HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 1

Datasheet: E02

Date: 3-03-08

INTRODUCTION

Hardware items listed are approved for Pyropanel VP and SP Series doorsets. This approval does not

apply to other door types. The list is updated regularly but includes obsolete items which are listed for

reference purposes. Refer to website www.pacificdoors.co.nz for the most up-to-date list. All items

indicated in the list as [PDS] must be factory installed or prepared for by Pacific Door Systems Ltd.

Hardware for F0.5 doorsets is listed separately.

1. MECHANICAL LATCHES

Note: For fire doors to comply with AS/NZS 1905.1 the following conditions apply to latches:

• No non-self-latching functions are permitted, including deadlock bolts

• Materials for essential latching components must have a melting point of:

- For integrity up to and including 120 min not less than 890oC

- For integrity in excess of 120 min not less than 1030oC

1.1 CYLINDRICAL OR TUBULAR LOCKS AND LATCHES

Make Code Note Max.Rating

AH 2000-100 series 1 VP120

Boyd LE series 1 VP240

Carbine EA 3000 series 1 VP240

Corbin 400, 1400 1 VP240

Corbin 6600 VP120

Corkey 800 KT VP240

Dorma CL600 VP240

Efco 1000 1 VP240

Efco 5300 1 VP240

EZSET EA3000 1 VP240

EZSET 100EA, 104EA VP240

EZSET RA series VP240

Falcon S 452 DL 1 VP240

Gainsborough 840 SS, GOV, CV 1 VP240

Gainsborough 4000 series VP240

Gainsborough 4300 VP240

Gainsborough 4500 series VP240

Gainsborough 4600 series VP240

Gainsborough 4700 series VP240

Goal UH series 1 VP240

Hafele 1200 VP240

Ilco Unican Model EA3000 VP240

Ilco Unican 6000 series VP240

Ilco Unican Model 3700 VP120

Kaba KL series VP240

Kwikset 411 B, C, G, WL VP120

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 2

Datasheet: E02

Date: 3-03-08

1.1 CYLINDRICAL OR TUBULAR LOCKS AND LATCHES CONTINUED.

Make Code Note Max.Rating

Laidlaw Thomson AD series 1 VP240

Lane 3000, 3100 series 1 VP240

Legge G2 series VP240

Lemaar Montoro, Denia 1 VP240

Lockwood 500 VP120

Lockwood 530 1 VP240

Lockwood 930-950-970-990 VP240

Lockwood 1300 series KNK VP120

Lockwood 5200 VP120

Lockwood 5300 1 VP240

Lockwood 7000, 7020, 7040, 7070 1 VP240

Lockwood 110 combination lock 1 VP240

Lockwood NX5 and NX6 1 VP240

Lockwood Nexion NF22, NF12 VP240

MCM 500 1 VP120

Nara HL 4000 Series 1 VP240

Nara HL 8300 Series 1 VP240

Posse B300 1 VP240

Posse C100 SS series VP240

Posse C300 SS series VP240

Premiapri N14PB VP240

Schlage A and AL Series 1 VP240

Schlage D Series 1 VP240

Schlage F series VP120

Schlage S Series VP240

Schlage TH885 VP240

Schlage Z series VP120

Showa SS G25 VP120

Stanley Byron 32 VP60

Stronglok LHS1082 with Vinco C-70 FDL VP180

Vinco CL7000 1 VP240

Weiser A530 VP240

Wilka 3000 VP120

Yale 5300 1,2 VP240

1.2 MORTICE LOCKS AND LATCHES

Make Code Note Max.Rating

Abloy 2595 1 VP240

Abloy 3000 series VP240

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 3

Datasheet: E02

Date: 3-03-08

1.2 MORTICE LOCKS AND LATCHES CONTINUED.

Make Code Note Max.Rating

Abloy EL580 series VP240

Abloy 4291 VP240

ABS 1100 series 1 VP120

Accord CH-382 VP120

Accord CH-382 SS VP240

Astra 430-439 1 VP240

Boyd ML VP240

Chubb 3R35X 1 VP240

CISA 52300 VP120

CISA 52760 VP240

Corbin Series 9200, 9500, models –01, -51, -54, -

55

VP120

Corbin Series 9400, 9700, 9700T

Models –10, -51, -54, -55, -57

VP240

Corbin Series 9800 models –51, -54, -55, -57 VP240

Dorma ST9600 series (excluding 9603 deadlock) VP240

Efco 3000 1 VP240

Efco 8000 series 1 VP240

