QUOTATION
Everest Emergency Vehicles, Inc.
Bob Haselman
1133 Rankin Street Suite D-1
St. Paul, MN 55116
651-236-8944
651-690-1871
bob.haselman@everestev.com
Quote No: REV 7-3-1813
Job/Order No: 6401
07/30/2013 11:00:59 Page 1
PART NO S DESCRIPTION QTY
== Road Rescue Boilerplate - 2013.003 01/02/13 == 1
00-01-0999 Information - Scope, Purpose and Classification 1
WARRANTY 1
00-02-8100 Warranty - Documentation 1
00-02-8200 Warranty - Module Structural 1
00-02-8300 Warranty - Electrical, Standard System 1
00-02-8400 Warranty - Paint 1
00-02-8500 Warranty - Conversion 1
== Ford, F-Series, 189" WB - 168" Bodies - 2013.003 01/02/13 == 1
01- CHASSIS REQUIREMENTS 1
01-01-2401 S < > 2011 Ford F450 XLT 4X4, 108" C/A, 189"W/B, 16,500 GVWR 1
(SO.CHASS.6401)
Motorcraft alternator- 200 amp and 157 amp, 4.10 limited slip wide track rear axle, 4-wheel
ABS, Lever activated 4X4, block heater, cruise control, power windows, power door locks,
driver/passenger air bag, 40/20/40 bench seat, AM/FM with cd player, daytime running
lights, adjustable brake and accelerator pedals, manual telescoping heated/power mirrors,
OEM rubber floor, spare tire,
Requires fuel fill for DEF tank located on the street side of the module just forward of the
rear wheels and the installation of a hoseline Heat/AC system with expansion Valve. Install
a CAN Vehicle Controller Module (CVC501-A) will also be added to the chassis to allow the
rear Heat/AC to operate independent from the front. This is due to the 2012 F-450 chassis
configuration (Q-195)
***Includes the Kelderman Air Suspension W/Electric VAlve Control Package, Air Dryer,
Heated Spitter Valve and Rear Sway-Bar*****
Ref Truck Number 6355 for SR.
(ULTAMEDIC)
CHASSIS OPTIONS 1
01-03-1001
A
lternator - Standard OEM 1
01-07-0120 Front Suspension - Ford F-Series (4x4) 1
01-07-1000 Sway Bar, Front - OEM 1
01-07-6410 < > Rear Suspension - Kelderman, Ford F-Series 1
With air dryer, std with Kelderman air suspension
01-07-9025 <
A
ir Dump W/Enable SW moved to rear doors, For Air Suspension 1
Dump feature to be activated by the left rear entry door. With the enable switch in the "on"
position. Switch to be mounted on the curbside rear entry door on the lock box. When
enable switch is de-activated the air dump will not work.
Ignition switch hot, std.
Safety Triggers:
(1) Dump switch to be 'on' position
(2) Vehicle Must be in Park
(3) Emergency Brake must be set
(4) Module is to be in the 'On' position
(5) Open Street side rear entry door
07/30/2013 11:00:59 Page 2
PART NO S DESCRIPTION QTY
01-17-5100 < Block Heater Switch - Wired to Shoreline 1
The chassis shall include a 110VAC powered engine block heater. The block heater shall
be wired to the module shoreline system and will include an OEM disconnect located in
the engine compartment.
In the driver seat area, there shall be an On/Off switch with pilot light for the engine block
heater, powered from shore.
Switch shall be mounted behind the drivers seat on floor close to side wall and will have a
"Block Heater Switch" plaque.
CAB EXTERIOR OPTIONS 1
01-20-0100 Mirrors - OEM Standard 1
CAB INTERIOR OPTIONS 1
01-21-3500 Cab Insulation - Thinsulate in Cab Ceiling (STANDARD) 1
01-21-5000 < Rear View Mirror - Upgrade, Auto Dimming, Compass,Temp & Homelink 1
The vehicle shall be equipped with a Night Vision Safety mirror that includes auto dimming,
integrated compass, outside temperature gauge and three button programmable garage
door opener. The mirror will mount on the OEM windshield in place of the OEM rear view
mirror.
TIRES / WHEELS 1
01-23-4100 > Spare Tire Bracket - Delete 1
01-24-2003 SS Wheel Simulators - Phoenix Brand w/ Lug Nut covers, F-Series 1
== Type 1 - UM 168" Module, F-Series - 2013.003 01/02/13 == 1
02-01-7000 S < > Ultramedic - 174"L x 96"W Type 1, crawl/-Though Module 13-3 1
REF truck # 6355
Ultramedic I - 174"L x 96"W Type I Crawl-Through Module. Aisle width to be 46". The
interior headroom shall be 72"
NOTE: 6 inches added to the length of Box
SEE Part Number 02-02-1001 for pricing
See Part # 03-19-2300 to change the Walk through to a crawl through.
See Part # 04-04-1600: Battery tray and box will be coated with scorpion liner same color
as exterior compartments.
02-01-9500 Interior Headroom - 72" 1
02-01-9622 > Standard Aisle Width = 46" 1
02-02-1000 Materials, Type I & Type III 1
02-02-1001 X < 6" box extension, from 168" to 174" 1
SO.BODY.6401 Ref SR#2013059
Module length is extended 6" to 174".
03 - MODULE EXTERIOR 1
03-02-0200 < Module Undercoating (STANDARD) 1
The entire underbody (excluding drive shaft, wheels, fuel tank and 12 inches either side of
exhaust system) shall be sprayed with undercoating for rust prevention, corrosion
protection and added sound deadening.
EXTERIOR MODULE CONSTRUCTION 1
03-03-1400 > Module Roof Radius, 3 Inch High (STANDARD) 1
03-03-1500 > Extreme Bonding Tape (STANDARD) 1
03-03-1600 > Sub-floor Gusset Supports (STANDARD) 1
03-03-1700 > One Piece Side Body Panels (STANDARD) 1
03-03-1800 > Reinforce Rear Header (STANDARD) 1
03-03-1900 > Single Sheet Module Roof Sheet (STANDARD) 1
03-03-2010 < > Drop Curbside Forward Body Skirt - 5", Add Double Step, Light Duty Chassis 1
Drop Curbside Forward Body Skirt, Add Double Step ahead of the Curbside Wheelwell -
Drop curbside forward body skirt a total of 5 Inches lower than the rearward skirt and
Incorporate a Double Step in the Side Entry Step well. Increase the depth of stepwell
inboard as far as sub structure permits. Side surfaces to be Diamond Plate. Step surface
07/30/2013 11:00:59 Page 3
PART NO S DESCRIPTION QTY
to be a combination of NFPA Diamond Plate and removable 9" Grip Strut insert. The
second step to be fabricated of NFPA Diamond Plate and installed so that the step surface
is midway between the stepwell floor surface and the module floor (Ultramedic, Promedic
only)
03-03-2110 < > Drop Streetside Forward Body Skirt - 5", Light Duty Chassis 1
The manufacturer shall drop the lower body skirt along the street side of the module ahead
of the rear wheel well at the bottom of the module by approximately 5".
03-03-8005 Fuel Fill - Standard Pocket -Square 1
03-03-8400 DEF Fill - Standard Pocket 1
MODULE ENTRANCE 1
03-05-0100 > Module Access - Standard 1
03-06-0100 < Entry Doors - Hidden Hinge, Seal on Door ,W/Fail Safe Latching,STD 1
This includes the Fail Safe Latching mechanisms on all three entrance doors.
03-06-0700 Door Restraints - Rear, Polished Cast Aluminum, Pin & Slot Style 1
03-06-0800 < Door Restraints - Side, Heavy Duty Gas Spring Hold Opens 1
Curbside Door Restraint - Heavy Duty gas spring hold opens. - Attached by 1/4" x 20 SS
Machine Screws with 1/4" x 20 Nut Inserts into Corner Gusset in Door Side entrance door
to open to 90+ degrees. (STANDARD)
03-06-1011 Door Handles - TriMark Chrome 1
03-06-1200 Rotary Latches - (STANDARD) 1
03-06-1300 Nader Pins - (STANDARD) 1
03-06-1481 < Interior Door Handles, Relocate to Top of Door 1
The interior side and rear entrance door paddle handles and lock boxes shall be located at
the top of each of the doors.
03-06-1500 Door Panel, Inner - Stainless Steel (STANDARD) 1
03-06-2200 Magnetic Entry Door Switches (STANDARD) 1
03-06-4010 > Lock Boxes, White Diamond Grade (STANDARD) 1
03-06-4200 Coil Cords for Electrical Circuits (STANDARD) 1
03-06-4400 Door Panel Mounting Screws (STANDARD) 1
03-06-5059 < Door Flashers - (3) Whelen 500 Red LED w/ Int Flasher 1
(3) Whelen Series 500 Red LED lights with an internal flasher installed on patient entrance
doors. (2) Outboard corners of rear door interior panels and (1) outboard corner of curbside
door interior panel. Each light to flash when the respective door is opened.
