D 18.0
NGT-SR-TCVR NGTTM SR Transceiver B 7.0
NGT-SRX-BASE NGTTM SRx Base Station Configuration A, PSU, T463 20.0
NGT-SRX-MOB NGTTM SRx Mobile Configuration B, D 18.0
NGT-SRX-TCVR NGTTM SRx Transceiver Configuration B 7.0
NGT-SRX-BASE-AUS NGT SRx Base Configuration for Australia B, T643, PSU 14.47
NGT-SRX-TCVR-AUS NGTTM SRx Transceiver Configuration for Australia B 5.04
NGT-SRX-MOB-3040 NGT™ SRx Mobile (3040) Configuration for Australia B, B, TUBE 14.58
NGT-SRX-MOB-AUS NGT™ SRx Mobile (9350) Configuration for Australia B, D 16.46
REMOTE-ENVOY-ETH Envoy Remote Control Accessories — Ethernet B 1.6
REMOTE-NRI-CTRL-
2W NGT™ Remote Interface Control Site — 2 Wire Interface B 4.63
REMOTE-NRI-TCVR-
2W NGT™ Remote Interface Transceiver Site — 2 Wire
Interface
B4.16
REMOTE-SPLIT-CTRL-
8571-2W NGT™ Split-site Control Site — 2 Wire Interface B 6.99
REMOTE-SPLIT-RX-
8571-2W NGT™ Split-site Receive Site — 2 Wire Interface B 6.49
REMOTE-SPLIT-TX-
8571-2W NGT™ Split-site Transmit Site — 2 Wire Interface B 6.39
REMOTE-SPLIT-TXRX-
8571-2W NGT™ Split-site Transmit & Receive — 2 Wire Interface B.B 13.0
REMOTE-SPLIT-CTRL-
8571-4W NGT™ Split-site Control Site — 4 Wire Interface B 6.91
REMOTE-SPLIT-RX-
8571-4W NGT™ Split-site Receive Site — 4 Wire Interface B 6.41
REMOTE-SPLIT-TX-
8571-4W NGT™ Split-site Transmit Site — 4 Wire Interface B 6.31
REMOTE-SPLIT-TXRX-
8571-4W NGT™ Split-site Transmit & Receive Site — 4 Wire
Interface
B.B 13.0
RTI-3033-NGT 3033 Telephone Interconnect HPA 10.0
Page 174 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
XPATCH-NGT 3031 CrosspatchTM for NGT™ L 0.84
XPATCH-2110 3031 CrosspatchTM for 2110 L 0.84
05-06374 Earth Braid, 1.5 m M 0.5
06-02489-EN Quick Reference Card, Crosspatch™ 3031 (English) L 0.32
06-02809-EN Quick Reference Card, Envoy™ (English) L 0.32
08-01233 Strain Relief L 0.5
08-01503-002 Cable, Coax Assembly, UHF Type Connectors, RG58, 2 m M 0.5
08-01503-006 Cable, Coax Assembly, UHF Type Connectors, RG58, 6 m L 0.5
08-01503-008 Cable, Coax Assembly, UHF Type Connectors, RG58, 8 m L 0.5
08-01503-030 Cable, Coax Assembly, UHF Type Connectors, RG58,
30 m
B3.0
08-03255 Cable, Battery, 6 m L 0.5
08-04146-001 Cable, 6-way Phone M 0.5
08-04284 Cable, Phone Plug Adaptor Modular to 604 Plug M 0.5
08-04515-001 Earth Wire, 0.5 m M 0.5
08-04835-013 Tuner, 9103 Automatic Antenna with 10 m Cables B 4.0
08-04835-015 Tuner, 9103 Automatic Antenna with 30 m Cables B 4.0
08-04971-010 Cable, Coax Assembly, UHF Type Connectors, RG213,
10 m
A2.0
08-04971-030 Cable, Coax Assembly, UHF Type Connectors, RG213,
30 m
A5.0
08-04971-050 Cable, Coax Assembly, UHF Type Connectors, RG213,
50 m
A7.0
08-04971-100 Cable, Coax Assembly, UHF Type Connectors, RG213,
100 m
A 20.0
08-05063-001 9350 Main Assembly D 7.0
08-05086-001 Cable, Data Interface, 2 m L 0.5
08-05086-006 Cable, Data Interface, 6 m L 0.5
08-05123-001 Cable, NSP Interface M 0.5
08-05140-001 9350 Spring L 1.0
08-05288-009 Rack Cabinet, 9RU High, 19" Format, 500 mm Deep R 23.4
08-05288-012 Rack Cabinet, 12RU High, 19" Format, 500 mm Deep R 22.0
08-05288-018 Rack Cabinet, 18RU High, 19" Format, 500 mm Deep H 24.0
08-05399-001 Cable, Battery Paralleling (+ve) M 0.5
Codan Radio Communications Commercial Product Catalogue Page 175
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
08-05399-002 Cable, Battery Paralleling (-ve) M 0.5
08-05610-001 Cable, CIB Interface, 0.5 m M 0.5
08-05610-002 Cable, CIB Interface, 2 m M 0.5
08-05610-006 Cable, CIB Interface, 6 m P4 0.5
08-05610-030 Cable, CIB Interface, 30 m 1/2B 3.0
08-05627-002 Cable, NGTTM /EnvoyTM to 9350/304X Control, 2 m L 0.2
08-05627-006 Cable, NGTTM /EnvoyTM to 9350/304X Control, 6 m L 0.5
08-05627-008 Cable, NGTTM /EnvoyTM to 9350/304X Control, 8 m L 0.5
08-05627-010 Cable, NGTTM /EnvoyTM to 9350/304X Control, 10 m PSU 0.5
08-05627-020 Cable, NGTTM /EnvoyTM to 9350/304X Control, 20 m PSU 1.2
08-05627-030 Cable, NGTTM /EnvoyTM to 9350/304X Control, 30 m B 3.0
08-05628-001 NGTTM SR 2010 RF Unit B 5.0
08-05628-004 NGTTM VR 2011 RF Unit B 5.0
08-05628-007 NGTTM ASR 2010 RF Unit B 5.0
08-05628-009 NGTTM SRx 2012 RF Unit B 5.0
08-05629-001 NGTTM SR 2020 Handset L 0.3
08-05629-007 NGTTM ASR 2020 Handset L 0.3
08-05629-009 NGTTM SRx 2020 Handset L 0.3
08-05630-001 NGTTM SR 2030 Junction Box 1/2B 0.5
08-05630-005 Split-site Interface Control Junction Box 1/2B 0.5
08-05630-007 NGTTM ASR 2030 Junction Box 1/2B 0.5
08-05712-001 Cable, NGTTM to 3012 Modem, 1 m L 0.5
08-05712-006 Cable, NGTTM to 3012 Modem, 6 m L 0.72
08-05837-002 Cable, Coax Assembly, UHF to N-type Connectors, RG58,
2m
L0.125
08-05837-006 Cable, Coax Assembly UHF to N-type Connectors, RG58,
6m
PSU 0.285
08-05837-010 Cable, Coax Assembly UHF to N-type Connectors, RG58,
10 m
PSU 0.5
08-05837-020 Cable, Coax Assembly UHF to N-type Connectors, RG58,
20 m
PSU 1.1
08-05847-001 Interface Adaptor M 0.2
Page 176 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
08-05858-001 Cable, NRI to Line Modem M 0.5
08-05859-001 Cable, Power NRI to Line Modem M 0.5
08-05864-001 3030 NGTTM Remote Interface Unit B 2.0
08-05868-001 Cable, Power to RF Unit and NRI M 0.5
08-05877-004 3012 HF Data Modem B 2.74
08-05920-001 Cable, DC Extension, 1 m M 0.2
08-05956-001 Cable, High Power Amplifier Controller L 0.5
08-05974-001 3061 500 W Power Amplifier HPPA1 20.0
08-05975-001 3062 1 kW Power Amplifier HPPA1 27.0
08-05980-001 UUPlusTM Email for HF Client Software 1/2B 0.5
08-05981-001 UUPlusTM Email for HF Server Software 1/2B 0.5
08-05989-001 Cable, Power Adaptor, Split-site M 0.5
08-05990-001 Cable, 8571 Split-site Remote Interface to NGTTM M0.5
08-05994-001 8571 NGTTM Remote Control Interface B 2.0
08-06022-001 Envoy™/NGT™ Handset Control Cable, 6 m M 0.4
08-06067-001 3061 500 W Power Supply Unit HPPA2 14.0
08-06102-001 3062 1 kW Power Supply Unit HPPA2 17.0
08-06130-001 Basic High Power Rack Configuration H 90
08-06130-002 Remote Control, High Power Rack Configuration H 90
08-06130-003 Remote Control and Data Modem High Power Rack
Configuration
H90
08-06130-004 Split-site Remote Control High Power Rack
Configuration
H90
08-06155-001 2110 SSB Tcvr Unit (1.5 ppm) PSU 3.5
08-06155-002 2110 SSB Tcvr Unit (0.5 ppm) PSU 3.5
08-06155-003 2110v SSB Tcvr Unit (1.5 ppm) PSU 3.5
08-06185-001 Battery Pack 12 V 8Ah NiMH 1/2B 2.6
08-06186-001 Battery Pack 12 V 13Ah NiMH 1/2B 3.4
08-06213-001 Cable, VP-116 Interface M 0.5
08-06214-001 Cable, Charger O/P, 6way M 0.3
08-06215-001 Cable, charger O/P, 19way M 0.3
Codan Radio Communications Commercial Product Catalogue Page 177
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
08-06216-001 Cable, DC Charger I/P, Lighter Adaptor M 0.4
08-06217-001 Cable, DC Charger I/P, Clips Adaptor M 0.4
08-06222-001 NGTTM ASR VP-116 Junction Box 1/2B 0.5
08-06237-001 Cable, 2110 Prog 19way MIL-D9F M 0.5
08-06259-001 Earth Wire with Clip M 0.3
08-06274-001 3212 HF Data Modem B 4.34