Erebus E900, E901, E951, E954, E957 VP120

Falcon M and LM2000 series

Models 2100,2380,2410,2520,2560,2580

VP120

Gainsborough 1000 series 1100, 1400, 1500, 1900 10 VP240

Gainsborough 3000 series 3400, 3500, 3900 VP120

Glutz 4728, 4828, 4738, 4838 VP240

Goal AS-1 7 VP120

Goal UC-1 7 VP240

Goal UCC; GC Cup Handle VP240

Hafele 2500 VP240

Hafele 2595 with Dialock furniture VP120

Hafele 911.23.270 VP240

Hafele 911.03.181 with Dialock DTSH terminal VP240

Kaba MS mortice lock VP240

Lanetronics E335 1 VP240

Lane Astra 430-439 VP240

Legge 990 series VP240

Legge Ingersoll Rand PRO5596-990 keypad / lever

furniture with 990 mortice lock

VP60

Legge E800 – Models E800, E801, E802, E803,

E851, E852, E853, E857

VP120

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 4

Datasheet: E02

Date: 3-03-08

1.2 MORTICE LOCKS AND LATCHES CONTINUED.

Make Code Note Max.Rating

Legge E900 – Models E900, E901, E951, E954 VP120

Lockwood Electric Access Deadlatch VP240

Lockwood 570, 572, 574 VP240

Lockwood 3570 and 3570E series incl. digital furniture VP240

Lockwood 3670 series Securilock VP240

Lockwood M8600 VP240

Lockwood 8000 series VP240

Lockwood Digital Access Locks DGT530, DGT572DL,

DKO572DL, DKOLKO572DL

VP240

MIWA UXAL3H VP240

MIWA AL5HA Card Lock (with auto deadbolt)

AL5H series with deadbolt removed

VP180

Modric HD99 – Models 9960, 9962, 9970, 9990 VP120

Novas 6000 series VP120

Padde XS VP180

Pennine E900 Models E900, E901, E951, E954, E957 VP120

Pennine 800 Models 800, 801, 802, 803, 806, 851,

852, 853

VP120

Russwin 5000 series with Saflok Mark 5 or Saflok

Micro Card card key furniture

VP120

Saflok Mark 5 Card Key Lock 1, 8 VP240

Saflok Micro Card Key Lock 1, 8 VP240

Saflok ME, MS, MT series VP180

Schlage M series (except Deadbolts or devices fitted

with hold back function)

VP240

Schlage L – Models 9010, 9040, 9050, 9060, 9070,

9080, 9082

VP240

Showa 535-15 VP120

Showa LL VP120

Tesa 2035 VP120

Tesa / Onity HT24 card operated VP120

Union 2642, 2657, 2677, 26773, 2370 9 VP120

Vingcard Models 1040, 1050, 1060, 1080, 1090,

2100, 3000, 3500 Euro or ANSI lockcase

VP240

Vingcard DV80 series Presidio VP240

Weider 5750 VP240

Winkhaus 2501 series VP240

Wilka 207 VP240

Yaletronic 1100 VP180

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 5

Datasheet: E02

Date: 3-03-08

1.3 RIM AND SURFACE MOUNTED LOCKS AND LATCHES

Make Code Note Max.Rating

Efco 506, 507 VP120

Lockwood 001 double cylinder automatic deadlatch VP240

Lockwood 001/002 combination set VP120

Padde GK Escape latch 3 VP240 [PDS]

Rivers Model D, 2 and 4 point locks using sexbolts VP240

Surelock McGill Multiple Bolting system with auto latching VP240 [PDS]

1.4 ROLLER LATCHES

Make Code Note Max.Rating

Clifton Roller latch 4 VP30 DA [PDS]

Kevdon Roller latch 4 VP30 DA [PDS]

Legge (Erebus) 1511 4 VP30 DA [PDS]

Sopers SP15201 4 VP30 DA [PDS]

UDM FR Roller latch 5,6 VP240 [PDS]

Notes: 1. The latch sets indicated might have either steel or brass strike bolts, strikers, or bolt

retaining plates. Steel is rated VP240 while brass is rated VP120.

2. Plastic striker box not permitted on Yale 5300

3. With steel through-bolt fixings

4. The Clifton, Kevdon, Legge and Soper Roller latches may only be used with VP30

Double Action (DA) doorsets in timber frames (including VP30-DA Heritage).

5. The UDM Roller latch may be used with Double or Single Action frames

6. The UDM Roller latch may be the sole means of latching (Head latching or Stile

latching) in VP series hinged doorsets.