03-06-6065 < Power Door Locks - Module Entry Doors 1
Install power door locks in side and rear entrance doors. Includes (2) lock/unlock
switches, one at side door and one at rear door. Also includes (1) hidden switch in rear
license frame for unlock function only. System will be tied to OEM chassis power locks so
that both systems operate as one. Does not include wireless remote.
SIDE DOOR STEP 1
03-08-3030 Stepwell Light - LED, Whelen 2", Clear 1
WINDOWS 1
03-09-0030 Module Window Requirements 1
03-09-1120 Window - Side Entry Door, 18X18, Slider - Bronze Glass 1
03-09-1220 Window - Rear Entry Doors, 18X24, Fixed - Bronze Glass 1
03-09-2020 < Window - Squad Bench 14X33.5, Fixed - Bronze Glass 1
Reflective bronze window that is approximately 14"Hx33.5"L will be installed on the
curbside wall above the squad bench.
03-09-2910 < Dry Erase Boards, Over Squad Bench. Slides to each side. 1
"Dry Erase" (2) Piece Sliding Window Covers
- Over curbside squad bench window in sliding glass track. Each side recessed behind
the corresponding side's backrest cushion when in the open position. Writing board to be
07/30/2013 11:00:59 Page 4
PART NO S DESCRIPTION QTY
polished white laminate on aluminum.
MODULE TO CHASSIS MOUNTING SYSTEM 1
03-10-5000 Module to chassis mounting system-Light Duty I (10) 1
03-11-6000 Connecting Bellows, Type I 1
REAR BUMPER AND REAR STEP CONSTRUCTION 1
03-12-1800 Rear Bumper - Recessed 9" Pocket, Flip-up 1
03-12-3020 < > Bumper Pods, CPI Cast Aluminum w/RR Logo. (UM & PM) 1
Cast Products Bumper Pods, High Polish Finish. Mounted on the outboard rear step
bumper frame members. The CPI cast aluminum pod shall include a RR Logo embossed
in the cast pattern on the step tread.
03-12-4000 < Warning Light, Interior for Rear Flip-up Bumper 1
LED Warning Light to Indicate Rear Flip-up Bumper is Up. Install flashing LED warning
light over rear doors in overhead cushion that is activated by proximity switch. Includes
"BUMPER UP" plaque by light.
03-12-4210 < Whelen OS Mini In Bumper Pocket 1
Install (2) Whelen OS Mini (white LED) marker lights to illuminate the rear bumper step.
Lights shall be located on the inside opposing faces of the bumper pocket. Lights shall
turn ON when the curbside rear entry door is open.
03-12-5600 < Tow Eyes - Rear Chrome with 6" x 6"x 6" Deep Box 1
Mounted to Steel Reinforcement Plate bolted to the OEM Chassis Frame Rails. Tow Eyes
to be Recessed In Rear Kick Panel in cast aluminum box's that are 6" x 6" x 6" deep.
(Ultramedic, Promedic Only)
INSULATION 1
03-13-2220 < > Whisper Quiet - Sound Dampening/Thermal Insulation Package (UM & PM) 1
Whisper Quiet - Sound Dampening/Thermal Insulation Package. (ULTRAMEDIC AND
PROMEDIC)
Reflective Barrier/Barymat/Spray Foam Thermal Insulation Package:
A. Reflective Barrier - Low-E Foil Wrapped Insulation System - The module walls shall
be insulated with high density 1" block foam. Wall areas that are too irregular for 1" block
foam insulation, or where the block foam will interfere with wall outlets and wire chases,
are to be insulated with 3M brand acoustical Thinsulate insulation. Then the entire interior
of the module shall be wrapped with 1/4" Low-E foil wrapped radiant barrier foam style
insulation.
B. This radiant barrier material will cover the following:
- Full ceiling and wrapping over the corner radius and down the sidewall
- Full side, front and rear walls from the top of the wall to the lowest possible point along
the side, front and rear walls
- Seams to be taped with silver / foil ducting tape to secure seams.
C. Barymat sound deadening insulation over wheel wells and interior side of exterior
compartment walls. (Installed under 3M brand acoustical Thinsulate insulation).
D. Spray foam underbody insulation prior to undercoat application, full subfloor coverage
where applicable. Includes curbside step well area.
ELECTROLYSIS PREVENTION 1
03-14-4000 < Electrolysis Prevention, Fluid Film (STANDARD) 1
Fluid Film is used at Every Point Where the Mounting Process has the Propensity to Break
Paint (STANDARD)
COMBINATION RUB RAIL AND FENDER RING 1
03-15-6020 > Crash Rail, Diamond Plate Formed ILOS Rubber 1
03-15-7040 < > Fender Rings - Polished Alum, Dropped Skirts Both Sides - Type 1 & 3 1
Mounted with long leg forward on drop skirt both sides of module ILOS rubber.
SPLASH GUARDS AND RUNNING BOARDS 1
07/30/2013 11:00:59 Page 5
PART NO S DESCRIPTION QTY
03-16-1800 < Mud Flaps - Rear, Black w/ RR Logo (Standard) 1
Heavy Duty Rubber Mud Flaps w/ RR Logo
- Heavy Duty Rubber Mud Flaps to be bolted to the wheel liner behind the rear duals with
with 1/4" x 20 Stainless Steel bolts, washer and nylon locknut for ease of maintenance and
repair
(STANDARD)
03-16-3100 Running Board Inserts - 7" Grip Strut , Type I 1
03-17-1000 < Drip Rails 1
Polished Aluminum Drip Rails - Above All Doors, Entry and Compartment (Standard)
CAB TO MODULE ACCESS 1
03-19-2100 < Cab to Module Fluid Dam, (STANDARD) 1
Cab to Module Fluid Dam - A formed fluid dam, 4" tall to be installed below the cab to
module walk through door to prevent fluids from contaminating the cab. The floor and fluid
dam to be fully sealed. (STANDARD)
03-19-2300 Cab to Module, Crawl Through Door, ILOS 1
03-19-5500 > Crawl Through Door - Type I & MD 1
LICENSE PLATE HOLDER 1
03-20-0550 < Rear License Holder Location - Center Recessed in Bumper Pocket 1
Diamond plate and sealed around all the edges with Sikaflex
EXTERIOR COMPARTMENT CONSTRUCTION 1
04-01-0100 Exterior Compartment Construction, Light Duty 1
04-01-3000 < Door Sill Protection, Stainless Steel. (STANDARD) 1
Door Sill Protection - Install Stainless Steel sill protector on lower edge of all door frames
to prevent paint damage. (STANDARD)
EXTERIOR COMPARTMENT DOORS 1
04-02-0100 Compartment Door - Hidden Hinge, Seal on Door (UM) 1
04-02-0710 < Compartment Handles, Exterior - TriMark Chrome (UM) 1
TriMark Two-Point Cast w/Polished Chrome Paddle Handle and Housing, Locking and
Non-Locking, with floating cam - Mounted in CNC Cut Opening in Each Compartment Door
Skin w/OEM Clamp Assembly.
(STANDARD ULTRAMEDIC)
04-02-0740 Compartment Handle, TriMark Chrome, Street side, locking 1
04-02-0745 Compartment Handle, TriMark Chrome, Street side, non-locking 1
04-02-0750 Compartment Handle, TriMark Chrome, Curbside, locking 1
04-02-0800 < Compartment Door Locks - TriMark 1
Compartment Door Handle Manual Locks. - All doors shall incorporate double cut,
non-directional tumbler assemblies that are keyed alike (STANDARD)
04-02-1000 Compartment Door Nader Pin - (STANDARD) 1
04-02-1200 Compartment Door Lubrication - Door Handles and Latches (STANDARD) 1
04-02-1300 Compartment Door Reflectors - (STANDARD) 1
04-02-1500 Magnetic Compartment Door Switches - (STANDARD) 1
04-02-2010 Compartment Door Panel, Inner - Diamond Plate (STANDARD) 1
04-02-2300 Compartment Door, Gas Struts - (STANDARD) 1
04-02-2500 Compartment Door Panel Mounting Screws - (STANDARD) 1
04-03-0100 Compartment Switches - Door Jambs, Standard 1
04-03-0410 Compartment Light Locations - Ultramedic 1
04-03-1600 < Door Open Indicators, (STANDARD Smart Display) 1
Door Open Indicators, LCD/VGA - Magnetic Proximity Switches located at the top of the
door between the jamb and the door frame will activate a door open indicator on the driver's
control panel. The VGA screen will include a digital layout with door open indicators for
each door, cab and module and activate the corresponding Interior compartment light.
(STANDARD)
04-03-2400 S < Compartment Lights - LED, Flexible Strip, KineQuip 1
Kinequip flexible LED lighting ILOS compartment lighting. (# 1, 2, 4, 6, and 8 Compts)
Install (2) Strips in each exterior compartment installed on inside of door flanges facing in.
(1) strip on each side of door.
(2) Full height strips in the #1 compartment. (Also wired to O2 light switch in rear switch
panel)
07/30/2013 11:00:59 Page 6
PART NO S DESCRIPTION QTY
(2) Full height strips in the #2 compartment
(2) Full height strips in the #3 compartment
(2) Full height strips in the #4 compartment.
(2) Full height strips in the #6 compartment.