08-06330-001 Cable, NGTTM to Q9600 Modem, 1 m M 0.5
08-06356-001 Cable, NGT™/Envoy™ to 3212 Modem, 1 m L 0.42
08-06356-006 Cable, NGT™/Envoy™ to 3212 Modem, 6 m L 0.76
08-06357 Cable, BNC to UHF Coaxial, 1 m M 0.2
08-06359-002 Cable, Serial D9M-D9F Isol Shield Cable, 2 m M 0.4
08-06359-006 Cable, Serial D9M-D9F Isol Shield Cable, 6 m L 0.1
08-06360-002 Cable, 9-way to 9-way Serial, 2 m L 0.42
08-06360-006 Cable, 9-way to 9-way Serial, 6 m L 0.55
08-06361-002 Cable, Serial 25-way to 25-way, 2 m L 0.55
08-06361-006 Cable, Serial 25-way to 25-way, 6 m L 0.83
08-06380-001 Cable, Serial 6-way to D9F M 0.5
08-06422-001 Cable, 2110 Manpack to 3012 Modem, 1 m L 0.46
08-06454-001 NGTTM to MICOM Interface Box L 0.49
08-06730-001 3031 VHF/UHF to HF Crosspatch™ for NGT™ L 0.54
08-06730-002 3031 VHF/UHF to HF Crosspatch™ for 2110 L 0.59
08-06737-001 Cable, 2110v Prog 5way MIL-D9F M 0.5
08-06738-001 Cable, charger O/P, 5way M 0.3
08-06739-001 Tuner, SG235C 500 W PEP B 3.5
08-06740-030 Cable, SG235C Control, 30 m 1/2B 3.0
08-06766-001 Cable, 3031 to VHF/UHF Transceiver Generic, 2 m L 0.5
08-06786-001 Cable, 2110 Manpack to 3112 Modem, 1 m L 0.44
08-07000-001 EnvoyTM 2220 Handset L 0.3
08-07000-002 EnvoyTM 2221 Limited Keyset Handset L 0.3
08-07007-001 3040 Main Assembly B 5.0
08-07009-001 Battery Pack 12 V 17Ah LiFePO4 PSU 3.0
Page 178 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
08-07010-006 Antenna Tuner Control Cable, 6 m L 1.0
08-07148-001 3040 Spring L 1.0
08-07204-001 EnvoyTM 2230 Desk Console 1/2B 1.1
08-07214-001 Cable, Envoy™ USB Programming M 0.04
08-07218-001 EnvoyTM X1 2210 RF Unit PSU 2.9
08-07218-002 EnvoyTM X2 2210 RF Unit 2.9
15-00112 Complete Vehicle Installation Kit B 2.5
15-00129 NGTTM Handset Cradle Kit M 0.5
15-00134 NGTTM Remote Control Earth Kit for the Remote Site L 0.5
15-00135 NGTTM Remote Control Earth Kit for the Control Site L 0.1
15-00136 Cradle, NGTTM RF Unit Mounting/3012 HF Data Modem B 2.3
15-00139 Cradle, 2110/2110v with Screws B 2.5
15-00140 Cradle, 2110 with Interface Adpaptor B 3.5
15-00141 Cradle, 2110 with 9350 Interface B 2.6
15-00143 2110 External DC for Cradle L 0.3
15-00144 2110 External DC Vehicle Kit 1/2B 2.1
15-00145 CrosspatchTM 3031 Installation Kit P1 0.12
15-00149 EnvoyTM Handset Cradle L 0.05
15-00158 Earth Mat for Base Whip Antenna, Ground Installations 406A 3.0
15-00159 Radial Ground Plane for Base Whip Antenna, Roof
Installations
B6.0
15-00163 Earth Stake C 2.0
15-00164-010 19" Rack-mounting Frame for 8571 Split-site Remote
Interface
A2.0
15-00172-001 NGTTM Universal 19" Rack-mounting Tray 3RU with Blank
Front Panel
F2.0
15-00172-002 NGTTM /EnvoyTM Universal 19" Rack-mounting Tray 3RU,
Front Panel with Speaker Grill and Mounting Holes
F2.5
15-00173 Set of 1RU + 2RU Blank Front Panels B 0.6
15-00176 19" Rack-mounting Frame suitable for 3020 Transceiver
Supply, and 3012 or 3212 HF Data Modems
T2.39
15-00216 Backpack, External Frame BPK 5.5
15-00218 Backpack, Softpack B2 2.5
Codan Radio Communications Commercial Product Catalogue Page 179
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
15-00323 NVIS Antenna Kit C 2.0
15-00403 Ant, Tuned Long Wire (2–30 MHz) B 1.0
15-00406-001 Ant, Base Whip, Ground Mounting (9.5 m/31 ft
Unloaded)
406 7.0
15-00406-002 Ant, Base Whip, Roof Mounting (9.5 m/31 ft Unloaded) 406A 7.0
15-00411-003 Ant, TFD411, 125 W, 2–30 MHz, 43 m T 6.0
15-00411-004 Ant, TFD411, 125 W, 2–30 MHz, 34 m T 6.0
15-00411-005 Ant, TFD411, 125 W, 2–30 MHz, 27 m T 6.0
15-00411-011 Ant, TFD411, 1000 W, 2–30 MHz, 34 m T 17.0
15-00411-012 Ant, TFD411, 1000 W, 2–30 MHz, 43 m T 17.0
15-00422-012 Mast, Guyed 12 m with Erection Kit M1, M2 47.0
15-00422-015 Mast, Guyed 15 m with Erection Kit M3, M4 51.0
15-00446 Counterpoise 4-wire kit M 0.5
15-00452 Ant, 3 m (10’) Collapsible Whip 25 W 1/2C 1.4
15-00453 Ant, 1.5 m (5’) Tape Whip 25 W 1/2C 1.3
15-00454 Ant, Long Wire and Adaptor 25 W PEP (1.6–30 MHz) L 0.8
15-00455 Ant, Wire Dipole 25 W PEP (3–30 MHz) 1/2B 3.2
15-00456 Ant, Broadband Dipole 25 W PEP (3–30 MHz) 1/2B 3.1
15-00457 Ant, Dipole and Broadband kit 25 W PEP (2–30 MHz) 1/2B 3.8
15-00458 Ant, End-fed Broadband 25 W PEP (3–30 MHz) 1/2B 1.6
15-00459 Ant, 1.5 m (5’) Knock Over Whip 25 W 1/2C 1.3
15-00462 Anchor peg L 0.4
15-00464 Lightning Arrestor M 0.5
15-00508 Voltage Regulator (24 V to 12 V operation 20 A) B 1.2
15-00531 Solar Power Supply 40 W SOLA 9.0
15-00532 Solar Power Supply 80 W SOLA 18.0
15-00533 Solar Power Supply 240 W 533A, C 44.0
15-00573 2110 Battery Charger AC 1 A L 0.7
15-00576 2110 Voltage Regulator (24 V to 12 V operation 7 A) L 0.98
15-00577 2110 Solar Battery Charger 1/2B 3.0
Page 180 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
15-00578 2110 Hand-powered Battery Charger F 5.0
15-00602 Desk Console Headphones, NGT™ B 1.0
15-00649 External Speaker with 4 m Lead M 0.4
15-00662 Morse Key for Envoy™/NGT™ L 0.5
15-00702 Cable Kit for Float Charge L 2.0
15-00704 Vehicle Interference Suppression Kit L 1.0
15-00711 Fuse Holder with 32 A Fuse L 0.5
15-00712 Fuse, 32 A M 0.5
15-00765 GPS Receiver/Antenna for VR and SRx L0.67
15-00766 NGTTM (VR and SRx) Desk Console 1/2B 1.5
15-00771 GPS Receiver/Antenna for ASR L0.64
15-02063-CD NGTTM Transceiver System Technical Service Manual on
CDROM (English)
M0.25
15-04102-
##
Reference Manual, Remote Control NGTTM Systems L 0.5
15-04104-
##
User Guide, HF Data Modem 3012 L 0.5
15-04104-CD User Guide, HF Data Modem 3012 (English) M 0.25
15-04125-EN Reference Manual, Split-site Remote Control NGTTM
Systems (English)
L0.5
15-04127-
##
Getting Started Guide, NGT™ Transceiver, includes
Reference Manual on CDROM
L0.5
15-04164-EN NSP Software CD Package M 0.25
15-04131-
##
Reference Manual, High Power Amplifiers 3061/3062 L 0.5
15-04136-
##
Getting Started Guide, 2110 series Manpack Transceiver,
includes Reference Manual on CDROM
M0.5
15-04137-EN Getting Started Guide, NGT™ ASR Transceiver, includes
Reference Manual on CDROM (English)
L0.5
15-04140-
##
Getting Started Guide, NGT™ SRx Transceiver, includes
Reference Manual on CDROM
L0.5
15-04142-
##
Installation Handbook, Automatic Tuning Whip Antenna
9350
L0.5
15-04146-CD User Guide, HF Data Modem 3212 on CDROM P4 0.3
15-04146-EN User Guide, 3212 HF Data Modem (English) P4 0.3
##
denotes language version, see page 165, Language Support
Codan Radio Communications Commercial Product Catalogue Page 181
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
15-04148-CD User Guide, CrosspatchTM 3031 on CDROM (English) M 0.25
15-04148-EN User Guide, CrosspatchTM 3031 (English) L 0.5
15-04155-EN Codan HF ExpressTM and STANAG 5066 Stack (English) P1 0.14
15-04177-## EnvoyTM Transceiver Getting Started Guide, includes
Reference Manual on CDROM
L0.5
15-04178-CD TPS-3250 EnvoyTM Programming Software CD M 0.25
15-10469 Opt Fan (Retro Fit) 1/2B 0.5
15-10471 NGT™ (SR and ASR) Desk Console (Retro Fit) 1/2B 1.0