7. Timber knobs or plastic levers not permitted.

8. In conjunction with any approved mortise lock.

9. Only used in pair doorsets if no taller than 2200mm

10. The locksets must be installed with three holes through the face, one 12.7mm in

diameter and two 6.5mm diameter holes 21mm either side

2. POWER BOLTS

Make Code Max. Rating Note

Loktronic Locking Bolt (Fail Secure)

VP240

VP120

1

2

[PDS]

[PDS]

Trimec ES8000 V-lock VP240 3

Notes: 1. Device is rated VP240 as a supplementary locking device only

2. Device is rated VP120 as a sole latching device, but must be fitted with a brass

change of direction block. Only approved with fail-secure or power-to-open function.

Device must be fitted with a bevelled bolt or electrically wired to hold the bolt

retracted until the door leaf has closed

3. Power-To-Lock (PTL) with supplementary latching. Power-To-Open (PTO) can be sole

latching device.

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 6

Datasheet: E02

Date: 3-03-08

3. ELECTRIC LATCHES Type: C = Cylindrical; M = Mortise

Make Code Type Max. Rating

Accord Digital Latch Bolt Series C VP30

Corkey 800KT C VP240

Lane Lanetronics E335240 M VP240

Lockwood 3570 Series Electric with conventional or digital

furniture

M VP240

Legge 990MFE M VP240

Miwa Electron UXAL 3H M VP240 [PDS]

Russwin 5000 with Saflock Mk5 Card Key M VP120

Schlage M Series electric M VP240

Schlage Intellis TH885 C VP240 [PDS]

Schlage D Series electric C VP240

ILCO Unican 1000 Series, L1000 Series, EE1000 Series C VP120

Notes: 1. Steel latch bolts rated VP240, Brass rated VP120.

2. For installation of wire-ways in door leaf [PDS] is required.

3. Latches in fail-safe mode require auxiliary latching. UDM Roller Head latching is

recommended.

4. ELECTRIC STRIKES

Make Code Max. Rating

Adams Rite 7800 Series VP90

EFF-EFF 43 KI VP240

Gainsborough ES1000 series VP240

Harcor 50/12/C VP240

Honeywell RS 2-75959 VP120

Honeywell Alpha RS 2-75959 VP240

Lockwood EK 35 VP240

Loktronic 500 Series DKS Strike VP240

Padde ES100 series VP240

ES110 series VP240

ES200 and ES2000 series VP240

ES700 and ES7000 series VP240

Padde MT110 VP240

Rofu 1400 or 3400 Series VP120

Trimec TS100 VP240

TS110 VP240

TS200 and TS2000 VP240

TS700 and TS7000 VP240

ES 3100 VP240

Von Duprin 3041 or 3042 VP120

Von Duprin 6211 VP120

Notes: 1. “Fail Safe” electric strikes are only approved if the door closer is fitted to the opening

or hinge face of the leaf.

2. All strikes are approved only in steel jambs.

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 7

Datasheet: E02

Date: 3-03-08

5. MAGCLAMPS

Make Code Max. Rating Note

Efco GI 300 & GI 300D (VP60 without seal to

head of leaf; VP120 with seal; VP240

with seal and fusible screw fixing)

Up to

VP240

1-3

Efco GI 200 (VP60 without seal to head of

leaf; VP240 with seal to head of leaf)

Up to

VP240

1-3

Guardsman MES series VP60 1-3

HFH 10000 Series – 10000, 10002, 10010-

ECO, 10030, 10050, 10060-ECO-D

VP240 1-4

Lockwood GI 200, GI 300, GI 300D as for Efco GI

Loktronic 1710 Slimline VP240 1-4

Loktronic ZB1710 Slimline, ZB1710 VP60 1-3

Locknetics Models 268, 280, 290, 350, 390 VP240 1-4

Padde Models CCW30, EML2H, EML2HD, EML6,

EML10, EML11, EML12

VP60 1-3

Rixon Firemark 1700, FM1710 VP240 1-4

Rixon Firemark ZBFM1710 VP60 1-3

Rofu 8011-LC or 8022(pair) VP240 1-4

Securiton 62 Magnalock VP240 1-4

Trimec Z series VP240 1-3

Von Duprin 1200 series, DS4010, DS4020, DD4010 VP240 1-4

Notes: 1. Approved for both timber and steel jambs. For installation in timber jambs [PDS] is

required. In timber jambs the magclamps body may be housed into oversize stops or

located between lengths of stop.

2. Electromagnet must be connected to jamb not door leaf. “Z” bracket installation is

only rated VP60. All-steel connectors must be used.

3. Auxiliary approved mechanical latch is required with all magclamps

4. For installation on VP90-240 doors [PDS] is required.

6. SHEARLOCKS

Make

Code Max. Rating

Locknetics GF3000 series VP30 [PDS]

Von Duprin 700 Series (Obsolete model) VP30 [PDS]

Notes: 1. Device must be used in conjunction with an auxiliary mechanical latch set

2. Shearlock may only be fitted to 48mm leaf in a steel-framed doorset, and to a special

modified head in a timber framed doorset, both for 30 minutes fire resistance.