(2) Full height strips in the 6.5 compartment.
(2) Full height strips in the #8 compartment.
This option deletes all standard compartment lighting.
04-03-2405 X < Kinequip Strip Lights across top of compts 1
SO.LTS.6401 Ref SR# 2013059 REF truck # 6355
Kinequip lights will be located on both sides of compts , then this code will take lights
across top of every exterior compt. including #3,#6.5 and #8.
EXTERIOR COMPARTMENT INTERIOR 1
04-04-1000 < Exterior Compartment - Interior Finish, Scorpion Rubberized 1
Exterior Compartment Interior Scorpion Rubberized Liner Color Choice.
Scorpion rubberized polyurethane coating applied to the surfaces of ALL exterior
compartment walls and dividers.
04-04-1001 Color = Dark Gray 1
04-04-1600 < > Compartment #8.5 and Battery Tray Coated with Scorpion 1
8.5 Compartment and Battery Tray Shall be Coated with Scorpion Liner
04-04-2300 < Exterior Compartment - Floor Matting "MateFlex" 1
Black matflex to be installed in all exterior comp floors and shelves.
04-04-2400 < Sweep-Out Edging - "MateFlex" 1
Includes all std compartment floors with matflex. (Black)
04-05-0001 < Exterior Compartment Shelving and Unistrut - Standard 1
All exterior shelving Unistrut shall be welded to the walls prior to any compartment wall
finish. Where specified, exterior adjustable shelves shall be box pan formed of a minimum
.125 inch Aluminum Diamond Plate and corners shall be welded. Shelves shall be
infinitely adjustable, and securely mounted to heavy gauge aluminum Unistrut track.
(Standard)
04-05-6000 > Compartment Shelving - Scorpion 9
04-05-6001 < (1) Scorpion Shelf 9
On all exterior compt shelves, including Right Stack Shelves.
(1) in Compt. 1
(1) in compt. 2
(3) in compt. 4
(2) in compt. 6
(2) in compt. 8
Note: Dark Gray same as exterior compartments.
EXTERIOR - COMPARTMENT #1 1
04-06-0010 < Electrical Storage - Compartment #1 1
#1 Compartment Electrical Storage - Recessed into the bulkhead side of compartment #1
shall be an enclosed area for the installation of miscellaneous electrical components. The
aluminum cover for this area to be installed with 'J' molding The 'J' molding to be full
length of panel on bottom and inboard side. Outboard side of panel to be secured with
mechanical fasteners. (STANDARD)
07/30/2013 11:00:59 Page 7
PART NO S DESCRIPTION QTY
04-06-0020 < Compartment #1 - Full Height, Standard Configuration (UM) 1
The forward most compartment on the street side of the module. It shall be externally
vented with stamped louvers, to prevent compression of the air inside the compartment to
allow you to shut the door.
Note: See Part 04-03-2400 and 04-03-2405 for lighting modifications.
04-06-1600 < > Shelf, Removable - (1) Full Width, Compartment #1 1
Install (1) full width removable shelf mounted in compartment #1. ILOS
Note: This shelf to be scorpion lined same color as compt.
04-06-1700 > Delete Divider, Fixed - Compartment #1 1
EXTERIOR - COMPARTMENT #2 1
04-07-0600 < Compartment #2 - Standard Configuration, (UM) 1
#2 Compartment to be directly behind the #1 compartment and below the interior action
area shelf on the street side of the module. Includes (1) adjustable shelf on Unistrut track.
Note: Drawer in face of Lower Left cabinet is recessed into the #2 compt. Also the inside
access cabinet is recessed into #2 compartment.
Note: See Part # 04-03-2400 and 04-03-2405 for lighting modifications.
(STANDARD Ultramedic)
EXTERIOR - COMPARTMENT #3 1
04-08-3300 < Compartment #3 - 8.5"H x 22"W w/Hinged Door 1
#3 Compartment with Hinged Door - Hinged #3 compartment access door over streetside
wheel well. Door is approximately 8.5"H x 22"W. Includes in/out access through the CPR
seat and "NO" slide out tray.
Note: See Part # 04-03-2400 and 04-03-2405 for lighting modifications. (Ultramedic,
Promedic Only).
EXTERIOR - COMPARTMENT #4 1
04-09-3200 S < > Compartment #4 - Full Height 1
Full Height #4 Compartment streetside rear of module with Interior Upper left #4 Cabinet
- #4 Compartment to be full height to bottom of upper left #4 cabinet. Compartment
includes (1) adjustable shelf.
Note: See option 04-03-2400 and 04-03-2405 for lighting modifications.
04-09-3700 Double Doors #4 Compartment 1
04-09-4505 < Shelf Adjustable , Compartment #4, Standard 1
Note: This shelf is to be scorpion lined same color as comp.
04-09-4520 S < > Shelf Adjustable - Additional, Compartment #4 2
(2) additional shelves for #4 compartment.
Location: Both in comp. 4.
Note: Both of these shelves are to be scorpion lined same color as comp.
Total of (3) shelves in this compt. No additional lights due to the usage of Kinequip lighting
EXTERIOR - COMPARTMENT #6 1
04-11-0600 < Compartment #6 - Standard Configuration (UM) 1
Exterior compartment #6 shall be located at the curbside rear of the module. The
compartment shall have a single door. This compartment shall be configured primarily for
the vertical storage of backboards and other miscellaneous equipment. The manufacturer
shall install a louvered vent in the upper left wall of the #6 compartment to enable the door
to close without added compression. This compartment shall be per the size and
configuration shown in the attached prints.
Compartment door to open past 90 degrees.
Note: See option 04-03-2400 and 04-03-2405 for lighting modifications.
07/30/2013 11:01:00 Page 8
PART NO S DESCRIPTION QTY
04-11-4510 < Shelf Adjustable - Compartment #6 1
Mounted to the right of the divider.
Located 41" up from floor to allow room for stairchair underneath.
Note: Shelf will be scorpion lined same color as comp.
04-11-4520 < > Shelf Adjustable - (1) Additional, Compartment #6 1
Must pick quantity if more than one is needed.
Location: Mounted forward of the divider.
Note: shelf will be scorpion lined same color as the comp.
04-11-4560 < > Divider, Fixed - Compartment #6 (UM) 1
Divider to be installed so there will be 10" clear opening to the right when comp. door is
open.
04-11-4631 < > Equipment Strap - (1), Quick Release, Plastic Buckle 1
(1) equipment restraint strap with quick release buckle
Must pick quantity if more than one is needed.
Location: Mounted from wall one to divider for back boards.
EXTERIOR - COMPARTMENT #6.5 1
04-12-3400 < > Compartment #6.5 - Base Configuration (UM & PM) 1
This comp. will have a strap for the door to keep it from opening too far.
Note: See option 04-03-2400 and 04-03-2405 for lighting modifications.
EXTERIOR - COMPARTMENT #8 1
04-14-1400 < Compartment #8 - Full Height, "A" Style Configuration 1
Exterior compartment #8 shall be the forward most compartment on the curbside of the
module allowing interior / exterior access to the interior ALS cabinet.
To be full height to the bottom of the locking drug cabinet.
Also to include two adj shelves painted with scorpion liner the same color as the other
exterior comps.
Note: See option 4.3.24 and 4.3.500 for lighting modifications.
EXTERIOR - COMPARTMENT #8.5 1
04-15-0400 < Compartment #8.5 - Drawer Style Battery Box Configuration 1
Battery access door mounted slide out battery tray.
Battery Tray to be Scorpion lined same color as other exterior comps. This does not
include the slides.
See Option 4.4.16 to spray scorpion on battery tray.
<INTERIOR TRIM AND FEATURES 1
New Interior Trim - All cabinet and wall panel aluminum trim to be Gray anodized. (No
Black trim to be used). All protective corner trim will be Opaque and will include a matching
domed end cap. (STANDARD)
INTERIOR ADJUSTABLE SHELVES 1
INTERIOR TRIM 1
05-05-1000 Interior Trim - Standard 1
HEADLINER 1
05-06-1100 < Ceiling Medical Devise Rail (STANDARD) 1
A near surface mounted Medical Device rail system shall be installed over the primary cot.
Each side of the track will have a solid surface accent stripe to match the action wall
counter. The track system to be surface mounted and run the entire length of the module
with the sole intent of providing easy access to allow the medical personnel to quickly
access equipment for administering aid to the patient.
07/30/2013 11:01:00 Page 9
PART NO S DESCRIPTION QTY
See separate options for additional IV hangers, oxygen outlet and AM/FM speakers.
The medical device rail allows for previsions for standard:
(1) IV Hanger
(3) Patient Lights focused at head, torso and legs
(2) antenna accesses under cot lights.
See separate options for additional IV hangers, oxygen outlets and AM/FM speakers.
05-06-1200 Headliner - Vinyl Ceiling, No Seams (STANDARD) 1
05-06-1802 < White LED Strip Lights, Ceiling Medical Device Rail. (UM & PM) 1
Note: These should run full length due to the stop and turn lights being removed.