15-10507 Opt Voice Encryptor (Retro Fit) 1/2B 0.5
15-10509 Opt 2 W, 2-wire (Retro Fit) 1/2B 0.5
15-10510 Opt 4 W, 4-wire (Retro Fit) 1/2B 0.5
15-60012 3040 Automatic Whip Antenna Installation Handbook,
c/w Antenna Connector Sealing Kit
P4 0.2
15-60024 Desk Console Hand-held Microphone, Envoy™ M 0.22
15-60025 Desk Console Boom Microphone, Envoy™ L 0.1
15-60026 Desk Console Headset, Envoy™ PSU 1.17
15-60027 Desk Console PTT footswitch, Envoy™ M 0.26
15-60028 Desk Console Headphones, Envoy™ PSU 1.16
30-35002-006 19" 1RU Vent Panel 406A 1.0
30-35002-019 19" 4RU Vent Panel 406A 2.0
30-35002-020 Fixed Equipment Rail, 457 mm Long 406A 0.5
30-37601-002 Copper Earth Strip M 0.5
30-38000-002 Shackle L 0.1
39-79150-080 Ferrite Bead Clamp P1 0.13
60-00063-501 6-way Modular Wall Mounting Socket L 0.1
60-00098-590 Adaptor, 9-pin D PIug to 25-pin D Socket P1 0.13
60-11163-204 Plug, UHF (RG213) W/proof P1 0.1
60-11163-221 Plug, UHF (RG58) W/proof P1 0.1
65-72000-012 Battery, Lead acid 12 V 90Ah (supplied dry charged) – 18.0
65-72003 Battery, 12 V 100Ah Gelcell – 39.0
##
denotes language version, see page 165, Language Support
Page 182 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
65-72004 Battery, 12 V 185Ah Gelcell – 65.0
67-90200 Cable, 2C IEC C7 AUS, 2 m L 0.5
67-90201 Cable, 2C IEC C7 UK, 2 m L 0.5
67-90202 Cable, 2C IEC C7 US, 2 m L 0.5
67-90203 Cable, 2C IEC C7 EU, 2 m L 0.5
67-90305 Cable, 3C Blk Mld IEC AUS, 2 m L 0.5
67-90306 Cable, 3C Blk Mld IEC UK, 2 m L 0.5
67-90307 Cable, 3C Blk Mld IEC US, 2 m L 0.5
67-90308 Cable, 3C Blk Mld IEC EU, 2 m L 0.5
67-90309 Cable, 3C Blk Mld IEC 320-UK, 2 m L 0.5
67-90406 Cable, USB Adaptor for Memory Stick Programming 0.01
67-90800 Cable, Ethernet Crossover CAT-5E, 2 m Red L 0.38
67-90801 Cable, Ethernet Crossover CAT-5E, 10 m Red L 0.64
67-90802 Ethernet Straight CAT-5E Cable, 2 m Blue L 0.38
67-90803 Ethernet Straight CAT-5E Cable, 10 m Blue L 0.64
67-90805 Cable, Ethernet Straight CAT-5E, 100 m Blue B 2.71
78-01012 Ant, Semi-delta (2–30 MHz, 125 W PEP) T 6.0
78-01022 Ant, Full Delta (2–30 MHz, 125 W) 1022 30.0
78-01031 Adaptor, USB to DB-9, Serial M 0.5
78-02007 Battery Charger AC-DC 3121 M 0.5
78-02008 Battery Charger DC-DC 3122 M 0.5
78-02012 Battery Charger AC-DC 3123 M 0.5
78-07003-010 InterNav-CHFTM GPS Tracking Software–10 User 1/2B 1.0
78-07003-025 InterNav-CHFTM GPS Tracking Software–25 User 1/2B 1.0
78-07003-050 InterNav-CHFTM GPS Tracking Software–50 User 1/2B 1.0
78-07003-100 InterNav-CHFTM GPS Tracking Software–100 User 1/2B 1.0
78-07003-990 InterNav-CHFTM GPS Tracking Software–1 User (Dealer) 1/2B 1.0
78-08000 Handset H-250/U L 0.7
78-13016 Modem, Leased Line 1/2B 1.0
78-13035 Mast, Man-portable 6 m Tactical T 6
78-14010 3040/3042 NVIS Antenna Kit TUBE 2.6
Codan Radio Communications Commercial Product Catalogue Page 183
Issue 8 January 2015
Shipping Weights
SHIPPING WEIGHTS Shipping Weights
PART NO. DESCRIPTION BOX TYPE PACKED
WGHT (kg)
78-16019 Power Supply Unit, 90 to 264 V AC L 0.2
78-16042 Sealevel PCI Synchronous Serial Card L 0.39
78-18058 Riser, fibreglass TUBE 2.0
78-23007-003 9350 Fibreglass Whip, 1.6 m NV 0.5
78-23025 9350 Tapered Stainless Steel Whip, 1.2 m NV 0.2
78-23056 9350 Tapered Stainless Steel Whip, 1.65 m NV 0.2
78-23085 3040 Fibreglass Whip, 1.6 m TUBE 1.5
78-23086 3040 Stainless Steel Whip TUBE 1.5
Page 184 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Standard Packing Dimensions
NOTE 1: All weights shown are net packed weights calculated to the nearest 0.5 kg.
NOTE 2: In a number of instances accessories will be packed together or with the main equipment
resulting in a reduction of the total published weight.
NOTE 3: Where applicable, the standard pack reference code has been given as a general guide to
the overall dimensions of the carton/crate used to pack main equipment and some selected
accessories. It should be noted, however, that the dimensions shown might vary from time-to-time
depending on the consignment circumstances.
Standard Packing Dimensions
STANDARD PACKING DIMENSIONS
REF CODE DIMENSIONS APPROXIMATE
VOLUME (m3)
A 510 x 510 x 280 mm 0.07
AA 510 x 510 x 280 mm 0.07
B 510 x 340 x 280 mm 0.05
B1 510 x 340 x 280 mm 0.05
B2 510 x 340 x 280 mm 0.04
BPK 590 x 410 x 200 mm 0.05
C 2200 x 130 x 90 mm 0.03
CMR 660 x 330 x 330 mm 0.07
D 1700 x 200 x 180 mm 0.06
E 1940 x 480 x 190 mm 0.18
F 600 x 600 x 350 mm 0.13
H 790 x 710 x 1670 mm 0.94
HPPA1 680 x 640 x 420 mm 0.18
HPPA2 680 x 640 x 420 mm 0.18
L 300 x 200 x 100 mm 0.01
M 230 x 210 x 105 mm 0.01
M1 3150 x 160 x 160 mm 0.08
M2 930 x 230 x 200 mm 0.04
M3 3150 x 160 x 160 mm 0.08
M4 930 x 230 x 200 mm 0.04
N 780 x 530 x 80 mm 0.03
NV 2200 x 125 x 90 mm 0.02
O 1200 x 530 x 80 mm 0.05
P1 150 x 220 x 0 mm 0.0
P4 240 x 370 x 0 mm 0.0
PSU 400 x 300 x 190 mm 0.02
Codan Radio Communications Commercial Product Catalogue Page 185
Issue 8 January 2015
Standard Packing Dimensions
STANDARD PACKING DIMENSIONS CONT.
REF CODE DIMENSIONS APPROXIMATE
VOLUME (m3)
R 600 x 600 x 550 mm 0.20
S 170 x 170 x 70 mm 0.01
SD1 1750 x 6.0 x 6.0 mm 0.0
SD2 770 x 360 x 100 mm 0.02
SOLA 1000 x 550 x 200 mm 0.11
SYST 1040 x 520 x 300 mm 0.16
SYS1 1030 x 520 x 300 mm 0.16
SYS2 1030 x 520 x 300 mm 0.16
SYS3 1030 x 520 x 300 mm 0.16
T 800 x 300 x 250 mm 0.06
TW 600 x 550 x 400 mm 0.13
019A 1900 x 460 x 185 mm 0.16
023A 1260 x 830 x 440 mm 0.46
023B 1100 x 1110 x 390 mm 0.48
023C 4500 x 1570 x 140 mm 0.99
024A 960 x 630 x 270 mm 0.16
024B 1100 x 1110 x 390 mm 0.48
024C 4500 x 1570 x 140 mm 0.99
1/2B 311 x 231 x 243 mm 0.02
1/2C 950 x 130 x 90 mm 0.01
40W 660 x 360 x 620 mm 0.15
406 2270 x 120 x 120 mm 0.03
406A 602 x 230 x 50 mm 0.006
408L1 660 x 410 x 160 mm 0.04
408L2 1960 x 180 x 180 0.06
420/14 5200 x 260 x 260 mm 0.35
420/23 7800 x 260 x 260 mm 0.52
533A 1200 x 530 x 300 mm 0.19
1021 1260 x 830 x 470 mm 0.49
1022 910 x 285 x 205 mm 0.05
Page 186 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Standard Terms &
Conditions of Supply
Standard Terms & Conditions of Supply
“Codan’s Standard Terms and Conditions and International Product Warranty (as updated from time to time) apply to all
Orders for the supply of Products by Codan to the Purchaser.”
Dictionary
In the Standard Terms and Conditions of Supply, the words below have the following meanings:
$ means AUD, unless specifically otherwise specified;
ACDC means the Australian Commercial Dispute Centre Limited A.C.N. 003 042
840 of Level 6, 50 Park Street, Sydney, NSW, 2000, Australia;
Agreement means the contract between Codan and The Purchaser as described in clauses 1.4 and 1.5;
Anything of Value includes cash or cash equivalents, gifts, services, employment offers, loans, travel expenses,
entertainment, political contributions, charitable donations, subsidies, per diem payments, sponsorships, honoraria or
provision of any other asset, even if nominal in value.