7. HOLD OPEN DEVICES

Make Code Max. Rating

Dorma A50, A70, AW50, AT50, AT70 armatures

associated with EM-50 and EM-70 series

electromagnetic hold open devices.

VP240

Dorma MAG, MAW, MAT armatures for Dorma EM series VP60-DA

LCN SEM7830 VP240

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 8

Datasheet: E02

Date: 3-03-08

8. HINGES

Type Make Model Material Max. Rating

Butt Ajax 100 x 100mm VP240 [PDS]

Classic 100 x 100 Ball Bearing Stainless Steel VP240 [PDS]

Dalco 321 100 x 100mm Stainless Steel VP240 [PDS]

Efco EF10025SSFPBB VP240 [PDS]

Efco SS Ball bearing Stainless Steel VP240 [PDS]

Glutz SS Ball bearing Stainless Steel VP240 [PDS]

Hafele 926.84, 926.89 VP240 [PDS]

HK SS90044B30 Stainless Steel VP240 [PDS]

Kingsway 100 x 100 2.5mm Stainless Steel VP240 [PDS]

Laidlaw Thompson 100 x 100 3mm Stainless Steel VP240 [PDS]

Lane 100 x 100 2.5mm Steel VP240 [PDS]

Lockwood HS 100x100 VP240 [PDS]

Lockwood SUS304 100x100 VP240 [PDS]

McKinney TB 100 x 100 Steel or S/S VP240 [PDS]

Nara D10 100x100 3mm S/S VP240 [PDS]

Nara All metal spring hinge 100x100 VP240 [PDS]

Nikon 100 x 100 Stainless Steel VP240 [PDS]

Pyropanel Surface mount 100x70 2.4mm Stainless Steel VP120 [PDS]

Schlage 413, 100 x 100 2.5mm Stainless Steel VP240 [PDS]

Schlage 417, 100 x 100 3mm Stainless Steel VP240 [PDS]

SCL SUS-304, 102x102mm Stainless Steel VP240 [PDS]

Stanley PB780, SW781, BB783 Stainless Steel VP240 [PDS]

Trio 100 x 100 Mild or Stainless Steel VP240 [PDS]

Yank 100 x 100 3mm Brass (Note 4) [PDS]

Broad Butt 100h x 125w S/S 3mm thick VP60 [PDS]

Rising Butt Schlage 411, 100 x 75 (Note 3) VP240 [PDS]

Surelock S2 / HA2 / 130 x 75 VP240 [PDS]

Butterfly Nara D10 / 100 x100 Stainless Steel VP240 [PDS]

Lift-off UDM 127 x 100 Stainless Steel VP240 [PDS]

Strap Tuff TUI Ball bearing steel/ 250mm VP240 [PDS]

Continuous Steel or Stainless steel continuous hinge at least 1.6mm thick,

leaf width not less than a 100 x100 butt hinge, fixed with screws

in a staggered pattern at not less than 200mm centres.

VP120 [PDS]

Restrictions 1. Brass hinges or screws are generally not approved. Brass plated steel is approved

2. May only be used as a centre hinge or as an additional hinge of 3 or 4 and must

be used in conjunction with Nara D10 hinges to accommodate lift.

3. Brass hinge is limited to FRR60 minutes in steel frames for leaf sizes up to 1.95m2

and FRR 30 minutes in timber frames.

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 9

Datasheet: E02

Date: 3-03-08

9. OTHER ELECTRONIC ACCESSORIES

Device Make Notes

Max. Rating

Microswitch Keep Abloy VP30

Reed Switch Chubb 3 VP240

GRI-Telemark 3 VP240

Sentrol 1076, 1077, 1078,

1076C, 1077C, 1078C

3 VP240

Tane Alarm SD-70, SD-80 3 VP240

Power Transfer Abloy 8810 and 8811 Lead Cover 2 VP240 [PDS]

Abloy EA280 & EA281 Lead Cover 2 VP240 [PDS]

Lane Flexitran 1 VP240 [PDS]

Lockwood PWRLEAD VP240 [PDS]

Lockwood power transfer hinge VP240 [PDS]

Loktronic VP240 [PDS]

McKinney TA or TB Series VP240 [PDS]

Schlage PT1 1 VP240 [PDS]

Von Duprin EPT 218 & EPT 1024 3 VP240 [PDS]