05-06-2600 DELETE - Red/Amber LED Turn/Brake Strip Lights (UM & PM) 1
FLOORING 1
05-07-1000 <
A
lluminum Floor/Wall Cove Moulding. (STANDARD) 1
Seams at perpendicular floor and cabinet intersections will be finished wih an aluminum
cove moulding trim. The seams where cabinets meet floor will be sealed with a caulking
sealant / adhesive before installing the aluminum cove moulding.
05-07-1400 < Stainless Steel Rear Threshold, 45 Degree Chamfered (STANDARD) 1
The rear door threshold shall be 14 gauge stainless steel with 45 degree chamfered edge.
The threshold will be permanently installed with Sikaflex 252 sealant/adhesive. The
Sikaflex material will both secure the threshold and provide a full perimeter seal to prevent
fluid borne contamination. The threshold shall include 3M "Safety Walk" anti-skid tape to
prevent slipping. There will be no holes drilled in the stainless and no screw type
attachments required.
05-07-3000 Lonplate II Flooring Choice 1
05-07-3007 Color - 411 Putty 1
05-07-6100 Curbside Stainless Steel Threshold 1
HEAD BUMPERS 1
BACKRESTS 1
05-10-1301 S < Rear Entry Door Grab Bars - "C" Bars, 16" Anti-Microbial 1
SO.RBARS.6401 REF SR# 2013059
"C" Bars - 16" Anti-Microbial. 1.25" Diameter stainless steel "C" Bars mounted to each
rear door. Approximately 16" wide by 24" high. Clear Anti-Microbial finish.
Note: This is a new style "C" shaped bar to wrap around the window.
05-10-1401 S < Side Entry Door Grab Bars - "C" Bar - 16" Anti-Microbial 1
SO.SBAR.6401 REF SR#2013059
"C" Bar - 16" Anti-Microbial. 1.25" Diameter stainless steel "C" Bars mounted to side entry
door. Approximately 16" wide by 24" high. Clear Anti-Microbial finish.
Note: This is a new style "C" shaped bar to wrap around the window. Vertical portion of bar
will partially block window view.
05-10-1903 Ceiling Grab Rail - Center 108" Anti-Microbial 1
05-10-2101 < Ceiling Grab Rail - Streetside 72" Anti-Microbial 1
1.25" Diameter stainless steel grab rail mounted to ceiling. Streetside of center.
Clear Anti-Microbial finish.
Includes increasing the top flange of the U2 and U4 cabinets.
PLASMA HANGER 1
05-11-4000 IV Hangers - CPI #IV2008 (STANDARD) 1
05-11-4002 < Quantity (2) 1
Installed in the standard locations above the Torso area the primary cot and squad bench.
INTERIOR STREETSIDE #1 - LEFT STACK and BULKHEAD 1
05-12-1600 < Left Stack - Storage Area #1 - 45 Deg Angled 1
A two section vertical cabinet shall be provided behind the attendant seat on the streetside
forward corner on a 45 degree bevel that includes the access doors to the cabinet. The
lower cabinet door shall be aluminum with multi spec coating per previous options and the
07/30/2013 11:01:00 Page 10
PART NO S DESCRIPTION QTY
upper cabinet shall be a Lexan door with full perimeter extruded aluminum frame.
This includes one adj shelf in the upper section.
Note: Both Doors will have locking latches.
05-12-1820 < Shelf Adjustable, Addtional - Left Stack 1
Note: This is located in the Lower Left Stack
05-12-1850 < Upper Bulkhead Cabinet, 17"D with Sliding Acrylic Doors 1
For access to the electrical components, the upper bulkhead cabinet shall have a sliding
doors and restocking feature installed in addition to the electrical power distribution
cabinet.This includes one adj shelf. Cabinet back and shelf to be mounted with velcro for
easy access to the electrical components. The cabinet will be approximately 17" D.
INTERIOR STREETSIDE #2 - ACTION AREA 1
05-13-0700 < Medical Device Rail - Action Area Wall 1
An action wall Medical Device rail system shall be installed on the streetside wall. Each
side of the track will have a solid surface accent stripe to match the action wall counter.
The track system to be surface mounted and run the entire length of the action wall from
the #1 compartment to the CPR seat.
The medical device rail allows for previsions for the standard (2) Oxygen Outlets, Oxygen
Solenoid Valve, Suction Regulator, 12V Outlet and 110V Outlet.
05-13-1100 X <
A
ngled Upper Left #2 Cabinet, Full Length Switch Panel Configuration 1
Custom upper Left #2 cabinet w/Switch Panel Cabinet.
The upper left #2.5 cabinet has been deleted and replaced with a padded beveled panel,
The upper left #2 cabinet to be approximately 43" wide. Includes (1) adjustable shelf. The
lower 6" area of upper left #2 to be a separate enclosed cabinet area that is full length with
the entire length of the face of the cabinet tilted slightly down for ease of accessibility to
the attendant.
05-13-2000 < Stainless Steel Wall Panel- Entire Street Side Wall 1
The street side wall shall be finished with full height, one piece stainless steel installed
from the front of the forward action area to the rear of the rear action shelf aft of the CPR
seat. The stainless steel is to be one single piece with no exposed fasteners.
05-13-2200 < > Countertop - Forward Action Area and Rear Monitor Area. 1
There shall be a sealed, solid surface counter top on the forward action area and the
monitor/work shelf aft of the streetside CPR seat. The color and pattern design of the solid
surface counter top material shall be as follows:
05-13-2215
A
vonite Autumn Wheat, K3-7725 1
05-13-2500 < Polish Avonite Counter 1
Avonite countertop shall be polished to a high gloss finish.
05-13-2640 S < Drawer - Slide-Out Laptop with Hinged Locking Lid Below Action Counter 1
SO.SLIDE.6401 REF SR#2013059
There shall be a slide out laptop/paperwork drawer below action wall counter. The drawer
shall incorporate a lift-up Lexan lid and a locking latch on the drawer face. Non Locking
Slides w/Gas Assist strut. Strut shall be mounted on the bottom of the drawer to keep the
drawer in the open position.
Drawer shall be approximately 4 in. D x 13 in. W x 18" D.
Note: Placement of drawer, attendant seat and cot is critical to allow for proper leg room.
Note: THIS WILL RAISE THE HEIGHT OF THE A/A COUNTERTOP AND THE
TELEMETRY AREA COUNTERTOP BY 4" TO ALLOW FOR ADDITIONAL LEG ROOM
AND FOR DRAWER TO CLEAR THE COT. THIS WILL CREATE A 2" NOTCH IN THE
07/30/2013 11:01:00 Page 11
PART NO S DESCRIPTION QTY
NUMBER 2 COMPARTMENT.
05-13-2645 X < Slide out Drawer Below Action wall counter 1
SO.DRWR.6401 REF SR# 2013059 REF truck # 6355
The interior of the drawer shall be approximately
12-1/2" H X 7" W X 18" D.
Drawer shall have non-locking slides and a locking latch in the face of the drawer. Drawer
to have (2) adj, plexi dividers that will run full depth of drawer.
05-13-2647 X < Lower Left #2 cabinet, W Retaining Lip 1
SO.CAB.6401 REF SR#2013059
This is recessed into the # 2 exterior compartment, with NO DOOR, and a retaining lip on
the bottom. Approx 1" lip.
INTERIOR STREETSIDE #3 - CPR SEAT 1
05-14-0500 < Streetside - CPR Seat, Standard Configuration 1
- The CPR seat shall include a flip up seat equipped with a gas strut hold open device and
positive latch for securing the lid when closed. The CPR seat shall include a 2" foam seat
and backrest, the upper and lower sections will be padded on both sides for added
protection.
05-14-0900 < CPR Seat Lid Hold-Down 1
CPR Seat Lid Hold-down - Install a Black Tri Mark recessed paddle latch, (1) under CPR
seat lid.
05-14-1000 S < > Cabinet - Upper Left U3, 12"H x 41"W, Non-KKK Compliant 1
There shall be a upper left U3 cabinet with sliding doors, restocking feature and no shelf.
Cabinet shall be approximately 12" high, 10-3/4" deep, and shall span the full width
between the upper left U2 and U4 cabinets.
NOTE : The distance between the top of the CPR seat cushion to the bottom of the
cabinet cushion will not be in compliance with KKK-A-1822F requirements for head
clearance.
05-14-2450 Seat Belts, CPR Seat - Standard 2-Point 1
INTERIOR STREETSIDE #4 - REAR AREA 1
05-15-1000 S <
A
ngled Upper Left #4 Cabinet 1
Decrease the standard width of the cabinet 17" and add an angled section at the CPR
seat. Upper left U4 cabinet with sliding Acrylic doors, restocking feature and (1) adjustable
shelf. Cabinet shall be in the upper left street side rear of the module and will provide
interior access only.
Note: The exhaust fan has been moved to behind the U2 cabinet to allow cabinet U4 to be
as wide as possible
05-15-4505 X < Dawer,Slide out below rear countertop 1
SO.SDRWR.6401 REF SR#2013059 REF truck # 6355
The interior of the drawer will be approximately
12-1/2"H X 8-3/4"W X 18"D
Drawer shall have a non-locking slides and a locking latch on the face.