AUD means Australian dollars;
Business Day means any day except a Saturday, Sunday or public holiday in South Australia;
Calendar Day means a calendar day with periods expressed in Calendar Days subject to extension if necessary to allow for
public holidays in South Australia and/or the location where the Product (if imported) is sourced as the case may be;
Catalogue means any and all catalogues of Codan products published and distributed by Codan in hard copy and
electronically (including by making available for viewing through its official website) to its actual and prospective
customers, setting out product details and current prices, as updated and replaced by Codan from time to time in
its discretion;
Codan or Company means Codan Limited A.C.N. 007 590 605 of 81 Graves Street, Newton, South Australia, 5074, Australia;
Confidential Information means all information disclosed by Codan or The Purchaser and includes:
(a) the fact that the parties will have, or are having, discussions, and the substance of those discussions;
(b) financial information and other trade secrets and confidential know-how;
(c) information regarding each party’s business; and
(d) all information generated by the parties which is based on the information referred to in these paragraphs (a) to (c)
inclusive,
but excludes information that:
(e) the parties create or develop (whether alone or jointly with any person) independently of the Confidential Information;
(f) is public knowledge (otherwise than as a result of a breach of confidentiality by either party or any person to whom it
has disclosed the information);
(g) is rightfully known to, or in the possession or control of either party or any of its personnel and not subject to an
obligation of confidentiality in accordance with the terms of this Agreement; or
(h) becomes available to either party from a source other than the parties and which source has the right to use and
disclose and is not bound by any obligation of confidentiality in respect of the same;
Credit Limit means the AUD value of any credit facility extended by Codan to The Purchaser;
Duties means any stamp, transaction or registration duty or similar charge imposed by any Government Agency and
includes, but is not limited to, any interest, fine, penalty, charge or other amount imposed but excludes any income tax;
EUR or € means the euro (the official currency of the Eurozone);
Existing Arrangements means any arrangements and agreements between Codan and The Purchaser in effect as at the
date an Order is submitted, as agreed by Codan in writing;
Facilitating Payment means a payment to an individual to secure or expedite the performance of a routine government
action by Government Officials;
Force Majeure Event means anything outside a party’s reasonable control including, without limitation, shortages of
materials, fire, storm, flood, earthquake, explosion, accident, enemy acts, war, rebellion, insurrection, sabotage, epidemic,
quarantine restriction, labour dispute, labour shortage, transportation embargo or failure or delay in transportation;
Government Agency means any government or governmental, semi governmental, administrative, fiscal or judicial body,
department, commission, authority, tribunal, agency or entity;
Codan Radio Communications Commercial Product Catalogue Page 187
Issue 8 January 2015
Standard Terms &
Conditions of Supply
Government Official means:
(a) any officer or employee of a government or any department, agency or instrument of a government (including but not
limited to any Government Agency);
(b) any person acting in an official capacity for or on behalf of a government or any department, agency, or instrument of a
government (including but not limited to any Government Agency);
(c) any officer or employee of a company or business owned in whole or part by a government;
(d) any officer or employee of a public international organisation such as the World Health Organisation or United Nations;
(e) any officer or employee of a political party or any person acting in an official capacity on behalf of a political party;
and/or
(f) any candidate for political office;
GST has the meaning it does in section 195-1 of the GST Act;
GST Act means A New Tax System (Goods and Services Tax) Act 1999 (Cth), as amended, varied or replaced from
time to time;
Insolvency Event, in relation to The Purchaser, means any of the following events:
(a) The Purchaser is unable to pay its creditors (or any class of them) in the ordinary course of business;
(b) a receiver, receiver and manager, administrator, liquidator or similar officer is appointed to The Purchaser or
any of its assets;
(c) The Purchaser enters into, or resolves to enter into, a scheme of arrangement, compromise or composition with any
class of creditors;
(d) a resolution is passed or an application to a court is taken for the winding up, dissolution, official management or
administration of The Purchaser; or
(e) anything having a substantially similar effect to any of the events specified above happens under the law of any
applicable jurisdiction;
Intellectual Property Rights means any and all intellectual and industrial property rights anywhere in the world, including
but not limited to the rights comprised in any patent, copyright, design, trade mark, eligible layout or similar right whether
at common law or conferred by statute, rights to apply for registration under a statute in respect of those or
like rights and rights to protect trade secrets and know how, throughout the world for the full period of the rights and
all renewals and extensions;
International Product Warranty means the warranty set out in the document on page 195, which is incorporated into and
forms part of these Standard Terms and Conditions;
Order means an order for Products created as the result of The Purchaser’s issue of a formal purchase order to Codan in hard
copy or electronically (in a form agreed by Codan). Issuance of an Order (whether or not a Quotation is first issued by Codan)
is deemed to constitute acceptance of these Standard Terms and Conditions by The Purchaser. In the event that a
Quotation is issued by Codan, issuance of an Order is also deemed to constitute acceptance of the Quotation
by The Purchaser;
Order Acknowledgement means Codan's written confirmation that an Order has been received from The Purchaser, and
the Agreement brought into existence;
Order Value means the total price charged by Codan to The Purchaser for any Order, and including any amounts payable by
The Purchaser and charged by Codan in accordance with clause 3.1;
Payment refers to and includes any direct or indirect offer to pay, promise to pay, authorisation of payment of, or transfer of,
Anything of Value;
Perfected has the meaning given to that term in the PPSA;
PPSA means the Personal Properties Securities Act 2009 (Cth) and any regulations made under it;
PPS Register means the register established under the PPSA;
Products means the products to be manufactured and/or imported by Codan for The Purchaser as listed in the Order;
Quotation or Quote means the quote, if any, issued by Codan to The Purchaser in respect of the Products to which these
Standard Terms and Conditions of Supply are attached;
Security Agreement has the meaning given to that term in the PPSA;
Security Interest has the meaning given to that term in the PPSA;
Supply has the same meaning it does in section 9-10 of the GST Act and excludes any “GST-free supplies” and “input taxed
supplies” as those terms are defined in section 195-1 of the GST Act;
Page 188 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Standard Terms &
Conditions of Supply
Tax or Taxes means any tax, levy, charge, impost, fee, deduction, compulsory loan or withholding (including corporate tax,
personal income tax, fringe benefits tax, payroll tax, withholding tax, excise and import duties, GST, consumption tax, value
added tax or any other taxes, levies or charges), which is assessed, levied, imposed or collected by any Government Agency,
and includes any interest, fine, penalty, charge, fee or any other amount imposed on or in respect of any such amounts;
The Purchaser means the entity requesting that Products be supplied and sold to it by Codan by the issuance of an Order,
as listed in the Quotation (if applicable); and
USD means US dollars.
1. Catalogue/Credit Offers, Quotations and Agreement
1.1 The Purchaser acknowledges and agrees:
(a) that the Catalogue and/or approval of a Credit Limit by Codan following a request for a credit facility received
from The Purchaser in the form specified by Codan constitutes an offer by Codan to sell the Products to The
Purchaser on the terms and conditions set out in these Standard Terms and Conditions of Supply, at the
standard prices for the Products set by Codan which are current on the date The Purchaser submits an Order
to Codan, as notified by Codan to The Purchaser (subject always to clause 2.1 below) (Catalogue/Credit Offer);
and
(b) that the Catalogue/Credit Offer may be accepted by The Purchaser at any time by submitting an Order with
Codan.
1.2 By submitting an Order in response to a Catalogue/Credit Offer, The Purchaser warrants and represents to
Codan that:
(a) it has been provided with a copy of Codan's current Product Price list and that it has reviewed this list prior to
submitting the Order; and
(b) it has read and understood these Standard Terms and Conditions of Supply prior to submitting the Order, and
agrees to be bound by them in full.
1.3 In addition to the Catalogue/Credit Offer, Codan may, in its discretion and following a request
by The Purchaser, make an offer to The Purchaser for the sale of Products by issuing a Quotation. Unless
otherwise specified in the Quotation issued by Codan to The Purchaser (if any) or agreed to in writing by Codan,
all Quotations issued by Codan are valid for 30 days from the date of issue (Acceptance Period). The Purchaser
must accept a Quotation by submitting an Order with Codan during the Acceptance Period. Any Quotation not
accepted by The Purchaser during the Acceptance Period will lapse.
1.4 A contract between Codan and The Purchaser for the supply by Codan, and the purchase by The Purchaser, of the
Products will come into existence:
(a) in cases where a Quotation is issued by Codan, on the date The Purchaser accepts the Quotation by
submitting a valid Order with Codan within the Acceptance Period; and
(b) in all other cases, on the date that The Purchaser submits a valid Order with Codan, in response to the
Catalogue/Credit Offer.
1.5 Codan will determine in its sole discretion whether an Order Form has been validly completed and submitted by
The Purchaser.
1.6 The contract will comprise:
(a) these Standard Terms and Conditions of Supply;
(b) the Quotation issued by Codan, if any;
(c) the Product details listed in the Order; and
(d) the invoice issued by Codan to The Purchaser,
to the exclusion of any other terms and conditions (including but not limited to any variations to either these
Standard Terms and Conditions or the terms of the Quotation or the Catalogue/Credit Offer (as applicable)
purported to be made by The Purchaser in the Order) and apart from any terms, conditions or guarantees implied
or provided for by applicable law which cannot lawfully be excluded. Codan may (but is not obliged to) issue an
Order Acknowledgement to The Purchaser, confirming the terms of the contract.
1.7 In the event of an inconsistency between any of the documents listed in clause 1.5 above, the terms of these
Standard Terms and Conditions will prevail to the extent of the inconsistency, with the terms of the
Quotation (if any) prevailing thereafter. To the extent of any inconsistency between the document in clause 1.6(c)
and 1.6(d) above, the document described in clause 1.6(d) will prevail.
1.8 Neither this Agreement nor any Order that has been submitted can be cancelled by The Purchaser except with the
prior written consent of Codan. Codan can cancel and terminate any Order or this Agreement in its sole
discretion, without penalty, if it considers that an Order Form has not been validly completed and/or submitted
by
The Purchaser.
Codan Radio Communications Commercial Product Catalogue Page 189
Issue 8 January 2015
Standard Terms &
Conditions of Supply
2. Prices
2.1 Prices specified by Codan for the Products in a Quotation or any current Product Price list issued by Codan, as
applicable, are based upon the prevailing currency exchange rates generated by the Codan system. Subject to
Codan deciding in its sole discretion that it would be fair and reasonable in the circumstances to do so, Codan
may pass on any variation in currency exchange rates to The Purchaser in any invoice issued in accordance with
clause 3.2.
2.2 If a Quotation has been issued by Codan, The Purchaser acknowledges that it has been prepared by Codan
on the basis of, and in reliance upon, the information provided by The Purchaser, and further acknowledges that
the provision of incomplete or misleading information by The Purchaser, unforeseen circumstances,
misinterpretations, variations and similar events may result in charges additional to those set out in the
Quotation being payable by The Purchaser for the Products. The Purchaser agrees to pay any such additional
amounts to Codan, in full.
2.3 Unless otherwise expressly specified by Codan, all prices stated are exclusive of Product delivery costs and freight
charges.