Notes: 1. Only rated VP30 in timber frame

2. Where timber frames are used a layer of Intumex L is to be glued to the

inside base of the lead cover channel

3. May only be used in a steel frame

10. SELF LATCHING PAIR HARDWARE FOR INACTIVE LEAF

Make Type Note Max. Rating

Dalco DC1851 chain bolt VP240 [PDS]

Lockwood 530 or 930 or 950 Deadlatch 2 VP120 [PDS]

Glutz GDS-0148-A-SS VP240

Glynn Johnson FB41T or FB41B Autolatch 3 VP30/VP60 [PDS]

Schlage D Model 14-043 VP120 [PDS]

UDM FR Roller Latch VP240 [PDS]

UDM Autobolt VP240 [PDS]

UDM Chain latch VP240 [PDS]

Weider Model 180 VP240 [PDS]

Winkhaus Flushbolt VP240

Yank Flushbolt VP120 [PDS]

Restrictions: 1. All are approved for timber and steel jambs.

2. These deadlatches are installed in the door head with an appropriate snib (The

Lockwood 8530-57SC is recommended). Backset length should be 70mm

minimum. The deadlatches are rated VP60 for door leaves taller than 2400mm.

3. VP60 in steel jambs only.

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 10

Datasheet: E02

Date: 3-03-08

11. SEQUENCE SELECTOR FOR PAIRS

Make Code Max. Rating

Briton Closerite VP240

DCI 600 VP240

Dorma SR390 VP240

Dorma SR391, SR392, SR393 VP60

Dorma TS93 GSR system VP120

Efco 3000 & 4000 VP240

Gainsborough 3350SS VP240

Glynn Johnson COR VP240

Hafele 931.71.900 VP240

Lane 5230, 5180, 5305, 2359, 2369 VP240

Lockwood / Efco 3000 & 4000 VP240

Newstar SF-250F VP240

Ryobi RB-34 VP240

Tiki S1991 VP240

Weider DS-2800, DS-3600 VP240

Note: Sequence Selectors are required on pair doorsets with non-self-latching functions such as

rebated meeting stiles or central locking.

12. SECURITY ACCESSORIES

Make Type Code Notes Max.Rating

Chubb Hinge Bolt WS12 VP60 [PDS]

Chubb Hinge Bolt WS7 2 VP240

Duo Hinge Bolt HBC, HBW VP240

Securicraft Securichain MC41 3 VP120 [PDS]

Notes: 1. Up to 2 hinge bolts may be used, set into the leaf near the top and/or bottom hinges

2. Steel jambs only

3. Rated VP60 in Drywall and VP120 in concrete/masonry installation

13. SURFACE MOUNTED CLOSERS

Note:

• Fixture of surface-mounted closers to Pyropanel mineral fibre board cored fire doors requires self-

tapping screws, which must penetrate at least 32mm into the leaf.

• Cushioned backcheck function is required on all closers for compliance with AS/NZS 1905.1. All

listed closers comply with this requirement.

• Hold open devices are required on certain fire doors for compliance with NZ Building Code C/AS1

3.17.9. Requirements for fire detection to release hold-open devices are given in C/AS1 3.17.10.

• For fire doors on escape routes, NZBC C/AS1 requires closers to be adjustable to satisfy the

requirements for maximum forces required to open the door, set out in C/AS1 Appendix C 8.1.2.