05-15-4700 S < > Countertop - 18" Aft of CPR Seat 1
Counter aft of CPR seat to be 18" wide. Requires notching the #4 compartment. The door
frame notch close out at the rear of the counter to be 18" wide.
05-15-4900 Interior Access - Sliding Acrylic Doors, to Exterior Compartment #4 1
INTERIOR CURBSIDE - SQUAD BENCH AREA 1
05-16-0100 Curbside Squad Bench - Seating Capacity (3), Two Piece Hinged Lid 1
05-16-0200 Seat Belts, Squad Bench - Standard 2-Point 1
05-16-0300 Restraint Belts, Squad Bench - Standard 1
05-16-0500 < Medical Device Rail - Squad Bench 1
A Medical Device Rail system shall be installed on the curb side wall. Each side of the
track will have a solid surface accent stripe to match the action wall counter. The track
system to be surface mounted. The medical device rail allows for previsions for the
standard Oxygen Outlet and Ceiling Light Timer.
07/30/2013 11:01:00 Page 12
PART NO S DESCRIPTION QTY
05-16-0600 Latches, Lids - Squad Bench Tri Mark , Standard 1
05-16-1323 < Storage, Resessed (2) O2 Brackets - Open, Head of Squad Bench 1
There shall be a recessed cabinet for (2) F.W. #521 portable oxygen bottle brackets at the
forward end of squad bench. The cabinet shall be located to the left of the side entry door
stepwell and below the squad bench lid. The cabinet shall be open access with no doors.
See Part# 05-17-0320 for A Bar special
And Part # 14-02-6120 for the 521 brkts.
05-16-1400 < Interior, Squad Bench - Scorpion Liner 1
The interior walls and floor of the squad bench base shall be coated with Scorpion spray
on rubberized liner material.
Same color as exterior comps. (DARK GRAY)
05-16-8200 < Cabinet - Upper Squad Bench, 12"H Non-KKK Compliant 1
There shall be a cabinet located above the squad bench. The cabinet will be
approximately 8-1/2"H x 12"D and will the same length as the squad bench. The cabinet
shall be divided into two (2) separate sections by a fixed center divider. Each section will
have sliding Acrylic doors and restocking feature. The distance between the top of the
squad bench cushion to the bottom of the cabinet cushion will not be in compliance with
KKK-A-1822F requirements for head clearance.
NOTE: Increase top flange by approx. 1" to allow for clearance of the c/s restocking doors
and the c/s grab rail.
INTERIOR CURBSIDE - BIOHAZARD 1
05-17-0320 < > Squad Bench "A" Bar 18" - Anti-Microbial, Waste Only for F.W. 521 Installation 1
stainless steel Anti-Microbial "A" style Grab Bar/Arm Rest mounted at the head of the
squad bench. This bar shall have the ability to be pivoted or removed to allow for placing a
long board patient on the squad bench. Mounted integral to the 'A' bar shall be an 8 quart
waste container. The container shall be positioned in the upper section of the "A" Bar.
05-17-2000 > Glove Butler(s) 1
05-17-2120 < Glove Butler (4) Total - Over Curbside Entry, Surface Mounted 1
There shall be (4) Glove Butler II glove boxes installed above the side module entrance
door with drop down door and locking. Door to be bottom hinged to tip out for restocking.
Access holes to be cut in door for glove removal.
INTERIOR CURBSIDE - RIGHT STACK STORAGE #8 1
05-18-0600 < Right Stack - Upper Heater-A/C Unit, Standard Configuration (UM & PM) 1
heat A/C unit located at the top of the right stack/ALS cabinet. Conditioned air shall be
distributed through six vents evenly spaced down the full length of the ceiling. There shall
be a floor to ceiling plenum with intake vents of sufficient size to allow recirculation of the
conditioned air.
05-18-0800 Right Stack - Hidden Air Intake (STANDARD) 1
05-18-1000 < Right Stack - "A" Style Standard (UM & PM) 1
Upper section to be locking drug cabinet with a single aluminum drop down door.
Lower section to have framed 3/8" Lexan doors with locking latches and (2) adjustable
shelves with access from interior or exterior.
Note: Shelves will be scorpion lined same color as exterior compts.
See Part # 04-03-2400 and 04-03-2405 for lighting modifications.
05-18-5110 U8 - Drug Cabinet, Single Aluminum Drop-Down Door, Interior 1
05-18-5310 L8 - ALS Cabinet, Dual Lexan Doors, (2) Adj Shelves, Interior / Exterior 1
05-18-5311 X < Right stack shelves, .125 alum 1
SO.2SHF.6401 REF SR#2013059 REF truck Number 6355
Right stack shelve (2) will be made from .125 aluminum.
Note: These will be scorpion lined per previous ref. code.
07/30/2013 11:01:00 Page 13
PART NO S DESCRIPTION QTY
05-18-9110 < Sweep-Out Floor Lower Right Stack ALS 1
The floor of the Right Stack ALS cabinet shall be constructed of 14 Ga. Stainless steel
and be sweep out style to the interior and exterior.
Floor will be made of 14 gage SS.
ATTENDANT SEAT 1
05-19-5800 <
A
ttendant Seat - EVS Vac Form, 3-Point Belt, Swivel Base 1
To ensure proper and safe use of the child seat feature, the swivel base must lock in
forward facing or rearward facing positions only.
NOTE: CHANGE THE DIMENSION FROM THE FRONT COT MOUNTING PLATE TO
THE FRONT OF THE SEATBASE TO 22" FROM THE STANDARD 18".
THE COT MOUNT WILL BE MOVED TOWARDS THE FRONT BY 6" TO MAKE UP FOR
THE 6" BOX EXTENSION.
05-19-5805 Color - Taupe 1
INTERIOR COLORS 1
05-20-2000 < Multi-Spec Interior Surfaces - Standard 1
LOWER BAND - The patient compartment interior surfaces will be spray painted with a
"Multi-Spec" base-coat/clear coat system anywhere a Thermo plastic laminate surface is
normally installed. This includes interior wall panels, ALS cabinet, left stack, lower left
cabinet and #1 and #6 exterior compartment surfaces. The manufacturer must use the
same metal prep and finish processes as used on the exterior of the module to finish the
interior surfaces to the following finish:
05-20-2012 Color - Buckskin #99-6003 1
05-20-5300 < Upper Band Vinyl Color - Cabinets and Stitched Cushions 1
Upper Band Vinyl Color Choice for cabinets and stitched cushions.
05-20-5310 Color - Heidi Soft Sandlewood HDI-6332 1
05-20-5500 Lower Band Vinyl Color - Vacuum Formed Cushions 1
05-20-5509 Color - Taupe 1
05-20-9000
A
crylic Glass Color Choice (STANDARD) 1
05-20-9003 Color - Smoke (Bronze) 1
MISC. INTERIOR OPTIONS 1
05-21-4000 Interior Cabinet Lights, Kinequip LED Strip 1
05-21-4040 < Upper Left Cabinets - 2, 2.5 ,3, 4, 7 and 7.5 1
Note: The 2.5 has been deleted for the angled cabinet. Please use this set of lights for the
left stack.
05-21-4041 X < Whelen,2" Led lights, Surface mnt, under upper cabinets 1
SO-LEDLTS-6401 REF. SR#2013059
Whelen #T0CACCCR with #TFLANGEC
(3) Lights on the street side will be mounted at the 2" dead space under cabinets #2 and
#4.
(2) under # 2 cabinet evenly spaced
(1) under #4 cabinet centered over telemetry countertop.
These will be operated with a switch on the streetside switch panel.
(2) Lights will be mounted (1) each under #7 and #7.5 cabinets. These will be mounted on
the cushion and switched with there own switch in the C/S switch panel.
05-21-5100 Squad Bench & Lower Left, 11 Inch Stainless Kickpanels 1
05-21-7000 < Interior Access, #6 Compartment, w/ Hinged Lexan Door 1
The patient compartment shall include a inside/outside access to the #6 compartment.
The access opening will be fully framed and will include an aluminum framed, single
hinged, 3/8" Lexan door, secured with (2) locking latches. The access will be installed at
the forward portion of the #6 compartment, and facing the aisle. The door will extend from
the highest possible/practical point of the compartment down to the level of the shelf in
comp. 6. the shelf is mounted 41" above the floor to leave room for stair chair and will be
approx 11-1/2" wide. Exterior shelf retaining lip to be aligned with door opening
07/30/2013 11:01:00 Page 14
PART NO S DESCRIPTION QTY
05-21-8900 < Cabinet Latch - Southco Lever Latch, Chrome Locking 11
All LATCHES ARE LOCKING IN THIS UNIT.
06-01-0100 General Wiring - General Harness Standard 1
COMMUNICATION 1
06-06-1011 S < > Camera - Interior (1) Addtional 1
Mounted high in the forward bulkhead area and connected to the voyager LCD monitor
pedestal in the cab headliner. Camera mounted rearward to record patient and crew
activity.
Note: Camera will have the microphone enabled for driver to hear from the module.
Both cameras will be connected to the same monitor in cab headliner.