3. Payment
3.1 The Purchaser is solely responsible for payment of all freight, insurance, delivery costs, Taxes and other charges
levied or payable in respect of the Products, unless otherwise agreed by the parties in writing.
3.2 Codan will invoice The Purchaser for the Order Value of the Order at any time following receipt of such Order.
3.3 Unless otherwise stated in the Quotation the due date for payment by The Purchaser to Codan for the Order
(Due Date) is as follows:
(a) 30 days from the date on which the invoice was issued, if the following conditions are satisfied at the time
that the Order was submitted to Codan (i) The Purchaser has a pre-approved credit facility with Codan and (ii)
the Order Value, combined with any outstanding payments due to Codan by The Purchaser at the time of the
Order, fall within The Purchaser’s approved Credit Limit; and
(b) in all other cases, payment is immediately due at the time that The Purchaser places the Order with Codan.
3.4 If The Purchaser fails to make any payment by the Due Date, then, without prejudice to any other right or remedy
available to Codan, Codan may, in its sole discretion elect to:
(a) suspend any further deliveries to The Purchaser arising from the Order;
(b) cancel the Order for Products not yet supplied to The Purchaser in whole or in part by Codan;
(c) enter the property of The Purchaser in order to repossess the Products;
(d) appoint a receiver or receiver and manager to do anything the law allows a receiver or receiver and manager
to do;
(e) charge The Purchaser interest (both before and after any judgement) on the unpaid amount at the rate of
10% per annum until payment is made in full; and/or
(f) withdraw any Credit Limits or credit facilities previously approved and extended to The Purchaser.
4. Delivery
4.1 Unless otherwise stated in any Order Acknowledgement issued by Codan to The Purchaser, Codan will deliver the
Products to The Purchaser in the manner (i) specified in the Order or (ii) if a Quotation has been issued, in the
manner specified in the Quotation, regardless of what is stated in the Order submitted by The Purchaser.
4.2 Codan will use its reasonable endeavours to deliver the Products described in the Order on the delivery date
requested by The Purchaser.
4.3 Risk of damage to or destruction or loss of the Products will pass to The Purchaser at the time of delivery to
The Purchaser or its nominated carrier, as appropriate.
4.4 Notwithstanding delivery and the passing of risk in the Products, the parties acknowledge and agree that the title
to, and property and ownership of, the Products supplied under this Agreement will not pass to The Purchaser
until Codan has received, in cleared funds, payment in full for the Products and any other sums which are or may
become due to Codan under this Agreement or any other agreement or arrangement between the parties.
4.5 Until such time as full title, property and ownership of the Products passes to The Purchaser in accordance with
clause 4.4, and while the Products remain in The Purchaser’s full control and possession:
(a) The Purchaser must hold the Products as Codan’s fiduciary agent and bailee;
(b) The Purchaser must keep the Products properly stored, protected and insured;
(c) Codan may at any time after payment is overdue require The Purchaser to deliver up the Products to Codan
and, if The Purchaser fails to deliver up the Products immediately, Codan may enter the premises of
The Purchaser or any third party where the Products are stored and repossess them; and
(d) The Purchaser must not pledge or in any way charge by way of security for any indebtedness, any of the
Products which remain the property of Codan. If The Purchaser does pledge or in any way charge by way of
security for any indebtedness any of the Products for which property and ownership has not passed to The
Purchaser, all moneys owing by The Purchaser to Codan will (without prejudice to any other right or remedy of
Codan) immediately become due and payable to Codan.
Page 190 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Standard Terms &
Conditions of Supply
5. PPSA
5.1 The Purchaser acknowledges that until such time as full title, property and ownership of the Products passes to
The Purchaser under clause 4.4, this Agreement constitutes a Security Agreement for the purposes of the PPSA,
and Codan has a Security Interest in the Products.
5.2 Without limiting clause 17.6, The Purchaser agrees to do such things as Codan may require from time to time to
ensure that any Security Interest of Codan arising from or connected with this Agreement is Perfected under the
PPSA for whatever period Codan determines in its sole discretion, including signing documents and providing
Codan with all further information required to enable Codan to register its Security Interests on the PPS Register,
and to otherwise protect Codan's position under the PPSA. The Purchaser must keep Codan fully informed of all
relevant information regarding it and its activities, including by providing not less than 14 days notice in writing
of any proposed change in its name or contact details, and immediately advising Codan of material changes in its
business activities.
5.3 The Purchaser agrees to indemnify Codan for all expenses incurred by Codan in registering its Security Interests
on the PPS Register, and will reimburse Codan for all such expenses immediately upon demand.
5.4 The Purchaser waives its rights under section 157 of the PPSA to receive a notice in relation to the registration
events to which section 157(3)(a) of the PPSA applies, including without limitation, the right to receive a copy of a
verification statement confirming registration of a financing statement or financing change statement relating
to the Security Interest created by this Agreement.
5.5 The Purchaser agrees that nothing in sections 118, 121(4), 125, 130, 142 or 143 of the PPSA will apply to this
Agreement or any Security Interest in the Products created by this Agreement, and waives its rights to receive any
of the following documents:
(a) a notice of removal of an accession under section 95 of the PPSA;
(b) a notice of an intention to seize collateral under section 123 of the PPSA;
(c) a notice of a disposal of collateral under section 130 of the PPSA;
(d) a statement of account under section 132(3)(d) of the PPSA;
(e) a statement of account under section 132(4) of the PPSA;
(f) a notice of retention of collateral under section 135 of the PPSA; and
(g) any notice from Codan under each of the provisions listed in section 144 of the PPSA.
6. The Purchaser's Obligations
6.1 Codan and The Purchaser agree that The Purchaser:
(a) is solely responsible for consideration and validation of Product designs and Product functionality, to confirm
suitability for particular applications, as desired by The Purchaser;
(b) must advise Codan of all statutory, regulatory and other official standards and/or requirements which the
Product must comply with, at the time of submitting the Order to Codan and immediately upon becoming
aware of these at any other time; and
(c) must provide Codan with any other information which Codan may request in respect of the intended
application/use of the Products.
7. Warranty
7.1 Codan agrees to provide the International Product Warranty in respect of the Products.
7.2 The International Product Warranty will not apply in the event of termination of this Agreement by Codan
pursuant to clauses 12.4, 13.4 or 15.3.
8. Exclusion and Limitations of Liability
8.1 The Purchaser acknowledges and agrees that notwithstanding clause 4.2, any delivery dates quoted by Codan for
delivery of the Products are approximate only, and will not be binding upon Codan.
8.2 Codan does not exclude or limit the application of any provision of any applicable statute, legislation or other
regulation (including the Competition and Consumer Act 2010 (Cth) and its Schedules and Regulations) where to
do so would contravene that statute, legislation or regulation or cause any part of this clause to be void and
nothing in this Agreement is to be interpreted as doing so.
8.3 Subject always to clause 8.2, to the extent permitted by law Codan excludes from this Agreement:
(a) all conditions, warranties, guarantees and terms implied by statute, general law, international convention or
custom, except any implied term, condition, guarantee or warranty the exclusion of which would contravene
any statute or cause this clause to be void (Non-excludable Condition);
(b) all liability to The Purchaser for consequential or indirect damages arising out of or in connection with this
Agreement even if Codan knew they were possible, or they were otherwise reasonably foreseeable, and
including without limitation, loss of profits and damage suffered as a result of claims by any third person,
such as a customer of The Purchaser; and
(c) all liability to The Purchaser in negligence for acts or omissions of Codan, its employees, agents and
contractors arising out of or in connection with this Agreement.
Codan Radio Communications Commercial Product Catalogue Page 191
Issue 8 January 2015
Standard Terms &
Conditions of Supply
8.4 To the extent permitted by law, Codan will not be responsible for any consequences of any modification to the
Products (whether or not authorised) or for any loss, damage or claim arising from such actions. The Purchaser
agrees to indemnify,
defend and hold harmless Codan against any and all claims, demands, suits, causes of action, damages and legal
fees (on a solicitor-own client basis) or expenses or costs whatsoever arising, directly or indirectly, from any
modification of the Products, and unconditionally frees, releases and discharges Codan and its officers, agents,
contractors and employees from any claim or cause of action arising in connection with such matters, to the
fullest extent permitted by applicable law.
8.5 To the extent permitted by law, Codan will not be liable or otherwise responsible for any loss, accident, damage or
injury arising in connection with The Products, or any failure of the Products to operate in the manner required by
The Purchaser, whether or not caused by a defect or fault in the Products or due to Codan's negligence. The
Purchaser unconditionally frees, releases and discharges Codan and its officers, agents, contractors and
employees from any claim or cause of action arising in connection with the use of the Products by The Purchaser,
to the fullest extent of the law.
8.6 To the extent permitted by law, Codan’s liability to The Purchaser for breach of any Non-excludable Condition
which is applicable (and other than one implied by sections 51, 52 or 53 of Schedule 2 of the Competition and
Consumer Act 2010 (Cth) is limited to any one of, at Codan’s option, repairing or replacing the Products in respect
of which the breach occurred, supplying equivalent products, payment of the cost of replacing the Products or
acquiring equivalent products, or payment of the cost of having the Products repaired.
8.7 Notwithstanding anything to the contrary in this Agreement, and to the extent permitted by law, Codan’s
maximum liability to The Purchaser for any cause of action or claim in connection with the Products or this
Agreement shall be limited to a total aggregate amount equal to the Order Value of the Order in connection
with which the cause of action or claim arose.
9. Intellectual Property
9.1 The Purchaser expressly acknowledges and agrees that Codan is the sole proprietor and owner of all existing and
future Intellectual Property Rights associated with the Products (including all modifications and improvements),
and that this Agreement does not grant or transfer to it any rights to the Intellectual Property Rights associated
with the Products.
9.2 The Purchaser must not copy, reverse engineer, improve, enhance, develop, refine, modify or otherwise alter any
aspect of the Products or any Intellectual Property Rights associated with the Products, or permit or assist a third
party to undertake any of these actions.