Make Code Maximum Rating

Abloy Modul 230 series VP240

Abloy DC240 VP240

Accord 90 VP240

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 11

Datasheet: E02

Date: 3-03-08

13. SURFACE MOUNTED CLOSERS CONTINUED

Make Code Maximum Rating

Arrow 7x7 Series Surface mounted VP90 plastic cover,

VP240 metal cover

Boyd/Axim 1500BC VP120

Boyd/Axim 1024 Series VP90

Boyd/Axim 7000/1000BC VP120

Boyd Sentronic 4010/4110 VP90 plastic cover,

VP120 metal cover

Briton 81 series VP120

Briton 121.5 series VP120

Briton 220 VP240

Briton 1000 series VP120

Briton 2000 series VP120

Briton 2508S VP120

Briton 5000 VP120

Corbin 500 series VP120

Delta 70BC Series VP120

Doric DK53 VP120

Dorma TS68 VP240

Dorma TS73F Series VP240

Dorma TS71 VP240

Dorma TS72 without hold open VP240

Dorma TS73 EMF VP120

Dorma TS73 EMR VP120

Dorma TS73 V-F VP240

Dorma TS77 Series VP240

Dorma TS83 Series VP120

Dorma TS90 VP240

Dorma TS92 without hold open VP120

Dorma TS93 series incl. EMF or EMR VP120

Dorma TS97 VP120

Dor-o-matic SC60, SC80 VP240

Efco 4080 Series VP120

Efco 1300 Series VP240

Gainsborough 3000 series VP240

Gainsborough 3200 series VP120

Gainsborough 3050/3060 VP120

Gainsborough 3100 VP240

Geze (Hafele) TS2000V BC series VP240

Geze (Hafele) TS4000, TS4000DA series VP120

Geze (Hafele) TS5000, TS5000L, TS5500 series VP120

Global 70BC series VP120

Glutz PDC-500, PDC-730, PDC-770, PDC-830 VP240

Hafele DCL51, DCL55, DCL110 VP90

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 12

Datasheet: E02

Date: 3-03-08

13. SURFACE MOUNTED CLOSERS CONTINUED

Make Code Maximum Rating

HFH 60 BC series VP120

Justor CH series VP240

Kaba 702 SIL VP120

King D70 BC, D70 P BC series VP240

King 600 BC, 600 P BC series VP120

King 900 BC series VP120

Lane 70 BC series VP120

Lane SL 65 BC VP120

LCN 524, 523T VP 240

LCN 4310 ME series VP90

LCN

1070 series

1460 series

4010, 4110, 4040 series

Sentronic 4010/411 SE

All VP90 with

plastic cover,

VP120 with metal

cover

Leado 980 series VP240

Lockwood C999 EM hold open to any Lockwood

closer

VP240

Lockwood 3024 series VP240

Lockwood 414 / 426 series VP120

Lockwood 409 series VP120

Lockwood 713 series VP240

Lockwood 714 / 726 series VP240

Lockwood 724 series VP240

Lockwood 1300 series VP240

Lockwood LW 1730 series VP240

Lockwood LW 1830 series VP240

Lockwood LW 2000 series VP240

Lockwood LW 2500 series VP240

Lockwood 7714 / 7724 series VP240

Lockwood 7726 series VP240

Lockwood Miwa M200 VP120

Lockwood Miwa M800 VP240

Lockwood 8002 Door Operator VP60

MAB 400 series VP120

MBC 525 BC series VP240

MBC 527 BC series VP120

Newman Tonks NT 121 BC VP240

Newstar 80 VP120

Nikon 90 VP240

NHN 1080 series VP120

Novas 1000 BC VP240

Novas (Guardsman) 1300 BC VP240

Novas (Guardsman) 1500 BC VP120

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 13

Datasheet: E02

Date: 3-03-08

13. SURFACE MOUNTED CLOSERS CONTINUED

Make Code Maximum Rating

Novas (Guardsman) 3000 BC VP240

Pyropanel TS77 Series VP240

Ryobi 7000 Series VP120

Ryobi 70 Series VP120

Ryobi 90 Series VP120

Ryobi 1500 BC Series VP120

Ryobi 1550 BC Series VP90 plastic cover

Ryobi D-2550 DA series VP240

Ryobi D-3550 series VP240

Sabre BC730 series: models 732, 733, 734 VP240

Sabre Models 735, 736 VP120

Sabre 836 AS VP240

Sabre 2100 B series VP240

Spartan 1002-BC VP240

Tiki 80 series, 90 VP120

Vinco DC67 VP120

Vinco DC934 VP240

Weider 1000 series VP240

Weider 1500 BC series VP120

Yale 2000 series VP90 plastic cover

VP240 metal cover

Yale 3501 series VP120

Yank BC1002AS VP240

14. CONCEALED CLOSERS

Make Type Notes Max. Rating

Arrow 7x7 Series VP120 [PDS]

Briton 531 VP60 [PDS]

Corbin 500 VP120 [PDS]

Dorma ITS-86 1 VP180 [PDS]

Dorma ITS-96 without hold open 1 VP180 [PDS]

LCN 3030 Series VP240 [PDS]

LCN 330 3 VP240 [PDS]

Lockwood 409/091 1 VP240 [PDS]

Newstar CL60 VP240 [PDS]

Tiki 60 VP240 [PDS]

Notes: 1. Installation approved in steel jambs only (where noted)

2. Only surface mounted arm brackets may be used with timber jambs (except see Note

3). Either surface mounted or mortised arm brackets may be used with steel jambs.