06-06-1200 < Camera System - Exterior Back-Up, Over Rear Doors for PC System 1
Camera mounted exterior over the rear doors and connected to the Voyager LCD monitor
pedistal mounted in the cab headliner. Wire to turn camera on when vehicle is placed in
reverse.
Note: Camera to have the Microphone enabled.
06-06-1600 Two Way Radio Routing Path Cab to Module. (STANDARD) 1
06-06-1700 Two Way Radio Prewire, 12VDC Power and Ground (STANDARD) 1
06-06-3004 < >
A
ntenna UHF/VHF - (4) Bases and Cables 1
Install (4) NMO Antenna bases with pre-attached 35' cables. Road Rescue will not make or
break any radio connections.
Antenna Locations: Module ceiling
Cable Termination Locations: (3) Front Console (1) lower left stack.
06-06-6100 < Radio Power - (2) 8 Gauge 12VDC Power/Ground 1
The Black ground wire to be connected to a main ground point, the Red power wire to be
left unconnected near a direct to battery connection point inside the power distribution
cabinet. Both wires to route to the lower section of the Left Stack/Radio Cabinet and be of
sufficient length to allow routing to the Cab Console as an alternate radio installation
location. Wires to be labeled at both ends
RADIO AND CLOCKS 1
06-07-6000 < Clock - Digital DDS 12/24 Hour 2.5" LED, Over Rear Doors 1
Included with this vehicle, there shall be Digital 12/24 hour clock with 2.5" display
recessed in the cushion over the right stack. Clock is approximately 6" x 18" and displays
hours, minutes and seconds in 12 hour or military time and adjusts automatically for
daylight savings time. Operates on Internal memory battery.
06-07-7400 < Speakers - Mounted in Ceiling w/Volume Control in Action Wall 1
(2) speakers wired to the OEM AM/FM/CD stereo. The speakers shall be recessed in the
ceiling. There will be a volume control located in the action area.
07 - ELECTRICAL 12 VOLT DC 1
07-01-0010 < Crct Pwr Accs.,Ign/Shrline,1-20 amp 12VDC to 2 locs,W/O,PD9130 chrgr 1
(1) 10 amp lead shall be coiled up behind the A./A panel for future use.
(1) 10 amp lead shall be coiled up behind the drivers seat in the cab, for future use.
Note: This code will be used when and additional battery charger has already been
installed, the PD9130 will not be used with this option.
07-02-1000 Voltmeter - Standard 1
07-02-1100
A
larm,Low Voltage,With Buzzer and Indicator,in cab console 1
07-03-1000
A
mmeter - for PC System 1
BATTERY SYSTEM 1
07-05-0400 < Batteries - Type I Configuration, (2) OEM (1) Additional 1
The two OEM batteries under the hood. One additional battery shall be supplied by the
07/30/2013 11:01:00 Page 15
PART NO S DESCRIPTION QTY
manufacturer and located in the exterior compartment located below the right front ALS
cabinet.
07-07-0400 < Module Disconnect - PC System 1
The module disconnect shall utilize a dedicated switch located on the main drivers control
panel to disconnect module power loads. This shall be a safety feature only and should not
be used at any other time. This switch shall disconnect the entire module electrical
system with the exception of the 12V DC outlets, DOT lighting circuitry including backup
alarm, the door open warning display, and the chassis circuitry.
07-08-0100 Battery Ground 1
07-08-0203 (3) Straps 1
07-09-6000 Battery Charger - Prewire only, 12V. (STANDARD) 1
07-10-1000 < Power Outlets 12V, (2) Power Point Style, On with Ignition (STANDARD) 1
(1) outlet shall be mounted on the action wall and (1) outlet shall be mounted above the top
shelf in the lower section of the right front stack ALS cabinet. Outlets on this circuit shall
be wired "On with Ignition" and protected by a medical isolator.
07-10-5301 < (1) Additional 12V Outlet, Direct to Battery 1
In cab behind drivers seat next to console.
FRONT CONSOLE 1
08-01-3101 < Driver's Switch Panel/Radio Console - PC System, Custom 1
Floor mounted aluminum console for switch panel, Siren, and (4) more components. Siren
mounted in top portion. Remainder of face plate left blank for radio installer.
Console to be larger than std.
Ref. 6355 Console
08-01-4200 < Cup Holder, (2) Position Aluminum in the Cab 1
(2) position aluminum cup holder in the cab at the aft end of the driver's console. The
holders shall be made of .125 aluminum wrapped with a high quality, commercial vinyl to
match front console with a plastic laminated top designed to accommodate (2) removable
plastic cups. Laminate shall match the front console faceplate.
08-02-0500 Driver's Control Panel - Carling Rocker Switches 1
08-02-4000 < > Rear Heat A/C 'Enable' Switch, Front Console 1
There shall be a rear heat A/C 'enable' switch on the front console
08-02-5600
A
larm, "Emergency Brake Not Set" 1
08-02-8000 < Warning Lights - Cab Ceiling "Open Door", "Emergency Brake" 1
There shall be (2) flashing LED lights in cab ceiling forward of OEM dome light with
chrome accent rings. (1) Amber to flash when the emergency brake is applied and (1) Red
to flash when compartment or module entrance door is open. Included shall be a Black
plaque with White lettering that says 'OPEN DOOR' and one that say's 'EMERGENCY
BRAKE APPLIED'.
Mount forward of the OEM cab dome light, centered and parallel to the doors, close to
each other.
ATTENDANT CONTROL PANEL 1
08-03-0500 <
A
ttendant's Control Panel - Carling Rocker Switches 1
All switches are same design as the Driver's control panel. Attendant's control panel
includes red/amber/green patient status switches to actuate patient status indicators in
driver's control panel and momentary switch to actuate audible alarm in driver's control
panel. See below for all standard switch positions.
07/30/2013 11:01:00 Page 16
PART NO S DESCRIPTION QTY
Control panel meters and switch legends have electroluminescent backlighting. The switch
function legend is screen printed from the back for durability, white on black to prevent
bleed out and flush mounted in panel surface.
The standard rear switch panel shall include, at a minimum, three spare switches along
with standard switching functions as follows:
1. Dome Lights - Three-way 'On/Off' with driver's control panel.
2. Cot Lights - 'Hi-Off-Lo'
3. Bench Lights - 'Hi-Off-Lo'
4. Oxygen Compartment Light 'On/Off'
5. Electric O2 'On/Off'
6. Suction 'On/Off'
7. Blank
8. Silent Signal (Green) 'On/Off'
9. Silent Signal (Amber) 'On/Off'
10. Silent Signal (Red) 'On/Off'
11. Signal Buzzer 'Momentary On'
12. Blank
13. Exhaust Fan 'On/Off'
14. Inverter 'On/Off'
08-03-2300 <
A
dditional Rear Control Panel Curbside, PC System 1
mount a secondary rear control panel on the curbside of the module on an access panel
above the head of the squad bench. It shall include a cabinet angled towards the rear. The
secondary control panel will work in conjunction with the primary rear control panel and the
front control panel.
Layout- Dome lights, cot lights, bench lights, suction, exhaust fan and O2 switch.
08-04-3902 Power Distribution - PC Board Electrical System (UM & PM) 1
EMERGENCY SYSTEMS - Ford F-Series 1
WARNING AUDIBLE - SIREN, SPEAKERS, AIR HORNS 1
09-03-1010 < Siren Electronic - Whelen 295SLSA1 1
Whelen #295SLSA1 "Self Diagnostic", non-remote siren, with NC microphone. The siren
shall be ignition powered and will provide hands free control feature that allows switching
between three siren modes and siren off from the horn ring. Siren mode choices are user
programmable from 17 different Scan-Lock siren tones. Includes remote Siren/Horn
switch on drivers control panel.
09-03-2020 < Speakers - (2) CPI "Though-The-Bumper" for F-Series 1
Cast Products #SAD/P3806 speakers recessed in bumper.
09-03-4030 < Siren Electronic, Addtional - Whelen 'Howler' 1
Whelen 'Howler' low frequency siren speaker system installed behind the OEM bumper. A
momentary 'Aux Siren' switch and a 'Siren Brake' switch shall be installed.
09-05-0200 Backup Alarm (STANDARD) 1
09-06-0200 Emergency Sequencer/Load Manager (STANDARD) 1
WARNING VISUAL LIGHT PACKAGE - LED (Whelen Super-Series) 1
WARNING VISUAL - FRONT UPPER (ZONE A) 1
09-50-1307 Visual Warning Front Upper - (7) Seven Light Straight Line Configuration 1
AUXILLARY EMERGENCY LIGHTS 1
POWER SUPPLIES - SEQUENCERS 1
09-80-2300 < > EEV,Wrng Lt Flshr - InPower 4875P2 Flshr,Terminal Strips 1
EEV - InPower 4875P2 Flasher with alternating flash pattern..
Install a InPower 4875P2 Programmable Electronic Flasher ILOS in the dead space area.
Flasher to be set to triple flash.
07/30/2013 11:01:00 Page 17
PART NO S DESCRIPTION QTY
Includes routing 4 conductor cable to ALL light heads ILOS.
