§ Robust

§ Secure

§ Intelligent

§ Intuitive

§ Integrated

™

With Codan Sentry’s Digital Voice, your message is always heard loud and clear.

Base

A Codan Sentry-H base configuration

delivers reliable and powerful com-

munications over vast distances with

power outputs from 150 to 1000 W.

The ruggedised RF units versatile de-

sign makes installation into permanent

and temporary bases simple, and it

operates from wide ranging DC and AC

power sources.

We realise that every organisations’

needs are different. That’s why we

provide a choice of control options

for your Codan Sentry-H system,

including a robust hand-held and

indoor desk console.

Mobile

When space is limited, Codan Sentry’s

compact and highly integrated unit with

robust handset makes mobile installa-

tion easy. We’ve eliminated the need

for an external power amplifier, often

required in competitor systems, and

we’ve engineered the Codan Sentry

to provide 150 W of power so

that you get the best and most

reliable communications.

Benefits

Robust

After fifty years of supplying radios into the harshest regions of the world, the

Codan brand is a badge that stands for ruggedness and reliability. Our Codan

Sentry-H radio is the culmination of this experience. It has been tested to a

broad range of stringent environmental standards including MIL-STD-810G,

so it gets the job done no matter where you operate.

Secure

Codan Sentry-H ensures your information and team remains safe and secure

through use of AES-256 bit encryption applied to data transfers, digital voice

and 3G ALE. An option for internal frequency hopping is provided to prevent

third party interference and monitoring and keep your intel safe.

Intelligent

Codan Sentry’s internal SDR architecture comprises the latest-generation

high-performance Digital Signal Processor (DSP), Field Programmable Gate

Array (FPGA), and system on chip (SoC) technology devices providing

exceptional performance, and future upgradability via its IP / Ethernet / USB

connectivity. Choosing Sentry is investing in your future.

Intuitive

Codan knows that when lives are on the line, operation of the radio must be

second nature. Codan Sentry-H provides an intuitive user-experience interface

that can be switched into various languages for fast and instinctive control.

Integrated

Competing manpack-based tactical solutions require heavy components

interconnected by large, unreliable, and difficult-to-install cabling. Codan Sentry

eliminates this hassle and combines all key functions into a single compact unit.

CODAN

Now more is less.

At Codan we understand it’s tough today to afford a tactical High

Frequency (HF) radio system that has all the features you desire,

without compromising on essentials like durability and security.

That’s why we’ve created the Codan Sentry-H Software-De-

fined Radio with next generation Digital Voice, 3G ALE (future)

and Frequency Hopping. It’s the most robust and affordable

high-power radio we’ve ever built for voice and data communica-

tions, delivered in a small form-factor that’s ideal for mobile and base

configurations.

Codan Sentry’s advanced SDR architecture means you can

upgrade any time in the future to ensure sustainability in today’s

challenging conditions. What’s more with Codan’s intelligent

handset that can be configured to local languages, end-users

require less training than other competitor radios and are able to

respond faster when it counts. When you can’t afford to compro-

mise on performance or features, the Codan Sentry-H provides

unbeatable value for money.

www.codanradio.com/sentry-H

CODAN RADIO COMMUNICATIONS

Australia: +61 8 8305 0528

Canada: +1 250 382 8268

¡ US: +1 703 723 7373

¡ UUAE: +971 44 53 72 01

 

¡     HFsales@codanradio.com

12-30051-EN Issue 2

Count on Codan

Codan Radio provides communications solutions

that enable our customers to save lives, create

security and support peacekeeping worldwide. We

form strong and close bonds with our customers

to become their trusted communications provider,

so we can build the next generation of products

based on real needs.

With our legendary ruggedness and reliability, plus

global distribution and support centres all backed

by Codan’s specialist field team of deployable

engineers – we when we say, “Anytime, Anywhere”

you know we really mean it.

Specifications

 Frequency range: 250 kHz to 30 MHz

 Output power: 150 W PEP

 Digital Voice (Vocoder): MELPe and TWELP;

600–2400 bit/s

 Data Modem (high speed): STANAG 4539 /

MIL-STD-110A/B; Up to 19,200 bit/s

 Encryption: CES-128; AES-256 (voice and data;

3G ALE–future)

 GPS/GLONASS/BeiDou: Fully integrated

NMEA-0183

 Channels: 1000

 Contacts: 500

 Networks: 20

 Linking and data: MIL-STD-188-141B ALE,

STANAG 4538 (3G ALE–future)

 Frequency Hopping: Up to 25 hops per second;

programmable hop bandwidth

 Size (RF Unit): 66.5 mm (2.6″) H x 220 mm

(8.6″) W x 197 mm (7.7″) D

 Weight (RF Unit): 2.8 kg (6.2 lb)

 Multiple Languages: English, Chinese, Dari,

French, Spanish, Russian

Preliminary — Subject to change without notice