3. Mortised arm may be installed in timber jamb in Heritage VP30 Series doors.

4. Leaf glazing directly below concealed closers is not permitted except in VP30 Series

Heritage fire doors

5. Concealed closers are not recommended in exterior doors.

6. Rating VP120 applies where door height exceeds 2400mm.

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 14

Datasheet: E02

Date: 3-03-08

15. PANIC EXIT DEVICES

Type Make Code Note Max. Rating

Rod/Latch Adams Rite 3100 VP240 [PDS]

Briton 373, 374, 377, 378, 379 4 VP240 [PDS]

Dorma

PHA 2102/2203 (3 point

latching only)

VP120 [PDS]

Glutz 8600 VP240 [PDS]

JPM 9300, 9400 VP240 [PDS]

Lionheart E9801, E9802 4 VP240 [PDS]

Lockwood 520V 5 VP240 [PDS]

Lockwood 5510 and 5530 series VP240 [PDS]

Rod/Latch Lockwood 9000 VP240 [PDS]

Massoud (MBC) 571 series VP60 [PDS]

Trident 1089 4 VP240 [PDS]

Weider 3730, 3731 Series 4 VP240 [PDS]

Von Duprin

2227F, 8827F, 9827F,

9927F

3 VP240/VP60 [PDS]

Rim Latch Adams Rite 3700 VP240 [PDS]

Boyd ED22F VP60 [PDS]

JPM 9000, 9100 VP240 [PDS]

Lockwood 520 VP240 [PDS]

Lockwood 9000 VP240 [PDS]

Massoud (MBC) 570 Series VP60 [PDS]

Von Duprin 22F, 88F, 98F, 99F 3 VP240/VP60 [PDS]

Mortice Latch Adams Rite 3300 VP240 [PDS]

Lockwood 9000 VP240 [PDS]

Von Duprin 8875F, 9875F, 9975F 3 VP240/VP60 [PDS]

Weider 8909 VP240 [PDS]

Restrictions: 1. VP Series fire doors – All devices are surface-fixed and must be mounted using

at least nominal 5mm steel hex bolts passing through the leaf.

2. All devices in VP Series fire doors may be fitted to doorsets with timber or steel

jambs (except see Note 5)

3. Models without the F suffix have brass components and are therefore only rated

60 minutes.

4. Device may only be used in conjunction with a fire rated mortice or tubular latch

or lockset. Fire resistance is then dependent on the fire resistance of the latch or

lockset.

5. Steel frame only. Length adjustment mechanism for the vertical actuating rods

must be fitted with a nylon screw.

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 15

Datasheet: E02

Date: 3-03-08

16. DOUBLE-ACTION HARDWARE

Device Make Notes Max.Rating

Roller latch Kevdon

Clifton

Soper SP15201

Legge (Erebus) 1511

3

3

3

3

VP30

VP30

VP30

VP30

[PDS]

[PDS]

[PDS]

[PDS]

FR Roller latch UDM VP120 [PDS]

Locking Abloy EL414 Electric Lock 8 VP60 [PDS]

Abloy EL415 Electric Lock 7 VP60 [PDS]

Loktronic Power Bolt 1 VP120 [PDS]

Trimec ES8000 V-lock 9 VP120 [PDS]

Head Spring Dorma RTS85 VP120 [PDS]

Lockwood Efco OTC series VP120 [PDS]

Lockwood 9800 series VP120 [PDS]

Ryobi 30 series 5 VP120 [PDS]

Floor Spring Dorma BTS80F VP120 [PDS]

Dorma BTS75 3 VP30 [PDS]

Dorma EMB VP120 [PDS]

Lockwood Efco EF840 (FS 840) VP120 [PDS]

Lockwood 7310/7410 VP120 [PDS]

Lockwood 7750 series VP120 [PDS]

MAB 7312, 7412 4 VP120 [PDS]

Panic Exit Lock Surelock McGill Multiple Bolt B1 6 VP120 [PDS]

Notes: 1. The Loktronic Power Bolt should be integrated with a fire detection system so that

the bolt disengages on an alarm or power failure (fail safe or power-to-lock mode). In

this mode the lock requires an auxiliary UDM roller latch.

2. A roller latch is required with double action doorsets. The UDM roller latch is standard

3. These items are approved only for VP30-DA in timber jambs with special requirements

4. VP120 with steel arms, VP60 with brass arms

5. Ryobi 30 series is limited to models without hold-open and with cushioned backcheck

function.

6. Fitted with solid lower latch bar and hollow upper latch bar. Requires fitting of roller

restraint auto-bolting mechanism and associated head ramp.

7. Abloy EL415 (fail unlocked) installed in the frame head, requires a modified strike

plate to the head of the door leaf and an auxiliary UDM roller latch.

8. Abloy EL414 (fail locked) installed in the frame head, requires a modified strike plate

to the head of the door leaf but does not require auxiliary latching and may not meet

egress requirements.