ALL WIRES TO BE LABELED LIGHTHEAD SPECIFIC AND ROUTED TO THE DEAD
SPACE.
Install (4) terminal strips in the dead space area labeled Phase 1, Phase 1P, Phase 2, and
Phase 2P.
Install (1) grounding stud near the 4875P2 flasher.
Connect all of the scan lock wires to grounding stud. All lights are to alternate and the
model #900's are to alternate flash over/under.
All forward facing White lights are to be 'On' in Primary mode only.
Program flash pattern on light heads as follows:
Model #500 Grill lights = Steady #25
Model #700 lights =Steady #14
Model #900 lights = Steady/Steady
Install a relay near the flasher for an auto PARK cutout circuit. Label this relay 'Park Cut
Out'.
NOTE: If the front fender intersection lights are ordered with split colors then the light head
will be wired with constant power and set lighthead to Comet flash alternating #3 flash
pattern and if there are white LED's they will be 'On' in Primary mode only.
09-95-1201 < Whelen 900 LED, w/Chrome Flange - RED w/ Clear Lens (Internal Flasher) 1
IATS
Rear Body - Upper Curbside Window
09-95-1201 < Whelen 900 LED, w/Chrome Flange - RED w/ Clear Lens (Internal Flasher) 1
IATS
Rear Body - Upper Streetside Window
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
IATS
Rear Body - Lower Curbside Window
Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Fl
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
IATS
Front Body - Upper Curbside Outer
Blue on top
Red on the bottom
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
IATS
Front Body - Upper Curbside Inner
Red on top
Blue on bottom
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
IATS
Front Body - Upper Streetside Inner
Red on top
Blue on bottom
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
IATS
Front Body - Upper Streetside Outer
Blue on top
Red on the bottom
07/30/2013 11:01:00 Page 18
PART NO S DESCRIPTION QTY
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Streetside Body - Upper Forward
Blue above
Red below
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Streetside Body - Upper Rear
Red above
Blue below
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Curbside Body - Upper Forward
Blue above
Red below
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Curbside Body - Upper Rear
Red above
Blue below
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Rear Body - Upper Streetside Corner
Blue above
Red below
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Rear Body - Upper Curbside Corner
Blue above
Red below
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Front Body - Upper Curbside Corner
Red on top
Blue on bottom
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Front Body - Upper Center
Blue on top
Red on the bottom
09-95-1206 < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Front Body - Upper Streetside Corner
Red on top
Blue on bottom
07/30/2013 11:01:00 Page 19
PART NO S DESCRIPTION QTY
09-95-1206 X < Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Flasher) 1
IATS
Rear Body - Lower Streetside Window
Whelen 900 LED, w/Chrome Flange - RED/BLUE Split, Clear Lens (Internal Fl
09-95-2203 < Whelen 700 LED - AMBER w/ Clear Lens (Internal Flasher) 1
ILOS
Rear Body - Upper Center
09-95-2209 < Whelen 700 LED - RED/BLUE Split, Clear Lens (Internal Flasher) 1
IATS
Rear Intersectors-RH Side
Red to front
Blue to the rear
09-95-2209 < Whelen 700 LED - RED/BLUE Split, Clear Lens (Internal Flasher) 1
IATS
Rear Intersectors LH Side
Red to front
Blue to rear
09-95-2209 < Whelen 700 LED - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Intersectors - LH Side
Blue to the front
Red to the rear
09-95-2209 < Whelen 700 LED - RED/BLUE Split, Clear Lens (Internal Flasher) 1
ILOS
Intersectors - RH Side
Blue to the front
Red to the rear
09-95-4206 S < Whelen 500 LIN6 Super LED - RED/BLUE Split 1
ILOS
Grille - LH Standard Position (FORD)
Red to outside
Blue to inside
09-95-4206 S < Whelen 500 LIN6 Super LED - RED/BLUE Split 1
ILOS
Grille - LH Standard Position (FORD)
Red to outside
Blue to inside
09-95-4208 X < Whelen, Dominator lightbar,B,R,W.W.R.B 1
SO.LBAR.6401 REF SR#2013059 REF truck Number 6355
Whelen #D6BRWWRB TIR3
Mounted on the lower bar of the front grille on special brkts.
Lights to be TRI3's configured as follows:
B/R/W/W/R/B set to comet flash 75.
This bar will have a separate switch in drivers console labeled "AUX GRILL LTS"
09-95-9230 Housings, Cast, 500 Series, Grille, Ford, F-series, Pair 1
07/30/2013 11:01:00 Page 20
PART NO S DESCRIPTION QTY
09-95-9235 Housings, Cast, 15 degree angled, 7x3, Intersection, F-series, Pair 1
EXTERIOR AUTOMOTIVE LIGHTING 1
10-01-1030 < Tail Lights, Brake/Turn - Whelen 600-Series LED (Max-Population) 1
These lights shall have chrome trim rings and be mounted vertically above the rear
diamond plate area.
Note: See drawings for locations.
10-01-1220 < Back-up Lights - Whelen 600-Series LED Rear (Max-Intensity) 1
The rear of the module shall be equipped with Whelen 600 Series LED back-up lights.
(maximum intensity)
Note: Relocated to the rear tread bright area.
10-01-2010 < Marker/Clearance Lights, Front - Whelen OS Mini LED, Amber 1
The front of the module shall have (5) amber clearance lights. The clearance lights shall
be Whelen OS Mini with chrome flanges.
Note: This includes deleting the front light bar.
10-01-2110 < Marker/Clearance Lights, Side and Rear - Whelen OS Mini LED, Red/Amber 1
The side body marker lights and rear clearance lights shall be Whelen OS Mini LED type.
There shall be (2) Amber mounted at the forward end of each side module roof extrusion,
(2) Red mounted at the rearward end of each side module roof extrusion and (5) Red
mounted in the rear module roof extrusion. In addition there shall be (2) Red marker
lights on each side in the midline of the body at the rear. (1) On each side shall function as
a marker light and (1) will function as a turn signal.
10-01-5020 < Outboard Rear Flashers, Wired to OEM Brake Lights (STANDARD) 1
The Red LED's thru the rear window flashers shall be wired to the OEM brake lights.
These lights shall NOT function as brake lights when Emergency Flashers are on.
10-01-7100 < Front Turn - Whelen 600-Series LED, Amber Arrow, w/ Flange 1
On box front upper outer corners just under outer corner lights.
10-01-9510 < Turn Signal / Brake - Interior, LED in Cusion Over Rear Doors 1
(2) Turn Signals, (2) Brake LED Indicators in Cushion Over Rear Doors.
- Install (2) Amber LED turn signal indicators and (2) Red LED brake light indicator on the
cushion over the rear doors to inform personnel in patient compartment when the vehicle is
turning and braking. These lights will have chrome bezels. Does not require any plaques.
FLOOD AND LOAD SYSTEMS 1
10-02-1010 < Scene Lighting - (4) Whelen 900 Series Super LED 1
There shall be a total of four Whelen 900 Super LED, 24 diode, gradiant 8-32 degree scene
lights with chrome trim ring mounted two streetside and two curbside.
10-02-2030 < Rear Load Lights - (2) Whelen 700 Series Super LED, 12 Diode 8-32° Scene 1
(2) Whelen Model 700 Super LED, 12 diode, gradiant 8-32 degree load lights over the rear
module entry doors.
10-02-3010 < Lighting Operation - Side Scene, Rear Load and Back-Up Lights, Standard 1
The electrical system shall be wired so that the rear module load lights and the lower
back-up lights will operate when the rear doors are open, the switch on the front panel is
activated, or when the vehicle is placed in reverse. With the module power switch "off",
both the lower back-up lights and the upper load lights will operate when the vehicle is
07/30/2013 11:01:00 Page 21
PART NO S DESCRIPTION QTY
placed in reverse. The curbside scene lights will operate when the curbside door is
opened.
10-02-4314 < Scene, Addtional - (1) Whelen Dual Panel Pioneer Flasher / Flood Light, Recessed 1
There shall be a Whelen Pioneer Flasher/Flood light recessed into the front body wall. A
separate switch shall be mounted in the front console that will change the light from the
flash mode to the flood scene mode. The light shall be wired to activate in the flash
warning mode with the warning lights and the flood mode on with ignition constant.
(1) Whelen pioneer PFA2 Dual panel LED scene light installed in recess mount on the front
wall of the module, just below cool bar in center.
The pioneer Dual panel light to flash as a white center warning light. Also add separate
switch on the front console to change light to a solid flood while in the warning mode. Also
allow the pioneer to act as a front flood light with out the emergency master on. Locate
switch with the Scene lights and mark as front flood.
10-02-7010 < Fog / Driving Lights - Prewire 1
Wires ran to the lower area behind grill. Switch located in front console.