9.3 Notwithstanding anything to the contrary in this Agreement, The Purchaser acknowledges and agrees that Codan
will own all rights in any improvements, enhancements developments, modifications or refinements to the
Products or associated Intellectual Property Rights developed or created by The Purchaser, and
The Purchaser will have no claim to such materials. The Purchaser agrees that it will execute, procure and deliver
to Codan all assignments required to give effect to this clause 9.3, and hereby waives any and all rights to
any such improvements, developments, enhancements modifications or refinements.
10. Confidentiality
10.1 Each party:
(a) may use Confidential Information of the other party solely for the purposes of this Agreement;
(b) must keep confidential all Confidential Information of the other party; and
(c) may disclose Confidential Information of the other party only to (i) employees and contractors who (A) are
aware and agree that the Confidential Information of the other party must be kept confidential and (B) either
have a need to know (and only to the extent that each has a need to know), or have been specifically approved
by the other party, or (ii) as required by law or stock exchange regulation.
10.2 Each party must notify the other party immediately once it becomes aware of any breach of confidentiality and
must take all reasonable steps necessary to prevent further unauthorised use or disclosure of the Confidential
Information.
11. Taxes and Government Charges
11.1 The amounts payable by The Purchaser to Codan for, or in connection with this Agreement do not include any
amounts on account of Taxes and Duties. The Purchaser shall be solely liable for and shall pay, when due and
payable, all Taxes and Duties which may be imposed in relation to the Products, or which is assessed or
chargeable in respect of this Agreement and any associated documents or transactions.
11.2 The Purchaser agrees to indemnify Codan in respect of any liability for Taxes and Duties, and shall pay any Taxes
and Duties notified to it by Codan immediately upon request. The Purchaser must provide Codan with all
necessary tax invoices, receipts and other documentation as required by Codan in accordance with applicable
laws, legislation and regulations.
Page 192 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Standard Terms &
Conditions of Supply
11.3 In the case of GST payable in Australia, if applicable, The Purchaser must pay to Codan an additional amount on
account of GST equal to the amounts payable by The Purchaser for the Supply multiplied by the prevailing GST
rate. Notwithstanding anything to the contrary in this clause, The Purchaser is not required to pay any additional
GST amount until such time as The Purchaser has been provided with a tax invoice by Codan, which is in an
approved form for GST purposes.
11.4 The additional amounts due to Codan on account of Taxes and Duties are payable at the same time and in the
same manner as the price and any other amounts payable by The Purchaser are required to be paid to Codan
under this Agreement.
12. Government Approvals
12.1 Codan agrees, at its cost, to use its reasonable endeavours to obtain all necessary export licences, clearances and
other consents and approvals from Government Agencies which are necessary for the sale and supply/export of
the Products to The Purchaser. The Purchaser agrees to complete and provide to Codan any documentation
required by Codan to obtain any required approvals and consents.
12.2 The parties agree that Codan's obligations under this Agreement are conditional upon Codan being issued all
necessary export licences, clearances and other consents and approvals by the relevant Government Agencies.
In the event that Codan is unable to secure all necessary licences, clearances, permits, approvals and other
necessary consents from appropriate Government Agencies, Codan shall be entitled to immediately terminate
this Agreement by written notice, and Codan shall not be required to supply the Products to The Purchaser.
In no circumstances shall Codan be liable to The Purchaser or any other person for any loss or damage (including
without limitation indirect or consequential loss or loss of profits) arising in connection with Codan's failure
to obtain any necessary documentation from Government Agencies required for the sale and supply/export of
the Products to The Purchaser, or the termination of this Agreement pursuant to this clause 12.2, and The
Purchaser unconditionally frees, releases and discharges Codan and its officers, agents, contractors and
employees from any claim or cause of action arising in connection with Codan's failure to obtain any export
licence, clearances and other necessary consents and approvals from appropriate Government Agencies.
12.3 The Purchaser is solely responsible, at its sole cost and expense, for ensuring that the Products meet the
requirements of any country into which they are imported, and must obtain and maintain any necessary
import licences and permits, and all other clearances and consents from Government Agencies required for the
acquisition and use of the Products by The Purchaser (including but not limited to customs approvals and
clearances). Codan shall supply The Purchaser with any documents reasonably requested by
The Purchaser for the purposes of complying with its obligations under this clause 12.3.
12.4 Codan may at any time require that The Purchaser supply it with copies of licences, permits, clearances and
approvals issued by Government Agencies and obtained by The Purchaser as required by clause 12.3, and
The Purchaser agrees to immediately comply with any such request. If at any time Codan becomes aware
that The Purchaser has failed to comply with its obligations under clause 12.3, it may immediately terminate this
Agreement by written notice, and all outstanding amounts shall become immediately due and payable by
The Purchaser. The Purchaser agrees to indemnify, defend and hold harmless Codan against any and all claims,
demands, suits, causes of action, damages and legal fees (on a solicitor own client basis) or expenses or costs
whatsoever arising, directly or indirectly, from any failure by The Purchaser to comply with its obligations
under clauses 12.3 or 12.4.
13. Anti-Bribery and Corruption Requirements
13.1 It is a material term of this Agreement that The Purchaser must comply with the following:
(a) The Purchaser must comply fully at all times with all applicable laws and regulations, including but not
limited to applicable anti-corruption laws of the territory in which The Purchaser conducts business with
Codan.
(b) The Purchaser must not, and covenants that it will not, in connection with the performance of this
Agreement, directly or indirectly promise, authorise, ratify, offer to make or make, or take any action, in
furtherance of any Payment of Anything of Value to any individual, or to an intermediary for payment to any
individual, including a Government Official, for the purpose of influencing or inducing or as a reward for any
act, omission or decision to secure an improper advantage or to improperly assist The Purchaser or Codan in
obtaining or retaining business.
(c) The Purchaser must not, and covenants that it will not, in connection with the performance of this
Agreement, directly or indirectly promise, authorise, ratify or offer to make or make any Facilitating Payment
to any individual, or to an intermediary for payment to any individual, including a Government Official.
(d) The Purchaser must not contact, or otherwise meet with any Government Official with respect to any
transactions required under this Agreement, without the prior written approval of Codan and, when
requested by Codan, only in the presence of a Codan designated representative.
Codan Radio Communications Commercial Product Catalogue Page 193
Issue 8 January 2015
Standard Terms &
Conditions of Supply
(e) The Purchaser represents that it has not been convicted of or pleaded guilty to a criminal offence, involving
fraud or corruption; that it is not now, to the best of its knowledge, the subject of any government
investigation for such offences, and that it is not now listed by any government agency as debarred,
suspended, proposed for suspension or debarment, or otherwise ineligible for government procurement
programs.
(f) The Purchaser represents and warrants that except as disclosed in writing:
(i) it does not have any interest which directly or indirectly conflicts with its proper and ethical performance
of this Agreement; and
(ii) it will maintain arms length relations with all third parties (including Government Officials) with which it
deals for or on behalf of Codan or in the performance of this Agreement.
13.2 The Purchaser agrees that Codan may make full disclosure of information relating to a possible violation of the
terms of this clause 13 at any time and for any reason to any competent government bodies and its agencies
(including Government Agencies), and to whomsoever Codan determines in good faith has a legitimate need to
know.
13.3 Codan will be entitled to terminate this Agreement (without payment of compensation to The Purchaser)
immediately on written notice to The Purchaser, if The Purchaser fails to perform its obligations in accordance
with the terms of this clause 13. Codan will not be responsible or liable for any loss or damages whatsoever
arising from or in connection with this clause 13, whether sustained by The Purchaser or any other party.
14. Insurance
14.1 The Purchaser must take out and maintain at all times, with reputable insurers, valid and enforceable insurance
policies in respect of the following:
(a) product and public liability insurance, for an amount not less than $10 million per incident or event;
(b) all necessary statutory workers compensation insurance; and
(c) such other risks that a reasonable, prudent person carrying on the business of The Purchaser would be
likely to insure against.
15. Termination
15.1 Codan may terminate this Agreement with immediate effect by written notice to The Purchaser if:
(a) The Purchaser is the subject of an Insolvency Event; or
(b) at the time of termination, a Force Majeure Event has persisted for greater than 40 Business Days.
15.2 The Purchaser may terminate this Agreement with immediate effect by written notice to Codan if Codan
breaches any material term of this Agreement, which is capable of remedy, and fails to remedy the breach within
20 Business Days after receiving a notice requiring it to do so.
15.3 Without limiting Codan's other rights under this Agreement, Codan may terminate this Agreement with
immediate effect by written notice to The Purchaser if:
(a) The Purchaser breaches any term of this Agreement, which is capable of remedy, and fails to remedy the
breach within 20 Business Days after receiving a notice requiring it to do so;
(b) The Purchaser breaches any term of this Agreement and such breach is not capable of remedy; or
(c) The Purchaser repeatedly breaches any term of this Agreement and, within 20 Business Days after receiving a
notice requiring it to do so, fails to satisfy Codan that a breach of that term will not recur.
15.4 Termination of this Agreement will not affect any accrued rights or remedies a party may have as at the date of
termination, unless explicitly stated otherwise in this Agreement.
16. Dispute Resolution
16.1 A party will not commence arbitration or court proceedings (except proceedings seeking interlocutory relief)
in respect of a dispute arising out of this Agreement (Dispute) unless it has complied with this clause.
16.2 A party claiming that a Dispute has arisen will notify the other party of the Dispute in writing.
16.3 Each party to the Dispute will ensure that during the 30 Calendar Day period after a notice is given under clause
16.2 (or a longer period agreed between the parties) the chief executive officers (or equivalents) of the parties
will use their best reasonable endeavours to resolve the dispute in good faith.
16.4 If after fourteen (14) days the parties are unable to resolve the Dispute under clause 16.3, the parties will
attempt to settle the dispute by mediation conducted in accordance with the Commercial Mediation Guidelines
of the ACDC.
16.5 The parties shall attempt to agree on the appointment of a mediator for the purposes of mediation of the Dispute
pursuant to clause 16.4, and if the parties cannot agree on the identity of a mediator within seven (7) Calendar
Days, the mediator will be appointed by ACDC within seven (7) Calendar Days thereafter. Mediation will be held
within seven (7) Calendar Days of the appointment of the mediator.
16.6 Each party will bear its own costs of resolving a Dispute under this clause 16, and will bear equally the costs of
any mediator required to be engaged.