9. Power-To-Lock (PTL) with supplementary latching. Power-To-Open (PTO) can be sole

latching device

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 16

Datasheet: E02

Date: 3-03-08

17. DOOR OPERATORS

Make Type Notes Max. Rating

Abloy DA361 swing door operator 1 VP120

Ditec Transit UE 2 VP60

Ditec Wel E 2 VP60

Dorma CD80 Door Operator 3 VP240

Dorma ED200 Door Operator 4 VP240

Dorma ED800 Door Operator 4 VP240

LCN 4611, 4622 autoequaliser 5 VP120

LCN 4630 / 4640 autoequaliser 6 VP240

LCN 4820 auto equaliser door operator 7 VP120

Lockwood 8002 series, transom mounted VP240

Notes: 1. Modifications to installation are required – contact distributor www.levco.co.nz.

Local fire or smoke detection is required either side of doors.

2. In timber-framed door only. Modifications are required to the standard installation - a

fire door package is available from the distributor www.doormaticsnz.co.nz.

Local fire or smoke detection is required either side of doors.

3. Transom mounted; fitted to a steel plate, or with long screws into lintel

4. Special conditions apply for fixing this closer. Closer may only use standard arm and

may only be mounted on the push side of the leaf. Operator must revert to closer in

the event of fire exposure

5. Modifications to installation required. Autoequaliser must revert to self-closure on

local detection of smoke or heat from fire.

6. Modification of operator to include steel mounting plate is required

7. Latching of door leaf must prevent inadvertent operation of opener during fire

exposure.

18. VIEWING LENSES

Make Type Notes Max.Rating

ABUS 2200 VP240

Chubb 8V001, WS8, WS13 VP120

Chubb WS9 VP60

Doorscope DS-1000 1 VP60 [PDS]

ERA VP240

Hafele 959.06.002 and .008 VP240

HH Model B-03 VP240

Hotel Gong system VP240

Lane Model 006 VP240

Lockwood 160 Security Door Viewer VP240

Nikon 2200, 2180, 2170, 2160 VP240

Pyropanel Panaramic VP120

Schlage DV004 VP240

Yank Models 2160, 2170, 2180, 2200 VP240

Note: 1. Special factory fitting methods are required for the Doorscope DS-1000.

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 17

Datasheet: E02

Date: 3-03-08

19. DOOR EDGE SEALS

Make Code Max. Rating

Firepro FP1212 VP240

Firepro FP1515 VP240

Lorient FDBU20 Intumescent sill seals VP240

Lorient HP4002 intumescent perimeter seal VP240

Lorient IS7010si VP240

Lorient IS7020si VP240

Lorient IS7025si VP240

Lorient IS7080si VP240

Lorient IS7085si VP240

Lorient IS8010si VP240

Lorient IS8011si VP240

Lorient IS8020si VP240

Lorient IS8085si VP240

Lorient IS8090si VP240

Lorient IS8091si VP240

Lorient LE1212 VP240

Lorient LE1515 VP240

Pacific Door Systems Acoustic Compression Seal (bottom edge) VP60 [PDS]

Pyropanel Euroseal VP120 [PDS]

Pacific Door Systems PFS-3 VP240 [PDS]

Pacific Door Systems TP390 VP60 [PDS]

Raven RP4T VP240

Raven RP8 VP240 [PDS]

Raven RP10 & RP10Si VP240

Raven RP23 VP240

Raven RP24 VP240

Raven RP25 VP240

Raven RP38 & RP38Si (rebated or surface-fixed) VP240 [PDS]

Raven RP39 VP240

Raven RP60 VP240

Raven RP78 and RP78Si VP240

Raven RP93Si VP240

Raven RP99Si VP240 [PDS]

Raven RP114 Sill gap seal VP240

Raven RP120 VP240

Raven RP150 VP240

HARDWARE LIST – Pyropanel Fire Doors

© 2008 Pacific Door Systems Ltd 18

Datasheet: E02

Date: 3-03-08

20. FIRE RESISTANT GLAZING

Make Maximum Specification with Integrity Rating Insulation

Rating

DTI Film Overlay FW60/VP240 - [PDS]

NEG Firelite VP30 / FW30-1 / FW30-2 / VP60 / FW60 - [PDS]

Georgian Wired VP120 / FW60 / FW30-1 / FW30-2 - [PDS]

Georgian Wired Clear

Laminated Float

VP30 / FW30-2 - [PDS]

Schott Robax VP240 / FW30-1 / FW30-2 - [PDS]

Schott Pyran VP120 / FW30-1 / FW30-2 - [PDS]

Schott Vycor VP240 - [PDS]

Pyroceram VP240 / FW60 / FW120 - [PDS]

Pyrobel 16 FW30-1 / VP30 / VP60 30 [PDS]

Restrictions: Datasheets for FW30-1 and FW30-2 should be consulted for further information on

approved glazing