Cab Enty - Lighting 1
10-02-8020 Cab Entry, 4" Whelen LED Courtesy Lighting 1
INTERIOR LIGHTING - CEILING 1
11-01-1400 < Dome Lights - Kinequipe 8" Round LED 1
The interior lighting system shall consist of (11) Kinequipe 8" Round LED Dome Lights
fixtures in the following configuration:
(3) Cot lights In the medical device rail over the primary cot
(2) Bench lights over the squad bench
(3) Dome lights Streetside
(1) Dome light Curbside over head of squad bench
(1) Dome light Curbside rear
(1) Dome Light over the walkway
The four outside corner lights and the (1) light over the CPR seat area and the (1) over the
walkway shall be designated module dome lights and be activated when the side or rear
module entrance doors are opened or by a three-way circuit allowing these lights to be
turned on and off from cab or module. The lights over the primary cot and squad bench
shall have switches in the module that will allow independent high/low/off control. The
lights shall produce at least 35 foot candles of light over ninety percent of the cot surface
area in the high setting.
11-01-9000 < Timer - Restocking (STANDARD) 1
A momentary switch to be wired direct to battery through a 15 minute timer to operate the
Module Dome Lights while the vehicle is Off. This feature will enable personnel to clean
and restock the vehicle, but eliminates the risk of leaving the lights on and draining the
batteries. The momentary switch to be located on the curbside wall near the side entrance
door.
SPOTLIGHTS / HANDHELD LIGHTS 1
11-02-1000 Handheld Spotlight - Sho-Me 200,000 CP (STANDARD) 1
11-02-9100 < Wiring for a Rechargeable Flashlight 12V 1
Wiring for two flash lights. Direct to Batteries.
ATTENDANT LIGHT 1
11-03-1500 <
A
ttendant Light - Kinequip LED Strip Under UL2-2.5 Cabinets, Action Wall 1
Kinequip LED strip lighting under the upper left #2 Cabinet.
Install Kinequip LED Strip Lighting on the bottom surface of the cabinets and close to the
action wall. The LED strip shall be mounted in an anodized aluminum channel and run the
full length of the Upper Left #2 cabinet. Includes an On/Off switch on the rear switch
panel.
ILOS Attendant Light.
07/30/2013 11:01:00 Page 22
PART NO S DESCRIPTION QTY
12-01-5400 < Shore Inlet - Kussmaul Super Auto-Eject, 20Amp 1
White cover
12-01-8000 < (1) Shore Indicator, "ON" Green Indicator Light 1
Green LED waterproof indicator light installed above the shore power inlet. This light is to
be wired after the GFI breaker to indicate shore power is 'ON' and breaker has not tripped.
12-02-0200 < Receptacles, Interior - 110V-15A (1) Action Wall, (1) Right Stack 1
here shall be two 110VAC 2-wire plus ground illuminated 15 amp duplex outlets, one
located on the action area wall, and one in the right front stack ALS cabinet. The outlet in
the ALS cabinet shall be located on the inboard wall of the lower section, above the top
shelf. All 110VAC outlets shall be hospital grade.
12-02-2049 Receptacles, Interior - (1) Addtional 110V-15A, Aft CPR Seat Counter 1
12-02-2050 Receptacles, Interior - (1) Addtional 110V-15A, Action Area Wall 1
12-02-2100 < > Receptacles, Interior - (1) Additional 110V-15A, Custom Location (each) 1
Mounted on floor of cab behind driver seat next to console.
POWER SUPPLY - 110VAC 1
12-03-1110 < Inverter Charger - Vanner 1050W, Indicator on Console 1
The vehicle shall be equipped with a Vanner 'UL' listed 1050 watt inverter/55 amp battery
charger #20-1050CUL with internal transfer relay. This system includes a battery charger
indicator mounted on driver side of the radio console.
ENVIROMENTAL CLIMATE CONTROL SYSTEM 1
13-01-1200 < HVAC - Central Air Flow Discharge (UM & PM) 1
he design of the Heat/AC environmental system is to provide optimal air flow and
distribution of conditioned air evenly to all areas of the module interior. Conditioned air
shall not be discharged from one vent area but shall be distributed through multiple vents
evenly spaced in a line down the length of the module ceiling. The plenum that supplies
the vents shall be built into the module roof structure and shall not be visible. In order to
support the efficient and effective performance of the system and to prevent the build-up of
condensation inside, the interior of the plenum will be completely insulated with a reflective
barrier insulation material.
13-01-2000 Climate Control - Standard (UM & PM) 1
13-02-0100 Exhaust Fan - Standard 100 CFM 1
13-02-0210 Exhaust Fan, Relocate - Behind #2.5 Cabinet 1
13-02-5602 > HVAC Aux Front Wall COOLBAR - Hoseline, Ford F-series PC ELEC 1
13-02-9000 Heater Valves, (2) Manual Shut-off Valves 1
13-03-1000 Return Air System 1
13-03-2000 Return Air Central Plenum 1
13-03-3000 Heat /AC Cabinet 1
COT MOUNTING PROVISIONS 1
14-01-1010 Cot Mounting - Hardware 1
14-01-1110 Post & Wheel Cups - None (STANDARD) 1
14-01-1210 Safety Hook - Ship Loose 1
14-01-1230 < Safety Hook - Stryker with bolts. 1
With bolts shipped loose.
14-01-1500 < Cot Mount - Stryker 6370 Single Center Position 1
Note: Move cot forward a total of 6" for the additional box length
Make sure to mount the attendant seat 22" from the front mounting plate.
OXYGEN AND AIR SYSTEMS 1
14-02-0050 Oxygen System - PC System 1
14-02-1000 O2 Cylinder Wrench - (STANDARD) 1
14-02-2000 O2 Cylinder Bracket - Zico #QR-MV (STANDARD) 1
07/30/2013 11:01:00 Page 23
PART NO S DESCRIPTION QTY
14-02-3000 O2 Control - Electric with Manual Bypass on Action Wall. (STANDARD) 1
14-02-3160 Oxygen Regulator, with 24" braided hose extension (PC System) 1
14-02-4000 < O2 Outlets - Ohio Style, (2) Action Wall, (1) Squad Bench (STANDARD) 1
Note: Only one outlet in the A/A, one was moved to the ceiling per following ref. code.
14-02-4100 O2 Outlet - Relocate (1) Action Wall Outlet to Ceiling 1
14-02-4730 < > O2 Gauge - 3000 psi, Compartment Wall, #1 1
Gauge installed on wall of #1 compartment. Mount as high as possible to allow removal of
oxygen tank.
14-02-6120 < > O2 Cylinder Holder - (2) FW-521 Universal 1
Locate at the head of the squad bench, below in boxed out stepwell.
VACUUM SYSTEM 1
14-03-1010 Suction System - SSCOR On-Board (STANDARD) 1
14-03-3010 < Ohio Vacuum Outlet, Quick Disconnect 1
An Ohio style vacuum outlet shall be installed adjacent to the SSCOR suction canister.
The outlet shall be provided with an Ohio style quick release barbed adapter for 5/16"
suction hose.
MISC MEDICAL 1
14-04-1000 Fire Extinguisher - 5# (ABC) w/ Mounting Bracket. (STANDARD) 1
14-04-2020 < IV Warmer - Minco 12VDC IV Warmer w/Switch 1
There shall be a Minco 10A/12V heat pad/IV warmer with pad cover for interior cabinet.
Includes 12V On/Off switch at action wall and thermostat preset to maintain 100 degrees
F. Wired direct to batteries.
Mounted in the lower section of the U2 cabinet.
Includes "Heat Pad" plaque on exterior of cabinet where pad is located.
PAINT AND FINISH 1
15-00-0100 Road Rescue Paint Process - Standard 1
15-01-2000 Module Paint - Single Color, OEM White 1
15-01-5000 Cab Paint - Single Color, OEM White 1
GRAPHICS AND LETTERING 1
15-03-0500 X < Two color Thunderbolt with a two inch QRS 1
SO.GRAPH.6401 REF SR# 2013059
Scotchlite design as follows:
Two color thunderbolt:
LOWER 2" STRIPE TO BE White 5000
UPPER 8" STRIPE TO BE Blue 680-75
2" QRS TO BE Blue 680-75
All stripes to wrap around the back of the module.
15-03-3900 RR Badge Logos (STANDARD) 1
15-03-4000 < RR Logos and Model Name (STANDARD) 1
As a standard part of the manufacturer's production process, logos shall be applied to the
following locations:
Ultramedic with light colored body
(3) White scotchlite RR logos: (1) on each entry door lock box
(2) Black scotchlite RR Logos:(1) on each cab fender just below "A" piller.
(2) Black Scotchcal "Ultramedic" Logo" (1) each on the #4 and #6 comp. doors.
(1) Road Rescue BAdge: Install just above rear diamond plate wrap on drivers side.
Standard
15-03-4001 Ultramedic - Black Logos 1
15-03-6201 X < Star Of Life, 32" Blue,Installed on Roof 1
SO.STAR.6401 REF SR#2013059 Ref truck # 6355
15-04-1000 Nomenclature Plaques. DIESEL. (STANDARD) 1
16 - REFERENCES AND STANDARDS 1
07/30/2013 11:01:01 Page 24
PART NO S DESCRIPTION QTY
16-01-0200 Owner's Manual (STANDARD) 1
== Dealer Provided - EMS Equipment - 2013.003 01/02/13 == 1