Page 194 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
Standard Terms &
Conditions of Supply
16.7 If mediation does not proceed within the timetable set out in clauses 16.4 and 16.5, or is not successful in
resolving the Dispute, the parties will be entitled to terminate the Dispute resolution process by giving notice in
writing to all other parties and commence arbitration or court proceedings in respect of the Dispute. Nothing in
this clause 16 prevents a party from seeking urgent interlocutory relief.
16.8 Nothing in this clause 16 prevents or limits The Purchaser from exercising its rights and requiring remedies from
Codan in respect of a breach of a Non-Excludable Condition (subject always to clause 8 above).
17. Miscellaneous
17.1 Interpretation – In these Standard Terms and Conditions of Supply:
(a) the singular includes the plural and vice versa;
(b) the word person includes a firm, a body corporate, an unincorporated association, body or organisation
established pursuant to international treaty, intergovernmental body, or government authority and other
official authority;
(c) a reference to a document or legislation includes a reference to that document or legislation as varied,
amended, novated or replaced from time to time;
(d) a reference to a person includes a reference to the person’s executors, administrators, successors, substitutes
(including, but not limited to, persons taking by novation) and permitted assigns; and
(e) headings are inserted for convenience and do not affect the interpretation of these Standard Terms and
Conditions of Supply.
17.2 Survival – The provisions of clauses 1, 2, 3, 4, 5, 7, 8, 9, 10, 11, 12, 13, 16 and 17 of these Standard Terms and
Conditions of Supply survive the expiry or termination of this Agreement.
17.3 Force Majeure – If a Force Majeure Event precludes Codan from partially or wholly complying with its obligations
under this Agreement then:
(a) as soon as reasonably practicable after that Force Majeure Event arises, Codan must notify The Purchaser
of the Force Majeure Event, and Codan’s obligation to perform in accordance with this Agreement will be
suspended for the duration of the actual delay arising directly out of the Force Majeure Event or 40 Business
Days, whichever is shorter, provided that Codan does everything reasonably possible to mitigate the
effects of the Force Majeure Event.
(b) If a Force Majeure Event persists for greater than 40 Business Days, Codan shall be entitled to terminate this
Agreement in accordance with clause 15.1(b).
17.4 Governing Law – This Agreement will be governed by and construed in accordance with the laws applicable
in South Australia. The parties submit to the exclusive jurisdiction of the courts of South Australia in respect of
matters arising out of or in connection with this Agreement (including Disputes). The parties agree that the
United Nations Convention on Contracts for the International Sale of Goods (adopted at Vienna, Austria on 10 April
1980) (including as incorporated into South Australian law by the Sale of Goods (Vienna Convention) Act 1986
(SA)) will not apply to this Agreement.
17.5 No Assignment – The Purchaser must not assign or otherwise deal with its rights and obligations under this
Agreement without the prior written approval of Codan, to be provided by Codan in its reasonable discretion.
17.6 Further Action – Each party must (a) do all acts necessary or desirable to give full effect to this Agreement,
and (b) refrain from doing anything which might prevent full effect being given to this Agreement.
17.7 Variation – A variation or modification of this Agreement must be in writing and signed by an authorised
representative of each party.
17.8 Severability – If any provision of this Agreement is held by any competent authority to be invalid or unenforceable
in whole or in part the validity of the other provisions of this Agreement and the remainder of the provision in
question will not be affected.
17.9 No Waiver – No waiver by a party of any breach of this Agreement by another party shall be considered as
a waiver of any subsequent breach of the same or any other provisions.
17.10 Entire Agreement – This Agreement constitutes the entire agreement between the parties about its subject
matter (without limiting clause 8.2 in any way) and subject to the remainder of this clause, supersedes all
previous representations, understandings and agreements in connection with that subject matter. This
Agreement overrides any terms for the sale and supply of Products tendered to Codan by The Purchaser,
irrespective of whether such terms are tendered before or subsequent to the date of the Order. However, the
parties agree that the Existing Arrangements continue in full force and effect, and that nothing in this document
supersedes, alters or otherwise affects the Existing Arrangements. In the event of an inconsistency between the
obligations of the Parties under this Agreement and any Existing Arrangements, the Existing Arrangements
prevail to the extent necessary.
17.11 Relationship – The relationship between the parties is and will remain that of independent contractors, and
nothing in this document constitutes the parties as partners or joint venturers or constitutes any party as the
agent of another party or gives rise to any other form of fiduciary relationship between the parties.
17.12 Notices – Notices by a party must be delivered by (i) prepaid post (ii) facsimile or (iii) hand, and sent to the address
of the receiving party specified in the Order. Notices shall be deemed to have been received by hand upon
delivery, by post within two (2) Business Days of sending and by facsimile upon receipt of a successful
transmission report.
Codan Radio Communications Commercial Product Catalogue Page 195
Issue 8 January 2015
International Product Warranty
provided by Codan
International Product Warranty
1. In this document:
(a) ACL means the Australian Consumer Law as set out in Schedule 2 of the Australian Competition and Consumer
Act 2010 (Cth);
(b) Codan means Codan Limited A.C.N. 007 590 605 of 81 Graves Street, Newton, South Australia, 5074, Australia
(Ph: +61 (8) 8305 0311);
(c) Codan Products means, with the exception of LMR Products, all Codan products manufactured by or on behalf
of Codan;
(d) LMR Products means all Land Mobile Radio products manufactured in Canada;
(e) Material means a material or component used by Codan in the manufacture of Warranted Products;
(f) Warranted Products means the Codan Products and the LMR Products;
(g) Warranty Period means:
i) for Codan products, a period of three (3) years from the date of shipment to the purchaser; and
(ii) for LMR Products, a period of two (2) years from the date of shipment to the purchaser; and
(h) Workmanship means the handling, assembly and manufacturing processes performed by or on behalf of
Codan in order to manufacture Codan Warranted Products.
2. Codan warrants that for the duration of the Warranty Period, all Warranted Products will be free of faults arising
from defects in design, Workmanship or Materials, on the terms and conditions set out in this document.
3. Should any fault due to bad design, Workmanship or Materials be proven in Warranted Products acquired by the
purchaser at any time within the prescribed Warranty Period, Codan will, subject to the terms of this document as
set out below, remedy such fault free of charge provided the Warranted Products are returned to Codan or to a
service centre authorised by Codan.
4. All Warranted Products returned for warranty repair must be sent to 81 Graves Street, Newton, South Australia,
5074, Australia if returned to Codan, and if returned to a service centre authorised by Codan must be sent to the
address for the service centre as listed on Codan's website. The purchaser is responsible for all freight, insurance,
taxes, duties and any costs of returning the Warranted Products to Codan or a service centre authorised by Codan
for warranty repairs. Codan is only responsible for the freight costs of returning the repaired Warranted Products to
the purchaser.
5. All Warranted Products returned for warranty repair must have a valid Return Material Authorisation (RMA)
number issued by Codan or a Codan authorised service centre prior to return by the purchaser. This RMA number
must be clearly indicated and marked on all documentation and packaging by the purchaser when returning the
Warranted Products in accordance with item 4 of this document.
6. This express warranty shall not extend to damage of Warranted Products during transit or transportation, or any
abuse, accident or improper installation, connection, adjustment, repair or use of goods otherwise than in
accordance with instructions issued by Codan. This express warranty does not apply to any Warranted Products in
respect of which the serial number has been altered, defaced or removed.
7. This express warranty is incorporated into, and forms part of, Codan's Standard Terms and Conditions of Supply.
Accordingly, it is subject to the terms of Codan's Standard Terms and Conditions of Supply, including but not limited
to clauses 8.2 - 8.7.
8. Subject to the matters set out in this express warranty, and to the full extent permitted by law, no liability (whether
expressed or implied) of any nature whatsoever, is accepted by Codan for any consequential loss, damage or injury
arising as a result of any fault in the Warranted Products.
9. This express warranty does not extend to goods supplied by Codan which are not designed or manufactured by or
on behalf of it. Some goods supplied but not manufactured by or on behalf of Codan, or Materials manufactured by
third parties which are used in Warranted Products, benefit from specific warranties provided by their
manufacturers. Codan will make reasonable endeavours to ensure that the purchaser receives the full benefit of any
warranty given by the manufacturer in respect of goods supplied but not manufactured by or on behalf of Codan,
and Materials manufactured by third parties. To the extent permitted by law, such action will be the sole remedy
available to the purchaser in respect of any faulty or defective goods or Materials not manufactured by or on behalf
of Codan.
10. This express warranty is valid for Warranted Products purchased from Codan anywhere in the world. Warranty
service will be provided in accordance with this express warranty in any country of the world where there is a service
centre authorised by Codan.
11. The benefits conferred by this express warranty are in addition to all other non-excludable rights and remedies
which the purchaser may have under the ACL and any similar laws in Australia or elsewhere.
12. To the extent permitted by law, Codan’s liability for any non-excludable term, condition, guarantee or warranty
applicable under the ACL or its equivalents is limited to (at Codan’s option):
(a) In the case of goods – repairing, replacing or supplying equivalent goods, or paying the cost of any of those
remedies to the purchaser; or
(b) In the case of services – supplying the services again or paying the cost of having the services supplied again.
Page 196 Codan Radio Communications Commercial Product Catalogue
Issue 8 January 2015
International Product Warranty
provided by Codan
13. Codan provides the following advice to all purchasers who are consumers as defined by the ACL and to whom the
ACL applies, as required by the ACL:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 197
Issue 8 January 2015
This is an Addendum to the HF Radio Communications International Product Catalogue, Issue 8, January 2015.
It outlines the details of the new 2240 SmartLink™ accessory now offered with the Envoy™ Transceiver.
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
2240 SmartLink Accessory
The Envoy SmartLink is a rugged Ethernet switch
that provides wired and wireless access points for
a connected Envoy transceiver system for both
mobile and base applications.
Up to two SmartLinks may be connected directly
to an Envoy RF Unit with no requirement for
external power supply. The SmartLink supports
connection of either Handset or Desk Console
control point devices.
SmartLinks may also be deployed into IP networks
in support of remote access Envoy transceiver
system applications.
STANDARD FEATURES:
• 2221 or 2220 Handset connection
• 2230 Desk Console connection
• Compatible with Envoy X1 and X2
transceivers
• Wireless access point (antenna optional)
• 2 x RJ-45 Ethernet ports
• Status LED indicators
• Reset function
• Linking cable connection
• External speaker connection
• External power supply connection (12 V DC)
NOTE: 2221 or 2220 Envoy Handsets must be of
Mk2 build standard when used with the
SmartLink. This is required to support output of
speaker audio at the SmartLink.
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 198
Issue 8 January 2015
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
SMARTLINK-DIRECT-SINGLE
08-07336-001
78-01263
08-07205-006
08-04515-001
15-04186-EN
SmartLink Direct Single, 6 m
This package can be used for directly connecting
a SmartLink to an Envoy RF Unit using a 6 m
interface cable. The package contains the parts
needed for adapting a standard Envoy mobile
configuration for use with the SmartLink. No
external DC supply is required for the SmartLink
in this configuration.
Typical use case scenarios include mobile Envoy
installations where WiFi or Ethernet cable access
to embedded Envoy data modems is required.
This configuration presents the added advantage
of keeping the RF Unit 15-way and 6-way
interfaces free for connection of other
accessories.
COMPRISING:
• 2240 Envoy SmartLink
• WiFi Antenna, direct connect
• Cable, Envoy SmartLink to RF Unit, 6 m
• Earth Wire, 0.5 m
•
2240 Reference Manual
SMARTLINK-DIRECT-SINGLE package parts shown in an Envoy mobile system
*Computer and computer WiFi shown only for illustration. Computer is not supplied by Codan.
*
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 199
Issue 8 January 2015
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
SMARTLINK-DIRECT-DUAL-6M
08-07336-001
78-01263
08-07337-006
08-07205-006
15-00649
08-07000-001
15-00149
08-04515-001
15-04186-EN
SmartLink Direct Dual, 6 m
This package can be used for connecting two
SmartLinks to an Envoy RF Unit using a 6 m
interface cable and 6 m linking cable. Note that
this package assumes use of 2221/2220 Handset
control points. If a 2230 Desk Console is required
at either Smartlink, the 08-07338-001 interface
cable may be required. The package contains the
parts needed for adapting a standard Envoy
mobile configuration to a dual SmartLink, dual
Control Point (Handset) configuration. No
external DC supply is required for the SmartLink
in this configuration.
Typical use case scenarios include mobile Envoy
installations where dual Envoy control points are
required. WiFi or Ethernet cable access to
embedded Envoy data modems, via the
SmartLink, is also supported, however it is
recommended that WiFi is enabled at only one
SmartLink when two SmartLinks are in close
proximity.
COMPRISING:
• 2240 Envoy SmartLink (x2)
• WiFi Antenna, direct connect
• Cable, Envoy SmartLink Linking, 6 m
• Cable, Envoy SmartLink to RF Unit, 6 m
• External Speaker, 4 m lead
• Envoy 2220 Handset
• Envoy Handset cradle kit
• Earth Wire, 0.5 m (x2)
• 2240 Reference Manual
SMARTLINK-DIRECT-DUAL-6M package parts shown in an Envoy mobile system
*Computer and computer WiFi shown only for illustration. Computer is not supplied by Codan.
*
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 200
Issue 8 January 2015
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
SMARTLINK-NETWORK-CONSOLE
SmartLink Network Console
This package can be used for connecting a
SmartLink to an Envoy RF Unit via a CAT5e
Ethernet cable (the Ethernet connection may be
via network infrastructure or a direct cable
connection). This package includes an interface
cable for connecting a 2230 Desk Console to the
SmartLink. The package contains the parts needed
for adapting a standard Envoy base (Desk Console
control point) configuration for use with the
SmartLink over a network connection.
An external DC supply is required for the
SmartLink in this configuration
Typical use case scenarios include base Envoy
installations where the distance between the
control point and RF Unit exceeds 30 m which is
the maximum distance supported by standard
Codan interface cabling. A continuous CAT5e
Ethernet cable up to 75 m long can be used to
connect the SmartLink to the Envoy RF Unit. The
connection can also be made via IP network
infrastructure such as a LAN, WAN etc.
WiFi or Ethernet cable access to embedded Envoy
data modems, via the SmartLink, is also
supported. There is an added advantage of
keeping the RF Unit 15-way and 6-way interfaces
free for connection of accessories.
...continued next page
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 201
Issue 8 January 2015
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
SMARTLINK-NETWORK-CONSOLE
08-07336-001
78-01263
08-07338-001
78-16019
67-9020#
67-90802
08-07215-001
15-04186-EN
COMPRISING:
• 2240 Envoy SmartLink
• WiFi Antenna, direct connect
• Cable, Envoy SmartLink to 2230 Console, 3 m
• SmartLink AC Mains Power Supply
• AC Mains Cable for SmartLink AC Mains PSU, 2 m
• Ethernet Cable, 2 m (x2)
• Cable, Transceiver to Ethernet Adaptor
• 2240 Reference Manual
SMARTLINK-NETWORK-CONSOLE package parts shown in an Envoy base system
*Computer and computer WiFi shown only for illustration. Computer is not supplied by Codan.
*
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 202
Issue 8 January 2015
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
SMARTLINK-NETWORK-HANDSET
SmartLink Network Handset
This package can be used for connecting a
SmartLink to an Envoy RF Unit via a CAT5e
Ethernet cable (the Ethernet connection may be
via network infrastructure or a direct cable
connection). This package assumes use of a 2221
or 2220 Handset to the SmartLink. The package
contains the parts needed for adapting a standard
Envoy base (Handset control point) configuration
for use with the SmartLink over a network
connection. An external DC supply is required for
the SmartLink in this configuration.
Typical use case scenarios include base Envoy
installations where the distance between the
control point and RF Unit exceeds 30 m which is
the maximum distance supported by standard
Codan interface cabling. A continuous CAT5e
Ethernet cable up to 75 m long can be used to
connect the SmartLink to the Envoy RF Unit. The
connection can also be made via IP network
infrastructure such as a LAN, WAN etc.
WiFi or Ethernet cable access to embedded Envoy
data modems, via the SmartLink, is also
supported. There is an added advantage of
keeping the RF Unit 15-way and 6-way interfaces
free for connection of accessories.
...continued next page
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 203
Issue 8 January 2015
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
SMARTLINK-NETWORK-HANDSET
08-07336-001
78-01263
78-16019
67-9020#
67-90802
08-07215-001
15-04186-EN
COMPRISING:
• 2240 Envoy SmartLink
• WiFi Antenna, direct connect
• SmartLink AC Mains Power Supply
• AC Mains Cable for SmartLink AC Mains PSU, 2 m
• Ethernet Cable, 2 m (x2)
• Cable, Transceiver to Ethernet Adaptor
• 2240 Reference Manual
SMARTLINK-NETWORK-HANDSET package parts shown in an Envoy base system
*Computer and computer WiFi shown only for illustration. Computer is not supplied by Codan.
*
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 204
Issue 8 January 2015
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
78-01263
WiFi Antenna, direct connect
Gimbled WiFi antenna for direct connection
to RP-SMA connector on 2240 SmartLink
unit.
78-01265
WiFi Antenna, Mag-mount with 3 m
cable
Stub WiFi antenna with 3 m extension
coaxial cable for connection to RP-SMA
connector on 2240 SmartLink. Antenna has a
magnetic base.
08-07205-001
08-07205-006
08-07205-010
08-07205-030
Interface cable for connecting 2240
SmartLink directly to Envoy RF Unit.
NOTE:
This is the same cable used for connecting
the Envoy 2230 Desk Console to the Envoy
RF Unit
Cable, Envoy SmartLink to RF Unit, 1 m
Cable, Envoy SmartLink to RF Unit, 6 m
Cable, Envoy SmartLink to RF Unit, 10 m
Cable, Envoy SmartLink to RF Unit, 30 m
08-07337-001
08-07337-006
08-07337-010
Linking cable used to link two SmartLink
units together.
Cable, Envoy SmartLink Linking, 1 m
Cable, Envoy SmartLink Linking, 6 m
Cable, Envoy SmartLink Linking, 10 m
...continued next page
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 205
Issue 8 January 2015
2240 SMARTLINK ACCESSORY
PRODUCT
PART NO.
DESCRIPTION
08-07338-001
Cable, Envoy SmartLink to 2230 Console,
3 m
Interface cable for connecting 2230 Envoy
Desk Console directly to 2240 Smartlink
control point connector
78-16019
SmartLink AC Mains Power Supply
The AC mains power supply is required for
any SmartLink that does not have a direct
connection to an Envoy RF Unit via Codan
interface cables i.e. 08-07337-0XX linking
and/or 08-07205-0XX RF Unit interface
cables
67-9020#
AC Mains Cable for SmartLink AC Mains
Power Supply, 2 m
For country type variants of AC Mains cables,
(see page 119 of the HF Radio
Communications International Product
Catalogue)
08-04515-001
Earth Wire. 0.5 m
2240 Smartlink Accessory Addendum
Codan Radio Communications Commercial Product Catalogue Page 206
Issue 8 January 2015
Cable lengths
When two Envoy SmartLinks are linked using Codan control and linking cables from the same RFU, there are
specific cable length combinations that may be used.
Figure 1: Cable lengths between Envoy SmartLinks and RFU
Table 1: Allowable lengths of Codan control and linking cables:
If cable A is... cable B may be..
1 m (08-07205-001) 1 m (08-07337-001)
6 m (08-07337-006)
10 m (08-07337-010)
6 m (08-07205-006) 1 m (08-07337-001)
6 m (08-07337-006)
10 m (08-07337-010)
10 m (08-07205-010) 1 m (08-07337-001)
6 m (08-07337-006)
30 m (08-07205-030) Not applicable
NOTE: The 30 m variant of cable A (08-07205-030) is recommended for use in single Envoy SmartLink
systems only.
NOTE: These lengths assume that only one control point is connected per Envoy SmartLink. If you connect
more than one control point per Envoy SmartLink, for example a handset to the control point connector and a
desk console via an Ethernet cable, the lengths may need to be shorter.
143
LONDON
BEIJING

Navigation menu
